Air cycle systems, once largely replaced by vapour-compression technologies due to efficiency concerns, are now re-emerging as a viable and sustainable alternative for highly dynamic thermal applications and excel in ultra-low temperature. By using air as the working fluid, these systems eliminate the need for synthetic refrigerants and comply naturally with evolving environmental regulations. This study presents the conceptual design and simulation-based analysis of a novel air cycle machine developed for advanced automotive testing environments. The system is intended to replicate a wide range of climatic conditions—from deep winter to peak summer—through the use of fast-responding turbomachinery and a flexible control strategy. A central focus is placed on the radial turbine, which is designed and evaluated using a modular, open source framework that integrates geometry generation, off-design CFD simulation, and performance mapping. The study outlines a potential operating strategy based on these simulations and discusses a control architecture combining lookup tables with zone-specific PID tuning. While the results are theoretical, they demonstrate the feasibility and flexibility of the proposed approach, particularly the turbine’s role within the system. Full article

The supercritical carbon dioxide (sCO₂) Brayton cycle has advantages such as a compact system and high energy density. Axial turbines, the key component of the cycle, have lower rotational speeds, pressure ratios and engineering difficulties compared to radial turbines. This study focuses on the initial design parameters and the complete design process of a small-scale axial turbine based on nuclear power and utilizing supercritical carbon dioxide. The design objective of this study is a 150 kW single-stage axial turbine. AXIAL software is used for batch calculations in the preliminary turbine design to determine the most reasonable initial design parameters, including back pressure, rotational speed, average radius, and mass flow rate. These initial parameters serve as the starting point for the overall turbine design process. The one-dimensional design results of the turbine show an isentropic efficiency of 77.15%, and numerical simulations validate the accuracy of this efficiency. Full article

This paper presents the first-of-its-kind full-crown Detached Eddy Simulation (DES) of a radial turbine designed for operation in a transcritical CO₂-based power cycle. The simulation domain contains not only the main blade passage but also the exhaust diffuser and the rotor disk cavities. To ensure accurate simulation of the turbine, two hybrid RANS/LES models, using the Improved Delayed Detached Eddy Simulation (IDDES) approach, are validated in a flow around a circular cylinder at $\mathrm{Re}=3900$, obtaining excellent agreement with other experimental and numerical studies. The turbine simulation was performed using the k-$\omega$-SST-based IDDES model, which was identified as the most appropriate approach for accurately capturing all relevant flow dynamics. Thermophysical properties of CO₂ are modeled with the Span–Wagner reference equation, which was evaluated by a highly efficient spline-based table look-up method. A preliminary assessment of the grid quality in the context of DES is performed for the full-crown simulation, and characteristic flow features of the main passage and cavity flow are highlighted and discussed. Full article

Pumped storage power stations are effective stabilizers and regulators of the power grids. However, during the transient process, especially the operating point entering the S-shaped region, the internal flow patterns and pressure pulsations in the pump–turbine unit change violently, seriously affecting the safety of the power stations, which requires enough optimizations in the design stage of the pump–turbine. In this paper, to explore the key factors which influence the evolutions of flow patterns and pressure pulsations during the runaway process, three pump–turbine runners with different inlet blade lean, including positive angle, no angle and negative angle, were selected to simulate by using the three-dimensional method. The results show that the changes in the inlet blade lean angles have significant effects on the variation periods and maximum values of the macro parameters during the runaway process, and especially the runner with no lean angle results in the smallest oscillation periods and pressure pulsations but enlarges the runner radial forces. In addition, backflows generate from the hub side under the cases with positive or no blade lean angle, while those occur from the shroud side due to the negative angle. The results provide a basic reference for the design of the pump–turbine. Full article

