Search Results (144)

With their superior switching speed, GaN high-electron-mobility transistors (HEMTs) enable high power density, reduce energy losses, and increase power efficiency in a wide range of applications, such as power electronics, due to their high breakdown voltage. GaN-HEMT devices are subject to long-term reliability due to the self-heating effect and lattice mismatch between the SiC substrate and the GaN. Depletion-mode GaN HEMTs are utilized for radio frequency applications, and this work investigates three wide-bandgap (WBG) GaN HEMT fixed-frequency oscillators with output buffers. The first GaN-on-SiC HEMT oscillator consists of an HEMT amplifier with an LC feedback network. With the supply voltage of 0.8 V, the single-ended GaN oscillator can generate a signal at 8.85 GHz, and it also supplies output power of 2.4 dBm with a buffer supply of 3.0 V. At 1 MHz frequency offset from the carrier, the phase noise is −124.8 dBc/Hz, and the figure of merit (FOM) of the oscillator is −199.8 dBc/Hz. After the previous study, the hot-carrier stressed RF performance of the GaN oscillator is studied, and the oscillator was subject to a drain supply of 8 V for a stressing step time equal to 30 min and measured at the supply voltage of 0.8 V after the step operation for performance benchmark. Stress study indicates the power oscillator with buffer is a good structure for a reliable structure by operating the oscillator core at low supply and the buffer at high supply. The second balanced oscillator can generate a differential signal. The feedback filter consists of a left-handed transmission-line LC network by cascading three unit cells. At a 1 MHz frequency offset from the carrier of 3.818 GHz, the phase noise is −131.73 dBc/Hz, and the FOM of the 2nd oscillator is −188.4 dBc/Hz. High supply voltage operation shows phase noise degradation. The third GaN cross-coupled VCO uses 8-shaped inductors. The VCO uses a pair of drain inductors to improve the Q-factor of the LC tank, and it uses 8-shaped inductors for magnetic coupling noise suppression. At the VCO-core supply of 1.3 V and high buffer supply, the FOM at 6.397 GHz is −190.09 dBc/Hz. This work enhances the design techniques for reliable GaN HEMT oscillators and knowledge to design high-performance circuits. Full article

Bipolar power supply can effectively reduce line losses and optimize power transmission. This paper proposes a low-power bipolar DC–DC converter with voltage self-balancing, which not only achieves bipolar output but also automatically balances the inter-pole voltage under load imbalance conditions without requiring additional voltage balancing control. This paper first elaborates on the derivation process of the proposed converter, then analyzes its working principles and performance characteristics. A 400 W experimental prototype is built to validate the correctness of the theoretical analysis and the voltage self-balancing capability. Finally, loss analysis and conclusions are presented. Full article

Detecting defects in transmission line insulators is crucial to prevent power grid failures as power systems continue to expand. This study introduces YOL011n-SSA, an enhanced insulator defect detection technique method that addresses the challenges of effectively identifying flaws in complex environments. First, this study incorporates the StarNet network into the backbone of the model. By stacking multiple layers of star operations, the model reduces both parameter count and model size, improving its adaptability to real-time object detection tasks. Secondly, the SOPN feature pyramid network is introduced into the neck part of the model. By optimizing the multi-scale feature fusion of the richer information obtained after expanding the channel dimension, the detection efficiency for low-resolution images and small objects is improved. Then, the ADown module was adopted to improve the backbone and neck parts of the model. It effectively reduces parameter count and significantly lowers the computational cost by implementing downsampling operations between different layers of the feature map, thereby enhancing the practicality of the model. Meanwhile, by introducing the NWD to improve the evaluation index of the loss function, the detection model’s capability in assessing the similarities among various small-object defects is enhanced. Experimental results were obtained using an expanded dataset based on a public dataset, incorporating three types of insulator defects under complex environmental conditions. The results demonstrate that the YOLO11n-SSA algorithm achieved an mAP@0.5 of 0.919, an mAP@0.5:0.95 of 70.7%, a precision of 0.95, and a recall of 0.875, representing improvements of 3.9%, 5.5%, 2%, and 5.7%, respectively, when compared to the original YOLO1ln method. The detection time per image is 0.0134 s. Compared to other mainstream algorithms, the YOLO11n-SSA algorithm demonstrates superior detection accuracy and real-time performance. Full article

