Search Results (50)

This paper presents internal flow measurements in two shape-transitioning nozzle ducts using planar Particle Image Velocimetry (PIV). Nozzle 1 is a converging nozzle transitioning from a square cross-section to a rectangular exit with an equivalent diameter ($D_e$) of 2.2 in, an exit aspect ratio of 6.68, and a length-to-diameter ratio ($L/D_e$) of 7.8. Nozzle 2 also converges globally but incorporates a diverging sidewall that introduces localized adverse pressure gradients. Both nozzles are tested at an exit Mach number of 0.2, corresponding to $R{e}_{D_e}\approx 2.50\times {10}^5$. Wall-normal velocity profiles reveal boundary layer thinning under favorable pressure gradients followed by thickening in regions of streamwise curvature and local adverse pressure gradients. In nozzle 2, the adverse streamwise pressure gradient along the diverging wall produces thicker boundary layers than in nozzle 1, while a cross-stream pressure imbalance shifts the velocity peak toward the diverging wall. Complementary steady RANS simulations using the k–$\omega$ SST turbulence model yield wall-normal velocity profile agreement within 2% mean absolute error for both nozzles in the upstream and mid-duct regions, with errors increasing toward the exit. Discharge coefficients from CFD and experiment agree within approximately 1%, with nozzle 1 exhibiting greater integrated losses than nozzle 2 despite thinner boundary layers at the measured plane, indicating a three-dimensional loss distribution. Independent pitot probe measurements at the nozzle exit confirm the PIV trends over the CFD predictions in the near-exit region. Full article

Integrating a heat exchanger (HEX) into the cooling duct of a high-power fuel-cell-based aircraft presents a critical trade-off between thermal performance and aerodynamic penalties. The present study addresses this challenge through the design and system-level analysis of a HEX integrated into the cooling duct. Developed as part of the Clean Aviation project FAME, the design features a rectangular inlet, a circular outlet, and a tilted HEX. The evaluation is performed using high-fidelity Large Eddy Simulations (LESs). The HEX is modeled with a porous media approach based on the Darcy–Forchheimer equation, while the simulations are carried out using a self-adapted version of the pisoFoam solver, termed pisoTempFoam, to account for heat transfer. The study reveals that while component-level design choices, such as a straight inlet and tilted HEX configuration, successfully mitigate local flow separation and duct-induced losses, a critical system-level performance issue emerges. The analysis demonstrates that the cooling duct design, when subjected to realistic operational conditions, generates the high pressure head to overcome the resistance of the HEX. The external aerodynamic analysis also indicates that the HEX resistance is a critical factor, and without overcoming it the system fails to capture the required air mass flow rate, compromising thermal management. The findings highlight the necessity to optimize the design, by an adapted duct shape or an auxiliary fan, to overcome the HEX-induced pressure drop. The porous media approach is thereby validated as an effective tool for rapid system-level design analysis, despite its inherent limitation in capturing detailed downstream turbulence. Full article

This study numerically investigates heat transfer and thermodynamic behavior in twisted square and rectangular air ducts while keeping a constant hydraulic diameter (D_h = 30 mm). Three aspect ratios are considered (AR = 1.00, 0.75, and 0.50). The heated test section (900 mm) is divided into three equal segments, and three pitch patterns are examined: a uniform pitch (400–400–400 mm, P444) and two axial gradients (300–400–500 mm, P345; 500–400–300 mm, P543). All results are compared to a standard reference, the straight square duct (SD-AR1.00), to ensure fair comparisons across all cases with Reynolds numbers between 5000 and 20,000. Among the twisted ducts, the strongest rectangularity combined with the increasing pitch sequence, TSD-AR0.50-P345, provides the best overall balance. Its heat transfer rises from Nu = 39.39 to 88.62, giving Nu/Nu₀ = 1.493 → 1.433, while the pressure penalty increases to f/f₀ = 1.345 → 1.405. Under cube-root weighting of friction, this case maintains the highest thermal performance factor, TPF = 1.352 at Re = 5000 and TPF = 1.279 at Re = 20,000. Second-law trends support the same ranking: exergy destruction decreases from 12.81 W (baseline) to 8.44 W at Re = 5000 (≈34% reduction) and from 6.54 W to 4.84 W at Re = 20,000 (≈26% reduction). The Bejan number remains high at low Reynolds numbers (≈0.998), indicating heat-transfer irreversibility dominance, but drops at higher Reynolds numbers (≈0.87) as frictional effects become more important. In general, the results show that adding a small axial pitch increase to rectangularity can improve near-wall mixing while reducing losses downstream. This leads to a clear improvement in both first-law performance and exergy-based measures. Full article

