Introducing a memristor into chaotic systems facilitates the construction of high-dimensional hyperchaotic systems. The hyperchaotic signals generated by these systems have important applications in the field of information security. A five-dimensional hyperchaotic system is constructed by introducing a memristor. Its hyperchaotic nature is discussed using phase diagrams and Lyapunov exponential diagrams. The effects of the parameters on the dynamical behavior are examined by bifurcation diagrams and Lyapunov exponential diagrams. To validate the theoretical model, an electronic circuit was designed for circuit simulation. The electronic simulation of the circuit was carried out using the Multisim simulation platform. Finally, the fixed-time projection synchronization of the system was taken into consideration. Three sets of synchronization schemes were considered and simulated. The synchronization scheme has the features of fast synchronization speed and robustness. It is potentially valuable for applications in the fields of chaotic communication and chaotic encryption. Full article

This paper proposes a design for a platform-based Multi-phase Interleaved Synchronous Buck Converter (MISBC). A custom platform was developed to compare the theoretical performance of a MISBC circuit simulated with Multisim to a prototype that was built at Western Sydney University. The work disclosed in this manuscript describes some steps adopted during the selection of each component and technical considerations taken during the design of the Printed Circuit Board (PCB). The platform designed has a maximum power output of 260 Watts, with a buck reduction of the nominal voltage from 97 Volts to 24 Volts at a maximum switching frequency of 50 kHz. This switching frequency is achieved with an open-loop circuit configuration coupled with synchronized signal generators, used to validate the dead band required between the activation of each set of transistors implemented in a half-bridge configuration. A summary of the results based on the duty cycle required to achieve the buck voltage desired highlights the advantages of each operating mode of the MISBC circuit. Here the theoretical performance is compared against the data acquired during functional evaluations of the prototype, making possible future interpretations of the ideal control algorithm required to maximize the performance output of MISBC circuits. Full article

In the past, low-frequency analog control circuits were largely used in analog control systems. With the rapid development of modern digital electronic technology, the digitization of traditional low-frequency analog control circuits while retaining the same functions as the original analog control systems has become an important trend in the field of electronic design. For this reason, this study aimed to develop an analog signal digitization model for control signals at a low frequency below 10 Hz. In terms of signal receiving and transmission requirements, the proposed model is configured with analog-to-digital converter (ADC), digital-to-analog converter (DAC), and pulse width modulation (PWM) functions. In the development environment, the input and output signals are first normalized and processed with PWM, enabling the digital signal processor to deal with analog signal receiving, processing, and external transmission. To replace the existing compensator in analog circuits, a digital compensator is used in the digital signal processor. Based on the bilinear function in MATLAB software, the parameter values demanded for the digital compensator can thus be obtained, achieving the automatic calculation of bilinear transformation in the system. Multisim simulation is then used to simulate analog circuit systems for comparison with the digitized outcomes. The experimental results reveal that the performance of the designed digital control circuit matches the simulation outcomes in both Bode gain (dB) and phase responses when the signal frequency is below 10 Hz. The effectiveness of the digitized analog control circuit for low-frequency control signals is therefore confirmed. Full article

During the in-orbit operation of spacecraft, permanent magnet synchronous motors are commonly used as power sources in the drive mechanisms of solar panel arrays and the high-precision servo control systems based on satellites. Apart from the performance of the motors themselves and the software control algorithms, the accuracy of the entire control system is also influenced by angle sensors used to detect the rotor position of the motors. As a high-precision angular measuring instrument, the inductosyn possesses excellent environmental adaptability and long service life. Effectively utilizing the inductosyn can greatly enhance the performance of servo control systems. To address the complexity of the decoding process for dual-channel round inductosyn-to-digital converters, this paper proposes a design of the decoding circuit for dual-channel round inductosyn based on the parallel-synchronization decoding method of two AD2S1210 Resolver-to-Digital Converter (RDC) decoding chips. The decoding circuit amplifies the excitation signal outputted by the AD2S1210 for driving the round inductosyn, and processes the sine and cosine induction signals outputted by the round inductosyn through filtering, amplification, and other methods; by using analog circuitry, the output signals of the dual-channel round inductosyn are processed to meet the input requirements of the AD2S1210. Finally, through both the Multisim (circuit simulation software Version 14.1) simulation and physical experiments, it was verified that the decoding circuit designed in this paper could process the input/output signals of the dual-channel round inductosyn and AD2S1210, and successfully decoded the analog induction signal of the round inductosyn. This greatly simplifies the signal decoding process for the dual-channel round inductosyn. Full article

Because of the large number of parameters that interact in amplifier functions, determining dynamic regime parameters as well as the mode of function of amplifier stages is an extremely complex problem. This paper describes a LabVIEW application for studying the functioning of an amplifier in various connections. The user selects the generator’s parameters, the type of connection and its parameters, as well as the load circuit characteristics. The application can determine both the stage characteristics and the Bode characteristics. The amplifier’s stability zone, as well as its gain and phase, are determined based on these characteristics. An important advantage of this application is that the design of the amplifier stage can be created starting from some parameters that the amplifier can establish, from which the values of components can be determined. In order to validate the simulation results from the LabVIEW application, the specialized program Multisim was used, as well as experimental measurements using the Electronics Explorer Board. Both Multisim and Electronics Explorer Board can determine Bode characteristics. In both simulations and experimental amplifiers, the same schemes with the same transistor were used. The application can be used for educational purposes as well as to design an amplifier’s stage to achieve specific parameters. Full article