For high-power magnetic resonance imaging (MRI) radio frequency (RF) combiners operating in the frequency range from 60 MHz to 300 MHz, the primary challenges lie in achieving high-power transmission capability while minimizing the insertion loss (IL), reducing the physical dimensions, and meeting application bandwidth requirements. This paper presents a high-performance RF power combiner based on capacitor-loaded microstrip technology for 3.0T MRI radio frequency power amplifier (RFPA) systems. The proposed combiner features low loss, high integration, and miniaturization, and it comprises multiple branches, each employing microstrip lines and capacitors in a series–parallel arrangement to achieve an impedance transformation of 50 Ω to 100 Ω. Each branch was designed through theoretical analysis and electromagnetic simulations to achieve a line length 30% shorter than λ/4, a 6.2 mm line width, and 0.08 dB IL at the 3.0T MRI operation frequency band. A two-way to one-way combiner was further designed using this branch structure to achieve 0.2 dB IL through simulation optimization. A four-way to one-way combiner was then constructed by cascading two-way combiners and optimized via ADS-HFSS software(ADS2014 HFSS19) co-simulation. The fabricated combiner module uses an FR4 substrate and achieves a 0.4 dB insertion loss, −25 dB return loss, and 25 dB port isolation at 128 MHz ± 1 MHz, with compact dimensions (320 × 200 × 10 mm). To ensure high power capability, thermal analysis was performed to confirm that the module’s power-handling capacity exceeded 8 kW, and experimental validation with the 8 kW 3.0T RFPA demonstrated a stable temperature rise of approximately 2 °C. In this study, the innovative single-branch topology and the RF high-power four-to-one combiner for 3.0T MRI systems were used, resolving the trade-offs between power-handling capability, insertion loss, structural compactness, and operating bandwidth in MRI power combiners. The combiner was successfully integrated into the 3.0T MRI RFPA system, reducing the overall dimensions of the RFPA system and simplifying its installation, thereby enabling high-quality imaging validation. This solution demonstrates the scalable potential of the design for other high-field MRI systems operating in the MHz range (from tens to hundreds of MHz), including in 1.5T and 7.0T MRI systems. Full article

Selecting grid loss reduction strategies is crucial for energy-saving transformations, particularly in the context of electricity transmission and distribution pricing reforms. The optimization of strategic selection is not easy due to the vast number of grid devices, which leads to a multitude of possible strategy combinations. This paper presents an optimal model for selecting loss reduction strategies, aiming to minimize the sum of comprehensive investment costs and energy loss costs over the life cycle of the strategies. The energy loss costs include both direct expenses due to energy loss and indirect costs, namely, carbon emission penalties. The constraints include allowable voltage deviations, branch power transmission, the number of loss reduction measures, loss rates, and total investment limits. The model comprehensively considers both economic benefits and the social benefits of reduced carbon emissions. It can help companies better adapt to electricity transmission and distribution pricing reforms, reduce operational costs, and contribute to low-carbon development. Finally, the model is validated using the data provided by one provincial power grid company in China. The results show that the loss reduction reaches 13.9 MW and the reduced carbon emission per hour is 10.425 t. The proposed method is also compared with the enumeration method, which demonstrates its effectiveness and efficiency. Further research will be conducted on establishing functional relationships between electricity sales prices and line losses to incentivize companies to apply loss reduction measures under different pricing functions. Full article

