This study presents a system for precisely measuring pulsed magnetic fields with high amplitude and microsecond duration with minimal interference. The system comprises a probe with an advanced magnetic field sensor and a measurement unit for signal conversion, analysis, and digitization. The sensor uses a thin nanostructured manganite La-Sr-Mn-O film exhibiting colossal magnetoresistance, which enables precise magnetic field measurement independent of its orientation. Films with different compositions were optimized and tested in pulsed magnetic fields. The measurement unit includes a pulsed voltage generator, an ADC, a microcontroller, and an amplifier unit. Two versions of the measurement unit were developed: one with a separate amplifier unit configured for the sensor positioned more than 1 m away from the measurement unit, and the other with an integrated amplifier for the sensor positioned at a distance of less than 0.5 m. A bipolar pulsed voltage supplying the sensor minimized the parasitic effects of the electromotive force induced in the probe circuit. The data were transmitted via a fiber optic cable to a PC equipped with a special software for processing and recording. Tests with 20–30 μs pulses up to 15 T confirmed the effectiveness of the system for measuring high pulsed magnetic fields. Full article

Hole-doped manganese oxides exhibit a gigantic negative magnetoresistance, referred to as colossal magnetoresistance (CMR), owing to the interplay between double-exchange (DE) ferromagnetic metal and charge-ordered antiferromagnetic insulator/semiconductor phases. Magnetoresistive manganites display a sharp resistivity drop at the metal–insulator transition temperature (T^MI). CMR effects in perovskite manganites, specifically La_0.67Ca_0.33MnO₃ (La-Ca-Mn-O or LCMO), have been extensively investigated. This review paper provides a comprehensive introduction to the crystallographic structure, as well as the electronic and magnetic properties, of LCMO films. Furthermore, we delve into a detailed discussion of the effects of epitaxial strain induced by different substrates on LCMO films. Additionally, we review the early findings and diverse applications of LCMO thin films. Finally, we outline potential challenges and prospects for achieving superior LCMO film properties. Full article

The effects on the structure and magnetic properties of Eu_1−xY_xMnO₃ (0.0 ≤ x ≤ 0.5) thin films due to lattice strain were investigated and compared with those obtained in equivalent composition ceramics. The films were deposited by spin-coating chemical solution onto Pt\TiO₂\SiO₂\Si (100) standard substrates. X-ray diffraction and Raman spectroscopy measurements revealed that all films crystallize in orthorhombic structure with space group Pnma, observing an added contraction of the unit cell with increasing Y-substitution ou Eu, corresponding to a broadening of the Mn-O1-Mn angle and a gradual decrease in magnetic order response. Full article

The results of magnetoresistance (MR) and resistance relaxation of nanostructured La_1−xSr_xMn_yO₃ (LSMO) films with different film thicknesses (60–480 nm) grown on Si/SiO₂ substrate by the pulsed-injection MOCVD technique are presented and compared with the reference manganite LSMO/Al₂O₃ films of the same thickness. The MR was investigated in permanent (up to 0.7 T) and pulsed (up to 10 T) magnetic fields in the temperature range of 80–300 K, and the resistance-relaxation processes were studied after the switch-off of the magnetic pulse with an amplitude of 10 T and a duration of 200 μs. It was found that the high-field MR values were comparable for all investigated films (~−40% at 10 T), whereas the memory effects differed depending on the film thickness and substrate used for the deposition. It was demonstrated that resistance relaxation to the initial state after removal of the magnetic field occurred in two time scales: fast’ (~300 μs) and slow (longer than 10 ms). The observed fast relaxation process was analyzed using the Kolmogorov–Avrami–Fatuzzo model, taking into account the reorientation of magnetic domains into their equilibrium state. The smallest remnant resistivity values were found for the LSMO films grown on SiO₂/Si substrate in comparison to the LSMO/Al₂O₃ films. The testing of the LSMO/SiO₂/Si-based magnetic sensors in an alternating magnetic field with a half-period of 22 μs demonstrated that these films could be used for the development of fast magnetic sensors operating at room temperature. For operation at cryogenic temperature, the LSMO/SiO₂/Si films could be employed only for single-pulse measurements due to magnetic-memory effects. Full article

