Light, as one of the most crucial environmental factors, plays an essential role in the growth, physiology, and evolutionary survival of fish. To cope with diverse light conditions in aquatic environments, fish adapt through photosensory systems composed of both visual and non-visual pathways. The retina is a key component of the visual system of fish, capable of converting external optical signals into neural electrical signals, making it crucial for visual formation. During the process of visual signal transduction, opsins serve as the molecular foundation for vision formation. They can be divided into two major categories: visual opsins and non-visual opsins. Among these, melanopsin, as a member of the non-visual opsin family, acts as a key upstream factor in the circadian phototransduction pathway of fish. In this review, we review the adaptability of fish retinal structures to light reception and introduce in detail the gene diversity and relative expression levels of fish opsins. At the same time, we comprehensively describe the molecular mechanism by which fish adapt to changes in the underwater light environment. We also concluded that melanopsin, as a non-imaging photoreceptor, possesses not only core light-sensing functions but also non-imaging visual functions such as circadian rhythm regulation, body coloration changes, and hormone secretion. This review suggests that future research should not only elucidate the physiological functions of melanopsin in fish but also comprehensively reveal the mechanisms underlying the multi-adaptive nature of fish vision across varying light environments. Through these studies, researchers can have a deeper understanding of the physiological regulation mechanism of fish in complex light environments, and then formulate fish light environment management strategies, optimize aquaculture practices, improve economic returns, and promote the development of related fields. Full article

Radiative cooling (RC) offers a passive pathway to reduce surface and system temperatures by emitting thermal radiation through the atmospheric window, yet its daytime effectiveness is often constrained by geometry, angular solar exposure, and practical integration limits. This work experimentally investigates the use of passive non-imaging optics, specifically compound parabolic concentrators (CPCs), as enhancers of RC performance under realistic conditions. A three-tier experimental methodology is followed. First, controlled indoor screening using an infrared lamp quantifies the intrinsic heat gain suppression of a commercial RC film, showing a temperature reduction of nearly 88 °C relative to a black-painted reference. Second, outdoor rooftop experiments on aluminum plates assess partial RC coverage, with and without CPCs, under varying orientations and tilt angles, revealing peak daytime temperature reductions close to 8 °C when CPCs are integrated. Third, system-level validation is conducted using a modified GUNT ET-202 solar thermal unit to evaluate the transfer of RC effects to a water circuit absorber. While RC strips alone produce modest reductions in water temperature, the addition of CPC optics amplifies the effect by factors of approximately three for ambient water and nine for water at 70 °C. Across all configurations, statistical analysis confirms stable, repeatable measurements. These results demonstrate that coupling commercially available RC materials with non-imaging optics provides consistent and measurable performance gains, supporting CPC-assisted RC as a scalable and retrofit-friendly strategy for urban and building energy applications while calling for longer-term experiments, durability assessments, and techno-economic analysis before deriving definitive deployment guidelines. Full article

In the field of non-imaging optics, the use of freeform lenses for achieving uniform illumination is of significant research importance. However, existing studies have primarily focused on uniform illumination design for planar targets and have made remarkable progress, while relatively less attention has been paid to uniform illumination on curved surfaces. To address this, this paper proposes a design method for freeform lenses aimed at uniform illumination on curved surfaces. The key to this method lies in utilizing the first kind of surface integral Equation to transform the problem from the Cartesian coordinate system on the target surface into a planar coordinate system, thereby significantly reducing computational complexity. Simulation results confirm the feasibility of the proposed lens design method in enabling the realization of high-efficiency, high-uniformity illuminance distribution on a curved surface via secondary optics for LEDs. Full article

The balance between cortical excitation and inhibition (E/I balance) in the cerebral cortex is critical for cognitive processing and neuroplasticity. Modulation of this balance has been linked to a wide range of neuropsychiatric and neurodegenerative disorders. The human visual system has well-differentiated magnocellular (M) and parvocellular (P) pathways, which provide a useful model to study cortical excitability using non-invasive visual flicker stimulation. We present an Arduino-driven non-image forming system to deliver controlled flickering light stimuli at different frequencies and wavelengths. By triggering the critical flicker fusion (CFF) frequency, we attempt to modulate the M-pathway activity and attenuate P-pathway responses, in parallel with induced optical scattering. EEG recordings were used to monitor cortical excitability and oscillatory dynamics during visual stimulation. Visual stimulation in the CFF, combined with induced optical scattering, selectively enhanced magnocellular activity and suppressed parvocellular input. EEG analysis showed a modulation of cortical oscillations, especially in the high frequency beta and gamma range. Our results support the hypothesis that visual flicker in the CFF, in addition to spatial degradation, initiates detectable neuroplasticity and regulates cortical excitation and inhibition. These findings suggest new avenues for therapeutic manipulation through visual pathways in diseases such as Alzheimer’s disease, epilepsy, severe depression, and schizophrenia. Full article

