The inherent non-ideal characteristics of circuit components and inter-channel mismatch errors induce nonlinear amplitude and phase distortions in time-interleaved pipelined analog-to-digital converters (TI-pipelined ADCs), significantly degrading system performance. Limited by prior modeling, conventional digital calibration methods only correct partial errors, while machine learning (ML) approaches achieve comprehensive calibration at a high computational cost. This work proposes an ensemble calibration framework that combines polynomial modeling and ML techniques. The ensemble calibration framework employs a two-stage correction: a learned Volterra front-end performs forward mapping to compensate static baseline nonlinear distortions, while a lightweight neural network back-end implements inverse mapping to correct dynamic nonlinear distortions and inter-channel mismatch errors adaptively. Experiments conducted on TI-pipelined ADCs show improvements in both the spurious-free dynamic range (SFDR) and signal-to-noise and distortion ratio (SNDR). It is noteworthy that in two ADCs fabricated using 40 nm CMOS technology, the 12-bit, 3000 MS/s silicon-validated four-channel TI-pipelined ADC exhibits SFDR and SNDR improvements from 35.47 dB and 35.35 dB to 79.70 dB and 55.63 dB, respectively, while the 16-bit, 1000 MS/s silicon-validated four-channel TI-pipelined ADC demonstrates an enhancement from 38.62 dB and 40.21 dB to 80.90 dB and 62.43 dB, respectively. Furthermore, a comparison with related studies reveals that our method achieves comprehensive calibration performance for wide-band inputs while substantially reducing computational complexity, requiring only 4.4 K parameters and 8.57 M floating-point operations per second (FLOPs). Full article

This paper presents a prototype open-loop pipelined stage in a 45 nm CMOS process for supporting 1.8 GS/s and 10-bit design specifications of pipelined ADCs. In order to alleviate the severe non-linearity expressed by open-loop MDACs, an innovative current-mode harmonic compensation is proposed to provide input related third harmonic terms to cancel non-linearity. In addition, an effective double-sampling scheme is optimized by modifying compensation timing and input of a residual amplifier so that the pipelined stage can be immune to memory effect and improve power efficiency. The memory effect compensation scheme can provide a 21 dB improvement on output SNDR of the double-sampling pipelined stage. The simulation results illustrate that the open-loop pipelined ADC stage achieves an output SNDR of at least 52 dB with 840 mV input amplitude and 240 fF load while consuming only 11.24 mW. Full article

This paper proposes a low-power 10-bit 20 MS/s pipelined analog-to-digital converter (ADC) designed for the burgeoning needs of low-data-rate communication systems, particularly within the Internet of Things (IoT) domain. To reduce power usage, multiple power-saving techniques are combined, such as sample-and-hold amplifier-less (SHA-less) architecture, capacitor scaling, and dynamic comparators. In addition, this paper presents a novel operational amplifier (op-amp) with gain boosting, featuring a dual-input differential pair that enables internal pipeline stage switching, effectively alleviating the crosstalk and memory effects inherent in conventional shared op-amp configurations, thereby further reducing power consumption. A prototype ADC was fabricated in a 180 nm CMOS process and the core size was 0.333 mm². The ADC implemented operated at a 20 MHz sampling rate under a 1.8 V supply voltage. It achieved a spurious-free dynamic range (SFDR) of 61.83 dB and a signal-to-noise-and-distortion ratio (SNDR) of 54.15 dB while demonstrating a maximum differential non-linearity (DNL) of 0.36 least significant bit (LSB) and a maximum integral non-linearity (INL) of 0.67 LSB. Notably, the ADC consumed less than 5 mW of power at the mentioned sampling frequency, showcasing excellent power efficiency. Full article

Data acquisition systems that receive analog signals, convert them to digital, and perform signal processing are used in a variety of systems that use acoustics, radar, sonar, indoor localization, and navigation. The previous systems, such as NI USRP-RIO, are expensive to build, and the number of signals a single device can receive is limited to between two and four. In order to receive more channels of signals, multi-channel data acquisition systems using ADCs operating at tens of MSPS have been proposed. However, these systems require additional processing time because data acquisition and signal processing are performed on different devices. In this paper, we propose a multi-channel data acquisition system using a 16-channel ADC that can support up to 100 MSPS. In particular, to reduce unnecessary signal transmission time, we propose a one-chip structure where all processes are performed on a single chip. Also, we propose a data acquisition system that applies pipelining techniques to enable real-time processing. To verify the proposed system, we used TI ADS52J90 and a Kintex UltraScale KCU105 evaluation board, and confirmed that it is possible to receive and process all channels simultaneously. Furthermore, it is possible to configure a real-time system by adjusting the speed of the signal-processing operation and the speed of the communication interface. Therefore, the proposed system is expected to reduce the cost of system construction by performing signal reception and processing with a single chip, and to reduce the time required for overall signal processing. Full article

