Micromachines, MEMS and actuators suffer from much more significant relative friction and wear issues than their equivalent macroscopic devices. Active magnetic bearings can be a good option to mitigate friction issues; however, their construction at microscale is still an open research topic. In this work, we have developed a micrometric-size active magnetic bearing with a simple configuration and one vertical degree of freedom. This active magnetic microbearing is composed of a coreless coil with 1 mm outer diameter, 0.3 mm inner diameter and 0.5 mm length that holds a 0.3 mm outer diameter, 0.5 mm length NdFeB N52 micromagnet. Stable magnetic levitation is achieved by regulating the coil current based on precise position measurements of the magnet obtained using the smallest commercially available Hall-effect microsensor. The microprobe integrates between the coil and magnet, reducing the total size of the device. A maximum axial load capacity of 1.16 mN/A has been demonstrated. This micromagnetic bearing is one of the smallest active magnetic bearings developed to date, demonstrating the viability of this kind of system at the micrometric scale. Full article

The technology development for the mass ceramic gas flow sensor (CGFS) adopted for harsh operating conditions is presented. The main characteristic of this technology is its simplicity and affordability for mass fast prototyping of CGFS with a limited set of technological equipment. Special attention is paid to the discussion of the technological and operational materials’ compatibility, flexibility, and speed of their processing to adapt the best mass flow sensor design option. The CGFS, designed and manufactured in just a few days, was tested in conditions close to the real ones and demonstrated the ability to measure gas flow in the range from 0.21 m/s to 1.25 m/s, with a constant power consumption of 152 mW@346 °C. Full article

We report a dispersion-controlled Yb-doped fiber chirped pulse amplification (CPA) system incorporating a tunable chirped fiber Bragg grating (CFBG) stretcher and a single-grating transmission compressor for dynamic compensation of power-dependent nonlinear effect. During the pulse amplification, the CFBG introduces adjustable third-order dispersion (TOD). By tuning the initial TOD provided by CFBG from −0.1965 ps³ at 2.37 W to −0.1791 ps³ at 9.65 W, residual TOD is efficiently compensated with the power-dependent nonlinear effect. As a result, by optimizing the dispersion balance at each output power, nearly constant femtosecond pulses with a duration of 250 fs are obtained over the entire power range, confirming effective control of nonlinear and dispersive effects in the amplification. The high-quality 1030 nm pulses enable efficient second-harmonic generation (SHG) in a type-I BBO crystal, producing 3.56 W femtosecond output at around 515 nm with a pulse duration of 190 fs, close to the Fourier transform limit. These results demonstrate a robust approach to generating high-power and temporal coherent ultrafast pulses suitable for precision micromachining and two-photon polymerization. Full article

This work presents, to the best of our knowledge, the first experimental report of an erbium/ytterbium double-clad ring fiber laser based on nonlinear polarization rotation (NPR) operating in a self-starting Q-switched high-order harmonic mode locking noise-like pulse (QHML-NLP) regime. The NPR mechanism relies on an arrangement composed of a beam splitter cube, a half-wave retarder, and a quarter-wave retarder. Through specific adjustments of the wave retarders and pump power, the laser cavity engages the QHML-NLP regime, where mode-locked burst-like pulses containing a significant number of NLPs are modulated by a giant Q-switched envelope. The laser system emits at the 132nd-order harmonic mode locking (HML) frequency, representing the highest order achieved to date in the framework of QHML-NLP. Additional features include a broadband optical spectrum with dual-wavelength emission at 1568.4 nm and 1605.9 nm, and maximum energies of 2.37 µJ for the Q-switched envelope and 200 nJ for the mode-locked burst-like pulse. These detailed experimental results reveal remarkable aspects in the NLP dynamics, contributing to a deeper understanding of their physical mechanisms and highlighting their potential as novel laser sources for micromachining and nonlinear optics. Full article