The industrial scenario is indispensable for ubiquitous 6G coverage, which demands hyper-reliable and low-latency communication for full automation, control, and operation. To meet these demands, it is widely believed that it is necessary to introduce not only the conventional sub-6 GHz bands but also high-frequency technologies, such as millimeter wave (mmWave), terahertz (THz), and visible light bands. In this paper, we conduct a channel characterization and comparison in the industrial scenario from the sub-6 GHz to visible light bands. The channel characteristics, including the path loss (PL), root mean square (RMS) delay spread (DS), and angle spread (AS), were analyzed with respect to the frequency dependence and the distance dependence. On the one hand, the visible light band exhibited significant differences in channel characteristics compared to the electronic wave band. Due to the line-of-sight transmission of VLC, the visible light band had a higher path loss, and the path loss exponent reached 3.84. Due to the Lambertian radiation pattern, which has a wide range of reflection angles, the AS of the visible light band was much larger than that of the electronic wave band, which were 1.73 and 0.80 for the visible light and THz bands, respectively. On the other hand, the blockage effect of the metal instruments in the industrial scenario will greatly affect the channel characteristics. As the transceiver distance grows large, signals from both sides of the receiver will be blocked by metal instruments, resulting in a decreasing trend in the RMS DS for the electronic wave band. Moreover, the statistical characteristics of the channel properties were modeled and compared with the 3GPP TR 38.901 standard. It was found that the height of the receiver caused the difference between the proposed model and the 3GPP model and needs to be taken into account when modeling. Furthermore, we extended the 3GPP model to the THz and VLC bands and provided the statistical parameters of the channel characteristics for all frequency bands. This study can provide insights for the evaluation and standardization of multi-frequency communication technology in the industrial scenario. Full article

High-current-carrying capability with minimum thermal elongation is one of the key reasons for using high-temperature low-sag (HTLS) conductors in modern power systems. However, their higher operational temperature can significantly affect corona discharge characteristics. Corona is one of the key factors in transmission line design considerations. Corona discharge is the leading cause of audible noise, radio interference, and corona loss in power transmission systems. The influence of conductor temperature on corona discharge characteristics is investigated in this paper using experimental methods and computational simulations. A simulation framework has been developed in COMSOL Multiphysics using the physics of plasmas and electrostatics to simulate corona plasma dynamic behavior and electric field distribution. The results show that the conductor temperature enhances the ionization by electron impact, enhances the production of positive and negative ions, changes the electric field distribution, and increases the electron temperature. This analysis emphasizes that temperature-dependent conditions affect the inception and intensity of corona discharge. Additionally, an experimental model was developed to evaluate corona voltage–current characteristics under varying temperature conditions. The study presents both simulation results and a newly developed model for predicting corona current at high conductor temperatures. Full article

Traditional JPEG series image compression algorithms have limitations in speed. To improve the storage and transmission of 14-bit/pixel images acquired by infrared line-scan detectors, a novel method is introduced for achieving high-speed and highly efficient compression of line-scan infrared images. The proposed method utilizes the features of infrared images to reduce image redundancy and employs improved Huffman coding for entropy coding. The improved Huffman coding addresses the low-probability long coding of 14-bit images by truncating long codes, which results in low complexity and minimal loss in the compression ratio. Additionally, a method is proposed to obtain a Huffman code table that bypasses the pixel counting process required for entropy coding, thereby improving the compression speed. The final implementation is a low-complexity lossless image compression algorithm that achieves fast encoding through simple table lookup rules. The proposed method results in only a 10% loss in compression performance compared to JPEG 2000, while achieving a 20-fold speed improvement. Compared to dictionary-based methods, the proposed method can achieve high-speed compression while maintaining high compression efficiency, making it particularly suitable for the high-speed, high-efficiency lossless compression of line-scan panoramic infrared images. The code table compression effect is 5% lower than the theoretical value. The algorithm can also be applied to analyze images with more bits. Full article

Detecting the moisture content of stored maize kernels is critical for minimizing post-harvest losses. To measure the moisture content of maize kernels under low-temperature conditions, a small-strip transmission line device was employed to construct a non-destructive measurement platform. The dielectric constant of maize kernels with varying moisture content was measured at temperatures ranging from −15 °C to 20 °C and frequencies between 1 and 200 MHz. By using the dielectric constant, frequency, and temperature as input variables, along with volume density and scattering parameter characteristics, three moisture content prediction models—SPO-SVM, XGBoost, and GA-BP—were established. The results show that temperature significantly affects the dielectric constant of maize kernels, especially when the moisture levels exceed 22.4%. The prediction model significantly improves the prediction accuracy under low-temperature conditions after introducing the volume density feature. Furthermore, incorporating the multi-phase and amplitude characteristics of scattering parameters further improves the model’s performance. This study verifies the mechanism and behavior of dielectric constant variations in maize kernels under low-temperature conditions. The proposed model effectively mitigates measurement errors caused by the icing of free water and is well suited for measuring maize moisture content under low-temperature conditions. Full article

