Search Results (33)

As the core component of ultra-precision machine tools, the manufacturing errors of aerostatic spindles are inevitable due to the limitations of machining and assembly processes, and these errors significantly affect the spindle’s static and dynamic performance. To address this issue, a force model of the unbalanced air film, considering the straightness errors of the rotor’s radial and thrust surfaces, was constructed. Unlike conventional studies that rely solely on idealized error assumptions, this research integrates actual straightness measurement data into the simulation process, enabling a more realistic and precise prediction of bearing performance. Rotors with different tolerance specifications were fabricated, and static performance simulations were carried out based on the measured geometry data. An experimental setup was built to evaluate the performance of the aerostatic spindle assembled with these rotors. The experimental results were compared with the simulation outcomes, confirming the validity of the proposed model. To further quantify the influence of straightness errors on the static characteristics of aerostatic spindles, ideal functions were used to define representative manufacturing error profiles. The results show that a barrel-shaped error on the radial bearing surface can cause a load capacity variation of up to 46.6%, and its positive effect on air film load capacity is more significant than that of taper or drum shapes. For the thrust bearing surface, a concave-shaped error can lead to a load capacity variation of up to 13.4%, and its enhancement effect is superior to those of the two taper and convex-shaped errors. The results demonstrate that the straightness errors on the radial and thrust bearing surfaces are key factors affecting the radial and axial load capacities of the spindle. Full article

The spindle is a critical component that significantly influences the performance of machine tools. In motorized spindles, heat generation from both the bearings and built-in motor leads to thermal deformation of structural components, which, in turn, affects machining accuracy. This study investigates the thermo-mechanical behavior of motorized spindles under various operational conditions, with the aim of accurately predicting thermally induced axial deformation and determining optimal temperature sensor placement. To achieve this, temperature rise and deformation data were simultaneously collected using appropriate data acquisition systems across varying spindle speeds. A correlation analysis confirmed a strong positive relationship exceeding 97.5% between temperature rise at all sensor locations and axial thermal deformation. Multivariate regression analysis was then applied to identify optimal combinations of sensor data for accurate deformation prediction. Additionally, a finite element (FE) thermal–mechanical model was developed to simulate spindle behavior, with the results validated against experimental measurements and regression model predictions. The four-variable regression model and FE simulation achieved Root Mean Square Errors (RMSEs) of 0.84 µm and 0.82 µm, respectively, both demonstrating close agreement with experimental data and effectively capturing the trend of thermal deformation over time under different operating conditions. Finally, an optimal sensor configuration was identified that minimizes pre-diction error while reducing the number of required sensors. Overall, the proposed methodology offers valuable insights for optimizing spindle design to enhance thermal–mechanical performance. Full article

This work introduces an end-to-end methodology, from data gathering to fault notification, for the predictive maintenance of rotary components of machine tools. This is done through fingerprint routines; that is, processes that are executed periodically under the same no-load conditions to obtain a snapshot of the machine condition. High-frequency vibration data gathered during these routines combined with knowledge about the machine structure and its components are used to obtain failure-specific features. These features are then introduced to an anomaly and paradigm shifts detection algorithm. The method is evaluated through three distinct scenarios. First, we use synthetically generated data to test its ability to detect controlled variations and edge cases. Second, we use with publicly available data obtained from bearing run-to-failure tests under normal load conditions on a specially designed test rig. Finally, the methodology is validated using real-world data collected from a spindle bearing installed in a machine tool. The novelty of this work lies in performing anomaly detection using failure-specific features derived from fingerprint routines, ensuring stability over time and enabling precise identification of machine conditions with minimal data requirements. Full article

Machine tool vibrations play a significant role in hindering productivity during machining. The growing vibrations accelerate tool wear and chipping, cause a poor wave surface finish, and may damage the spindle bearing. Some research showed that tribological properties such as friction factors can have obvious influences on the topography of rough surfaces and the nonlinear dynamic characteristics of machine tool systems. Therefore, studying the vibration friction dynamic characteristics on the normal contact stiffness (NCS) of joints of CNC machine tools is absolutely necessary for improving the machining accuracy and precision of the whole system. The study results of NCS of joints of the CNC and the friction coefficient are discussed in this paper. The model of NCS based on fractal parameters was obtained. The models of deformations of the rough surfaces and contact surfaces were deduced. The results showed that the NCS based on the calculation method considering the elastic–plastic deformation of the asperity is much higher in precision than the methods considering only elastic or plastic deformation separately. The observations this paper described suggest that in the CNC machine tools system, higher D and G and higher friction coefficients lead to higher normal contact stresses (NCSs). Full article

