Search Results (272)

Bending-dominated lattice structures offer superior stability but suffer from low stiffness and natural frequencies, posing resonance risks in aerospace applications. To address this, a novel Membrane-Wrapped Lattice (MWL) encapsulated by a micrometer-scale metallic film is proposed. A theoretical framework based on the tension-compression asymmetry of the membrane is established to analyze the influence of membrane thickness on the neutral axis shift, ultimately deriving analytical formulations for flexural stiffness and natural frequencies. MWL specimens with varying membrane thicknesses (0–50 μm) were fabricated via selective laser melting and adhesive bonding, then subjected to three-point bending and vibration tests. Results demonstrate that wrapping with a 50 μm 316 L stainless steel membrane increases the flexural stiffness by 128% and the fundamental natural frequency by 85%. The experimental measurements align well with theoretical and numerical predictions, validating this lightweight, high-stiffness design strategy. Full article

The performance of a four-frequency differential laser gyroscope (FFDLG) is severely affected by the magnetic field. In this paper, the following conclusions are discussed through theoretical analyses and experimental data: First of all, the Zeeman effect cannot fully explain the magnetic effect on the gain region due to the plasma movement. Secondly, an FFDLG does not have a unique optimal operating point where the gyroscope is not affected by any magnetic field. Plasma movement driven by Lorentz force induces a Fresnel drag effect, leading to a frequency imbalance and magnetic error in the ring laser gyroscope (RLG). This mechanism, involving the interaction between moving gain media and the counter-propagating beams, was missed in previous research. Full article

The Atomic Clock Ensemble in Space (ACES) mission, currently operating aboard the International Space Station (ISS), is designed to provide high-precision time and frequency measurements and to test fundamental aspects of relativistic physics. Gravitational redshift (GRS), a fundamental prediction of General Relativity (GR), implies that clocks positioned at different gravitational potentials experience relative time dilation. Previous GRS experiments have focused primarily on microwave technologies, with negligible experimental coverage in the optical domain, particularly for ground-to-space links. Motivated by the European Laser Timing (ELT) experiment and the high-precision laser-cooled cesium clock aboard ACES, we introduce and evaluate an optical time-transfer method designed to achieve high-accuracy measurements of GRS. In the absence of actual ELT/ACES optical data, a high-fidelity numerical simulation framework was developed to assess the performance of this method. The framework incorporates representative ELT/ACES mission parameters, including the space-based cesium clock and the H-MASER clock located at the reference ground station, both providing frequency stability at the level of ${10}^{-15}$ for 1000 s averaging time. Applying a $\pm 1\sigma$ filtering criterion, we obtain a simulated dataset comprising 33 ELT/ACES passes, representing a total observation time of 4.38 h over a single week. Analysis of this high-fidelity dataset reveals a GRS deviation from GR of $(-7.19\pm 0.63)\times {10}^{-5}$, achieving a 3.4 orders of magnitude improvement over the best previous laser-ranging experiment conducted at the University of Maryland (UMD), USA, 51 years ago. These simulation results demonstrate that the optical time-transfer link constitutes a powerful tool for testing fundamental physics and, when combined with next-generation optical atomic clocks, enables unprecedented capabilities in space-based timekeeping and geoscience applications. Full article

A robust and cost-effective fiber-optic ultrasound sensor based on a slope-symmetric Fabry–Perot interferometer (FPI) is presented, employing dual-channel quadrature-biased heterodyne interrogation with an acousto-optic modulator (AOM). By introducing a 200 MHz frequency shift that yields an effective π/2 phase offset between the direct (unshifted) and frequency-shifted optical paths, the system ensures complementary sensitivity: when one channel operates at zero slope on the FPI transfer function (minimum sensitivity), the other resides at maximum slope, providing inherent immunity to laser wavelength drift and environmental perturbations. Experimental validation demonstrates reliable ultrasound detection across varying operating points. At quadrature extremes, one channel achieves peak amplitudes of ±2 V while the other is quiescent, whereas intermediate points enable simultaneous detection with amplitudes of ±1.5 V (AOM channel) and ±0.05–0.1 V (direct channel), accompanied by corresponding DC levels ranging from ~0.4 V to 1.6 V. The AOM channel utilizes simple envelope detection after 9.5–11.5 MHz bandpass filtering, maintaining low cost, though coherent mixing is suggested for enhanced weak-signal performance. The angle-symmetric FPI design, combined with gold-disk reflector adaptations and potential femtosecond laser micromachining, further reduces fabrication costs without sacrificing finesse or sensitivity. This quadrature-biased approach offers superior stability compared to single-channel systems, making it highly suitable for practical applications in photoacoustic imaging, nondestructive testing, and structural health monitoring. Full article

