Existing wet tropical urban drainage systems often fail to accommodate runoff generated during extreme rainfall. Water-sensitive urban design (WSUD) systems have the potential to retrofit the existing urban drainage system by enhancing infiltration and retention functions. However, studies supporting this assumption were based on temperate or arid climatic conditions, raising questions about its relevance in wet tropical catchments. To answer these questions, in this study a comprehensive modelling study of WSUD effectiveness in a tropical environment was implemented. Engineers Park, a small sub-catchment of 0.27 km² at Saltwater Creek, Cairns, Queensland, Australia was the study site in which the flood mitigation capabilities of grey and WSUD systems under major (1% Annual Exceedance Probability—AEP), moderate (20% AEP), and minor (63.2% AEP) magnitudes of rainfall were evaluated. A detailed one-dimensional (1D) and coupled 1D2D hydrodynamic model in MIKE+ were developed and deployed for this study. The results highlighted that the existing grey infrastructure within the catchment underperformed during major events resulting in high peak flows and overland flow, while minor rainfall events increased channel flow and shifted the location of flooding. However, the integration of WSUD with grey infrastructure reduced peak flow by 0% to 42%, total runoff volume by 0.9% to 46%, and the flood extent ratio to catchment area from 0.3% to 1.1%. Overall, the WSUD integration positively contributed to reduced flooding in this catchment, highlighting its potential applicability in tropical catchments subject to intense rainfall events. However, careful consideration is required before over-generalization of these results, since the study area is small. The results of this study can be used in similar study sites by decision-makers for planning and catchment management purposes, but with careful interpretation. Full article

A one-dimensional numerical overland flow model based on the cascade plane theory was developed to estimate rainfall-induced runoff and soil erosion on converging and diverging plane surfaces. The model includes three components: (i) soil infiltration using Horton’s infiltration equation, (ii) overland flow using the kinematic wave approximation of the one-dimensional Saint-Venant shallow water equations for a cascade of planes, and (iii) soil erosion based on the sediment transport continuity equation. The model’s performance was evaluated by comparing numerical results with laboratory data from experiments using a rainfall simulator and a soil flume. Four independent experiments were conducted on converging and diverging surfaces under varying slope and rainfall conditions. Overall, the numerically simulated hydrographs and sediment graphs closely matched the laboratory results, showing the efficiency of the model for the tested controlled laboratory conditions. The model was then used to numerically explore the impact of different plane soil surface geometries on runoff and soil loss. Seven geometries were studied: one rectangular, three diverging, and three converging. A constant soil surface area, the rainfall intensity, and the slope gradient were maintained in all simulations. Results showed that increasing convergence angles led to a higher peak and total soil loss, while decreasing divergence angles reduced them. Full article

More frequent high-intensity, short-duration rainfall events increase the risk of flash floods on steeply sloped watersheds. Where measured data are unavailable, numerical models emerge as valuable tools for predicting flash floods. Recent applications of various hydrological and hydrodynamic models to predict overland flow have highlighted the need for improved representations of the complex flow processes that are inherent in flash floods. This study aimed to identify an optimal modeling approach for characterizing leaf litter losses during flash floods. At a gauged watershed in the Hidegvíz Valley in Hungary, a physical-based model was calibrated using two distinct rainfall–runoff events. Two modeling methodologies were implemented, integrating canopy interception and leaf litter storage, to understand their contributions during flash flood events. The results from the model’s calibration demonstrated this approach’s effectiveness in determining the impact of leaf litter on steep-sloped watersheds. Soil parameters can estimate the behavior of leaf litter during flash flood events. In this study, hydraulic conductivity and initial water content emerged as critical factors for effective parametrization. The findings underscore the potential of a hydrodynamic model to explore the relationship between leaf litter and flash flood events, providing a framework for future studies in watershed management and risk-mitigation strategies. Full article

