During the marine transport of liquid hydrogen, heat ingress leads to the generation of boil-off gas (BOG), which increases the pressure in the liquid hydrogen storage tanks. Effective BOG management is therefore essential to ensure tank safety and minimize hydrogen loss. This study develops a cryogenic compression recovery and storage system for BOG generated during the marine transport of 160,000 m³ liquid hydrogen. The core process involves compressing a portion of the BOG and subsequently utilizing the BOG’s inherent cold energy to cool the compressed hydrogen, ultimately enabling the storage of the final cryogenic compressed hydrogen product. ASPEN-PLUS software was employed to analyze the proposed system’s specific energy consumption (SEC) and ψ (hydrogen density/SEC) for producing cryogenic compressed hydrogen (CcH₂) across a temperature range of 53 to 110 K and a pressure range of 40 to 100 MPa. Seven optimal sets of state parameters were identified for the cryogenic compressed hydrogen product. Based on a specified optimal parameter set of 80 K and 50 MPa, a simulation of the proposed system’s performance yielded a SEC of 2.25 kWh/kg CcH₂ and an exergy efficiency of 87.88% with BOG feed at 53 K and 0.1 MPa, along with the exergy loss and exergy efficiency for each component. Compared to a BOG re-liquefaction system and a MRJT CcH₂ system under identical conditions, the proposed system achieves 31.81% and 64.9% reduction, respectively, in SEC and 17.32% and 94.6% improvement, respectively, in exergy efficiency. Furthermore, the effects of feed temperature and cryogenic compressed hydrogen product mass flow rate on the proposed system’s SEC and exergy efficiency were investigated. Full article

This study proposes a CO₂ re-liquefaction system utilizing the cold energy of LNG and liquid hydrogen (LH₂) to efficiently manage boil-off gas in alternative fuel-based CO₂ carriers. Process simulations using Aspen HYSYS V11 under 100% and 70% propulsion loads evaluated the Specific Energy Consumption (SEC), Coefficient of Performance (COP), UA of heat exchangers, and Specific Life Cycle Cost (SLCC). The results demonstrate that under both 100% and 70% propulsion load conditions, the utilization of cold energy decreases the SEC by 24.5% and improves the COP by approximately 34% compared to the reference model without cold energy utilization. Sensitivity analysis on the minimum temperature approach indicates limited impact on performance. The UA of the heat exchangers decreased by up to 83% (LNG) and 87% (LH₂), offering significant downsizing advantages. Economically, SLCC was reduced by up to 14.8% and 15.9% for the LNG and H₂ models, respectively, due to lower Capital Expenditure (CAPEX) and Operating Expenditure (OPEX). Consequently, this study demonstrates that exploiting the cold energy of alternative fuels significantly improves both the thermodynamic performance and economic feasibility of CO₂ re-liquefaction systems, providing foundational data for future optimization. Full article

This study presents an integrated, open-source process simulation for converting agricultural biogas into high-purity liquid hydrogen using DWSIM (Distillation, Water, Separation and Inorganic Modules), an open-source sequential-modular simulator. The model simulates a farm-scale biogas feed and is optimised to enhance liquid hydrogen yield while reducing specific energy consumption under set operating conditions. The proposed model links biogas upgrading via dual pressure swing adsorption, steam–methane reforming, two-stage water–gas shift, hydrogen purification, and cryogenic liquefaction within a single optimisation framework. Using a representative farm-scale feed (103.7 kg h⁻¹ biogas containing 60 mol% CH₄), the optimised process produces 16.5 kg h⁻¹ of liquid hydrogen with 99.2% para-hydrogen purity while simultaneously capturing 104 kg h⁻¹ of CO₂ at 98% purity and 16 bar. Optimal operating conditions include SMR at 909 °C and 16 bar with a steam-to-carbon ratio of 3.0, followed by high- and low-temperature water–gas shifts at 413 °C and 210 °C, respectively. The overall cold-gas efficiency (LHV basis, excluding liquefaction electricity) reaches 78%, and the specific electricity demand for liquefaction is 32.4 kWh per kg of liquid hydrogen, which is consistent with reported values for small-scale hydrogen liquefiers. Sensitivity analysis over a methane content range of 40–75% confirms near-linear scalability of hydrogen output (R² = 0.998), demonstrating feedstock flexibility without re-parameterisation. The developed process in this work provides a transparent and extensible digital twin for early-stage design and optimisation of decentralised biogas-to-hydrogen systems. Using the open-source DWSIM platform ensures full transparency, reproducibility, and accessibility compared with proprietary simulators. Full article

