Search Results (28)

Magnetorheological (MR) foams represent a class of smart materials with unique tunable viscoelastic properties when subjected to external magnetic fields. Combining porous structures with embedded magnetic particles, these materials address challenges such as leakage and sedimentation, typically encountered in conventional MR fluids while offering advantages like lightweight design, acoustic absorption, high energy harvesting capability, and tailored mechanical responses. Despite their potential, challenges such as non-uniform particle dispersion, limited durability under cyclic loads, and suboptimal magneto-mechanical coupling continue to hinder their broader adoption. This review systematically addresses these issues by evaluating the synthesis methods (ex situ vs. in situ), microstructural design strategies, and the role of magnetic particle alignment under varying curing conditions. Special attention is given to the influence of material composition—including matrix types, magnetic fillers, and additives—on the mechanical and magnetorheological behaviors. While the primary focus of this review is on MR foams, relevant studies on MR elastomers, which share fundamental principles, are also considered to provide a broader context. Recent advancements are also discussed, including the growing use of artificial intelligence (AI) to predict the rheological and magneto-mechanical behavior of MR materials, model complex device responses, and optimize material composition and processing conditions. AI applications in MR systems range from estimating shear stress, viscosity, and storage/loss moduli to analyzing nonlinear hysteresis, magnetostriction, and mixed-mode loading behavior. These data-driven approaches offer powerful new capabilities for material design and performance optimization, helping overcome long-standing limitations in conventional modeling techniques. Despite significant progress in MR foams, several challenges remain to be addressed, including achieving uniform particle dispersion, enhancing viscoelastic performance (storage modulus and MR effect), and improving durability under cyclic loading. Addressing these issues is essential for unlocking the full potential of MR foams in demanding applications where consistent performance, mechanical reliability, and long-term stability are crucial for safety, effectiveness, and operational longevity. By bridging experimental methods, theoretical modeling, and AI-driven design, this work identifies pathways toward enhancing the functionality and reliability of MR foams for applications in vibration damping, energy harvesting, biomedical devices, and soft robotics. Full article

Magnetorheological elastomers (MREs) are smart composite materials with tunable mechanical properties by ferromagnetic particle interactions. This study applied the microstructure-based dipole and Maxwell methods to evaluate the magneto-mechanical coupling and magnetostrictive responses of MREs, focusing on various particle distributions. The finite element modeling of representative volume elements with fixed volume fractions revealed that the straight chain microstructure exhibits the most significant magnetostrictive effect due to its low initial shear stiffness and significant magnetic force contributions. For particle separations exceeding three radii, the dipole and Maxwell methods yield consistent results for vertically or horizontally aligned particles. For particle separations greater than three radii, the dipole and Maxwell methods produce consistent results for vertically and horizontally aligned particles. However, discrepancies emerge for angled configurations and complex microstructures, with the largest deviation observed in the hexagonal particle distribution, where the two methods differ by approximately 27%. These findings highlight the importance of selecting appropriate modeling methods for optimizing MRE performance. Since anisotropic MREs with straight-chain alignments are the most widely used, our results confirm that the dipole method offers an efficient alternative to the Maxwell method for simulating these structures. Full article

Magnetic hydrogel soft robots have shown great potential in various fields. However, their contact dynamic behaviors are complex, considering stick–slip motion at the contact interface, and lack accurate computational models to analyze them. This paper improves the numerical computational method for hydrogel materials with magneto-mechanical coupling effect, analyses the inchworm-like contact motion of the biomimetic bipedal magnetic hydrogel soft robot, and designs and optimizes the robot’s structure. In the constitutive model, a correction factor representing the influence of the direction of magnetic flux density on the domain density has been introduced. The magnetic part of the Helmholtz free energy has been redefined as the magnetic potential energy, which can be used to explain the phenomenon that the material will still deform when the magnetic flux density is parallel to the external magnetic field. The accuracy of the simulation is verified by comparing numerical solutions with experimental results for a magnetic hydrogel cantilever beam. Furthermore, employing the present methods, the locomotion of a magnetic hydrogel soft robot modeled after the inchworm’s gait is simulated, and the influence of the coefficient of friction on its movement is discussed. The numerical results clearly display the control effect of the external magnetic field on the robot’s motion. Full article

