Search Results (1,095)

Ensuring friction stir welding (FSW) joint quality typically relies on ultrasonic testing (UT) and radiographic testing (RT), but achieving complete coverage is challenging, and echo-based defect discrimination becomes difficult in dissimilar joints. Laser ultrasonics is a promising non-contact technique that remotely assesses weld quality and provides high spatial resolution at the generation and detection points. This study establishes a laser-ultrasonic method for defect detection in dissimilar Cu–Al FSW joints. Slit-like artificial defects (0.1–2.5 mm deep in 5 mm thick plates) were introduced at the Al-side interface of specimens fabricated with an Al-offset tool. Experiments and numerical simulations were used to evaluate wave modes and irradiation configurations, focusing on intensity-attenuation ratios of specific wave types, including longitudinal and Rayleigh waves. On the non-slit surface, attenuation of reflected longitudinal waves enabled detection of defects ≥0.5 mm deep. On the slit surface, Rayleigh-wave attenuation allowed identification of defects as shallow as 0.1 mm, although slit-side irradiation may be less practical during joining. These results demonstrate that defect identification in dissimilar materials can be achieved by evaluating wave-intensity attenuation rather than relying solely on the presence of reflected echoes, suggesting potential for implementing laser ultrasonics in in-process monitoring of FSW joints. Full article

The adjustable-ring-mode (ARM) scanning laser was used to perform butt welding on 0.5 mm thick TA1 titanium alloy and 304 stainless steel (SS304) thin sheets, with 1.2 mm diameter AZ61S magnesium alloy welding wire as the filling material. Microhardness test results show that the hardness distribution presented a trend of being higher in the base metals on both sides and lower in the middle filling area, with no hardening observed in the weld zone. For all specimens subjected to horizontal and axial weld bending tests, the bending angle reached 108° without any cracks occurring. When the ring power was in the range of 800–1000 W, or the scanning frequency was between 100 and 200 Hz, all the average tensile strengths of the welded joints were more than 80% of that of the AZ61S filling material (approximately 240 MPa); the maximum average tensile strength stood at 281.2 MPa, which is equivalent to 93.7% of the AZ61S. As the ring power or scanning frequency increased further, the tensile strengths of the joints showed a decreasing trend. The remelting effect of the trailing edge of the ARM laser under high energy conditions, or the scouring of the turbulent molten flow induced by the scanning beam, damages the weak links at the newly formed solid–liquid interface and increases the Fe concentration in the molten pool. This leads to a thicker FeAl interface layer during growth, thereby resulting in a decline in the mechanical properties of the welded joints. Full article

Sapphire (α-Al₂O₃) has been widely used in high-power lasers, optical windows, semiconductor substrates, radomes, and other applications due to its exceptional optical properties, high hardness, excellent chemical stability, and thermal resistance. However, machining sapphire poses significant challenges because of the material’s high hardness and brittleness. Traditional mechanical and chemical–mechanical machine methods often fail to meet the processing requirements for micro and nanoscale structures. Recently, the use of femtosecond lasers—with ultra-short pulses and extremely high peak power—has allowed for the precise machining of sapphire with minimal thermal damage, a method akin to cold processing. Femtosecond laser processing offers significant advantages in fabricating three-dimensional micro- and nanoscale structures, surface and internal modification, optical waveguide writing, grating fabrication and dissimilar materials welding. Thus, this paper systematically reviewed the research progress in femtosecond laser processing of sapphire, covering technical approaches such as ablation, hybrid processing and direct writing micro- and nanoscale fabrication. The capability of femtosecond laser processing to modulate sapphire’s optical properties, wettability and mechanical and chemical characteristics were discussed in detail. The current challenges related to efficiency, cost, process standardization and outlines future development directions, including high-power lasers, parallel processing, AI optimization and multifunctional integration were also analyzed. Full article

Air-cooled steel is a high-strength steel widely used in automotive subframe applications. In this study, the microstructural evolution and fatigue performance of air-cooled steel welded joints subjected to a one-step heat treatment and an additional two-step heat treatment were systematically investigated. The results indicate that, after the one-step heat treatment, the microstructure of the welded joints transformed from coarse lath martensite to a mixture of tempered martensite and newly formed martensite. After the two-step heat treatment, the microstructure of the welded joints evolved from coarse lath martensite to newly formed martensite, M-A islands, bainitic ferrite, and a small amount of polygonal ferrite. Under both heat treatment conditions, the fatigue limits of the welded specimens were lower than those of the base metal, which can be attributed to the reduced overall deformation compatibility induced by the welded joints. In addition, the welded joints exhibited superior crack propagation resistance compared with the base metal after both heat treatment processes, which is likely related to the enhanced ability of dislocation structures and grain boundaries to impede crack propagation. Full article