In response to the challenge of timely fault identification in the spindle bearings of machine tools operating in complex environments, this study proposes a method based on a combination of infrared imaging with an Informer and a CNN + Swin Transformer. The aim is to achieve real-time monitoring of bearing faults, precise fault localization, and classification of fault severity. To accomplish this, an angular contact ball bearing was chosen as the research subject. Initially, an infrared image dataset was constructed, encompassing various fault positions and degrees, by simulating different forms of bearing faults. Subsequently, an Informer-based bearing temperature prediction model was established to select faulty bearing data. Lastly, the faulty data were input into the CNN + Swin Transformer model for bearing fault recognition and classification. The results demonstrate that the Informer model accurately identifies abnormal temperature rises during bearing operation, effectively screening out faulty bearings. Under steady-state conditions, the model achieves a classification accuracy of 97.8%. Furthermore, after employing the Informer screening process, the proposed model exhibits a recognition precision of 98.9%, surpassing other models such as CNN, SVM, and Swin Transformer, which are mentioned in this paper. Full article

The spindle tool is an important module of the machine tool. Its dynamic characteristics directly affect the machining performance, but it could also be affected by thermal deformation and bearing preload. However, it is difficult to detect the change in the bearing preload through sensory instruments. Therefore, this study aimed to establish a digital thermal–mechanical model to investigate the thermal-induced effects on the spindle tool system. The technologies involved include the following: Run-in experiments of the milling spindle at different speeds, the establishment of the thermal–mechanical model, identification of the thermal parameters, and prediction of the thermal-induced preload of bearings in the spindle. The speed-dependent thermal parameters were identified from thermal analysis through comparisons with transient temperature history, which were further used to model the thermal effects on the bearing preload and dynamic compliance of the milling spindle under different operating speeds. Current results of thermal–mechanical analysis also indicate that the internal temperature of the bearing can reach 40 °C, and the thermal elongation of the spindle tool is about 27 µm. At the steady state temperature of 15,000 rpm, the bearing preload is reduced by 40%, which yields a decrease in the bearing rigidity by approximately 16%. This, in turn, increases the dynamic compliance of the spindle tool by 22%. Comparisons of the experimental measurements and modeling data show that the variation in bearing preload substantially affects the modal frequency and stiffness of the spindle. These findings demonstrated that the proposed digital spindle model accurately mirrors real spindle characteristics, offering a foundation for monitoring performance changes and refining design, especially in bearing configuration and cooling systems. Full article

In this work, a modified numerical algorithm that couples the quasi-static theory with the mixed thermal elastohydrodynamic lubrication (mixed-TEHL) model is proposed to examine the mechanical properties and lubrication performance of the spindle bearing that is used in a high-speed machine tool with spinning. The non-Newtonian fluid characteristics of the lubricant and the non-Gaussian surface roughness are also considered. Moreover, the mechanical properties and lubrication state of the bearing are examined in various service environments. The results indicate that the temperature reduces the lubrication efficiency, which in turn exerts a significant impact on the mechanical properties. The lubrication that either behaves in the manner of Newtonian or non-Newtonian fluid has a relatively negligible influence on the bearing working state, while the non-Gaussian surface roughness significantly alters the oil film thickness and temperature. Calculations with different operating conditions demonstrate that the operating parameters (i.e., axial load, rotation speed) will directly affect the performance of the bearings via the changes in the oil film thickness and the temperature. Full article

Ceramic-copper substrates, as high-power, load-bearing components, are widely used in new energy vehicles, electric locomotives, high-energy lasers, integrated circuits, and other fields. The service length will depend on the substrate’s copper-coated surface quality, which frequently achieved by utilising an abrasive strip polishing procedure on the substrate’s copper-coated surface. Precision diamond fly-cutting processing machine tools were made because of the low processing accuracy and inability to match the production line’s efficiency. An analysis of the fly-cutting machining principle and the structural makeup of the ceramic-copper substrate is the first step in creating a roughness prediction model based on a tool tip trajectory. This model demonstrates that a shift in the tool tip trajectory due to spindle runout error directly impacts the machined surface’s roughness. The device’s structural optimisation design is derived from the above analyses and implemented using finite element software. Modal and harmonic response analysis validated the machine’s gantry symmetrical structural layout, a parametric variable optimisation design optimised the machine tool’s overall dimensions, and simulation validated the fly-cutterring’s constituent parts. Enhancing the machine tool’s stability and motion accuracy requires using the LK-G5000 laser sensor to measure the guideway’s straightness. The result verified the machine tool’s design index, with the Z- and Y-axes’ straightness being better than 2.42 $\mathsf{\mu }$m$/800$ mm and 2.32 $\mathsf{\mu }$m$/200$ mm, respectively. Ultimately, the device’s machining accuracy was confirmed. Experiments with flying-cut machining on a 190 × 140 mm ceramic-copper substrate yielded a roughness of Sa9.058 nm. According to the experimental results, the developed machine tool can fulfil the design specifications. Full article