Advanced scientific and industrial equipment requires magnetic field sensors with decreased dimensions while keeping high sensitivity in a wide range of magnetic fields and temperatures. However, there is a lack of commercial sensors for measurements of high magnetic fields, from ∼1 T up to megagauss. Therefore, the search for advanced materials and the engineering of nanostructures exhibiting extraordinary properties or new phenomena for high magnetic field sensing applications is of great importance. The main focus of this review is the investigation of thin films, nanostructures and two-dimensional (2D) materials exhibiting non-saturating magnetoresistance up to high magnetic fields. Results of the review showed how tuning of the nanostructure and chemical composition of thin polycrystalline ferromagnetic oxide films (manganites) can result in a remarkable colossal magnetoresistance up to megagauss. Moreover, by introducing some structural disorder in different classes of materials, such as non-stoichiometric silver chalcogenides, narrow band gap semiconductors, and 2D materials such as graphene and transition metal dichalcogenides, the possibility to increase the linear magnetoresistive response range up to very strong magnetic fields (50 T and more) and over a large range of temperatures was demonstrated. Approaches for the tailoring of the magnetoresistive properties of these materials and nanostructures for high magnetic field sensor applications were discussed and future perspectives were outlined. Full article

A revisited study of perovskite-based manganite La_0.67Sr_0.33MnO₃ (LSMO) deposited onto corning-glass (CG) substrates is reported here. The LSMO films were fabricated with RF sputtering with different deposition times, varying from 60 to 180 min, resulting in films with thicknesses of 35.0–109.7 nm. Rietveld refinements of the XRD spectrum showed that the samples exhibited hexagonal structures with a space group of R-3c (167) and remained unmodified structures. Clusters of monolayer growth were observed from the morphologies of the films. Interestingly, the average particle size obtained with an AFM perceived an insignificant variation of 31.7–35.6 nm despite the film thickness increment. Optical, electrical and magnetic properties were studied, as particle-size variation usually has a notable contribution to changes in these properties. It was found that the optical band gap (E_g) was in direct variation with the deposition time due to enhanced thickness and surface roughness. The temperature dependence of the resistivity graph was fitted with the percolation model to obtain further enlightenment on the electrical transport in the films. Low-field magnetoresistance (LFMR) was observed for all samples. Ferromagnetic to paramagnetic transition was observed in the vicinity of all samples’ T_C values. Full article

A measurement system based on the colossal magnetoresistance CMR-B-scalar sensor was developed for the measurement of short-duration high-amplitude magnetic fields. The system consists of a magnetic field sensor made from thin nanostructured manganite film with minimized memory effect, and a magnetic field recording module. The memory effect of the La_1−xSr_x(Mn_1−yCo_y)_zO₃ manganite films doped with different amounts of Co and Mn was investigated by measuring the magnetoresistance (MR) and resistance relaxation in pulsed magnetic fields up to 20 T in the temperature range of 80–365 K. It was found that for low-temperature applications, films doped with Co (LSMCO) are preferable due to the minimized magnetic memory effect at these temperatures, compared with LSMO films without Co. For applications at temperatures higher than room temperature, nanostructured manganite LSMO films with increased Mn content above the stoichiometric level have to be used. These films do not exhibit magnetic memory effects and have higher MR values. To avoid parasitic signal due to electromotive forces appearing in the transmission line of the sensor during measurement of short-pulsed magnetic fields, a bipolar-pulsed voltage supply for the sensor was used. For signal recording, a measurement module consisting of a pulsed voltage generator with a frequency up to 12.5 MHz, a 16-bit ADC with a sampling rate of 25 MHz, and a microprocessor was proposed. The circuit of the measurement module was shielded against low- and high-frequency electromagnetic noise, and the recorded signal was transmitted to a personal computer using a fiber optic link. The system was tested using magnetic field generators, generating magnetic fields with pulse durations ranging from 3 to 20 μs. The developed magnetic field measurement system can be used for the measurement of high-pulsed magnetic fields with pulse durations in the order of microseconds in different fields of science and industry. Full article

