Search Results (89)

This study presents a numerical investigation of the internal flow characteristics within the draft tube of a Kaplan turbine using computational fluid dynamics (CFD). The distribution and evolution of vortical structures, particularly the formation and development of vortex ropes under various operating conditions, are systematically analyzed. The study aims to explore the effects of blade angle and guide vane opening on the internal flow characteristics of the unit, thereby providing guidance for flow control strategies. The influence of guide vane opening and turbine head on vortex dynamics and flow stability is examined, with a focus on the pressure pulsations induced by vortex ropes through frequency-domain analysis. The results indicate that increased guide vane openings and higher heads lead to the expansion and downstream extension of the vortex rope into the elbow section, causing significant low-frequency pressure pulsations and enhancing flow instability. These findings contribute to a deeper understanding of unsteady flow behavior in Kaplan turbine draft tubes and provide a theoretical foundation for improving hydraulic stability and optimizing operational performance. Full article

In the Amazon, nearly one million people remain without reliable access to electricity. Moreover, the rural electricity grid is a mostly single-phase, ground-return type, with poor energy quality and high expenses. This study examines very low-head micro-hydropower (MHP) sites in the Amazon, emphasizing the integration of multiple axial-flow turbines. It includes an analysis of flow duration curves and key curves, both upstream and downstream, to design an MHP plant with multiple units targeting maximized energy yield. The presence of multiple turbines is crucial due to the substantial annual flow variation in the Amazon rivers. One contribution of this work is its scalable framework for ultra-low-head and high flow variability in small rivers, which is applicable in similar hydrological configurations, such as those typical of the Amazon. The design applies the minimum pressure coefficient criterion to increase turbine efficiency. Computational Fluid Dynamics (CFD) simulations forecast turbine efficiency and flow behavior. The CFD model is validated using experimental data available in the literature on a similar turbine, which is similarly used in this study for cost reasons, with discrepancies under 5%, demonstrating robust predictions of turbine efficiency and head behavior as a function of flow. This study also explores the implications of including inlet guide vanes (IGVs). We use a case study of a small bridge in Vila do Janari, situated in the southeastern part of Pará state, where heads range from 1.4 to 2.4 m and turbine flow rates span from 0.23 to 0.92 m³/s. The optimal configuration shows the potential to generate 63 MWh/year. Full article

Under extremely low-head conditions, the performance and stability of pump-turbine units are strongly influenced by the flow distortion caused by variations in guide vane opening. In this study, a pump-turbine model—representative of a domestic pumped storage power station—was investigated through a combination of experimental observations and three-dimensional unsteady numerical simulations employing the SST k-ω turbulence model. The analysis focused on characterizing the variations in turbulence kinetic energy, pressure pulsations, and impeller force fluctuations as the guide vane opening was altered. The results reveal that, with increasing guide vane opening, the turbulence kinetic energy within the impeller region is notably reduced. This reduction is primarily attributed to a decrease in energy losses along the suction surfaces of the blades and within the straight pipe section of the tailwater tunnel. Simultaneously, pressure pulsations were detected at multiple locations including the volute inlet, the blade-free zone, downstream of the conical pipe, and along the inner surface of the shaft tube. While most regions experienced a decline in pressure pulsation intensity with larger openings, the bladeless zone exhibited a significant increase. Moreover, force analysis at four distinct guide vane settings indicated that an opening of 41 mm resulted in relatively uniform fluctuations in the impeller forces. This uniformity suggests that an optimal guide vane configuration exists, which minimizes uneven stress distributions and enhances the operational stability of the pump-turbine under extremely low-head conditions. These findings offer valuable insights for the design and operational optimization of pump-turbine systems in pumped storage power stations. Full article

Aiming at the problems of inaccurate feature extraction, slow convergence, and low diagnostic accuracy of wind turbine misalignment fault diagnosis under complex working conditions, this paper proposes an innovative diagnostic method based on two channels of U-Net and ResNet50. The model innovatively introduces the multi-head attention mechanism (MHA) in the jump connection of the U-Net architecture to form hybrid U-Net and optimizes the feature fusion process with dynamically learnable weights, which significantly enhances the ability to capture local details and key fault features. In the ResNet50 branch, deep global features are fully mined for extraction. To further achieve the co-optimization of global and local information, a shared hybrid expert attention (SHEA) module is proposed. This module achieves efficient integration of features by adaptively fusing the multi-scale local features output from the hybrid U-Net decoder with the deep global features extracted from the ResNet50 backbone network through a dynamic weighting and expert selection mechanism. The multi-scale features optimized by the SHEA module are fed into the classifier for fault type determination. The experimental results show that the method demonstrates excellent convergence speed and 99.64% classification accuracy under complex working conditions, providing an effective solution for the intelligent diagnosis of wind turbine misalignment faults. Full article