This study analyzes the impact of powder-blasted surface modification on the performance of non-imaging solar concentrators and evaluates a ray-tracing simulation approach to virtual solar power measurements. Powder blasting was applied to poly(methyl methacrylate) (PMMA) sheets to create a rough, Lambertian-like scattering surface, enhancing light trapping and total internal reflection. The effects of this modification were systematically assessed using optical transmission spectroscopy, angular scattering measurements, and solar cell efficiency characterization under standard AM1.5 illumination. The results show that surface roughening significantly improves light redirection toward the concentrator’s edge, enhancing solar cell performance. OptisWorks ray-tracing simulations were employed to model the concentrator’s optical behavior, demonstrating strong agreement (within 5–10% deviation) with experimental data. These findings confirm that surface modification is crucial in optimizing concentrator efficiency and establishing ray tracing as a reliable tool for virtual performance evaluation in photovoltaic applications. Full article

Background: Image-guided navigation has revolutionized precision cardiac interventions, yet current technologies face critical limitations in real-time guidance and procedural accuracy. Method: Here, we comprehensively evaluate state-of-the-art imaging modalities, from conventional fluoroscopy to emerging hybrid systems, analyzing their applications across coronary, structural, and electrophysiological interventions. Results: We demonstrate that novel approaches combining optical coherence tomography with near-infrared spectroscopy or fluorescence achieve unprecedented plaque characterization and procedural guidance through simultaneous structural and molecular imaging. Our analysis reveals key challenges, including imaging artifacts and resolution constraints, while highlighting recent technological solutions incorporating artificial intelligence and robotics. We show that non-imaging alternatives, such as fiber optic real-shape sensing and electromagnetic tracking, complement traditional techniques by providing real-time navigation without radiation exposure. This paper also discusses the integration of image-guided navigation techniques into augmented reality systems and patient-specific modeling, highlighting initial clinical studies that demonstrate their significant promise in reducing procedural times and improving accuracy. These findings establish a framework for next-generation cardiac interventions, emphasizing the critical role of multimodal imaging platforms enhanced by AI-driven decision support. Conclusions: We conclude that continued innovation in hybrid imaging systems, coupled with advances in automation, will be essential for optimizing procedural outcomes and expanding access to complex cardiac interventions. Full article

Optical freeform surfaces are widely used in imaging and non-imaging systems due to their high design freedom. In freeform surface manufacturing and assembly, dynamic freeform surface measurement that can guide the next operation remains a challenge. To meet this urgent need, we propose a dynamic interferometric method based on a machine learning-configured deformable mirror (DM). In this method, a dynamic interferometric system is developed. By using coaxial structure and polarization interference, transient measurement of the measured surface can be realized to meet dynamic requirements, and at the same time, DM transient monitoring can be realized to reduce the accuracy loss caused by DM surface changes and meet dynamic requirements. A transient phase modulation scheme using machine learning to configure the DM surface is proposed, which keeps the system in a measurable state. Compared with the traditional phase modulation scheme that relies on iteration, the scheme proposed in this paper is more efficient and is conducive to meeting dynamic requirements. The feasibility is verified by practical experiments. The research in this paper has significance for guiding the application of dynamic interferometry in the measurement of dynamic surfaces. Full article

