Wind energy harvesting based on triboelectric nanogenerators (TENGs) is a promising solution for powering distributed Internet of Things (IoT) nodes, yet its practical efficiency and stability are often hindered by the fluctuating and unpredictable nature of wind. Here, we propose a self-regulating TENG (SR-TENG) that leverages the synergistic effects of centrifugal, elastic, and frictional forces to automatically switch between non-contact and contact modes based on wind speed. This configuration achieves an ultra-low start-up wind speed of 0.86 m/s, ensures sustainable high-performance output across a broad wind speed range, and exhibits excellent durability with no observable performance degradation during 23,000 s of continuous operation at 375 rpm. Systematic structural optimization enables the SR-TENG to reach a peak open-circuit voltage of 140 V, a short-circuit current of 12.5 μA, and a transferred charge of 300 nC at 375 rpm. When integrated with a customized power management circuit, the system delivers a 30.39-fold increase in effective output power at a 1 MΩ load and a 4-fold faster charging rate for a 10 μF capacitor. For practical validation, the harvested ambient wind energy successfully powers a wireless temperature-humidity sensor for real-time cloud data transmission. These results highlight that the SR-TENG holds great potential for advanced wind energy harvesting and self-powered sensing applications in distributed IoT systems. Full article

The cyber–physical integrated power distribution system is poised to become the predominant trend in the development of future power systems. Although the highly intelligent panoramic link information system in substations facilitates the efficient, cost-effective, and secure operation of the power system, it is also exposed to dual threats from both internal and external factors. Under intentional cyber information attacks, the operational data and equipment response capabilities of the panoramic link information system within smart substations can be illicitly manipulated, thereby disrupting dispatcher response decision-making and resulting in substantial losses. To tackle this challenge, this paper delves into the research on automatic verification and active defense mechanisms for the cyber–physical power distribution system under panoramic link attacks in smart substations. Initially, to mitigate internal risks stemming from the uncertainty of new energy output information, this paper utilizes a CGAN-IK-means model to generate representative scenarios. For scenarios involving external intentional cyber information attacks, this paper devises a fixed–flexible adjustment resource response strategy, making up for the shortfall in equipment response capabilities under information attacks through flexibility resource regulation. The proposed strategy is assessed based on two metrics, voltage level and load shedding volume, and computational efficiency is optimized through an enhanced firefly algorithm. Ultimately, the efficacy and viability of the proposed method are verified and demonstrated using a modified IEEE standard test system. Full article

In order to adapt to the development trend of large-scale access of distributed resource and power market reform, it has gradually become an industry consensus that multi-agent resources of a distribution network participate in regulation in the form of clusters. Based on the “centralized–distributed” regulation architecture, and relying on the regulation process of cluster partition, external characteristics calculation, command decomposition, and deaggregation, a cluster regulation strategy is proposed considering market factors. Firstly, the behavior characteristics of each agent are analyzed under the market trading mechanism. Then, the model of multi-agents participating in regulation in the form of a single point and a cluster is established. In the process of cluster partition, considering the active and reactive power–voltage coupling characteristics of the distribution network, a Monte Carlo random cluster partition sample generation method and screening mechanism are designed to deal with the problem of insufficient and inapplicable samples in the actual scene. At the same time, in order to reduce the difficulty of solving the cluster’s external characteristics, a multi-agent output range simplification method is proposed for the process of “external characteristics calculation”. Finally, the improved IEEE-33 bus system was taken as an example to verify the accuracy of the cluster regulation method when responding to the Automatic Generation Control (AGC) and Automatic Voltage Control (AVC) scheduling commands of the superior grid under market factors and different cluster partitions. The results show that the relative error of the command tracking of the proposed multi-agents in different cluster forms is less than 5.5%, which verifies the correctness of the proposed method. Full article

