Search Results (37)

This study establishes a standardized framework for thermal propagation test in nickel-7 lithium-ion battery systems through a high-frequency electromagnetic induction heating method. The non-intrusive triggering mechanism enables precise thermal runaway initiation within two seconds through localized eddy current heating (>1200 °C), validated through cell-level tests with 100% success rate across diverse trigger positions. System-level thermal propagation tests were conducted on two identical battery boxes. The parallel experiments revealed distinct propagation patterns influenced by system sealing quality. In the inadequately sealed system (Box 01), flame formation led to accelerated thermal propagation through enhanced convective and radiative heat transfer. In contrast, the well-sealed system (Box 02) maintained an oxygen-deficient environment, resulting in a controlled sequential propagation pattern. The testing methodology incorporating dummy modules proved efficient for validating thermal protection strategies while optimizing costs. This study contributes to a deeper understanding of thermal runaway propagation mechanisms and the development of standardized testing protocols for large-format battery systems. Full article

This paper reviews the current state of research on half-bridge (HB) inverters used in induction heating power supplies, emphasizing their topological structures, output power control methods, and switching strategies. The study explores various control techniques to regulate low power levels in a series resonant inverter (SRI) configured with an HB structure for induction heating applications. Pulse frequency modulation (PFM) is commonly employed to regulate standard power levels by adjusting the operating frequency relative to the resonant frequency. As the operating frequency increases beyond resonance, the output power decreases. However, in certain scenarios, achieving low power levels necessitates high frequencies, which introduces significant control challenges. To address these issues, it is crucial to develop alternative approaches that ensure efficient power reduction, without compromising system performance. This work evaluates and compares multiple solutions tailored for a high-frequency induction heating system delivering 18 kW at an operating frequency of approximately 100 kHz. The study places particular emphasis on optimizing key component sizing and analyzing inverter losses to enhance overall system efficiency and reliability. Full article

The article presents basic information about the induction heating of gears, which are widely used in various industries. This article presents the methodology and results of a coupled FEM simulation of a circuit model for a power electronics converter connected to an inductor-charged heating system. The induction heating of gears was performed using a high-frequency inverter with SiC MOSFET transistors. A prototype inverter was built using a full-bridge structure with a series-parallel resonant circuit. The operating frequency was 350 kHz, the output power of the inverter was 3.5 kW, and the drain efficiency was equal to 96%. Coupled simulation was performed for a charge in the form of a gear made of 42CrMo4 steel (material parameters are provided in the article) for two types of heating: with and without a magnetic field concentrator. In addition, the article presents the results of co-simulation studies in the following form: a distribution of magnetic induction in the gear, energy density in the gear, the characteristics of energy density in a single tooth on the 8 mm length and the temperature of the tooth tip for two types of induction heating. Full article

Induction heating technology plays a significant role in heating applications with its high efficiency, fast response, and precise control ability. Traditional resonant inverter-based systems face problems such as complexity, lack of flexibility, and low efficiency in multi-load situations. To overcome these issues, a new non-resonant full-bridge multiple-output inverter topology using silicon carbide (SiC) semiconductor devices is presented. While the system is simplified by eliminating resonant components, efficiency is increased thanks to SiC devices. In the study, a coil design methodology focusing on coil resistance and inductance is presented to optimize energy transfer and maximize system performance. Load-sensing and advanced frequency-modulation techniques are integrated to provide precise and independent power regulation in multi-loads. Thus, the efficiency of energy distribution and system robustness are increased. The proposed topology offers heating performance that provides homogeneous heat distribution. The developed prototype was proven to operate reliably with high efficiency under different load conditions and was suitably applied for domestic induction heating applications. An efficiency of 96.78% was achieved at a 50 kHz operating frequency and 2000 W power level. Full article

