Understanding dynamic groundwater–surface water interactions in alluvial plains is critical for sustainable water resource management, yet seasonal variability and spatial heterogeneity of these exchanges remain imprecisely quantified. Here, we present an improved ²²²Rn mass balance model for evaluating the seasonal hydraulic exchange between groundwater and the Xintongyang Canal in the Taizhou alluvial plain over the course of a hydrologic year. To reduce the model uncertainty, the “background” ²²²Rn for non-groundwater sources was incorporated into the model to replace the influence of hyporheic exchange. The results indicate that the hydraulic exchange process of surface water and groundwater has significant spatiotemporal differences. Based on the calculations from the ²²²Rn mass balance model, the canal leakage flux follows the order of summer > autumn > winter > spring over the course of a hydrologic year. In contrast, the groundwater discharge flux follows the order of summer > spring > autumn > winter. During a hydrological year, summer demonstrated the most intense water exchange dynamics, with peak fluxes reaching 0.0455 m³/(s·m) for surface water leakage and 0.0013 m³/(s·m) for groundwater discharge, revealing pronounced spatial heterogeneity in dominant exchange processes. ²²²Rn activity in canal and groundwater varies significantly across different regions, with canal leakage being the dominant mode of hydraulic exchange within the study area. The change of the hydraulic exchange process was mainly affected by factors such as rainfall. In the process of promoting surface water leakage, precipitation will also strengthen the supplement of groundwater and contribute to the groundwater discharge in most of the canal sections. This study offers insight into the seasonal variations of groundwater and surface water interaction within an alluvial plain. Full article

In situ evaluations of the metabolic rates (i.e., respiration and excretion) of salmonid eggs are mostly indirect, focusing on the sampling of hyporheic water from wild or artificial nests. Comparatively, experimental studies carried out under controlled, laboratory conditions are less abundant due to methodological difficulties. This study presents a novel experimental setup aimed to address this issue and enable the measurement of oxygen and dissolved inorganic nitrogen fluxes in simulated rainbow trout (O. mykiss) egg pockets. The experimental setup consists of reconstructed egg pockets in cylindrical cores under flow-through conditions. Live and dead eyed-stage eggs were incubated in a natural, sterilised gravel substrate. Hyporheic water circulation was ensured using peristaltic pumps, with the possibility to collect and analyse inflowing and outflowing water for chemical analyses. Microcosm incubations, with closed respirometry of eggs in water alone, were also carried out in order to infer the importance of microbial respiration in the simulated egg pockets. The results show an increasing trend in oxygen demand, due to the development of biofilm in the reconstructed egg pockets and increased egg respiration rates. Moreover, egg pockets showed positive ammonium net fluxes connected with the advancing developmental egg stage, while nitrate removal peaked during the last phase of the experiment, mainly due to the formation of oxic-hypoxic interfaces, leading to couple nitrification–denitrification processes. The suggested approach enables to test a number of in situ situations, including the effects of extreme hydrological conditions, sediment clogging and sudden changes in water chemistry or temperature on the survival and metabolic performances of nests, at different egg development stages. Full article

Understanding the dynamics of hyporheic flow is important for managing water resources, since this interfacial flow exchange affects the fate and transport of contaminants in rivers. This study numerically quantifies the effect of hyporheic exchange on solute residence times in surface water systems by simulating solute transport in unified turbulent open-channel and hyporheic zone systems. Interfacial hyporheic fluxes (q_int) increase with increased Reynolds number (Re) that produces an enhanced bottom pressure gradient over the ripple bed. Heavy-tailed breakthrough curves emerge when hyporheic flow is considered in transport simulation. This reveals that hyporheic flow is a dominant driver of non-Fickian transport in surface water as this interfacial flow exchange delays solute transport with slow porewater flows. Furthermore, the increase in Re extends the longitudinal spreading of solute tracers because a higher surface flow velocity intensifies the magnitude of hyporheic flow and associated storage effects. This can be confirmed by the ratio of the maximum residence time to the peak arrival time that increases with the increase in Re, following a power-law relationship with both Re and q_int. Full article