Straight-walled diffusers can boost the power density of horizontal-axis hydrokinetic turbines (HKTs), but are prone to boundary layer separation when the divergence angle is too large. We perform a systematic factorial study of three diffuser configurations, slotless, mid-length single-slot, and outlet-slot with dual divergence angles, using a two-dimensional, transient SST k–$\omega$ Reynolds-averaged Navier–Stokes model validated against wind tunnel data (maximum error 6.4%). Eight geometries per configuration are generated through a $2^3$ Design of Experiments with variation in the divergence angle, flange or slot position, and inlet section. The optimal outlet-slot design re-energises the boundary layer, shortens the recirculation zone by more than 50%, and raises the mean axial velocity along the diffuser centreline by 12.6% compared with an equally compact slotless diffuser, and by 42.6% relative to an open flow without a diffuser. Parametric analysis shows that the slot position in the radial (Y) direction and the first divergence angle have the strongest influence on velocity augmentation. In contrast, the flange angle and axial slot location (X) are second-order effects. The results provide fabrication-friendly guidelines, restricted to straight walls and a single slot, that are capable of improving HKT performance in shallow or remote waterways where complex curved diffusers are impractical. The study also identifies key geometric and turbulence model sensitivities that should be addressed in future three-dimensional and multi-slot investigations. Full article

Savonius drag-based rotors, a type of vertical-axis wind turbine (VAWT), are well-suited for urban environments—particularly residential rooftops—owing to their compact design and ability to capture wind from all directions. However, their relatively low efficiency and narrow operational range pose significant challenges, such as limited energy output under variable wind conditions and reduced performance across a broad range of tip speed ratios. To address these issues, this study explores flow augmentation using strategically placed deflectors, referred to as Wind Accelerators and Guiding Rotor Houses (WAG-RHs). Four different configurations, including double, triple, oblique, and straight designs, were evaluated against both omni-directional guide vanes (ODGVs) and a conventional rotor. The findings show that the ODGV configuration successfully extends the operational range from a tip speed ratio of 0.5 to 0.6—termed the extended performance point (EPP)—and increases the power coefficient ($C_p$) by up to 300% compared to the conventional design. Among all setups, the straight WAG-RH configuration proved most effective, not only achieving the EPP but also delivering a 385% and 264.3% increase in local and AVE $C_p$ values, respectively compared to the conventional rotor. It also outperformed the ODGV-equipped rotor by 25%, thanks to its radial and dual-plane arrangement. Full article

Axial flux permanent magnet (AFPM) machines offer some advantages over conventional radial flux machines for the case of a limited space in the axial direction, such as high torque density, compact structure, and modular design ability. They, therefore, are increasingly used in wind power and electrical vehicles. This paper focuses on developing an effective analytical model and equivalent auto-finite element method (FEM), including rotor linear motion for the design of axial flux permanent magnet generators in vertical axis wind turbines. The initial design of a 1.35 kW-AFPM generator with an outer double rotor and double layer concentrated windings is based on analytical equations, and then it is refined using equivalent time-stepping transient FEM, including rotor linear motion to calculate voltage, electromagnetic force, and torque. The automatic generation of an equivalent transient 2D-FEM model to replace a time-consuming 3D-FEM model is investigated. As a consequence, the influence of slotting the effect on a 1.35 kW-AFPM machine’s performances, such as air gap flux density, internal voltage, and cogging torque, is announced. Full article

Additive manufacturing offers new perspectives for creating complex geometries with improved design features at lower cost and with reduced manufacturing time. It may even become possible to print a micro-turbojet engine in one single print, but then unconventional geometrical constraints on compressor and turbine designs are inevitable. If a radial machine were printed through additive manufacturing as a standalone component, the most logical print direction would be from the radial outlet/inlet to the axial inlet/outlet to ease the process and limit the supports, with limited additional constraints compared to traditional manufacturing methods. If the rotor comprising a radial compressor and turbine needs to be printed in one single print, one of the components will be printed in a direction that is not favorable. In the present work, the radial turbine is considered to be printed in the unfavorable direction, namely, from the axial outlet to the radial inlet. These geometrical constraints orient the geometry towards a mixed-flow configuration with a trailing-edge cutback. Such design features reduce the available design space for improvement and will clearly have an unfavorable impact on performance. Therefore, a multi-disciplinary gradient-based adjoint optimization of the mixed-flow turbine is performed, striving to limit the adverse impact on total-to-total efficiency while respecting the mass flow rate and power matching with the upstream compressor. The structural constraint limits the p-Norm von Mises stress to a maximum threshold based on the material yield strength at the operating temperature. The results show that a satisfactory compromise can be found between manufacturability constraints, material limits and aerodynamic performance. Full article

