Mode division multiplexing (MDM) is an emerging optical communication solution for high-capacity wired–wireless applications. Due to the presence of modal crosstalk and link impairments in MDM, this work aims to design a system that provides low complexity, an improved Shannon Capacity limit, and high spectral efficiency. In this work, a quad modal MDM system using an integrated parabolic index multimode fiber and free-space optics (PIMMF-FSO) link is presented. Four linearly polarized (LP) modes, LP₀₁, LP₂₂, LP₀₃, and LP₁₃ based on a 16 × 10 Gbps MDM system offering different sixteen channels, are realized. Results show that the system can sustain a 7.5 dB insertion loss over 100 m FSO and a 100 m fiber range for different LP modes under the impact of clear air, moderate haze, heavy rain and wet snow climates with weak turbulence. A faithful fiber range of 3000 m can be obtained successfully in the proposed system with a −10 dB link loss, −7.62 dBm received power and 10 dB noise. Compared to existing designs, the proposed design offers optimum performance in terms of high channel capacity and a high traffic rate with low complexity and high spectral efficiency. Additionally, high received power, with acceptable noise, link loss, FSO misalignments and fiber nonlinearities, is successfully obtained. Full article

This paper presents two broadband four-way power dividers based on a novel T-coil topology, operating in the 22–32 GHz band (covering the K/Ka bands). Type I adopts a cascaded power division structure, while Type II employs a direct-feed integrated architecture. The innovation lies in the introduction of isolating capacitors at the input and output ports, which significantly shortens the critical transmission line lengths in both topologies. This effectively reduces the equivalent inductance and raises the self-resonant frequency, achieving wideband response while maintaining structural simplicity, compact size, and ease of integration. Both circuits were fabricated using a standard 45 nm CMOS process. The measured core chip areas (excluding pads) are only 0.125 mm² for Type I and 0.066 mm² for Type II, demonstrating excellent integration density. Through even-mode and odd-mode theoretical analysis and full-wave electromagnetic simulation verification, both power dividers exhibit good impedance matching and port isolation across the target frequency band. Measurement results further confirm their performance: across the entire 22–32 GHz band, both power dividers achieve a return loss better than 11 dB and isolation exceeding 15 dB; the insertion loss is 1.1–1.4 dB for Type I and 0.8–1.3 dB for Type II; the amplitude imbalance is below ±0.3 dB and ±0.1 dB, respectively; and the phase imbalance is less than ±5° and ±3°, respectively. All measured data show good agreement with simulation results. In summary, Type I offers advantages in layout flexibility and isolation performance, while Type II excels in insertion loss and chip size. Both provide practical circuit solutions for broadband, high-performance, and compact power division systems. Full article

To meet the increasingly strict requirements of modern communication, radar detection and electronic measurement systems for wide-bandwidth, low-insertion-loss and high-isolation signal routing, this paper presents a 16 × 16 programmable switch matrix that simultaneously achieves wideband operation (DC-40 GHz), low insertion loss (≤0.9 dB maximum), high isolation (>50 dB typical), and systematic modular scalability, a combination not found in existing implementations. The matrix, constructed with high-quality coaxial switches and optimized RF circuitry and electromagnetic structures, provides flexible and stable single-pole multi-throw (SPMT) signal routing across an ultra-wide frequency range from DC to 40 GHz. The switch matrix features a modular architecture, integrating multiple RF switching units, drive control circuits, and communication interface modules. This architecture achieves minimal signal path depth while maintaining full connectivity between any input and output port, directly minimizing cumulative insertion loss. Through precise impedance matching design and isolation structure optimization, the system still exhibits outstanding transmission characteristics at the 40 GHz high-frequency end: typical insertion loss does not exceed 0.9 dB, and the isolation between channels is better than 50 dB, effectively ensuring the integrity of signals in complex multi-channel environments. To meet the requirements of automated testing and remote control, the equipment integrates dual communication interfaces (serial port/network port), supports the SCPI command set and TCP/IP protocol, and can be conveniently embedded in various test platforms to achieve instrument interconnection and test process automation. Experimental verification shows that this matrix exhibits excellent switching stability and signal consistency across the entire 40 GHz, with a switching action time of less than 10 ms. Furthermore, it is capable of real-time topology reconfiguration via a microcontroller or FPGA. These innovations collectively deliver a switch matrix that meets the demanding requirements of 5G communication, millimeter-wave radar, and aerospace defense systems—applications where bandwidth, signal integrity, and system flexibility are paramount. Full article

