This paper presents the design and implementation of a D-band CMOS phase shifter based on a parallel reflective-load topology. Two phase-shifting architectures are explored, namely a 360° continuously tunable phase shifter and a 180° phase shifter combined with a phase inverter, enabling full 360° phase coverage. The circuit was simplified, and the number of bias lines was minimized to facilitate future array circuit implementation. In addition, a serial peripheral interface (SPI) circuit is implemented to simplify bias control and reduce the number of external connections during array chip packaging. Full article

This paper presents a highly linear one-bit loaded-line phase shifter that leverages PIN diodes in combination with a coupler-based impedance transformer. The proposed phase shifter adopts a loaded-line topology, where PIN diodes are configured in a parallel-to-ground arrangement to improve linearity performance. To further enhance linearity, a coupler-based impedance transformer is employed to reduce the impedance seen by each PIN diode, thereby minimizing nonlinear behavior. To demonstrate the effectiveness of this design, a one-bit digital phase shifter is developed, simulated, and fabricated to achieve a 45-degree phase shift at 2 GHz. Experimental measurements confirm an input third-order intercept point (IIP3) exceeding 100 dBm under a range of test conditions, validating the proposed architecture’s linearity advantages. Full article

This paper presents a novel dual-band Gysel filtering power divider (FPD) with an excellent isolation performance and a significantly wide isolation bandwidth. Although Gysel power dividers have been extensively studied in the field of radio frequency (RF), the integration of filtering functionality and the expansion of isolation bandwidth remain challenging. The proposed design addresses these challenges by incorporating frequency transform resonators (FTRs) and a microstrip/slotline (M/S) phase inverter into the classic Gysel topology. The FTR is directly connected to the output port to provide a dual-band response, enabling the Gysel FPD to operate without external coupling between the resonator and the port. The M/S phase inverter is a dual-layer 180° phase shifter, designed to replace the conventional 180° transmission lines loaded between the two isolation resistors of the Gysel FPD, achieving a wide isolation bandwidth. To validate the proposed design method, a dual-band Gysel FPD with center frequencies of 1.4 GHz and 1.7 GHz is designed, fabricated, and measured. The measured results show that the in-band return loss is greater than 20 dB, and the in-band insertion loss is about 0.6 dB, and the amplitude and phase imbalance characteristics are good. In addition, the 20 dB-isolation fractional bandwidth achieves 97% (0.78–2.25 GHz). The measured results show excellent agreement with the simulation results, validating the effectiveness of the proposed design methodology. Full article

In this paper, a filtered differential phase shifter with good selectivity is proposed and constructed. This study proposes and builds a filtered differential phase shifter with good selectivity. The main and reference lines in the suggested filtered differential phase shifter are structurally identical. The main line’s bandpass filtering function is achieved by a new coupled feeder, a parallel coupled line loaded with shorted branches, and a coupled resonator at the load end. It has impedance matching and additional transmission zeros/poles. By loading the coupled resonator at the load end, the selectivity of the phase shifter can be improved and the passband and transmission zeros/poles of the phase shifter can be equitably distributed by varying the coupling coefficients and the electrical lengths of the loaded branches. The reference line is a coupled resonator with the same structure and its electrical length is related to the number of degrees of phase shift. Finally, a differential phase shifter is designed and measured. The fractional bandwidth of the proposed phase shifter is about 38%, the return loss reaches −11 dB, the insertion loss is about 1.02 dB, the deviation of the simulated results in terms of the number of degrees of phase shift is about 2.5 degrees, and the deviation of the tested results is about 6 degrees. The trend of the simulation results and the actual measurement results are in good agreement. Full article

To solve the problem of the large size of traditional industrial frequency phase-shift transformers and the harmonic distortion of multi-pulse wave rectifier systems, this paper proposes a three-stage shunt zigzag power electronic phase-shift transformer based on a double-tap multi-pulse wave rectifier, which combines the power factor correction (PFC) converter with the voltage-type SPWM inverter circuit to form a power electronic converter to realize the frequency boost and power factor correction. Through AC–DC–AC conversion, the frequency of the three-phase AC input voltage is increased, the number of core and coil turns in the transformer is reduced to reduce the size of the phase-shifter transformer, a zigzag structure of the phase-shifter transformer is used to solve the unbalanced distribution of current between the diode bridges, and a passive harmonic suppression method on the DC side is used to generate a loop current by using a group of single-phase rectifier bridges to regulate the input line current of the phase-shifter transformer. The phase-shifted voltage is input into two three-phase diode rectifier bridges to rectify and supply power to the load. Simulation and semi-physical test results show that the proposed method reduces the total harmonic distortion (THD) value of the input current of the phase-shifted transformer to 7.17%, and the THD value of the grid-side input current is further reduced to 2.49%, which meets the harmonic standard and realizes the purpose of power factor correction as well as being more suitable for high-power applications. Full article