This study addressed the issues related to the difficulty of determining the operating status of machine tool spindle bearings due to the high rotational speeds and rapid temperature fluctuations. This paper presents an optimized model that combines Convolutional Neural Networks (CNNs) and Informer to dynamically predict the temperature rise process of bearings. Taking the H7006C angular contact ball bearing as the research object, a combination of experimental data and simulations was used to obtain the training dataset. Next, a model for predicting the temperature rise of the bearing was constructed using CNN + Informer and the structural parameters were optimized. Finally, the model’s generalization ability was then verified by predicting the bearing temperature rise process under various working conditions. The results show that the error of the simulation data source model was less than 1 °C at steady state; the temperature error of the bearing temperature rise prediction model was less than 0.5 °C at both the temperature rise and steady-state stages under variable rotational speeds and variable load conditions compared to Informer and Long Short Term Memory (LSTM) models; the maximum prediction error of the operating conditions outside the dataset was less than 0.5 °C, and the temperature rise prediction model has a high accuracy, robustness, and generalization capability. Full article

In this paper, the tool-tip responses for ball end milling, due to the coupling effects of a flexible rotor-bearing system, are investigated numerically. The milling machine tool spindle is modelled as the flexible rotor-bearing system. The critical speeds, natural modes, and unbalance responses of the system are calculated by applying the generalized polynomial expansion method. This generalized polynomial expansion method expresses the displacement as a series formed by the product of generalized coordinates and axial coordinate polynomials. According to the dynamic cutting force obtained by some scholars in the past, combined with the characteristics of the flexible rotor, the dynamic response of the tool-tip for ball end milling is numerically analyzed. The responses, including time histories, orbits, and FFT diagrams, are plotted to analyze the dynamic behaviors of the tool-tip. The coupling effects of the flexible rotor-bearing system on the system for ball end milling are first studied using the generalized polynomial expansion method. Unlike previous studies, the natural frequency varies with spindle speed and which of the different modes are included in the tool-tip response depends mainly on the spindle speed. Thanks to the gyroscopic effect, the critical speeds and responses of tool-tips can be discussed with respect to various spindle speed and tool flutes. The natural modes are accurately determined, and will excite critical speeds for certain modes, including forward and backward modes, thereby significantly affecting tool-tip response. In addition, the cutting force component associated with the tool-tip response affects the rotor-bearing system parameters, complicating the issue. Milling at higher spindle speed (2160–19,950 rpm), an important new result is found that the tool-tip oscillates with the cutting-force frequency, accompanied by a longer period vibration of the first backward mode of the rotor-bearing system. It can also be seen from the frequency spectrum analysis that, as the spindle speed increases, the peak amplitude of the first backward mode becomes larger. Milling at lower spindle speed (960, 1320 rpm), the in-plane vibration trajectory of the tool-tip gradually expands outwards clockwise around the origin until a stable loop is reached. This is because only the first backward mode of the rotor-bearing system is excited. Considering the coupling effect of the rotor-bearing system to perform the vibration analysis of the milling machine system, the parameters of the system can be designed or the spindle speed can be selected to avoid severe vibration during machining. Full article

Friction losses are an important parameter for evaluating the operational behaviour of high-speed rolling bearings. Specifically, in machine tool applications, the bearings are subjected to high radial loads and high speeds, which lead to increased forces in the rolling contact and, as a result, increased bearing friction. In this high-speed application, hybrid spindle bearings, typically made of ceramic balls and steel raceways, show better frictional behaviour compared to full steel-made bearings. Therefore, precise knowledge of the friction characteristics of high-speed hybrid bearings can improve friction models and generalise them to spindle bearings with different types, geometries, and operating conditions. In this article, a new straightforward and cost-efficient method for measuring the frictional torque in spindle bearings is presented. A rigidly arranged 7008 hybrid spindle bearing pair was tested up to rotational speeds of 24,000 rpm and high radial loads of 3 kN. The effects of oil–air and grease lubrication are discussed in characteristic diagrams of the tested bearings. Then, based on the test results, a friction calculation model is presented and validated for the outer race control and minimised power dissipation regarding the influence of radial forces. Full article

