Enhancing the resilience of renewable energy systems in ultra-weak grids is crucial for promoting sustainable energy adoption and ensuring a reliable power supply during disturbances. Ultra-weak grids characterized by a very low Short-Circuit Ratio, less than 2, and high grid impedance significantly impair voltage and frequency stability, imposing challenging conditions for Inverter-Based Resources. To address these challenges, this paper considers a 110 KVA, three-phase, two-level Voltage Source Converter, interfacing a 700 V DC link to a 415 V AC ultra-weak grid. X/R = 1 is controlled using Sinusoidal Pulse Width Modulation, where the Grid-Connected Converter operates in Grid-Forming Mode to maintain voltage and frequency stability under a steady state. During symmetrical and asymmetrical faults, the converter transitions to Grid-Following mode with current control to safely limit fault currents and protect the system integrity. After fault clearance, the system seamlessly reverts to Grid-Forming Mode to resume voltage regulation. This paper proposes an improved control strategy that integrates voltage feedforward reactive power support and virtual capacitor-based virtual inertia using Active Disturbance Rejection Control, a robust, model-independent controller, which rapidly rejects disturbances by regulating d and q-axes currents. To test the practicality of the proposed system, real-time implementation is carried out using the OPAL-RT OP4610 platform, and the results are experimentally validated. The results demonstrate improved fault current limitation and enhanced DC link voltage stability compared to a conventional PI controller, validating the system’s robust Fault Ride-Through performance under ultra-weak grid conditions. Full article

To address the challenges of prolonged current isolation times and high dependency on varistors in traditional flexible short-circuit fault isolation schemes for DC systems, this paper proposes a rapid fault isolation circuit design based on an adaptive solid-state circuit breaker (SSCB). By introducing an adaptive current-limiting branch topology, the proposed solution reduces the risk of system oscillations induced by current-limiting inductors during normal operation and minimizes steady-state losses in the breaker. Upon fault occurrence, the current-limiting inductor is automatically activated to effectively suppress the transient current rise rate. An energy dissipation circuit (EDC) featuring a resistor as the primary energy absorber and an auxiliary varistor (MOV) for voltage clamping, alongside a snubber circuit, provides an independent path for inductor energy release after faults. This design significantly alleviates the impact of MOV capacity constraints on the fault isolation process compared to traditional schemes where the MOV is the primary energy sink. The proposed topology employs a symmetrical bridge structure compatible with both pole-to-pole and pole-to-ground fault scenarios. Parameter optimization ensures the IGBT voltage withstand capability and energy dissipation efficiency. Simulation and experimental results demonstrate that this scheme achieves fault isolation within 0.1 ms, reduces the maximum fault current-to-rated current ratio to 5.8, and exhibits significantly shorter isolation times compared to conventional approaches. This provides an effective solution for segment switches and tie switches in millisecond-level self-healing systems for both low-voltage (LVDC, e.g., 750 V/1500 V DC) and medium-voltage (MVDC, e.g., 10–35 kV DC) smart DC distribution grids, particularly in applications demanding ultra-fast fault isolation such as data centers, electric vehicle (EV) fast-charging parks, and shipboard power systems. Full article

This paper proposes a dual-mode CMOS analog front-end (AFE) circuit for short-wave infrared (SWIR) image sensors, which integrates a hybrid readout circuit (ROIC) and a 12-bit two-step single-slope analog-to-digital converter (TS-SS ADC). The ROIC dynamically switches between buffered-direct-injection (BDI) and direct-injection (DI) modes, thus balancing injection efficiency against power consumption. While the DI structure offers simplicity and low power, it suffers from unstable biasing and reduced injection efficiency under high background currents. Conversely, the BDI structure enhances injection efficiency and bias stability via an input buffer but incurs higher power consumption. To address this trade-off, a dual-mode injection architecture with mode-switching transistors is implemented. Mode selection is executed in-pixel via a low-leakage transmission gate and coordinated by the column timing controller, enabling low-current pixels to operate in low-noise BDI mode, whereas high-current pixels revert to the low-power DI mode. The TS-SS ADC employs a four-terminal comparator and dynamic reference voltage compensation to mitigate charge leakage and offset, which improves signal-to-noise ratio (SNR) and linearity. The prototype occupies 2.1 mm × 2.88 mm in a 0.18 µm CMOS process and serves a 64 × 64 array. The AFE achieves a dynamic range of 75.58 dB, noise of 249.42 μV, and 81.04 mW power consumption. Full article

