Search Results (281)

This study explores the use of embedded piezo sensor (EPS) employing the Electro-Mechanical Impedance (EMI) technique for real-time corrosion monitoring in reinforced E-waste concrete exposed to chloride-laden environments. With the growing environmental concerns over electronic waste (E-waste) and the demand for sustainable construction practices, printed circuit board (PCB) materials were incorporated as partial replacements for coarse aggregates in concrete. The experiment utilized M30-grade concrete mixes, substituting 15% of natural coarse aggregates with E-waste, aiming to assess both sustainability and structural performance without compromising durability. EPS configured with Lead Zirconate Titanate (PZT) patches were embedded into both conventional and E-waste concrete specimens. The EPS monitored the changes in the form of conductance and susceptance signatures across a 100–400 kHz frequency range during accelerated corrosion exposure over a 60-day period in a 3.5% NaCl solution. The corrosion progression was evaluated qualitatively through electrical impedance signatures, visually via rust formation and cracking, and quantitatively using the Root Mean Square Deviation (RMSD) of EMI signatures. The results showed that the EMI technique effectively captured the initiation and propagation stages of corrosion. E-waste concrete exhibited earlier and more severe signs of corrosion compared to conventional concrete, indicated by faster increases and subsequent declines in conductance and susceptance and higher RMSD values during the initiation phase. The EMI-based system demonstrated its capability to detect microstructural changes at early stages, making it a promising method for Structural Health Monitoring (SHM) of sustainable concretes. The study concludes that while the use of E-waste in concrete contributes positively to sustainability, it may compromise long-term durability in aggressive environments. However, the integration of EPS and EMI offers a reliable, non-destructive, and sensitive technique for real-time corrosion monitoring, supporting preventive maintenance and improved infrastructure longevity. Full article

Lead zirconate titanate (PZT) piezoelectric ceramics are widely used functional materials due to their strong and stable piezoelectric properties. A leveling method based on lead zirconate titanate piezoelectric ceramics is proposed for the high level of accuracy required in microelectromechanical fields such as aerospace, industrial robotics, biomedical, and photolithography. A leveling mechanism consisting of core components such as piezoelectric ceramic actuators and sensors is designed. The closed-loop leveling of the working platform is performed using the electromechanical coupling effect of the PZT piezoelectric material. Combined with the theory of the dielectric inverse piezoelectric effect in electric fields, a simulation is used to analyze the four force and deformation cases generated by the drive legs when the load is attached at different positions of the working platform, and the leveling is realized by applying the drive voltage to generate micro-motion displacement. Simulation and calculation results show that the leveling method can reduce the tilt angle of the working platform by 60% when the driving voltage is in the range of 10~150 V. The feasibility of the leveling method and the uniformity of the theoretical calculation and simulation are verified. Full article

This study presents the successful fabrication of lead zirconate titanate (PZT) thin films on silicon (Si) substrates using a hybrid deposition method combining spin-coating and RF sputtering techniques. Initially, a PZT layer was deposited through four successive spin-coating cycles, followed by an additional layer formed via RF sputtering. The resulting multilayer structure was annealed at ${700 }^{°}$C for 2 h to improve crystallinity. Comprehensive material characterization was conducted using XRD, SEM, cross-sectional SEM, EDX, and UV–VIS absorbance spectroscopy. The analyses confirmed the formation of a well-crystallized perovskite phase, a uniform surface morphology, and an optical band gap of approximately 3.55 eV, supporting its suitability for sensing applications. Building upon these findings, a multilayer PZT-based touch sensor was fabricated and electrically characterized. Low-frequency I–V measurements demonstrated consistent and repeatable polarization behavior under cyclic loading conditions. In addition, $\left|Z\right|$–f measurements were performed to assess the sensor’s dynamic electrical behavior. Although expected dielectric responses were observed, the absence of distinct anti-resonance peaks suggested non-idealities linked to ${\mathrm{Ag}}^{+}$ ion diffusion from the electrode layers. To account for these effects, the classical Butterworth–Van Dyke (BVD) equivalent circuit model was extended with additional inductive and resistive components representing parasitic pathways. This modified model provided excellent agreement with the measured impedance and phase data, offering deeper insight into the interplay between material degradation and electrical performance. Overall, the developed sensor structure exhibits strong potential for use in piezoelectric sensing applications, particularly for tactile and pressure-based interfaces. Full article