Alterations in the dynamical properties of an atomic force microscope microcantilever beam system in tapping mode can appreciably impact its measurement precision. Understanding the influence mechanism of dynamic parameter changes on the system’s motion characteristics is vital to improve the accuracy of the atomic force microscope in tapping mode (AFM-TM). In this study, we categorize the mathematical model of the AFM-TM microcantilever beam system into systems 1 and 2 based on actual working conditions. Then, we analyze the alterations in the dynamic properties of both systems due to external excitation variations using bifurcation diagrams, phase trajectories, Lyapunov indices, and attraction domains. The numerical simulation results show that when the dimensionless external excitation g < 0.183, the motion state of system 2 is period 1. When g < 0.9, the motion state of system 1 is period 1 motion. Finally, we develop the equivalent circuit model of the AFM-TM microcantilever beam and perform related software simulations, along with practical circuit experiments. Our experimental results indicate that the constructed equivalent circuit can effectively analyze the dynamic characteristics of the AFM-TM microcantilever beam system in the presence of complex external environmental factors. It is observed that the practical circuit simulation attenuates high-frequency signals, resulting in a 31.4% reduction in excitation amplitude compared to numerical simulation results. This provides an essential theoretical foundation for selecting external excitation parameters for AFM-TM cantilever beams and offers a novel method for analyzing the dynamics of micro- and nanomechanical systems, as well as other nonlinear systems. Full article

In this work, a novel memristive Chua’s oscillator circuit is presented. In the proposed circuit, a linear negative resistor, which is parallel coupled with a first-order memristive diode bridge, is used instead of the well-known Chua’s diode. Following this, an extensive theoretical and dynamical analysis of the circuit is conducted. This involves numerical computations of the system’s phase portraits, bifurcation diagrams, Lyapunov exponents, and continuation diagrams. A comprehensive comparison is made between the numerical simulations and the circuit’s simulations performed in Multisim. The analysis reveals a range of intriguing phenomena, including the route to chaos through a period-doubling sequence, antimonotonicity, and coexisting attractors, all of which are corroborated by the circuit’s simulation in Multisim. Full article

As advanced systems continue to advance and fuse functions expand, the demand for higher power supply requirements for fuses has increased. Consequently, researchers have turned their attention to the recovery of energy from the environment. Piezoelectric energy harvesting has gained significant popularity due to its advantageous characteristics, such as high energy density, ease of implementation, and compact size. However, the presence of various component types within the energy harvesting circuit inevitably results in the generation of reactive power, leading to a reduction in the circuit’s power factor. To address this issue, this paper introduces the adoption of the third-order valley-fill circuit as the power factor correction circuit. The implementation process involves the utilization of Multisim software to simulate the double-limit zero-crossing detection circuit, pulse signal generation circuit, and power factor correction circuit. Furthermore, the aforementioned circuits were subjected to plate-level welding, followed by individual tests to evaluate the effectiveness of the double-limit zero-crossing detection, pulse signal test, and load voltage measurement. These findings unequivocally exemplify the successful accomplishment of the intended objective of augmenting the output power by the third-order valley-fill circuit. Full article

At present, memristive neural networks with various topological structures have been widely studied. However, the memristive neural network with a star structure has not been investigated yet. In order to investigate the dynamic characteristics of neural networks with a star structure, a star memristive neural network (SMNN) model is proposed in this paper. Firstly, an SMNN model is proposed based on a Hopfield neural network and a flux-controlled memristor. Then, its chaotic dynamics are analyzed by using numerical analysis methods including bifurcation diagrams, Lyapunov exponents, phase plots, Poincaré maps, and basins of attraction. The results show that the SMNN can generate complex dynamical behaviors such as chaos, multi-scroll attractors, and initial boosting behavior. The number of multi-scroll attractors can be changed by adjusting the memristor’s control parameters. And the position of the coexisting chaotic attractors can be changed by switching the memristor’s initial values. Meanwhile, the analog circuit of the SMNN is designed and implemented. The theoretical and numerical results are verified through MULTISIM simulation results. Finally, a color image encryption scheme is designed based on the SMNN. Security performance analysis shows that the designed cryptosystem has good security. Full article

The high-speed and high-accuracy current control circuit is a key component for the high-performance electro-hydraulic proportional valve. In this paper, a new capacitive reservoir-based PWM digital circuit (CRPDC) is designed, modeled, and analyzed. The proposed CRPDC employs a capacitive reservoir circuit to acquire electricity from the DC power supply while the PWM control signal is at a high level and the supply current for the proportional valve coil while the PWM control signal is at a low level, which will result in a small ripple and fast response of the coil current. For the proposed CRPDC, the charging and discharging mathematical models are specially established to reveal the response characteristics of the proportional-valve coil current. The coil current control performance of the proposed CRPDC is simulated by the mathematical models and the Multisim models. Simulation results demonstrate that the designed CRPDC can energize the coil current in a high-accuracy and fast-speed manner. In summary, the designed CRPDC has wide application in the current control of the proportional valve coil. Full article