The increasing share of renewable energy sources (RES) in modern power systems necessitates the development of efficient, large-scale energy storage technologies capable of mitigating generation variability. Liquid Air Energy Storage (LAES), particularly in its adiabatic form, has emerged as a promising candidate by leveraging thermal energy storage and high-pressure air liquefaction and regasification processes. Although LAES has been widely studied, the impact of ambient temperature on its performance remains insufficiently explored. This study addresses that gap by examining the thermodynamic response of an adiabatic LAES system under varying ambient air temperatures, ranging from 0 °C to 35 °C. A detailed mathematical model was developed and implemented in Aspen Hysys to simulate the system, incorporating dual refrigeration loops (methanol and propane), thermal oil intercooling, and multi-stage compression/expansion. Simulations were conducted for a reference charging power of 42.4 MW at 15 °C. The influence of external temperature was evaluated on key parameters including mass flow rate, unit energy consumption during liquefaction, energy recovery during expansion, and round-trip efficiency. Results indicate that ambient temperature has a marginal effect on overall LAES performance. Round-trip efficiency varied by only ±0.1% across the temperature spectrum, remaining around 58.3%. Mass flow rates and power output varied slightly, with changes in discharging power attributed to temperature-driven improvements in expansion process efficiency. These findings suggest that LAES installations can operate reliably across diverse climate zones with negligible performance loss, reinforcing their suitability for global deployment in grid-scale energy storage applications. Full article

Liquid hydrogen is regarded as a key energy source and propellant for lunar bases due to its high energy density and abundance of polar water ice resources. However, its low boiling point and high latent heat of vaporization pose severe challenges for storage and management under the extreme lunar environment characterized by wide temperature variations, low pressure, and low gravity. This paper reviews the strategies for siting and deployment of liquid hydrogen storage systems on the Moon and the technical challenges posed by the lunar environment, with particular attention for thermal management technologies. Passive technologies include advanced insulation materials, thermal shielding, gas-cooled shielding layers, ortho-para hydrogen conversion, and passive venting, which optimize insulation performance and structural design to effectively reduce evaporation losses and maintain storage stability. Active technologies, such as cryogenic fluid mixing, thermodynamic venting, and refrigeration systems, dynamically regulate heat transfer and pressure variations within storage tanks, further enhancing storage efficiency and system reliability. In addition, this paper explores boil-off hydrogen recovery and reutilization strategies for liquid hydrogen, including hydrogen reliquefaction, mechanical, and non-mechanical compression. By recycling vaporized hydrogen, these strategies reduce resource waste and support the sustainable development of energy systems for lunar bases. In conclusion, this paper systematically evaluates passive and active thermal management technologies as well as vapor recovery strategies along with their technical adaptability, and then proposes feasible storage designs for the lunar environment. These efforts provide critical theoretical foundations and technical references for achieving safe and efficient storage of liquid hydrogen and energy self-sufficiency in lunar bases. Full article