This article investigates energy harvesting methods designed to capture energy from the alternating magnetic field surrounding a current-carrying conductor. The study focuses on the use of piezoelectric transducers in both monolithic and bimorph configurations. Experimental tests were conducted using vibrating beam structures composed of a single-layer piezoelectric material as well as bimorph piezoelectric composites, both utilizing lead zirconate titanate (PZT) as the active material. The results demonstrate a significant improvement in energy harvesting efficiency when using the bimorph configuration. Specifically, the bimorph-based system generated a peak voltage of 4.26 V and a current of 127.16 μA, resulting in an RMS power output of 272.48 μW. The operating principles, signal conditioning strategies, and structural differences in the evaluated designs are discussed in detail. The outcomes indicate the potential of such systems for powering autonomous sensors in low-power industrial monitoring applications. Full article

Ultrasonic applications such as non-destructive testing, biomedical imaging or range measurements are currently based on piezoelectric bulk transducers. Yet, these kinds of transducers with their mm to cm dimensions are rather impractical in fields in which both frequencies in the kHz region and small-feature sizes are required. This fact mainly relates to the inverse relationship between the resonance frequency constant and the transducers’ dimension, yielding a higher frequency and attenuation with a decreasing size. Piezoelectric micromachined ultrasonic transducers (PMUTs), in comparison, incorporate a small-scale µm design while preserving the operating frequency in the desired kHz range. This contribution presents the detailed manufacturing of such a PMUT with a multiple ring electrode‑based structure to additionally adjust the sound pressure fields. The PMUT will be characterized by its deflection in air along with the characterization of the piezoelectric material lead zirconate titanate (PZT) itself. The measurements showed a maximum polarization of 21.8 µC/cm² at 50 kV/cm, the PMUT’s displacement of 30.50 nm/V in air when all electrodes are driven, and an adjustable deflection via different electrode excitations without the need for additional hardware. The ring design also offered the possibility to emit two distinct frequencies simultaneously. These results demonstrate the potential of the designs for small-feature-size applications as they are in high demand for implantable devices, miniaturized ultrasonic-based communication or drug delivery. Full article

Interface debonding between high-strength grouting materials and the inner surfaces of steel tubes in grouting jacket connections (GJCs), which have been widely employed in offshore wind turbine support structures, negatively affects their mechanical behavior. In this study, an interface debonding defect detection and localization approach for scaled underwater GJC specimens using surface wave measurements with piezoelectric lead zirconate titanate (PZT) actuation and sensing technology was validated experimentally. Firstly, GJC specimens with artificially mimicked interface debonding defects of varying dimensions were designed and fabricated in the lab, and the specimens were immersed in water to replicate the actual underwater working environment of GJCs in offshore wind turbine structures. Secondly, to verify the feasibility of the proposed interface debonding detection approach using surface wave measurements, the influence of the height and circumferential dimension of the debonding defects on the output voltage signal of PZT sensors was systematically studied experimentally using a one pitch and one catch (OPOC) configuration. Thirdly, a one pitch and multiple catch (OPMC) configuration was further employed to localize and visualize the debonding defect regions. An abnormal value analysis was carried out on the amplitude of the output voltage signals from PZT sensors with identical wave traveling paths, and the corresponding abnormal surface wave propagation paths were identified. Finally, based on the influence of interface debonding on the surface wave measurements mentioned above, the mimicked interface debonding defect was detected successfully and the region of debonding was determined with the intersection of the identified abnormal wave travelling paths. The results showed that the mimicked debonding defect can be visualized. The feasibility of this method for interface debonding defect detection in underwater GJCs was confirmed experimentally. The proposed approach provides a novel non-destructive debonding defect detection approach for the GJCs in offshore wind turbine structures. Full article