The global need for balance between energy generated from intermittent renewable sources and the actual demand has introduced severe operational challenges on hydropower, a steady energy source in the current context. Although it has some flexibility in operation by varying flow, head, and speed, the entirety of its operational range must be optimized to be more effective. The non-optimal conditions caused by these operational changes result in flow separation on runner blades that results in low efficiency and can be mitigated with the use of vortex generators. The vortex generators can be designed with the empirical method based on the boundary layer height, and the estimated boundary layer height for the Francis turbine runner blade in this study is 2.5 mm. The selected height of the counter-rotating rectangular vortex generators is 5 mm, and two pairs are attached close to the leading edge of the runner blade on the pressure side. The experimental analysis of the runner is conducted at all operating ranges, and efficiency is compared with the reference case. The reliable increment in efficiency obtained is 0.40% ± 0.22%, measured at a GV opening of 13 degrees (full load) and a reference speed of (333 rpm). Similarly, at the same GV opening, the increment in efficiency is obtained at a high speed (408 rpm) with a value of 1.20% ± 0.40%. However, the efficiency increment at part load and the BEP is not as significant since the values lie within the uncertainty band. Thus, these simple passive devices can be employed, and the streamwise vortices generated can be utilized to reduce the impact of flow separation on the Francis runner blades. Full article

With the development of a power system predominantly reliant on new energy sources, turbine generator sets are increasingly required to operate under wide load conditions, resulting in numerous unstable flow phenomena and substantial economic losses for power stations. This study employs the Shear Stress Transport (SST) k-ω turbulence model to combine numerical simulations with experimental methods. It calculates the guide vane opening at the rated head of a Francis turbine and examines the internal flow field characteristics and pressure pulsations under various operating conditions. The findings indicate that the entropy production ratio in the draft tube is the highest among all load conditions, ranging from about 72.7% to 95.9%. Energy dissipation in the vaneless zone and the runner increases with greater opening. At 45% and 100% load conditions, the draft tube is mainly influenced by dynamic and static interference, single and double frequencies induced by runner rotation, and low-frequency fluctuations of the vortex and. Under 60% load conditions, pressure fluctuations in the draft tube are primarily caused by the eccentric vortex band, characterized by higher intensity and a frequency of 0.2 f_n. Numerical results closely align with experimental observations. The findings provide essential guidance for ensuring the stable operation of power plant units. Full article

Cross-flow turbines are widely used in microhydropower systems because of their cost-effectiveness, environmental sustainability, adaptability, and robust design. However, their relatively lower efficiency than other turbine types limit their application in large-scale projects. Previous studies have identified poor flow profiles as a significant factor contributing to inefficiency, with the number of blades playing a critical role in the flow behavior, efficiency, and structural stability. This study employed numerical simulations to analyze how varying the number of blades affects the internal flow characteristics and performance of the turbine at, and off, its best operating points. Configurations with 16, 20, 24, 28, 32, 36, 40, and 44 blades were investigated under constant low-head conditions, fully open valve settings, and varying runner speeds. Simulations were performed using ANSYS CFX, incorporating steady-state conditions, a two-phase flow model with a movable free surface, and a shear stress turbulence model. The results indicate that the 28-blade configuration achieved a maximum hydraulic efficiency of 83%, outperforming the preset 24-blade setup by 6%. Flow profiles were examined using pressure and velocity gradients to identify regions of adverse pressure. Due to the impulse nature of the turbine, the flow profile is more sensitive to changes in the flow speed than to pressure. The flow trajectory showed stability in the first stage but exhibited discrepancies in the second stage, which were attributed to turbulence, recirculation, and shaft flow impingement. The observed performance improvements were linked to reduced hydraulic losses due to flow separation and friction, emphasizing the significance of the number of blades and the regions of optimal efficiency under low-head conditions. Full article