Diffusion-weighted imaging (DWI) combined with radiomics can aid in the differentiation of breast lesions. Segmentation characteristics, however, might influence radiomic features. To evaluate feature stability, we implemented a standardized pipeline featuring shifts and shape variations of the underlying segmentations. A total of 103 patients were retrospectively included in this IRB-approved study after multiparametric diagnostic breast 3T MRI with a spin-echo diffusion-weighted sequence with echoplanar readout (b-values: 50, 750 and 1500 s/mm²). Lesion segmentations underwent shifts and shape variations, with >100 radiomic features extracted from apparent diffusion coefficient (ADC) maps for each variation. These features were then compared and ranked based on their stability, measured by the Overall Concordance Correlation Coefficient (OCCC) and Dynamic Range (DR). Results showed variation in feature robustness to segmentation changes. The most stable features, excluding shape-related features, were FO (Mean, Median, RootMeanSquared), GLDM (DependenceNonUniformity), GLRLM (RunLengthNonUniformity), and GLSZM (SizeZoneNonUniformity), which all had OCCC and DR > 0.95 for both shifting and resizing the segmentation. Perimeter, MajorAxisLength, MaximumDiameter, PixelSurface, MeshSurface, and MinorAxisLength were the most stable features in the Shape category with OCCC and DR > 0.95 for resizing. Considering the variability in radiomic feature stability against segmentation variations is relevant when interpreting radiomic analysis of breast DWI data. Full article

Due to nonideal residue amplification, the limited resolution of pipelined analog-to-digital converters (ADCs) has become a popular research topic for ADC designers. High-gain and high-speed amplifiers usually consume too much power for a decent ADC. Hence, this paper proposes a fast and cost-effective foreground calibration strategy for cyclic-pipelined ADCs. The calibration strategy compensates for the gain error due to inter-stage residual amplification, which alleviates the DC gain requirement for internal amplifiers. Unlike other digital calibrations, the proposed scheme is implemented with a cyclic-pipelined structure, and only one parameter needs to be calibrated, whose value can be feasibly calculated by the Fix-Point Iteration algorithm. The proposed calibration scheme is implemented in an area-efficient 16-bit, 2 MS/s cyclic-pipelined ADC, fabricated in 180 nm CMOS technology. The ADC is designed and realized by cycling a 6-bit sub-ADC four times with 1-bit redundancy each time. The calibration algorithm manages to recover the sampled data to 93.85 dB spurious free dynamic range (SFDR) even with a 57.8 dB-DC-gain amplifier. The total power consumption of ADC is 17.92 mW and it occupies an active area of 1.8 mm². Full article

A 16-bit 125 MS/s pipelined analog-to-digital converter (ADC) implemented in a 0.18 $\mathsf{\mu }$m CMOS process is presented in this paper. A sample-and-hold amplifier-less (SHA-less) modified 2.5-bit front-end is adopted, which splits the sampling capacitor in half to eliminate the common-mode voltage buffer. The multiplying-digital-to-analog converter (MDAC) in the first pipeline stage is modified by reusing the sampling capacitor in a foreground digital calibration for improving the ADC linearity. This design can circumvent a dedicated reference buffer to generate the calibration voltages at all comparator thresholds. By calibrating the ADC in the digital domain, the integral non-linearity (INL) is improved from −9.2/10 LSB to −3/2.2 LSB, and the spurious-free dynamic range (SFDR) is optimized by over 8dB. The ADC consumes 154mW (reference buffer and clock included) from a 1.8 V supply. Full article

While wireless sensor node (WSNs) have proliferated with the rise of the Internet of Things (IoT), uniformly sampled analog–digital converters (ADCs) have traditionally reigned paramount in the signal processing pipeline. The large volume of data generated by uniformly sampled ADCs while capturing most real-world signals, which are highly non-stationary and sparse in information content, considerably strains the power budget of WSNs during data transmission. Given the pressing need for intelligent sampling, this work proposes an extrema pulse generator devised to trigger ADCs at significant signal extrema, thereby curbing the volume of data points collected and transmitted, and mitigating transmission power draw. After providing a comprehensive signal-theoretic rationale, we construct and experimentally validate these circuits on a system-on-chip field-programmable analog array in a 350 nm complementary metal-oxide-semiconductor (MOS) process. Operating within a power range of 4.3–12.3 µW (contingent on the input bandwidth requirements), the extrema pulse generator has proven to be capable of effectively sampling both synthetic and natural signals, achieving significant reductions in data volume and signal reconstruction error. Using a nonideality-resilient reconstruction algorithm, that we develop in this work, experimental comparisons between extrema and uniform sampling show that extrema sampling achieves an 18-fold lower normalized root mean square reconstruction error for a quadratic chirp signal, despite requiring 5-fold fewer sample points. Similar improvements in both the reconstruction error and effective sampling rate objectives are found experimentally for an electrocardiogram signal. Using both theoretical and experimental methods, this work demonstrates the potential of extrema-triggered systems for extending Pareto frontiers in modern, resource-constrained sensing scenarios. Full article

