Increasing the shear reinforcement ratio (ρ_w) can help meet architectural and structural requirements but often results in less reliable punching strength estimates from design codes. Nonlinear finite element analysis (NLFEA) has the potential to support a thorough assessment of the punching strength of slabs with shear studs, yet accurately modelling the interaction between concrete and transverse steel to capture the strength provided by shear rebars is challenging while using user-friendly software. This paper explores methodologies to assess the punching strength of slabs with double-headed studs with a commercial NLFEA program. Experimental tests were used to define the input parameters for the concrete’s nonlinear behaviour and to evaluate modelling approaches for shear studs, resulting in two strategies applied to slabs with varying ρ_w. NLFEA provided accurate punching strength estimates, consistently reproducing slabs’ rotations, crack patterns, and flexural strains. However, discrepancies in shear rebar strains highlight the challenges of using NLFEA to assess the response of slabs with shear reinforcement. Moreover, NLFE and experimental strengths were compared to estimates using the fib Model Code 2010 with levels of approximation (LoA) II, III, and IV, showing that, for the selected tests, increasing complexity in LoA IV did not consistently improve strength estimate accuracy. Full article

This paper introduces a component model for analysing embedded column bases to predict rotational stiffness, moment resistance, and the full-range moment–rotation response. The key components identified include the embedded column, concrete in compression on the column side, concrete in compression beneath the base plate, concrete in punching shear above the base plate, and anchor bolts. The embedded column is modelled as a Timoshenko beam, considering both shear and flexural deformations, while other components are represented by springs. Methods are provided for determining their uniaxial constitutive behaviour. A simplified iterative solution method is proposed, where the embedded column is further simplified into three rigid segments to specifically address shear and bending deformations. A corresponding simplified finite element model is developed for accurate numerical solutions. The validity of the component model is confirmed through comparisons with the results of existing tests and refined solid finite element analysis for H-steel column bases. The simplified iterative solution method effectively predicts strength but underestimates the stiffness of deeply embedded column bases. This is due to the trilinear deformation pattern simplification, which concentrates flexural deformation at the upper bearing stress resultant force point, leading to an overestimation of steel column rotation on the foundation surface. Full article

This study seeks to experimentally evaluate the punching shear performance of two-way concrete slabs reinforced with conventional steel and basalt fiber-reinforced polymer (basalt-FRP) bars subjected to punching loading condition. Basalt-FRP bars offer high tensile strength and corrosion resistance but are understudied in two-way concrete slabs concerning punching shear. This study aims to fill this gap, with key implications for future structural design considerations. To achieve the objectives of the study, six large-scale square slabs were fabricated and subjected to a concentric load until failure. The parameters of the experiment included are the type of reinforcement used (either basalt-FRP or steel), the percentage of basalt-FRP used (ranging from 0.88% to 1.77%), the size of the basalt-FRP bars used (either 16 or 12 mm), and the concrete’s compressive strength (25, 30, and 35 MPa). The findings from the tests showed that incorporating basalt-FRP bars with one-quarter equivalent axial stiffness ($\rho \left(E_f/E_s\right)$) to that of steel significantly enhanced the punching shear resistance of flat slabs, achieving approximately 65% of the capacity observed in steel-reinforced control sample. Moreover, increasing the amount of basalt-FRP bar reinforcement to half of the equivalent axial stiffness of steel had a substantial effect in improving shear strength, reaching approximately 89% of the capacity observed in the steel-reinforced specimen and concurrently reducing deflection during the failure. Additionally, the reinforcement type and concrete compressive strength played a crucial role in determining the ultimate load, failure modes, and crack propagation patterns. The study reveals discrepancies between experimental results and existing models for punching shear in FRP-reinforced slabs. Certain prevalent models prove to be conservative in their estimates, while others offer more accurate predictions, indicating the need for comprehensive model refinement. The investigation found that one model, encompassing the majority of variables affecting punching shear, exhibited the highest level of precision, with a slight adjustment recommended to enhance its accuracy further. This study suggests a sustainable, more durable way to reinforce concrete in bridges and high-rise buildings, potentially improving construction efficiency, enhanced service life, and potential updates to building codes. Full article