Titanium alloys and copper have broad applications in aerospace, defense, and industry, but their dissimilar welding faces challenges from significant physicochemical differences and easy formation of brittle Ti-Cu intermetallic compounds, while existing methods like laser welding or friction stir welding have limitations, such as low strength or inability to weld ultra-thin plates. This study adopted cold welding to join Ti-6.5Al-1Mo-1V-2Zr alloy and 99.90% pure copper. The mechanical properties of the joint were tested, the microstructure and fracture of the weld were observed, and the phase composition of the weld was analyzed. The results show that the weld fusion zone mainly consists of Cu-based solid solution and Cu₃Ti. Low cold welding heat input reduces the Cu₃Ti content, so the joint mechanical properties do not decrease significantly. The tensile strength of the joint reaches 284 MPa, which is 83% of that of copper-based metals, and the elongation rate reaches 6.25%. Diffusion kinetics and solidification thermodynamics analyses confirm that Cu₃Ti intermetallic compounds are preferentially generated in the weld seam. Full article

In aerospace manufacturing, laser welding of TC4/TA18 dissimilar titanium alloys in bottom-locking configurations is essential for lightweight design, yet the residual stress behavior of such joints remains insufficiently understood. This study systematically examines the influence of laser power on residual stress distribution in laser-welded TC4/TA18 bottom-locking tubular joints. Welded specimens were fabricated at three distinct laser power levels (600 W, 800 W, and 1000 W). Experimental characterization included macroscopic morphology analysis and residual stress measurement using the blind-hole drilling method, among other techniques. Concurrently, a three-dimensional thermo-elastic-plastic finite element model was established based on ABAQUS 2022 to simulate the transient temperature field and stress–strain field during the welding process. The results indicate that due to the differences in thermophysical properties between the two titanium alloys and the wall thickness effect, both the temperature field and residual stress distribution of the TC4/TA18 dissimilar titanium alloy bottom-locking joints exhibit significant asymmetry. Laser power exerts a selective influence on the residual stress field: within the parameter range of this study, increasing laser power can significantly reduce the peak hoop stress of TA18 thin-walled tubes and TC4 thick-walled tubes, as well as the peak axial stress of TC4 thick-walled tubes, while remarkably increasing the peak axial stress of TA18 thin-walled tubes. The numerical simulation results are in good agreement with the experimental data, verifying that the established finite element model is an effective tool for predicting welding outcomes. Full article

The laser welding of 4 mm thick Ti80 alloy under different powers was analyzed, and the weld morphology, microstructure, and mechanical properties were studied. A simulation model was established based on ABAQUS, and laser welding simulations were conducted using 2520 W and 3000 W laser welding power sources to analyze the temperature field and stress field, which were verified by experiments. The increase in power changed the weld morphology from Y-shaped to X-shaped and affected the number of pores in incomplete and complete penetration. The microstructure in the weld zone presented fine acicular α′ phase. Subsequently, grain boundary distribution maps, Kernel Average Misorientation (KAM) maps, and geometrically necessary dislocation (GND) density maps were generated through electron backscatter diffraction (EBSD) analysis. These comprehensive data visualizations enabled multi-dimensional investigation, establishing and analyzing correlations between laser welding parameters, microstructural evolution, and mechanical properties in Ti80 titanium laser welding. The hardness of the base material was 320 HV to 360 HV, and it increased from 420 HV to 460 HV in the weld zone. At 3000 W, the tensile strength reached 903.12 MPa, and the elongation was 10.40%, indicating ductile fracture. The simulation results accurately predicted the maximum longitudinal residual stress in the weld zone, with an error of 1.65% to 1.81% of the measured value. Full article

Assurance of the integrity of every weld joint is highly desirable, and defect detection methods that can be applied to welds at high temperatures immediately after welding are required. The laser ultrasonic (LU) method, which generates ultrasonic waves in the target via pulsed laser irradiation, is a well-known technique for non-contact defect detection during welding. Ultrasonic waves excited in ablation mode exhibit large amplitudes and predominantly surface-normal propagation, which has driven extensive research into their application for weld inspection. However, owing to the size and weight of conventional equipment, such systems have largely been limited to bench-top experimental setups. To address this, we developed an LU robotic system incorporating a compact, lightweight laser source and an improved signal-processing system. We conducted experiments to measure signals and to detect backside slits in flat plates and blowholes in lap-fillet welds. Additionally, a method to improve the sensitivity of laser interferometers was investigated and demonstrated on smut-covered areas near weld beads. Full article