This paper presents the design and experimental validation of a compact low-pass filter based on a quasi-eight-shaped defected ground structure (DGS). The study begins with a single DGS resonator that perturbs the ground-plane current distribution, introducing additional effective inductance and capacitance. An equivalent circuit model is developed to provide physical insight into the resonant mechanism and to establish the relationship between the DGS geometry and the electromagnetic response. By incorporating microstrip stubs on the top layer, the resonant structure is transformed into a low-pass filtering configuration with improved passband characteristics. Subsequently, a higher-order topology composed of two identical quasi-eight DGS units and three microstrip stubs is implemented to significantly enhance the rejection performance and extend the stopband bandwidth. The fabricated prototype exhibits a measured cutoff frequency of approximately 2.1 GHz, with an insertion loss lower than 1 dB in the passband. A wide stopband extending from 2.8 GHz to 8 GHz is achieved, with attenuation exceeding 26 dB. The close agreement between the equivalent circuit model, full-wave electromagnetic simulations, and measured results confirms the effectiveness and physical consistency of the proposed design. Owing to its compact planar implementation and strong harmonic suppression capability, the proposed filter is suitable for microwave front-end and antenna applications. Full article

Thin-film lithium niobate electro-optic modulators exhibit outstanding advantages such as large bandwidth, low insertion loss, and low half-wave voltage, demonstrating broad application prospects. However, due to internal defects in lithium niobate crystals, modulators exhibit electro-optic relaxation phenomena, with the relaxation time of thin-film structures being reduced by more than two orders of magnitude compared to bulk materials. In this study, we fitted and simulated the electro-optic relaxation behavior of thin-film lithium niobate modulators based on RC circuit model, effectively explaining their time-domain response characteristics under low-frequency conditions. By comparing thin-film modulators with and without silica cladding structures, the fitting results indicate that the relaxation time of modulators with cladding is approximately 11.9 ms, showing positive DC drift, whereas the relaxation time of modulators without cladding is significantly shortened to about 88.6 μs and exhibits negative DC drift. Additionally, the enhancement of optical intensity alters the photoconductivity of the material, thereby affecting its low-frequency electro-optic response behavior. This research provides important ideas for the design and optimization of next-generation integrated lithium niobate photonic modulators with high stability and controllability. Full article

Cochlear implantation (CI) effectively restores hearing across the whole lifespan but may be followed by vestibular complaints, especially in adult recipients. The aim of this narrative review is to provide a comprehensive characterization of vestibular complaints after CI in adults, collecting clinical and instrumental data, as well as discussing the risk factors for their development. From data reported in the literature, we defined five recurring clinical presentations of postoperative vestibular disturbances (phenotypes): acute postoperative vestibular syndrome, benign paroxysmal positional vertigo (BPPV), delayed Ménière-like vertigo attributable to secondary endolymphatic hydrops, chronic postoperative disequilibrium, and stimulation-linked vertigo. According to the different pathogeneses underlying each presentation, the management of postoperative vestibular complaints should be phenotype-guided, including short-course vestibular suppressants and early mobilisation for acute presentations; canalith repositioning for BPPV; empiric therapy for hydropic-like episodes; and vestibular rehabilitation when imbalance is persistent, programming changes for stimulation-linked symptoms. Alongside this phenotype-driven approach, subjective symptoms are common across cohorts but are usually transient and persistent disability is uncommon. Furthermore, instrumental data across the studies indicate that objective abnormalities cluster in otolith and low-frequency canal measures: Cervical, ocular VEMP, and caloric responses are more often impaired than high-frequency canal function on vHIT, confirming histopathological studies showing preferential saccular involvement during the insertion of the electrode array. The risk of postoperative vestibular complaints not only appears to be modulated more by patient-related factors, especially pre-existing vestibular loss, but also by the aetiology of deafness, or age, rather than by device characteristics; atraumatic surgical approaches may further reduce this risk. This review emphasizes that future research on vestibular complaints after CI should adopt standardized phenotypes when evaluating symptoms, objective vestibular function, falls, and quality of life. Additionally, it should correlate these outcomes with hypothetical risk factors and detailed surgical reports. Full article