Cold forging is widely used in many industries. Multi-stage cold forming is usually utilized in forging fasteners. In this study, numerical simulation and experimental investigations were carried out on a five-stage cold-forming process for the manufacturing of low-carbon steel AISI 1010 relief valve regulating nuts. The forming process through five stages included preparation and centering for backward extrusion, backward extrusion over die pin, upset, backward extrusion over a moving punch, and piercing. The formability of the workpiece was studied, such as the effects on forming force response, maximum forming force, effective stress and effective strain distributions, metal flow patterns, and strength. A comparison of the forming forces obtained in the forming experiment with the numerical simulation results of the five-stage cold forming showed a good agreement with the trend of the forming force growth. For the maximum forming force and forming energy, the fourth stage of backward extrusion over the moving punch at the upper face was the largest among the five stages. The total maximum forming forces from the first to the fifth stages were numerically 440.9 kN and experimentally 449.4 kN, meaning the FE simulation and experimental results were in good agreement. The numerically simulated effective strain distributions were consistent with the experimentally tested hardness distributions. Highly compacted grain flow lines also resulted in higher hardness. The overall hardness of the workpiece formed by five-stage cold forming increased by 31% compared to the initial billet. The hardness of the workpiece increased with the forming stages, and the strain-hardening effect was obvious. The strength of the workpiece was significantly increased by five-stage cold forming. Full article

Background/Objective: Optimization of needle characteristics for trans-septal puncture is of paramount importance to reduce the extent of tissue deformation. This was achieved by studying the mechanical behavior of fossa ovalis (FO) in lamb hearts. The fossa ovalis tissue samples obtained after dissection were subjected to experimental indentation and tensile tests to determine tissue deformation. Methods: Lamb hearts (n = 20) were dissected to obtain fossa ovalis tissue samples. These were subjected to indentation and tensile tests to determine the puncture and rupture forces respectively. Indentation tests were performed using two different indenters: A steel indenter with a hemispherical tip and a Brockenbrough (BRK) needle (bevel tip). Tensile tests were formed using Zwick Roell (Z005) tensile machine at 100 N load cell. ImageJ analysis was also performed to determine the diameter and shape of FO. Results: Indentation results demonstrated that the hemispherical indenter requires a greater punch force compared to the puncture force with the BRK needle. The mean punch force of the hemispherical indenter (15.57 N) was nearly 3 times greater than the puncture force of the BRK needle (5.47 N). Variations between the two indenters provide an insight into the importance of device geometry on trans-septal procedures. The tensile test results illustrated a typical failure pattern with a toe region, linear region, and failure region. The mean rupture force determined was 10.51 N. ImageJ analysis confirmed an oval shape of FO and the diameters measured were in the range 9.0–15.3 mm. Conclusions: The mechanical aspects of fossa ovalis in lamb hearts were successfully studied through a series of experimental indentation and tensile tests. This study serves as a guide to dissecting the challenging FO sample. The procedures for indentation and tensile tests are detailed with common experimental challenges encountered addressed. The correlation of the parameters involved in these experimental tests to the collagen fiber orientation in tissues is also discussed, providing an insight into the deformation of tissues and variations in fiber orientation before and after trans-septal procedures. Full article

The punching shear failure of reinforced concrete (RC) flat slabs is an undesirable type of failure, as it is sudden and brittle. This paper presents an experimental and numerical study to explore the behavior of flat slabs made of different types of concrete under the influence of punching shear. Experimental tests were carried out on four groups of flat slabs, each group representing a different type of concrete: ordinary normal concrete (NC), high-strength concrete (HSC), strain-hardening cementitious composite concrete (SHCC), and ultra-high-performance fiber concrete (UHPFC). Each group consisted of six slabs, one representing an unreinforced control slab other than the reinforcement of the bottom mesh, and the others representing slabs internally reinforced with SHCC-filled steel tubes and high-strength bolts. An analytical equation was used to predict the punching shear capacity of slabs internally reinforced using steel assemblies. A numerical model was proposed using the ABAQUS program, and was validated by comparing its results with our experimental results. Finally, a case study was performed on large-scale slabs. The results showed that using steel assemblies inside NC slabs increased the slab’s punching shear capacity but does not completely prevent punching shear failure. Internally unreinforced slabs made of UHPFC and SHCC were able to avoid punching shear failure and collapse in a ductile bending pattern due to the high compressive and tensile strength of these types of concrete. The proposed analytical method succeeded in predicting the collapse load of slabs reinforced with steel assemblies with a difference not exceeding 9%. Full article