With the requirement of flexible operation of hydraulic turbine units, Francis turbine units have to adjust their output into extended operating ranges in order to match the demand of the power grid, which leads to more off-design conditions. In off-design conditions, hydraulic excitation causes excessive stress, pressure pulsation, and vibration on the machines. Different designs of Francis turbines cause different hydraulic excitations and vibrational behaviors. To conduct better condition monitoring and fault prognosis, it is of paramount importance to understand the vibrational behavior of a machine. In order to reveal the influence factors of the vibration behavior of Francie turbine units, field tests have been conducted on two similar-designed Francis turbine units and vibration features have been compared in this research. The vibrational behavior of two Francis turbine units installed in the same power station is compared under extended operating condition. Field tests have been performed on the two researched units and the vibration has been compared using the spectrum analysis method. The vibration indicators are extracted from the test data and the variation rules have been compared. By comparing the vibration behavior of the two machines, the design and installation difference of the two machines have been analyzed. This research reveals the effects of different designs and installations of Francis turbines on the vibration performance of the prototype units. The obtained results give guidance to the designers and operators of Francis turbine units. Full article

The Pelton turbine is an ideal choice for developing high-head hydropower resources. However, its cantilever-beam structure exposes the runner to intense alternating loads from high-velocity jets, causing localized high stresses, structural vibrations, and potential bucket fractures, all of which compromise safe operation. This study employs fluid–structure interaction analysis for the numerical investigation of a six-nozzle Pelton turbine to examine its unstable flow characteristics and hydrodynamic excitation under high-velocity jets. Our findings indicate that low-order frequencies primarily induce overall runner oscillations, while high-order frequencies result in oscillation, torsional displacement, and localized vibrations. Torsional displacement at the free end of the bucket induces stress concentrations at the root of the bucket and the splitter, the outflow edge, and the cut-out. The amplitudes of stress and displacement are correlated with the nozzle opening, with displacement typically in phase with torque, while stress fluctuations exhibit a phase lag. The stress and displacement values are higher on the bucket’s front, with maximum stress occurring at the bucket root and maximum displacement at the outflow edge, particularly in regions subjected to prolonged jet impact. The dominant frequency of the stress pulsations matches the number of nozzles. This study elucidates the dynamic response of Pelton turbines under high-velocity jets, correlating fluid load with runner dynamics, identifying maximum stress and deformation points, and providing technical support for performance evaluation. Full article

To investigate the hydraulic characteristics during the start-up process of a full-flow pumped storage unit under low-head conditions, numerical simulations were conducted to study the dynamic characteristics during the process, providing a detailed analysis of the dynamic behavior of the internal flow field during the transition period as well as the associated variation in external performance parameters. Study results revealed a vortex-shedding phenomenon during the initial phase of the start-up process. These vortices restrict the flow, initiating a water hammer effect that abruptly elevates the upstream pressure within the runner. As the high-pressure water hammer dissipated, the flow rate rapidly increased, leading to a secondary but relatively weaker water hammer effect, which caused a momentary drop in pressure. This series of events ultimately resulted in significant oscillations in the unit’s head. After the guide vanes stop opening, the vortex structures at the runner inlet and outlet gradually weaken. As the runner torque continues to decline, the unit gradually approaches a no-load condition and enters the S-shaped region. Concurrently, pressure pulsations intensify, and unstable vortex formations reemerge along the leading and trailing edges of the runner blades. The escalated flow velocity at the runner’s exit contributes to the elongation of the vortex band within the draft tube, ultimately configuring a double-layer vortex structure around the central region and the pipe walls. This configuration of vortices precipitates the no-load instability phenomenon experienced by the unit. Full article

The water flow within the turbine passage of a hydropower station exhibits high-speed closed-pressure flow. The flow field characteristics will directly affect the turbine’s operational efficiency and safety. To ensure the safe operation of the turbine and accurately monitor its flow state, the relationship between the flow characteristics in the turbine passage and its discharge noise must be established. In this study, the relationship between the flow field and the noise field of the turbine is explored using a combination of a model turbine passage discharge noise test and numerical simulation of flow field characteristics. Results show that the operating parameters are closely related to the discharge noise’s characteristics, in which the operating head and discharge of the unit’s operating parameters greatly influence the discharge noise in the flow passage. Hydrodynamic factors, such as fluctuation pressure and pressure in the flow field, show a strong correlation with the discharge noise characteristics. As the pressure and fluctuation pressure in the inlet area of the spiral case intensify, the sound pressure level (SPL) of the discharge noise increases and the main frequency decreases. A large-scale vortex easily forms in the spiral case and draft tube area, thereby causing low-frequency fluctuation and forming high-decibel noise. Also, the runner area is the main sound source region of the turbine passage. The research results will provide technical and theoretical support for the safe operation and accurate fault diagnosis of hydropower stations. Full article

