Search Results (15)

This paper presents a particular tunneling method, the new Austrian tunneling method (NATM), which plays an important role in reducing subsidence of the surface and damage to structures in urban areas. It has a wide range of applications in shallow tunneling projects all over the world. In this study, numerical modeling of the third-line Metro tunnel in Tehran, which is designed and stabilized by the NATM, is under discussion. The foregoing tunnel is excavated manually with a one-meter advancing step. In this project, the constructors use a lattice girder and spray concrete with 31 cm thickness as the initial lining. A suitable numerical software for this modeling is PLAXIS 3D Tunnel, which allows high-resolution finite element modeling (FEM) of the studied object. The performance of this method is investigated and compared with that of other NATMs. The numerical modeling yielded a value of 30.01 mm for earth subsidence in the most damaged area of the settlement, which was confirmed with a dramatically low difference by earth surface monitoring. Moreover, this tunnel was drilled and excavated using various methods, among which the least settlement was obtained by the proposed method. The results are promising, and they indicate that tunneling with this method should continue to be used to expand the subway line in the city. Full article

The steel rib and the lattice girder are two typical steel arch frames used in the primary lining of the New Austrian Tunnelling Method (NATM) highway tunnel. In the process of tunnel construction, it is necessary to choose the support method according to the mechanical properties, durability, construction difficulty, and economic benefits. In order to analyze the mechanical characteristics of steel arch frames, a loading and measurement test system for steel arch was designed, and destructive tests were carried out on a three-bar lattice girder, four-bar lattice girder, and I-beam steel rib. The steel utilization coefficient was introduced to compare the mechanical properties of the different types of steel frames. The results show that the I-beam steel rib has the largest steel utilization coefficient, but it is not well combined with concrete. Among the lattice girders, the three-bar W-shaped lattice girder uses the least amount of steel under the same load, which reduces the construction cost and is worth applying and popularizing. Additionally, the steel utilization coefficient of different types of lattice girders can be optimized through the ratio of steel bar diameters. It is proved that the steel utilization coefficient can provide a reference for the evaluation and selection of steel frames for the primary lining of highway tunnel engineering. Full article

In recent years, with the development of building technology, the Chinese construction industry has begun to gradually promote the prefabricated buildings to save on construction costs. Among them, composite slabs, as essential components of prefabricated buildings, have been widely used by designers mainly in favor of their low cost. However, is it possible to further reduce the cost without affecting the quality? Researchers think so if the operation cycle of support from the bottom of composite slabs can accelerate and the mechanical properties of their bottom plate can be optimized. To prove this hypothesis, researchers proposed a new type of prestressed concrete composite slab with removable rectangular steel-tube lattice girders (referred to as CDB composite slabs), whose bottom plate consists of a temporary structure composed of a prestressed concrete prefabricated plate and removable rectangular steel-tube lattice girders. Through static bending performance tests on three prefabricated bottom plates and one composite slab, researchers measured corresponding load-displacement curves, load-strain curves, crack development, and distribution, etc. The test results show that the top chord rectangular steel tubes connected to the bottom plate concrete through web reinforcement bars significantly improve the rigidity, crack resistance, and load-bearing capacity of the bottom plate and possess better ductility and out-of-plane stability. The number of supports at the bottom of the bottom plate is effectively reduced, with the maximum unsupported span reaching 4.8 m. Beyond 4.8 m, only one additional support is needed, and the maximum support span can be up to 9.0 m, which provides space for cost reduction. The cooperative load-bearing performance of the prefabricated bottom plate and the post-cast composite layer concrete is good. The top chord rectangular steel tubes are easy to dismantle and can be reused, which reduces the steel consumption by about 24% compared to that used for the same size of ordinary steel-tube lattice-girder concrete composite slabs. It can greatly decrease the cost. In conclusion, the results have shown that the new method researchers proposed here is practically applicable and also provides great space to save on financial costs. Full article

