Additive Manufacturing of Fibre Reinforced Polymer Composites

A special issue of Polymers (ISSN 2073-4360). This special issue belongs to the section "Polymer Composites and Nanocomposites".

Deadline for manuscript submissions: 15 November 2024 | Viewed by 14110

Special Issue Editors


E-Mail Website
Guest Editor
School of Traffic & Transportation Engineering, Central South University, Changsha 410075, China
Interests: additive manufacturing; fibre-reinforced polymer composites; composite structure; mechanical property

E-Mail Website
Guest Editor
School of Traffic & Transportation Engineering, Key Laboratory of Traffic Safety on Track, Central South University, Changsha 410075, China
Interests: 3D printing; fibre-reinforced polymer composites; formulation; thermo environment
Special Issues, Collections and Topics in MDPI journals

E-Mail Website
Guest Editor
State Key Laboratory for Strength and Vibration of Mechanical Structures, School of Aerospace Engineering, Xi’an Jiaotong University, Xi’an 710049, China
Interests: lightweight design; composite material; cellular material; failure; impact mechanism
Special Issues, Collections and Topics in MDPI journals

E-Mail Website
Guest Editor
Engineering and Physical Science Research Council, CIMComp, University of Cambridge, Cambridge, UK
Interests: mineral-filled polymers; material modelling; composites technology; artificial intelligence

Special Issue Information

Dear Colleagues,

Additive manufacturing has been adopted in many applications (e.g., aerospace, automotive, railway, consumer, and biomedical) due to its revolution in fabricating complex products with customised features. Additive manufacturing of fibre-reinforced polymer composites has attracted increasing attention because of its excellence in improving and diversifying material properties by introducing reinforcements. This Special Issue focuses on recent advances in additive manufacturing of fibre-reinforced polymer composites. Example topics may include different additive manufacturing processes, formulations of different materials, strengths and drawbacks of additive manufacturing methods, and multi-physical characterisation of fibre-reinforced polymer composites. Original research papers, short reports, and reviews are welcome to be published on this Special Issue. It will be an opportunity to take a look at the latest trends and future technologies in the research field of advanced fibre-reinforced polymer composites.

Dr. Chengxing Yang
Prof. Dr. Kui Wang
Dr. Jianxun Zhang
Dr. Andrea Codolini
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Polymers is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2700 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • additive manufacturing
  • 3D printing
  • continuous fibre
  • short fibre
  • polymer
  • composite material
  • formulation
  • mechanical properties
  • characterisation

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (11 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Research

14 pages, 5049 KiB
Article
Compression Behavior of 3D Printed Composite Isogrid Structures
by Marina Andreozzi, Carlo Bruni, Archimede Forcellese, Serena Gentili and Alessio Vita
Polymers 2024, 16(19), 2747; https://doi.org/10.3390/polym16192747 - 28 Sep 2024
Viewed by 285
Abstract
Composite materials, particularly carbon fiber-reinforced polymers (CFRPs), have become a cornerstone in industries requiring high-performance materials due to their exceptional mechanical properties, such as high strength-to-weight ratios, and their inherent lightweight nature. These attributes make CFRPs highly desirable in aerospace, automotive, and other [...] Read more.
Composite materials, particularly carbon fiber-reinforced polymers (CFRPs), have become a cornerstone in industries requiring high-performance materials due to their exceptional mechanical properties, such as high strength-to-weight ratios, and their inherent lightweight nature. These attributes make CFRPs highly desirable in aerospace, automotive, and other advanced engineering applications. However, the compressive behavior of CFRP structures remains a challenge, primarily due to the material sensitivity to structural instability, leading to matrix cracking and premature failure under compressive loads. Isogrid structures, characterized by their unique geometric patterns, have shown promise in enhancing the compressive behavior of CFRP panels by providing additional support that mitigates these issues. Traditionally, these structures are manufactured using automated techniques like automated fiber placement (AFP) and automated tape laying (ATL), which, despite their efficacy, are often cost-prohibitive for small-scale or custom applications. Recent advancements in 3D-printing technology, particularly those involving continuous fiber reinforcement, present a cost-effective and flexible alternative for producing complex CFRP structures. This study investigates the compressive behavior of 3D-printed isogrid structures, fabricated using continuous carbon fiber reinforcement via an Anisoprint Composer A3 printer equipped with towpreg coextrusion technology. A total of eight isogrid panels with varying infill percentages were produced and subjected to buckling tests to assess their performance. The experimental results indicate a direct correlation between infill density and buckling resistance, with higher infill densities leading to increased buckling loads. Additionally, the failure modes were observed to shift from local to global buckling as the infill density increased, suggesting a more uniform distribution of compressive stresses. Post-test analyses using optical microscopy and scanning electron microscopy (SEM) revealed the presence of voids within the 3D-printed structures, which were found to negatively impact the mechanical performance of the isogrid panels. The findings of this study demonstrate that 3D-printed isogrid CFRP structures can achieve significant buckling resistance, making them a viable option for high-performance applications. However, the presence of voids remains a critical issue, highlighting the need for process optimizations in 3D-printing techniques to enhance the overall performance and reliability of these structures. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