Estimating the critical slope angle (CSA) for sheet erosion is important for the precision estimation of sheet erosion and the development of erosion control practices. This study developed mathematical equations considering rainfall intensity and soil infiltration to efficiently estimate both instantaneous (at a given instant during rainfall) and cumulative CSAs, while also providing a valuable explanation for the change in CSA. The mathematical equations were consistent with observations from runoff plots (NSE = −1.01) of loess soils from Zhangjiakou (China) and simulation results (NSE = 0.96) from the Water Erosion Prediction Project model for a loam soil in Montana (USA). Estimated instantaneous CSA determined by the mathematical equations increased as the ratio of rainfall intensity to soil infiltration (I/f) increased, resulting in higher observed cumulative CSA after heavy versus normal rainfall events. Heavy rainfall, compacted soil, and varying rainfall duration affected the CSA by changing the I/f ratio. Maximum instantaneous CSA provided a better prediction of changes in soil erosion dynamics than that obtained from CSAs determined by field observations or experimental simulations. The mathematical equations illustrate the underlying physical mechanisms by which rainfall intensity and soil infiltration affect the CSA through changing the shear stress of overland flow. The results of this study provide critical information for guiding the development of effective soil erosion control strategies. Full article

Pluvial floods caused by extreme overland flow inland account for half of all flood damage claims each year along with fluvial floods. In order to increase confidence in pluvial flood susceptibility mapping, overland flow models need to be intensively evaluated using observations from past events. However, most remote-sensing-based flood detection techniques only focus on the identification of degradations and/or water pixels in the close vicinity of overflowing streams after heavy rainfall. Many occurrences of pluvial-flood-induced damages such as soil erosion, gullies, landslides and mudflows located further away from the stream are thus often unrevealed. To fill this gap, a transferable remote sensing fusion method called FuSVIPR, for Fusion of Sentinel-2 & Very high resolution Imagery for Pluvial Runoff, is developed to produce damage-detection maps. Based on very high spatial resolution optical imagery (from Pléiades satellites or airborne sensors) combined with 10 m change images from Sentinel-2 satellites, the Random Forest and U-net machine/deep learning techniques are separately trained and compared to locate pluvial flood footprints on the ground at 0.5 m spatial resolution following heavy weather events. In this work, three flash flood events in the Aude and Alpes-Maritimes departments in the South of France are investigated, covering over more than 160 km² of rural and periurban areas between 2018 and 2020. Pluvial-flood-detection accuracies hover around 75% (with a minimum area detection ratio for annotated ground truths of 25%), and false-positive rates mostly below 2% are achieved on all three distinct events using a cross-site validation framework. FuSVIPR is then further evaluated on the latest devastating flash floods of April 2022 in the Durban area (South Africa), without additional training. Very good agreement with the impact maps produced in the context of the International Charter “Space and Major Disasters” are reached with similar performance figures. These results emphasize the high generalization capability of this method to locate pluvial floods at any time of the year and over diverse regions worldwide using a very high spatial resolution visible product and two Sentinel-2 images. The resulting impact maps have high potential for helping thorough evaluation and improvement of surface water inundation models and boosting extreme precipitation downscaling at a very high spatial resolution. Full article

The precision of numerical overland flow models is limited by their computational cost. A GPU-accelerated 2D shallow flow model is developed to overcome this challenge in this study. The model employs a Godunov-type finite volume method (FVM) to solve shallow water equations (SWEs) with unstructured grids, while also considering rainfall, infiltration, bottom slope, and friction source terms. The numerical simulation demonstrates that this model has well-balanced and robust properties. In an experiment of urban rain-runoff and flood, the accuracy and stability of the model are further demonstrated. The model is programmed with CUDA, and each numerical computation term is processed in parallel to adopt multi-thread GPU acceleration technology. With the GPU computation framework, this model can achieve a speeding up ration around 75 to single-thread CPU in the dam-break flow for a large-scale application. Full article

Urban flood modeling usually involves simulating drainage network runoff and overland flow. We describe a method for urban pluvial flood modeling by coupling the stormwater management model (SWMM) with a raster-based 2D hydrodynamic model, which is based on a simplified form of the shallow water equations. Then, the method is applied to a highly urbanized area in Nanjing City, China. The elevation of the raster-based 2D hydrodynamic model shows that the raster-based model has comparable capabilities to LISFLOOD-FP for surface flood modeling. The calibration and validation results of the coupled model show that the method is reliable. Moreover, simulation results under the six rainfall return periods, which include 1-, 5-, 10-, 20-, 50-, and 100-year return periods show that node overflow, water depth, and flooding area increase proportionately as the intensity of rainfall increases. Therefore, the coupling model provides a simplified and intuitive method for urban pluvial flood modeling, which can be used to detect flood-sensitive areas and elevate the capacity of urban drainage networks for urban pluvial flooding. Full article