Interface debonding between the steel tube and grouting materials in grouting jacket connections (GJCs) of offshore wind turbine supporting structures leads to negative effects on the load-carrying capacity and safety concerns. In this paper, an interface debonding defect detection and localization approach for scale underwater GJC specimens using surface wave measurement is proposed and validated numerically. A multi-physics finite element model (FEM) of underwater GJCs with mimicked interface debonding defects, surrounded by water, and coupled with surface-mounted piezoelectric lead zirconate titanate (PZT) patches is established. Under the excitation of a five-cycle modulated signal, the surface stress wave propagation, including transmission, diffraction, and reflection, within the outer steel tube, grouting material, and inner steel tube is simulated. The influence of mimicked interface debonding defects of varying dimensions on stress wave propagation is systematically analyzed through stress wave field distributions at distinct time intervals. Additionally, the response of surface-mounted PZT sensors in the underwater GJC model under a one-pitch-one-catch (OPOC) configuration is analyzed. Numerical results demonstrate that the wavelet packet energy (WPE) of the surface wave measurement from the PZT sensors corresponding to the traveling path with a mimicked interface debonding defect is larger than that without a defect. To further localize the debonding region, a one pitch and multiple catch (OPMC) configuration is employed, and an abnormal value analysis is conducted on the WPEs of PZT sensor measurements with identical and comparable wave traveling patches. The identified debonding regions correspond to the simulated defects in the models. Full article

This paper introduces a wearable silent text input system designed to capture text input through silent speech, without generating audible sound. The system integrates Electromyography (EMG) and piezoelectric lead zirconate titanate (PZT) sensors in a miniaturized form that can be comfortably attached to the chin, making it both comfortable to wear and esthetically pleasing. The EMG sensor records muscle activity linked to specific tongue and jaw movements, while the PZT sensor measures the minute vibrations and pressure changes in the chin skin caused by silent speech. Data from both sensors are analyzed to capture the timing and intensity of the silent speech signals, allowing the extraction of key features in both time and frequency domain. Several machine learning (ML) models, including both feature-based and non-feature-based approaches commonly used for classification tasks, are employed and compared to detect and classify subtle variations in sensor signals associated with individual alphabet letters. To evaluate and compare the ML models, EMG and PZT signals for the eight most frequently used English letters are collected across one hundred trials each. Results showed that non-feature-based models, particularly the Fea-Shot Learning with fused EMG and PZT signals, achieved the highest accuracy (95.63%) and F1-score (95.62%). The proposed system’s accuracy and real-time performance make it promising for silent text input and assistive communication applications. Full article

Piezoelectric materials based on polyvinylidene fluoride (PVDF) are widely regarded as ideal candidates for the fabrication of piezoelectric energy harvesters (PEHs). However, the relatively low power output of PVDF limits its widespread application and poses a significant challenge to the advancement of PEHs. To address this issue, we have designed a novel PEH using silver-modified lead zirconate titanate/PVDF (pPZT@Ag/PVDF), which achieves a remarkable balance between high output performance and long-term stability. The pPZT@60Ag/PVDF PEH generates a peak voltage of 14.33 V, which is about 2.6 times that of the pure lead zirconate titanate/PVDF (pPZT/PVDF) PEH. This enhancement is attributed to the confined structure within the PVDF fibers, as well as the enhancement in dipole orientation alignment and the local electric field induced by silver nanoparticle modification. Furthermore, the pPZT@60Ag/PVDF PEH demonstrates a peak power density of 0.58 μW/cm², with negligible degradation in output voltage after 6000 bending cycles, and efficiently harvests mechanical energy from human movement. This study presents an effective method for fabricating high-performance PEHs, which is expected to advance the development of next-generation energy harvesting devices. Full article

Establishing dependable and resilient methodologies for identifying damage that may compromise the integrity of reinforced concrete (RC) infrastructures is imperative for preventing potential catastrophic failures. Continuous evaluation and Structural Health Monitoring (SHM) can play a key role in extending the lifespan of new or existing buildings. At the same time, early crack detection in critical members prevents bearing capacity loss and potential failures, enhancing safety and reliability. Furthermore, implementing discrete fibers in concrete has significantly improved the ductility and durability of Fiber-Reinforced Concrete (FRC). The present study employs a hierarchical clustering analysis (HCA) to identify damage in FRC by analyzing the raw Electromechanical Impedance (EMI) signature of piezoelectric lead zirconate titanate (PZT) transducers. The experimental program consisted of three FRC standard cylinders subjected to repeated loading. The loading procedure consists of 6 incremental steps carefully selected to gradually deteriorate FRC’s structural integrity. Additionally, three PZT patches were adhered across the height of its specimen using epoxy resin, and their EMI response was captured between each loading step. Subsequently, the HCA was conducted for each PZT transducer individually. The experimental investigation demonstrates the efficacy of HCA in detecting load-induced damage in FRC through the variations in the EMI signatures of externally bonded PZT sensors. Full article