In the manufacturing process of advanced integrated circuits, electron beam inspection equipment is crucial for yield assurance, while vibration poses a core challenge affecting its precision and speed. Vibrations in production line equipment are mostly multi-frequency; However, research findings in this field remain limited. Moreover, existing compensation schemes often struggle to meet industrial-grade precision and real-time requirements. This paper presents the design and implementation of a high-speed electron beam vibration compensation system based on positioning. The system incorporates state-of-the-art laser positioning and electrostatic scanning deflectors, and features an integrated signal processing and compensation signal output module. The study involved improvements and optimizations to the positioning processing analysis and compensation module, control software and algorithms, and calibration software and algorithms, demonstrating superior performance compared to existing methods. System validation data demonstrates that the proposed scheme effectively compensates for both single-frequency and multi-frequency disturbances at frequencies below 200 Hz, achieving an average attenuation of 50% to 90% and a repetitive compensation accuracy of less than 0.3 nm. These metrics meet the industrial application requirements for electron beam inspection equipment. The overall error in long-term repeatability tests complies with the stability demands of industrial production lines, confirming its practical applicability in production environments. Full article

Sustainable feedstock management remains a major challenge in laser beam powder bed fusion (PBF-LB), where conventional reuse strategies are typically limited to sieving and blending rather than full material regeneration. Ultrasonic atomization (UA) offers a fundamentally different powder production route based on capillary-wave instabilities induced at the surface of a molten metal by high-frequency vibrations. In contrast to turbulence-driven atomization, droplet formation in UA is primarily governed by ultrasonic frequency and intrinsic thermophysical properties of the melt, enabling quasi-deterministic particle formation with high sphericity and reduced satellite formation. In this study, ultrasonic atomization was investigated as a closed-loop route for converting PBF-LB-manufactured 316L stainless steel parts into reusable powder. Printed rods were remelted and atomized under controlled variation of electric current and vibration amplitude. The resulting powders were characterized in terms of morphology, internal microstructure, particle size distribution, chemical composition, and gas impurity content. UA produced highly spherical particles with reduced internal porosity and improved flowability compared to the initial gas-atomized powder, while preserving the principal alloying elements. An increase in oxygen content was observed after recycling, attributed to selective high-temperature oxidation under residual oxygen in nominally inert conditions. The results establish a mechanistic framework for transforming consolidated PBF-LB material into secondary feedstock and identify key parameters governing structural and compositional stability in closed-loop recycling. Full article

This paper proposes a method to generate a low-noise 10.23 MHz time-frequency reference signal based on high-order harmonic locking of the repetition rate (f_r) of an optical frequency comb (OFC). An all-polarization-maintaining (PM) Erbium-doped fiber laser with a 122.76 MHz f_r is constructed using the nonlinear amplifying loop mirror (NALM) principle. By applying a feedback control to the intracavity piezoelectric actuator (PZT) and electro-optic modulator (EOM), the 10th harmonic of f_r is phase-locked to a high-performance rubidium atomic clock (Rb clock), achieving low-noise conversion from the Rb clock to the target signal. Experimental results show that the generated 10.23 MHz signal exhibits residual phase noise of −123.4 dBc/Hz at 1 Hz offset and −158 dBc/Hz at 1 MHz offset, and achieves a residual frequency stability of 3.52 × 10⁻¹³ @ 1 s and 3.65 × 10⁻¹⁵ @ 10,000 s. This harmonic locking scheme validates the advantages of photonic microwave generation in achieving ultra-low phase noise while preserving the long-term stability of atomic clocks, providing a strategic solution for next-generation BeiDou Navigation Satellite System (BDS) time-frequency payloads. Full article

In this paper, a novel symmetrical three-wavelength toggling archetype for measuring the concentration of gases using a tunable diode laser absorption spectroscopy (TDLAS) system is introduced and demonstrated. The system was operated at 1.5714 µm with a 2 kHz update rate, targeting an absorption line of gaseous CO₂. Precompensated diode–current pulses are introduced to offset the inherent thermal time constants of the diode laser by orders of magnitude. Here, repetition rates matching that of contemporary methods can be achieved, while simultaneously providing a noteworthy wavelength stability of 0.6 pm for the three targeted wavelengths that are approximately 70 pm apart (142 pm maximum wavelength excursion). A 10 Hz current loop locks one of the wavelengths to a CO₂ absorption peak, thus providing an absolute and stable wavelength reference. The flexibility in choosing the shape and repetition frequency of the current pulses makes this approach easily adaptable to other gases and/or absorption lines, since wavelength filters are avoided. The new method is benchmarked against a two-wavelength precompensated continuous-wave TDLAS technique, revealing a fourfold improvement in reproducibility with system restart over the span of 24 days, while outperforming other widespread spectroscopic techniques applied to comparable transmittance levels. The effect of the analytical model was further studied by thermally inducing baseline changes, showing a 7.9 ± 0.2 times weaker correlation between concentration and temperature with respect to the one observed using the two-wavelength TDLAS archetype. These results demonstrate the system’s suitability for sensitive applications. Full article

