Search Results (24)

This work shows a three-dimensional (3D) layerwise model for static and free vibration analyses of functionally graded piezomagnetic materials (FGPM) spherical shell structures where magnetic and elastic fields are completely coupled. The 3D magneto-elastic governing equations for spherical shells are made of the three equations of equilibrium in three-dimensional form and the three-dimensional divergence equation for the magnetic induction. Governing equations are written in the orthogonal mixed curvilinear reference system ($\alpha$, $\beta$, z) allowing the analysis of several curved and flat geometries (plates, cylindrical shells and spherical shells) thanks to proper considerations of the radii of curvature. The static cases, actuator and sensor configurations and free vibration investigations are proposed. The resolution method uses the imposition of the Navier’s harmonic forms in the two in-plane directions and the exponential matrix methodology in the transverse normal direction. Single-layered and multilayered simply-supported FGPM structures have been investigated. In order to understand the behavior of FGPM structures, numerical values and trends along the thickness direction for displacements, stresses, magnetic potential, magnetic induction and free vibration modes are proposed. In the results section, a first assessment phase is proposed to demonstrate the validity of the formulation and to fix proper values for the convergence of results. Therefore, a new benchmark section is presented. Different cases are proposed for several material configurations, load boundary conditions and geometries. The possible effects involved in this problem (magneto-elastic coupling and effects related to embedded materials and thickness values of the layers) are discussed in depth for each thickness ratio. The innovative feature proposed in the present paper is the exact 3D study of magneto-elastic coupling effects in FGPM plates and shells for static and free vibration analyses by means of a unique and general formulation. Full article

The thermomechanical effects on aircraft structures in flight are compared between fair weather and a lightning storm based on a model problem, namely, equations of anisothermal unsteady piezoelectromagnetism are solved in the particular case of a parallel-sided slab assuming (i) steady conditions and spatial dependence only on the coordinate orthogonal to the slab; (ii) the displacement vector orthogonal to the slab; (iii) the magnetic field orthogonal to the electric field, with both in the plane parallel to the sides of the slab. The exact analytical solution is obtained in the linear approximation for the displacement vector, electric and magnetic fields and temperature as function of the coordinate normal to the slab, taking into account heating by the Joule effect of Ohmic electric currents and Fourier thermal conduction. These specify the strain and stress tensors, the electric current and the heat flux. The material properties involved include the mass density, dielectric permittivity, magnetic permeability, elastic stiffness tensor, electromagnetic coupling and thermal stress tensors, pyroelectric and pyromagnetic vectors and piezoelectric and piezomagnetic tensors. The analytic results of the theory are simplified assuming (i) isotropic material properties; (ii) a steady state independent of time. The profiles as a function of the coordinate normal to the slab of the electric and magnetic fields, temperature and heat flux and displacement, strain and stress are obtained in these conditions. Full article

Polyimides (PIs) have been extensively used in thin film and micro-electromechanical system (MEMS) processes based on their excellent thermal and mechanical stability and high glass transition temperature. This research explores the development of a novel multilayer and multifunctional polymer composite electro-piezomagnetic device that can function as an energy harvester or sensor for current-carrying wires or magnetic field sensing. The devices consist of four layers of composite materials with a polyimide matrix. The composites have various nanoparticles to alter the functionality of each layer. Nanoparticles of Ag were used to increase the electrical conductivity of polyimide and act as electrodes; lead zirconate titanate was used to make the piezoelectric composite layer; and either neodymium iron boron (NdFeB) or Terfenol-D was used to make the magnetic and magnetostrictive composite layer, which was used as the proof mass. A novel all-polymer multifunctional polyimide composite cantilever was developed to operate at low frequencies. This paper compares the performance of the different magnetic masses, shapes, and concentrations, as well as the development of an all-magnetostrictive device to detect voltage or current changes when coupled to the magnetic field from a current-carrying wire. The PI/PZT cantilever with the PI/NdFeB proof mass demonstrated higher voltage output compared to the PI/Terfenol-D proof mass device. However, the magnetostrictive composite film could be operated without a piezoelectric film based on the Villari effect, which consisted of a single PI-Terfenol-D film. The paper illustrates the potential to develop an all-polymer composite MEMS device capable of acting as a magnetic field or current sensor. Full article