Ensuring the reliability and safety of electrical power systems requires the efficient detection of defects in high-voltage transmission line insulators, which play a critical role in electrical isolation and mechanical support. Environmental factors often lead to insulator defects, highlighting the need for accurate detection methods. This paper proposes an enhanced defect detection approach based on a lightweight neural network derived from the YOLOv11n architecture. Key innovations include a redesigned C3k2 module that incorporates multidimensional dynamic convolutions (ODConv) for improved feature extraction, the introduction of Slimneck to reduce model complexity and computational cost, and the application of the WIoU loss function to optimize anchor box handling and to accelerate convergence. Experimental results demonstrate that the proposed method outperforms existing models like YOLOv8 and YOLOv10 in precision, recall, and mean average precision (mAP), while maintaining low computational complexity. This approach provides a promising solution for real-time, high-accuracy insulator defect detection, enhancing the safety and reliability of power transmission systems. Full article

In ultrasound systems, a protection circuit must be used to protect the receiver electronics from the high-voltage pulses generated by the transmitter and to minimize the signal loss and distortion of the low-voltage echoes generated by the transducer. Especially for certain ultrasound applications, such as intravascular ultrasound, particle manipulation, and cell stimulation, proper performance of the ultrasound transducers is desirable due to their low sensitivity. As the operating frequency of the ultrasound transducer increases, the size of the transducer decreases, increasing the amplitude of the transmitted signals to achieve proper acoustic performance. In such environments, a protection circuit can be used to protect the receiver electronics in ultrasound systems. To design suitable protection circuits, transistors, resistors, capacitors, and inductors are used, and the parameters of insertion loss, noise, total harmonic distortion, and recovery time of the protection circuits must be carefully considered. Various approaches have been developed to protect circuits such as transmission lines, transformers, bridge diodes, and metal-oxide-semiconductor field-effect transistor devices. Certain protection circuits are beneficial for impedance matching and area reduction. Other protection circuits have been designed to increase bandwidth, reduce insertion loss, or improve the signal-to-noise ratio for different ultrasound applications. Therefore, this review article may be useful for academic ultrasound researchers or circuit designers in selecting appropriate protection circuit types for specific ultrasound transducer applications. Full article

Accurate and efficient segmentation of key categories of transmission line corridor point clouds is one of the prerequisite technologies for the application of transmission line drone inspection. However, current semantic segmentation methods are limited to a few categories, involve cumbersome processes, and exhibit low accuracy. To address these issues, this paper proposes EMAFL-PTv3, a deep learning model for semantic segmentation of transmission line corridor point clouds. Built upon Point Transformer v3 (PTv3), EMAFL-PTv3 integrates Efficient Multi-Scale Attention (EMA) to enhance feature extraction at different scales, incorporates Focal Loss to mitigate class imbalance, and achieves accurate segmentation into five categories: ground, ground wire, insulator string, pylon, and transmission line. EMAFL-PTv3 is evaluated on a dataset of 40 spans of transmission line corridor point clouds collected by a drone in Wuhan and Xiangyang, Hubei Province. Experimental results demonstrate that EMAFL-PTv3 outperforms PTv3 in all categories, with notable improvements in the more challenging categories: insulator string (IoU 67.25%) and Pylon (IoU 91.77%), showing increases of 7.06% and 11.39%, respectively. The mIoU, mA, and OA scores reach 90.46%, 92.86%, and 98.07%, representing increases of 5.49%, 2.75%, and 2.44% over PTv3, respectively, proving its superior performance. Full article

