Search Results (29)

To address the ill-posedness of the Hessian matrix in monocular visual-inertial SLAM (Simultaneous Localization and Mapping) caused by unobservable depth of feature points, which leads to convergence difficulties and reduced robustness, this paper proposes a Pre-Dog-Leg feature optimization method based on an adaptive preconditioner. First, we propose a multi-candidate initialization method with robust characteristics. This method effectively circumvents erroneous depth initialization by introducing multiple depth assumptions and geometric consistency constraints. Second, we address the pathology of the Hessian matrix of the feature points by constructing a hybrid SPAI-Jacobi adaptive preconditioner. This preconditioner is capable of identifying matrix pathology and dynamically enabling preconditioning as a strategy. Finally, we construct a hybrid adaptive preconditioner for the traditional Dog-Leg numerical optimization method. To address the issue of degraded convergence performance when solving pathological problems, we map the pathological optimization problem from the original parameter space to a well-conditioned preconditioned space. The optimization equivalence is maintained by variable recovery. The experiments on the EuRoC dataset show that the method reduces the number of Hessian matrix conditionals by a factor of 7.9, effectively suppresses outliers, and significantly improves the overall convergence time. From the analysis of trajectory error, the absolute trajectory error is reduced by up to 16.48% relative to RVIO2 on the MH_01 sequence, 20.83% relative to VINS-mono on the MH_02 sequence, and up to 14.73% relative to VINS-mono and 34.0% relative to OpenVINS on the highly dynamic MH_05 sequence, indicating that the algorithm achieves higher localization accuracy and stronger system robustness. Full article

Simultaneous Localization and Mapping (SLAM) has long been a fundamental and challenging task in robotics literature, where safety and reliability are the critical issues for successfully autonomous applications of robots. Classically, the SLAM problem is tackled via probabilistic or optimization methods (such as EKF-SLAM, Fast-SLAM, and Graph-SLAM). Despite their strong performance in real-world scenarios, these methods may exhibit inconsistency, which is caused by the inherent characteristic of model linearization or Gaussian noise assumption. In this paper, we propose an alternative monocular SLAM algorithm which theoretically relies on interval analysis (iMonoSLAM), to pursue guaranteed rather than probabilistically defined solutions. We consistently modeled and initialized the SLAM problem with a bounded-error parametric model. The state estimation process is then cast into an Interval Constraint Satisfaction Problem (ICSP) and resolved through interval constraint propagation techniques without any linearization or Gaussian noise assumption. Furthermore, we theoretically prove the obtained consistency and propose a versatile method for numerical validation. To the best of our knowledge, this is the first time such a proof has been proposed. A plethora of numerical experiments are carried to validate the consistency, and a preliminary comparison with classical EKF-SLAM in different noisy situations is also presented. Our proposed iMonoSLAM shows outstanding performance in obtaining reliable solutions, highlighting the potential application prospect in safety-critical scenarios of mobile robots. Full article

A tightly coupled hybrid monocular visual SLAM system for unmanned underwater vehicles (UUVs) is introduced in this paper. Specifically, we propose a robust three-step hybrid tracking strategy. The feature-based method initially provides a rough pose estimate, then the direct method refines it, and finally, the refined results are used to reproject map points to improve the number of features tracked and stability. Furthermore, a tightly coupled visual hybrid optimization method is presented to address the inaccuracy of the back-end pose optimization. The selection of features for stable tracking is achieved through the integration of two distinct residuals: geometric reprojection error and photometric error. The efficacy of the proposed system is demonstrated through quantitative and qualitative analyses in both artificial and natural underwater environments, demonstrating excellent stable tracking and accurate localization results. Full article