Flexible polymer-based piezoelectric nanogenerators (PENGs) have gained significant interest due to their ability to deliver clean and sustainable energy for self-powered electronics and wearable devices. Recently, the incorporation of fillers into the ferroelectric polymer matrix has been used to improve the relatively low piezoelectric properties of polymer-based PENGs. In this study, we investigated the effect of various nanofillers such as titania (TiO₂), zinc oxide (ZnO), reduced graphene oxide (rGO), and lead zirconate titanate (PZT) on the PENG performance of the nanocomposite thin films containing the nanofillers in poly(vinylidene fluoride-co-trifluoro ethylene) (P(VDF-TrFE)) matrix. The nanocomposite films were prepared by depositing molecularly thin films of P(VDF-TrFE) and nanofiller nanoparticles (NPs) spread at the air/water interface onto the indium tin oxide-coated polyethylene terephthalate (ITO-PET) substrate, and they were characterized by measuring their microstructures, crystallinity, β-phase contents, and piezoelectric coefficients (d₃₃) using SEM, FT-IR, XRD, and quasi-static meter, respectively. Multiple PENGs incorporating various nanofillers within the polymer matrix were developed by assembling thin film-coated substrates into a sandwich-like structure. Their piezoelectric properties, such as open-circuit output voltage (V_OC) and short-circuit current (I_SC), were analyzed. As a result, the PENG containing 4 wt% PZT, which was named P-PZT-4, showed the best performance of V_OC of 68.5 V with the d₃₃ value of 78.2 pC/N and β-phase content of 97%. The order of the maximum V_OC values for the PENGs of nanocomposite thin films containing various nanofillers was PZT (68.5 V) > rGO (64.0 V) > ZnO (50.9 V) > TiO₂ (48.1 V). When the best optimum PENG was integrated into a simple circuit comprising rectifiers and a capacitor, it demonstrated an excellent two-dimensional power density of 20.6 μW/cm² and an energy storage capacity of 531.4 μJ within 3 min. This piezoelectric performance of PENG with the optimized nanofiller type and content was found to be superior when it was compared with those in the literature. This PENG comprising nanocomposite thin film with optimized nanofiller type and content shows a potential application for a power source for low-powered electronics such as wearable devices. Full article

Forcecardiography (FCG) uses force sensors to record the mechanical vibrations induced on the chest wall by cardiac and respiratory activities. FCG is usually performed via piezoelectric lead-zirconate titanate (PZT) sensors, which simultaneously record the very slow respiratory movements of the chest, the slow infrasonic vibrations due to emptying and filling of heart chambers, the faster infrasonic vibrations due to movements of heart valves, which are usually recorded via Seismocardiography (SCG), and the audible vibrations corresponding to heart sounds, commonly recorded via Phonocardiography (PCG). However, PZT sensors are not flexible and do not adapt very well to the deformations of soft tissues on the chest. This study presents a flexible FCG sensor based on a piezoelectric polyvinylidene fluoride (PVDF) transducer. The PVDF FCG sensor was compared with a well-assessed PZT FCG sensor, as well as with an electro-resistive respiratory band (ERB), an accelerometric SCG sensor, and an electronic stethoscope for PCG. Simultaneous recordings were acquired with these sensors and an electrocardiography (ECG) monitor from a cohort of 35 healthy subjects (16 males and 19 females). The PVDF sensor signals were compared in terms of morphology with those acquired simultaneously via the PZT sensor, the SCG sensor and the electronic stethoscope. Moreover, the estimation accuracies of PVDF and PZT sensors for inter-beat intervals (IBIs) and inter-breath intervals (IBrIs) were assessed against reference ECG and ERB measurements. The results of statistical analyses confirmed that the PVDF sensor provides FCG signals with very high similarity to those acquired via PZT sensors (median cross-correlation index of 0.96 across all subjects) as well as with SCG and PCG signals (median cross-correlation indices of 0.85 and 0.80, respectively). Moreover, the PVDF sensor provides very accurate estimates of IBIs, with R² > 0.99 and Bland–Altman limits of agreement (LoA) of [−5.30; 5.00] ms, and of IBrIs, with R² > 0.96 and LoA of [−0.510; 0.513] s. The flexibility of the PVDF sensor makes it more comfortable and ideal for wearable applications. Unlike PZT, PVDF is lead-free, which increases safety and biocompatibility for prolonged skin contact. Full article

