Search Results (34)

In the operation of enhanced geothermal systems (EGSs), complex physical and chemical coupling processes, which are crucial for the efficient exploitation of geothermal energy, are involved. In situ studies of multi-fracture hot dry rocks (HDRs) face significant challenges, leading to a shortage of experimental data for verifying numerical simulations and supporting experimental techniques. In this paper, a multi-field coupling experimental simulation technique was designed for a multi-fracture geothermal reservoir. This technique enables the experimental investigation of the effects of fracture and reservoir characteristics, working fluid parameters, and wellbore arrangement on the multi-field coupling transport mechanism inside geothermal reservoirs during EGS operation. In addition, the practicability and reliability of the experimental technique were proved via a two-dimensional multi-fracture model. The experimental technique addresses a research gap in studying multi-fracture geothermal reservoirs and holds potential to promote substantial progress in geothermal resource exploitation. Full article

Enhanced or engineered geothermal systems (EGSs), or non-hydrothermal resources, are highly notable among sustainable energy resources because of their abundance and cleanness. The EGS concept has received worldwide attention and undergone intensive studies in the last decade in the US and around the world. In comparison, hydrothermal reservoir resources, the ‘low-hanging fruit’ of geothermal energy, are very limited in amount or availability, while EGSs are extensive and have great potential to supply the entire world with the needed energy almost permanently. The EGS, in essence, is an engineered subsurface heat mining concept, where water or another suitable heat exchange fluid is injected into hot formations to extract heat from the hot dry rock (HDR). Specifically, the EGS relies on the principle that injected water, or another working fluid, penetrates deep into reservoirs through fractures or high-permeability channels to absorb large quantities of thermal energy by contact with the host hot rock. Finally, the heated fluid is produced through production wells for electricity generation or other usages. Heat mining from fractured EGS reservoirs is subject to complex interactions within the reservoir rock, involving high-temperature heat exchange, multi-phase flow, rock deformation, and chemical reactions under thermal-hydrological-mechanical (THM) processes or thermal-hydrological-mechanical-chemical (THMC) interactions. In this paper, we will present a THM model and reservoir simulator and its application for simulation of hydrothermal geothermal systems and EGS reservoirs as well as a methodology of coupling thermal, hydrological, and mechanical processes. A numerical approach, based on discretizing the thermo-poro-elastic Navier equation using an integral finite difference method, is discussed. This method provides a rigorous, accurate, and efficient fully coupled methodology for the three (THM) strongly interacted processes. Several programs based on this methodology are demonstrated in the simulation cases of geothermal reservoirs, including fracture aperture enhancement, thermal stress impact, and tracer transport in a field-scale reservoir. Results are displayed to show geomechanics’ impact on fluid and heat flow in geothermal reservoirs. Full article

In hot dry rocks (HDRs), hydraulic fracturing is necessary to create enhanced geothermal systems (EGSs) and optimize flow rates between injection and production wells. The geometry of the induced fracture is related to numerous factors, including rock mechanical properties, especially Young’s modulus and Poisson’s ratio. In this paper, we show the influence of Young’s and Poisson’s parameters on fracture geometry in selected HDR-type prospective areas in Poland. Parameters were determined in the laboratory based on drill core samples from granite and sandstone formations using both dynamic and static methods. The results obtained reveal strong differences between dynamic and static values in granite and less diverse results in sandstone. Based on these data, numerical simulations of fracture geometry were carried out, taking into account the variability in the rocks’ elastic parameters. Sensitivity analysis showed that relatively high diversity in the elastic parameters led to a relatively slight impact on the fracture geometry of the tested formations. The influence of Young’s modulus did not exceed 6.5% of the reference half-length and width values for sandstone and 7.3% of the half-length for granite. Variability in the fracture width was significant in granite formation and amounted to 46.4%. The influence of Poisson’s ratio was marginal in both tested types of rocks. The research results, which have not been reported previously, can be considered for the design of hydraulic fracturing operations in enhanced geothermal systems in Poland. Full article

Geothermal energy and hot dry rock (HDR), as an important clean energy technology, have garnered widespread attention globally in recent years. Enhanced Geothermal Systems (EGS), a technology for extracting energy from low-permeability Hot Dry Rock (HDR) reservoirs, is crucial for the utilization of geothermal energy. Although interest in this area has significantly increased, a comprehensive and systematic analysis providing a clear understanding of the development context is still lacking. To this end, this paper presents a bibliometric analysis of 1764 relevant publications from 1996 to 2023, revealing research trends and hotspots in this field. Utilizing tools such as Bibliometrix (Version 4.2.3), CiteSpace (Version 6.2.R2), and VOSviewer (Version 1.6.19), the study analyzes publication trends, subject categories, journals, authors, institutions, and national contributions. The results indicate that EGS technology, rock mechanical behavior, and environmental impact assessment are the primary research hotspots, with China being the leading country in terms of publication volume. Future research directions include technological optimization, environmental sustainability, and the advancement of interdisciplinary collaboration. This study provides a valuable reference for further research and application in geothermal energy and HDR and offers a dynamic perspective on shifting research priorities. Full article