Two-view epipolar initialization for feature-based monocular SLAM with the RANSAC approach is challenging in dynamic environments. This paper presents a universal and practical method for improving the automatic estimation of initial poses and landmarks across multiple frames in real time. Image features corresponding to the same spatial points are matched and tracked across consecutive frames, and those that belong to stationary points are identified using ST-RANSAC, an algorithm designed to detect inliers based on both spatial and temporal consistency. Two-view epipolar computations are then performed in parallel among frames and corresponding features to select the most reliable initialization. The proposed method is integrated with ORB-SLAM3 and evaluated on dynamic datasets for comparative analysis with the baseline. The experimental results demonstrate that the proposed method improves the accuracy of initial pose estimations with the construction of static landmarks while significantly reducing feature extraction scale and computational cost. Full article

To address the inherent scale ambiguity and positioning drift in monocular visual Simultaneous Localization and Mapping (SLAM), this paper proposes a novel localization method that integrates monocular visual SLAM with Ultra-Wideband (UWB) ranging information. This method enables high-precision localization for unmanned aerial vehicles (UAVs) in complex environments without global navigation information. The proposed framework, IVU-AutoNav, relies solely on distance measurements between a fixed UWB anchor and the UAV’s UWB device. Initially, it jointly solves for the position of the UWB anchor and the scale factor of the SLAM system using the scale-ambiguous SLAM data and ranging information. Subsequently, a pose optimization equation is formulated, which integrates visual reprojection errors and ranging errors, to achieve precise localization with a metric scale. Furthermore, a global optimization process is applied to enhance the global consistency of the localization map and optimize the positions of the UWB anchors and scale factor. The proposed approach is validated through both simulation and experimental studies, demonstrating its effectiveness. Experimental results show a scale error of less than 1.8% and a root mean square error of 0.23 m, outperforming existing state-of-the-art visual SLAM systems. These findings underscore the potential and efficacy of the monocular visual-UWB coupled SLAM method in advancing UAV navigation and localization capabilities. Full article

In this paper, we present a novel monocular simultaneous localization and mapping (SLAM) initialization algorithm that relies on structural features by tracking structural lines. This approach addresses the limitations of the traditional method, which can fail to account for a lack of features or their uneven distribution. Our proposed method utilizes a sliding window approach to guarantee the quality and stability of the initial pose estimation. We incorporate multiple geometric constraints, orthogonal dominant directions, and coplanar structural lines to construct an efficient pose optimization strategy. Experimental evaluations conducted on both the collected chessboard datasets and real scene datasets show that our approach provides superior results in terms of accuracy and real-time performance compared to the well-tuned baseline methods. Notably, our algorithm achieves these improvements while being computationally lightweight, without the need for matrix decomposition. Full article

Many visual SLAM systems are generally solved using natural landmarks or optical flow. However, due to textureless areas, illumination change or motion blur, they often acquire poor camera poses or even fail to track. Additionally, they cannot obtain camera poses with a metric scale in the monocular case. In some cases (such as when calibrating the extrinsic parameters of camera-IMU), we prefer to sacrifice the flexibility of such methods to improve accuracy and robustness by using artificial landmarks. This paper proposes enhancements to the traditional SPM-SLAM, which is a system that aims to build a map of markers and simultaneously localize the camera pose. By placing the markers in the surrounding environment, the system can run stably and obtain accurate camera poses. To improve robustness and accuracy in the case of rotational movements, we improve the initialization, keyframes insertion and relocalization. Additionally, we propose a novel method to estimate marker poses from a set of images to solve the problem of planar-marker pose ambiguity. Compared with the state-of-art, the experiments show that our system achieves better accuracy in most public sequences and is more robust than SPM-SLAM under rotational movements. Finally, the open-source code is publicly available and can be found at GitHub. Full article

In order to improve the initialization robustness of visual inertial SLAM, the complementarity of the optical flow method and the feature-based method can be used in vision data processing. The parallel initialization method is proposed, where the optical flow inertial initialization and the monocular feature-based initialization are carried out at the same time. After the initializations, the state estimation results are jointly optimized by bundle adjustment. The proposed method retains more mapping information, and correspondingly is more adaptable to the initialization scene. It is found that the initialization map constructed by the proposed method features a comparable accuracy to the one constructed by ORB-SLAM3 in monocular inertial mode. Since the online extrinsic parameter estimation can be realized by the proposed method, it is considered better than ORB-SLAM3 in the aspect of portability. By the experiments performed on the benchmark dataset EuRoC, the effectiveness and robustness of the proposed method are validated. Full article

