With the increasing penetration of distributed photovoltaics (PVs) in distribution networks (DNs), issues like voltage violations and fluctuations are becoming more prominent. This paper proposes a spatio-temporal adaptive voltage coordination control strategy involving multiple timescales and multi-device collaboration. Aiming at the heavy workload caused by the continuous sampling of real-time data in the whole domain, an intra-day innovative construction of intra-day minute-level optimization and real-time adaptive control double-layer control mode are introduced. Intra-day minute-level refinement of on-load tap changer (OLTC) and step voltage regulator (SVR) day-ahead scheduling plans to fully utilize OLTC and SVR voltage regulation capabilities and improve voltage quality is discussed. In real-time adaptive control, a regional autonomy mechanism based on the functional area voltage quality risk prognostication coefficient (VQRPC) is innovatively proposed, where each functional area intelligently selects the time period for real-time voltage regulation of distributed battery energy storage systems (DESSs) based on VQRPC value, in order to improve real-time voltage quality while reducing the data sampling workload. Aiming at the state of charge (SOC) management of DESS, a novel functional area DESS available capacity management mechanism is proposed to coordinate DESS output and improve SOC homogenization through dynamically updated power–capacity availability (PCA). And vine model threshold band (VMTB) and deviation optimization management (DOM) strategies based on functional area are innovatively proposed, where DOM optimizes DESS output through the VMTB to achieve voltage fluctuation suppression while optimizing DESS available capacity. Finally, the DESS and electric vehicle (EV) cooperative voltage regulation mechanism is constructed to optimize DESS capacity allocation, and the black-winged kite algorithm (BKA) is used to manage DESS output. The results of a simulation on a modified IEEE 33 system show that the proposed strategy reduces the voltage fluctuation rate of each functional area by an average of 36.49%, reduces the amount of data collection by an average of 68.31%, and increases the available capacity of DESS by 5.8%, under the premise of a 100% voltage qualification rate. Full article

The integration of electrolyzers and fuel cells can cause voltage fluctuations within microgrids if not properly scheduled. Therefore, controlling voltage and reactive power becomes crucial to mitigate the impact of fluctuating voltage levels, ensuring system stability and preventing damage to equipment. This paper, therefore, seeks to enhance voltage and reactive power control within reconfigurable microgrids in the presence of innovative power-to-hydrogen technologies via electrolyzers and hydrogen-to-power through fuel cells. Specifically, it focuses on the simultaneous coordination of an electrolyzer, hydrogen storage, and a fuel cell alongside on-load tap changers, smart photovoltaic inverters, renewable energy sources, diesel generators, and electric vehicle aggregation within the microgrid system. Additionally, dynamic network reconfiguration is employed to enhance microgrid flexibility and improve the overall system adaptability. Given the inherent unpredictability linked to resources, the unscented transformation method is employed to account for these uncertainties in the proposed voltage and reactive power management. Finally, the model is formulated as a convex optimization problem and is solved through GUROBI version 11, which leads to having a time-efficient model with high accuracy. To assess the effectiveness of the model, it is eventually examined on a modified 33-bus microgrid in several cases. Through the results of the under-study microgrid, the developed model is a great remedy for the simultaneous operation of diverse resources in reconfigurable microgrids with a flatter voltage profile across the microgrid. Full article

A new energy industry represented by photovoltaic and wind power has been developing rapidly in recent years, and its randomness and volatility will impact the stable operation of the power system. At present, it is proposed to enrich the regulation of the power grid by tapping the regulation potential of load-side resources. This paper evaluates the overall voltage regulation capability of substations under the premise of considering the impact on network voltage security and providing a theoretical basis for the participation of load-side resources of distribution networks in the regulation of the power grid. This paper proposes a Zbus linear power flow model based on Fixed-Point Power Iteration (FFPI) to enhance power flow analysis efficiency and resolve voltage sensitivity expression. Establishing the linear relationship between the voltages of PQ nodes, the voltage of the reference node, and the load power, this paper clarifies the impact of reactive power compensation devices and OLTC (on-load tap changer) tap changes on the voltages of various nodes along the feeder. It provides theoretical support for evaluating the voltage regulation range for substations. The day-ahead focus is on minimizing network losses by pre-optimizing OLTC tap positions, calculating the substation voltage regulation boundaries within the day, and simultaneously optimizing the total reactive power compensation across the entire network. By analyzing the calculated examples, it was found that a pre-scheduled OLTC (on-load tap changer) can effectively reduce network losses in the distribution grid. Compared with traditional methods, the voltage regulation range assessment method proposed in this paper can optimize the adjustment of reactive power compensation devices while ensuring the voltage safety of all nodes in the network. Full article

