Search Results (52)

For the past few decades, during each disastrous earthquake, severe damage and poor seismic performance of masonry infilled RC frames, including many newly designed ones, have been reported extensively. Inherent problems related to analysis and design methods for tight-fit infilled frame structures have not yet been solved and are recognized as being far from satisfactory in terms of completeness and reliability. The primary objective of this research was to propose and test an innovative method that can effectively mitigate undesirable interaction damage to masonry infilled RC frame structures. This proposed technical solution consists of connection of the infill panel to the bounding columns with steel reinforcement connections deployed in mortar layers and anchored to the columns. This is practical, cheap and easy to implement without any specific technology, which is especially important for developing countries. A three story, two bay RC building model with the proposed connection implemented on the infill walls was designed and tested on the shake table at IZIIS in Skopje, N. Macedonia. The test results and design guidelines/recommendations from the proposed research are also expected to benefit the infrastructural development in other countries threatened by earthquakes, preferably in the Balkan and the Mediterranean region. Full article

This study investigates the acoustic and mechanical performance of three types of 3D-printed polylactic acid (PLA) panels with varying infill densities (5–100%) and structural configurations. Using fused filament fabrication (FFF), panels were designed as follows: Type 1 (core infill only), Type 2 (core infill + 1.6 mm shell), and Type 3 (core infill + multi-layer shells). Acoustic testing via impedance tube revealed that Type 2 panels with a 65% infill density achieved the highest sound absorption coefficient (α = 0.99), while Type 1 panels exhibited superior sound transmission loss (TLn = 53.3 dB at 60% infill). Mechanical testing demonstrated that shell layers improved tensile and bending resistance by 25.7% and 36.9%, respectively, but reduced compressive strength by 23.6%. Microscopic analysis highlighted ductile failure in Type 2 and brittle fracture in Type 3. The optimal panel thickness for acoustic performance was identified as 4 mm, balancing material efficiency and sound absorption. These findings underscore the potential of tailored infill parameters in sustainable noise-control applications. Full article

This study addresses the unique challenge of the partition walls in subway stations, featuring high height, fire prevention, and located outside the main frames, by introducing a confined autoclaved aerated concrete (AAC) panel wall system. Different from studies on a main frame with infill walls, this study aimed to explore the seismic performance of partition walls, which were fabricated with confined high AAC panel walls and located outside the main frames. A custom-designed partition wall, measuring 6600 mm in height, 3400 mm in width, and 200 mm in thickness, underwent cyclic testing. A detailed analysis of specimen’s failure modes was conducted, focusing on seismic behavior such as hysteresis curves, envelope curves, ductility, stiffness degradation, and energy-dissipation capacity. Additionally, the study delved into shear deformation, relative slippage between AAC panels, and reinforcement strains within the specimen. Finally, the D-value method for calculating the initial stiffness of the confined high AAC panel walls and the weak sub-structural approach for determining the load-bearing capacity of confined high AAC panel walls were proposed and validated. The results indicate that the strength degradation factor of the confined high AAC panel walls ranges from 0.971 to 0.716. The drift of its upper portion accounts for 76.94–83.63% of the total drift, while the energy dissipation factor of its upper portion is 0.8–4.8% higher than that of the entire specimen. The yield and ultimate drift rotations of the entire confined high AAC panel wall and its upper portions satisfy the elastic and elastic-plastic inter-story drift rotation limits specified in the Chinese code. The calculated initial stiffness of the confining frame, obtained using the D-value method, closely aligns with experimental results, with a deviation of only 2.48%. Additionally, the load-bearing capacity calculated using the weak sub-structural approach deviates from the experimental average by just 4.30%. Full article

This study explores the flexural behavior of continuous fiber-reinforced composite sandwich structures built entirely using material extrusion additive manufacturing. The continuous fiber additive manufacturing system used in this study works sequentially, thus enabling the addition of fiber reinforcement just in the face sheets, where it is most effective. Three-point bending tests were carried out on sandwich panel specimens built using thermoplastic reinforced with continuous glass fiber to quantify the effect of fiber reinforcement and infill density in the flexural properties and failure mode. Sandwich structures containing continuous fiber reinforcement had higher flexural strength and rigidity than unreinforced sandwiches. On the other hand, an increase in the lattice core density did not improve the flexural strength and rigidity. The elastic modulus of fiber-reinforced 3D-printed sandwich panels exceeded the predictions of the analytical models; the equivalent homogeneous model had the best performance, with a 15% relative error. However, analytical models could not correctly predict the failure mode: wrinkle failure occurs at 75% and 30% of the critical load in fiber-reinforced sandwiches with low- and high-density cores, respectively. Furthermore, no model is currently available to predict interlayer debonding between the matrix and the thermoplastic coating of fiber layers. Divergences between analytical models and experimental results could be attributed to the simplifications in the models that do not consider defects inherent to additive manufacturing, such as air gaps and poor interlaminar bonding. Full article