To overcome the intrinsic trade-off among miniaturization, ultrawideband (UWB) performance, and structural simplicity in conventional frequency-selective rasorber (FSR) design, this paper proposes a miniaturized UWB absorption–transmission–absorption (A-T-A) FSR based on an inter-cell current-interaction mechanism. The structure comprises a dielectric matching layer (DML), a lossy frequency-selective surface (FSS), a lossless FSS layer, and air/dielectric spacers. Both FSS layers are fabricated on Rogers 4350B substrates without any metallized via or multiple lossy/lossless FSS stacking. The proposed FSR achieves a miniaturized structure with dimensions of 0.085 λ_L × 0.085 λ_L × 0.118 λ_L (where λ_L corresponds to the wavelength at the lowest absorption frequency). A fractional operational bandwidth around 144% is obtained, covering 2.88–12.87 GHz and 14.98–17.61 GHz with absorptivity over 80%, together with a low-loss transmission band of 13.57–14.56 GHz exhibiting a minimum insertion loss of 0.41 dB. As the incident angle increases up to 40°, the FSR retains more than 134% bandwidth for both TE and TM polarizations. A prototype was fabricated and measured, and the results agree well with the simulations. Full article

This paper presents the concept of a 2D m × n waveguide-based power combiner (PC) that is scalable with respect to the operating frequency band and number of input ports. To our knowledge, this work reports the first planar (2D) power combiner, where the input waveguide ports are distributed in two spatial dimensions to form an array, rather than arranged along a single linear (1D) axis as in conventional corporate or cascaded waveguide combiners. The novelty of the approach relies on using H-plane rectangular waveguide T-junctions and low-loss polarization twisters in between vertically stacked T-junctions to facilitate scalability. The work is motivated by the aim to coherently combine the output power of multiple modified uni-traveling carrier (MUTC) terahertz (THz) waveguide photodiodes (PDs) in a 2D array configuration. In the manuscript, the design of a 2 × 2 planar waveguide power combiner for the WR3 band (220–320 GHz) is reported, and it is also shown that this block can be further extended to m × n input ports. Full-wave numerical analysis of the proposed 2 × 2 power combiner shows a return loss of 11 dB at the output port and an average transmission coefficient of about −6.5 dB, i.e., an overall power combining efficiency of ~90%. Furthermore, to enable 2D photodiode array integration, the manuscript presents a new slot-bow tie antenna integrated MUTC photodiode for radiating the optically generated THz power from each PD vertically into the rectangular waveguide. The simulation results of reflection loss and insertion loss for the slot bow-tie antenna are shown to be better than 10 dB and 1.4 dB over the full WR3 band, respectively. To prove scalability of the power combiner concept w.r.t. the number of input ports, a 2 × 4 power combiner is also analyzed. Results reveal a return loss better than 10 dB from 225 to 318 GHz and a transmission coefficient of approximately −9.7 dB at 300 GHz, i.e., a power combining efficiency of ~85%. Full article