This manuscript attempts to classify typical errors occurring during the design, production, and use of prefabricated and prestressed concrete girders and slabs manufactured in Poland for industrial buildings since the 1950s. Although the cases discussed concern Poland, most of them have a universal character, and as such are also found in other countries. The defects and errors are illustrated with examples and the causes of their occurrence are also discussed. A method of classifying flaws based on the period of their occurrence was proposed. Most of the examples discussed were encountered by the authors during their professional work. In most of the presented cases, repair was possible, enabling further safe operation. This paper shows how important it is to periodically check the technical condition of prestressed structures and how common and at the same time trivial mistakes may be made by designers and contractors of this type of structure, despite the experience of over 70 years of their mass use. The quality of modern prestressed structures is undoubtedly higher. Using the experience of previous generations, designers and contractors abandoned the less durable post-tensioned concrete lattice girders. Errors, if they appear, are most often at the stage of implementing new products or are the result of poor workmanship or disregard for unfavorable weather conditions. Full article

To investigate the fire risk in a complex tunnel with varying cross-sections, sloped structures, and dense upper cover beams, this study considered four fire source positions: the immersed tube section, confluence section, highway auxiliary road section, and four-lane sections of the main line. It also considered four beam spacings: 1 m, 1.8 m, 3.6 m, and 7.2 m. The Fire Dynamics Simulation Software FDS was utilized to create a comprehensive tunnel model. The analysis focused on temperature and visibility changes at a 2 m height under a 20 MW fire condition for different fire source positions. These changes were then compared with critical danger values to assess the safety of evacuating personnel within the tunnel. Subsequently, this study proposed corresponding emergency rescue strategies. The findings indicated that when the beam grid spacing exceeded 3.6 m, the upper dense beam gap showed a robust smoke storage capacity, leading to a reduced distance of high-temperature smoke spread. However, this increased smoke storage disrupted the stability of the smoke layer, resulting in a heightened smoke thickness. The location of the ventilation vent at the entrance of the immersed tunnel section caused a non-uniform ventilation flow under the girder, deflecting the smoke front towards the unventilated side and decreasing visibility in the road auxiliary area. In comparison to scenarios without a beam lattice, the presence of a beam lattice in the tunnel amplified fire hazards. When the beam lattice spacing was 3.6 m or greater, the extent of the hazardous environment, which is unfavorable for personnel evacuation, expanded. With the exception of the scenario where the fire source was located in the highway auxiliary roadway, all other conditions surpassed 150 m, which is roughly one-third of the tunnel length. Consequently, more targeted strategies are necessary for effective evacuation and rescue efforts. Full article

Aluminum alloys provide corrosion resistance, lightweight construction, and functionality through extruded profiles. The creation of heat-affected zones (HAZs), which can reduce load-bearing capacity by up to 50% and complicate K-joint design, makes it difficult to apply aluminum in truss systems. Since EN 1999-1-1 (EC 9) does not even provide guidelines for welded aluminum K-joints, practitioners turn to EN 1993-1-8 (EC 3), resulting in a conservative design that ignores the advantages of aluminum. This study investigated the behavior of welded K-joints in lattice girders made of alloy EN AW 6082 T6. The comparison of the experimental and numerical results showed different load-bearing behaviors depending on dimensions and cross-section types. Further tests were carried out. The aim was to derive an aluminum-specific design procedure. Full article

This experimental study was conducted to evaluate the deflection performance of wire-integrated steel deck plates with various end details subjected to cumulative gravity loads. In general, when deck plates are installed in the Republic of Korea, vertical bars are mounted at the ends of the wire-integrated deck plates. However, this process can extend the construction time, thus incurring additional costs. Consequently, this study aimed to examine the structural performance of a deck plate when a lattice foot—rather than a vertical bar—is installed at the end of it. A total of nine specimens were prepared; the experimental variables included the end details, height of the lattice truss girder, and structure type. To evaluate the deflection performance, the cumulative gravity load (as a construction load) and a concrete self-weight were applied to the specimens, and the deflections of each specimen were measured. In the experimental results, the deflection values of the specimen with vertical bars were 0.9~6.1 mm, while those for the specimen without vertical bars were 0.8~5.0 mm. This means that a lattice foot exhibits better deflection performance than conventional end details. Additionally, the deflection of the specimens satisfied the deflection limits required in the relevant standards. Full article