Deep borehole heat exchangers (DBHEs) have been widely used for extracting geothermal energy in China. However, the application of this technology in an open well with high temperature remains unknown. In this paper, the thermal performance of a DBHE installed in a groundwater-filled hot dry rock (HDR) well in the Gonghe Basin of Qinghai Province in China was investigated. A U-shaped pipe subjected to a hydraulic pressure of 30 MPa and a temperature of 180 °C was tested successfully. Severe heat loss was detected during the test, which might have been due to the pipe not being well-insulated. To better understand the performance of DBHEs, a numerical model was developed. The results indicate that the pipe’s thermal performance increased by 247% using insulation with a 15 mm layer thickness and a thermal conductivity of 0.042 W/m·K. Thermal performance was significantly improved by increasing the fluid flow rate and pipe diameter. Among the different pipe configurations, double U-shaped buried pipes can achieve the highest performance. The heat-specific rate can reach up to 341.33 W/m with a double U-shaped pipe with a diameter of 63 mm. The second highest rate can be achieved with a coaxial pipe, while single U-shaped pipes have the lowest one. Full article

The reserves of hot dry rock (HDR) geothermal resources are huge. The main method used to develop HDR geothermal resources is called an enhanced geothermal system (EGS), and this generally uses hydraulic fracturing. After nearly 50 years of research and development, more and more countries have joined the ranks engaged in the exploration and development of HDR in the world. This paper summarizes the base technologies, key technologies, and game-changing technologies used to promote the commercialization of HDR geothermal resources. According to the present situation of the exploration, development, and utilization of HDR at home and abroad, the evaluation and site selection, efficient and low-cost drilling, and geothermal utilization of HDR geothermal resources are defined as the base technologies. Key technologies include the high-resolution exploration and characterization of HDR, efficient and complex fracture network reservoir creation, effective microseismic control, fracture network connectivity, and reservoir characterization. Game-changing technologies include downhole liquid explosion fracture creation, downhole in-situ efficient heat transfer and power generation, and the use of CO₂ and other working fluids for high-efficient power generation. Most of the base technologies already have industrial applications, but future efforts must focus on reducing costs. The majority of key technologies are still in the site demonstration and validation phase and have not yet been applied on an industrial scale. However, breakthroughs in cost reduction and application effectiveness are urgently needed for these key technologies. Game-changing technologies remain at the laboratory research stage, but any breakthroughs in this area could significantly advance the efficient development of HDR geothermal resources. In addition, we conducted a comparative analysis of the respective advantages of China and the United States in some key technologies of HDR development. On this basis, we summarized the key challenges identified throughout the discussion and highlighted the most pressing research priorities. We hope these technologies can guide new breakthroughs in HDR geothermal development in China and other countries, helping to establish a batch of HDR exploitation demonstration areas. In addition, we look forward to fostering collaboration between China and the United States through technical comparisons, jointly promoting the commercial development of HDR geothermal resources. Full article

In the exploitation of deep geothermal energy from hot dry rock (HDR) reservoirs, traditional drilling methodologies exhibit a retarded penetration rate, posing a significant impediment to efficient energy extraction. The fluidic DTH hammer is recognized as a drilling method with potential in hard formations. However, a low energy utilization was observed due to the substantial fluid loss in the fluidic oscillator (the control component of a fluidic hammer). In order to reduce the energy loss and improve the performance of fluidic hammers, a fluidic oscillator with a deflector structure is proposed in this paper. Utilizing Computational Fluid Dynamics (CFD) simulations, the optimal structural parameters for the deflector structure have been delineated, with dimensions specified as follows: a = 13.5 mm; b = 2.0 mm; and c = 2.2 mm. Subsequently, the flow field and the performance were observed. The maximum flow recovery of the output channel of the deflector structure increased by 9.1% in the backward stroke and 3.6% in the forward stroke. Moreover, the locking vortex range is expanded upward, which improves the wall attachment stability of the main jet. Finally, to substantiate the numerical findings and evaluate the practical efficacy of the deflector structure, a series of bench tests were conducted. According to the results, compared with the original structure, the average impact frequency can be increased by 5.8%, the single average impact energy increased by 7.5%, and the output power increased by 13.8%. Full article