Virtual synchronous generator (VSG) control, which can provide inertia output, damp power oscillations, and offer frequency and voltage support to power grids, has become a growing trend in the control field of wind power generation. As a new technology, there are still challenges that VSG control has not solved well, such as transient overvoltage suppression. A kind of transient overvoltage, which often occurs during the commutation failures of HVDC transmission systems, will trigger a mass of wind turbine generators (WTGs) disconnecting from grids. To reduce the grid-disconnection risk of the virtual synchronous generator control-based doubly fed induction generators (VSG-DFIGs), this paper first analyzes the mechanism of the automatic voltage regulation (AVR) control usually employed by VSG-DFIGs, then proposes measures to suppress the transient overvoltage. To solve the problem of the reactive power response lag issued by VSG-DFIGs, which will further aggravate the transient overvoltage in continuous low and high voltage faults, the time constant of the AVR control is switched. To fully exploit the potential of the DFIGs’ reactive power support, the droop coefficient of the AVR control is switched during the abnormal voltage stages. The switched droop coefficient will change the rotor excitation current magnitude, thus adjusting the internal potential of a DFIG, finally better supporting or suppressing the terminal voltage during the low or high voltage periods. Simulation results based on the DIgSILENT/PowerFactory platform demonstrate that the proposed method can effectively suppress the transient overvoltage that occurs in continuous low and high voltage events caused by the commutation failures of HVDC transmission systems, reducing the number of WTGs disconnecting from the grids. Full article

Wind power is currently the most mature representative of sustainable energy generation technology, which has been developed and utilized on a large scale worldwide. The random and fluctuating nature of wind power output poses a threat to the secure and stable operation of the system. Consequently, the transmission of wind power has garnered considerable attention as a crucial factor in mitigating the challenges associated with wind power integration. In this paper, an artificial-intelligence-aided frequency coordination control strategy applicable to wind power transmission systems based on hybrid DC transmission technology is proposed. The line commutated converter (LCC) station at the sending end implements the strategy of auxiliary frequency control (AFC) and automatic generation control (AGC) to cooperate with each other in order to assist the system frequency regulation. The AFC controller is designed based on the variable forgetting factor recursive least squares (VFF-RLS) algorithm for system identification. First, the VFF-RLS algorithm is used to identify the open-loop transfer function of the system. Then, the AFC controller is designed based on the root locus method to achieve precise control of the system frequency. The DC line power modulation quantity is introduced in the AGC to automatically track the active power fluctuation and frequency deviation of the system. The AGC utilizes the classical proportional-integral (PI) control. By selecting the integrated time absolute error (ITAE) performance index to construct the reward function, and using a deep Q-network (DQN) for controller parameter optimization, it achieves improved regulation performance for the AGC. The voltage source converter (VSC) station at the receiving end implements an adaptive DC voltage droop control (ADC)strategy. Finally, the effectiveness and robustness of the proposed frequency control strategy are verified through simulation experiments. Full article

In power engineering, the importance of maintaining a high power factor in low-voltage electrical installations is known. In power substations for industry, the usual method of coupling is to use an automatic power factor controller which connects capacitors banks (with electromagnetic contactors). Sometimes, AC reactors are connected to the phases of the capacitors banks (to reduce transient phenomena and the deforming regime), depending on the desired value of the power factor. This paper presents an analysis (more focused on experimentation) of a low-cost system for automatic regulation of the power factor with a reduction in transients and an increase in the life of contactors (eliminating the electric arc during switching on), with capacitors banks for low-voltage three-phase installations that connect the capacitors banks by means of one three-phase solid-state relay (an expensive device for a quality device; one is used for all capacitors banks) and using several electromagnetic contactors. The automatic power factor adjustment system has a controller with a microprocessor with six outputs, controlled by the phase shift between the current (measured with a current transformer proportional to the current in a bar) and the phase voltage, which is part of a system of distribution bars (L1,2,3, N) from which electrical consumers (e.g., induction motors) are supplied. To reduce transients when connecting capacitors banks, a three-phase solid-state relay and two related electromagnetic contactors are used for each capacitors bank. The automatic power factor controller is connected to two low-capacity PLCs that control the logic of connecting the capacitors banks to reduce transients. By using the proposed regulation system, a cheaper control solution is obtained compared to the use of one solid-state relay for each capacitors banks, under the conditions in which the power factor adjustment is made as in the classic solution. If twelve capacitors banks are used, the proposed installation is 22.57% cheaper than the classical power factor regulation installation. Full article