25 pages, 16876 KiB
Article
Optimization of 3D Printing Parameters of High Viscosity PEEK/30GF Composites
by Dmitry Yu. Stepanov, Yuri V. Dontsov, Sergey V. Panin, Dmitry G. Buslovich, Vladislav O. Alexenko, Svetlana A. Bochkareva, Andrey V. Batranin and Pavel V. Kosmachev
Polymers 2024, 16(18), 2601; https://doi.org/10.3390/polym16182601 - 14 Sep 2024
Viewed by 700
Abstract
The aim of this study was to optimize a set of technological parameters (travel speed, extruder temperature, and extrusion rate) for 3D printing with a PEEK-based composite reinforced with 30 wt.% glass fibers (GFs). For this purpose, both Taguchi and finite element methods [...] Read more.
The aim of this study was to optimize a set of technological parameters (travel speed, extruder temperature, and extrusion rate) for 3D printing with a PEEK-based composite reinforced with 30 wt.% glass fibers (GFs). For this purpose, both Taguchi and finite element methods (FEM) were utilized. The artificial neural networks (ANNs) were implemented for computer simulation of full-scale experiments. Computed tomography of the additively manufactured (AM) samples showed that the optimal 3D printing parameters were the extruder temperature of 460 °C, the travel speed of 20 mm/min, and the extrusion rate of 4 rpm (the microextruder screw rotation speed). These values correlated well with those obtained by computer simulation using the ANNs. In such cases, the homogeneous micro- and macro-structures were formed with minimal sample distortions and porosity levels within 10 vol.% of both structures. The most likely reason for porosity was the expansion of the molten polymer when it had been squeezed out from the microextruder nozzle. It was concluded that the mechanical properties of such samples can be improved both by changing the 3D printing strategy to ensure the preferential orientation of GFs along the building direction and by reducing porosity via post-printing treatment or ultrasonic compaction. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

22 pages, 2735 KiB
Article
Low-Velocity Impact of Clamped Rectangular Sandwich Tubes with Fiber Metal Laminated Tubes
by Yao Wang, Jianxun Zhang, Hui Guo and Hui Yuan
Polymers 2024, 16(13), 1833; https://doi.org/10.3390/polym16131833 - 27 Jun 2024
Viewed by 492
Abstract
Fiber metal laminated sandwich tubes are made up of alternating fiber-reinforced composite and metal layers. Fiber metal laminated tubes have the advantages of the high strength and high stiffness of fiber and the toughness of metal, so they have become an excellent load-bearing [...] Read more.
Fiber metal laminated sandwich tubes are made up of alternating fiber-reinforced composite and metal layers. Fiber metal laminated tubes have the advantages of the high strength and high stiffness of fiber and the toughness of metal, so they have become an excellent load-bearing and energy-absorbing, lightweight structure. Due to the complexity of the fiber layup, it is difficult to establish an analytical model of the relevant structural properties. In this work, introducing the number and volume fraction of fiber layup, based on the modified rigid–plastic model, an analytical model is established for low-velocity impacts on sandwich tubes with fiber metal laminated tubes, which provided a theoretical basis for the design of fiber–metal composite tubes. In addition, a numerical simulation was conducted for low-velocity impacts on clamped rectangular sandwich tubes with fiber metal laminated (FML) tubes and a foam core. By comparing the results obtained from the theoretical analysis and numerical calculations, it is shown that the analytical results can reasonably agree with the numerical results. The influences of the metal volume fraction (MVF), the strength ratio factor of the FML metal layer to the FML composite layer, and the relative strength of the foam on the dynamic response of the rectangular sandwich tubes with FML tubes and a metal foam core (MFC) are discussed. It is shown that by increasing the fiber content and fiber strength of the FML tubes and the foam strength, the load-carrying and energy-absorbing capacity of the rectangular sandwich tubes can be effectively improved, especially by changing the fiber properties. In addition, present analytical solutions can be applied to make predictions about the dynamic response of the rectangular sandwich tubes with FML tubes and MFC during impacts with low-velocity and reasonably heavy-mass. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