Geothermal energy can be obtained from hot dry rock (HDR). The target temperatures for heat extraction from HDR range from 100 to 400 °C. Artificial fracturing is employed to stimulate HDR and create a network of fractures for geothermal resource extraction. Liquid nitrogen (LN₂) is environmentally friendly and shows better performance in reservoir stimulation than does conventional fracturing. In this study, triaxial compression experiments and acoustic emission location techniques were used to evaluate the impacts of temperatures and confining pressures on the mechanical property deterioration caused by LN₂ cooling. The numerical simulation of LN₂ fracturing was performed, and the results were compared with those for water and nitrogen fracturing. The results demonstrate that the confining pressure mitigated the deterioration effect of LN₂ on the crack initiation stress, crack damage stress, and peak stress. From 20 to 60 MPa, LN₂-induced reductions in these three stress parameters ranged between 7.73–18.51%, 3.46–12.15%, and 2.51–8.50%, respectively. Cryogenic LN₂ increased the number and complexity of cracks generated during rock failure, further enhancing the fracture performance. Compared with those for water and nitrogen fracturing, the initiation pressures of LN₂ fracturing decreased by 61.54% and 68.75%, and the instability pressures of LN₂ fracturing decreased by 20.00% and 29.41%, respectively. These results contribute to the theoretical foundation for LN₂ fracturing in HDR. Full article

Deep hot dry rock (HDR) geothermal energy is a widespread and sustainable renewable energy that could be extracted for the decarbonisation of electricity generation. Measurements are essential for hydraulic fracturing in HDR monitoring, which can be used for assessing the current state and predicting the future performance of geothermal systems. However, a major challenge is that it is difficult to implement hydraulic fracturing for HDR under high-temperature and high-pressure (HTHP) conditions. Similarly, it is hard to conduct laboratory-scale hydraulic fracturing experiments under HTHP due to the sealing failure of injection pipes in boreholes. Therefore, in this paper, we proposed a novel sealing technique by using a wedge-shaped structure for sealing injection pipes under HTHP environments. By conducting numerical simulations and experimental verifications, we discovered that (1) compression stress should be applied on the seal to achieve pre-sealing. Specifically, a compression displacement of between 2 mm and 6 mm is suggested. (2) Copper material with good ductility, high-temperature bearing performance, and excellent thermal expansion is preferred for manufacturing the seal components. (3) Heating-induced thermal expansion of sealing is conducive to re-sealing rocks. Full article

Due to its simple structure and stable operation, the Organic Rankine Cycle (ORC) has gained significant attention as a primary solution for low-grade thermal power generation. However, the economic challenges associated with development difficulties in hot dry rock (HDR) geothermal power systems have necessitated a better balance between performance and cost effectiveness within ORC systems. This paper establishes a game pattern of the Organic Rankine Cycle with performance as the master layer and economy as the slave layer, based on the Stackelberg game theory. The optimal working fluid for the ORC is identified as R600. At the R600 mass flow rate of 50 kg/s, the net system cycle work is 4186 kW, the generation efficiency is 14.52%, and the levelized cost of energy is 0.0176 USD/kWh. The research establishes an optimization method for the Organic Rankine Cycle based on the Stackelberg game framework, where the network of the system is the primary optimization objective, and the heat transfer areas of the evaporator and condenser serve as the secondary optimization objective. An iterative solving method is utilized to achieve equilibrium between the performance and economy of the ORC system. The proposed method is validated through a case study utilizing hot dry rock data from Qinghai Gonghe, allowing for a thorough analysis of the working fluid and system parameters. The findings indicate that the proposed approach effectively balances ORC performance with economic considerations, thereby enhancing the overall revenue of the HDR power system. Full article

The exploration of Hot Dry Rock (HDR) geothermal energy is essential to fulfill the energy demands of the increasing population. Investigating the physical and mechanical properties of heated rock under different cooling methods has significant implications for the exploitation of HDR. In this study, ultrasonic testing, uniaxial strength compression experiments, Brazilian splitting tests, nuclear magnetic resonance (NMR), and scanning electron microscope (SEM) were conducted on heated granite after different cooling methods, including cooling in air, cooling in water, cooling in liquid nitrogen, and cycle cooling in liquid nitrogen. The results demonstrated that the density, P-wave velocity (V_p), uniaxial compressive strength (UCS), tensile strength (σ_t), and elastic modulus (E) of heated granite tend to decrease as the cooling rate increases. Notably, heated granite subjected to cyclic liquid nitrogen cooling exhibits a more pronounced decline in physical and mechanical properties and a higher degree of damage. Furthermore, the cooling treatments also lead to an increase in rock pore size and porosity. At a faster cooling rate, the fracture surfaces of the granite transition from smooth to rough, suggesting enhanced fracture propagation and complexity. These findings provide critical theoretical insights into optimizing stimulation performance strategies for HDR exploitation. Full article