Considering the integration of distributed energy resources (DER) such as distributed generation, demand response, and electric vehicles, day-ahead scheduling plays a significant role in the operation of active distribution systems. Therefore, this article proposes a comprehensive methodology for the short-term operational planning of a distribution company (DisCo), aiming to minimize the total daily operational cost. The proposed methodology integrates on-load tap changers, capacitor banks, and flexible loads participating in demand response (DR) to reduce losses and manage congestion and voltage violations, while considering the costs associated with the operation and use of controllable resources. Furthermore, to forecast PV output and load demand behind the meter at the MV/LV distribution transformer level, a short-term net load forecasting model using deep learning techniques has been incorporated. The proposed scheme is solved through an efficient two-stage strategy based on genetic algorithms and dynamic programming. Numerical results based on the modified IEEE 13-node distribution system and a typical 37-node Latin American system validate the effectiveness of the proposed methodology. The obtained results verify that, through the proposed methodology, the DisCo can effectively schedule its installations and DR to minimize the total operational cost while reducing losses and robustly managing voltage and congestion issues. Full article

This paper presents a novel modular voltage control algorithm for optimal scheduling of a distribution system’s load tap changers to minimize the number of tap changes while maintaining a voltage deviation (VD) around a desired target. To this end, a bi-objective optimal voltage regulation (OVR) problem is addressed in two distinct stages. First, the operational constraint on the load tap changer is removed to form a single-objective OVR problem relating to the voltage. The solution obtained in this stage is ultimately utilized to determine the penalty value assigned to the distance from the optimal (solely in terms of voltage) control value. In the second stage, the optimal scheduling problem is formulated as a minimum-cost-path problem, which can be efficiently solved via dynamic programming. This approach allows the identification of optimal scheduling that considers both the voltage-related objective as well as the number of load tap changer switching operations with no added computational burden beyond that of a simple voltage optimization problem. The method imposes no restriction on the load tap changer’s operation and is tested under two different target functions on the standard IEEE-123 test case. The first attains a nominal voltage with a 0.056 p.u. voltage deviation and the second is the well-known conservation voltage reduction (CVR) case with a 0.17 p.u. voltage deviation. The method is compared to an evolutionary-based algorithm and shows significant improvement in the voltage deviation by a factor of 3.5 as well as a computation time acceleration of two orders of magnitude. The paper demonstrates the effectiveness and potential of the proposed method as a key feature in future cutting-edge OVR methods. Full article

Considering the possible overvoltage caused by high-penetration photovoltaics (PVs) connected to the distribution networks (DNs), a cluster partition-based voltage control combined day-ahead scheduling and real-time control for distribution networks is proposed. Firstly, a community detection algorithm utilizing a coupling quality function is introduced to divide the PVs into clusters. Based on the cluster partition, day-ahead scheduling (DAS) is proposed with the objective of minimizing the operating costs of PVs, as well as the on-load tap changer (OLTC). In the real-time control, a second-order cone programming (SOCP) model-based real-time voltage control (RTVC) strategy is drawn up in each cluster to regulate the PV inverters, and this strategy can correct the day-ahead scheduling by modifications. The proposed strategy realizes the combination of day-ahead scheduling and real-time voltage control, and the optimization of voltage control can be greatly simplified. Finally, the proposed method is applied to a practical 10 kV feeder to verify its effectiveness. Full article

With distributed generation (DG) being continuously connected into distribution networks, the stochastic and fluctuating nature of its power generation brings ever more problems than before, such as increasing operating costs and frequent voltage violations. However, existing robust scheduling methods of flexible resources tend to make rather conservative decisions, resulting in high operation costs. In view of this, a two-stage robust optimal scheduling method for flexible distribution networks is proposed in this paper, based on the pairwise convex hull (PWCH) uncertainty set. A two-stage robust scheduling model is first formulated considering coordination among on-load tap changers, energy storage systems and flexible distribution switches. In the first stage, the temporal correlated OLTCs and energy storage systems are globally scheduled using day-ahead forecasted DG outputs. In the second stage, FDSs are scheduled in real time in each time period based on the first-stage decisions and accurate short-term forecasted DG outputs. The spatial correlation and uncertainties of the outputs of multiple DGs are modeled based on the PWCH, such that the decision conservativeness can be reduced by cutting regions in the box with low probability of occurrence. The improved column-and-constraint generation algorithm is then used to solve the robust optimization model. Through alternating iterations of auxiliary variables and dual variables, the nonconvex bilinear terms induced by the PWCH are eliminated, and the subproblem is significantly accelerated. Test results on the 33-bus distribution system and a realistic 104-bus distribution system validate that the proposed PWCH-based method can obtain much less conservative scheduling schemes than using the box uncertainty set. Full article