Developing lead zirconate titanate (PZT)-based electro-optic (EO) modulators is vital for integrated photonics. The high annealing temperature required for the processing of PZT thin films restricts their compatibility with modern complementary metal–oxide–semiconductor (CMOS) technology. In this work, high-quality PZT films were fabricated on SiO₂/Si substrates at a low annealing temperature of 450 °C. The PZT films demonstrated a preferential (100) orientation and were uniform and crack-free. Based on the low-temperature PZT films, we subsequently designed and fabricated a Mach–Zehnder Interferometer (MZI) waveguide modulator. The measured half-wave voltage (V_π) was 4.8 V at a wavelength of 1550 nm, corresponding to an in-device EO coefficient as high as 66 pm/V, which shows potential use in optical devices. The results reported in this work show great promise for the integration of PZT thin films with other complex systems. Full article

Crystallographic texture engineering through templated grain growth (TGG) has gained prominence as a highly effective strategy for optimizing the electromechanical performance of lead-free piezoelectric ceramics, offering a pathway toward sustainable alternatives to lead-based systems like lead zirconate titanate (PZT). By achieving high degrees of texture, with Lotgering factors (LFs) often exceeding 90%, these systems have demonstrated piezoelectric properties that rival or even surpass their lead-based counterparts. Despite these advancements, the field lacks a comprehensive understanding of how specific template parameters influence the texture quality and functional properties across different material systems. This review provides an in-depth analysis of the influence of the template morphology, composition, and crystallographic orientation on the texturing of key lead-free systems, including BaTiO₃ (BT), (K_0.5Na_0.5)NbO₃ (KNN), and Bi_0.5Na_0.5TiO₃ (BNT). Furthermore, it explores how the template selection affects the induced crystallographic direction, and how this impacts the material’s phase structure and domain configurations, ultimately influencing the piezoelectric and dielectric properties. By consolidating the existing knowledge and identifying current challenges, this work highlights key strategies for optimizing the texture and electromechanical performance in lead-free ceramics, providing essential insights for future research aimed at advancing high-performance, environmentally friendly piezoelectric materials for applications such as sensors, actuators, and energy-harvesting devices. Full article

One of the challenging problems in the research and development of vibration sensors relates to the formation of Ohmic contacts for the removal of an electrical signal. In some cases, it is proposed to use arrays of carbon nanotubes (CNTs), which can serve as highly elastic electrode materials for vibration sensors. The purpose of this work is to study the effect of a current-collecting layer of CNTs grown over silicon on the properties of a lead zirconate titanate (PZT) film, which is frequently employed in mechanical vibration sensors or energy harvesters. For the experiments, a vibration sensor mock-up was created with the PZT-CNT-Ni-V-SiO₂-Si and PZT-CNT-Ni-V-Si structures where an array of vertically oriented CNTs was grown over an oxidized or high-alloyed silicon substrates by plasma chemical deposition from a gas phase. Then, a thin film of PZT was applied to the CNT layer with a high-frequency reactive plasma spraying. For comparison, the PZT film was applied to silicon without a CNT layer (PZT-Si structure). The calculated average value of the piezoelectric module is 112 pm/V for the Ni-PZT-PT-Ni-Si-SiO₂ sample, and 35 pm/V for PZT-Ni-SiO₂-Si. It can be seen that the contact realized with the help of CNT ensures more than three times the best efficiency in terms of the piezoelectric module. The value of the piezoelectric module of the vibration sensor with the PZT-CNT-Ni-V-Si structure was 186 pm/V, and the value of the residual polarization was 23.2 µC/cm², which is more than eight and three times, respectively, higher than the values of these properties for the vibration sensor with the PZT-Si structure. It is shown that the vibration sensor can operate in the frequency range of 0.1–10 kHz. Full article