With the rapid development of renewable energy in China, thermal power units are facing decommissioning issues, while the power system is confronted with severe challenges such as reduced grid strength and insufficient voltage support. For power systems with multiple renewable energy stations, the short-circuit ratio at the connection points of renewable energy stations is an important indicator for measuring grid strength. Engineering requirements specify that the short-circuit ratio at these connection points should not be lower than 2.0. This study focuses on transforming retired thermal power units into synchronous condensers to improve the short-circuit ratio at renewable energy station connection points. This paper first studies the impact of thermal power unit operation, shutdown, and synchronous phasor operation on the short-circuit ratio, deriving the short-circuit ratio expressions for renewable energy stations under different states of thermal power units. It further analyzes the impact of different main transformer capacities and unit transformation capacities on the short-circuit ratio. Next, a multi-dimensional evaluation system is constructed, incorporating the change in short-circuit ratio at grid-connection points of multiple renewable energy stations ($\Delta MRSC{R}_{\mathrm{S}}$), the main transformer capacity within short-circuit ratio enhancement range ($S_{\mathrm{T}}$), the pre-retrofit short-circuit ratio level at grid-connection points of multiple renewable energy stations ($S_{\mathrm{G}}$), and the retrofitted unit capacity ($MRSC{R}_{\mathrm{S}}$) to comprehensively assess the transformed thermal power units. Finally, a case analysis conducted on the modified IEEE-39 bus system using the PSASP platform verifies that operating thermal power units as synchronous condensers can significantly enhance the short-circuit ratios of multiple renewable energy sites. Given that small-capacity thermal units are approaching retirement, there is a stronger preference for retrofitting these smaller units as synchronous condensers. The multi-dimensional evaluation method proposed in this study specifically identifies small-capacity thermal units as the most suitable candidates for such retrofitting. This approach provides theoretical support for implementing synchronous condenser operation in retired thermal power units and promotes the coordinated optimization of grid security and renewable energy integration. Full article

To address the stability problem related to grid-connected modular multilevel converter high voltage direct current (MMC HVDC) connected to weak alternative current (AC) systems, the short-circuit ratio (SCR) that affects the stability of the system was analyzed first. Short-circuit ratios with SCR values greater than 1.3 were obtained, and the system could still operate stably. By applying the theoretical equations of classical circuits, it has been theoretically proven that for the constant active power and constant AC voltage control modes on the weak system side, after the flexible direct current enters the weak system mode, the power must be reduced to ensure the stable operation of the system. Combined with the actual situation of the north channel of the Chongqing–Hubei back-to-back MMC HVDC project, which is connected to the weak system mode, measures such as the optimization of the control mode and the improvement of control functions in the weak system mode were proposed, and simulation calculations and real time digital simulator (RTDS) simulation verifications were carried out. These control strategies have been applied to the Chongqing–Hubei MMC HVDC project, and on-site verification tests have been conducted to ensure stable operation in the weak system mode. Full article