The breeding blanket is a key component of tokamaks, primarily responsible for extracting heat from fusion reactions and for tritium breeding, which is essential to ensure a fusion reactor’s fuel self-sufficiency. Recent technological advancements have led to the development of Dual-Cooled Lead–Lithium (DCLL) breeding blankets, which employ a liquid metal (specifically a Lead–Lithium eutectic alloy) as a heat transfer medium and tritium breeder, while helium gas is used to cool the structural components of the reactor. The interaction between the moving electrically conducting fluid and the strong magnetic field in the tokamak environment leads to magnetohydrodynamic (MHD) effects. The latter are characterized by the induction of eddy currents within the fluid and resulting Lorentz forces generated by their interaction with the magnetic field, which cause additional pressure losses and reduce heat transfer efficiency. This work investigates the pressure drop experienced by a Lead–Lithium flow within a rectangular section conduit under the action of an external, uniform magnetic field of different intensities. An analytical model was developed to estimate the total MHD-induced pressure losses along the channel for different values of the external magnetic field intensity and then benchmarked against relative computational fluid dynamics (CFD) simulations carried out using COMSOL Multiphysics. This comparison allowed the validation of the analytical predictions as well as a better understanding of the influence of the applied magnetic field intensity on the overall pressure drop. Therefore, the aim of the analytical model is to provide analytical tools for reasonably accurate estimations of MHD pressure losses suitable for future preliminary design purposes. Full article

Binary mixtures of HFE-73DE and ethyl acetate are investigated as dielectric working fluids for laminar minichannel cooling. Thermophysical properties of the pure components and four mixtures (10/90, 25/75, 50/50 and 75/25 mass % HFE-73DE/ethyl acetate) were measured over the relevant temperature range. Single-phase convective heat transfer tests were then carried out in a heated 1 × 4 × 180 mm minichannel test section under constant heat-flux conditions for pure HFE-73DE. A three-dimensional conjugate CFD model with temperature-dependent liquid properties was developed in Simcenter STAR-CCM+ and validated against these measurements; the average relative temperature difference between CFD and experiment remained below 0.5%, while a grid-convergence study based on the Grid Convergence Index (GCI) confirmed that the numerical uncertainty is comparable to the experimental one. The validated model was subsequently used to predict the axial evolution of wall temperature, fluid-core temperature, velocity and heat transfer coefficient for the four mixtures under identical conditions. The mean Nusselt numbers obtained from CFD were further compared with the classical Shah and London fully developed laminar solution for rectangular ducts, revealing that the present configuration yields values about 35–42% higher than the theoretical prediction owing to asymmetric heating and conjugate heat transfer. The results show that increasing the HFE-73DE mass fraction strengthens convective heat transfer and reduces fluid-temperature rise, while intermediate compositions (50/50 and 75/25) provide a favourable compromise between enhanced heat transfer performance and moderate pressure drop. The study provides guidance for composition selection and the design of dielectric minichannel heat exchangers operating with HFE-73DE/ethyl acetate mixtures. Full article