Formaldehyde (H₂CO) is a hazardous volatile organic compound widely present in indoor and industrial environments, and its real-time, highly sensitive detection is essential for environmental safety. However, existing detection techniques often face challenges in simultaneously achieving high sensitivity and long-term stability, and many conventional photoacoustic spectroscopy (PAS) systems rely strongly on low gas flow rates to suppress flow-induced noise, which limits their applicability for continuous online monitoring. In this work, an ultraviolet photoacoustic spectroscopy (UV-PAS)-based H₂CO detection system operating in a nitrogen (N₂) background is developed. The system integrates a compact differential photoacoustic cell (PAC) with a 320 nm ultraviolet laser source, in which the resonator length and buffer configuration are carefully optimized to enhance acoustic resonance and effectively suppress flow-related disturbances. Notably, a key innovation of this study is that the system maintains a stable photoacoustic response even under relatively high gas flow conditions. Experimental results demonstrate that at a flow rate of 250 sccm, the photoacoustic signal amplitude remains stable, and the noise level is well controlled, significantly reducing the dependence of conventional PAS systems on low-flow operation. The photoacoustic cell exhibits a resonant frequency of 1767 Hz and a quality factor of 46. Calibration using a 47.31 ppm H₂CO:N₂ gas mixture shows a good linear response with a correlation coefficient of R² = 0.98844. The minimum detection limit reaches 2.50 ppm at a 1 s integration time and is further improved to 88.1 ppb at an integration time of 2202 s based on Allan–Werle deviation analysis. These results demonstrate that the proposed UV-PAS system provides a sensitive, stable, and cost-effective solution for real-time trace H₂CO detection while retaining robust performance at elevated gas flow rates, highlighting its strong potential for practical applications. Full article

This paper presents a stochastic framework for the inverse identification of structural material degradation (SMD) in cantilever beams. The method combines the Karhunen–Loéve (KL) expansion for the efficient parameterisation of spatially varying material decay with experimental Frequency Response Function (FRF) data within a Bayesian inference scheme. This approach employs a low-dimensional spectral parameterisation via the KL expansion, which mitigates the curse of dimensionality inherent in element-wise model updating, and provides a full-field probabilistic description of SMD. A two-phase constraint strategy was developed to address the fundamental tension between physical plausibility and algorithmic stability of the inverse identification algorithm: (1) physical regularisation during identification stabilises the ill-posed inverse problem, and (2) post-convergence selective regularisation eliminates physically impossible stiffness enhancements (exceeding 1.1 × baseline) that arise from measurement and modelling uncertainties. This phased approach prevents the algorithm distortion that occurs when constraints are applied too stringently during iteration, while ensuring final results respect fundamental physical principles. The framework is experimentally validated on a steel cantilever beam with a symmetric open-edge cut. Laser vibrometry measurements under swept-sine excitation demonstrate successful localisation and quantification of SMD, with the 95% credible interval accurately capturing the damaged region after physical constraint application. The adaptive constraint strategy resolves the delicate balance between mathematical stability and physical plausibility in inverse identification. Full article

The integrated III-V self-injection locked (SIL) laser exhibits excellent linewidth compression, noise reduction, and frequency stability. However, the laser’s low efficiency and fluctuating output power severely limit its applications in optical coherent transmission, light detection and ranging (LiDAR), spectroscopy, and so on. Based on the rate equations for a semiconductor laser coupled to counter-propagating fields in a micro-ring resonator (MRR), we systematically investigate the laser power and linewidth compression under self-locking conditions. We improve the slope efficiency by adjusting the injection phase, diode–MRR coupling efficiency, the normalized mode-coupling rate between clockwise (CW) and counter-clockwise (CCW) modes, and the MRR Q-factor. The results show that the enhanced diode–MRR coupling efficiency effectively increases the laser slope efficiency and improves the stability of the injection phase and feedback intensity. The injection phase significantly influences the range of the self-injection locked state. The normalized mode-coupling rate effectively affects the locking bandwidth and maintains stable power transfer. The MRR intrinsic Q-factor has a positive correlation with improving the laser slope efficiency and compressing the linewidth. Full article