Soft magnetoactive elastomers (MAEs) are currently considered to be promising materials for actuators in soft robotics. Magnetically controlled actuators often operate in the vicinity of a bias point. Their dynamic properties can be characterized by the piezomagnetic strain coefficient, which is a ratio of the time-harmonic strain amplitude to the corresponding magnetic field strength. Herein, the dynamic strain response of a family of MAE cylinders to the time-harmonic (frequency of 0.1–2.5 Hz) magnetic fields of varying amplitude (12.5 kA/m–62.5 kA/m), superimposed on different bias magnetic fields (25–127 kA/m), is systematically investigated for the first time. Strain measurements are based on optical imaging with sub-pixel resolution. It is found that the dynamic strain response of MAEs is considerably different from that in conventional magnetostrictive polymer composites (MPCs), and it cannot be described by the effective piezomagnetic constant from the quasi-static measurements. The obtained maximum values of the piezomagnetic strain coefficient (∼${10}^2$ nm/A) are one to two orders of magnitude higher than in conventional MPCs, but there is a significant phase lag (35–60°) in the magnetostrictive response with respect to an alternating magnetic field. The experimental dependencies of the characteristics of the alternating strain on the amplitude of the alternating field, bias field, oscillation frequency, and aspect ratio of cylinders are given for several representative examples. It is hypothesized that the main cause of observed peculiarities is the non-linear viscoelasticity of these composite materials. Full article

The study uses complex variable functions and conformal mapping to investigate the scattering and dynamic stress concentration phenomena of SH waves in non-circular opening magnetic–elastic materials. Elastic dynamics and piezomagnetic equations are employed to derive expressions for the scattered wave intensity and dynamic stress concentration coefficient around non-circular openings. Special attention is devoted to elliptical openings, where different incident angles and dimensionless wave numbers exhibit varying effects on the dynamic stress concentration coefficients. The numerical results indicate a positive correlation between the dynamic stress concentration coefficient and the illumination region of elliptical openings, with low wave numbers exerting a more significant influence. These findings provide a valuable theoretical foundation for studying fatigue mechanics in piezomagnetic materials. Therefore, to enhance the performance and reliability of piezomagnetic materials, it is imperative to conduct elastic dynamic analysis of non-circular defects in low-frequency environments. Full article

The magnetoelectric (ME) sensor is a new type of magnetic sensor with ultrahigh sensitivity that suitable for the measurement of low-frequency weak magnetic fields. In this study, a metglas/PZT-5B ME sensor with mechanical resonance frequency $f_{res}$ of 60.041 kHz was prepared. It is interesting to note that its magnetic field resolution reached 0.20 nT at $f_{res}$ and 0.34 nT under a DC field, respectively. In order to measure ultralow-frequency AC magnetic fields, a frequency up-conversion technique was employed. Using this technique, a limit of detection (LOD) under an AC magnetic field lower than 1 nT at 8 Hz was obtained, and the minimum LOD of 0.51 nT was achieved at 20 Hz. The high-resolution ME sensor at the sub-nT level is promising in the field of low-frequency weak magnetic field measurement technology. Full article

A beam-like structure of antisymmetric laminated multiferroic piezoelectric semiconductor (LMPS), which consists of two piezomagnetic (PM) and two piezoelectric semiconductor (PS) layers is proposed. The structure could be in pure flexure deformation under an applied magnetic field. Through this deformation mode and the induced polarization field through the magneto-electro-semiconductive (MES) coupling mechanism, the semiconducting properties of PS layers can be manipulated by the applied magnetic field. In order to better understand and quantitatively describe this deformation mode, the one-dimensional governing equations for the LMPS beam are developed based on the three-dimensional theory. The analytical solutions are then presented for the LMPS cantilever beam with open-circuit conditions. The multi-field coupling responses of the LMPS cantilever beam under the longitudinal magnetic field are investigated. Numerical results show that the amplitude of each physical quantity is proportional to the applied magnetic field, and the thickness ratio of the PS phase plays a significant role in the MES coupling behaviors of the LMPS beam. The proposed structure can be integrated into cement structures but also fabricated cement-based multiferroic PS composite materials and structures. It provides an important material and structure basis for developing structural health monitoring systems in the fields of civil and transportation infrastructures. Full article