The ventilation system is one of the most important elements of a building for the appropriate insurance of indoor climate parameters. Nowadays, textile ventilation systems are increasingly being used as a solution for low-energy buildings. Greater air movement and distribution in ventilation systems often leads to one of the most noticeable issues for people—increased noise in the indoor environment. One of the solutions is to use noise reducing diffusers. The aim of this research was to design and test a diffuser that fulfills noise regulations, would be light (weight less than 3 kg), be able to flexibly change geometry and have a design that harmonizes with the interior design, could be easily installed into a suspended ceiling, have a simple connection to the ventilation duct and be able to be effortlessly removed for maintenance, and be sustainable (usage of recycled materials). Three types of diffusers were created according to set characteristics and tested. The test results showed that the aim of the research was achieved—the emitted noise levels are below the regulation’s required level of less than 45 dBA. Also, it is light—the weight is 1.7 kg and 2.8 kg, respectively, for square and rectangular diffusers; has a flexible construction and design; is made from recycled materials. Full article

This study presents a novel framework for uncertainty propagation in power-law, Bingham, and Casson fluids through rectangular ducts under stochastic viscosity (Case I) and pressure gradient conditions (Case II). Using the computationally efficient Stochastic Finite Difference Method with Homogeneous Chaos (SFDHC), validated via comparison with quasi-Monte Carlo simulations, we demonstrate significantly lower computational costs across varying Coefficients of Variation (COVs). For viscosity uncertainty (Case I), results show a 0.54–2.8% increase in mean maximum velocity with standard deviations reaching 75.3–82.5% of the COV, where the power-law model exhibits the greatest sensitivity (velocity variations spanning 71.2–177.3% of the mean at COV = 20%). Pressure gradient uncertainty (Case II) preserves mean velocities but produces narrower and symmetric distributions. We systematically evaluate the effects of aspect ratio, yield stress, and flow behavior index on the stochastic velocity response of each fluid. Moreover, our analysis pioneers a performance hierarchy: Herschel–Bulkley fluids show the highest mean and standard deviation of maximum velocity, followed by power-law, Robertson–Stiff, Bingham, and Casson models. A key finding is the extreme fluctuation of the Robertson–Stiff model, which exhibits the most drastic deviations, reaching up to 177% of the average velocity. The significance of fluid-specific stochastic analysis in duct system design is underscored by these results. This is especially critical for non-Newtonian flows, where system performance and reliability are greatly impacted by uncertainties in viscosity and pressure gradient, which reflect actual operational variations. Full article

This study investigates the impact of nanofluids (TiO₂, Fe₃O₄, Al₂O₃, and graphene) on thermoelectric power generation within a rectangular heat exchanger equipped with internal winglets. The integration of internal winglets in heat exchangers, alongside the use of nanofluids, is a recent strategy aimed at enhancing convective heat transfer. This numerical research analyzes fluid dynamics and temperature variations on both the cold and hot sides of the thermoelectric generator (TEG). Three different heat exchanger models are evaluated: the first model features a pair of winglets in both ducts; the second model only has winglets in the hot duct; and the third model does not include any winglets. The performance of the nanofluids is systematically compared with that of distilled water. The results show that the Al₂O₃ nanofluid produces the highest power output at 7.8461 watts, which is 1.5% greater than that of TiO₂ and 1.22% higher than distilled water. Moreover, using Al₂O₃ in a heat exchanger with winglets in both ducts results in a 5% increase in power generation compared to a configuration without winglets and a 2% improvement over a model that has winglets only in the hot duct. This enhancement can be attributed to an increased heat transfer area and improved fluid mixing, which together facilitate more effective heat transfer to TEG. Full article

Aircraft, as electromagnetically complex targets, have radar cross-sections (RCSs) that are influenced by various factors, with the inlet duct being a critical component that often serves as a primary source of electromagnetic scattering, significantly impacting the scattering characteristics. In light of the conflict between aerodynamic performance and electromagnetic characteristics in the design of aircraft engine inlet grilles, this paper proposes a metasurface radar-absorbing inlet grille (RIG) solution based on a NACA symmetric airfoil. The RIG adopts a sandwich structure consisting of a polyethylene terephthalate (PET) dielectric substrate, a copper zigzag metal strip array, and an indium tin oxide (ITO) resistive film. By leveraging the principles of surface plasmon polaritons, electromagnetic wave absorption can be achieved. To enhance the design efficiency, a multi-objective Bayesian optimization framework driven by the expected hypervolume improvement (EHVI) is constructed. The results show that, compared with a conventional rectangular cross-section grille, an airfoil-shaped grille under the same constraints will reduce both aerodynamic losses and the absorption bandwidth. After 100-step EHVI–Bayesian optimization, the optimized balanced model attains a 57.79% reduction in aerodynamic loss relative to the rectangular-shaped grille, while its absorption bandwidth increases by 111.99%. The RCS exhibits a reduction of over 8.77 dBsm in the high-frequency band. These results confirm that the proposed optimization design process can effectively balance the conflict between aerodynamic performance and stealth performance for RIGs, reducing the signal strength of aircraft engine inlets. Full article