13 pages, 5774 KiB
Article
The Development of Biocomposite Filaments for 3D Printing by Utilizing a Polylactic Acid (PLA) Polymer Matrix Reinforced with Cocoa Husk Cellulose Fibers
by Victor Hugo Martins de Almeida, Raildo Mota de Jesus, Gregório Mateus Santana, Sabir Khan, Erickson Fabiano Moura Sousa Silva, Iago Silva da Cruz, Ian de Souza Santos and Paulo Neilson Marques dos Anjos
Polymers 2024, 16(13), 1757; https://doi.org/10.3390/polym16131757 - 21 Jun 2024
Cited by 1 | Viewed by 996
Abstract
Vegetable fibers are increasingly used in biocomposites, but there is a need for further development in utilizing by-products like cocoa husks. Three-dimensional printing, through Fused Filament Fabrication (FFF), is advancing rapidly and may be of great interest for applying biocomposite materials. This study [...] Read more.
Vegetable fibers are increasingly used in biocomposites, but there is a need for further development in utilizing by-products like cocoa husks. Three-dimensional printing, through Fused Filament Fabrication (FFF), is advancing rapidly and may be of great interest for applying biocomposite materials. This study focuses on developing innovative and fully biodegradable filaments for the FFF process. PLA filaments were prepared using cellulose fibers derived from cocoa husks (5% mass ratio). One set of filaments incorporated fibers from untreated husks (UCFFs), while another set utilized fibers from chemically treated husks (TCFFs). The fabricated materials were analyzed using scanning electron microscopy (SEM), thermogravimetric analysis (TGA), and Fourier transform infrared (FTIR) techniques, and they were also tested for tensile strength. ANOVA reveals that both UCFFs and TCFFs significantly predict tensile strength, with the UCFFs demonstrating an impressive R2 value of 0.9981. The optimal tensile strength for the filament test specimens was 16.05 MPa for TCFF8 and 13.58 MPa for UCFF8, utilizing the same printing parameters: 70% infill and a layer thickness of 0.10 mm. Additionally, there was an 18% improvement in the tensile strength of the printed specimens using the filaments filled with chemically treated cocoa husk fibers compared to the filaments with untreated fibers. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

18 pages, 14551 KiB
Article
Design and Optimization of 3D-Printed Variable Cross-Section I-Beams Reinforced with Continuous and Short Fibers
by Xin Zhang, Peijie Sun, Yu Zhang, Fei Wang, Yun Tu, Yunsheng Ma and Chun Zhang
Polymers 2024, 16(5), 684; https://doi.org/10.3390/polym16050684 - 2 Mar 2024
Cited by 1 | Viewed by 1297
Abstract
By integrating fiber-reinforced composites (FRCs) with Three-dimensional (3D) printing, the flexibility of lightweight structures was promoted while eliminating the mold’s limitations. The design of the I-beam configuration was performed according to the equal-strength philosophy. Then, a multi-objective optimization analysis was conducted based on [...] Read more.
By integrating fiber-reinforced composites (FRCs) with Three-dimensional (3D) printing, the flexibility of lightweight structures was promoted while eliminating the mold’s limitations. The design of the I-beam configuration was performed according to the equal-strength philosophy. Then, a multi-objective optimization analysis was conducted based on the NSGA-II algorithm. 3D printing was utilized to fabricate I-beams in three kinds of configurations and seven distinct materials. The flexural properties of the primitive (P-type), the designed (D-type), and the optimized (O-type) configurations were verified via three-point bending testing at a speed of 2 mm/min. Further, by combining different reinforcements, including continuous carbon fibers (CCFs), short carbon fibers (SCFs), and short glass fibers (SGFs) and distinct matrices, including polyamides (PAs), and polylactides (PLAs), the 3D-printed I-beams were studied experimentally. The results indicate that designed and optimized I-beams exhibit a 14.46% and 30.05% increase in the stiffness-to-mass ratio and a 7.83% and 40.59% increment in the load-to-mass ratio, respectively. The CCFs and SCFs result in an outstanding accretion in the flexural properties of 3D-printed I-beams, while the accretion is 2926% and 1070% in the stiffness-to-mass ratio and 656.7% and 344.4% in the load-to-mass ratio, respectively. For the matrix, PAs are a superior choice compared to PLAs for enhancing the positive impact of reinforcements. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Graphical abstract