The integration of variable distributed energy sources (DERs) can reduce overall system inertia, potentially impacting the transient response of both conventional and renewable generators within electrical grids. Although transient stability indicators—for instance, the Critical Clearing Time (CCT), fault-induced short-circuit current ratios, and machine parameters, including subtransient–transient reactances and associated time constants—are influenced by total system inertia, their detailed evaluation remains insufficiently explored. These parameters provide standardized benchmarks for systematically assessing the transient stability performance of conventional and photovoltaic (PV) generators as the penetration level of distributed PV systems (PVD1) increases. This study explores the relationship between conventional stability parameters and system inertia across different levels of PV penetration. CCT, a key metric for transient stability assessment, incorporates multiple influencing factors and typically increases with higher system inertia, making it a reliable comparative indicator for evaluating the effects of PV integration on system stability. To investigate this, the IEEE New England 39-bus system is adapted by replacing selected synchronous machines with PVD1 PV units and adjusting the PV penetration levels. The resulting system behavior is then compared to that of the original configuration to evaluate changes in transient stability. The findings confirm that transient and subtransient reactances, along with their respective time constants under fault conditions, are shaped not only by the characteristics of the generator on the faulted line but also by the surrounding network structure and overall system inertia. The newly introduced sensitivity parameters offer insights by capturing trends specific to conventional versus PV-based generators under different inertia scenarios. Notably, transient parameters show similar responsiveness to inertia variations to subtransient ones. This paper demonstrates that in certain scenarios, the integration of low-inertia PV generators may generate insufficient energy, which is not above critical energy during major disturbances, resulting surviving fault and subsequently an infinite CCT. While the integration of PV generators can be beneficial for their own operational performance, it may adversely impact the dynamic behavior and fault response of conventional synchronous generators within the system. This highlights the need for effective planning and control of DER integration to ensure reliable power system operation through accurate selection and application of both conventional and proposed transient stability parameters. Full article

Voltage source converter-based high-voltage direct current (VSC-HVDC) systems integrated into weak AC grids may exhibit oscillation-induced instability, posing significant threats to power system security. With increasing structural complexity and diverse control strategies, the stability characteristics of VSC-HVDC system require further investigation. This paper focuses on the stability of a receiving-end VSC-HVDC system consisting of a DC voltage-controlled VSC parallel-connected to a power-controlled VSC, under various operating conditions. First, small-signal models of each subsystem were developed and a linearized full-system model was constructed based on port relationships. Then, eigenvalue and participation factor analyses were utilized to evaluate the influence of control strategy, asymmetrical grid strength, power flow direction, and tie line on the system’s small-signal stability. A feasible short-circuit ratio (SCR) region was established based on joint power–topology joint, forming a stable operating space for the system. Finally, the correctness of the theoretical analysis was validated via MATLAB/Simulink time-domain simulations. Results indicate that, in comparison to the power control strategy, the DC voltage control strategy was more sensitive to variations in the AC system and demands a strong grid, and this disparity was predominantly caused by the DC voltage control. Furthermore, the feasible region of the short-circuit ratio (SCR) diminished with the increase in the length of the tie-line and alterations in power flow direction under the mutual-support power mode, leading to a gradual reduction in the system’s stability margin. Full article

By integrating the grid-following control and grid-forming control, the adaptability of grid-connected converters to the grid impedance fluctuation can be effectively improved, and a stable operation in a wide short circuit ratio range can be realized. The existing fusion control schemes focus on the influence of the short circuit ratio on the stability of the converter, ignoring the influence of the active power fluctuation of the renewable energy in the design of the fusion scheme. In order to improve this shortcoming, an adaptive switching control of voltage source converters in the renewable energy station is proposed in this paper. Based on the oscillation characteristics of the grid-following converter and the grid-forming converter, this method selects the operating short circuit ratio as the switching index of the grid-following mode and the grid-forming mode. Compared with the current switching schemes based on the short circuit ratio, the operating short circuit ratio replaces the rated capacity of the station with the active output of the station, so it can more reasonably reflect changes in stability caused by active power fluctuations and then give the appropriate switching command, which means that unnecessary switching can be reduced and the control mode can be correctly converted to enhance stability when the system state changes. Full article

The increasing integration of renewable energy bases into power systems poses significant challenges for voltage stability and operational optimization. This paper develops an optimization model to maximize the total generation output in a renewable energy base while satisfying short-circuit ratio (SCR), transient overvoltage (TOV), and conventional operational constraints. To address the inherent nonlinearity of power systems, the trajectory sensitivities of SCR and TOV with respect to the decision variables are calculated, allowing the original nonlinear optimization problem to be transformed into a linear programming (LP) problem for efficient solving. Recognizing that the LP-based solution may not strictly satisfy all constraints during time-domain simulation verification due to system nonlinearity, the continuation method is introduced to ensure that a refined solution that satisfies all constraints is obtained. Case studies conducted on a real-world renewable energy base demonstrate the effectiveness and feasibility of the proposed approach. Full article