The paper presents a novel small-footprint varactor diode-based reconfigurable reflectarray (RRA) design and investigates its power reflection efficiency theoretically and experimentally in a real-life indoor environment. The surface is designed to operate at 865.5 MHz and is intended for simultaneous use with other wireless power transfer (WPT) efficiency-improving techniques that have been recently reported in the literature. To the best of the authors’ knowledge, no RRA intended to improve the performance of antenna-based WPT systems operating in the sub-GHz range has been designed and studied both theoretically and experimentally so far. The proposed RRA is a two-layer structure. The top layer contains electronically tunable phase shifters for the local phase control of an incoming electromagnetic wave, while the other one is fully covered by metal to reduce the phase shifter size and RRA’s backscattering. Each phase shifter is a pair of diode-loaded 8-shaped metallic patches. Extensive numerical studies are conducted to ascertain a suitable set of RRA unit cell parameters that ensure both adequate phase agility and reflection uniformity for a given varactor parameter. The RRA design parameter finding procedure followed in this paper comprises several steps. First, the phase and amplitude responses of a virtual infinite double periodic RRA are computed using full-wave solver Ansys HFSS. Once the design parameters are found for a given set of physical constraints, the phase curve of the corresponding finite array is retrieved to estimate the side lobe level due to the finiteness of the RRA aperture. Then, a diode reactance combination is found for several different RRA reflection angles, and the corresponding RRA radiation pattern is computed. The numerical results show that the side lobe level and the deviation of the peak reflected power angles from the desired ones are more sensitive to the reflection coefficient magnitude uniformity than to the phase agility. Furthermore, it is found that for scanning angles less than 50°, satisfactory reflection efficiency can be achieved by using the classical reactance profile synthesis approach employing the generalized geometrical optics (GGO) approximation, which is in accord with the findings of other studies. Additionally, for large reflection angles, an alternative synthesis approach relying on the Floquet mode amplitude optimization is utilized to verify the maximum achievable efficiency of the proposed RRA at large angles. A prototype consisting of 36 elements is fabricated and measured to verify the proposed reflectarray design experimentally. The initial diode voltage combination is found by applying the GGO-based phase profile synthesis method to the experimentally obtained phase curve. Then, the voltage combination is optimized in real time based on power measurement. Finally, the radiation pattern of the prototype is acquired using a pair of identical 4-director printed Yagi antennas with a gain of 9.17 dBi and compared with the simulated. The calculated results are consistent with the measured ones. However, some discrepancies attributed to the adverse effects of biasing lines are observed. Full article

In this article, a tunable RF sensor is presented for the measurement of dielectric materials (liquids and solids) based on a metamaterial resonator. The proposed novel configuration sensor has a microstrip line-loaded metamaterial resonator with tunable characteristics by utilizing a single varactor diode in the series of the resonator. CST Microwave studio is employed for 3D simulations of the tunable sensor, and the desired performance is attained by optimizing various structural parameters to enhance the transmission coefficient ($S_{21}$ magnitude) notch depth performance. The proposed RF sensor can be tuned in L and S-bands using the varactor diode biasing voltage range of 0–20 V. To validate the performance of the sensor, the proposed design has been simulated, fabricated, and tested for the dielectric characterization of different solid and liquid materials. Material testing is performed in the bandwidth of 1354 MHz by incorporating a single metamaterial resonator-based sensor. Agilent’s Network Analyzer is used for measuring the S-parameters of the proposed sensor topology under loaded and unloaded conditions. Simulated and measured S-parameter results correspond substantially in the 1.79 to 3.15 GHz frequency band during the testing of the fabricated sensor. This novel tunable resonator design has various applications in modulators, phase shifters, and filters as well as in biosensors for liquid materials. Full article