Composite materials, particularly carbon fiber-reinforced polymers (CFRPs), have become a cornerstone in industries requiring high-performance materials due to their exceptional mechanical properties, such as high strength-to-weight ratios, and their inherent lightweight nature. These attributes make CFRPs highly desirable in aerospace, automotive, and other advanced engineering applications. However, the compressive behavior of CFRP structures remains a challenge, primarily due to the material sensitivity to structural instability, leading to matrix cracking and premature failure under compressive loads. Isogrid structures, characterized by their unique geometric patterns, have shown promise in enhancing the compressive behavior of CFRP panels by providing additional support that mitigates these issues. Traditionally, these structures are manufactured using automated techniques like automated fiber placement (AFP) and automated tape laying (ATL), which, despite their efficacy, are often cost-prohibitive for small-scale or custom applications. Recent advancements in 3D-printing technology, particularly those involving continuous fiber reinforcement, present a cost-effective and flexible alternative for producing complex CFRP structures. This study investigates the compressive behavior of 3D-printed isogrid structures, fabricated using continuous carbon fiber reinforcement via an Anisoprint Composer A3 printer equipped with towpreg coextrusion technology. A total of eight isogrid panels with varying infill percentages were produced and subjected to buckling tests to assess their performance. The experimental results indicate a direct correlation between infill density and buckling resistance, with higher infill densities leading to increased buckling loads. Additionally, the failure modes were observed to shift from local to global buckling as the infill density increased, suggesting a more uniform distribution of compressive stresses. Post-test analyses using optical microscopy and scanning electron microscopy (SEM) revealed the presence of voids within the 3D-printed structures, which were found to negatively impact the mechanical performance of the isogrid panels. The findings of this study demonstrate that 3D-printed isogrid CFRP structures can achieve significant buckling resistance, making them a viable option for high-performance applications. However, the presence of voids remains a critical issue, highlighting the need for process optimizations in 3D-printing techniques to enhance the overall performance and reliability of these structures. Full article

Semi-Interlocking Masonry (SIM) represents an innovative building system developed at the Centre for Infrastructure Performance and Reliability at the University of Newcastle, Australia. This system employs a unique approach to interlocking mortar-less engineered masonry panels constructed from SIM units. These units are designed to offer substantial energy dissipation capacity, primarily attributed to the friction occurring on the sliding bed joints between the units within the panel during seismic events. The primary aim of this study is to evaluate the viability of incorporating semi-interlocking masonry as infill panels in the construction of multi-story buildings across diverse geographical locations with varying seismic conditions in Australia. To assess the feasibility of SIM panels in different conditions (according to Australian Standard AS1170) in Australia, a comprehensive analysis using Strand7 R3.1.4 is conducted on a three-story structure incorporating traditional masonry infill panels and SIM panels. Displacement and base shear capacities are compared in response to seismic events across various scenarios in different locations within Australia. The insights gained from this comparative analysis contribute valuable information regarding the viability of implementing SIM as a contemporary construction material. Full article

Concrete-encased composite plate shear walls (C-PSW/CEs) can realize the in-plane shear yielding of infill steel plate with the buckling restrained from the concrete panel. Concrete panels also additionally resist portions of lateral loading in C-PSW/CEs, whereby the shear stiffness and strength of the C-PSW/CE are improved. However, research on the in-plane behaviors of concrete panels and the interactions between structural elements is limited. In this paper, the mechanical characteristics and the interactions and the shear resistances of C-PSW/CEs with double-sided concrete encasements were studied. First, the effects of concrete thickness on the damage process, steel plate buckling, and shear resistances of C-PSW/CEs under lateral loading were tested. Then, finite element analyses of the internal forces of the horizontal and inclined cross-sections and the shear force–drift ratio responses of C-PSW/CEs were undertaken with the extended finite element method (XFEM) to simulate the cracking behaviors of concrete panels. A shear force–drift ratio model based on mechanics was developed by considering the lateral load resistances of concrete panels and their effects on steel plates in C-PSW/CEs. Full article