A numerical tool for simulating the detection signals of electromagnetic nondestructive testing technology (ENDT) is of great significance for studying detection mechanisms and improving detection efficiency. However, the quantitative analysis methods for ENDT have not yet been sufficiently studied due to the absence of an effective constitutive model. This paper proposed a new magneto–mechanical model that can reflect the dependence of relative permeability on elasto–plastic deformation and proposed a finite element–infinite element coupling method that can replace the traditional finite element truncation boundary. The validity of the finite element–infinite element coupling method is verified by the experimental result of testing electromagnetic analysis methods using TEAM Problem 7. Then, the reliability and accuracy of the proposed model are verified by comparing the simulation results under elasto–plastic deformation with experimental results. This paper also investigates the effect of elasto–plastic deformation on the transient magnetic flux signal, a quantitative hyperbolic tangent model between Bz_pp (peak–peak value of the normal component of magnetic flux signal) and elastic stress, and the exponential function relationship between Bz_pp and plastic deformation is established. In addition, the difference and mechanism of a magnetic flux signal under elasto–plastic deformations are analyzed. The results reveal that the variation of the transient magnetic flux signal is mainly due to domain wall pinning, which is significantly affected by elasto–plastic deformation. The results of this paper are important for improving the accuracy of quantitative ENDT for elasto–plastic deformation. Full article

It is very important to carry out effective safety inspections on suppression rigging because of the bad service environment of suppression rigging: marine environments. In this paper, the multi-parameter simulation method in ANSYS and ANSYS Electronics Suite simulation software is used to simulate the effect of geomagnetic fields on the magnetic induction intensity of defective pressed rigging under the variable stress in marine environments. The results of the ANSYS simulation and geomagnetic flaw detection equipment are verified. The simulation results show that, according to the multi-parameter simulation results of ANSYS and ANSYS Electronics Suite simulation software, it can be found that, under the action of transverse force, the internal stress of the pressed rigging will affect the magnetic field around pressed rigging with defects. With an increase in internal stress in the range of 0~20 MPa, the magnetic induction intensity increases to 0.55 A/m, and with an increase in internal stress in the range of 20~150 MPa, the magnetic induction intensity decreases to 0.06 A/m. From the use of a force magnetic coupling analysis method, it can be obtained, under the lateral force of the defects in suppressing rigging, that magnetic flux leakage signals decrease with an increase in the rigging’s radial distance. The experiment results show that the difference between the peak and trough of the magnetic induction intensity at the pressed rigging defect calculated by the ANSYS simulation is very consistent with the results measured by the geomagnetic flaw detection equipment. Full article

The resonant magnetoelectric (ME) effect of Fe₇₈Si₉B₁₃/Pb(Zr,Ti)O₃ (FeSiB/PZT) composites with a surface-modified Fe₇₈Si₉B₁₃ amorphous alloy has been studied. The surface-modified FeSiB can improve the ME coefficient at the resonant frequency by optimizing the magnetomechancial power conversion efficiency. The maximum ME coefficient of the surface-modified ribbons combined with soft PZT (PZT5) is two-thirds larger than that of the composites with fully amorphous ribbons. Meanwhile, the maximum value of the ME coefficient with surface-modified FeSiB ribbons and hard PZT (PZT8) is one-third higher compared with the fully amorphous composites. In addition, experimental results of magnetomechanical coupling properties of FeSiB/PZT composites with or without piezoelectric layers indicate that the power efficiency of the composites first decreases and then increases with the increase in the number of FeSiB layers. When the surface crystalline FeSiB ribbons are combined with a commercially available hard piezoelectric ceramic plate, the maximum magnetoelectric coupling coefficient of the ME composite reaches 5522 V/(Oe*cm), of which the electromechanical resonant frequency is 23.89 kHz. Full article