The traditional charging pile management system usually only focuses on the basic charging function, which has problems such as single system function, poor user experience, and inconvenient management. In this paper, the battery energy storage technology is applied to the traditional EV (electric vehicle) charging piles to build a new EV charging pile with integrated charging, discharging, and storage; Multisim software is used to build an EV charging model in order to simulate the charge control guidance module. On this basis, combined with the research of new technologies such as the Internet of Things, cloud computing, embedded systems, mobile Internet, and big data, new design and construction methods of the energy storage charging pile management system for EV are explored. Moreover, K-Means clustering analysis method is used to analyze the charging habit. The functions such as energy storage, user management, equipment management, transaction management, and big data analysis can be implemented in this system. The simulation results of this paper show that: (1) Enough output power can be provided to meet the design and use requirements of the energy-storage charging pile; (2) the control guidance circuit can meet the requirements of the charging pile; (3) during the switching process of charging pile connection state, the voltage state changes smoothly. It can provide a new method and technical path for the design of electric vehicle charging pile management system, which can effectively reduce the system’s operation and maintenance costs and provide more friendly and convenient charging services. Full article

For the wide frequency spectrum of chaotic signals, it is difficult to realize chaotic signal conditioning. Therefore, researchers turn to the exploration of chaotic systems with independent non-bifurcation control for easy chaos modification. In this paper, a system with only one non-quadratic term is modified for providing multiscale amplitude/frequency control. By adjusting the feedback with an odd higher degree term, a switchable chaotic oscillator is obtained, which provides the different scales of amplitude/frequency control with the chaotic signal. Multisim-based circuit simulation shows the efficiency and convenience of chaotic signal control. Full article

In this paper, on the basis of the three-dimensional Chen system, a smooth continuous nonlinear flux-controlled memristor model is used as the positive feedback term of this system, a hyper-chaotic circuit system is successfully constructed, and a simulated equivalent circuit is built for simulation using Multisim software, which agrees with the numerical simulation results by comparison. Meanwhile, a new impulsive control mode called the three-stage-impulse is put forward. It is a cyclic system with three components: continuous inputs are exerted in the first and third parts of the cycle while giving no input in the second part of the cycle, an impulse is exerted at the end of each continuous subsystem, the controller is simple in structure and effective in stabilizing most existing nonlinear systems. The Chen hyper-chaotic system will be controlled based on the three-stage-impulse control method combined with the Lyapunov stability principle. At the end of this paper, we have employed and simulated a numerical example; the experimental results show that the controller is effective for controlling and stabilizing the newly designed hyper-chaotic system. Full article

In this research article, a simple four-dimensional (4D) chaotic dynamic system with uncomplicated structure and only one nonlinear term is introduced. The features of the proposed design have been conducted with some standard nonlinear dynamic analysis and mathematical tools which show the chaotic nature. One of the most important indicators for detecting complexity of the chaotic systems is the Kaplan-York dimension of the system. Moreover, one of the main criteria of chaotic systems is its simplicity due to the reduction of operating costs. Therefore, it seems necessary to design a system as simple as possible and with high complexity. In this research, a comparison has been made between the proposed system and similar chaotic systems, which has given noticeable results. For the practical implementation of the proposed design, the circuit analysis using Multisim software has been employed. The proposed scheme has been used in the application of image encryption to show the efficiency of the proposed chaotic system and standard encryption tests have been performed. The rest of the numerical results have been conducted using MATLAB/Simulink software. Full article

Vibration energy harvesting has received much attention as a new type of power solution for low-power micro/nano-devices. However, VEH (vibration energy harvester) based on PVDF (polyvinylidene fluoride) piezoelectric materials have a low output power and energy conversation efficiency due to the relatively low piezoelectric constant, coupling coefficient, and dielectric constant. For this reason, we design a vibration energy conversion power supply, which consists of a VEH with a PVDF piezoelectric thin film planar array vibration structure and an energy harvesting circuit for regulating the electric energy of multiple sources. Furthermore, our solution was validated by simulations of structural dynamics in COMSOL and equivalent circuits model in Multisim. From the circuitry simulation results, the output current and the charging period increase and decrease, doubling, respectively, for each doubling of the number of array groups of films. Moreover, the solid mechanics simulation results show that the planar array structure makes the phase and amplitude of the input vibration waves as consistent as possible so that the same theoretical enhancement effect of the circuitry model is achieved. An identical experimental test was implemented with vibration conditions of 75 Hz-2.198 g. The fabricated harvester quickly charged the 22 V-0.022 F ultracapacitor bank to 5 V in 24 min. The maximum open circuit voltage and output power, respectively, were 10.4 V and 0.304 mW. This maximum charging power was 11.69 times higher than that of a single film. This special power supply can replace batteries to power low-power electronics deployed in vibrating environments, thus reducing the maintenance costs of equipment and environmental pollution rates. Full article