Artificial turf provides a consistent and durable surface; however, it has historically been associated with a high skin injury risk, or a ‘friction burn’, when a player falls or slides. Second-generation surfaces feature a short carpet pile, whilst third generation (3G) carpet piles are longer, enabling the integration of a performance infill. 3G surfaces provide sufficient energy absorption characteristics to be approved as Rugby Turf; however, such pitches can still cause skin injuries, despite being assessed using a friction-based test. Reducing skin injury risk motivates this study to develop a more sensitive testing methodology. A new test apparatus and impactor are proposed, achieving kinematics representative of an elite male rugby tackle. A commercially available skin simulant is employed to ensure the collection of repeatable and valid data. Photography and thresholding were used to assess surface abrasion and material transfer, whilst a thermal camera captured surface temperature change. Accelerometers quantified the surface resistance during the impact and sliding phases. These metrics were compiled into the Maxwell Tribo Index (MTI), providing a single measure of skin injury risk. The results demonstrated good repeatability and validity when four teams tested four different 3G surfaces. These results compared favourably to an expert panel’s ranked order. Full article

Prefabricated panel-assembled wall systems, comprising a confining frame and infill lightweight panels of autoclaved aerated concrete (AAC), are widely employed in framed structures. Different from studies on a main frame with infill walls, this study aimed to explore the seismic performance of partition walls, which were fabricated with AAC panel-assembled walls and located outside of the main frames. Two full-scale specimens, one with a door opening and the other without, were constructed and cyclic loading tests were executed to examine the failure modes, hysteresis characteristics, envelope curves, ductility, strength and stiffness degradation, as well as energy dissipation capacity of the AAC panel-assembled walls. Additionally, a restoring-force model for the panel-assembled walls was developed and a method for predicting the lateral load-bearing capacity of the AAC panel-assembled walls was proposed. The findings indicated that the panels enhanced the system’s lateral resistance, energy dissipation capacity, and deformation capability. The door frame increased the initial stiffness, peak lateral load and energy dissipation capacity of the AAC panel-assembled wall compared to the wall without a door frame. Compared to the specimen without a door frame, the peak lateral load of the specimen with a door frame increased by 19.7–30.1%. The deformation capacity of the panel-assembled walls aligned with the requirements for concrete framed structures. Full article

To evaluate the sound insulation capacity of small panels made of polymeric materials by 3D printing, a Taguchi L18-type factorial experiment with eight independent variables was designed and materialized. The independent variables were the panel thickness, polymer material type, 3D printing speed, infill percent, infill pattern, layer thickness, frequency, and sound volume. Empirical mathematical models were determined through the mathematical processing of the experimental results using specialized software. These empirical mathematical models highlight the meaning and intensity of the influence exerted by the input factors in the process on the acoustic pressure level of the energy absorbed after the passage of sounds through the small panels manufactured by 3D printing from polylactic acid and polyethylene terephthalate glycol. The factor with the strongest influence was the frequency of the sounds, with a maximum of the sound pressure level for a frequency of 13,000 Hz. A polylactic acid panel between the sound source and the sound-receiving sensor reduces the sound pressure level by about 45% from 95.8 to 65.8 dB. The power function type mathematical model in the case of the energy absorbed by the panel highlights the fact that the highest values of the exponents are those attached to the sound frequency (exponent equal to 1.616) and, respectively, to the thickness of the panel (exponent equal to −0.121). Full article

Buildings located in extreme cold climates encounter challenges (e.g., heat loss, condensation, and frozen utilities), especially within their wall envelopes. These challenges also play a pivotal role in occupant health, comfort, and the structural integrity of the building. While the existing literature has primarily focused on thermal performance, this study underscores the importance of evaluating hygrothermal performance within wall envelopes, given the existence of mold growth even in cases of high thermal resistance. Therefore, the aim of this study was to evaluate the hygrothermal performance of an adaptable house wall (AHW) panel that incorporates composite infill panels paired with vacuum-insulated panels to endure harsh cold conditions in Alaska. Therefore, three steps were proposed to: (1) collect the material and thermal properties of the AHW; (2) model the hygrothermal performance of the AHW in WUFI^® PRO v6.7 software; and (3) analyze the results. The results revealed a moderate risk of mold growth in the inner plywood layer of the AHW, whereas the outer plywood layer showed zero risk, indicating an acceptable condition. The findings aid decisionmakers in recognizing potential mold-related issues in building walls before advancing to the construction phase. Full article