Frequency tracking and amplitude control are essential for piezoelectric transducers. Frequency tracking ensures the piezoelectric transducer operates at the resonant frequency for maximum power output, and amplitude control regulates the mechanical motion of the output. This paper presents a novel driver based on a push–pull inverter for piezoelectric transducers. The proposed driver realizes the frequency tracking and amplitude control scheme by a voltage sensing bridge in the case of transformer secondary matching, guaranteeing automatic frequency tracking and precise mechanical functions regardless of environmental and load variations. The proposed scheme is verified by the ultrasonic scalpel and the ultrasonic motor (USM). The experimental results show that this scheme reduces the build-up time from 10 ms to 3 ms and loaded frequency variations from 250 Hz to 200 Hz. In addition, the amplitude control performance was further observed on USM for various loads. The overshoot is less than 5.4% under different load torques. Therefore, the proposed scheme improves the load adaptability and stability of piezoelectric transducers and promotes the application of piezoelectric transducers under various conditions. Full article

In the literature, different approaches that are employed in designing automatic voltage regulators (AVRs) usually model the AVR as a single-input-single-output system, where the input is the generator reference voltage, and the output is the generator voltage. Alternately, it could be thought of as a double-input, single-output system, with the excitation voltage change serving as the additional input. In this paper, unlike in the existing literature, we designed the AVR system as a sextuple-input single-output (6ISO) system. The inputs in the model include the generator reference voltage, regulator signal change, exciter signal change, amplifier signal change, generator output signal change, and the sensor signal change. We also compared the generator voltage responses for various structural configurations and regulator parameter choices reported in the literature. The effectiveness of numerous controllers is investigated; the proportional, integral and differential (PID) controller, the PID with second-order derivative (PIDD2) controller, and the fractional order PID (FOPID) controller are the most prevalent types of controllers. The findings reveal that the regulator signal change and the generator output signal change significantly impact the generator voltage. Based on these findings, we propose a new approach to design the regulator parameter to enhance the response to generator reference voltage changes. This approach takes into consideration changes in the generator reference voltage as well as the regulator signal. We calculate the regulator settings using a cutting-edge hybrid technique called the Particle Swarm Optimization African Vultures Optimization algorithm (PSO–AVOA). The effectiveness of the regulator design technique and the proposed optimization algorithm are demonstrated. Full article

This paper introduces a novel power supply voltage adjustment strategy that can determine the optimum voltage value based on the amount of absorbed power. The novel automatic voltage adjustment technique was called inverse maximum power point tracking (iMPPT). The proposed control strategy consists of a modified maximum power point tracking (MPPT) algorithm (more precisely the P&O method). In this case, the modified MPPT technique establishes the minimum value of the input absorbed power of a consumer load served by a switched-mode power supply (SMPS). The iMPPT adjusts the input power by modifying the input voltage of the main power supply. The served loads are connected to the variable power supply via an interfacing power electronics converter that performs the automatic voltage regulation function (AVR). The optimal value of the input voltage level can be achieved when the input power of the automatic voltage regulation converter is at a minimum. In that case, the energy conversion efficiency ratio is at a maximum, and the overall losses related to the front-end power stage are at a minimum. The proposed technique can also be considered a Maximum Efficiency Tracking (MET) method. By performing the inverse operation of a maximum power point tracking algorithm on the input demanded power of a switched mode power supply (SMPS), the optimum input voltage level can be determined when the maximum energy conversion ratio (related to a given load level) is achieved. The novel proposed iMPPT method can improve the energy conversion ratio from 85% up to approximately 10% in the case of an output power level of 800 W served by a synchronous buck converter at the input voltage level of 350 V. The total amount of recovered power in this situation can be approximately 100 W. Full article