Isotropic magnetorheological elastomers (MREs) with hybrid-size particles are proposed to tailor the zero-field elastic modulus and the relative magnetorheological rate. The hyperelastic magneto–mechanical property of MREs with hybrid-size CIPs (carbonyl iron particles) was experimentally investigated under large strain, which showed differential hyperelastic mechanical behavior with different hybrid-size ratios. Quasi-static magneto–mechanical compression tests corresponding to MREs with different hybrid size ratios and mass fractions were performed to analyze the effects of hybrid size ratio, magnetic flux density, and CIP mass fraction on the magneto–mechanical properties. An extended Knowles magneto–mechanical hyperelastic model based on magnetic energy, coupling the magnetic interaction, is proposed to predict the influence of mass fraction, hybrid size ratio, and magnetic flux density on the magneto–mechanical properties of isotropic MRE. Comparing the experimental and predicted results, the proposed model can accurately evaluate the quasi-static compressive magneto–mechanical properties, which show that the predicted mean square deviations of the magneto–mechanical constitutive curves for different mass fractions are all in the range of 0.9–1. The results demonstrate that the proposed hyperelastic magneto–mechanical model, evaluating the magneto–mechanical properties of isotropic MREs with hybrid-size CIPs, has a significant stress–strain relationship. The proposed model is important for the characterization of magneto–mechanical properties of MRE-based smart devices. Full article

The unique magnetic field environment during electromagnetic launch imposes higher requirements on the design and protection of the internal electronic system within the launch load. This low-frequency, Tesla-level extreme magnetic field environment is fundamentally distinct from the Earth’s geomagnetic field. The excessive change rate of magnetic flux can readily induce voltage within the circuit, thus disrupting the normal operation of intelligent microchips. Existing simulation methods primarily focus on the physical environments of rails and armatures, making it challenging to precisely compute the magnetic field environment at the load’s location. In this paper, we propose a computational rail model based on the magneto–mechanical coupling model of a railgun. This model accounts for the dynamic current distribution during the launch process and simulates the magnetic flux density distribution at the load location. To validate the model’s accuracy, three-axis magnetic sensors were placed in front of the armature, and the dynamic magnetic field distribution during the launch process was obtained using the projectile-borne-storage testing method. The results indicate that compared to the previous literature methods, the approach proposed in this paper achieves higher accuracy and is closer to experimental results, providing valuable support for the design and optimization of the launch load. Full article

Understanding the correlation between magnetomechanical coupling factors (k) and damping factors (Q⁻¹) is a key pathway toward enhancing the magnetomechanical power conversion efficiency in laminated magnetoelectric (ME) composites by manipulating the magnetic and mechanical properties of Fe-based amorphous metals through engineering. The k and Q⁻¹ factors of FeSiB amorphous ribbons annealed in air at different temperatures are investigated. It is found that k and Q⁻¹ factors are affected by both magnetic and elastic properties. The magnetic and elastic properties are characterized in terms of the magnetomechanical power efficiency for low-temperature annealing. The k and Q⁻¹ of FeSiB-based epoxied laminates with different stacking numbers show that a −3 dB bandwidth and Young’s modulus are expressed in terms of the magnetomechanical power efficiency for high lamination stacking. Full article

We present the design, simulation, and characterization of a magnetic shape-memory alloy (MSMA) film actuator that transitions from bistable switching to resonant self-actuation when subjected to a stationary heat source. The actuator design comprises two Ni-Mn-Ga films of 10 µm thickness integrated at the front on either side of an elastic cantilever that moves freely between two heatable miniature permanent magnets and, thus, forms a bistable microswitch. Switching between the two states is induced by selectively heating the MSMA films above their Curie temperature Tc. When continuously heating the permanent magnets above Tc, the MSMA film actuator exhibits an oscillatory motion in between the magnets with large oscillation stroke in the frequency range of 50–60 Hz due to resonant self-actuation. A lumped-element model (LEM) is introduced to describe the coupled thermo-magnetic and magneto-mechanical performance of the actuator. We demonstrate that this performance can be used for the thermomagnetic energy generation of low-grade waste heat (T < 150 °C) with a high power output per footprint in the order of 2.3 µW/cm². Full article