Construction industrialization addresses various challenges in the traditional construction industry, enabling building structures to conserve resources and enhance energy efficiency while reducing emissions. Precast shear walls involve the factory-based production of components, followed by transportation to a construction site for assembly. The method of connecting these components is crucial for precast concrete shear wall systems. Common connection methods include lap-spliced connections, post-tensioned connections, welded connections, bolted connections, and sleeve connections. However, challenges such as construction precision and technology proficiency have limited their application. In response, a novel precast concrete shear wall system utilizing angle steel connectors has been proposed. These angle steel connectors enhance the shear resistance of horizontal joints between precast concrete shear walls and the foundation, providing provisional support for specimen positioning and installation. Presently, the seismic performance of this innovative precast shear wall system under the combined actions of cyclic horizontal loads and axial pressure or tension has been extensively investigated. In practical engineering applications, precast concrete shear wall systems are often accompanied by infill walls. However, there is limited research on the seismic performance of precast concrete shear wall systems with infill walls. To address this gap, this study designed and fabricated two novel precast concrete shear walls with different infill wall constructions. One specimen featured an infill wall composed of a single wall panel, while the other had an infill wall consisting of two panels. Pseudo-static tests were conducted on both specimens under constant axial compression. Subsequently, the seismic performance and force mechanism of the two specimens were compared with the novel precast concrete shear walls without infill walls. The test results demonstrated that the specimen with two infill wall panels exhibited superior overall performance compared to the one with a single continuous infill wall panel. Furthermore, it was observed that, during the loading process, the edge columns of specimens with infill walls provided the majority of the increased load-bearing capacity, while the infill walls made a limited contribution to the overall load-bearing capacity of the structures. Full article

An assembled floor system is a main step in the industrialization of construction in civil engineering, where the stiffness and anti-crack properties under designed loads and its self-weight are the main concerns. This paper presents a new type of assembled integral composite floor system, which is composed of precast ribbed bottom slab, lightweight infills, cast-in-situ upper slab and joints. Through the couplers for squeezing and splicing of longitudinal bars, shear keys and cast-in-situ joints between the precast panels and cast-in-situ upper part, the whole hollow floor system could not only exhibit satisfactory mechanical performance, but also lower the self-weight and shorten the construction time. To study its flexural behaviors, a full-scale specimen sized 9.2 m × 9.2 m was designed and tested under static area load. With the load increased to the designed loads of Chinese design code GB50010-2010, mechanical performance (i.e., crack distribution, deformation and stress distribution) were analyzed. To further study its load-carrying capacity and working mechanism, an effective finite element model was established in ABAQUS and compared with experimental and simulation results. It was found that the deflection of the floor under the normal service load and the crack width met the needs of normal use, and the finite element model could serve as a reliable method for the load-carrying capacity calculation. Full article

Reinforced concrete infilled frames have been studied over the years along with the infilled openings. To resist the lateral loads that are applied on the frames, stress is transferred from the reinforced concrete (RC) to infill, which leads to brittle collapse. The conventional interface medium, which was considered by researchers and recent studies, was prepared by changing the interface materials between the RC frame and infill panels to different elastic materials. This study focuses on optimizing the interface pressure using a butyl rubber tube, which reduces the stress distribution to the infill panel from the RC frame. A 50% window opening was adopted in this study, which is the optimized size from previous research. The optimization patterns followed linear and nonlinear patterns, such as the same pressures in all stories and varying pressures in all stories. The third story had a 8 PSI pattern and the other stories had a 2 PSI pattern; all stories with 8 PSI patterns achieved the least displacement when compared to other variations. A monotonic static analysis was performed for both the experimental and analytical study. The boundary conditions were pinned, and coupling interfaces were made for the master and slave surfaces. The pressure conditions were applied in various linear and nonlinear patterns to optimize the pressure. A comparative study was performed on the displacement, stiffness, and drift ratio for the critical position of the interface pressure in both the analytical and experimental studies. The difference was approximately 0.53% in the analytical study and 0.37% in the experimental work. The optimization was performed using both an experimental model and an analytical model, which had an error percentage of 0.61%. Full article

Unreinforced masonry-infilled reinforced concrete frames are a prevalent taxonomy class not only in the Mediterranean region but also in Europe and worldwide, where buildings of this type abound or are ubiquitous. Thus, somewhat expectedly, various earthquake events and sequences have repeatedly shown the poor seismic behaviour of masonry infill walls, which, in turn, have brought into question issues of the variability, uncertainty, and interaction of in-plane (IP) and out-of-plane (OoP) responses. The latter aspect is examined in this paper, which provides a systematic review concerning the conceptualisation and development of numerical macro-models for simulating the behaviour of solid infill wall panels taking their IP–OoP interaction into account. To this end, the most important parameters involved in the cyclic behaviour of unreinforced solid masonry infill walls are addressed first, and then the main models currently available in the literature are scrutinised and key features discussed, with emphasis posed on issues of accuracy/suitability and easiness or level of complexity/sophistication. Full article
