In reactive power compensators applied in drives with asynchronous motors, a control strategy focusing on the compensation of higher-order current harmonics is implemented. Control schemes of such compensators typically employ low-pass Butterworth filters with fixed cut-off frequencies to isolate the reactive power component. However, the impact of alternative filter types on compensator performance remains insufficiently explored. Furthermore, in the control systems under consideration, stator phase current signals of the asynchronous motor are used as reference inputs. This approach proves effective under the steady-state operating conditions of the drive. Under non-steady-state operating conditions—typical for traction drive systems—this approach becomes ineffective due to the increased complexity in obtaining accurate reference current signals. As a result, the performance of the filters also deteriorates. It is therefore proposed to investigate the impact of alternative filter types on the efficiency of compensator operation. To address this challenge, the following strategies are suggested: implement higher-order harmonic compensation in the system of stator phase supply voltages of the asynchronous motor; use the control signals from the Field-Oriented Control (FOC) algorithm as reference inputs; and adapt the cut-off frequencies of the filters dynamically to match the frequency of the supply voltage. The simulation results indicate that the use of an elliptic filter in compensator control systems yielded the highest effectiveness. Moreover, the results confirmed the efficiency of the proposed solutions under both steady-state and non-steady-state operating conditions of the traction drive. These approaches support the development of reactive power compensators integrated into traction drive systems for railway rolling stock. Full article

Motor railway vehicles necessitate enhanced control of wheel-rail contact mechanics to ensure optimal adhesion. During train running, driving wheelsets exhibit torsional vibrations that compromise adhesion and potentially lead to axle damage. Consequently, the development of dynamic models for analyzing driving wheelset stick-slip phenomena and control strategies is an area of significant research interest for traction control, studies on rail corrugation, and locomotive drivetrain design. Despite their application in various railway vehicle problems, non-smooth models have not been explored as an alternative for analyzing stick-slip, and existing research has focused on extensive computations based on Kalker’s theory or simplified models using constitutive friction laws. This work demonstrates the efficacy of non-smooth models in studying motor wheelset stick-slip. The non-smooth approach is suited for control systems, prioritizes simplicity while capturing the essential friction characteristics, and enables efficient dynamic simulations. The proposed model incorporates a set-valued friction law, and the equations of motion are formulated as a switch model. Numerical integration is achieved through an event-driven algorithm. The paper showcases application examples for the model. A direct comparison with an equivalent model using a constitutive friction law shows that the non-smooth integration is an order of magnitude more efficient in the stick phase. Full article

This paper investigates the application of high-capacity supercapacitors in railway systems, with a particular focus on their role in energy recovery during braking processes. The study highlights the potential for significant energy savings by capturing and storing energy generated through electrodynamic braking. Experimental measurements conducted on a diesel–electric multiple unit revealed that approximately 28.3% to 30.5% of the energy could be recovered from the traction network, regardless of the type of drive used—whether electric or diesel. This research also explores the integration of starch-based carbon as an electrode material in supercapacitors, offering an innovative, sustainable alternative to traditional graphite or graphene electrodes. The carbon material was obtained through a simple carbonization process, with experimental results demonstrating a material capacity of approximately 130 F/g. To quantify the energy recovery, calculations were made regarding the mass and power requirements of the supercapacitors. For the tested vehicle, it was estimated that around 28.7% of the energy could be recovered during the braking process. To store 15 kWh of energy, the total mass of the capacitors required is approximately 245.1 kg. The study emphasizes the importance of increasing voltage levels in railway systems, which can enhance energy transmission and utilization efficiency. Additionally, the paper discusses the necessity of controlled energy discharge, allowing for the flexible management of energy release to meet the varying power demands of trains. By integrating high-voltage supercapacitors and advanced materials like starch-based carbon, this research paves the way for more sustainable and efficient railway systems, contributing to the industry’s goals of reducing emissions and improving operational performance. The findings underscore the crucial role of these capacitors in modernizing railway infrastructure and promoting environmentally responsible transportation solutions. Full article