In this study, a multi-objective optimization method is proposed to solve day-ahead voltage control problems in distribution systems. The main purpose is to determine the optimal schedule for on-load tap changer (OLTC) settings at the sub-station and switched capacitors (SC) based on day-ahead load forecasting. The optimization criteria presented in this study include: (1) minimizing the voltage deviations at the main transformer bus, and (2) minimizing the total power loss. In the proposed method, the Pareto front and Manhattan distance are combined as indices to assess and select the best solution. Multi-Pareto optimality is used to improve the performance of the proposed scheduling strategy. In this study, the network components were modeled by the DIgSILENT Power Factory 15.2, while the multi-objective optimization algorithm was implemented on the MATLAB 2016a software package. Additionally, the effects of different distributed generation (DG) grid-connected points and operation scenarios on voltage control scheduling were examined. The efficiency and performance of the proposed method were verified using an IEEE 33 BUS test system. Compared with the local voltage level (LVL) and reactive power device control (RPDC) methods, the proposed method delivered percentage reductions in (1) voltage deviations at all buses, (2) voltage variations, (3) total system power loss, and (4) difference in values of up to 160.93%, 31.16%, 10.35%, and 434.34%, respectively. Full article

Typically, the main control on alternating current (AC) power systems is performed by the scheduling of rotary machines of synchronous generators and static machines of on-load tap changer (OLTC) transformers and volt-ampere reactive (VAR) sources. Large machines of synchronous generators can be managed by utilizing terminal voltage control when synchronized in parallel to the power system. These machines are typically terminal voltage regulated. In addition, substation on-load tap changer (OLTC) transformers improve system voltage management by controlling variable turn ratios that are adjusted in different levels known as taps along either the primary or secondary winding. Moreover, volt-ampere reactive (VAR) sources of static VAR compensators (SVCs), which are automated impedance devices connected to the AC power network, are designed for voltage regulation and system stabilization. In this paper, scheduling of these machines is coordinated for optimal power system operation (OPSO) using a recent algorithm of social network search optimizer (SNSO). The OPSO is performed by achieving many optimization targets of cost of fuel, power losses, and polluting emissions. The SNS is a recent optimizer that is inspired from users in social networks throughout the different moods of users such as imitation, conversation, disputation, and innovation mood. The SNSO is developed for handling the OPSO problem and applied on an IEEE standardized 57-bus power system and real Egyptian power system of the West Delta area. The developed SNSO is used in various assessments and quantitative analyses with various contemporary techniques. The simulated findings prove the developed SNSO’s solution accuracy and resilience when compared to other relevant techniques in the literature. Full article

This paper proposes a coordinated voltage regulation method for active distribution networks (ADNs) to mitigate nodal voltage fluctuations caused by photovoltaic (PV) power fluctuations, where a three-stage optimization scheme is developed to coordinate and optimize the tap position of on-load tap changers (OLTCs), the reactive power of capacitor banks (CBs), and the active and reactive power of soft open points (SOPs). The first stage aims to schedule the OLTC and CBs hourly using the rolling optimization algorithm. In the second stage, a multi-objective optimization model of SOPs is established to periodically (15 min) optimize the active and reactive power of each SOP. Meanwhile, this model is also responsible for optimizing the Q-V droop control parameters of each SOP used in the third stage. The aim of the third stage is to suppress real-time (1 min) voltage fluctuations caused by rapid changes in PV power, where the Q-V droop control is developed to regulate the actual reactive power of SOPs automatically, according to the measured voltage at the SOPs’ connection points. Furthermore, numerous simulations and comparisons are carried out on a modified IEEE 33-bus distribution network to verify the effectiveness and correctness of the proposed voltage regulation method. Full article

The voltage and reactive power control (Volt/VAR Control, VVC) in distribution networks has become a challenging issue with the increasing utilization of distributed generations (DGs). In this paper, a heuristic-based coordinated voltage control scheme that considers distribution voltage control devices, i.e., on-load tap changers (OLTC) and step voltage regulators (SVR), as well as reactive power control devices, i.e., DGs, are proposed. Conventional voltage control methods using non-linear node voltage equations require complex computation. In this paper, the formulation of simplified node voltage equations accounting for changes in tap position of distribution voltage control devices and reactive power changes of reactive power control devices are presented. A heuristic coordinated voltage control scheme using the proposed simplified node voltage equations is proposed. A coordinated voltage control scheme to achieve voltage control for nominal voltage and conservative voltage reduction (CVR) is presented. The results of the proposed schemes are compared with the results from the quadratic optimization method to confirm that the proposed schemes yields suitably similar results. Furthermore, a tap scheduling method is proposed to reduce the number of tap changes while controlling network voltage. The tap position is readjusted using a voltage control performance index (PI). Simulation results confirm that when using this method the number of tap changes is reduced. The proposed scheme not only produces reasonable performance in terms of control voltage of networks but also reduces the number of tap changes made by OLTC. The proposed control method is an alternative candidate for a system to be applied to practical distribution networks due to its simplified calculations and robust performance. Full article