The stability control of nominal frequency and terminal voltage in an interconnected power system (IPS) is always a challenging task for researchers. The load variation or any disturbance affects the active and reactive power demands, which badly influence the normal working of IPS. In order to maintain frequency and terminal voltage at rated values, controllers are installed at generating stations to keep these parameters within the prescribed limits by varying the active and reactive power demands. This is accomplished by load frequency control (LFC) and automatic voltage regulator (AVR) loops, which are coupled to each other. Due to the complexity of the combined AVR-LFC model, the simultaneous control of frequency and terminal voltage in an IPS requires an intelligent control strategy. The performance of IPS solely depends upon the working of the controllers. This work presents the exploration of control methodology based on a proportional integral–proportional derivative (PI-PD) controller with combined LFC-AVR in a multi-area IPS. The PI-PD controller was tuned with recently developed nature-inspired computation algorithms including the Archimedes optimization algorithm (AOA), learner performance-based behavior optimization (LPBO), and modified particle swarm optimization (MPSO). In the earlier part of this work, the proposed methodology was applied to a two-area IPS, and the output responses of LPBO-PI-PD, AOA-PI-PD, and MPSO-PI-PD control schemes were compared with an existing nonlinear threshold-accepting algorithm-based PID (NLTA-PID) controller. After achieving satisfactory results in the two-area IPS, the proposed scheme was examined in a three-area IPS with combined AVR and LFC. Finally, the reliability and efficacy of the proposed methodology was investigated on a three-area IPS with LFC-AVR with variations in the system parameters over a range of  ± 50%. The simulation results and a comprehensive comparison between the controllers clearly demonstrates that the proposed control schemes including LPBO-PI-PD, AOA-PI-PD, and MPSO-PI-PD are very reliable, and they can effectively stabilize the frequency and terminal voltage in a multi-area IPS with combined LFC and AVR. Full article

A dual-mode hybrid step-up circuit for electromagnetic energy harvesting (EVEH) is proposed in this paper, with the merits of continuous output power delivery with and without external vibrations, simple architecture, and no need for extra circuits to start up. The proposed hybrid converter combines a multi-stage voltage multiplier (VM) with a boost regulator, which utilizes the winding inductance of the electromagnetic energy harvester as a boost inductor. With external vibration, the proposed circuit powers the load and stores energy in the super-capacitor through VM mode. When external vibration disappears, it automatically switches to boost mode and powers the load using the energy stored in the supercapacitor. For hybrid mode operation, the number of VM stages is optimized considering the following three aspects: sufficient voltage gains when vibration is on, time durations to provide constant power when vibration is off for as long as possible, and low losses at VM stage. A GaN-based dual-mode hybrid converter is built to verify the output regulation capability with an in-house-designed electromagnetic energy harvester. The outputs of the hybrid circuit achieve 4.05 V and 1.64 mW at a 100-Hz external vibration frequency and an acceleration of 0.7 g. The peak efficiency of the proposed hybrid converter reaches 60.7%. When external vibration disappears, the circuit is able to maintain a stable output for 13 s with a super-capacitor of 0.1 F. Full article

This paper presents a new control technique based on uncertain fuzzy models for handling uncertainties in nonlinear dynamic systems. This approach is applied for the stabilization of a multimachine power system subject to disturbances. In this case, a state-feedback controller based on parallel distributed compensation (PDC) is applied for the stabilization of the fuzzy system, where the design of control laws is based on the Lyapunov function method and the stability conditions are solved using a linear matrix inequalities (LMI)-based framework. Due to the high number of system nonlinearities, two steps are followed to reduce the number of fuzzy rules. Firstly, the power network is subdivided into sub-systems using Thevenin’s theorem. Actually, each sub-system corresponds to a generator which is in series with the Thevenin equivalent as seen from this generator. This means that the number of sub-systems is equal to the number of system generators. Secondly, the significances of the nonlinearities of the sub-systems are ranked based on their limits and range of variation. Then, nonlinearities with non-significant variations are assumed to be uncertainties. The proposed strategy is tested on the Western systems coordinating council (WSCC) integrated with a wind turbine. The disturbances are assumed to be sudden variations in wind power output. The effectiveness of the suggested fuzzy controller is compared with conventional regulators, such as an automatic voltage regulator (AVR) and power system stabilizers (PSS). Full article