This study systematically investigates the behavior of droplet transfer and the characteristics of weld morphology in laser-cable-type welding wire (CWW) arc hybrid welding under varying Ar-CO₂ shielding gas compositions, utilizing AH36 shipbuilding steel. During the hybrid welding process, a comparative analysis was conducted on the welding process and weld formation using a high-speed camera system and a current–voltage waveform acquisition system. The experimental findings indicated that the arc width exhibited an upward trend, while the arc height demonstrated a decline as the CO₂ content increased. Additionally, the welding current experienced a decrease. Furthermore, the arc became more regular with an increase in the top arc width, which enhanced process stability. The peak intensity of the curve for 90% Ar + 10% CO₂ was the largest, and the peak range was the narrowest, indicating that the current was more stable compared to the other two shielding gas compositions. The droplet transfer frequency exhibited a decreasing trend with the increase in CO₂, while the diameter initially decreased and then increased. As the CO₂ content increased, the droplet transfer mode transitioned from a mixed mode involving both globular transfer and short circuits to predominantly globular transfer. The increase in CO₂ promoted weld penetration while reducing its width, with the penetration depth of the weld increasing by 12.3% when the CO₂ content rose to 18%. Full article

This study investigated the use of oscillating laser welding with Cu, Mo, and Nb interlayers to mitigate the issue of brittle intermetallic compound (IMC) formation in titanium-steel dissimilar welding for TC4/304SS lap joints. This study systematically examined the influence of interlayer type on joining mechanisms, microstructure, and mechanical properties. Results indicated that direct welding produced Ti-Fe IMCs (TiFe phase) through fusion, resulting in a thick brittle layer. The Cu interlayer facilitated fusion welding while promoting the formation of TiFe₂ and TiCu₄ phases. Mo and Nb interlayers, through fusion-brazing and brazing mechanisms, respectively, inhibited Ti-Fe IMCs by generating Fe-Mo/Nb IMCs and (Ti, Mo/Nb) solid solutions. Mechanical testing indicated that Mo-interlayer joints exhibited the highest shear strength at 1129.53 N, representing a 31% increase relative to direct joining. This was followed by Nb at 1004.4 N, Cu at 871.6 N, and direct welding at 859.13 N. Fracture transitioned from brittle IMC layers in Cu and direct welding to interfaces between interlayers and TC4 in Mo and Nb systems. This study presents Mo/Nb interlayers as the most effective choice for high-strength Ti-steel joints, providing insights for the selection of interlayers in engineering applications. Full article

In this study, with the rapid development of the field of rail vehicles, the laser welding process with high energy and small thermal deformation is selected, which reduces the working hours of post-welding grinding, repainting, and other processes, and ensures the industrial design requirements of the beautiful body after welding. The welding process for the non-penetration laser lap welding of SUS301L stainless-steel plates was optimized to address the problem of welding marks on the outer surface of railway vehicle car bodies. The impact of laser power, welding speed, and defocusing amount on weld penetration and tensile shear load was investigated using the response surface methodology. The results showed that the optimal response model for tensile shear load was the linear model, while the optimal response model for weld penetration was the 2FI model. The defocusing amount had the greatest influence on tensile shear load and weld penetration. When the laser power was 1.44 kW, the welding speed was 15 mm/s, and the defocusing amount was −4 mm, the tensile shear load reached its maximum by prediction. The actual tensile shear load of welded joints using these parameters was 4293 N with an error of merely 0.31% relative to the predicted value. The shear strength of laser-welded joints was measured at 429.3 N/mm, meeting the criteria established by the relevant standards. The tensile fracture shows characteristics of brittle fracture. The surface of the welded joints was bright white and well-formed, while the back side of the lower plate exhibited no signs of melting or welding marks. The microstructure of the weld zone (WZ) exhibited irregular columnar austenite and plate-like ferrite, while the heat-affected zone (HAZ) comprised columnar austenite and elongated bars or networks of δ-ferrite. The small-angle grain in welded joints can reduce grain boundary defects and mitigate stress concentration. After welding, angular deformation occurred, resulting in a residual stress distribution that shows tensile stress near the weld and compressive stress at a distance from the weld. Full article

This paper reviews tab-to-busbar interconnections in lithium-ion battery packs, focusing on resistance welding (RW), laser beam welding (LBW), and ultrasonic welding (USW). The functional roles of tabs and busbars and typical material choices (Al-, Cu-, and Ni-plated Cu) are outlined. Subsequently, the processes are compared in terms of heat input, interfacial metallurgy, electrical resistance, mechanical robustness, and manufacturability. USW, as a solid-state method, suppresses porosity and limits Al-Cu intermetallic growth, but is sensitive to thickness, stack geometry, and tool wear. LBW enables high-speed, automated production with precise energy delivery, yet requires careful control to mitigate spatter, porosity, and brittle IMCs in dissimilar joints. RW remains cost-effective and flexible but can suffer from electrode wear and variability with highly conductive stacks. This review also summarizes the effect of the busbar material (Al versus Cu) and thickness on the connection resistance and temperature increase under a high current. No single process is universally superior, and the selection should match the stack-up, reliability targets, and production constraints. This paper aims to provide an overview of recent and conventional research trends for each welding method and to introduce selected non-traditional approaches, thereby presenting a range of viable options for future applications. Full article

