Three-dimensional (3D) radar imaging is essential for target detection and measurement of scattering characteristics. Cylindrical scanning, a prevalent spatial sampling technique, provides benefits in engineering applications and has been extensively utilized for assessing the radar stealth capabilities of large aircraft. Traditional cylindrical scanning generally utilizes highly sampled full-coverage techniques, leading to an excessive quantity of sampling points and diminished image efficiency, constraining its use for quick detection applications. This work presents an efficient 3D sampling strategy that integrates vertical linear scanning with horizontal rotating motion to overcome these restrictions. A joint angle–space sampling model is developed, and geometric constraints are implemented to enhance the scanning trajectory. The experimental results demonstrate that, compared to conventional techniques, the proposed method achieves a 94% reduction in the scanning duration while maintaining a peak sidelobe level ratio (PSLR) of 12 dB. Furthermore, this study demonstrates that 3D imaging may be accomplished solely by a “V”-shaped trajectory, efficiently determining the minimal possible sampling aperture. This approach offers novel insights and theoretical backing for the advancement of high-efficiency, low-redundancy 3D radar imaging systems. Full article

In recent years, synthetic aperture radars (SARs) have been widely applied in various fields due to their all-weather, day-and-night global imaging capabilities. As one of the most common types of antennas, the reflector antenna offers some advantages for spaceborne radars, including low cost, lightweight, high gain, high radiation efficiency, and low sidelobes. Consequently, spaceborne SAR systems based on reflector antennas exhibit significant potential. This paper reviews the main types and characteristics of reflector antennas, with particular attention to the structural configurations and feed arrangements of deployable reflector antennas in spaceborne SAR applications. Additionally, some emerging techniques, such as digital beamforming, staggered SAR, and SweepSAR based on reflector antennas, are examined. Finally, future development directions in this field are discussed, including high-resolution wide-swath imaging and advanced antenna deployment schemes. Full article

Capacitive micromachined ultrasonic transducers (CMUTs) have been developed for air-coupled applications to address key challenges such as noise, prolonged ringing, and side-lobe interference. This study introduces an optimized CMUT design that leverages the squeeze-film damping effect to achieve a low-quality factor, enhancing resolution and temporal precision for imaging as one of the suggested airborne application. The device was fabricated using the PolyMUMPs process, ensuring high structural accuracy and consistency. Finite element analysis (FEA) simulations validated the optimized parameters, demonstrating improved displacement, reduced side-lobe artifacts, and sharper main lobes for superior imaging performance. Experimental validation, including Laser Doppler Vibrometer (LDV) measurements of membrane displacement and mode shapes, along with ring oscillation tests to assess Q-factor and signal decay, confirmed the device’s reliability and consistency across four CMUT arrays. Additionally, this study explores the implementation of multi-frequency CMUT arrays, enhancing imaging versatility across different air-coupled applications. By integrating multiple frequency bands, the proposed CMUTs enable adaptable imaging focus, improving their suitability for diverse diagnostic scenarios. These advancements highlight the potential of the proposed design to deliver a superior performance for airborne applications, paving the way for its integration into advanced diagnostic systems. Full article

A low-profile dual-polarized shared-aperture phased array antenna is proposed for Ku-band satellite communications in this paper. The stacked octagonal patches loaded with Via-rings are proposed as dual-polarized shared-aperture radiation elements, with the characteristics of wide impedance bandwidth, high gain, and weak coupling. Furthermore, innovative minimized three-port ring couplers are utilized for the differential-fed antenna array, further suppressing the cross-polarization component. Substrate integrated coaxial line (SICL) and microstrip line (MS) feed networks are employed for the excitation of transmitting band (Tx) horizontal polarization and receiving band (Rx) vertical polarization, respectively. The non-uniform subarray architecture is optimized to minimize the sidelobe levels with the reduced number of transmitter and receiver (T/R) radio frequency phase-shifting modules. As proof-of-concept examples, 16 × 24 and 32 × 24 array antennas are demonstrated and fabricated. The measured impedance bandwidths of the proposed phased array antennas are around 21.1%, while the in-band isolations are above 36.7 dB. Gains up to 29 dBi and 32.4 dBi are performed by two prototypes separately. In addition, the T/R phase-shifting modules are utilized to validate the beam-scanning characteristic, which is of value for dynamic satellite communications. Full article