Due to their high cost efficiency and flexibility, semi-precast concrete slabs with lattice girders are widely used in constructions all over the world. Prefabricated concrete slabs, combined with in situ concrete topping, exhibit a quasi-monolithic structural behavior in which lattice girders serve as vertical shear reinforcement and ensure the transfer of longitudinal shear within the interface, acting in combination with concrete-to-concrete bonding mechanisms. To be applicable in industrial and bridge construction, semi-precast slabs need to have sufficient resistance against fatigue failure. To improve and expand the limits of application, theoretical and experimental investigations are conducted at the Institute of Structural Concrete (IMB), RWTH Aachen University. To investigate the fatigue behavior of lattice girders, small size tests with lattice girder diagonals were carried out. These test results have been used to derive an S–N curve (S: stress, N: number of load cycles) for lattice girders for a more refined fatigue design. Subsequently, the fatigue behavior of semi-precast slabs with lattice girders was investigated by fatigue tests on single-span slab segments. The fatigue design regulations of lattice girders according to technical approvals can generally be confirmed by this test program; however, they tend to be conservative. The use of the derived S–N curve leads to significantly improved agreement of fatigue behavior observed in tests and design expressions. Full article

In this study, qualitative tests were carried out to compare the behaviour of selected slabs exposed to short- and long-term loading. Full-scale models of the half-slab and hollow-core slab with dimensions of 6.30 m × 6.30 m, built of four different precast panels, were tested. The first two were semi-precast lattice girder slabs, the third semi-precast prestressed ribbed panels, and the last was composed of hollow-core panels. A common feature was the lack of joint reinforcement and the same modular width of 600 mm. The short-term load was applied sequentially in the first stage, and displacement was measured using an electronic method. In the second stage of long-term testing, the load was mainly applied to one part of the slab. Testing under short-term and long-term load allows determining the change in the performance of panel slabs over time. The panels maintained the ability of load redistribution based on their interaction despite the work of the longitudinal joints being only through the concrete cross-section. The behaviour of slabs with concrete topping shows more significant lateral interactions than elements connected only by shear key. Comparative calculations were made based on four computational models. Comparative analysis showed that the current design procedures lead to a safe but conservative estimation of the slab behaviour. Full article

In this study, on-site bending experiments which represented realistic and pragmatic engineering applications were performed to investigate the resistance, deflection, and cracking process of latticed girder composite slabs. Then, utilizing ABAQUS software, nonlinear finite element (FE) models were established to investigate the behavior of the slabs. The modeling took into account the contact between the precast and cast-in-place concrete interfaces. Additionally, a damage-cracking methodology was introduced to evaluate the crack opening width of the slab. The results demonstrated that the proposed numerical model was capable of reproducing the typical behavior of the composite slabs’ performance analysis. The experimental and numerical results demonstrate that the lattice girder composite slabs conformed to the requirement of existing design codes. Full article

This paper studies the behavior of lattice girder composite slabs with monolithic joint under bending. A full-scale experiment is performed to investigate the overall bending resistance, deflection and the final crack distribution of latticed girder composite slab under uniformly distributed load. A finite element model is given for the analysis of the latticed girder composite slabs. The effectiveness and correctness of the numerical simulations are verified against experimental results. The experimental and numerical studies conclude that the lattice girder composite slabs conform to the requirement of existing design codes. A parametric study is provided to investigate the effects of lattice girder with following conclusions: (a) the lattice girder significantly increases the stiffness of the slab when comparing with the precast slab without reinforcement crossing the interface; (b) the additional reinforcement near the joint slightly increases the stiffness and resistance, while it prevents damage near the joint. Full article