This study reveals the governing mechanism of mass flow distribution within a multi-inlet, multi-outlet corotating disc cavity, providing critical insights for designing advanced gas turbine secondary air systems. An experimentally verified numerical investigation is conducted across a range of rotational Reynolds numbers $R{e}_{\varphi }=5\times {10}^6~2\times {10}^7$ and axial Reynolds numbers $R{e}_z=2\times {10}^5~5\times {10}^5$, corresponding to Rossby numbers $Ro$ from 0.01 to 0.10. Results highlight that $Ro$ governs the internal flow and outlet mass flow distribution through two distinct regimes. In the rotation-dominated regime at low $Ro$, the radial outlet mass flow ratio $MR$ decreases sharply, and a stable, dual-zone vortical structure forms. As $Ro$ increases, growing inflow inertia disrupts this structure, causing vortices to merge, which enhances swirl uniformity and slows the rate of $MR$ decrease. This transition dictates outlet performance: the radial outlet discharge steadily improves with $Ro$, while the axial outlet performance increases abruptly around $Ro=0.02$ before saturating. Full article

During the installation and operation of Pelton turbines, deviations of the jet centerline from the runner pitch circle can compromise turbine stability and efficiency. Utilizing design data from a Pelton turbine on China’s Dadu River, this study employs the SST k-ω and VOF models to investigate the flow characteristics, pressure pulsations, and force on the bucket surface under varying offset conditions. The results demonstrate that radial offset causes the jet to enter the bucket later when deflected outward and earlier when deflected inward. All forms of offset exert adverse effects on turbine performance, with axial offsets causing more severe impacts than radial ones. The maximum pressure pulsation amplitude reached 24%. Afterwards, the erosion of Pelton turbines with different grain sizes was investigated by erosion modeling. It was found that the erosion of large grain size is more serious than that of small grain size. This research provides valuable theoretical insights and an important guiding role for improving the operational stability of Pelton turbines. Full article

To facilitate the development of next-generation gas turbine cooling systems, the present study systematically investigates the influence of inlet temperature differentials on the aerothermal characteristics and mass flow distribution within multi-inlet, multi-outlet corotating-disc cavities, for which inlet temperature differentials of 10 K, 30 K, and 50 K were applied. Steady-state Reynolds-averaged Navier–Stokes (RANS) simulations using the Shear Stress Transport (SST) k-ω model were performed across a range of flow conditions corresponding to Rossby numbers from 0.01 to 0.10, by varying the rotational and axial Reynolds numbers. This study finds that the inlet temperature differentials are a secondary driver of the aerothermal characteristics in the corotating cavity. Meanwhile, Rossby number dictates the main flow structure of radially stratified vortices and governs the thermal mixing between hot and cold streams. A higher Rossby number enhances mixing, causing the radial outlet temperature to rise significantly, while the axial outlet remains cool. A larger inlet temperature differential can induce secondary vortices at high Rossby numbers. Furthermore, the differential is revealed to increase cavity pressure, slightly reducing the radial outlet’s mass flow by up to 2.5% and its discharge coefficient by nearly 5% at high Rossby numbers. These insights allow engine designers to develop more precise and optimized cooling strategies. Full article