In the context of Industry 4.0, new methods of manufacturing, monitoring, and data generation related to industrial processes have emerged. Over the last decade, a new method of part manufacturing that has been revolutionizing the industry is Additive Manufacturing, which comes in various forms, including the more traditional Fusion Deposition Modeling (FDM) and the more innovative ones, such as Laser Metal Deposition (LMD) and Wire Arc Additive Manufacturing (WAAM). New technologies related to monitoring these processes are also emerging, such as Cyber-Physical Systems (CPSs) or Digital Twins (DTs), which can be used to enable Artificial Intelligence (AI)-powered analysis of generated big data. However, few works have dealt with a comprehensive data analysis, based on Digital Twin systems, to study quality levels of manufactured parts using 3D models. With this background in mind, this current project uses a Digital Twin-enabled dataflow to constitute a basis for a proposed data analysis pipeline. The pipeline consists of analyzing metal AM-manufactured parts’ surface roughness quality levels by the application of a Deep Neural Network (DNN) analytical model and enabling the assessment and tuning of deposition parameters by comparing AM-built models’ 3D representation, obtained by photogrammetry scanning, with the positional data acquired during the deposition process and stored in a cloud database. Stored and analyzed data may be further used to refine the manufacturing of parts, calibration of sensors and refining of the DT model. Also, this work presents a comprehensive study on experiments carried out using the CW-GTAW (Cold Wire Gas Tungsten Arc Welding) process as the means of depositing metal, resulting in hollow parts whose geometries were evaluated by means of both 3D scanned data, obtained via photogrammetry, and positional/deposition process parameters obtained from the Digital Twin architecture pipeline. Finally, an adapted PointNet DNN model was used to evaluate surface roughness quality levels of point clouds into 3 classes (good, fair, and poor), obtaining an overall accuracy of 75.64% on the evaluation of real deposited metal parts. Full article

This study presents the results of laser beam welding of dissimilar high-alloy super stainless steels. Differences in their thermal and mechanical properties pose significant challenges in manufacturing processes. The present work demonstrates the potential advantages of using 309L filler material in laser welding of high-alloy materials with different properties. The research focuses on a comparative evaluation of the effects of 309L filler metal on the TP904L—TP347 joint in terms of joint strength and microstructure. The analysis of the joints provides insight into the role of the filler metal in improving joint properties. The obtained results show that both welds exhibit a similar microstructure composed of pillar, cellular, and equiaxed dendrites; however, they differ in dendrite growth orientation, calculated ferrite number (FN), the G/R ratio, and dendrite arm spacing, indicating a lower thermal gradient in the joint welded with filler metal. The results also reveal the presence of precipitates in the welds near the TP904L steel fusion line, most likely Cr₂₃C₆ type. Mechanical properties evaluation, based on standard and miniaturized tensile tests as well as hardness measurement, shows that the use of 309L filler metal improves both the joint strength and ductility, although it does not significantly affect the material hardness. Full article

Solidification cracking is a critical defect in Cu–steel dissimilar laser welding for cylindrical lithium-ion battery busbar assembly, yet the metallurgical role of phosphorus (P) in crack formation has not been quantitatively established. In this study, the influence of phosphorus in the coating layer on weld solidification behavior was clarified by preparing Cu substrates with four different coating conditions—Ni–P-coated Cu (10 and 50 μm) and pure Ni-coated Cu (10 and 50 μm)—and performing high-speed single-mode fiber-laser welding under identical heat-input conditions. Shear-tensile testing, EPMA-based microstructural analysis, and Thermo-Calc solidification calculations were combined to correlate P segregation with solidification cracking susceptibility. The Ni–P 10 μm coating generated severe solidification cracking compared with the pure Ni 50 μm coating, which was attributed to excessive P enrichment in the terminal liquid phase (up to 8.8 mass%). This enrichment significantly expanded the mushy-zone width to approximately 869 K, yielding a highly solidification crack-susceptible fusion zone. In contrast, 50 μm pure Ni coatings produced narrow mushy-zone widths (200–400 K) and extremely low residual P levels (~0.1 mass%), resulting in fully crack-free microstructures. The 50 μm Ni coating exhibited the highest shear-tensile strength and largest rupture displacement among all conditions, confirming that suppression of P segregation directly improves both structural integrity and mechanical performance. Overall, this study demonstrates that phosphorus enrichment critically governs the solidification-cracking susceptibility of Cu–steel dissimilar welds by widening the solidification temperature range. Eliminating P from the coating layer and applying an adequately thick pure Ni coating constitute highly effective strategies for achieving crack-free, mechanically robust welds in lithium-ion battery busbar manufacturing. Full article