The application of induction heating power supply in the continuous production line of tinplate has garnered significant research and scholarly attention. However, the impedance matching of LC or CLC resonant circuits in the system lacks flexibility and is susceptible to overvoltage during startup. As a solution to the problem, a novel four-order LCLC parallel resonant circuit was proposed in this study for high-frequency induction heating power supply. By incorporating auxiliary inductors in parallel with CLC compensating capacitor branches, the induction heating system can operate reliably and achieve optimal load impedance matching. The equivalent circuit and mathematical model of the new resonant load were established, and the frequency characteristics of the circuit system were analyzed. Then, the parallel resonance characteristics of the new resonant circuit were comprehensively elucidated, including the quality factor, impedance characteristics, behavior of resonant current, and properties of voltage regulation. Finally, a simulation model of a high-frequency induction heating power supply was developed based on the proposed LCLC resonant circuit and compared with LC and CLC resonant circuits. The results demonstrated that the induction heating power supply system utilizing the proposed LCLC parallel resonant load exhibits superior parallel resonant characteristics, enhanced load impedance-matching flexibility, and improved output voltage stability when compared to traditional LC or CLC parallel resonant loads. Full article

The use of wide band gap (WBG) semiconductor switches in power converters is increasing day by day due to their superior chemical and physical properties, such as electrical field strength, drift speed, and thermal conductivity. These new-generation power switches offer advantages over traditional induction cooker systems, such as fast and environmentally friendly heating. The size of passive components can be reduced, and the decreasing inductance value of induction coils and capacitors with low ESR (equivalent series resistance) values contributes to total efficiency. Other design parameters, such as passive components with lower values, heatsinks with low volumes, cooling fans with low power, and induction coils with fewer turns, can offset the cost of WBG power devices. High-frequency operation can also be effective in heating non-ferromagnetic materials like aluminum and copper, making them suitable for heating these types of pans without complex induction coil and power converter designs. However, the use of these new generation power switches necessitates a re-examination of induction coil design. High switching frequency leads to a high resonance frequency in the power converter, which requires lower-value passive components compared to conventional cookers. The most important component is the induction coil, which requires fewer turns and magnetic cores. This study examines the induction heating equivalent circuit, discusses the general structure and design parameters of the induction coil, and performs FEM (finite element method) analyses using Ansys Maxwell. The results show that the induction coil inductance value in new-generation cookers decreases by 80% compared to traditional cookers, and the number of windings and magnetic cores decreases by 50%. These analyses, performed for high-power applications, are also performed for low-power applications. While the inductance value of the induction coil is 90 μH at low frequencies, it is reduced to the range of 5 μH to 20 μH at high frequencies. The number of windings is reduced by half or a quarter. The new-generation cooker system experimentally verifies the coil design based on the parameters derived from the analysis. Full article

This paper presents new resonant inverter topologies for dual-frequency induction heating (IH). These 2T1C and 3T topologies combine the advantageous features of two- and one-inverter solutions. An analytical description of the load impedance of a dual-frequency series-parallel circuit has been made. Using manufacturer datasheets and LTspice models of selected transistors, a MATLAB model was parameterized. Based on it, power losses are determined as a function of the following parameters: nominal power, frequency and DC bus voltage. The obtained results allowed for determining the data necessary in the design process. The research has been experimentally verified. Tests were carried out for pulsing and simultaneous operation. Power control characteristics as a function of frequency are determined. The possibility of operating the inverter with high efficiency (>97%) in the proposed 2T1C and 3T systems at nominal power is demonstrated. Full article

This paper proposes a single-stage direct AC to high-frequency (HF) AC resonant converter based on LLC configuration for induction heating (IH) systems or HF applications. Unlike conventional converters for IH systems, the proposed topology converts the utility frequency to HF AC in a single stage without using a DC link inductor and capacitors and takes the advantages of LLC configuration. Additionally, it improves the power factor to 0.9–1, lowers the THD (3.2% experimentally), and protects against the high-frequency components. An embedded control scheme was designed to keep the HF current oscillating at a resonant frequency, ensuring zero-voltage switching. The operating principle of the proposed topology was investigated using mathematical equations and equivalent circuits. Finally, it was verified using computer simulation, and an experimental prototype of 1.1 kW was developed to demonstrate the proposed topology’s uniqueness. Full article

This article presents the technical aspects that may reduce electric power consumption during the welding of pipes with the high-frequency induction (HFI) method. Experiments were carried out at Huta Łabędy S.A. Steelworks, during the test production of 323.9 × 5.6 mm pipes of P235GH steel grade. Two sets of HFI heating system settings were studied: with a variable squeeze force of the heated edges and a variable position of the inductor in relation to the welding point. It was proven that the temperature at the welding point increased due to the stronger squeeze of the heated edges, which reduced the electric power consumption. Reducing the distance of the inductor relative to the welding point had the same effect. By optimizing the squeeze force and the position of the inductor, energy consumption was reduced by about 5.5%. Microstructural studies of the welds did not show any adverse effects of the optimization. Full article