The magnetic behaviors and magnetocaloric effect (MCE) of Pr_0.7Sr_0.3MnO₃ (PSMO-7) film grown on a (001) SrTiO₃ single-crystal substrate by a pulsed laser deposition (PLD) were studied in this paper. X-ray diffraction with a high resolution (HRXRD) measurement shows that PSMO-7 film is grown with a (001) single orientation. The magnetic properties and the MCE related to the ferromagnetic (FM) phase transition of the PSMO-7 film are investigated using the temperature dependence of magnetization M(T) and the magnetic field dependence of magnetization M(H). The M(T) data suggest that with decreasing temperatures, the PSMO-7 film goes through the transition from the paramagnetic (PM) state to the FM state at around the Curie temperature (T_C). The T_C (about 193 K) can be obtained by the linear fit of the Curie law. Magnetic hysteresis loop measurements show that the PSMO-7 film exhibits the FM feature at temperatures of 10, 100, and 150 K (low magnetic hysteresis can be found), while the film reveals the PM feature with the temperature increased up to 200 and/or 300 K. The research results of M(H) data are consistent with the M(T) data. Furthermore, the magnetic entropy change ($-\mathsf{\Delta }{S}_{\mathrm{M}}$) of the PSMO-7 film was studied. It was found that the maximum value of ($-\mathsf{\Delta }{S}_{\mathrm{M}}$) near T_C reaches about 4.7 J/kg·K under the applied field change of 20 kOe, which is comparable to that of metal Gd ($-\mathsf{\Delta }{S}_{\mathrm{M}}$ of 2.8 J/kg K under 10 kOe), indicating the potential applications of PSMO-7 film in the field of magnetic refrigeration. Full article

Magnetic perovskite films have promising properties for use in energy-efficient spintronic devices and magnetic refrigeration. Here, an epitaxial ferromagnetic La_0.67Ba_0.33Mn_0.95Ti_0.05O₃ (LBMTO-5) thin film was grown on SrTiO₃(001) single crystal substrate by pulsed laser deposition. High-resolution X-ray diffraction proved the high crystallinity of the film with tetragonal symmetry. The magnetic, magnetocaloric and magnetoresistance properties at different directions of the applied magnetic field with respect to the ab plane of the film were investigated. An in-plane uni-axial magnetic anisotropy was evidenced. The LBMTO-5 epilayer exhibits a second-order ferromagnetic-paramagnetic phase transition around 234 K together with a metal–semiconductor transition close to this Curie temperature (T_C). The magnetic entropy variation under 5 T induction of a magnetic field applied parallel to the film surface reaches a maximum of 17.27 mJ/cm³ K. The relative cooling power is 1400 mJ/cm³ K (53% of the reference value reported for bulk Gd) for the same applied magnetic field. Giant magnetoresistance of about 82% under 5 T is obtained at a temperature close to T_C. Defined as the difference between specific resistivity obtained under 5 T with the current flowing along the magnetic easy axis and the magnetic field oriented transversally to the current, parallel and perpendicular to the sample plane, respectively, the in-plane magneto-resistance anisotropy in 5 T is about 9% near the T_C. Full article

Epitaxial strain modifies the physical properties of thin films deposited on single-crystal substrates. In a previous work, we demonstrated that in the case of La_2/3Ca_1/3MnO₃ thin films the strain induced by the substrate can produce the segregation of a non-ferromagnetic layer (NFL) at the top surface of ferromagnetic epitaxial La_2/3Ca_1/3MnO₃ for a critical value of the tetragonality τ, defined as τ = |c − a|a, of τ_C ≈ 0.024. Although preliminary analysis suggested its antiferromagnetic nature, to date a complete characterization of the magnetic state of such an NFL has not been performed. Here, we present a comprehensive magnetic characterization of the strain-induced segregated NFL. The field-cooled magnetic hysteresis loops exhibit an exchange bias mechanism below T ≈ 80 K, which is well below the Curie temperature of the ferromagnetic La_2/3Ca_1/3MnO₃ layer. The exchange bias and coercive fields decay exponentially with temperature, which is commonly accepted to describe spin-glass (SG) behavior. The signatures of slow dynamics were confirmed by slow spin relaxation over a wide temperature regime. Low-energy muon spectroscopy experiments directly evidence the slowing down of the magnetic moments below ~100 K in the NFL. The experimental results indicate the SG nature of the NFL. This SG state can be understood within the context of the competing ferromagnetic and antiferromagnetic interactions of similar energies. Full article

Lanthanum manganite (LMO) thin films were deposited by co-sputtering La and Mn targets in an Ar and O₂ gas mixture. The films were synthesized on silicon and fused silica substrates. The influences of thermal annealing on the structure, optical and electrical properties of LMO films were investigated. The results exhibited a correlation between these properties. In the amorphous state, an increase in annealing temperature improved the optical transmission and decreased the electrical capacitance. The beginning of crystallization at 600 °C was manifested by a strong increase in the capacitance and a decrease in the optical transmission. At higher annealing temperature, polycrystalline films were obtained with different optical and electrical characteristics. On the other hand, the annealed LMO films showed a photocurrent effect during exposure to a weak LED light. Full article