Along with fluvial floods (FFs), surface water floods (SWFs) caused by extreme overland flow are one of the main flood hazards occurring after heavy rainfall. Using physics-based distributed hydrological models, surface runoff can be simulated from precipitation inputs to investigate regions prone to soil erosion, mudflows or landslides. Geomatics approaches have also been developed to map susceptibility towards intense surface runoff without explicit hydrological modeling or event-based rainfall forcing. However, in order for these methods to be applicable for prevention purposes, they need to be comprehensively evaluated using proxy data of runoff-related impacts following a given event. Here, the IRIP geomatics mapping model, or “Indicator of Intense Pluvial Runoff”, is faced with rainfall radar measurements and damage maps derived from satellite imagery and supervised classification algorithms. Six watersheds in the Aude and Alpes-Maritimes departments in the South of France are investigated over more than 2000 km² of rural areas during two flash-flood events. The results of this study show that the greater the IRIP susceptibility scores, the more SWFs are detected by the remote sensing-based detection algorithm. Proportions of damaged plots become even larger when considering areas which experienced heavier precipitations. A negative relationship between the mean IRIP accumulation scores and the intensity of rainfall is found among damaged plots, confirming that SWFs preferably occur over potentially riskier areas where rainfall is lower. Land use and soil hydraulic conductivity are identified as the most relevant indicators for IRIP to define production areas responsible for downslope deteriorations. Multivariate logistic regression is also used to determine the relative weights of upstream and local topography, uphill production areas and rainfall intensity for explaining SWF occurrence. This work overall confirms the relevance of IRIP methodology while suggesting improvements to its core framework to implement better prevention strategies against SWF-related hazards. Full article

There is still little experience on the effect of the Manning roughness coefficient in coupled hydrological-hydraulic distributed models based on the solution of the Shallow Water Equations (SWE), where the Manning coefficient affects not only channel flow on the basin hydrographic network but also rainfall-runoff processes on the hillslopes. In this kind of model, roughness takes the role of the concentration time in classic conceptual or aggregated modelling methods, as is the case of the unit hydrograph method. Three different approaches were used to adjust the Manning roughness coefficient in order to fit the results with other methodologies or field observations—by comparing the resulting time of concentration with classic formulas, by comparing the runoff hydrographs obtained with aggregated models, and by comparing the runoff water volumes with observations. A wide dispersion of the roughness coefficients was observed to be generally much higher than the common values used in open channel flow hydraulics. Full article

This paper presents the performance quantification of different green-grey infrastructures, including rainfall-runoff and infiltration processes, on the overland flow and its connection with a sewer system. The present study suggests three main components to form the structure of the proposed model-based assessment. The first two components provide the optimal number of green infrastructure (GI) practices allocated in an urban catchment and optimal grey infrastructures, such as pipe and storage tank sizing. The third component evaluates selected combined green-grey infrastructures based on rainfall-runoff and infiltration computation in a 2D model domain. This framework was applied in an urban catchment in Dhaka City (Bangladesh) where different green-grey infrastructures were evaluated in relation to flood damage and investment costs. These practices implemented separately have an impact on the reduction of damage and investment costs. However, their combination has been shown to be the best action to follow. Finally, it was proved that including rainfall-runoff and infiltration processes, along with the representation of GI within a 2D model domain, enhances the analysis of the optimal combination of infrastructures, which in turn allows the drainage system to be assessed holistically. Full article

Rainfall-runoff transformation on urban catchments involves physical processes governing runoff production in urban areas (e.g., interception, evaporation, depression, infiltration). Some previous 1D/2D coupled models do not include these processes. Adequate representation of rainfall–runoff–infiltration within a dual drainage model is still needed for practical applications. In this paper we propose a new modelling setup which includes the rainfall–runoff–infiltration process on overland flow and its interaction with a sewer network. We first investigated the performance of an outflow hydrograph generator in a 2D model domain. The effect of infiltration losses on the overland flow was evaluated through an infiltration algorithm added in a so-called Surf-2D model. Then, the surface flow from a surcharge sewer was also investigated by coupling the Surf-2D model with the SWMM 5.1 (Storm Water Management Model). An evaluation of two approaches for representing urban floods was carried out based on two 1D/2D model interactions. Two test cases were implemented to validate the model. In general, similar results in terms of peak discharge, water depths and infiltration losses against other 1D/2D models were observed. The results from two 1D/2D model interactions show significant differences in terms of flood extent, maximum flood depths and inundation volume. Full article