In this paper, an inductive power transfer (IPT) system without compensation elements is presented for small house appliances. The proposed system’s transmitter side is an independent induction heating cooktop. IPT can be achieved when the kettle with the receiving coils is placed on the transmitter coil. The coils are designed with a high coupling coefficient. The magnetic system model consisting of aligned transmitter and receiver coils is created in the Maxwell program. In the created model, the analysis depends on the air gap and frequency, which are the variables that affect the wireless power transfer. The electronic circuit simulation uses the coil model to examine the system’s dynamic behavior. The design of the transmitter/receiver coils of the IPT system is made with a cylindrical coil with a diameter of 145 mm, taking into account that it is compatible with the dimensions of the existing kettle and induction heating cooktops coil. A half-bridge series resonant converter circuit is used to adjust the power transferred to the load. To verify the simulation results and test the designed system, an experimental circuit using a 2200 W kettle is carried out. In the experiments, the air gap between the coils is kept constant at 7 mm, and measurements are taken for different powers. Experimental results confirm the magnetic model and simulation results. As a result, wireless power transfer is realized in a wide range without loss of performance in the kettle. System efficiency is greater than the 90% specified in the Ki cordless kitchen standard, and the harmonic currents drawn from the mains are lower than the values determined by the IEC 61000-3-2 standard. Full article

This paper presents a novel single-phase modified Vienna rectifier (MVR) for the harmonic mitigation and power factor improvement of an induction heating (IH) system. The latter employs a high-frequency resonant inverter that is responsible for the generation of high-frequency harmonics, which, in turn, deteriorates the power quality. This mitigation must be done in accordance with harmonic regulations such as IEEE Std. 519-2014,IEC-555, and EN 61000-3-2, etc. Consequently, an MVR is placed between the power supply and the IH system. The proposed novel MVR topology overcomes the limitations of conventional Vienna rectifiers, such as their unbalanced voltage across output capacitors, high ripple at the output DC bus, and high THD in the supply current, etc. The efficacy of the proposed model has been verified by a series of simulations in PSIM. It is followed by a hardware validation using an Arduino Uno ATmega328 digital controller on a 1.2 kW experimental prototype of the IH system. The simulation and experimental results of the power quality indices comply with the IEEE-519 standards. Full article

Lubricants have the ability to reduce frictions, prevent wear, convey metal debris particles and increase the efficiency of heat transfer; therefore, they have been widely used in mechanical systems. To assess the safety and reliability of the machine under operational conditions, the development of inductive debris sensors for the online monitoring of debris particles in lubricants has received more attention from researchers. To achieve a high-precision, high-efficiency sensor for accurate prediction on the degree of wear, the equivalent circuit model of the sensor coil has been established, and its equations discovering the relationship between the induced voltage and excitation frequency have been derived. Furthermore, the influence of excitation frequencies and metal debris on the magnetic flux density has been analyzed throughout the simulations to determine the sensor magnetic field. In order to identify a frequency range suitable for detecting both ferrous and non-ferrous materials with a high level of sensitivity, the analytical analysis and experiments have been conducted to investigate the frequency characteristics of the developed inductive debris sensor prototype and its improved inspection capability. Moreover, the developed inductive debris sensor with the noticeable frequency characteristics has been assessed and its theoretical model has been also validated throughout experimental tests. Results have shown that the detection sensitivity of non-ferrous debris by the developed sensor increases with the excitation frequency in the range of 50 kHz to 250 kHz, while more complex results for the detection of ferrous debris have been observed. The detection sensitivity decreases as the excitation frequency increases from 50 kHz to 300 kHz, and then increases with the excitation frequency from 300 kHz to 370 kHz. This leads to the effective selection of the excitation frequency in the process of inspection. In summary, the investigation into the frequency characteristics of the proposed novel inductive debris sensor has enabled its broad applications and also provided a theoretical basis and valuable insights into the development of inductive debris sensors with improved detection sensitivity. Full article