Recent research in the liquefied natural gas (LNG) industry has concentrated on reducing specific power consumption (SPC) during production, which helps to lower operating costs and decrease the carbon footprint. Although reducing the SPC offers benefits, it can complicate the system and increase investment costs. This review investigates the thermodynamic parameters of various natural gas (NG) liquefaction technologies. It examines the cryogenic NG processes, including integrating NG liquid recovery plants, nitrogen rejection cycles, helium recovery units, and LNG facilities. It explores various approaches to improve hybrid NG liquefaction performance, including the application of optimization algorithms, mixed refrigerant units, absorption refrigeration cycles, diffusion–absorption refrigeration systems, auto-cascade absorption refrigeration processes, thermoelectric generator plants, liquid air cold recovery units, ejector refrigeration cycles, and the integration of renewable energy sources and waste heat. The review evaluates the economic aspects of hybrid LNG systems, focusing on specific capital costs, LNG pricing, and capacity. LNG capital cost estimates from academic sources (173.2–1184 USD/TPA) are lower than those in technical reports (486.7–3839 USD/TPA). LNG prices in research studies (0.2–0.45 USD/kg, 2024) are lower than in technical reports (0.3–0.7 USD/kg), based on 2024 data. Also, this review investigates LNG accidents in detail and provides valuable insights into safety protocols, risk management strategies, and the overall resilience of LNG operations in the face of potential hazards. A detailed evaluation of LNG plants built in recent years is provided, focusing on technological advancements, operational efficiency, and safety measures. Moreover, this study investigates LNG ports in the United States, examining their infrastructures, regulatory compliance, and strategic role in the global LNG supply chain. In addition, it outlines LNG’s current status and future outlook, focusing on key industry trends. Finally, it presents a market share analysis that examines LNG distribution by export, import, re-loading, and receiving markets. Full article

In this study, cargo boil-off gas (BOG) re-liquefaction systems for ammonia-fueled liquefied carbon dioxide (LCO₂) carriers were analyzed. These systems use cold energy from ammonia to reliquefy the CO₂ BOG. In this study, a system that can completely reliquefy the CO₂ BOG at all engine loads using only one heat exchanger is proposed, instead of the existing cascade system that requires multiple components. R744, which has a low global warming potential, was used as the working fluid for the refrigeration cycle in the CO₂ BOG re-liquefaction system. The organic Rankine cycle (ORC) was used to reduce the net power consumption of the system. The existing and proposed systems were classified into Case 1 (existing system), Case 2 (our proposed system), and Case 3 (Case 2 combined with an ORC). Thermodynamic and economic analyses were conducted. Case 2 is a system with a simpler configuration than Case 1, but it has a similar thermodynamic performance. Case 3 has a higher exergy destruction rate than Cases 1 and 2, owing to the ORC, but it can significantly reduce the net power consumption. The economic analysis shows that Cases 2 and 3 reduce the total annual costs by 17.4% and 20.1%, respectively, compared to Case 1. The proposed systems are significantly more advantageous for long-term operation than existing systems. Full article

To prevent critical failure of the functional machinery of a ship, condition monitoring technologies have been much studied in recent times. In this respect, securing a fault database is a top priority in technology development. In this paper, we developed a test bed that simulates the LNG (liquefied natural gas) re-liquefaction system installed on LNG carriers to obtain data in various types of faults of ship machinery. To maintain rotor-dynamics characteristics, the structure was scaled based on the critical speed margin of the dynamic system. The developed test bed includes a gearbox and multiple shafts. It can simulate mass imbalance, misalignment, bearing fault, gear fault and impeller fault. To verify the validity of the vibration data obtained from the developed test bed, experiments were conducted on three fault modes: main shaft imbalance, pinion shaft imbalance, and gear fault. The time series data and FFT results were analyzed, and time domain features were extracted and statistically validated. Additionally, a simple diagnosis model was developed using the acquired data to evaluate its performance. The test data show distinct data with respect to fault conditions, and we can expect that the diagnosis algorithm can be developed using the test data. The developed test bed can provide not only for the fault data of a single component of the rotating machine but also for the combined fault data of the total system. In addition, we expect that it will solve the problem of securing fault data in the development of condition diagnosis technology if reliability is verified by identifying correlations by comparing data from the real system and data from the scaled test bed. Full article