This study investigates the sound insulation performance of an anechoic chamber, exploring the influence patterns of different multilayer material combinations on wall sound insulation characteristics. Based on sound transmission theory, a predictive model for multilayer material wall sound insulation was established. The finite element method was employed to simulate the sound propagation characteristics of walls and glass doors with various material combinations. After validating the simulation results through a double-room method experiment, the material combination scheme for the anechoic chamber walls and glass doors was optimized. Based on this, a 1000 mm × 1000 mm × 2300 mm soundproof room prototype was designed and constructed. Its sound insulation performance under reverberant conditions was tested using the insertion loss method and compared with simulation data. Simultaneously, a hybrid calculation method combining low-frequency finite element analysis with high-frequency statistical energy analysis enabled precise and efficient prediction of the overall sound insulation performance of the soundproof room. Research revealed that single-pane glass with thicknesses between 5 and 20 mm conformed to the mass law, with sound insulation increasing by an average of 0.8 dB per additional millimeter. The 10 mm single-pane glass emerged as the optimal choice for the soundproof room’s glass door due to its ideal thickness and excellent low-to-mid-frequency sound insulation. The optimized wall structure featured compact thickness, outstanding low-frequency sound insulation, and balanced mid-to-high-frequency performance. Simulation and experimental results for the core frequency range of 63–1000 Hz showed high consistency, which validates the reliability of the theoretical model and simulation methodology within this frequency band. The deviation of simulation results from experimental data in the frequency range above 1000 Hz is mainly caused by acoustic leakage due to experimental sealing defects, and the high-frequency simulation results are only used for trend analysis rather than conclusion support. This study identifies the optimal multi-layer material combination for soundproof rooms, providing practical material strategies for acoustic design. It also reveals the sound insulation mechanisms of multi-layer composite structures. The findings offer significant reference for optimizing soundproofing materials and structures in architectural acoustics and transportation noise control. Full article

In the present study, the limiter component with excellent low insertion loss and leakage power characteristics is used at the beginning of the receiving path, mounted at the rear end of the antenna of the AESA radar system, to protect the low noise amplifier (LNA) from excessive input power. The main components required for the X-band transmit/receive module are designed and manufactured mainly using bare-type components to reduce the module size. In this paper, we develop the limiter component, which is a key component, and verify whether it can secure performance that can be operated from the system perspective by mounting it on the receiving path of the transmit/receive module. The performance results of the limiter component unit obtained insertion loss of less than 0.615 dB at 10 GHz and leakage power of less than +16.8 dBm in the X-band. The main performance of the receiving path in the transmit/receive module unit obtained results of a noise figure of less than 3.2 dB and a gain of more than 37 dB (including two stages of LNA). Full article

The continuous growth of traffic in metro networks is increasing the need for cost-effective, scalable, and power-efficient optical solutions. Filterless optical networks (FONs) have emerged as a promising architecture for metro-aggregation and metro-access domains, thanks to their low complexity and reliance on passive optical components. However, their inherent broadcast nature introduces key challenges, including spectrum waste, limited power equalization, and significant noise accumulation, particularly when coherent pluggable transceivers are employed. This work provides a detailed assessment of FON performance using state-of-the-art multi-source agreement (MSA)-compliant coherent modules, evaluating both point-to-point (P2P) and digital subcarrier multiplexing (DSCM)-based point-to-multipoint (P2MP) architectures. A novel optical amplifier (OA) optimization algorithm is proposed to balance expressed and added signal power in FON, accounting for optical power saturation effects and optical performance degradation due to limited power at the receiver input. The analysis highlights the substantial impact of transmitter out-of-band (OB) noise in FONs and its detrimental accumulation during multi-channel colorless aggregation, which can limit network capacity. In scenarios with lower capacity requirements, P2MP architectures demonstrate superior performance, benefiting from reduced insertion loss and lower OB noise accumulation while offering enhanced scalability compared with P2P solutions. Overall, the study highlights that FONs combined with coherent pluggables can support cost-efficient and scalable metro solutions, provided that OB noise, power imbalance, and amplifier operation are properly addressed through optimized design strategies. Full article