Interrupted sampling repeater jamming (ISRJ) is characterized by its coherent processing gains and flexible modulation techniques. ISRJ generates spurious targets along the range, which presents significant challenges to the radar systems. However, existing ISRJ countermeasure methods struggle to eliminate ISRJ signals without compromising the integrity of the real target signal, especially under low-signal-to-noise-ratio (SNR) conditions, resulting in a deteriorated sidelobe and diminished detection performance. We propose a complex-valued encoder–decoder network (CVEDNet) to address these challenges based on signal decomposition. This network offers an end-to-end ISRJ suppression approach, working on complex-valued time-domain signals without the need for additional preprocessing. The encoding and decoding structure suppresses noise components and obtains more compact echo feature representations through layer-by-layer compression and reconstruction. A stacked dual-branch structure and multi-scale dilated convolutions are adopted to further separate the echo signal and ISRJ based on high-dimensional features. A multi-domain combined loss function integrates the waveform and range-pulse-compression information to ensure the amplitude and phase integrity of the reconstructed echo waveform during the training process. The effectiveness of the proposed method was validated in terms of its jamming suppression capability, echo fidelity, and detection performance indicators under low-SNR conditions compared to conventional methods. Full article

This paper proposes a new carrier domain approach to suppress spreading first-order sea clutter in shipborne passive radar systems using Digital Radio Mondiale (DRM) signals as illuminators. The DRM signal is a broadcast signal that operates in the high-frequency (HF) band and employs orthogonal frequency-division multiplexing (OFDM) modulation. In shipborne DRM-based passive radar, sea clutter sidelobes elevate the noise level of the clutter-plus-noise covariance matrix, thereby degrading the target signal-to-interference-plus-noise ratio (SINR) in traditional space–time adaptive processing (STAP). Moreover, the limited number of space–time snapshots in traditional STAP algorithms further degrades clutter suppression performance. By exploiting the multi-carrier characteristics of OFDM, this paper proposes a novel algorithm, termed Space Time Adaptive Processing by Carrier (STAP-C), to enhance clutter suppression performance. The proposed method improves the clutter suppression performance from two aspects. The first is removing the transmitted symbol information from the space–time snapshots, which significantly reduces the effect of the sea clutter sidelobes. The other is using the space–time snapshots obtained from all subcarriers, which substantially increases the number of available snapshots and thereby improves the clutter suppression performance. In addition, we combine the proposed algorithm with the dimensionality reduction algorithm to develop the Joint Domain Localized-Space Time Adaptive Processing by Carrier (JDL-STAP-C) algorithm. JDL-STAP-C algorithm transforms space–time data into the angle–Doppler domain for clutter suppression, which reduces the computational complexity. Simulation results show the effectiveness of the proposed algorithm in providing a high improvement factor (IF) and less computational time. Full article

This work presents a comprehensive study on formulations for the radiation pattern design of antenna arrays through convex optimization techniques, with a focus on linear, quadratic, and second-order cone programming. The proposed approaches heavily rely on the construction of Hermitian forms to systematically build convex optimization problems for synthesizing desired beam patterns while including practical constraints such as sidelobe levels (SLLs), maximum directivity, and null placement. By formulating the radiation pattern synthesis problem through a convex formulation, global optimality and computational efficiency are ensured. The paper introduces the mathematical foundations of the proposed methodologies, detailing the structure and benefits of each convex optimization model. Numerical examples demonstrate the effectiveness of the proposed methodologies in achieving high-performance radiation patterns for circular and planar arrays. The results highlight trade-offs between formulation complexity and pattern performance across different optimization models, providing valuable insights for antenna array pattern synthesis. Overall, this work underscores the potential of convex optimization in antenna array pattern synthesis methodologies. Full article