This study presents an innovative approach to quantifying uncertainty in Herschel–Bulkley (H-B) fluid flow through rectangular ducts, analyzing four scenarios: uncertain apparent viscosity (Case I), uncertain pressure gradient (Case II), uncertain boundary conditions (Case III) and uncertain apparent viscosity and pressure gradient (Case IV). Using the stochastic finite difference with homogeneous chaos (SFDHC) method, we produce probability density functions (PDFs) of fluid velocity with exceptional computational efficiency (243 times faster), matching the accuracy of Monte Carlo simulation (MCS). Key statistics and maximum velocity PDFs are tabulated and visualized for each case. Mean velocity shows minimal variation in Cases I, III, and IV, but maximum velocity fluctuates significantly in Case I (63.95–187.45% of mean), Case II (50.15–156.68%), and Case IV (63.70–185.53% of mean), vital for duct design and analysis. Examining the effects of different parameters, the SFDHC method’s rapid convergence reveals the fluid behavior index as the primary driver of maximum stochastic velocity, followed by aspect ratio and yield stress. These findings enhance applications in drilling fluid management, biomedical modeling (e.g., blood flow in vascular networks), and industrial processes involving non-Newtonian fluids, such as paints and slurries, providing a robust tool for advancing understanding and managing uncertainty in complex fluid dynamics. Full article

In various practical noise control scenarios, such as duct noise mitigation, industrial machinery, architectural acoustics, and underwater applications, it is essential to develop noise absorbers that deliver effective low-frequency attenuation while maintaining compact dimensions. To achieve low-frequency absorption within a limited spatial volume, this study proposes an embedded Helmholtz resonator featuring a roughened neck and establishes a numerical computational model that incorporates thermos viscous effects. A quantitative investigation is conducted on three types of embedded rough-neck geometries (rectangular-grooved, triangular-grooved, and undulated) to elucidate their acoustic performance, with particular attention to differences in acoustic transmission loss and acoustic impedance characteristics. In response to the practical demand for even lower-frequency attenuation, this work further focuses on optimizing the structural parameters of an embedded rectangular-grooved Helmholtz resonator (ERHR). A back-propagation (BP) neural network models and predicts how structural parameters impact the acoustic transmission coefficient, elucidating the effects of geometric variations. Moreover, by coupling the BP network with the Golden Jackal Optimization (GJO) algorithm, a BP-GJO optimization model is developed to refine the structural parameters. The findings reveal that the proposed method significantly improves resonator spatial utilization at a specific noise frequency while preserving acoustic transmission loss performance. This work thereby provides a promising strategy for designing low-frequency, compact Helmholtz resonators suitable for a wide range of noise control applications. Full article