This study proposes a feasible solution for boil-off gas (BOG) treatment to facilitate NH₃ fuel use by ocean-going ships, which is currently considered an alternative fuel for ships. Two systems were designed and analyzed for BOG in IMO Type-A NH₃ fuel storage tanks for 14,000 TEU container ships. First, BOG lost inside the storage tank minimized economic losses through the onboard re-liquefaction system. The total energy consumed by the system to process NH₃ gas generated in the fuel tank at 232.4 kg/h was 51.9 kW, and the specific energy consumption (SEC) was 0.223 kWh/kg. Second, NH₃ was supplied to the direct Low-Pressure Selective Catalytic Reduction (LP-SCR) system to treat marine pollutants generated by combustion engines. The feasible design point was determined by calculating the NH₃ feed flow rate using three methodologies. The energy consumed by the direct LP-SCR system was 3.89 and 2.39 kW, and the SEC was 0.0144 at 0.0167 kWh/kg at 100% and 25% load, respectively. The feasibility was indicated via economic analysis. Depending on the life cycle cost, the competitiveness of the re-liquefaction system depends on the price of NH₃, where a higher price yields a more economical solution. In conclusion, the direct LP-SCR system has a low overall cost because of its low energy consumption when supplying NH₃ and its reduced amount of core equipment. Full article

Liquefied natural gas (LNG)-fueled ships have the effect of reducing most pollutants, which is advantageous for responding to strict regulations. Because boil-off gas (BOG) is generated in the LNG storage tank of an LNG-fueled ship, a BOG re-liquefaction system is required. The representative systems for LNG-fueled ships were proposed by Kwak and Shen, but their exergy efficiencies were only 19.6% and 24.9%, respectively. To improve the system, this paper proposes novel BOG re-liquefaction systems combined with the fuel gas supply system. The systems utilize LNG cold energy in the BOG stream and N₂ reverse Brayton cycle, respectively. The proposed systems were simulated using a commercial program and were optimized using a genetic algorithm. The results of energy, exergy, and economic (3E) analyses performed for comprehensive evaluation of the proposed system show that the system in which LNG cold energy is applied to the BOG stream has the best performance. Specific energy consumption, exergy efficiency, and total annual costs of this system were improved by up to 78.6%, 69.2%, and 68.2%, respectively, compared to those of the existing systems. The overwhelmingly superior system is expected to greatly contribute to the improvement of the BOG re-liquefaction system for LNG-fueled ships. Full article

In this study, a boil-off gas reliquefaction system that is a part of liquid ethylene gas (LEG) carriers is evaluated. The reliquefaction system is formed by two thermally interconnected two-stage refrigeration cycles. The working fluid of the bottoming cycle is ethylene; the working fluid of the topping cycle is propylene. The research is based on determining the irreversibilities in the reliquefaction system cycles using the entropy-cycle method of thermodynamic analysis. The impact of the process performance in the main components on the reliquefaction system energy efficiency has been evaluated by the entropy-cycle method. The greatest thermodynamic irreversibility is observed in the two-stage compression process of the bottoming cycle (9%), total throttling irreversibility in the reliquefaction system (8.5%), and vapor superheating at the suction into the low stage of the two-stage compressor of the bottoming cycle (8%). The results of the study showed that it is necessary to improve the design of expansion devices using the replacement of throttle devices with ejectors when designing cascade ethylene reliquefaction plants. In addition, when operating such systems much attention should be paid to the condition of the insulation of cargo pipelines and the parameters of the cooling system of the cargo compressor. Full article

This study analysed a novel re-liquefaction system integrated with a fuel supply system (FSS) for an LPG carrier to conventional systems. The re-liquefaction system and FSS were installed independently in a conventional LPG carrier, while those systems were combined in the novel system. The condensed LPG in the re-liquefaction system was directly transferred to the FSS without the cooling and expansion process in the novel system. 84,000 m³ LPG carrier equipped with a 10 MW engine at normal continuous rating (NCR) was selected as a target ship. Aspen HYSYS ver.12.1 was employed for process simulation. The results showed that the energy consumption for the novel system was reduced by 38%. The energy for re-liquefaction was decreased because the flow rate recirculated was decreased, and the energy for FSS was reduced as the temperature of the stream supplied to the FSS was relatively high in the novel system. A sensitivity analysis was conducted to investigate the effect of the parameters on the results. The investigated parameters were LPG compositions, seawater temperature, compressor efficiency, and pump efficiency. The energy consumption for the system was significantly different depending on the LPG composition, and the energy consumption was changed by 2.5% for conventional systems and 0.9% for the novel systems with the variation of 4 °C seawater temperature. The energy for the novel system was reduced by 2.8% for conventional systems and 2.3% for the novel systems with the 5% increment of compressor efficiency, whereas pump efficiency had little effect on the results. Full article