Misalignment or unbalanced loading of machine tool spindle bearings often results in skewed bearing operation, which makes the spindle more susceptible to failure. In addition, due to the weak impact signal of the bearing in skewed operation, a single feature information cannot accurately characterize the operation status of the bearing. To address the above problems, this paper proposes a method to monitor the uneven running state of bearing load based on a dual-channel fusion improved dense connection (DenseNet) network. First, the original signal is pre-processed by overlapping sampling method, and the dual-channel experimental data are obtained by frequency-domain and time-frequency-domain algorithms; then the processed data are input into the improved 1D-DenseNet and 2D-DenseNet models respectively for feature extraction; then the frequency-domain and time-frequency-domain features are fused by concat splicing operation, and the output belongs to each category The probability distribution is used to characterize the operating state of the bearings. Finally, the validity of the algorithm model is verified by using the Case Western Reserve University public rolling bearing data set, and an experimental bench is designed and built for experimental verification of the uneven bearing load operation. The comparative analysis of the experimental results in this paper shows that the algorithm can extract the features of the input signal more comprehensively and finally achieve 100% recognition accuracy. Full article

Real-time condition monitoring and fault diagnosis of spindle bearings are critical to the normal operation of the matching machine tool. In this work, considering the interference of random factors, the uncertainty of the vibration performance maintaining reliability (VPMR) is introduced for machine tool spindle bearings (MTSB). The maximum entropy method and Poisson counting principle are combined to solve the variation probability, so as to accurately characterize the degradation process of the optimal vibration performance state (OVPS) for MTSB. The dynamic mean uncertainty calculated using the least-squares method by polynomial fitting, fused into the grey bootstrap maximum entropy method, is utilized to evaluate the random fluctuation state of OVPS. Then, the VPMR is calculated, which is used to dynamically evaluate the failure degree of accuracy for MTSB. The results show that the maximum relative errors between the estimated true value and the actual value of the VPMR are 6.55% and 9.91%, and appropriate remedial measures should be taken before 6773 min and 5134 min for the MTSB in Case 1 and Case 2, respectively, so as to avoid serious safety accidents that are caused by the failure of OVPS. Full article

Spindles are key components of machine tools. An efficient estimation of the spindle condition and its prognosis can improve production efficiency and quality due to predictive maintenance planning. This paper proposes a method for predicting the remaining useful life (RUL) of machine tool spindle bearings using a combined calculation and experimental approach. The calculation model based on the ISO 281 standard uses monitored real loading conditions caused by the machining process and the machine tool operation. The model enables the updated calculation of the spindle lifetime L_10h using real load distribution. Since the operation hours of the spindle are also monitored, the remaining useful life (RUL) of the spindle can be calculated. This RUL value is corrected using a bearing condition assessment based on the effective value of the vibration velocity RMS according to the ISO 20816 standard and measured data from the machine tool control system. The proposed method is tested on two different spindle types featuring three pieces of every type. The experimental results of six spindles are compared and validated with a concurrent blind evaluation conducted by a skilled expert. The validation shows a very good match of the proposed method and the expert opinion. The method combining a calculation of the spindle lifetime using monitored real load distribution and subsequent result correction using vibration signal enables the implementation of a full automated estimation of the spindle RUL. Full article

Precision spindle and bearings are the key components in precision machine tools. These structures greatly affect the machining accuracy and service life of the machine tools. In this paper, considering the uncertainty of rolling elements when the bearings are working at high speed, a new 2D equivalent simulation model of angular contact ball bearing was established based on the general finite element software, Abaqus. Meanwhile, the equivalent material parameters of virtual bearing ball in this 2D model were obtained via a standard bearing stiffness test and a parametric inversed method. The time to calculate of this model is reduced by 200 times compared with the 3D bearing simulation model. Then, the 2D equivalent simulation model of the spindle was established based on the 2D bearing model, which is used to calculate the axial stiffness and maximum contact stress between bearing balls and inner/outer rings in different assembly parameters. The results show that the stiffness of the spindle increases slowly at first, but then increases rapidly to a peak value after the bearing inner spacer sleeve is in contact with the bearing inner ring, and finally tends to stable, with the preload of the spindle continuing to increase. Full article