The distorted spots induced by atmospheric turbulence significantly degrade the spot position detection accuracy of the quadrant detector (QD). In this paper, we utilize angular measurement and homogenization characteristics of non-imaging microlens array (NI-MLA) systems, effectively reducing the distortion degree of the spots received on the QD target surface, thereby significantly enhancing the spot detection accuracy of the QD. First, based on the principles of geometric optics and Fourier optics, it is proved that the NI-MLA system possesses the angular measurement characteristic (AMC) within the paraxial region while deriving and verifying the focal length of the system. Then, the QD computation curve characteristics of the system under non-turbulence are explored. This study further elucidates the mathematical principle of the NI-MLA system for mitigating the spot position detection random error of QD (SPDRE-QD) and discusses in depth the relationship between the NI-MLA system’s capability to mitigate the SPDRE-QD and the system’s parameters under various turbulence intensities. Finally, it is experimentally verified that the root-mean-square error (RMSE) of the QD computation values using the NI-MLA system are reduced by a significant improvement of at least 2.44 times and up to 17.36 times compared with that of the conventional optical system of QD (COS-QD) under turbulence conditions ranging from weak to strong. Full article

The application of non-imaging hyperspectral sensors has significantly enhanced the study of leaf optical properties across different plant species. In this study, chlorophyll fluorescence (ChlF) and hyperspectral non-imaging sensors using ultraviolet-visible-near-infrared shortwave infrared (UV-VIS-NIR-SWIR) bands were used to evaluate leaf biophysical parameters. For analyses, principal component analysis (PCA) and partial least squares regression (PLSR) were used to predict eight structural and ultrastructural (biophysical) traits in green and purple Tradescantia leaves. The main results demonstrate that specific hyperspectral vegetation indices (HVIs) markedly improve the precision of partial least squares regression (PLSR) models, enabling reliable and nondestructive evaluations of plant biophysical attributes. PCA revealed unique spectral signatures, with the first principal component accounting for more than 90% of the variation in sensor data. High predictive accuracy was achieved for variables such as the thickness of the adaxial and abaxial hypodermis layers (R² = 0.94) and total leaf thickness, although challenges remain in predicting parameters such as the thickness of the parenchyma and granum layers within the thylakoid membrane. The effectiveness of integrating ChlF and hyperspectral technologies, along with spectroradiometers and fluorescence sensors, in advancing plant physiological research and improving optical spectroscopy for environmental monitoring and assessment. These methods offer a good strategy for promoting sustainability in future agricultural practices across a broad range of plant species, supporting cell biology and material analyses. Full article

Concentration of solar energy may be obtained by reflection, refraction, or a combination of the two. The collectors of a reflection system are designed to concentrate the sun’s rays onto a photovoltaic cell or steam tube. Refractive lenses concentrate light by having it travel through the lens. The sun’s rays are partially reflected and then refracted via a hybrid technique. Hybrid focus techniques have the potential to maximize power output. Fresnel lenses are an efficient tool for concentrating solar energy, which may then be used in a variety of applications. Development of both imaging and non-imaging devices is occurring at this time. Larger acceptance angles, better concentration ratios with less volume and shorter focal length, greater optical efficiency, etc., are only some of the advantages of non-imaging systems over imaging ones. This study encompasses numerical, experimental, and numerical and experimental studies on the use of Fresnel lenses in various solar energy systems to present a comprehensive picture of current scientific achievements in this field. The framework, design criteria, progress, and difficulties are all dissected in detail. Accordingly, some recommendations for further studies are suggested. Full article

As the non-imaging light of optical instruments, stray light has an important impact on normal imaging and data quantification applications. The FY-3D Medium Resolution Spectral Imager (MERSI) operates in a sun-synchronous orbit, with a scanning field of view of 110° and a surface imaging width of more than 2300 km, which can complete two coverage observations of global targets per day with high detection efficiency. According to the characteristics of the operating orbit and large-angle scanning imaging of MERSI, a stray light radiation model of the polar-orbiting spectrometer is constructed, and the design requirements of stray light suppression are proposed. Using the point source transmittance (PST) as the merit function of the stray light analysis method, the instrument was simulated with all stray light suppression optical paths, and the effectiveness of stray light elimination measures was verified using the stray light test. In this paper, the full-link method of “orbital stray light radiation model-system, internal and external simulation design-system analysis and actual test comparison verification” is proposed, and there is a maximum decrease in the system’s PST by about 10 times after applying the stray light suppression’s optimization design, which can provide a general method for stray light suppression designs for polar-orbit spectral imagers. Full article