The hydrodynamics of a river confluence generate significant vertical, lateral, and stream-wise gradients in the context of velocity, thereby forming a highly complex three-dimensional flow structure, including the development of large-scale turbulence structures. The above features affect the ecologically important underlying hyporheic zone, where surface and subsurface waters interact, and hence affect biological activity and result in highly varied habitats for organisms as well as the whole river environment. The influence of challenging conditions for in situ monitoring of hyporheic exchange—such as non-sinusoidal temperature signals, uncertainty in thermal parameters, and unsteady flows—have led to the development of hyporheic exchange detection methods that are based on the phase and amplitude changes in transient thermal signals. The use of heat as a tracer can require complex steps, including the isolation of the diurnal component of the temperature signal from other signals as well as stochastic variation. The focus of this study was to investigate a field campaign carried out between the Ninemile Creek and its tributary confluence, located in Marcellus, NY. Temperature data of the shallowest saturated sediment layers were measured from April to May 2019. Flux estimations were calculated using VFLUX 2, a MatLab based code, which performed data filtering and DHR (Dynamic Harmonic Regression). The patterns and rates of vertical flux exchange were then analyzed, and sampling of the temporal thermal profiles was performed. Furthermore, multiple analytical solutions of the one-dimensional heat transport model were analyzed and discussed in order to obtain the confluence hydrodynamic effect as well as the variations in the vertical flux estimation. This was achieved by utilizing different sensor pairs and porous medium characteristics, such as thermal diffusivity and conductivity. The predicted flow field shows that confluence topography—which includes the turbulent kinetic energy downstream of the junction, shear layer formations, bed stratigraphy and water table gradients—affects the magnitude and patterns of hyporheic exchange. The results of this study could help to advance the calibration of one-dimensional heat transport models in order to better understand the key hydrological, hydraulic, and ecological issues associated with river confluence. Full article

The flux of water through the hyporheic zone (HZ) is controlled by stream bedforms, sinuosity, surface water velocity, local water table, seasonality, and hydraulic conductivity (K) of the bed material. Dependent on both the kinematic viscosity and density of water, K values are a function of temperature. In most studies, changes in temperature have been neglected because of the limited effect either density or viscosity has on K values. However, these variations are important given the role of K in HZ flux, which lead to the hypothesis that flow into the HZ would be more efficient (faster rate and greater depth) under warmer conditions than under cool conditions. To discern how water temperature affects flow depth in the HZ, VS2DHI simulations were created to map flow under both warm and cool thermal conditions. The models employed data collected from a series of varying temperature hydrologic flume tests in which the effects of hyporheic flow altering variables such as sinuosity, surface water velocity and volume, and bed-forms were controlled. Results verify that K values in the HZ were larger under warm conditions generating deeper HZ pathways, while the smaller K values under cool conditions produced shallower pathways. The simulations confirmed a faster speed of frontal movement under warm conditions than cool. Péclet numbers revealed a shallower advective extinction depth under cool conditions as opposed to warm. Full article

As an alternative resource, reclaimed water is rich in the various nutrients and organic matter that may irreparably endanger groundwater quality through the recharging process. During groundwater recharge with reclaimed water, hot spots and hot moments (HSHMs) in the hyporheic zones, located at the groundwater–reclaimed water interface, play vital roles in cycling and processing energy, carbon, and nutrients, drawing increasing concern in the fields of biogeochemistry, environmental chemistry, and pollution treatment and prevention engineering. This paper aims to review these recent advances and the current state of knowledge of HSHMs in the hyporheic zone with regard to groundwater recharge using reclaimed water, including the generation mechanisms, temporal and spatial characteristics, influencing factors, and identification indicators and methods of HSHMs in the materials cycle. Finally, the development prospects of HSHMs are discussed. It is hoped that this review will lead to a clearer understanding of the processes controlling water flow and pollutant flux, and that further management and control of HSHMs can be achieved, resulting in the development of a more accurate and safer approach to groundwater recharge with reclaimed water. Full article

The hyporheic zone (HZ) plays an important role in the river ecosystem, and hyporheic exchange and solute transport in the HZ are important ecological functions. However, the relationship between the design parameters of river structure and solute transport is still poorly understood. In this study, we combined flume experiments and numerical simulations to systematically evaluate how in-stream structures impact the solute transport depth (D_P), hyporheic vertical exchange flux (Q), and solute flux (Qs). The results showed that the in-stream structure had a significant influence on solute transport in the HZ and could obviously increase the intensity of hyporheic exchange and promote solute transport. Model results indicated that D_P, Q, and Qs increased with the ratio of ground height to underground height of structure (H/D) and structure number (N), while Q, D_P, and Qs increased with the structural spacing (S) to begin with; then, Q remained constant, and D_P and Qs decreased as S continued to increase. This study deepened our understanding of the influence of in-stream structural design parameters on HZ solute transport, which is helpful to provide a theoretical basis for ecological restoration projects in the river HZ. Full article