Based on the theory of magnetoacoustic coupled dynamics, the purpose of this paper is to evaluate the dynamic stress concentration near an elliptical opening in exponential-gradient piezomagnetic materials under the action of antiplane shear waves. By the wave function expansion, the solutions for the acoustic wave fields and magnetic fields can be obtained. Stress analysis is performed by the complex function method and the conformal mapping method, which are used to solve the boundary conditions problem, and is used to express the dynamic stress concentration coefficient (DSCC) theoretically. As cases, numerical results of DSCCs are plotted and discussed with different incident wave numbers and material parameters by numerical simulation. Compared with circular openings, elliptical openings are widely used in material processing techniques and are more difficult to solve. Numerical results show that the dynamic stress concentration coefficient at the elliptical opening is strongly dependent on various parameters, which indicates that the elliptical opening is more likely to cause crack and damage to exponential-gradient piezomagnetic materials. Full article

The loss effect in smart materials, the active part of a transducer, is of significant importance to acoustic transducer designers, as it directly affects the important characteristics of the transducer, such as the impedance spectra, frequency response, and the amount of heat generated. It is therefore beneficial to be able to incorporate energy losses in the design phase. For high-power low-frequency transducers requiring more smart materials, losses become even more appreciable. In this paper, similar to piezoelectric materials, three losses in Terfenol-D are considered by introducing complex quantities, representing the elastic loss, piezomagnetic loss, and magnetic loss. The frequency-dependent eddy current loss is also considered and incorporated into the complex permeability of giant magnetostrictive materials. These complex material parameters are then successfully applied to improve the popular plane-wave method (PWM) circuit model and finite element method (FEM) model. To verify the accuracy and effectiveness of the proposed methods, a high-power Tonpilz Terfenol-D transducer with a resonance frequency of around 1 kHz and a maximum transmitting current response (TCR) of 187 dB/1A/μPa is manufactured and tested. The good agreement between the simulation and experimental results validates the improved PWM circuit model and FEA model, which may shed light on the more predictable design of high-power giant magnetostrictive transducers in the future. Full article

In order to reveal the magnetic field response law and mechanism of concrete under load, the variation law of magnetic field intensity (MFI) of concrete samples under uniaxial loading, graded loading and cyclic loading was tested, and the field application scenarios of magnetic field monitoring technology are proposed. The results showed that a magnetic field signal would be generated during the loading failure process of the concrete sample, which was accompanied by the whole loading process. In the uniaxial compression process, MFI showed a steady increase trend, but it would increase rapidly when the load drop occurred in the sample. The stronger the rupture, the more significant the change of MFI. MFI was not linearly proportional to the amount of change in the load drop. MFI around the concrete sample was positively correlated with the load. When the concrete was in the constant load stage, MFI around the concrete remained basically stable. When the main rupture of the concrete sample occurred, MFI reached a peak value, it did not keep at a high level all the time, but decreased rapidly. There are two mechanisms for the generation of the magnetic field in the process of concrete failure under load, namely the piezomagnetic effect and the friction effect, which correspond to the action of the load and the excitation of the fracture, respectively. The former causes the stable increase of MFI, and the effect is related to the influence of the content of the piezoelectric magnetic material in the material composition; the latter leads to a sudden increase of MFI, and the effect is related to the triboelectric effect of the micro-particles of the material. The research results are conducive to the accurate prediction of the concrete magnetic field monitoring, and help promote the development of mine dynamic disaster monitoring and early warning technology. Full article

Magnetic sensors actuated by bulk acoustic wave (BAW) have attracted extensive attention due to the fact of their high sensitivity, GHz-level high frequency, and small size. Different from previous studies, suppression of energy loss and improvement in energy conversion efficiency of the BAW magnetoelectric (ME) sensor were systematically considered during the device design in this work. Finite element analysis models of material (magnetic composite), structure (ME heterostructure), and device (BAW ME magnetic sensor) were established and analyzed in COMSOL software. Additionally, the magnetic composite was prepared by radio frequency magnetron sputtering, and its soft magnetism was characterized by magnetic hysteresis loop and surface roughness. The research results demonstrate that after inserting four layers of 5 nm Al₂O₃ films, a performance of 86.7% eddy current loss suppression rate, a less than 1.1% magnetostriction degradation rate, and better soft magnetism were achieved in 600 nm FeGaB. Furthermore, compared with other structures, the two-layer piezomagnetic/piezoelectric heterostructure had a better ME coupling performance. Eventually, the design of the BAW ME magnetic sensor was optimized by the resonance-enhanced ME coupling to match the resonance frequency between the magnetic composite and the BAW resonator. When a 54,500 A/m direct current bias magnetic field was applied, the sensor worked at the first-order resonance frequency and showed good performance. Its linearity was better than 1.30%, the sensitivity was as high as 2.33 μmV/A, and the measurement range covered 0–5000 A/m. Full article