A well-known and powerful convex optimization strategy is exploited to enhance the electromagnetic performance of the Square Kilometer Array Low-Frequency radio telescope. The proposed method minimizes the peak sidelobe level while ensuring full control of the receiving pattern across the entire angular domain. The approach is validated through full-wave simulations that incorporate realistic embedded element patterns, demonstrating significant improvements in sidelobe suppression despite the geometric constraints of the array structure. The achieved results underscore the method’s potential for high-performance beam synthesis in large-scale radio astronomy arrays. Full article

The interference of sidelobe often causes different targets to exhibit similar features, diminishing fine-grained classification accuracy. This effect is particularly pronounced when the available data are limited. To address the aforementioned issues, a novel classification framework for sidelobe-affected SAR imagery is proposed. First, a method based on maximum median filtering is adopted to remove sidelobe by exploiting local grayscale differences between the target and sidelobe, constructing a high-quality SAR dataset. Second, a deep metric learning network is constructed for fine-grained classification. To enhance the classification performance of the network on limited samples, a feature extraction module integrating a lightweight attention mechanism is designed to extract discriminative features. Then, a hybrid loss function is proposed to strengthen intra-class correlation and inter-class separability. Experimental results based on the FUSAR-Ship dataset demonstrate that the method exhibits excellent sidelobe suppression performance. Furthermore, the proposed framework achieves an accuracy of 84.18% across five ship target classification categories, outperforming the existing methods, significantly enhancing the classification performance in the context of sidelobe interference and limited datasets. Full article

With the increasing complexity of the electromagnetic environment, radar waveform design needs to break through the limitation of traditional single-function architectures, prompting the emergence of integrated radar waveforms. Currently, the mainstream integrated signals are achieved through conventional waveform synthesis or time/frequency division multiplexing. However, the former suffers from limited design flexibility and is confined to single scenario applications, while the latter has interference between different sub-channels, which will limit the performance of multi-function radar. Aiming at the above problems, this paper proposes a waveform optimization method for a detection and cover integrated signal with high Doppler tolerance. By constructing a joint optimization model, the sidelobe characteristics of the signal’s autoambiguity function and the output response of the non-cooperative matched filter were incorporated into the unified objective function framework. The gradient descent algorithm is used to solve the model, and the optimized waveform with low sidelobe characteristics and multiple false target interference abilities is obtained. When the optimized waveform generates multiple false targets to cover our radar position, its peak sidelobe level (PSL) drops below −23 dB, and most of the sidelobe levels in the range-Doppler interval of interest drop below −40 dB. Finally, the proposed integrated waveform undergoes hardware-in-the-loop experiments, experimentally validating its performance and the effectiveness of the proposed method. Full article

When frequency-modulated continuous-wave (FMCW) laser radar (Ladar) is employed for three-dimensional imaging, the echo signal is susceptible to modulation nonlinearity and platform vibration due to modulation and the short wavelength. These effects cause main-lobe widening, side-lobe elevation, and positional shift, which degrades distance detection accuracy. To solve these problems, this paper proposes a compensation method combining multiple synchrosqueezing transform (MSST), equal-phase interval resampling, and high-order ambiguity function (HAF). Firstly, variational mode decomposition (VMD) is applied to the optical prism signal to eliminate low-frequency noise and harmonic peaks. MSST is used to extract the time–frequency curve of the optical prism. The nonlinearity in the transmitted signal is estimated by two-step integration. An internal calibration signal containing nonlinearity is constructed at a higher sampling rate to resample the actual signal at an equal-phase interval. Then, HAF compensates for high-order vibration and residual phase error after resampling. Finally, symmetrical triangle wave modulation is used to remove constant-speed vibration. Verifying by actual data, the proposed method can enhance the main lobe and suppress the side lobe about 1.5 dB for a strong reflection target signal. Natural-target peaks can also be enhanced and the remaining peaks are suppressed, which is helpful to extract an accurate target distance. Full article