Identifying and quantifying exchange flux across sediment-water interface is crucial when considering water and nutrient contributions to a eutrophic lake. In this study, observed temporal temperature distributions in shallow sediment of Lake Taihu (Eastern China) based on three-depth sensors at 14 sites throughout 2016 were used to assess temporal water exchange patterns. Results show that temporal temperature in shallow sediments differed with sampling sites and depths and the temperature amplitudes also clearly shrunk as the offshore distance increasing. Exchange fluxes estimated using the VFLUX 2 model based on temperature amplitude show that alternating-direction temporal flow exists in the eastern zone of Lake Taihu with averages of −13.0, −0.6, and 3.4 mm day⁻¹ (negative represents discharging into the lake) at three nearshore sites (0.5, 2.0, and 6.0 km away from the shoreline, respectively). Whereas downwelling flow occurred throughout almost the entire year with averages of 37.7, 23.5, and 6.6 mm day⁻¹ at the three southern nearshore sites, respectively. However, upwelling flow occurred throughout almost the entire year and varied widely in the western zone with averages of −74.8, 45.9, and −27.0 mm day^–1 and in the northern zone with averages of −76.2, −55.3, and −51.1 mm day⁻¹. The estimated fluxes in the central zone were relatively low and varied slightly during the entire year (−15.1 to 22.5 mm day⁻¹ with an average of −0.7 mm day⁻¹). Compared with the sub sensor pair (at 5 and 10 cm), the estimated hyporheic fluxes based on the top sensor pair (at 0 and 5 cm) varied within wider ranges and exhibited relatively larger values. Effects of upwelling flow at the western and northern zones need to be paid attention to on nearshore water quality particularly during winter and spring seasons. Estimated flow patterns at the four zones summarily reflect the seasonal water interaction near the sediment surface of Lake Taihu and are beneficial to improve its comprehensive management. Thermal dispersivity usually used for estimating the thermal diffusivity is more sensitive for upward hyporheic flux estimating even if with a low flux. Temperature amplitude ratio method can be used to estimate the exchange flux and suitable for low flux conditions (either upwelling or downwelling). A better evaluation of the exchange flux near inclined nearshore zones might need an optimized installation of temperature sensors along with the potential flow path and/or a vertical two-dimensional model in the future. Full article

The bioturbation activity of macroinvertebrates can affect the level of water exchange across the sediment–water interface. The impact of tubificid worm with different densities on the vertical water exchange at the sediment–water interface was investigated based on laboratory flume experiments. Vertical water fluxes, as well as physiochemical parameters, were measured at seven-day intervals, and the maximum penetration depths were obtained by dye injection before and after the tubificid bioturbation experiment, respectively. The bioturbation effects can be summarized in two aspects: (1) when the density was less than (or equal to) 20 individual/10 cm², the volume of vertical water exchange positively correlated with the tubificid bioturbation. Once the density exceeded (or equaled) 25 individual/10 cm², the vertical water flux decreased with increasing tubificid bioturbation. After 14 to 21 days, a negative correlation was identified between the bioturbation and the vertical water flux under all biological densities. (2) The maximum depth that the surface water can penetrate the sediment increased with increasing tubificid density. These results revealed that the vertical water was closely related to the biological density. The study has certain reference significance to understanding the spatiotemporal heterogeneity of hyporheic water exchange on a local scale. Full article

This paper introduces and tests the Sediment Bed Borehole Advection Method (SBBAM), a low cost, point-measurement technique which utilizes a push-point probe to quantify the vertical direction and magnitude of Darcy flux at the surface water—groundwater sediment interface. The Darcy flux measurements are derived from the residence-time analysis of tracer arrival calculated from measured tracer concentration time-series data. The technique was evaluated in the laboratory using a sediment bed simulator tank at eight flow rates (1–90 cm/day). Triplicate test runs for each flow rate returned average errors between 4–20 percent; r² = 0.9977. Full article

The objective of the present paper is to develop a methodology that could allow the representation of the analytical hyporheic flux equation model (AHF) in a numerical model done in MODFLOW. Therefore, the scope of the research is to show the viability of the methodology suggested in a real case (Biebrza river, Poland, Europe). Considering that the model requires extensive manipulation in the creation of the packages, a test phase through the seepage package of MODFLOW is carried out with the aim of representing the river package of MODFLOW. FloPy is the tool chosen to develop this implementation due to the versatility of manipulating the packages available in MODFLOW through coding. The obtained results showed a correct implementation of the AHF model using the example of the Biebrza River. The results obtained will enable a better understanding regarding the modelling of the interaction between the river and the aquifer, considering streams with specific geometries where the depth is dimensionally higher than the width. Full article