Compactness has obtained sufficient importance in wideband phase shifter design considerations, as it is directly related to fabrication cost. In this paper, a novel structure was presented to create compact broadband 180-degree phase shifter, which has the advantages of enhanced bandwidth and significantly reduced chip area. The proposed configuration consists of edge-coupled multi-microstrip lines (ECMML) and an artificial transmission line (ATL) with dual-shorted inductors, both of which have the periodic shunt load of capacitors. The ECMML can provide a high coupling coefficient, leading to an increase in the bandwidth, while the introduced capacitors can greatly reduce the line length (35.8% of the conventional method). To verify the relevant mechanisms, a wideband switched network with compact dimensions of 0.67 × 0.46 mm² was designed via 0.15-micrometer GaAs pHEMT technology. Combined with the measured switch transistor, it was shown that the proposed phase shifter exhibits an insertion loss of less than 2 dB, a return loss of greater than 12 dB, a maximum phase error of less than 0.6° and a channel amplitude difference of less than 0.1 dB in the range of 10 to 20 GHz. Full article

Multi-bit phase shifters are typically implemented by cascading multiple phase-shifting units, therefore incurring large dimensions and higher insertion losses. This paper presents highly compact single-unit two-bit reflection-type phase shifters (SUTBRTPSs), with large phase shifts range and lower insertion loss by using only one 3-dB hybrid coupler, unlike traditional multi-bit reflection-type phase shifters. To achieve this, two identical dual-voltage controlled reactance blocks (DVCRBs) are loaded to the 3-dB hybrid directional coupler at through and coupled ports, and 04 states of phase shifts are obtained between the input and isolated ports. Each DVCRB consists of 03 open-circuited transmission lines and switching p-i-n diodes and provides half of the required susceptance to achieve the desired phase shifts. Design theory is presented in detail, and for validation and demonstration, two typical SUTBRTPSs (0°/45°/90°/135° and 0°/22.5°/180°/202.5°) are designed, fabricated and measured. Being implemented in a single-unit structure, the proposed method yields highly compact dimensions of 0.44 λg × 0.46 λg and 0.54 λg × 0.46 λg, respectively. The simulation and measurements results are in good agreement and indicate maximum insertion losses of 1.7 and 2.1 dB with a return loss better than 20 dB and phase error of less than 1.5°. Full article

This paper presents a design for a dual-band tunable phase shifter (PS) with independently controllable phase shifting between each operating frequency band. The proposed PS consists of a 3-dB hybrid coupler, in which the coupled and through ports terminate with the same two reflection loads. Each reflection load consists of a series of quarter-wavelength (λ/4) transmission lines, λ/4 shunt open stubs, and compensation elements at each operating frequency arm. In this design, a wide phase shifting range (PSR) is achievable at each operating frequency band (f_L: lower frequency; f_H: higher frequency) by compensating for the susceptance occurring at the co-operating frequency band caused by the λ/4 shunt open stub. The load of f_L does not affect the load of f_H and vice versa. The dual-band tunable PS was fabricated at f_L = 1.88 GHz and f_H = 2.44 GHz, and testing revealed that achieved a PSR of 114.1° with an in-band phase deviation (PD) of ± 8.43° at f_L and a PSR of 114.0° ± 5.409° at f_H over a 100 MHz bandwidth. In addition, the maximum insertion losses were smaller than 1.86 dB and 1.89 dB, while return losses were higher than 17.2 dB and 16.7 dB within each respective operating band. Full article

In this study, we propose a 5-bit X-band gallium nitride (GaN) high electron mobility transistor (HEMT)-based phased shifter monolithic microwave integrated circuit for a phased-array technique. The design includes high-pass/low-pass networks for the 180° phase bit, two high-pass/bandpass networks separated for the 45° and 90° phase bits, and two transmission lines based on traveling wave switch and capacitive load networks that are separated for the 11.25° and 22.5° phase bits. The state-to-state variation in the insertion loss is 11.8 ± 3.45 dB, and an input/output return loss of less than 8 dB was obtained in a frequency range of 8–12 GHz. Moreover, the phase shifter achieved a low root mean square (RMS) phase error and RMS amplitude error of 6.23° and 1.15 dB, respectively, under the same frequency range. The measured input-referred P_1dB of the five primary phase shift states were larger than 29 dBm at 8 GHz. The RMS phase error and RMS amplitude error slightly increased when the temperature increased from 25 to 100 °C. The on-chip phase shifter exhibited no dc power consumption and occupied an area of 2 × 3 mm². Full article