This paper presents a detailed numerical investigation of the effect of hub-mounted riblets on the thermal and aerodynamic performance of a radial turbine rotor. While prior studies have shown that riblets reduce wall shear stress and improve aerodynamic efficiency, their influence on heat transfer and thermal losses remains underexplored. Using numerical simulations, this study examines the heat transfer characteristics within the rotor passage, comparing ribbed and smooth hub configurations under the same operating conditions. Results reveal that although riblets reduce frictional drag, they also enhance convective heat transfer—leading to a 6% increase in the heat transfer coefficient at the hub and 2.8% at the blade surfaces. This intensification of heat transfer results in a 4.3% rise in overall thermal losses, counteracting some of the aerodynamic gains. The findings provide new insights into the thermofluidic implications of surface modifications in turbomachinery and emphasise the importance of considering surface finish not only for aerodynamic optimisation but also for thermal efficiency. These results can inform future turbine design and manufacturing practices aimed at controlling surface roughness to minimise heat loss. Full article

Secondary flow phenomena have a significant influence on the generation of losses and the propagation of coolant on the turbine end walls. The majority of film cooling studies are carried out on linear rather than annular cascades due to the structural simplicity and ease of measurement integration of the former. This approach neglects the effects of the radial pressure gradient that is naturally imposed on the vortex flow in annular cascades. The first part of this paper numerically investigates the effect of the radial pressure gradient on the secondary flow under periodic flow conditions by comparing a linear and an annular case. It is shown that the radial pressure gradient has a significant influence on the propagation of the secondary flow induced vortices in the wake of the nozzle guide vanes (NGV). In the second part of the paper, a novel approach of a five-passage annular sector cascade is presented, which avoids the hub boundary layer separation, as is typical for this type of test rig. To increase the periodicity, a benchmark approach is introduced that includes multiple pointwise and integral flow quantities at different axial positions. Based on the optimized best-case design, general design guidelines are derived that allow a straightforward design process for annular sector cascades. Full article

A standard approach to design begins with scaling up state-of-the-art machines to new target dimensions, moving towards larger rotors with lower specific energy to maximize revenue and enable power production in lower wind speed areas. This trend is particularly crucial in floating offshore wind in the Mediterranean Sea, where the high levelized cost of energy poses significant risks to the sustainability of investments in new projects. In this context, the conventional approach of scaling up machines designed for fixed foundations and strong offshore winds may not be optimal. Additionally, modern large-scale wind turbines for offshore applications face challenges in achieving high aerodynamic performance in thick root regions. This study proposes a holistic optimization framework that combines multi-fidelity analyses and tools to address the new challenges in wind turbine rotor design, accounting for the novel demands of this application. The method is based on a modular optimization framework for the aerodynamic design of a new wind turbine rotor, where the cost function block is defined with the aid of a model reduction strategy. The link between the full-order model required to evaluate the target rotor’s performance, the physical aspects of blade aerodynamics, and the optimization algorithm that needs several evaluations of the cost function is provided by the definition of a surrogate model (SM). An intelligent SM definition strategy is adopted to minimize the computational effort required to build a reliable model of the cost function. The strategy is based on the construction of a self-adaptive, automatic refinement of the training space, while the particular SM is defined by the use of stochastic radial basis functions. The goal of this paper is to describe the new aerodynamic design strategy, its performance, and results, presenting a case study of a 15 MW wind turbine blades optimized for specific deepwater sites in the Mediterranean Sea. Full article

Organic Rankine Cycle (ORC) systems are widely used for converting low-temperature waste heat into useful power, but their overall efficiency depends heavily on the turbine’s performance, particularly the stator vane design in radial turbines. This study introduces a biomimetic approach to turbine design by implementing cambered stator vanes inspired by bird feather geometry. These specially shaped vanes are added to a radial inflow turbine and compared to a traditional design that uses straight (symmetric) vanes. The new cambered design helps guide the airflow more effectively, leading to higher tangential speeds and better energy transfer. Simulations show that this design increases the turbine’s power output from 388.6 kW to 394.87 kW and improves the system’s overall efficiency from 8.78% to 10.12%. A detailed study of different camber levels found that moderate curvatures (around 8–12%) gave the best results. Overall, this study demonstrates that implementing biomimetic cambered stator vanes in radial turbines can significantly enhance turbine performance and improve cycle-level efficiency in ORC systems for waste heat recovery. Full article