Emphasizing the importance of acoustic attenuation in maintaining compliance with stringent noise regulations and enhancing workplace safety, this analysis covers theoretical and practical aspects of prediction methods used for the development of sound attenuators for gas-turbine testing stands. This paper presents a preliminary analysis and evaluation of the improvement of the Embleton method for projecting a noise attenuator for industrial applications, especially for gas-turbine test stands. While primarily focusing on the static acoustic behavior of the attenuator, certain considerations were also made regarding flow conditions, Mach number-dependent attenuation, pressure drop, and self-generated noise aspects to provide a comprehensive perspective on applying a suitable evaluation method. The study investigates different calculation methods for the assessment of noise reduction for linear and staggered baffles applied on a scaled reduced model of an attenuator. Thus, the critical parameters and development requirements necessary for effective noise reduction in high-performance gas-turbine testing environments will be evaluated in a downscaled model. Key factors examined include the selection of design parameters and configurations from various topological options (single, double, and triple parallel baffles vs. double and triple staggered baffles). Advanced computational methods, like analytic and finite-element analysis (FEM), are used to predict acoustic performance and evaluate the prediction method. Experimental validation is performed to corroborate the simulation results, ensuring the reliability and efficiency of the attenuator. The results indicate that an improved prediction method led to a better design for a sound-attenuator module, which can significantly reduce noise levels without compromising the operational performance of the gas turbine inside a test cell. Full article

In this study, we introduced a new type of basis function and subsequently a Chebyshev delta shaped collocation method (CDSC). We then use this method to numerically investigate both the natural convective flow and heat transfer of nanofluids in a vertical rectangular duct on the basis of a Darcy–Brinkman–Forchheimer model and the electroosmosis-modulated Darcy–Forchheimer flow of Casson nanofluid over stretching sheets with Newtonian heating problems. The approximate solution is represented in terms of Chebyshev delta shaped basis functions. Novel error estimates for interpolating polynomials are derived. Computational experiments were carried out to corroborate the theoretical results and to compare the present method with the existing Chebyshev pseudospectral method. To demonstrate our proposed approach, we also compared the numerical solutions with analytic solutions of the Poisson equation. Computer simulations show that the proposed method is computationally cheap, fast, and spectrally accurate and more importantly the obtained approximate solution can easily be used by researchers in this field. Full article

Peristaltic flow in a straight rectangular duct is examined imposed by contraction pulses implemented by pairs of horizontal cylindrical segments with their axes perpendicular to the flow direction. The wave propagation speed is considered in such a range that triggers a laminar fluid motion. The setting is analyzed over a set of variables which includes the propagation speed, the relative occlusion, the modality of the squeezing pulse profile and the Carreau power index. The numerical solution of the equations of motion on Cartesian meshes is grounded in the immersed boundary method. An increase in the peristaltic pulse modality leads to the reduction in the shear rate levels on the central tube axis and to the movement of the peristaltic characteristics to higher pressure values. The effect of the no slip side walls (NSSWs) is elucidated by the collation with relevant results for the flow field produced under the same assumptions though with slip side walls (SSWs). Shear thinning behavior exhibits a significantly larger effect on transport efficiency for the NSSWs duct than on the SSWs duct. Full article

In this paper, the thermo-optical performance using novel cooling strategy improvements for a hybrid photovoltaic/parabolic dish concentrator with a conical thermal receiver using a beam splitter filter (PV/PDC-CTR-BSF) is investigated. The study’s main goal is to improve the cooling effectiveness of the serpentine-shaped cooling duct by investigating the effect of the cross-section shape and positioning of the cooling duct under the PV panel. Typical cooling pipes have either a rectangular or circular cross-section and are usually attached to the back sheet of the PV panel using off-the-shelf adhesives that have very low thermal conductivity. With the advent of 3D printing technology, the back sheets could be 3D-printed with integral cooling ducts of different cross-sections at different locations and orientations within the back sheet that allow for increased heat transfer from the back sheet and thus improve PV/PDC-CTR-BSF’s thermos-optical performance. For this purpose, the study investigates and compares the thermal performance of four different cooling duct cross-sections that include: rectangular, semi-circular, semi-elliptical and triangular. For each of the cooling duct cross-sections, several positions and orientations, which include flush below the back sheet layer and embedded inside the back sheet but positioned at the bottom, middle and top of the back sheet, are examined. Numerical simulations using the commercial software ANSYS FLUENT(R2019) are performed to assess the performance of the cooling ducts and, in turn, the thermo-optical performance of the PV/PDC-CTR-BSF system. The semi-elliptical cross-section duct embedded in the middle of the back sheet was found to yield the best cooling performance since its rate of heat removal from the PV back sheet was found to be the highest. Full article