A pair of punch and die was often fabricated using subtractive manufacturing processes such as milling and other machining processes. However, additive manufacturing could be used to perform the same processes. This study explored this possibility. In particular, this study fabricated a pair of T-shaped punch and die made of AISI316L austenitic stainless steel using an additive manufacturing process called plasma-assisted 3D printing. Accordingly, T-shaped negative and positive 2D patterns were screen-printed onto the mirror-polished surfaces of the substrates made of AISI316L austenitic stainless steel. The printed film worked like a mask to prevent the printed substrate surfaces from nitriding. In order to form a thick nitrided layer, the unprinted substrate surfaces were selectively nitrided at 673 K for 14.4 ks. The un-nitrided segments of the substrates were uniformly removed by sand-blasting that involved shooting silica particles on the substrate’s surfaces. As a result, the substrates printed with negative and positive T-shaped patterns were transformed into the punch head and die cavity. In order to see the efficacy of the fabricated punch and die pair, this pair was used for piercing the electrical steel sheets under a controlled clearance. Scanning Electron Microscopy with Energy Dispersive X-ray (SEM-EDX) was used to measure surface topography after piercing. In addition, SEM and a 3D profilometer were used to measure the punch and die profiles after piercing. The abovementioned measurement results showed that the fabricated punch and die exhibited highly accurate piercing behavior. Thus, the plasma-assisted 3D printing was useful for punch and die fabrication. Full article

Electromagnetic forming is a high-speed process, which features contactless force transmission. Hence, punching operations can be realized with a one-sided die and without a mechanical punch. As the forces act as body forces in the part near the surface, the process is especially convenient for embossing microstructures on thin sheet metals. Nevertheless, the die design is critical concerning wear like adhesion. Several die materials were tested, like aluminum, copper as well as different steel types. For all die materials adhesion phenomena were observed. To prevent such adhesion an a-C:H-PVD (Physical Vapor Deposition)-coating was applied to steel dies (X153CrMoV12) and tested by embossing aluminum sheets (Al99.5). By this enhancement of the die adhesion was prevented. Furthermore, the die surface was structured with tribology-effective patterns that were generated by micro hard milling. The embossing quality was topographically analyzed with respect to different initial surface states of the sheets. It was identified that thicker sheets facilitate better embossing results. Moreover, the initial sheet surface has a decisive influence on the embossing quality, whereby the characteristic of the topography showed different susceptibility on the initial sheet surface state. Full article

Cold forged parts are mainly employed in automotive and aerospace assemblies, and strength plays an essential role in such applications. Backward extrusion is one such process in cold forging for the production of axisymmetrical cup-like parts, which is affected by a number of variables that influence the quality of the products. The study on the influencing parameters becomes necessary as the complexity of the part increases. The present paper focuses on the use of a multi-layered feed forward artificial neural network (ANN) model for determining the effects of process parameters such as billet size, reduction ratio, punch angle, and land height on forming behavior, namely, effective stress, strain, strain rate, and punch force in a cold forging backward extrusion process for AISI 1010 steel. Full factorial design (FFD) has been employed to plan the finite element (FE) simulations and accordingly, the input variables and response patterns are obtained for training from these FE simulations. This ANN model-based analysis reveals that the forming behavior of the cold forging backward extrusion process tends to increase with the billet size as well as the reduction ratios. However, decreases in punch angle and land height lead to the reduction of punch forces, which in turn enhances the punch life. FE simulation along with the developed ANN model scheme would benefit the cold forging industry in minimizing the process development effort in terms of cost and time. Full article

Copper substrates were wrought to have micro-grooves for packaging by micro-stamping with use of a AISI316 stainless steel micro-punch array. The micro-texture of this arrayed punch was first tailored and compiled into CAD data. A screen film was prepared to have the tailored micro-pattern in correspondence to the CAD data. A negative pattern to this screen was printed directly onto the AISI316 die substrate. This substrate was plasma nitrided at 673 K for 14.4 ks. The unprinted die surfaces were selectively nitrogen super-saturated to have sufficiently high corrosion toughness and hardness; other surfaces were masked by the prints. The two-dimensional micro-pattern on the screen was transformed into a three-dimensional nitrogen supersaturated micro-texture embedded in the AISI316 die. The printed surfaces were selectively sand-blasted to fabricate the micro-textured punch array for micro-embossing. A uniaxial compression testing machine was utilized to describe the micro-embossing behavior in copper substrates and to investigate how the micro-texture on the die was transcribed to the copper. The micro-punch array in this study consisted of three closed loop heads with a width of 75 µm and a height of 120 µm after plasma nitriding and sand-blasting. Since the nitrogen supersaturated heads had sufficient hardness against the blasting media, the printed parts of AISI316 die were removed. The micro-embossing process was described by comparison of the geometric configurations between the multi-punch array and the embossed copper plate. Full article