This paper introduces a novel miniaturized, four-mode, semi-flexible leaky wave Multiple-Input Multiple-Output (MIMO) antenna specifically designed to advance vehicular communication systems. The proposed antenna addresses key challenges in 5G low- and high-frequency bands, including millimeter-wave communication, by integrating innovative features such as a periodic Spoof Surface Plasmon Polariton Transmission Line (SSPP-TL) and logarithmic-spiral-like semi-circular strip patches parasitically fed via orthogonal ports. These design elements facilitate stable impedance matching and wide impedance bandwidths across operating bands, which is essential for vehicular networks. The hybrid combination of leaky wave and SSPP structures, along with a defected wide-slot ground structure and backside meander lines, enhances radiation characteristics by reducing back and bidirectional radiation. Additionally, a naturalization network incorporating chamfered-edge meander lines minimizes mutual coupling and introduces a fourth radiation mode at 80 GHz. Compact in size (14 × 12 × 0.25 mm³), the antenna achieves high-performance metrics, including S11 < −18.34 dB, dual-polarization, peak directive gains of 11.6 dBi (free space) and 14.6 dBi (on vehicles), isolation > 27 dB, Channel Capacity Loss (CCL) < 3, Envelope Correlation Coefficient (ECC) < 0.001, axial ratio < 2.25, and diversity gain (DG) > 9.85 dB. Extensive testing across various vehicular scenarios confirms the antenna’s robustness for Vehicle-to-Vehicle (V2V), Vehicle-to-Pedestrian (V2P), and Vehicle-to-Infrastructure (V2I) communication. Its exceptional performance ensures seamless connectivity with mobile networks and enhances safety through Specific Absorption Rate (SAR) compliance. This compact, high-performance antenna is a transformative solution for connected and autonomous vehicles, addressing critical challenges in modern automotive communication networks and paving the way for reliable and efficient vehicular communication systems. Full article

In this article, resonance phenomena of high-speed interconnects and power delivery networks in glass packages are measured and analyzed. The resonances are generated in the interconnection by the physical dimension, cancelation of reactance components, and modes. When the resonances are generated in the operation frequency band, the signal/power integrity of the interconnect can be affected. As such, resonances generated in high-speed interconnects increase insertion loss, which degrades signal integrity. Also, resonances of the power delivery network (PDN) associated with boundary conditions increase PDN impedance, which degrades power integrity by generating power/ground noise and return current discontinuity of through vias. Recently, glass packaging has been gaining more attention due to its advantages associated with low substrate loss and large dimensions compared to silicon wafers. However, the low loss of the substrate and process variation may affect the resonance properties of interconnects. The resonance impacts on signal/power integrity must be analyzed, and mitigation plans should be proposed to maximize the advantages of the glass packaging technology. To analyze the resonance impacts on signal/power integrity, various glass package test vehicles are designed and fabricated. The fabricated test vehicles include transmission lines, PDNs, and patterns to measure an interaction between the through via and PDN. First, transmission line patterns that have 50-ohm characteristic impedance are measured. Due to the process variations, quarter-wave resonances are monitored, and at those frequencies, a sharp increase in insertion loss is observed, which deteriorates the signal integrity of the interconnect. Various PDN patterns are measured in the frequency domain, and regardless of the PDN shape, PDN impedance peaks are observed at the mode resonance frequencies. Due to a low-loss characteristic of the glass substrate, sharp PDN impedance peaks are generated at these frequencies. Also, at these frequencies, both signal and power integrity degradations are measured and analyzed. To fully benefit from the advantages of glass packaging technology, a thorough electrical performance analysis should be conducted to avoid resonances in the target frequency range. Full article

In wide-area networks (WANs) with high-speed, lossless transmission requirements, avoiding packet loss is crucial for ensuring link reliability, and maintaining link utilization over long distances is equally important. In this paper, we explore strategies for leveraging malfunctioning network links through link-local retransmission, optimizing our approach specifically for wide-area networks. To enhance performance, we select the duplicate threshold (dupthresh) based on the mean length deviation, which helps avoid triggering a certain portion of spurious fast retransmissions and reduces link bandwidth usage in an out-of-order environment. We evaluated our implementation on a programmable switch platform and found that this system maintained a low packet loss rate within a 10 Gbps line rate environment. It also reduces false retransmissions by 25% in the case of out-of-order links. Full article