In daily engineering practice, the execution of concrete slabs by the mean of precast floor plates is seen as a common and reliable way to create massive slabs. In the last few decades, however, there has been an evolution to flat slabs and other uses where important bending moments must be transferred over the joints between the floor plates. For this kind of application, there is a lack of knowledge and experimental evidence based on large-scale tests to define accurate failure and design models. In this work, a comprehensive overview is given of 20 large-scale tests and some additional tests to support the findings and observations. It is confirmed that a purely bending-based design of the joints delivers reliable results, but some conditions are set; first, the maximum distance of the lattice girder to the joint may not exceed 400 mm without voiding elements. Second, only a 95 mm distance must be respected with voiding elements or additional protruding reinforcement must be applied. Attention is also given to how the system works when the major components—adhesion, mechanical interlock, and friction—are missing at the interface. Finally, repair possibilities are discussed and how they should be designed. Full article

Under the circumstance of soft fractured surrounding rock with high geo-stress, the support technology of tunnel has become a major challenge. Traditional I-shaped steel and bar lattice girder, which cross-sections are often designed to be left-right symmetrical, may have insufficient strength and stiffness. Based on the concept of symmetry, a new support technology of spatial steel tubular grid (SSTG) arch is designed with high strength and large stiffness. In order to clarify the mechanical properties and failure mechanism of SSTG arch used as primary support, through laboratory and numerical experiments, this paper carries out the bending tests for the circumferential joint of SSTG arch components combined with the excavation tunnel project of Panyu Square Station in Guangzhou, and the analyses of the ultimate bearing capacity, deflection displacement, failure modes, and stress–strain evolution laws of joint components are conducted in detail. The results show that during the whole process of loading, the arch components have experienced elastic growth stage, plastic development stage, and final failure stage. The average ultimate bending capacity of SSTG arches is 340.5 kN·m, and the joint opening is 13.9 mm. The joint form of high-strength bolt + rigid flange plate proposed in the paper has reasonable stress state and high safety redundancy, which can bear the load of surrounding rock effectively, and ensure the safety in tunnel construction. The research results could provide a theoretical basis for the design and application of SSTG arch support in related projects. Full article

Heat-treated high-strength rebar has many advantages, such as high strength, superior ductility, high yield ratio, excellent welding and cold bending performance, which can effectively reduce the amount of rebar and improve the project quality. Although heat-treated high-strength rebar has been successfully applied in many fields of civil engineering, its application in tunnel engineering is just getting started. In this study, the on-site test of axisymmetric heat-treated high-strength lattice girders in rail tunnels and road tunnels was carried out. Comparative analysis of the performance of axisymmetric heat-treated high-strength lattice girders and original-design I20b steel rib was conducted. The test results show that the settlement of high-strength lattice girders is decreased by about 7%~30% compared with the test section of original-design I20b steel rib. The surrounding rock pressure is similar, but the stress of high-strength lattice girders is slightly higher than that of I20b steel rib. Due to the better binding ability of the lattice girders and the concrete, the ultimate bearing capacity of the ‘lattice girders and shotcrete’ is greater than that of the ‘I20b steel rib and shotcrete’. Moreover, the steel consumption of lattice girder is about 36% less than I20b steel rib, which shows significant economic and social benefits. Full article

A worldwide-accepted technique to protect steel lattice girders with welded hollow sections against corrosion is the hot-dip galvanizing process. In this process, vent holes are required in braces to fill the inner part protecting them from corrosion, to allow the immersion of the structure in the zinc bath and to recover the excess fluid after the bath. The cross-section reduction due to the vent hole could lead to a decrease in the effective brace resistance; this is not easily quantified, because there are neither prescriptions nor recommendations in the design codes to assess this effect. Therefore, the hollow structural sections could be underutilized due to doubts regarding the safety of this type of joint. This research was conducted in order to categorize different geometries and positions of vent holes in order to determine the best in terms of joint efficiency. A validated finite element model considering welds on lattice girders joints was extended to take into account different vent hole shapes. This research concludes that the presence of ventilation holes such as the ones considered in this study does not significantly affect the joint resistance, and that all the analyzed hole shapes could be proposed as a valid solution for machining vent holes. The conclusions drawn up from this work could be useful for structural steel designers, providing them with valuable design recommendations. Full article