Background: Whole-Body Diffusion-Weighted Imaging (WBDWI) is an established technique for staging and evaluating treatment response in patients with multiple myeloma (MM) and advanced prostate cancer (APC). However, WBDWI scans show inter- and intra-patient intensity signal variability. This variability poses challenges in accurately quantifying bone disease, tracking changes over follow-up scans, and developing automated tools for bone lesion delineation. Here, we propose a novel automated pipeline for inter-station, inter-scan image signal standardisation on WBDWI that utilizes robust segmentation of the spinal canal through deep learning. Methods: We trained and validated a supervised 2D U-Net model to automatically delineate the spinal canal (both the spinal cord and surrounding cerebrospinal fluid, CSF) in an initial cohort of 40 patients who underwent WBDWI for treatment response evaluation (80 scans in total). Expert-validated contours were used as the target standard. The algorithm was further semi-quantitatively validated on four additional datasets (three internal, one external, 207 scans total) by comparing the distributions of average apparent diffusion coefficient (ADC) and volume of the spinal cord derived from a two-component Gaussian mixture model of segmented regions. Our pipeline subsequently standardises WBDWI signal intensity through two stages: (i) normalisation of signal between imaging stations within each patient through histogram equalisation of slices acquired on either side of the station gap, and (ii) inter-scan normalisation through histogram equalisation of the signal derived within segmented spinal canal regions. This approach was semi-quantitatively validated in all scans available to the study (N = 287). Results: The test dice score, precision, and recall of the spinal canal segmentation model were all above 0.87 when compared to manual delineation. The average ADC for the spinal cord (1.7 × 10⁻³ mm²/s) showed no significant difference from the manual contours. Furthermore, no significant differences were found between the average ADC values of the spinal cord across the additional four datasets. The signal-normalised, high-b-value images were visualised using a fixed contrast window level and demonstrated qualitatively better signal homogeneity across scans than scans that were not signal-normalised. Conclusion: Our proposed intensity signal WBDWI normalisation pipeline successfully harmonises intensity values across multi-centre cohorts. The computational time required is less than 10 s, preserving contrast-to-noise and signal-to-noise ratios in axial diffusion-weighted images. Importantly, no changes to the clinical MRI protocol are expected, and there is no need for additional reference MRI data or follow-up scans. Full article

This study proposes self-calibration of capacitor mismatch errors for high-resolution pipeline analog-to-digital converters (ADCs). The proposed calibration circuit recursively amplifies the capacitor mismatch error by re-utilizing a multiplying digital-to-analog converter in a pipeline stage without increasing the circuit complexity, and the amplified error voltage is converted into digital code by utilizing the remaining pipeline stages. Error correction is performed by subtracting the digital code from the ADC output during normal operation. A prototype of a 12-bit pipeline ADC is fabricated in a 0.18 µm standard CMOS process. The ADC comprises eight 1.5-bit stages, followed by a 4-bit flash ADC as the final stage; the capacitor mismatch errors in the first two pipeline stages are corrected by utilizing the proposed self-calibration technique. Although the calibration method is employed in a 1.5-bit stage architecture, which uses a gain-of-two switched-capacitor amplifier, it is applicable to different bit-per-stage architectures. The ADC linearity significantly improves after calibration, and this is verified through simulations and measurements. Full article

Antibody–drug conjugates (ADCs) constitute a rapidly expanding category of biopharmaceuticals that are reshaping the landscape of targeted chemotherapy. The meticulous process of selecting therapeutic targets, aided by specific monoclonal antibodies’ high specificity for binding to designated antigenic epitopes, is pivotal in ADC research and development. Despite ADCs’ intrinsic ability to differentiate between healthy and cancerous cells, developmental challenges persist. In this study, we present a rationalized pipeline encompassing the initial phases of the ADC development, including target identification and validation. Leveraging an in-house, computationally constructed ADC target database, termed ADC Target Vault, we identified a set of novel ovarian cancer targets. We effectively demonstrate the efficacy of Surface Plasmon Resonance (SPR) technology and in vitro models as predictive tools, expediting the selection and validation of targets as ADC candidates for ovarian cancer therapy. Our analysis reveals three novel robust antibody/target pairs with strong binding and favourable antibody internalization rates in both wild-type and cisplatin-resistant ovarian cancer cell lines. This approach enhances ADC development and offers a comprehensive method for assessing target/antibody combinations and pre-payload conjugation biological activity. Additionally, the strategy establishes a robust platform for high-throughput screening of potential ovarian cancer ADC targets, an approach that is equally applicable to other cancer types. Full article