Giant magnetostrictive transducer can be widely used in active vibration control, micro-positioning mechanism, energy harvesting system, and ultrasonic machining. Hysteresis and coupling effects are present in transducer behavior. The accurate prediction of output characteristics is critical for a transducer. A dynamic characteristic model of a transducer is proposed, by providing a modeling methodology capable of characterizing the nonlinearities. To attain this objective, the output displacement, acceleration, and force are discussed, the effects of operating conditions on the performance of Terfenol-D are studied, and a magneto-mechanical model for the behavior of transducer is proposed. A prototype of the transducer is fabricated and tested to verify the proposed model. The output displacement, acceleration, and force have been theoretically and experimentally studied at different working conditions. The results show that, the displacement amplitude, acceleration amplitude, and force amplitude are about 49 μm, 1943 m/s², and 20 N. The error between the model and experimental results are 3 μm, 57 m/s², and 0.2 N. Calculation results and experimental results show a good agreement. Full article

This paper presents a methodology to program the weak coupling between magnetic and structural vector fields in an electromagnetic device modeled in two dimensions. The magneto-mechanical coupling phenomenon is present in electromagnetic devices where magnetic forces cause displacements in metallic materials. This work proposes a numerical solution to this problem by applying the 2D finite element method to the governing equations of this coupled multiphysics phenomenon. The well-known formulation yields accurate results; however, it is often not properly integrated into a computer program. This manuscript proposes a flexible and intuitive methodology for the implementation of the complex mathematics involved in this phenomenon into a computer program. The computer code receives the input parameters, discretizes the geometry by generating a 2D finite mesh, solves the resulting equations using the finite element method, and finally exports the results of the magnetic ang mechanical fields. The modeling is performed using an open-source platform for programming the finite element method in the programming language Python, and afterwards, the results are compared against a commercial software as validation of the proposed numerical approach. The novel magneto-mechanical coupling methodology is used to solve an engineering application, namely an electromagnetic actuator. Full article

Fe-based amorphous alloys have advantages of low iron loss and high effective permeability, which are widely used in sensors and actuators. Power efficiency is one of the most important indicators among power conversion applications. We compared the magnetomechancial power conversion factors of metallic glassy ribbons FeCoSiB (Vitrovac 7600) and FeSiB (Metglas 2605SA1). We investigated the crystallization process under different annealing temperatures and tested the magnetomechancial coupling factors (k) and quality factors (Q) by using resonant and anti-resonant methods. We found that the maximum coupling factor of the annealed Vitrovac ribbons was 23% and the figure of merits k²Q was 4–7; however, the maximum coupling factor of the annealed Metglas ribbons was 73% and the maximum value of k²Q was 16. We can observe that the Metglas 2605SA1 ribbons have higher values of the magnetomechanical power efficiency than those of the Vitrovac 7600 ribbons, which means they are better to be used in subsequent research regarding acoustically driven antennas. Full article

A review of the latest theoretical advances in the description of magnetomechanical effects and phenomena observed in magnetoactive elastomers (MAEs), i.e., polymer networks filled with magnetic micro- and/or nanoparticles, under the action of external magnetic fields is presented. Theoretical modeling of magnetomechanical coupling is considered on various spatial scales: from the behavior of individual magnetic particles constrained in an elastic medium to the mechanical properties of an MAE sample as a whole. It is demonstrated how theoretical models enable qualitative and quantitative interpretation of experimental results. The limitations and challenges of current approaches are discussed and some information about the most promising lines of research in this area is provided. The review is aimed at specialists involved in the study of not only the magnetomechanical properties of MAEs, but also a wide range of other physical phenomena occurring in magnetic polymer composites in external magnetic fields. Full article

Within this contribution, a novel benchmark problem for the coupled magneto-mechanical boundary value problem in magneto-active elastomers is presented. Being derived from an experimental analysis of magnetically induced interactions in these materials, the problem under investigation allows us to validate different modeling strategies by means of a simple setup with only a few influencing factors. Here, results of a sharp-interface Lagrangian finite element framework and a diffuse-interface Eulerian approach based on the application of a spectral solver on a fixed grid are compared for the simplified two-dimensional as well as the general three-dimensional case. After influences of different boundary conditions and the sample size are analyzed, the results of both strategies are examined: for the material models under consideration, a good agreement of them is found, while all discrepancies can be ascribed to well-known effects described in the literature. Thus, the benchmark problem can be seen as a basis for future comparisons with both other modeling strategies and more elaborate material models. Full article