We propose a one-dimensional Saint-Venant (open-channel) model for overland flows, including a water input–output source term modeling recharge via rainfall and infiltration (or exfiltration). We derive the model via asymptotic reduction from the two-dimensional Navier–Stokes equations under the shallow water assumption, with boundary conditions including recharge via ground infiltration and runoff. This new model recovers existing models as special cases, and adds more scope by adding water-mixing friction terms that depend on the rate of water recharge. We propose a novel entropy function and its flux, which are useful in validating the model’s conservation or dissipation properties. Based on this entropy function, we propose a finite volume scheme extending a class of kinetic schemes and provide numerical comparisons with respect to the newly introduced mixing friction coefficient. We also provide a comparison with experimental data. Full article

Splash erosion is an important soil erosion process in sloping lands. This study aims to improve the model of rain splash transport based on the results of previous studies and field experiments involving rainfall simulation. A field study was conducted to examine the effects of rainfall properties, herbaceous cover and surface flow on splash processes on hillslopes in northern China. On the basis of the experimental results, a comprehensive model of rain splash was established through the quantitative analysis of the interactive effects of rainfall kinetic energy, vegetation coverage and overland runoff depth on splash erosion rate and the probability density of splashed particles and maximum splash distance. The results showed that the estimated and observed values of splash transport exhibit high consistency and adaptability. However, several discrepancies were observed between the estimated and observed values for events with high vegetation coverage. These differences can be ascribed to the variation in overland runoff connectivity and the differences in soil surface cohesion at various wetness degrees. The proposed model provides insights into splash erosion characteristics and suggestions for erosion control practices on hillslopes. Full article

Karst regions are widely distributed in Southwest China and due to the complexity of their geologic structure, it is very challenging to collect data useful to provide a better understanding of surface, underground and fissure flows, needed to calibrate and validate numerical models. Without characterizing these features, it is very problematic to fully establish rainfall–runoff processes associated with soil loss in karst landscapes. Water infiltrated rapidly to the underground in rocky desertification areas. To fill this gap, this experimental work was completed to preliminarily determine the output characteristics of subsurface and underground fissure flows and their relationships with rainfall intensities (30 mm h⁻¹, 60 mm h⁻¹ and 90 mm h⁻¹) and bedrock degrees (30%, 40% and 50%), as well as the role of underground fissure flow in the near-surface rainfall–runoff process. Results indicated that under light rainfall conditions (30 mm h⁻¹), the hydrological processes observed were typical of Dunne overland flows; however, under moderate (60 mm h⁻¹) and high rainfall conditions (90 mm h⁻¹), hydrological processes were typical of Horton overland flows. Furthermore, results confirmed that the generation of underground runoff for moderate rocky desertification (MRD) and severe rocky desertification (SRD) happened 18.18% and 45.45% later than the timing recorded for the light rocky desertification (LRD) scenario. Additionally, results established that the maximum rate of underground runoff increased with the increase of bedrock degrees and the amount of cumulative underground runoff measured under different rocky desertification was SRD > MRD > LRD. In terms of flow characterization, for the LRD configuration under light rainfall intensity the underground runoff was mainly associated with soil water, which was accounting for about 85%–95%. However, under moderate and high rainfall intensities, the underground flow was mainly generated from fissure flow. Full article

Anthropogenic landscape conversion from forest to agricultural land affects baseflow. Baseflow is a source of potable water and can be used for the irrigation of high value crops. Finding ways to increase base and inter flow (i.e., groundwater flow) is, therefore, essential for the improvement of the livelihood of rural inhabitants. Therefore, the objective is to investigate the effect of landscape interventions on stream discharge and, in particular, on groundwater flow. The Tikur-Wuha experimental watershed in the upper reaches of the Blue Nile was selected because discharge data were available before and after implementation of a suite of land management practices that, among others, enhanced the percolation of water to below the rootzone. The parameter efficient distributed (PED) model was used to separate overland flow from total flow. The groundwater flow index (GWFI), defined as the quotient of the annual groundwater flow to the total stream discharge at the outlet of the watershed, was calculated. Our analysis with the PED model showed that at similar annual rainfall amounts, more baseflow and less surface runoff was generated after the landscape intervention, which promoted deep infiltration of the rainwater. The decrease in surface runoff shortly after the implementation of the land management practices is similar to observations in other watersheds in the Ethiopian highlands. Full article