Studies about adding graphene reinforcement to improve the microfabrication performance of alumina (Al₂O₃) ceramic materials are still too rare and incomplete to satisfy sustainable manufacturing requirements. Therefore, this study aims to develop a detailed understanding of the effect of graphene reinforcement to enhance the laser micromachining performance of Al₂O₃-based nanocomposites. To achieve this, high-density Al₂O₃ nanocomposite specimens were fabricated with 0 wt.%, 0.5 wt.%, 1 wt.%, 1.5 wt.%, and 2.5 wt.% graphene nanoplatelets (GNPs) using a high-frequency induction heating process. The specimens were subjected to laser micromachining. Afterward, the effects of the GNP contents on the ablation depth/width, surface morphology, surface roughness, and material removal rate were studied. The results indicate that the micro-fabrication performance of the nanocomposites was significantly affected by the GNP content. All nanocomposites exhibited improvement in the ablation depth and material removal rate compared to the base Al₂O₃ (0 wt.% GNP). For instance, at a higher scanning speed, the ablation depth was increased by a factor of 10 times for the GNP-reinforced specimens compared to the base Al₂O₃ nanocomposites. In addition, the MRRs were increased by 2134%, 2391%, 2915%, and 2427% for the 0.5 wt.%, 1 wt.%, 1.5 wt.%, and 2.5 wt.% GNP/Al₂O₃ nanocomposites, respectively, compared to the base Al₂O₃ specimens. Likewise, the surface roughness and surface morphology were considerably improved for all GNP/Al₂O₃ nanocomposite specimens compared to the base Al₂O₃. This is because the GNP reinforcement reduced the ablation threshold and increased the material removal efficiency by increasing the optical absorbance and thermal conductivity and reducing the grain size of the Al₂O₃ nanocomposites. Among the GNP/Al₂O₃ nanocomposites, the 0.5 wt.% and 1 wt.% GNP specimens showed superior performance with minimum defects in most laser micromachining conditions. Overall, the results show that the GNP-reinforced Al₂O₃ nanocomposites can be machined with high quality and a high production rate using a basic fiber laser system (20 Watts) with very low power consumption. This study shows huge potential for adding graphene to alumina ceramic-based materials to improve their machinability. Full article

Metal foreign objects will not only reduce the output power and efficiency of the wireless power transfer (WPT) system, but also will be heated under the eddy current effect. The method based on the detection coil array has been wildly adopted for foreign object detection (FOD), especially in high-power level WPT applications. However, the problems of low sensitivity or misjudgment still exist which leads to a safety hazard. Therefore, high sensitivity of the foreign object-detection method based on the excitation frequency optimization has been proposed in this paper. Based on the impedance change of the detection coil caused by the foreign object coupling, the frequency characteristics of detection sensitivity were analyzed under the conditions of different self-inductance detection coils. Then, the detection coil was designed and its corresponding optimal excitation frequency was selected to achieve the optimal detection effect to eliminate the area of low detection sensitivity. Finally, an FOD experimental prototype was established to verify the proposed frequency optimization strategy. The results show that the sensitivity of the FOD system is up to 97.56%. With the optimal excitation frequency of 6.22 MHz, as for 1-yuan coin in the center position and corner position of the detection coil, the detection sensitivity is 92.89% and 40.16%, respectively, which is 22.13% and 23.89% higher than that of the excitation frequency is 1 MHz. The improvement of detection sensitivity is helpful to detect accurately and eliminate the detection blind area. Full article

Thermoacoustic instabilities occur when heat release is coupled with pressure fluctuation, which may cause performance degradation of the combustor and serious structural damage. This study focued on an active control method using discharge plasma and showed experimentally that discharge plasma can make a difference in controlling the thermoacoustic instabilities in a Rijke tube. A vertically placed Rijke tube thermoacoustic system using induction heating tungsten mesh as a heat source was built. The results show that the high repetition rate discharge can effectively suppress the thermoacoustic oscillations in the Rijke tube and that they will not re-occur for some time. Additionally, their effectiveness depended more on average power than energy per pulse. Combining the collected pressure, schlieren data, and theoretical analysis, it can be suggested that the plasma discharge could heat the inlet airflow, which could influence the heat exchange and then could break thermo-acoustic coupling, and its high-frequency pressure perturbation might increase the dissipation of the energy of sound. Full article