The safety and reliability of high-speed train electric traction systems are crucial. However, the operating environment for China Railway High-speed (CRH) trains is challenging, with severe working conditions. Dataset imbalance further complicates fault diagnosis. Therefore, conducting fault diagnosis for high-speed train electric traction systems under data imbalance is not only theoretically important but also crucial for ensuring vehicle safety. Firstly, when addressing the data imbalance issue, the fault diagnosis mechanism based on support vector machines tends to prioritize the majority class when constructing the classification hyperplane. This frequently leads to a reduction in the recognition rate of minority-class samples. To tackle this problem, a self-tuning support vector machine is proposed in this paper by setting distinct penalty factors for each class based on sample information. This approach aims to ensure equal misclassification costs for both classes and achieve the objective of suppressing the deviation of the classification hyperplane. Finally, simulation experiments are conducted on the Traction Drive Control System-Fault Injection Benchmark (TDCS-FIB) platform using three different imbalance ratios to address the data imbalance issue. The experimental results demonstrate consistent misclassification costs for both the minority- and majority-class samples. Additionally, the proposed self-tuning support vector machine effectively mitigates hyperplane deviation, further confirming the effectiveness of this fault diagnosis mechanism for high-speed train electric traction systems. Full article

The stick–slip phenomenon, the initial stage when the traction wheel starts sliding on the rail, is a critical operation that needs to be detected quickly to control the traction drive. In this study, we have developed an experimental model that uses acceleration sensors mounted on the wheel to evaluate the amplitude of the stick–slip phenomena. These sensors can alert the driver or assist the traction control unit when a stick–slip occurs. We propose a method to reduce the amplitude of the stick–slip phenomenon using special hydraulic dampers and viscous dampers mounted on the tractive axles of the locomotive to prevent slipping during acceleration. This practical solution, validated through numerical simulation, can be readily implemented in railway systems. The paper’s findings can be used to select the necessary sensors and corresponding vibration dampers. By implementing these sliding reducers, a locomotive can significantly improve traction, apply more torque to the wheel, and increase the load of a carrier train, instilling confidence in the efficiency of the proposed solution. Full article

Rail traction and resistance play an essential role in the efficient operation of rail systems. The nature of traction is based on the balance between static friction and generated force at the perimeter of the driving wheels. The main objective of this paper is the development of a methodology and a modeling procedure for the design of train speed trajectory diagrams for the suburban railway. The model is applied to the Athens–Chalkida railway line (in Greece). For this purpose, geometric data for the above-mentioned railway line is collected from the Hellenic Railways Organization (OSE) and then recorded and digitized. A code is developed in MATLAB to calculate the total resistance of the railway line at each kilometer position. The traction elements of the trains operating on the Athens–Chalkida–Athens line, as well as other representative trains, and the magnitudes of their mechanical-aerodynamic resistances are recorded. The MATLAB program generates and compiles the train speed trajectory diagrams and the traction-resistance matrices. Finally, a comparison is made between the time, energy, CO₂ emissions, and fuel costs of the rail in relation to the competing mode of transportation, which, for the specific line studied, is the tourist bus. Full article

Induction motors make up approximately 80% of the electric motors in the railway sector due to their robustness, high efficiency, and low maintenance cost. Nevertheless, these motors are subject to failures which can lead to costly downtime and service interruptions. In recent years, there has been a growing interest in developing fault diagnosis systems for railway traction motors using advanced non-invasive detection and data analysis techniques. Implementing these methods in railway applications can prove challenging due to variable speed and low-load operating conditions, as well as the use of inverter-fed motor drives. This comprehensive review paper summarizes general methods of fault diagnosis for induction machines. It details the faults seen in induction motors, the most relevant signals measured for fault detection, the signal processing techniques for fault extraction as well as some classification algorithms for diagnosis purposes. By giving the advantages and drawbacks of each technique, it helps select the appropriate method that could address the challenges of railway applications. Full article