Modelling of water flow in the hyporheic zone and calculations of water exchange between groundwater and surface waters are important issues in modern environmental research. The article presents the Analytical Hyporheic Flux approach (AHF) permitting calculation of the amount of water exchange in the hyporheic zone, including vertical water seepage through the streambed and horizontal seepage through river banks. The outcome of the model, namely water fluxes, is compared with the corresponding results from the numerical model SEEP2D and simple Darcy-type model. The errors of the AHF model, in a range of 11–16%, depend on the aspect ratio of water depth to river width, and the direction of the river–aquifer water exchange, i.e., drainage or infiltration. The AHF model errors are significantly lower compared to the often-used model based on vertical water seepage through the streambed described by Darcy’s law. Full article

To assist river restoration efforts we need to slow the rate of river degradation. This study provides a detailed explanation of the hydraulic complexity loss when a meandering river is straightened in order to motivate the protection of river channel curvature. We used computational fluid dynamics (CFD) modeling to document the difference in flow dynamics in nine simulations with channel curvature (C) degrading from a well-established tight meander bend (C = 0.77) to a straight channel without curvature (C = 0). To control for covariates and slow the rate of loss to hydraulic complexity, each of the nine-channel realizations had equivalent bedform topography. The analyzed hydraulic variables included the flow surface elevation, streamwise and transverse unit discharge, flow velocity at streamwise, transverse, and vertical directions, bed shear stress, stream function, and the vertical hyporheic flux rates at the channel bed. The loss of hydraulic complexity occurred gradually when initially straightening the channel from C = 0.77 to C = 0.33 (i.e., the radius of the channel is three-times the channel width), and additional straightening incurred rapid losses to hydraulic complexity. Other studies have shown hydraulic complexity provides important riverine habitat and is positively correlated with biodiversity. This study demonstrates how hydraulic complexity can be gradually and then rapidly lost when unwinding a river, and hopefully will serve as a cautionary tale. Full article

The subsurface region where river water and groundwater actively mix (the hyporheic zone) plays an important role in conservative and reactive solute transport along rivers. Deposits of high-conductivity (K) sediments along rivers can strongly control hyporheic processes by channeling flow along preferential flow paths wherever they intersect the channel boundary. Our goal is to understand how sediment heterogeneity influences conservative and sorptive solute transport within hyporheic zones containing high- and low-K sediment facies types. The sedimentary architecture of high-K facies is modeled using commonly observed characteristics (e.g., volume proportion and mean length), and their spatial connectivity is quantified to evaluate its effect on hyporheic mixing dynamics. Numerical simulations incorporate physical and chemical heterogeneity by representing spatial variability in both K and in the sediment sorption distribution coefficient ( $K_d$ ). Sediment heterogeneity significantly enhances hyporheic exchange and skews solute breakthrough behavior, while in homogeneous sediments, interfacial flux and solute transport are instead controlled by geomorphology and local-scale riverbed topographies. The hyporheic zone is compressed in sediments with high sorptive capacity, which limits solute interactions to only a small portion of the sedimentary architecture and thus increases retention. Our results have practical implications for groundwater quality, including remediation strategies for contaminants of emerging concern. Full article

The hyporheic zone (HZ), the region beneath or alongside a streambed, can play a vital role in a stream ecosystem. Previous studies have examined the impacts of in-stream structures on the HZ and river restoration; however, studies on optimizing the design of in-stream structures are still lacking. Therefore, this study aims to propose a method for optimizing the design of in-stream structures (e.g., weirs) through comprehensively considering both nitrogen removal amount (NRA) and nitrogen removal ratio (NRR) in the HZ based on numerical modelling. The Hydrologic Engineering Center’s River Analysis System (HEC-RAS) and COMSOL Multiphysics are employed for surface water and hyporheic flow simulations, respectively, and these two models are coupled by the hydraulic head along the surface of the streambed. The NRA and NRR are both closely related with residence time (RT), while the NRA is also influenced by hyporheic flux. Using the model outputs under different scenarios, regression equations for estimating the relevant variables (e.g., the maximum upstream distance in the subsurface flow influenced by the weir, the RT, and the hyporheic flux) are proposed. Then, the cumulative NRA (CNRA) and NRR can be calculated, and an objective function is formulated as the product of the normalized CNRA and NRR. The results show that the optimal height of the weir can be obtained based on the proposed method, and the validation shows the good general performance of this method. Sensitivity analysis indicates that the optimal height generally can be sensitive to the river discharge, i.e., the optimal height increases when the river discharge increases and vice versa. In addition, it is observed that, in the case of the optimal height, hyporheic flux increases when the slope increases while the influence of depth to bedrock on hyporheic flux is not significant. This study enhances our understanding of the optimal in-stream structure design, and potentially benefits river restoration in the face of continual degradation caused by human activities. Full article