The results of colossal magnetoresistance (CMR) properties of La_1-xSr_xMn_yO₃ (LSMO) films grown by the pulsed injection MOCVD technique onto an Al₂O₃ substrate are presented. The grown films with different Sr (0.05 ≤ x ≤ 0.3) and Mn excess (y > 1) concentrations were nanostructured with vertically aligned column-shaped crystallites spread perpendicular to the film plane. It was found that microstructure, resistivity, and magnetoresistive properties of the films strongly depend on the strontium and manganese concentration. All films (including low Sr content) exhibit a metal–insulator transition typical for manganites at a certain temperature, T_m. The T_m vs. Sr content dependence for films with a constant Mn amount has maxima that shift to lower Sr values with the increase in Mn excess in the films. Moreover, the higher the Mn excess concentration in the films, the higher the T_m value obtained. The highest T_m values (270 K) were observed for nanostructured LSMO films with x = 0.17–0.18 and y = 1.15, while the highest low-field magnetoresistance (0.8% at 50 mT) at room temperature (290 K) was achieved for x = 0.3 and y = 1.15. The obtained low-field MR values were relatively high in comparison to those published in the literature results for lanthanum manganite films prepared without additional insulating oxide phases. It can be caused by high Curie temperature (383 K), high saturation magnetization at room temperature (870 emu/cm³), and relatively thin grain boundaries. The obtained results allow to fabricate CMR sensors for low magnetic field measurement at room temperature. Full article

The results of colossal magnetoresistance (CMR) properties of La_0.83Sr_0.17Mn_1.21O₃ (LSMO) films grown by pulsed injection MOCVD technique onto various substrates are presented. The films with thicknesses of 360 nm and 60 nm grown on AT-cut single crystal quartz, polycrystalline Al₂O₃, and amorphous Si/SiO₂ substrates were nanostructured with column-shaped crystallites spread perpendicular to the film plane. It was found that morphology, microstructure, and magnetoresistive properties of the films strongly depend on the substrate used. The low-field MR at low temperatures (25 K) showed twice higher values (−31% at 0.7 T) for LSMO/quartz in comparison to films grown on the other substrates (−15%). This value is high in comparison to results published in literature for manganite films prepared without additional insulating oxides. The high-field MR measured up to 20 T at 80 K was also the highest for LSMO/quartz films (−56%) and demonstrated the highest sensitivity S = 0.28 V/T at B = 0.25 T (voltage supply 2.5 V), which is promising for magnetic sensor applications. It was demonstrated that Mn excess Mn/(La + Sr) = 1.21 increases the metal-insulator transition temperature of the films up to 285 K, allowing the increase in the operation temperature of magnetic sensors up to 363 K. These results allow us to fabricate CMR sensors with predetermined parameters in a wide range of magnetic fields and temperatures. Full article

Nanocrystalline nickel manganite (NiMn₂O₄) powder with a pure cubic spinel phase structure was synthesized via sol-gel combustion and characterized with XRD, FT-IR, XPS and SEM. The powder was mixed with sodium alginate gel to form a nano-biocomposite gel, dried at room temperature to form a thick film and characterized with FT-IR and SEM. DC resistance and AC impedance of sensor test structures obtained by drop casting the nano-biocomposite gel onto test interdigitated PdAg electrodes on an alumina substrate were measured in the temperature range of 20–50 °C at a constant relative humidity (RH) of 50% and at room temperature (25 °C) in the RH range of 40–90%. The material constant obtained from the measured decrease in resistance with temperature was determined to be 4523 K, while the temperature sensitivity at room temperature (25 °C) was −5.09%/K. Analysis of the complex impedance plots showed a dominant influence of grains. The decrease in complex impedance with increase in temperature confirmed the negative temperature coefficient effect. The grain resistance and grain relaxation frequency were determined using an equivalent circuit. The activation energy for conduction was determined as 0.45 eV from the temperature dependence of the grain resistance according to the small polaron hopping model, while the activation energy for relaxation was 0.43 eV determined from the Arrhenius dependence of the grain relaxation frequency on temperature. Full article

The effects of an applied strain tensor on the electrical resistivity of a manganite granular system are investigated using a simple approach describing the induced deformation in terms of the tilt angle between adjacent grains. The results obtained assuming the resistivity of each grain as given by a metallic part, coming from the inner grain, and a surface-related tunnel contribution, allow us to estimate appreciable resistivity variations even in the case of small deformation angles. Full article