As the preferred architecture for high-speed and high-resolution analog-to-digital converters (ADC), the accuracy of pipelined ADC is limited mainly by various errors arising from multiple digital-to-analog converters (MDAC). This paper presents a multi-dimensional (M-D) MDAC calibration based on a genetic algorithm (GA) in a 12-bit 750 MS/s pipelined ADC. The proposed M-D MDAC compensation model enables capacitor mismatch and static interstage gain error (IGE) compensation on the chip and prepares for subsequent background calibration based on a pseudo-random number (PN) injection to achieve accurate compensation for dynamic IGE. An M-D coefficient extraction scheme based on GA is also proposed to extract the required compensation coefficients of the foreground calibration, which avoids falling into local traps through MATLAB. The above calibration scheme has been verified in a prototype 12-bit 750 MS/s pipelined ADC. The measurement results show that the signal-to-noise and distortion ratio (SNDR) and spurious-free dynamic range (SFDR) are increased from 49.9 dB/66.7 dB to 59.6 dB/77.5 dB with the proposed calibration at 25 °C. With the help of background calibration at 85 °C, the SNDR and SFDR are improved by 3.4 dB and 8.8 dB, respectively. Full article

Stability analysis remains a fundamental step in developing a successful imaging biomarker to personalize oncological strategies. This study proposes an in silico contour generation method for simulating segmentation variations to identify stable radiomic features. Ground-truth annotation provided for the whole prostate gland on the multi-parametric MRI sequences (T2w, ADC, and SUB-DCE) were perturbed to mimic segmentation differences observed among human annotators. In total, we generated 15 synthetic contours for a given image-segmentation pair. One thousand two hundred twenty-four unfiltered/filtered radiomic features were extracted applying Pyradiomics, followed by stability assessment using ICC(1,1). Stable features identified in the internal population were then compared with an external population to discover and report robust features. Finally, we also investigated the impact of a wide range of filtering strategies on the stability of features. The percentage of unfiltered (filtered) features that remained robust subjected to segmentation variations were T2w—36% (81%), ADC—36% (94%), and SUB—43% (93%). Our findings suggest that segmentation variations can significantly impact radiomic feature stability but can be mitigated by including pre-filtering strategies as part of the feature extraction pipeline. Full article

The Hyper-Kamiokande is a next-generation neutrinos and nucleon decay experiment. It consists of a huge Water Cherenkov detector and a high-intensity neutrino beam factory with a neutrino near detector complex. We are constructing the detector and planning to start operation in 2027. The photo sensor is one of the key components of the Water Cherenkov detector, and we decided to use large aperture PMTs of $50\mathrm{cm}$ diameter. It is required to prepare suitable digitizer for this particular PMT signal, which has twice as a good performance as those of the current PMTs. They should have sub-ns timing resolution and a wide dynamic range from $𝒪\left(\mathrm{mV}\right)$ to $𝒪\left(\mathrm{V}\right)$. We have developed three designs using different technologies. The first design processes the input signal in a pipeline of charge-to-time conversion and time-to-digital conversion. The second digitizes the input signal with flash-ADC. The third one uses the discrete components of discriminator and sampling ADC to record the timing and the charge of the input signal. Through a detailed evaluation, we have selected the “discrete design” for our readout system. Full article

This paper presents a single-channel 12-bit, 2 GS/s pipelined analog-to-digital converter (ADC) for wideband sampling receivers. The design adopts a novel source follower input buffer with multiple feedback loops to improve sample linearity and extend bandwidth. Additionally, an improved two stages charge pump amplifier topology is introduced, which doubles the Gain Bandwidth Product (GBW) without consuming additional power. To address the back-end ADC and background calibration, a multi-level dither strategy is employed, utilizing a new high-speed and low-cost uniform distribution pseudorandom code generator. The prototype ADC fabricated in 40 nm CMOS process achieves 68.24 dB SFDR up to Nyquist frequency with a sampling rate of 2 GS/s. Measurement results demonstrate a bandwidth exceeding 5 GHz, resulting in a Schreier FOMs of 152.4 dB. Full article