Maintaining optimal temperatures in the critical parts of an induction traction motor is crucial for railway propulsion systems. A reduced-order lumped-parameter thermal network (LPTN) model enables computably inexpensive, accurate temperature estimation; however, it requires empirically based parameter estimation exercises. The calibration process is typically performed in labs in a controlled experimental setting, which is associated with a lot of supervised human efforts. However, the exploration of machine learning (ML) techniques in varied domains has enabled the model parameterization in the drive system outside the laboratory settings. This paper presents an innovative use of a multi-agent reinforcement learning (MARL) approach for the parametrization of an LPTN model. First, a set of reinforcement learning agents are trained to estimate the optimized thermal parameters using the simulated data in several driving cycles (DCs). The selection of a reinforcement learning agent and the level of neurons in the RL model is made based on variability of the driving cycle data. Furthermore, transfer learning is performed on a new driving cycle data collected on the measurement setup. Statistical analysis and clustering techniques are proposed for the selection of an RL agent that has been pre-trained on the historical data. It is established that by synergizing within reinforcement learning techniques, it is possible to refine and adjust the RL learning models to effectively capture the complexities of thermal dynamics. The proposed MARL framework shows its capability to accurately reflect the motor’s thermal behavior under various driving conditions. The transfer learning usage in the proposed approach could yield significant improvement in the accuracy of temperature prediction in the new driving cycles data. This approach is proposed with the aim of developing more adaptive and efficient thermal management strategies for railway propulsion systems. Full article

This paper deals with the phenomenon of torsion oscillations in railway vehicle drive systems. The main goal is to reduce the risk of presence of torsional oscillations in wheelset drive, eventually to propose systems to effectively identify and eliminate torsional oscillations of wheelsets. Therefore, a simulation wheelset drive model including a detailed model of the asynchronous traction motor control was built. The results of computer simulations show that the torsional oscillations can be effectively eliminated by avoiding the resonance states between the excitation frequencies given by pulse width modulation of the inverter and the eigenfrequencies of the mechanical part of the drive. Furthermore, it was found that the presence of torsional oscillations of the wheels can be detected based on the traction motor current ripple. The wheelset drive model was subsequently implemented in a simulation model of a four-axle locomotive. A new algorithm of an anti-slip protection system that utilizes motor currents was implemented in the model. Simulations show that such an anti-slip protection system can prevent the occurrence of undesired large amplitude of wheelset torsional oscillations. The models and simulation results are presented in detail in the paper. Full article

Power line communication (PLC) is a technology that exploits existing electrical transmission and distribution networks as guiding structures for electromagnetic signal propagation. This facilitates low-rate data transmission for signaling and control operations. As the demand in terms of data rate has greatly increased in the last years, the attention paid to broadband PLC (BPLC) has also greatly increased. This concept also extended to railways as broadband traction power line communication (BTPLC), aiming to offer railway operators an alternative data network in areas where other technologies are lacking. However, BTPLC implementation faces challenges due to varying operating scenarios like urban, rural, and galleries. Hence, ensuring coverage and service continuity demands the suitable characterization of the communication channel. In this regard, the scientific literature, which is an indicator of the body of knowledge related to BTPLC systems, is definitely poor if compared to that addressed to BPLC systems installed on the electrical transmission and distribution network. The relative papers dealing with BTPLC systems and focusing on the characterization of the communication channel show some theoretical approaches and, rarely, measurements guidelines and experimental results. In addition, to the best of the author’s knowledge, there are no surveys that comprehensively address these aspects. To compensate for this lack of information, a survey of the state of the art concerning BTPLC systems and the measurement methods that assist their installation, assessment, and maintenance is presented. The primary goal is to provide the interested readers with a thorough understanding of the matter and identify the current research gaps, in order to drive future research towards the most significant issues. Full article

The article is devoted to the use of Park’s vector method for operational control of the rotor condition of induction motors of traction and auxiliary drives of railway rolling stock. In the course of the analysis, it was established that in order to increase the reliability and efficiency of the operation of vehicles, it is necessary to improve and implement diagnostic systems for monitoring the current state of the most damaged elements of induction electric motors built into the drive. This paper presents the development of a new approach to monitoring the state of a squirrel-cage rotor, which is based on the use of Park’s vector approach. In the course of the research, the issue of taking into account the asymmetric power supply of the engine during the diagnostic period during industrial operation was solved, which affects the accuracy of determining the degree of damage to the rotor. On the basis of the conducted research, the algorithm of the module for diagnosing the state of the squirrel-cage rotor of an induction motor has been developed for practical use in the built-in on-board systems of vehicles, which allows us to determine the degree of damage and monitor the development of the rotor defect during operation, including in automated mode. Full article