The development of photonic-integrated circuits (PICs) for data communication, sensing, and quantum computing is hindered by the high complexity and cost of traditional fabrication methods, which rely on expensive equipment, limiting accessibility for research and prototyping. This study introduces a Direct Laser Writing (DLW) system designed as a low-cost alternative, utilizing an XY platform for precise substrate movement and an optical system comprising a collimator and lens to focus the laser beam. Operating on a single layer, the system employs SU-8 photoresist to fabricate polymer-based structures on substrates such as ITO-covered glass. Preparation involves thorough cleaning, spin coating with photoresist, and pre- and post-baking to ensure material stability. This approach reduces dependence on costly infrastructure, making it suitable for academic settings and enabling rapid prototyping. A user interface and custom slicer process standard .dxf files into executable commands, enhancing operational flexibility. Experimental results demonstrate a resolution of 10 µm, with successful patterning of structures, including diffraction grids, waveguides, and multimode interference devices. This system aims to transform PIC prototype fabrication into a cost-effective, accessible process. Full article

This work presents the design, fabrication, and characterization of a three-dimensional FeCo-based flux-modulator microwinding intended for integration into high-torque axial-flux Vernier micromotors. The proposed micromotor architecture modulates the stator magnetic flux using 12 magnetically isolated FeCo teeth interacting with an 11-pole permanent-magnet rotor. The design requires the manufacturing of complex three-dimensional micrometric parts, including three teeth and a cylindrical core. Such a complex design cannot be manufactured using conventional micromanufacturing lithography or 2D planar methods. The flux-modulator envelope dimensions are 250 μm outer diameter and 355 μm height. It is manufactured using a femtosecond laser-machining process that preserves factory-finished surfaces and minimizes heat-affected zones. In addition, this micrometric part has been wound using 20 μm diameter enamelled copper wire. A dedicated magnetic clamping fixture is developed to enable multilayer microwinding of the integrated core, producing a 17-turn inductor with a 60.6% fill factor—the highest reported for a manually wound ferromagnetic-core microcoil of this scale. Geometric and magnetic characterization validates the simulation model and demonstrates the field distribution inside the isolated core. The results establish a viable micromanufacturing workflow for complex 3D FeCo microwindings, supporting the development of next-generation high-performance MEMS micromotors. Full article

The Clausius–Mossotti (CM) factor underpins the theoretical description of dielectrophoresis (DEP) and is widely used in micro- and nano-scale systems for frequency-dependent particle and cell manipulation. It has further been proposed as an “electrophysiology Rosetta Stone” capable of linking DEP spectra to intrinsic cellular electrical properties. In this paper, the mathematical foundations and interpretive limits of this proposal are critically examined. By analyzing contrast factors derived from Laplace’s equation across multiple physical domains, it is shown that the CM functional form is a universal consequence of geometry, material contrast, and boundary conditions in linear Laplacian fields, rather than a feature unique to biological systems. Key modelling assumptions relevant to DEP are reassessed. Deviations from spherical symmetry lead naturally to tensorial contrast factors through geometry-dependent depolarisation coefficients. Complex, frequency-dependent CM factors and associated relaxation times are shown to inevitably arise from the coexistence of dissipative and storage mechanisms under time-varying forcing, independent of particle composition. Membrane surface charge influences DEP response through modified interfacial boundary conditions and effective transport parameters, rather than by introducing an independent driving mechanism. These results indicate that DEP spectra primarily reflect boundary-controlled field–particle coupling. From an inverse-problem perspective, this places fundamental constraints on parameter identifiability in DEP-based characterization. The CM factor remains a powerful and general modelling tool for micromachines and microfluidic systems, but its interpretive scope must be understood within the limits imposed by Laplacian field theory. Full article

This paper investigates optical resonance wavelength (ORW) shifts in large-element, fiber-tip surface-micromachined optical ultrasound transducers (SMOUTs) induced by changes in ambient pressure and temperature. The displacement behavior of the SMOUT top membrane under varying pressure and temperature conditions is analyzed and modeled, and simulation results are presented for fiber-tip SMOUTs with four diameters (200, 400, 600, and 800 µm). Fabricated and assembled fiber-tip SMOUTs are experimentally characterized using two dedicated setups to measure their reflectivity spectra and ORW shifts over ambient pressures from 80 kPa to 120 kPa and temperatures from 25 °C to 45 °C. The experimental data show good agreement with the simulation results. These findings provide a solid basis for active control and compensation of ORW shifts via pressure and temperature adjustment. By stabilizing the reflectivity spectrum and minimizing ORW drift, the use of non-tunable high-power light sources to interrogate arrays of fiber-tip SMOUTs with enhanced operational stability and sensitivity is enabled. Full article