In the monocular visual-inertia mode of ORB-SLAM3, the insufficient excitation obtained by the inertial measurement unit (IMU) will lead to a long system initialization time. Hence, the trajectory can be easily lost and the map creation will not be completed. To solve this problem, a fast map restoration method is proposed in this paper, which adresses the problem of insufficient excitation of IMU. Firstly, the frames before system initialization are quickly tracked using bag-of-words and maximum likelyhood perspective-n-point (MLPNP). Then, the grayscale histogram is used to accelerate the loop closure detection to reduce the time consumption caused by the map restoration. After experimental verification on public datasets, the proposed algorithm can establish a complete map and ensure real-time performance. Compared with the traditional ORB-SLAM3, the accuracy improved by about 47.51% and time efficiency improved by about 55.96%. Full article

This paper presents a new method of removing mismatches of redundant points based on oriented fast and rotated brief (ORB) in vision simultaneous localization and mapping (SLAM) systems. On the one hand, the grid-based motion statistics (GMS) algorithm reduces the processing time of key frames with more feature points and greatly increases the robustness of the original algorithm in a complex environment. On the other hand, aiming at the situation that the GMS algorithm is prone to false matching when there are few symmetry feature point pairs, the random sample consensus (RANSAC) algorithm is used to optimize and correct it. Experiments show that the method we propose has an average error correction rate of 28.81% for individual GMS while the time consumed at the same accuracy threshold is reduced by 72.18% on average. At the same time, we compared it to locality preserving matching (LPM) and progressive sample consensus (PROSAC), and it performed the best. Finally, we integrated GMS-RANSAC into the ORB-SLAM2 system for monocular initialization, which results in a significant improvement. Full article

In view of traditional point-line feature visual inertial simultaneous localization and mapping (SLAM) system, which has weak performance in accuracy so that it cannot be processed in real time under the condition of weak indoor texture and light and shade change, this paper proposes an inertial SLAM method based on point-line vision for indoor weak texture and illumination. Firstly, based on Bilateral Filtering, we apply the Speeded Up Robust Features (SURF) point feature extraction and Fast Nearest neighbor (FLANN) algorithms to improve the robustness of point feature extraction result. Secondly, we establish a minimum density threshold and length suppression parameter selection strategy of line feature, and take the geometric constraint line feature matching into consideration to improve the efficiency of processing line feature. And the parameters and biases of visual inertia are initialized based on maximum posterior estimation method. Finally, the simulation experiments are compared with the traditional tightly-coupled monocular visual–inertial odometry using point and line features (PL-VIO) algorithm. The simulation results demonstrate that the proposed an inertial SLAM method based on point-line vision for indoor weak texture and illumination can be effectively operated in real time, and its positioning accuracy is 22% higher on average and 40% higher in the scenario that illumination changes and blurred image. Full article

In the aim of improving the positioning accuracy of the monocular visual-inertial simultaneous localization and mapping (VI-SLAM) system, an improved initialization method with faster convergence is proposed. This approach is classified into three parts: Firstly, in the initial stage, the pure vision measurement model of ORB-SLAM is employed to make all the variables visible. Secondly, the frequency of the IMU and camera was aligned by IMU pre-integration technology. Thirdly, an improved iterative method is put forward for estimating the initial parameters of IMU faster. The estimation of IMU initial parameters is divided into several simpler sub-problems, containing direction refinement gravity estimation, gyroscope deviation estimation, accelerometer bias, and scale estimation. The experimental results on the self-built robot platform show that our method can up-regulate the initialization convergence speed, simultaneously improve the positioning accuracy of the entire VI-SLAM system. Full article