The introduction of solar photovoltaic (PV) systems would provide electricity accessibility to rural areas that are far from or have no access to the grid system. Various countries are planning to reduce their emissions from fossil fuel, due to its negative effects, by substituting with renewable energy resources. The use of solar PV systems is expanding globally because of growing energy demands and depleting fossil fuel reserves. Grid integration of the solar system is expected to increase further in the near future. However, the power output of solar PV systems is inherently intermittent, and depends on the irradiance and the temperature operation of the solar cell, resulting in a wide range of defects. Hence, it is vital to extract peak power from the solar panel in all conditions to provide constant power to the load. This paper presents a tracking control method of the peak output power of a solar PV system connected to a DC-DC boost converter using an improved incremental conductance and integral regulator (IC + IR). The research was carried out because the solar PV output is dependent on environmental parameters, such as solar insolation and temperature. Therefore, it is pertinent to forecast the peak power point in outdoor conditions and to operate at that point, so that solar PV can produce the highest output each time it is used. A peak power point strategy that maximizes the output of a solar PV array is proposed. This method establishes the maximum output operation point under the effects of the solar insolation and the module temperature. An automatic converter restoration scheme with block/de-block signal control is proposed to protect the converters from the higher phase current, total capacitor voltage deviation, grid disturbance, and fault current. The proposed scheme also tracks the peak power point (PPP) of the solar array with stable output voltage under varying operating conditions. It reduces the error signal and ripples at the PPP during instantaneous and incremental conductance to zero. In addition, it controls the solar PV system under constantly changing climatic conditions, and thus improves the system efficiency. Full article

The subject of this publication is a method of controlling the DC voltage of a PWM rectifier supplied by a multiphase cage induction generator with the number of stator phases greater than three operating in a wide range of driving speeds. Voltage regulation is performed by changing the frequency and amplitude of the stator voltages with simultaneous switching of the phase sequence of these voltages. The step change of the voltage sequence is made in the designated ranges of the generator speed, which enables the stabilization of the output voltage in a wide range from the minimum speed of about 25% of the rated speed. Such sequence switching changes the number of pole pairs produced by the winding for each supply sequence. The difference compared to multi-speed induction machines is that, in the presented solution, there is only one winding, not a few, which enables good use of the machine’s magnetic core in the same dimensions as for the three-phase machine of a similar power. Steady-state characteristics and dynamic operation were obtained using laboratory measurements of a standalone nine-phase induction generator. The automatic control system maintained the output voltage at the set level, regardless of the generator load and driving power. Full article

One of the main characteristics of power systems is keeping voltages within given limits, done by implementing fast automatic voltage regulators (AVR), which can raise generator voltage (i.e., excitation voltage) in a short time to ceiling voltage limits while simultaneously affecting the damping component of the synchronous generator electromagnetic torque. The efficient way to increase damping in the power system is to implement a power system stabilizer (PSS) in the excitation circuit of the synchronous generator. This paper proposes an enhanced algorithm for PSS tuning in the multimachine system. The algorithm is based on the analysis of system participation factors and the pole placement method while respecting the time domain behavior of the system after being subdued with a small disturbance. The observed time-domain outputs, namely active power, speed, and rotor angle of the synchronous generator, have been classified and validated with proposed weight functions based on the minimal square deviation between the initial values in a steady-state and all sampled values during the transitional process. The system weight function proposed in this algorithm comprises s-domain and time-domain indices and represents a novel approach for PSS tuning. The proposed algorithm performance is validated on IEEE 14-bus system with a detailed presentation of the results in a graphical and table form. Full article