When a line-commutated converter–high-voltage direct current (LCC-HVDC) transmission system with large-scale integration of renewable energy encounters HVDC-blocking events, the sending-end power system is prone to transient overvoltage (TOV) risks. Renewable energy units that are connected via power electronic devices are susceptible to large-scale cascading disconnections due to electrical endurance and insulation limitations when subjected to an excessively high TOV, which poses a serious threat to the safe and stable operation of the system. Therefore, the prediction of TOV at renewable energy stations (RES) under DC blocking (DCB) scenarios is crucial for developing strategies for the high-voltage ride-through of renewable energy sources and ensuring system stability. In this paper, an approximate analytical expression for the TOV at RES under DCB fault conditions is firstly derived, based on a simplified equivalent circuit of the sending-end system that includes multiple DC transmission lines and RES, which can take into consideration the multiple renewable station short-circuit ratio (MRSCR). Building on this, a knowledge-embedded enhanced deep neural network (KEDNN) approach is proposed for predicting the RES’s TOV for complex power systems. By incorporating theoretical calculation values of the TOV into the input features, the task of the deep neural network (DNN) shifts from mining relationships within large datasets to revealing the correlation patterns between theoretical calculations and real values, thereby improving the robustness of the prediction model in cases of insufficient training data and irrational feature construction. Finally, the proposed method is tested on a real-world regional power system in China, and the results validate the effectiveness of the proposed method. The approximate analytical expression for the TOV at RES and the KEDNN-based TOV prediction method proposed in this paper can provide valuable references for scholars and engineers working in the field of power system operation and control, particularly in the areas of overvoltage theoretical calculation and mitigation. Full article

The main idea of this work is based on the latest achievements in the commercialization of sodium-ion (Na-ion) batteries, which constitute a basis of analysis for military applications as energy storage systems. Technical, engineering, and ecological aspects were analyzed to find the optimal solution for using Na-ion batteries for military purposes. When selecting batteries for military applications, the following criteria are required: (a) they are more durable than standard batteries, (b) resistant to fire, (c) cannot explode, (d) cannot emit heat so as not to reveal their position, (e) equipped with safety elements and protective circuits to ensure safety, and (f) have the highest possible energy density, defined as the ratio of capacity to weight. The advantages and challenges of Na-ion batteries are discussed and compared to typical lithium-ion batteries, and also lithium iron phosphate, Ni-Cd, and Ni-MH batteries. The prospects for expanding the practical applications of Na-ion batteries in the military are presented. The unique properties of Na-ion batteries, such as their lower risk of ignition, more excellent thermal stability, and ability to work in extreme conditions, are essential from the point of view of military operations. Additionally, when considering environmental and logistical aspects, sodium-ion batteries may offer more sustainable and cost-effective solutions for the military. Therefore, this work aims not only to present the technological potential of these systems but also to draw attention to their strategic importance for the future of military operations. Battery discharge can result from leaving current receivers switched on or even from a drop in temperature. The discharge current should not exceed 1/10 of the battery capacity (1C). Discharging below the discharge voltage may result in irreversible damage. Sodium-ion batteries are safer to use than their lithium counterparts and allow for discharge to 0 V, eliminating the possibility of uncontrolled thermal discharge due to a short circuit (explosion, ignition), which is particularly important in the military. Full article

The rising integration of renewable energy sources has resulted in a diminished capacity for voltage support within the system, which is characterized by low inertia and a reduced short circuit ratio (SCR). In order to improve grid strength and enhance the capacity for renewable energy integration, an initial analysis was conducted on the grid support capabilities of grid-forming (GFM) stations, followed by an investigation into how grid strength influences the dominant operational modes of GFM converters. Subsequently, leveraging the definition of the multi-infeed short circuit ratio, a calculation method for the SCR, applicable to new energy base stations featuring GFM substations, is developed. Additionally, a strategic approach to optimal location selection and sizing of these substations aimed at enhancing the SCR within new energy grids is proposed, with the model being solved through genetic algorithms. Finally, the effectiveness of the proposed method is verified based on the IEEE39-node system and a real new energy station. The results show that the system strength is greatly improved after the optimized configuration of the GFM equipment, and the maximum tolerable space of 90% new energy stations reaches 95% of the theoretical maximum tolerable space of each new energy station. Full article