20 pages, 10693 KiB
Article
PLA-Based Composite Panels Prepared via Multi-Material Fused Filament Fabrication and Associated Investigation of Process Parameters on Flexural Properties of the Fabricated Composite
by Zhaogui Wang, Lihan Wang, Feng Tang and Chengyang Shen
Polymers 2024, 16(1), 109; https://doi.org/10.3390/polym16010109 - 29 Dec 2023
Cited by 1 | Viewed by 1173
Abstract
This study prepares composite panels with three Polylactic acid (PLA)-based materials via the multi-material fused filament fabrication method. The influences of four processing parameters on the mechanical properties of 3D-printed samples are investigated employing the Taguchi method. These parameters include the relative volume [...] Read more.
This study prepares composite panels with three Polylactic acid (PLA)-based materials via the multi-material fused filament fabrication method. The influences of four processing parameters on the mechanical properties of 3D-printed samples are investigated employing the Taguchi method. These parameters include the relative volume ratio, material printing order, filling pattern, and filling density. A “larger is better” signal-to-noise analysis is performed to identify the optimal combination of printing parameters that yield maximum bending strength and bending modulus of elasticity. The results reveal that the optimal combination of printing parameters that maximizes the bending strength involves a volume ratio of 1:1:2, a material sequence of PLA/foam-agent-modified eco-friendly PLA (ePLA-LW)/glass fiber-reinforced eco-friendly PLA (ePLA-GF), a Gyroid filling pattern, and a filling density of 80%, and the optimal combination of printing parameters for maximum bending modulus involves a volume ratio of 1:2:1 with a material sequence of PLA/ePLA-LW/ePLA-GF, a Grid filling pattern, and 80% filling density. The Taguchi prediction method is utilized to determine an optimal combination of processing parameters for achieving optimal flexural performances, and predicted outcomes are validated through related experiments. The experimental values of strength and modulus are 43.91 MPa and 1.23 GPa, respectively, both very close to the predicted values of 46.87 MPa and 1.2 GPa for strength and modulus. The Taguchi experiments indicate that the material sequence is the most crucial factor influencing the flexural strength of the composite panels. The experiment result demonstrates that the flexural strength and modulus of the first material sequence are 67.72 MPa and 1.53 GPa, while the flexural strength and modulus of the third material sequence are reduced to 27.09 MPa and 0.72 GPa, respectively, only 42% and 47% of the first material sequence. The above findings provide an important reference for improving the performance of multi-material 3D-printed products. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