This study investigates the effects of post-fabrication annealing on polymer-based capacitive micromachined ultrasonic transducers (polyCMUTs). These devices comprise microscopic diaphragms produced via photolithographic patterning of polymer layers. Critical point drying, required to release the diaphragms, can cause significant plastic deformation, thereby reducing electromechanical coupling. Post-fabrication annealing, carried out in incremental steps up to 190 °C, led to an effective increase in coupling by a factor of 5.4. Atomic Force Microscopy showed that the initial upward deflection of 162.7 nm decreased to 6.2 nm after annealing at 190 °C, while also improving surface uniformity. In parallel, the transducer’s resonance frequency rose from 2.33 MHz (unannealed) to 2.60 MHz, and the input impedance phase angle at resonance increased from −68.1° to −4.3°. Together, these changes indicate a significant improvement in resonator behavior and, consequently, device performance. Thus, post-fabrication annealing is an effective measure to achieve the designed performance while enhancing manufacturing yield, thereby increasing the applicability of polyCMUTs. Full article

Thermocatalytic sensors are used as universal explosion meters for measurement of the Lower Explosive Limit (LEL) of hydrocarbon gases mixtures. Historically, thermo-catalytic sensors, with their bulky “pellistor” design, have been poorly suited for mass production using group microelectronic processing. Another significant challenge for developers of new sensor designs is to minimize power dissipation while enhancing the service life and resistance of catalytic elements to poisoning from silicon–organic and sulfur-containing gases. To meet the specified requirements, we developed a low-power thermocatalytic sensor utilizing ceramic technology, capable of holding the temperature of technology operations up to 900 °C. Full article

A reflective in-fiber liquid microsphere whispering gallery mode (WGM) resonator based on a Y-waveguide coupler is proposed and experimentally demonstrated. The sphere resonator is introduced inside a single-mode fiber (SMF) by using femtosecond laser micromachining and fusion splicing. A Y-waveguide coupler is fabricated with femtosecond laser direct writing, which is used to simultaneously excite and collect the WGM field through evanescent field coupling. High-index liquids are filled into the sphere through a laser-drilled channel to form a liquid microsphere where the WGM resonation takes place. The WGM resonator is sensitive to the refractive index (RI) of the filled liquids, and a RI sensitivity of 439 nm/RIU is achieved in an index range from 1.672 to 1.692. The liquid microsphere resonator is also sensitive to temperature, with a sensitivity of −307.1 pm/°C obtained. The microsphere resonator is small in size and robust, which has broad application prospects in the field of food and the chemical industry. Full article

Deep Reactive Ion Etching (DRIE), as a key process in silicon micromachining, remains constrained in high-precision applications by sidewall angle deviation and aspect ratio limitations. This study systematically investigates the mapping relationship between process parameters and etching morphology, focusing on the following aspects: the influence mechanism of C₄F₈ passivation time and bottom RF power on sidewall perpendicularity; and the effect patterns of etch cycle count, single-step time, and bottom RF power on aspect ratio and top–bottom line width (CD) difference. The findings reveal that dynamic adjustment of bottom RF power significantly influences sidewall angle: incremental adjustment tends to cause sharp angles (decreased angular precision), while decremental adjustment tends to form obtuse angles. Simply increasing the cycle count leads to a bottleneck in etch depth growth. Combining incremental bottom RF power adjustment can overcome depth limitations but induces axial variation in aperture dimensions. Optimizing the passivation-to-etch time ratio effectively controls etch morphology characteristics. This study achieved an etch depth of 112.2 μm for a 5 μm wide trench with an overall aperture size difference of 0.279 μm, providing a theoretical basis and practical guidance for parameter optimization in DRIE processes for high-precision silicon structure fabrication. Full article

Surface functionalisation of polymers is essential for enhancing properties such as wettability and mechanical resistance. This study presents a scalable, coating-free approach to fabricate hydrophobic and superhydrophobic Polydimethylsiloxane (PDMS) surfaces. Aluminium (AA2024) moulds were microstructured using a TruMicro femtosecond laser system to generate grid patterns with controlled hatch distances and depths, as well as laser-induced periodic surface structures (LIPSSs). These features were accurately replicated onto PDMS, as confirmed by scanning electron miscoscopy (SEM) and profilometry. Contact angle measurements showed a marked increase in hydrophobicity, reaching superhydrophobicity for optimised parameters, with surface stability maintained over four months without degradation. Full article