Rising electricity demand and the need to reduce pollutant emissions highlight the importance of renewable energy, especially solar power. While most studies on photovoltaic (PV) integration focus on developed countries, least developed and developing countries such as the Democratic Republic of Congo (DRC) face particular challenges due to fragile grid infrastructure. This work evaluates the technical and operational impacts of PV integration into the western grid of the DRC using DIgSILENT PowerFactory 2021 SP2 simulations. It examines penetration levels from 10% to 50% based on a 2012 MW baseline, and evaluates power losses, short-circuit ratios (SCRs), grid stability, harmonic distortions, and voltage oscillations. Results reveal that moderate penetration levels (10–20%) reduce active power losses by 25% while maintaining stability. However, above 30% penetration, critical challenges arise, including a drop of the SCR below the minimum recommended value of 3, prolonged voltage oscillations, and increased harmonic distortions, resulting from the reduced overall inertia of the grid following the increase in PV power from inverters without inertia. These findings emphasize the need for targeted solutions like Battery Energy Storage Systems (BESSs), Static Synchronous Compensators (STATCOMs), and harmonic filters. This work provides foundational insights for PV integration in fragile grids of LDCs and developing countries. Full article

Offshore wind farms are increasingly being commissioned farther from shore, and high voltage alternating current (HVAC) transmission systems are preferred because of their maturity and reliability. However, as cable length increases, ensuring system stability becomes more challenging, making it essential to investigate shunt reactor compensation configurations and converter control strategies. This study examines three different shunt reactor compensation arrangements and two control strategies, grid-forming (GFM) and grid-following (GFL), across three cable lengths (80 km, 120 km, and 150 km). The systems were evaluated based on small-signal stability using disk margins for different active power operating points, and later for different short-circuit ratios (SCR) and X/R. The results demonstrate that the GFM is preferable for longer cables and enhanced stability. The most robust configuration includes a shunt reactor placed in the mid-cable with additional reactors at both ends of the cable, followed by an arrangement with reactors at the beginning and end. The GFM converter control maintained stability across all operating points, cable lengths, and configurations, whereas the stability of the GFL unit was highly dependent on active power injection and struggled under weaker grid conditions. Thus, for longer HVAC cables, it is necessary to employ GFM control units, and it is recommended to use shunt reactors at the cable start and end, as well as at mid-cable, for optimal stability. Full article

The issues of low inertia, overvoltage, and wide-frequency oscillations in high-proportion renewable energy systems have become prominent, posing major challenges to renewable energy integration and threatening grid stability. Currently, many wind-rich areas ensure grid safety and stability by reducing wind farm output. To enhance the active power delivery capability of wind farms, this paper proposes a hybrid solution of a small synchronous condenser (SC) and static var generator (SVG) within wind farm stations to optimize reactive power and voltage at the point of grid connection. First, it was analyzed that the low short-circuit ratio (SCR) is a key factor affecting the stable operation of wind farms, and the sub-transient reactance of the SC can increase the SCR. Based on this, a method for configuring the capacity of the SC was developed. Next, simulation models for both the SC and the SVG were established, and their reactive power compensation capabilities were verified. The hybrid control approach combined the advantages of both devices, providing comprehensive voltage support across sub-transient, transient, and steady-state conditions for renewable energy stations. Furthermore, based on a practical 50.5 MW wind farm, which has been operating with a power delivery consistently limited to 60% of its capacity, a simulation model and scenarios were set up. A comparison of the simulation results shows that, with only the SVG in operation, the wind farm is prone to oscillations after a grid fault. However, after adopting the hybrid control of the SC and SVG, the wind farm operates stably. Therefore, installing a small SC within wind farms can effectively address the limitations of voltage stability and a low short-circuit ratio, thereby supporting higher levels of renewable energy integration. Full article