Uniaxial fatigue testing of micro-mechanical metallic specimens can provide valuable insight into damage formation. Magnetic and piezomagnetic testing are commonly used for qualitative characterization of damage in ferromagnetic specimens. Sensitive and accurate measurements with magnetic sensors is a key part of such a characterization. This work presents an experimental setup to induce structural defects in a micro-mechanical fatigue test. Simultaneously, the resulting piezomagnetic signals are measured during the complete lifetime of the tested specimen. The key component is a highly sensitive optically pumped magnetometer (OPM) used to measure the piezomagnetic hysteresis of a small specimen whose structural defects can be analyzed on a small scale by other metallographic characterization methods as well. This setup aims to quantify the magnetic signatures of damage during the fatigue process, which could enable non-destructive mechanical testing of materials. This paper reports the initial results obtained from this novel micro-magneto-mechanical test setup for a ferritic steel specimen. Full article

Fe–Co alloys are attracting attention as magnetostrictive materials for energy harvesting and sensor applications. This work investigated the magnetostriction characteristics and crystal structure of additive-manufactured Fe–Co alloys using directed energy deposition. The additive-manufactured Fe–Co parts tended to exhibit better magnetostrictive performance than the hot-rolled Fe–Co alloy. The anisotropy energy ΔK₁ for the Fe–Co bulk, prepared under a power of 300 W (referred to as bulk−300 W), was larger than for the rolled sample. For the bulk−300 W sample in a particular plane, the piezomagnetic constant d was large, irrespective of the direction of the magnetic field. Elongated voids that formed during additive manufacturing changed the magnetostrictive behavior in a direction perpendicular to these voids. Magnetic property measurements showed that the coercivity decreased. Since sensors should be highly responsive, Fe–Co three-dimensional parts produced via additive manufacturing can be applied as force sensors. Full article

A new model of non-classical phononic crystal (PC) microbeam for the elastic wave bandgap generation is provided, incorporating microstructure, piezomagnetism, piezoelectricity and temperature effects. The wave equation of a general magneto–electro–elastic (MEE) phononic crystal microbeam is derived, which recovers piezoelectric- and piezomagnetic-based counterparts as special cases. The piezomagnetic and piezoelectric materials are periodically combined to construct the PC microbeam and corresponding bandgaps are obtained by using the plane wave expansion (PWE) method. The effects of the piezomagnetism, piezoelectricity, microstructure, geometrical parameters and applied multi-fields (e.g., external electric potential, external magnetic potential, temperature change) on the bandgaps are discussed. The numerical results reveal that the bandgap frequency is raised with the presence of piezo and microstructure effects. In addition, the geometry parameters play an important role on the bandgap. Furthermore, large bandgaps can be realized by adjusting the external electric and magnetic potentials at micron scale, and lower bandgap frequency can be realized through the temperature rise at all length scales. Full article

Strain-mediated multiferroic composite structures are gaining scientific and technological attention because of the promise of low power consumption and greater flexibility in material and geometry choices. In this study, the direct magnetoelectric coupling coefficient (DME) of composite multiferroic cylinders, consisting of two mechanically bonded concentric cylinders, was analytically modeled under the influence of a radially emanating magnetic field. The analysis framework emphasized the effect of demagnetization on the overall performance. The demagnetization effect was thoroughly considered as a function of the imposed mechanical boundary conditions, the geometrical dimensions of the composite cylinder, and the introduction of a thin elastic layer at the interface between the inner piezomagnetic and outer piezoelectric cylinders. The results indicate that the demagnetization effect adversely impacted the DME coefficient. In a trial to compensate for the reduction in peak DME coefficient due to demagnetization, a non-dimensional geometrical analysis was carried out to identify the geometrical attributes corresponding to the maximum DME. It was observed that the peak DME coefficient was nearly unaffected by varying the inner radius of the composite cylinder, while it approached its maximum value when the thickness of the piezoelectric cylinder was almost 60% of the total thickness of the composite cylinder. The latter conclusion was true for all of the considered boundary conditions. Full article