A mode-matching formulation is presented and used to analyze the dispersion properties of twist-symmetric transmission lines. The structures are coaxial lines periodically loaded with infinitely thin screens, which are rotated with respect to each other to possess twist symmetry. The results obtained using the proposed formulation are in good agreement with those of commercial simulators. Furthermore, using the presented mode-matching formulation, it is demonstrated that the propagation characteristics in the twist-symmetric structures are linked to the scattering and coupling of the higher order modes. The physical insight offered by this analysis is valuable for the design of various electromagnetic devices, such as filters, antennas, and phase-shifters. Full article

Future satellite platforms and 5G millimeter wave systems require Electronically Steerable Antennas (ESAs), which can be enabled by Microwave Liquid Crystal (MLC) technology. This paper reviews some fundamentals and the progress of microwave LCs concerning its performance metric, and it also reviews the MLC technology to deploy phase shifters in different topologies, starting from well-known toward innovative concepts with the newest results. Two of these phase shifter topologies are dedicated for implementation in array antennas: (1) wideband, high-performance metallic waveguide phase shifters to plug into a waveguide horn array for a relay satellite in geostationary orbit to track low Earth orbit satellites with maximum phase change rates of 5.1°/s to 45.4°/s, depending on the applied voltages, and (2) low-profile planar delay-line phase shifter stacks with very thin integrated MLC varactors for fast tuning, which are assembled into a multi-stack, flat-panel, beam-steering phased array, being able to scan the beam from −60° to +60° in about 10 ms. The loaded-line phase shifters have an insertion loss of about 3 dB at 30 GHz for a 400° differential phase shift and a figure-of-merit (FoM) > 120°/dB over a bandwidth of about 2.5 GHz. The critical switch-off response time to change the orientation of the microwave LCs from parallel to perpendicular with respect to the RF field (worst case), which corresponds to the time for 90 to 10% decay in the differential phase shift, is in the range of 30 ms for a LC layer height of about 4 µm. These MLC phase shifter stacks are fabricated in a standard Liquid Crystal Display (LCD) process for manufacturing low-cost large-scale ESAs, featuring single- and multiple-beam steering with very low power consumption, high linearity, and high power-handling capability. With a modular concept and hybrid analog/digital architecture, these smart antennas are flexible in size to meet the specific requirements for operating in satellite ground and user terminals, but also in 5G mm-wave systems. Full article

Liquid crystals, which have high dielectric anisotropy even in the terahertz region and are easily controllable for dielectric permittivity by applying an electric field, have become increasingly attractive in recent years. The non-radiative dielectric (NRD) waveguide has a structure in which a dielectric line is sandwiched between two metal plates and by replacing the dielectric part with liquid crystal, a low loss liquid crystal-loaded NRD waveguide type terahertz phase shifter can be obtained. However, since the thickness of the liquid crystal layer is several hundred micrometers, it has a response time of as long as several hundred seconds when the driving voltage is removed. It is necessary to devise improvements for practical application. By inserting two polyethylene terephthalate (PET) films and reducing the thickness of the liquid crystal layer, the decay time was improved well, but the phase change was significantly reduced. In this study, we report improving both decay time and phase change with aligned nanofiber/liquid crystal complex. In addition, we demonstrate liquid crystal-load phase shifter, which has 360° phase change and the response time below one second. Full article

This paper presents a reflection-type phase shifter (RTPS) at W-band in a 0.13 µm complementary metal oxide semiconductor (CMOS) process. The RTPS is composed of a 90° hybrid coupler and two identical reflection loads. Lumped-distributed element transmission line is introduced in the 90° hybrid coupler to reduce the chip size. Series inductor-capacitor (LC) resonators are used as the reflective loads and parallel inductors are deployed to reduce insertion loss variation. By cascading two-stage RTPS, 90° phase shifting range and 10.5 dB insertion loss with 1 dB variations from 80 GHz to 90 GHz are achieved. An impressive 0.1 dB variation is obtained at 86 GHz. Full article