Frequency stability of a 509-nm single-frequency laser, a core component combined with an 852-nm single-frequency laser for two-step cesium Rydberg transitions, is critical for quantum control and metrology precision. Utilizing atomic transition as the absolute reference, we achieved laser frequency locking via modulation-free Rydberg two-color polarization spectroscopy (Rydberg–TCPS) and frequency-modulated Rydberg electromagnetically-induced transparency (Rydberg–EIT) spectroscopy with discrete instruments combination and with Red Pitaya FPGA module. The results show that the Red Pitaya FPGA module matches discrete instruments combination in stability, being more compact and only one-tenth the cost. Rydberg–TCPS scheme avoids modulation-induced noise and linewidth broadening, outperforming Rydberg–EIT scheme. The Red Pitaya FPGA module provides a cost-effective, compact solution for Rydberg research, lowering experimental barriers. Full article

The single-step Rydberg excitation of cesium atoms requires a 319 nm ultraviolet laser with a narrow laser linewidth, high frequency stability, and high output power. To meet these requirements, in this work, we construct a high-power, single-frequency UV laser system at this wavelength. In this system, the frequency stabilization of the 1560.492 nm seed laser is critical to the performance of the ultraviolet laser. We employ nonlinear frequency conversion technology, the 1560.492 nm laser is frequency-doubled to 780.246 nm via a single pass through a PPLN crystal, and function integration is realized based on the modular parameter adjustment interface provided by the PyRPL software. Subsequently, the 1560.492 nm laser is stabilized to the $D_2$ hyperfine transition line of Rb-87 atoms using polarization spectroscopy (PS) and radio-frequency-modulated saturation absorption spectroscopy (RF-SAS). A comparative study of these two techniques shows that RF-SAS achieves superior stabilization performance, with the residual frequency fluctuation of the frequency-doubled laser being 1.07 MHz over 30 min. According to frequency doubling theory, the actual residual frequency fluctuation of the 1560.492 nm fundamental-frequency laser can be calculated as 0.535 MHz. Compared with our earlier scheme that utilized an ultra-low-expansion (ULE) optical cavity as a frequency reference, the present scheme eliminates the long-term drift induced by environmental factors. In contrast to frequency stabilization relying on discrete instruments, this integrated scheme significantly reduces the cost, simplifies the system architecture, saves space, and greatly enhances the flexibility and controllability of the system. It therefore provides a reliable and cost-effective solution to ensure the portability and practicability of high-performance UV laser sources. This high-precision frequency stabilization scheme directly guarantees the performance of the 319 nm UV laser, suppressing its linewidth below 10 kHz. Thus, it fully meets the stringent laser linewidth and frequency stability requirements for the single-step Rydberg excitation of cesium atoms and provides a reliable light source foundation for subsequent precision spectroscopic measurements. Full article

The structure–property relationship of chitin nanofibrils (NCh) with tailored lengths (L-, M-, S-NCh) and their efficacy in stabilizing Pickering emulsions were systematically investigated. The nanofibrils, produced via high-pressure homogenization and ultrasonication (20 or 60 min), were characterized by transmission electron microscopy (TEM). Emulsion stability was predominantly governed by nanofibril length and concentration, with S-NCh (shortest) exhibiting superior performance, as evidenced by its minimal creaming index, smallest droplet size (1.18 μm at 0.5%), and homogeneous microstructure observed by confocal laser scanning microscopy (CLSM). A critical stabilizer concentration of 0.05% was identified, below which instability occurred due to insufficient interfacial coverage. Rheological analysis confirmed shear-thinning behavior and solid-like viscoelasticity at high frequencies. CLSM microstructural observations directly confirmed nanofibril adsorption at the interface and the formation of a continuous network between droplets, elucidating the stabilization mechanism. These findings demonstrate that shorter chitin nanofibrils provide a marked improvement in emulsion stability, offering a superior biomass-derived alternative for the design of stabilizers in food and pharmaceutical applications. Full article

This study systematically investigates the behavior of droplet transfer and the characteristics of weld morphology in laser-cable-type welding wire (CWW) arc hybrid welding under varying Ar-CO₂ shielding gas compositions, utilizing AH36 shipbuilding steel. During the hybrid welding process, a comparative analysis was conducted on the welding process and weld formation using a high-speed camera system and a current–voltage waveform acquisition system. The experimental findings indicated that the arc width exhibited an upward trend, while the arc height demonstrated a decline as the CO₂ content increased. Additionally, the welding current experienced a decrease. Furthermore, the arc became more regular with an increase in the top arc width, which enhanced process stability. The peak intensity of the curve for 90% Ar + 10% CO₂ was the largest, and the peak range was the narrowest, indicating that the current was more stable compared to the other two shielding gas compositions. The droplet transfer frequency exhibited a decreasing trend with the increase in CO₂, while the diameter initially decreased and then increased. As the CO₂ content increased, the droplet transfer mode transitioned from a mixed mode involving both globular transfer and short circuits to predominantly globular transfer. The increase in CO₂ promoted weld penetration while reducing its width, with the penetration depth of the weld increasing by 12.3% when the CO₂ content rose to 18%. Full article