Fiber-reinforced polymer (FRP) composites have been widely employed to design advanced structural columns such as the hybrid FRP–concrete–steel double-skin tubular column (hybrid DSTC) with potential benefits. To date, the safety and self-monitoring of the hybrid DSTCs are still a challenge to overcome due to the complex damage scenarios. This paper investigates the self-sensing performance of a newly developed smart double-skin tubular confined concrete column (smart BFST-DSTC) made of basalt FRP–steel composite with built-in optical fiber Bragg grating sensors (OFBGs). The design of the smart BFST-DSTC and sensing principle are firstly addressed, followed by an experimental investigation on the basic mechanical properties and strain-based sensing performance of ten scaled specimens under axial compression. The outcomes reveal the enhancement of the proposed column in terms of load-carrying capacity, confinement ratio, and axial stress-axial strain behavior, as well as failure and damage modes when compared with the hybrid DSTC. The self-sensing investigation demonstrates that the measurement range satisfies the requirement to monitor and evaluate the hoop strains of the FRP jackets and the health state of the inner tube. The smart BFST-DSTC can replace the hybrid DSTC with the ability to provide early failure warning and life cycle health monitoring. Full article

A diamond-like carbon (DLC) film, coated on a AISI420-J2 stainless steel substrate and vertically aligned graphite (VAG), was structured by high-density plasma oxidation to work as a DLC-punch for micro-stamping and DLC-nozzle array for micro-dispensing, in addition to acting as a copper-plated thermal spreader, respectively. Thick DLC films were micro-patterned by maskless lithography and directly plasma-etched to remove the unmasked regions. Thick VAG (Ca plates were micro-patterned by screen-printing and selectively etched to activate the surface. Raman spectroscopy as well as electric resistivity measurement proved that there was no degradation of VAG by this surface activation. Wet plating was utilized to prove that copper wettability was improved by this surface treatment. Full article

A diamond-like carbon (DLC) film, coated on an SKD11 (alloy tool steel) substrate, was shaped by plasma oxidation to form an assembly of DLC macro-pillars and to be used as a DLC-punch array that is micro-embossed into aluminum sheets. First, the SKD11 steel die substrate was prepared and DLC-coated to have a film thickness of 10 μm. This DLC coating worked as a punch material. The two-dimensional micro-patterns were printed onto this DLC film by maskless lithography. The unprinted DLC films were selectively removed by plasma oxidation to leave the three-dimensional DLC-punch array on the SKD11 substrate. Each DLC punch had a head of 3.5 μm × 3.5 μm and a height of 8 μm. This DLC-punch array was fixed into the cassette die set for a micro-embossing process using a table-top servo-stamper. Furthermore, through numerically controlled micro-embossing, an alignment of rectangular punches was transcribed into a micro-cavity array in the aluminum sheet. The single micro-cavity had a bottom surface of 3.2 μm × 3.2 μm and an average depth of 7.5 μm. A heat-transfer experiment in boiling water was also performed to investigate the effect of micro-cavity texture on bubbling behavior and the boiling curve. Full article

Recycle Aggregate Concrete (RAC) is a common “green” product used for a variety of purposes, although the durability and strength of the material still need more research to adequately determine influences on these parameters. The failure pattern, punching bearing capacity, and deflection variation of wallboard of both ordinary concrete and RAC with various rebar reinforcement diameters and spacing were analyzed. Based on experimental data, the ABAQUS finite element analysis of the thin wallboard was performed, and the calculated results are in good agreement with the experimental results. The results show that the failure characteristics of ordinary concrete wallboards and RAC wallboards are similar, but the brittleness of the RAC specimens is more significant. Under the same reinforcement ratio, concrete material, whether new or recycled, had little effect on the punching bearing capacity of the specimens. In the case of a low reinforcement ratio, increasing the reinforcement ratio (decreasing the spacing of steel bars) can effectively improve the bearing capacity of the wallboard. Under the same reinforcement ratio, the wallboard with larger diameter and larger spacing has a higher bearing capacity and less deformation after failure. Full article