Currently, simultaneous localization and mapping (SLAM) is one of the main research topics in the robotics field. Visual-inertia SLAM, which consists of a camera and an inertial measurement unit (IMU), can significantly improve robustness and enable scale weak-visibility, whereas monocular visual SLAM is scale-invisible. For ground mobile robots, the introduction of a wheel speed sensor can solve the scale weak-visibility problem and improve robustness under abnormal conditions. In this paper, a multi-sensor fusion SLAM algorithm using monocular vision, inertia, and wheel speed measurements is proposed. The sensor measurements are combined in a tightly coupled manner, and a nonlinear optimization method is used to maximize the posterior probability to solve the optimal state estimation. Loop detection and back-end optimization are added to help reduce or even eliminate the cumulative error of the estimated poses, thus ensuring global consistency of the trajectory and map. The outstanding contribution of this paper is that the wheel odometer pre-integration algorithm, which combines the chassis speed and IMU angular speed, can avoid the repeated integration caused by linearization point changes during iterative optimization; state initialization based on the wheel odometer and IMU enables a quick and reliable calculation of the initial state values required by the state estimator in both stationary and moving states. Comparative experiments were conducted in room-scale scenes, building scale scenes, and visual loss scenarios. The results showed that the proposed algorithm is highly accurate—2.2 m of cumulative error after moving 812 m (0.28%, loopback optimization disabled)—robust, and has an effective localization capability even in the event of sensor loss, including visual loss. The accuracy and robustness of the proposed method are superior to those of monocular visual inertia SLAM and traditional wheel odometers. Full article

Simultaneous Localization and Mapping (SLAM) has always been the focus of the robot navigation for many decades and becomes a research hotspot in recent years. Because a SLAM system based on vision sensor is vulnerable to environment illumination and texture, the problem of initial scale ambiguity still exists in a monocular SLAM system. The fusion of a monocular camera and an inertial measurement unit (IMU) can effectively solve the scale blur problem, improve the robustness of the system, and achieve higher positioning accuracy. Based on a monocular visual-inertial navigation system (VINS-mono), a state-of-the-art fusion performance of monocular vision and IMU, this paper designs a new initialization scheme that can calculate the acceleration bias as a variable during the initialization process so that it can be applied to low-cost IMU sensors. Besides, in order to obtain better initialization accuracy, visual matching positioning method based on feature point is used to assist the initialization process. After the initialization process, it switches to optical flow tracking visual positioning mode to reduce the calculation complexity. By using the proposed method, the advantages of feature point method and optical flow method can be fused. This paper, the first one to use both the feature point method and optical flow method, has better performance in the comprehensive performance of positioning accuracy and robustness under the low-cost sensors. Through experiments conducted with the EuRoc dataset and campus environment, the results show that the initial values obtained through the initialization process can be efficiently used for launching nonlinear visual-inertial state estimator and positioning accuracy of the improved VINS-mono has been improved by about 10% than VINS-mono. Full article

Simultaneous localization and mapping (SLAM) of a monocular projective camera installed on an unmanned aerial vehicle (UAV) is a challenging task in photogrammetry, computer vision, and robotics. This paper presents a novel real-time monocular SLAM solution for UAV applications. It is based on two steps: consecutive construction of the UAV path, and adjacent strip connection. Consecutive construction rapidly estimates the UAV path by sequentially connecting incoming images to a network of connected images. A multilevel pyramid matching is proposed for this step that contains a sub-window matching using high-resolution images. The sub-window matching increases the frequency of tie points by propagating locations of matched sub-windows that leads to a list of high-frequency tie points while keeping the execution time relatively low. A sparse bundle block adjustment (BBA) is employed to optimize the initial path by considering nuisance parameters. System calibration parameters with respect to global navigation satellite system (GNSS) and inertial navigation system (INS) are optionally considered in the BBA model for direct georeferencing. Ground control points and checkpoints are optionally included in the model for georeferencing and quality control. Adjacent strip connection is enabled by an overlap analysis to further improve connectivity of local networks. A novel angular parametrization based on spherical rotation coordinate system is presented to address the gimbal lock singularity of BBA. Our results suggest that the proposed scheme is a precise real-time monocular SLAM solution for a UAV. Full article