21 pages, 20803 KiB
Article
Study on the Properties of Multi-Walled Carbon Nanotubes (MWCNTs)/Polypropylene Fiber (PP Fiber) Cement-Based Materials
by Xiangjie Niu, Yuanzhao Chen, Zhenxia Li, Tengteng Guo, Meng Ren and Yanyan Chen
Polymers 2024, 16(1), 41; https://doi.org/10.3390/polym16010041 - 21 Dec 2023
Cited by 2 | Viewed by 1086
Abstract
In order to improve the mechanical properties and durability of cement-based materials, a certain amount of multi-walled carbon nanotubes (MWCNTs) and polypropylene fiber (PP fiber) were incorporated into cement-based materials. The mechanical properties of the multi-walled carbon nanotubes/polypropylene fiber cement-based materials were evaluated [...] Read more.
In order to improve the mechanical properties and durability of cement-based materials, a certain amount of multi-walled carbon nanotubes (MWCNTs) and polypropylene fiber (PP fiber) were incorporated into cement-based materials. The mechanical properties of the multi-walled carbon nanotubes/polypropylene fiber cement-based materials were evaluated using flexural strength tests, compressive strength tests, and splitting tensile tests. The effects of multi-walled carbon nanotubes and polypropylene fiber on the durability of cement-based materials were studied using drying shrinkage tests and freeze–thaw cycle tests. The effects of the multi-walled carbon nanotubes and polypropylene fibers on the microstructure and pore structure of the cement-based materials were compared and analyzed using scanning electron microscopy and mercury intrusion tests. The results showed that the mechanical properties and durability of cement-based materials can be significantly improved when the content of multi-walled carbon nanotubes is 0.1–0.15%. The compressive strength can be increased by 9.5% and the mass loss rate is reduced by 27.9%. Polypropylene fiber has little effect on the compressive strength of the cement-based materials, but it significantly enhances the toughness of the cement-based materials. When its content is 0.2–0.3%, it has the best effect on improving the mechanical properties and durability of the cement-based materials. The flexural strength is increased by 19.1%, and the dry shrinkage rate and water loss rate are reduced by 14.3% and 16.1%, respectively. The three-dimensional network structure formed by the polypropylene fiber in the composite material plays a role in toughening and cracking resistance, but it has a certain negative impact on the pore structure of the composite material. The incorporation of multi-walled carbon nanotubes can improve the bonding performance of the polypropylene fiber and cement matrix, make up for the internal defects caused by the polypropylene fiber, and reduce the number of harmful holes and multiple harmful holes so that the cement-based composite material not only has a significant increase in toughness but also has a denser internal structure. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

16 pages, 9944 KiB
Article
Path Planning and Bending Behaviors of 3D Printed Continuous Carbon Fiber Reinforced Polymer Honeycomb Structures
by Kui Wang, Depeng Wang, Yisen Liu, Huijing Gao, Chengxing Yang and Yong Peng
Polymers 2023, 15(23), 4485; https://doi.org/10.3390/polym15234485 - 22 Nov 2023
Cited by 5 | Viewed by 1353
Abstract
Continuous fiber reinforced polymer composites are widely used in load-bearing components and energy absorbers owing to their high specific strength and high specific modulus. The path planning of continuous fiber is closely related to its structural defects and mechanical properties. In this work, [...] Read more.
Continuous fiber reinforced polymer composites are widely used in load-bearing components and energy absorbers owing to their high specific strength and high specific modulus. The path planning of continuous fiber is closely related to its structural defects and mechanical properties. In this work, continuous fiber reinforced polymer honeycomb structures (CFRPHSs) with different printing paths were designed and fabricated via the fused deposition modeling (FDM) technique. The investigation of fiber dislocation at path corners was utilized to analyze the structural defects of nodes caused by printing paths. The lower stiffness nodes filled with pure polymer due to fiber dislocation result in uneven stiffness distribution. The bending performance and deformation modes of CFRPHSs with different printing paths and corresponding pure polymer honeycomb structures were investigated by three-point bending tests. The results showed that the enhancement effect of continuous fibers on the bending performance of honeycomb structures was significantly affected by the printing paths. The CFRPHSs with a staggered trapezoidal path exhibited the highest specific load capacity (68.33 ± 2.25 N/g) and flexural stiffness (627.70 ± 38.78 N/mm). In addition, the fiber distributions and structural defects caused by the printing paths determine the stiffness distribution of the loading region, thereby affecting the stress distribution and failure modes of CFRPHSs. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

16 pages, 7112 KiB
Article
Spatial 3D Printing of Continuous Fiber-Reinforced Composite Multilayer Truss Structures with Controllable Structural Performance
by Daokang Zhang, Xiaoyong Tian, Yanli Zhou, Qingrui Wang, Wanquan Yan, Ali Akmal Zia, Lingling Wu and Dichen Li
Polymers 2023, 15(21), 4333; https://doi.org/10.3390/polym15214333 - 6 Nov 2023
Cited by 4 | Viewed by 1782
Abstract
Continuous fiber-reinforced composite truss structures have broad application prospects in aerospace engineering owing to their high structural bearing efficiency and multifunctional applications. This paper presents the design and fabrication of multilayer truss structures with controlled mechanical properties based on continuous fiber-reinforced thermoplastic composite [...] Read more.
Continuous fiber-reinforced composite truss structures have broad application prospects in aerospace engineering owing to their high structural bearing efficiency and multifunctional applications. This paper presents the design and fabrication of multilayer truss structures with controlled mechanical properties based on continuous fiber-reinforced thermoplastic composite 3D printing. Continuous fiber composite pyramid trusses fabricated by 3D printing have high specific stiffness and strength, with maximum equivalent compression modulus and strength of 401.91 MPa and 30.26 MPa, respectively. Moreover, the relative density of a truss structure can be as low as 1.45%. Additionally, structural units can be extended in any direction to form a multilayer truss structure. Structural performance can be controlled by designing the parameters of each layer. This study offers a novel approach for designing a multifunctional multilayer truss structure, a structure with low-density needs and unique load-bearing effects. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