Geothermal resources have been recognized as important sources of clean renewable energy. The exploration, development, and utilization of geothermal resources, especially hot dry rock (HDR) resources, are highly important for achieving peak carbon and carbon neutrality. However, there is no comprehensive evaluation method for determining HDR target areas, and the evaluation scale and application disciplines are relatively simplistic. In this paper, we sought to optimize the identification of HDR target areas through a multiscale and multidisciplinary method and formed a set of generalized and demonstrative processes to guide the exploration of HDR resources. Through practical application to the Gonghe Basin and the Zhangzhou Basin, it was found that the comprehensive geothermal conditions of the Gonghe Basin are superior to those of the Zhangzhou Basin, and the geothermal reservoir depth, geothermal reservoir temperature, geothermal gradient, and heat flow are the four most important factors affecting hot dry rock geothermal resources. Using this method, the prioritization of target areas changes from a qualitative study to a quantitative and semiquantitative study, increasing the specificity and reliability of the decision-making process. Full article

Enhanced geothermal system (EGS) technologies have been developed to improve geothermal energy production from hot dry rock (HDR). In this study, discrete fracture network models for geometric topological networks that consider different parameters (the fracture density and the fracture length index) were built on the basis of fractal geometry theory. The heat extraction processes of CO₂ and water as the working fluid through different discrete fracture networks were simulated with the application of the thermal–hydraulic–mechanical (THM) coupled method. A series of sensitivity analyses were carried out to reveal the influences of fracture parameters on heat transfer processes. Based on the simulation results, heat extraction efficiencies and temperature distributions in the reservoir of CO₂ and water as the working fluid were compared, which showed that CO₂ as the working fluid can bring a faster thermal breakthrough. It was found that the fracture length index a = 2.5 and the fracture density I = 5.0 can provide the highest heat extraction rate compared with other cases. This study provides a detailed analysis of fracture parameters and working fluids, which will contribute to the optimized management of geothermal energy production. Full article

To better understand the geothermal system of the Gonghe Basin, we deployed 471 magnetotelluric survey points with an average distance of 2~3 km, covering the eastern and southern areas of the Basin. We used ModEM inversion software to carry out 3D inversion of 431 survey points and established a 3D-electrical model at a depth of 50 km in the area. The resistivity model shows that the low resistivity in the shallow part of the basin is related to the Cenozoic loose sedimentary cover, while the resistivity values of the mountains around the basin and the magmatic rock uplift zone are higher. The electrical model also shows that the high-conductivity layer is widely distributed in the middle and lower crust (15~35 km) of the basin, and direction of the high-conductivity layer is consistent with that of NW–SE fault in the basin. These high-conductivity layers may be the principal reason for the high heat flow values in the Gonghe Basin. Our resistivity model also shows that there is an obvious discontinuity between high- and low-resistivity blocks at different depths in the middle and upper crust. These discontinuities are consistent with the faults observed on the surface, which are related to the strong topographic relief. Our electrical model shows that these faults in the middle and upper crust are connected with the high-conductivity layer as the channel of heat transfer to the shallow part. Finally, the heat energy is enriched in the Triassic granite to form dry hot rock (HDR). The 3D-magnetotelluric imaging results depict the 3D-distribution characteristics of the geothermal system in the eastern and southern parts of the Gonghe Basin. Full article

This paper presents a numerical study on thermal energy mining from hot dry rock (HDR) using an enhanced geothermal system (EGS). In these simulations, the thermal–hydraulic–mechanical (THM) coupling model is employed on the basis of the embedded discrete fracture model. The evolution of physical fields of the fractured reservoir, including temperature field, pressure field, and stress field is studied over time, and the effects of different controllable factors, such as fracture morphology, fluid injection rate, and the distances between the injection well and producing well on the heat recovery capacity are investigated. The results show that the fracture morphology significantly influences heat extraction performance. The working fluid mainly flows along with the fracture networks, which causes locally low temperatures and low mean effective stress near fractures. The porosity and permeability increase due to the decrease in mean effective stress. For reservoir models with inclined fractures, there will be a significant decrease in the extraction temperature. In the 30th year, the decline in the heat recovery rate is 46.6%, which is much higher than the model without inclined fractures. Moreover, the increasing injection temperature barely influences the production temperature, while it significantly decreases the heat recovery of the EGS. When the injection and production well spacing is small, increasing the well spacing is an effective way to improve the thermal extraction performance of the EGS. In the model in the paper, the heat production increases up to 13.7% when the injection-production well spacing is increased from 150 m to 450 m. The results of this work could provide guidance for the optimization and operation of EGS. Full article