Additive manufacturing is transforming high-frequency electronics prototyping by offering a sustainable and cost-effective alternative to traditional methods. This work addresses and demonstrates two areas: the use of 3D printing for millimeter-wave (mmWave) antennas, and chip-to-chip or chip-to-PCB interconnects. Both approaches facilitate reduced material waste. A 47 GHz series-fed microstrip patch array was printed on flexible Kapton using aerosol jet technology, showing performance comparable to etched arrays on Roger’s substrates. Crucially, the Kapton film can be peeled off after testing, allowing the reuse of expensive low-loss substrates. Therefore, this method supports rapid, low-waste prototyping. To address future chip-to-chip and chip-to-PCB mmWave interconnect limitations, XTPL’s Ultra-Precise Dispensing (UPD) was used to fabricate 3D-printed micro-interconnects. At 73 GHz, these interconnect structures achieved return loss better than 10 dB and insertion loss under 1 dB—outperforming traditional bondwires. Together, these results show 3D printing’s potential to enable sustainable, high-performance mmWave RF systems. Full article

The present study introduces a novel design for lensed, chemically etched optical fibers (LEOFs) designed for efficient coupling with multicore fibers (MCFs). Experimental characterization at a wavelength of 1550 nm yielded an average coupling loss of approximately 0.76 dB under direct physical contact and 0.40 dB when the fiber end was positioned at an optimal working distance. Moreover, it was experimentally demonstrated that LEOFs exhibit high tolerance to longitudinal displacement and minimal wavelength-dependent variation in coupling efficiency. Based on this approach, fiber-in–fiber-out (FIFO) multicore couplers were fabricated using bundles of LEOFs that had been aligned to MCF cores. Bidirectional measurements yielded average insertion losses of 3.23–3.30 dB in TX and 3.20–3.27 dB in RX transmission directions at 1550 nm, with core-resolved losses as low as 1.09 dB for well-aligned channels. The results confirm the viability of LEOF-based multicore free-space coupling, with further improvements expected from enhanced fabrication accuracy. Full article

This paper reports a magnetically tunable U-band metallic waveguide isolator based on the ferromagnetic resonance (FMR) absorption effect. The device features a BaFe₁₂O₁₉ (BaM) single-crystal array integrated into a rectangular waveguide. By leveraging the high intrinsic magnetocrystalline anisotropy and narrow FMR linewidth of the single-crystal material, the isolator achieves high-frequency operation with a significantly reduced external bias field. Experimental results demonstrate a broad continuous tuning range from 50 GHz to 66 GHz. The device exhibits exceptional efficiency, with a typical insertion loss of less than 0.5 dB (minimum 0.24 dB) and an isolation exceeding 15 dB across the operating band. The cascaded array configuration ensures uniform magnetization and stable performance. This combination of ultra-low insertion loss and frequency agility makes the proposed isolator an ideal candidate for next-generation adaptive millimeter-wave communication and radar systems. Full article

This paper presents the design of a dual-frequency energy–frequency composite selective surface based on a double-period nested cross-fractal structure. The unit cell consists of a composite metallic layer loaded with diodes, an F4B dielectric substrate, and an intermediate layer with cross-shaped feeding line. The proposed model is structurally optimized and characterized using the periodic method of moments theory and the equivalent circuit method. In addition, its performance was verified through a comparative study. The results demonstrate that under low-power conditions, the surface achieves stable frequency-selective transmission at 2.4 GHz (S-band) and 4.2 GHz (C-band), enabling highly efficient signal transmission with an insertion loss of less than 0.6 dB. Under a high field strength, it automatically switches to an energy-selective state, providing full-band shielding effectiveness of ≥18 dB across a 2.0–5.0 GHz broadband, thereby achieving stealth functionality. The designed composite selective surface exhibits excellent angular stability and features a simple biasing network that does not require additional feeding lines. Thus, this study presents a new approach for designing such surfaces for operation in the microwave regime. Full article