Faced with increasingly complex electronic jamming environments, intra-pulse agility has become a primary method of anti-interrupted-sampling repeater jamming (ISRJ) for radar systems. However, existing intra-pulse agile signals suffer from high autocorrelation sidelobe levels and limited jamming suppression capabilities. These issues restrict the performance of intra-pulse agile signals in complex electromagnetic environments.This paper proposes an anti-interrupted-sampling repeater jamming method based on Simulated Annealing–2-optimization (SA-2opt) parallel optimization of waveforms and fractional domain extraction. Firstly, the proposed method employs the SA-2opt parallel optimization algorithm to optimize the joint frequency and chirp rate encoding waveform. Then, the received signal is subjected to the fractional Fourier transform (FrFT) and inverse transform to extract the target signal. Finally, jamming detection is conducted based on the multi-dimensional features of the pulse-compressed signal. After this detection, a time-domain filter is constructed to achieve jamming suppression. The optimized waveform exhibits the following advantages: the sub-pulses are orthogonal to each other, and autocorrelation sidelobe levels are as low as -20.7dB. The method proposed in this paper can achieve anti-ISRJ in the case of a high jamming-to-signal ratio (JSR). Simulation experiments validate both the effectiveness of the optimized waveform in achieving low autocorrelation sidelobes and the anti-ISRJ performance of the proposed method. Full article

Delay and sum (DAS) is one of the most common beamforming algorithms for photoacoustic image reconstruction. Owing to its high computational efficiency and ease of implementation, this method is particularly well-suited for real-time photoacoustic imaging. However, its shortcomings, such as that the algorithm can make high sidelobes and strong artifacts, are as prominent as its advantages. Some improved algorithms based on spatial coherence theory, such as DMAS, have significantly enhanced imaging quality. In this paper, we analyzed the beamforming principle and propose a photoacoustic imaging method by combining windowed enveloping and the delay and sum beamforming algorithm. The delay and sum beamforming algorithm is used for ensuring high computational efficiency, and windowed enveloping for the suppression of sidelobes and artifacts. Tests were performed for a simple circular source model and a multiple-source model. The results show that our method can effectively improve the quality of reconstructed images compared with DAS and some improved methods. In addition, this method also retains the advantage of the high parallelism of the DAS algorithm and is suitable for real-time imaging systems. Full article

In recent years, several advantages of noise radars have positioned this technology as a promising alternative to conventional radar technology. Immunity to jamming, low mutual interference, and low probability of interception are good examples of these advantages. However, the nature of random sequences introduces several issues, such as fluctuations in the range sidelobes of the autocorrelation function causing high sidelobe levels, hence not exploitable by radar systems. This study introduces the use of multi-objective evolutionary (MOE) algorithms to design noise radar waveforms with good autocorrelation properties as well as a low peak-to-average power ratio (PAPR). A set of Pareto-optimal waveforms are produced and, most importantly, entropy is introduced as a constraint in order to maintain the transmitted signal close to a full non-deterministic waveform. Moreover, a relation between PAPR and negentropy (negative entropy) is established theoretically and validated with other authors’ simulations. Full article

In the distributed multiple input multiple output (MIMO) system with the integrated radar and communication (IRAC) waveform transmitted, the synthesized transmit beampattern usually suffers from high sidelobes. To decrease the sidelobes of the transmit beampattern and accomplish radar and communication functions simultaneously in the distributed MIMO system, this paper proposes two IRAC waveform design methods. First, to minimize the maximal sidelobe of the transmit beampattern, this paper proposes the IRAC waveform design method with low sidelobes, and the designed IRAC waveform can produce the desired radar waveform in the target direction and communication waveform in the user direction, respectively. However, the designed IRAC waveform may have non-constant modulus, and it will be distorted if the power amplifier works in the saturation region. Then, to make sure the modulus of the designed IRAC waveform is constant, this paper proposes the IRAC waveform design method with constant modulus. In addition to producing the desired waveforms, the designed IRAC waveform has constant modulus. Moreover, the transmit beampattern has low sidelobes. Finally, the simulation results show that the proposed IRAC waveform design methods can simultaneously accomplish radar and communication functions and form the transmit beampattern with low sidelobes. Full article