The large number of small scale Distributed Energy Resources (DER) such as Electric Vehicles (EVs), rooftop photovoltaic installations and Battery Energy Storage Systems (BESS), installed along distribution networks, poses several challenges related to power quality, efficiency, and reliability. Concurrently, the connection of DER may provide substantial flexibility to the operation of distribution grids and market players such as aggregators. This paper proposes an optimization framework for the energy management and scheduling of operation for Low Voltage (LV) networks assuring both admissible voltage magnitudes and minimized line congestion and voltage unbalances. The proposed tool allows the utilization and coordination of On-Load Tap Changer (OLTC) distribution transformers, BESS, and flexibilities provided by DER. The methodology is framed with a multi-objective three phase unbalanced multi-period AC Optimal Power Flow (MACOPF) solved as a nonlinear optimization problem. The performance of the resulting control scheme is validated on a LV distribution network through multiple case scenarios with high microgeneration and EV integration. The usefulness of the proposed scheme is additionally demonstrated by deriving the most efficient placement and sizing BESS solution based on yearly synthetic load and generation data-set. A techno-economical analysis is also conducted to identify optimal coordination among assets and DER for several objectives. Full article

The growing penetration of photovoltaic (PV) systems may cause an over-voltage problem in power distribution systems. Meanwhile, charging of massive electric vehicles may cause an under-voltage problem. The over- and under-voltage problems make the voltage regulation become more challenging in future power distribution systems. Due to the development of smart grid and demand response, flexible resources such as PV inverters and controllable loads can be utilized for voltage regulation in distribution systems. However, the voltage regulation needs to calculate the nonlinear power flow; as a result, utilizing flexible resources for voltage regulation is a nonlinear scheduling problem requiring heavy computational resources. This study proposes an intelligent search algorithm called voltage ranking search algorithm (VRSA) to solve the optimization of flexible resource scheduling for voltage regulation. The VRSA is built based on the features of radial power distribution systems. A numerical simulation test is carried out on typical power distribution systems. The VRSA is compared with the genetic algorithm and voltage sensitivity method. The results show that the VRSA has the best optimization effect among the three algorithms. By utilizing flexible resources through demand response, the tap operation times of on-load tap changers can be reduced. Full article

This paper proposes a hierarchical look-ahead framework to conduct conservation voltage reduction (CVR) when distributed energy resources such as solar photovoltaic (PV) systems and energy storage systems (ESSs), and demand response programs are integrated into distribution systems. With the increasing deployment of PV systems in distribution systems, their frequently varying power output due to cloud movements could have a detrimental impact on the consumer’s voltage quality, consequently leading to degraded CVR performance. A two-level CVR framework for the coordination of an on-load tap changer (OLTC), capacitor banks (CBs), and the smart inverters of PV systems/ESSs is presented, in which these elements operate to reduce the voltage profile along the distribution feeder at different temporal scales. At the global level, the operations of the OLTC and the CBs are scheduled every hour to achieve the best CVR performance in an optimization problem using mixed-integer linear programming. When voltage violations occur rapidly, the smart inverters of PV systems and ESSs help to maintain a lower voltage profile every second based on the proposed piecewise droop control functions at the local level. A simulation study is carried out in an IEEE 33-bus distribution system with an OLTC, CBs, PV systems, and ESSs, and our results demonstrate the advantages of the proposed approach in terms of voltage level and energy savings. Furthermore, the impact of demand reduction on the proposed approach is quantified, and we verify that a higher demand reduction yields more energy savings in the proposed framework. Full article

Considering the possible overvoltage caused by the high proportion of photovoltaic systems (PVs) accessing distribution networks in the future, traditional centralized control methods will be too complex to satisfy the control response time demands. To solve this problem this paper presents a two-level voltage control method. At the day-ahead level, based on the PV-output and load-demand forecast, a community detection algorithm using an improved modularity index is introduced to divide the distribution network into clusters; a day-ahead optimal scheduling is drawn up on the basis of the network partition, and the objective is to minimize the operation costs of the distribution networks. At the real-time level, under the day-ahead optimal scheduling and network partition of the upper level, a real-time optimal voltage control algorithm is proposed based on the real-time operation data of the distribution networks, and the objective is to correct the day-ahead optimal scheduling through modifications. Thus, the algorithm realizes the combination of day-ahead scheduling and real-time control and achieves complete zonal voltage control for future distribution networks with high proportion of PVs. The proposed method can not only optimize the tap operation of an on-load tap changer (OLTC), improving the PV hosting capacity of the distribution network for a high proportion of PVs, but can also reduce the number of control nodes and simplify the control process to reduce the optimization time. The proposed approach is applied to a real, practical, 10 kV, 62-node feeder in Zhejiang Province of China to verify its feasibility and effectiveness. Full article