Operation modes of rolling stock at mining enterprises are considered and analyzed. The justification of the need to replace it with a modern specialized electric locomotive for quarry railway transport, equipped with an asynchronous traction electric drive and an on-board energy storage system, is presented. The determination of the parameters and structure of the on-board energy storage system, based on the condition of power compensation with limited power consumption from the traction network and ensuring the autonomous movement of the electric locomotive, is considered. This study was carried out by modeling the processes of energy exchange in the traction system of an electric locomotive. The use of lithium cells and supercapacitors in energy storage is considered. Variants of the hybridization of energy storage were studied from the standpoint of minimizing the weight, size, and cost indicators. It was established that reducing the mass of the energy storage device, which includes lithium cells and supercapacitors, leads to an increase in the cost of one kilowatt-hour of energy storage capacity, which reduces the attractiveness of capital expenditures for the creation of such an energy storage device. Hybridization of the energy storage device by combining lithium cells of different types practically does not improve its weight, size, and cost indicators. The recommended option is a storage capacity of energy based on LTO elements, for which it is necessary to select elements in order to minimize weight, size, and cost indicators. Full article

Traction electricity (TE) consumption in rail transportation (rail transport) is determined by factors (determinant) related to the characteristics of railway lines and vehicles. They have an impact on driving speeds, which, in turn, affect energy consumption. The scientific research presented here combined the results of expert, direct and indirect measurement methods, including brainstorming, mind mapping, system approach, heuristics, failure mode and effect analysis. The main objective was to demonstrate the influence of the determinants of TE consumption, depending on the route (road) geometry and characteristics of the traction of electric vehicles and whole trains (catenary-supplied electric vehicles, non-autonomous electric vehicles, and network traction vehicles, especially electric locomotives and electric multiple units, electric multiple-units (EMUs)). Using a new approach, the TE consumption equation, we applied values for the movement resistances of electric locomotives during braking for a jointed railway track M_{res JRT braking} and continuous welded rail tracks M_{res CWRt braking}. The values of the movement resistances of the electric locomotives during startup on the jointed railway track M_{res JRT startup} and continuous welded rail tracks M_{res CWRt startup} were also applied. They showed a strong correlation with the existing speeds of catenary-supplied electric vehicles. The implementation of the new innovative approach is an important contribution to the development of engineering and technical sciences, in particular, the disciplines of civil engineering, surveying/geodesy, and transport. Full article

The state-space interface of the railway track (track) geometry system with an electrified traction system (ETS) constitutes the geometric configuration that is utilised in this study. Importantly, driving comfort, smooth operation (smooth running), and compliance with the ETS are the desired aims. Direct measurement methods were used in the interaction with the system, especially in regard to the fixed-point, visual, and expert methods. In particular, track-recording trolleys were used. The subjects belonging to the insulated instruments also included the integration of certain methods, such as in the brainstorming, mind mapping, system approach, heuristic, failure mode and effect analysis, and system failure mode effects analysis methods. These were based on a case study and are representative of three real objects, i.e., electrified railway lines, direct current (DC), and scientific research objects (which specifically cover five research objects). The aim of the scientific research work is to increase the interoperability of the railway track geometric state configurations in regard to the sustainability development of the ETS. The results of this work confirmed their validity. By ensuring that the six-parameter defectiveness D₆ was defined and implemented, the D₆ parameter of the railway track condition was first estimated. The new approach reinforces the improvement in preventive maintenance and reductions in corrective maintenance; moreover, it is an innovative supplement to the existing direct measurement method in the configuration of the geometric condition of railway tracks and in the sustainability development of the ETS via interacting with the indirect measurement method. Full article

The gearbox is the key component of the traction drive system of a high-speed train. At the same time, the traction gearbox can easily experience a box housing failure due to bearing internal excitation from gear meshing and external excitation from motor torque fluctuation, the wheel polygon, and so on. In order to analyze the vibration and noise of the gearbox, a dynamic model of a high-speed train gear transmission system was established under the conditions of time-varying meshing stiffness and time-varying meshing error. A frequency spectrum analysis of the vibration at the key nodes of the model that changed with the speed was carried out. A test rig for a traction gearbox of a high-speed train was built, and a testing method for the vibration and noise of a high-speed train traction gearbox was put forward. The testing of and research on the traction gearbox under various working conditions were carried out, and the dynamic evaluation indexes of acceleration, vibration intensity, and air noise at different measuring points of the high-speed train traction gearbox were obtained. The study provided a test reference and a basis for the dynamic performance optimization design and fault diagnosis of a high-speed railway traction gearbox system. Full article