Strengthening regulations on carbon emissions from ships is important for ensuring that China can achieve its dual carbon aims of reaching peak carbon emissions before 2030 and achieving carbon neutrality before 2060. Currently, the primary means of monitoring ship exhaust emissions are the sniffing method and non-imaging optical remote sensing; however, these methods suffer from a low prediction efficiency and high cost. We developed a method for predicting the CO₂ content of ship exhaust that uses a convolutional neural network and mid-infrared spectral images. First, a bench experiment was performed to synchronously obtain mid-wave infrared spectral images of the ship exhaust plume and true values for the CO₂ concentration from the online monitoring of eight spectral channels. Then, the ResNet50 residual neural network, which is suitable for image prediction tasks, was selected to predict the CO₂ content. The preprocessed mid-infrared spectral image of each channel and the corresponding true value for the CO₂ content were input to the neural network, and convolution was applied to extract the radiation characteristics. The neural network then mapped the relationship between the true CO₂ content and the radiation characteristics for each channel, which it used to predict the CO₂ content in the ship exhaust. The results demonstrated that the predicted and true CO₂ contents had a root mean square error of <0.2, mean absolute error of <0.15, and mean absolute percentage error of <3.5 for all eight channels. The developed model demonstrated a high prediction accuracy with one channel in particular demonstrating the best performance. This study demonstrates that the method used for predicting the CO₂ content of ship exhaust based on convolutional neural networks and mid-infrared spectral images is feasible and has reference significance for the remote monitoring of ship exhaust emissions. Full article

Solar energy is a long-established technology, which has zero CO₂ emissions, and provides low-cost energy for a given area of land. The concentrator photovoltaic (CPV) has been given preference over the photovoltaic due to its high efficiency. In a CPV system, most of the solar cell area has been replaced with an optical concentrator. Various parabolic trough based CPV systems have been presented where a concentration of <300 is achieved. In the current research, a design is presented to achieve a high concentration of 622×. The design consists of two stages of concentration including parabolic trough as a main concentrator and nonimaging reflective grooves as a secondary concentrator. The trough reflects the incident light towards the secondary reflector where the light is redirected over the solar cell. Design of the two-stage concentrator, ray-tracing simulation, and results are presented. The system achieved an optical efficiency of 79%. The system would also be highly acceptable in solar thermal applications owing to its high concentration. Full article

We present a design of a non-imaging system based on a ray-tracing methodology. This system is mainly made of polycarbonate, while part of its surface is coated with metal. The Zemax^® optical simulation tool was used to calculate the optimal parameters of this system, such as heights, widths, and angles. This design aims to improve the light distribution uniformity of blended red-green-blue mini light-emitting diodes. Our simulation results show that this design can achieve 93% light distribution uniformity in a 36 mm × 36 mm area, and the height of this design is less than 5 mm. Full article

Research into solar absorption chillers despite their environmental benefits has been limited to date to mainly larger systems whilst ignoring smaller building-scale units, which can significantly benefit from the use of optimally designed, low concentrating, non-imaging optical reflectors. A solar absorption chiller system designed to provide year-round space cooling for a typical primary health care facility in Cairo, Egypt, was designed to match local ambient, solar, and occupancy conditions, its performance simulated and then optimized to minimize auxiliary power consumption using the TRNSYS18 software, TRNOPT. Different configurations of collector types, array areas, storage sizes and collector slopes were used to determine the optimum specifications for the system components. Non-concentrating Evacuated Tube Collectors (ETCs) were compared with the same Evacuated Tube Collectors but integrated with external Compound Parabolic Concentrators (CPCs) with a geometric concentration ratio of 1.5X for supplying thermal energy to the single-effect absorption chiller investigated. This paper describes a user-friendly methodology developed for the design of solar heat-powered absorption chillers for small buildings using TRNSYS18 employing the Hookes–Jeeves algorithm within the TRNOPT function. Clear steps to avoid convergence problems when using TRNSYS are articulated to make repeatability for different systems and locations more straightforward. Collector array areas were varied from 30 m² to 160 m² and the size of the water-based thermal storage from 1 m³ to 3 m³ to determine the configuration that can supply the maximum solar fraction of the building’s cooling requirements for the lowest lifetime cost. The optimum solar fraction for ETCs and CPCs was found to be 0.66 and 0.94, respectively. If the current air conditioning demand is met through adoption of the CPC-based solar absorption systems this can potentially save the emission of 3,966,247 tCO₂ per annum. Full article