The vibration of large Kaplan turbines has always been one of the key research issues of turbines. Affected by the load and head of the power station, the Kaplan turbine will operate under medium and low heads, and the components will vibrate violently, seriously threatening the stable operation of the unit. Compared with other types of turbines, the runner structure of the Kaplan turbine is more complex. Therefore, in addition to the fixed components, the dynamic response characteristics of the rotating components are also be the focus of this study. In this paper, four operating points under high, medium and low heads are selected. The unsteady flow field and fluid–structure interaction are calculated. The modal and dynamic stress characteristics of the fixed components (bottom ring, head cover and support cover) and the rotating components (blades, runner body and main shaft) are analyzed. The results show that the location of the stress concentration of fixed components under low heads changes significantly, and the stress fluctuates greatly due to the influence of the stay vanes. The rotating components are more affected by the rotation of the runner under low heads, and the displacement and stress fluctuations of the rotating structure are significantly greater than those of medium and high heads. The pressure fluctuations in the vaneless area and draft tube cause some low-frequency excitation. The stress fluctuations of rotating components under low heads are much greater than those of the fixed components. This shows that the head has a greater impact on the rotating components, which is more likely to cause damage to the rotating components, seriously threatening the stable operation of the unit. Full article

A variable-speed pump-turbine is the core component of a hydraulic storage and energy generation station. When the pump-turbine operates at a constant speed, its response to the power grid frequency is poor. In order to improve the hydraulic efficiency of the pumped storage unit, variable-speed units are used. However, there has been no numerical study on the effect of the rotational flow characteristics within the gap of a variable-speed pump-turbine. This paper calculates the flow characteristics within the gap of a variable-speed pump-turbine under three typical pump modes (maximum head minimum flow condition, minimum head maximum flow condition, and maximum speed condition). The research results indicate that the rotational speed significantly affects the pressure distribution, velocity distribution, and turbulent kinetic energy distribution within the crown and band gaps. The higher the speed, the larger the area of the high-pressure region before the runner inlet compared to other operating conditions, and similarly, the low-pressure area after the runner outlet is also larger than in other operating conditions. The change in speed mainly affects the internal flow field of the crown gap, with the most noticeable changes occurring in the pressure and flow velocity at the inlet and outlet of the crown gap. There is a clear trend of pressure drop and velocity increase within the gap as the speed increases. However, with the increase in speed, the pressure distribution and flow velocity within the band gap remain almost the same. In addition to speed changes, it is observed that the pressure within the gap and the flow velocity within the passages are also related to the head, especially in the condition of maximum head, where this relationship becomes more noticeable. Full article

With a large-range-operation head, the Francis turbine unit is the most widely used type of hydraulic turbine in the world. The general range of the Francis turbine is 20–700 m. Because of this, the operating stability of the Francis turbine needs to be focused on. In this paper, a multi-dimensional hill chart is applied to a low-head Francis turbine unit to describe its vibration characteristics. Firstly, a field test was conducted on the unit in order to obtain vibration data under different operating conditions. Secondly, the condition indicators were calculated and extracted from the experimental data. Then, the condition indicators under different head values and outputs were fitted to form a multi-dimensional hill chart. In the end, the vibration characteristics of the researched low-head Francis turbine unit were analyzed based on the multi-dimensional hill chart. Full article

Kaplan turbines are widely utilized in low-head and large flow power stations. This paper employs Computational Fluid Dynamics (CFD) to complete numerical calculations of the full flow channel under different blade angles and various guide vane openings, based on 25 off-cam experimental working conditions. The internal flow characteristics of the runner blade and draft tube are analyzed, and a discriminant number for quantitatively assessing the flow uniformity of the draft tube is proposed. The results indicate that low-frequency and high-amplitude pressure pulsations occur on the high- and low-pressure edge of the blade when the opening is small, with pulsations decreasing as the opening increases. The inner flow line of the draft tube is disturbed when both the blade angle and opening are small. Additionally, the secondary frequency of the draft tube inlet is double that of the vane passing frequency. The discriminant number of the flow inhomogeneity approaches 0 under optimal flow conditions. The number increases continuously with the decrease in efficiency, and the flow in the three piers of draft tube becomes more nonuniform. The research results provide a reference for enhancing performance and ensuring the operational stability of Kaplan turbines. Full article