This study proposed the integrated design of an NH₃ fuel supply system and a re-liquefaction system for an ocean-going NH₃-fueled ship. The target ship was a 14,000 TEU large container ship traveling from Asia to Europe. The NH₃ fuel supply system was developed to feed the liquid fuel at 40 °C and 80 bar and cope with the re-circulated fuel with the sealing oil. Its power consumptions and SECs ranged from 56.4 to 157.5 kW and from 0.0063 to 0.009 kWh/kg, respectively. An onboard re-liquefaction system with a vapor compression refrigeration cycle was also designed to liquefy the BOG from the fuel tank. The re-liquefaction system’s exergy efficiency and SEC were 34.71% and 0.224 kWh/kg, respectively. The equipment with the most exergy destruction was the heat exchangers, accounting for 60% of the total exergy destruction. NPV analysis found that it is recommended to introduce the re-liquefaction system to the target ship. At the NH₃ price of USD 250/ton, the reasonable cost of the re-liquefaction system is less than USD 1 million. According to LCC, NH₃ fuel is economically feasible if the carbon tax is more than USD 80/ton and the NH₃ price is around USD 250/ton. Full article

The present study is an analysis of the processes in the components of the LPG (propane/butane) reliquefaction plant under the conditions of co-mingling in tanks when transporting by sea. For the analysis, the monitoring data of an LPG cargo operation have been used. An energy analysis of the mixture-based reliquefaction plant has been performed. The characteristics of the mixture in the tanks, the operating conditions of the reliquefaction plant, and the performance of the system have been considered. The method of equivalence has been applied for thermodynamic analysis. The result of the substitution of actual processes with equivalent ones allows for the accomplishment of the parameters control of each working fluid within the mixture as a pure working fluid. It is shown that the low-boiling component determines the operating parameters of the entire reliquefaction plant. The method of equivalence and visualization of the processes within the LPG as a mixture using the thermodynamic diagrams of pure working fluids is recommended to shorten the path to set up the appropriate reliquefaction plant management strategy. The energy analysis performed using the method of equivalent cycles has been validated with the existing reliquefaction plant characteristics. The inaccuracies are in the limit of 4%. Full article

More and more applications, such as natural gas liquefaction, LNG reliquefaction, whole body cryotherapy and cryopreservation, require cooling in the temperature range from 110 to 150 K. This can be achieved in systems using standard refrigeration compressors, which are reliable and cost-effective, but are subject to certain operating limits. This paper investigates the potential of a three-stage cascaded refrigeration system based on standard refrigeration compressors in this range of temperatures. The investigation takes into account the vital limitations of refrigeration compressors and aims to look for possible refrigerant configurations (taking into account PFCs, HFCs, HCs and HOs); performance limitations such as cooling power temperature and system COP; and the influences of system architecture (single-stage and two-stage compression). The paper investigates whether it is possible to design a three-stage cascaded refrigeration system using standard refrigeration compressors, and if so, at what cost? This investigation shows that the three-stage cascaded refrigeration system can reach the lowest temperature of 127 K with a COP of 0.179, which corresponds to a Carnot efficiency of 0.262. Moreover, systems based on natural refrigerants are found to be advantageous in terms of achieved temperatures compared to those that use synthetic refrigerants. Furthermore, only the application of R50 (methane) is shown to allow temperatures below 130 K to be achieved, and this is possible only in a two-stage compression cascade system. For most of the investigated configurations, the suction pressure must be below atmospheric pressure to thermally couple cascade stages. Full article