29 pages, 9901 KiB
Article
Simulation-Based Identification of Operating Point Range for a Novel Laser-Sintering Machine for Additive Manufacturing of Continuous Carbon-Fibre-Reinforced Polymer Parts
by Michael Baranowski, Zijin Shao, Alexander Spintzyk, Florian Kößler and Jürgen Fleischer
Polymers 2023, 15(19), 3975; https://doi.org/10.3390/polym15193975 - 3 Oct 2023
Cited by 1 | Viewed by 1773
Abstract
Additive manufacturing using continuous carbon-fibre-reinforced polymer (CCFRP) presents an opportunity to create high-strength parts suitable for aerospace, engineering, and other industries. Continuous fibres reinforce the load-bearing path, enhancing the mechanical properties of these parts. However, the existing additive manufacturing processes for CCFRP parts [...] Read more.
Additive manufacturing using continuous carbon-fibre-reinforced polymer (CCFRP) presents an opportunity to create high-strength parts suitable for aerospace, engineering, and other industries. Continuous fibres reinforce the load-bearing path, enhancing the mechanical properties of these parts. However, the existing additive manufacturing processes for CCFRP parts have numerous disadvantages. Resin- and extrusion-based processes require time-consuming and costly post-processing to remove the support structures, severely restricting the design flexibility. Additionally, the production of small batches demands considerable effort. In contrast, laser sintering has emerged as a promising alternative in industry. It enables the creation of robust parts without needing support structures, offering efficiency and cost-effectiveness in producing single units or small batches. Utilising an innovative laser-sintering machine equipped with automated continuous fibre integration, this study aims to merge the benefits of laser-sintering technology with the advantages of continuous fibres. The paper provides an outline, using a finite element model in COMSOL Multiphysics, for simulating and identifying an optimised operating point range for the automated integration of continuous fibres. The results demonstrate a remarkable reduction in processing time of 233% for the fibre integration and a reduction of 56% for the width and 44% for the depth of the heat-affected zone compared to the initial setup. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

17 pages, 21553 KiB
Article
Digital Image Correlation Analysis of Strain Fields in Fibre-Reinforced Polymer–Matrix Composite under ±45° Off-Axis Tensile Testing
by Paweł Bogusz
Polymers 2023, 15(13), 2846; https://doi.org/10.3390/polym15132846 - 28 Jun 2023
Cited by 3 | Viewed by 1744
Abstract
This study presents an experimental investigation of an in-plane shear of a glass lamina composite using a ±45° off-axis tension test. Typically, the shear stress curve, shear modulus, and in-plane shear strength for composite lamina-type materials are identified. Previous research indicated that a [...] Read more.
This study presents an experimental investigation of an in-plane shear of a glass lamina composite using a ±45° off-axis tension test. Typically, the shear stress curve, shear modulus, and in-plane shear strength for composite lamina-type materials are identified. Previous research indicated that a loading rate affects the strength of this composite. This study extends the existing literature by utilising a non-contact optical digital image correlation (DIC) method to measure strain distribution during the test. Two cross-head displacement rates were examined. The obtained strain maps reveal an uneven distribution resembling fabric texture. As the deformation progresses, the differences in the strain pattern increase. Subsequently, a quantitative analysis of the differences between regions with extreme (minimum and maximum) strain values and regions with average values was conducted. Based on these measurements, shear stress–strain curves, indicating variations in their courses, were constructed. These differences may reach several percent and may influence the analysis of numerical simulations. The DIC results were validated using strain gauge measurements, a commonly utilised method in this test. It was demonstrated that the location of the strain gauge installation impacts the results. During the tests, the occurrence of multiple microcracks in the resin was observed, which can contribute to the nonlinearity observed in the shear stress–shear strain curve. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1
