Mesoscale coastal eddies are key components of ocean circulation, mediating the transport of heat, nutrients, and marine debris. The Surface Water and Ocean Topography (SWOT) mission provides high-resolution sea surface height data, offering a novel opportunity to improve the observation and characterization of these features, especially in coastal regions where conventional altimetry is limited. In this study, we investigate a mesoscale anticyclonic coastal eddy observed southwest of Mallorca Island, in the Balearic Sea, to assess the impact of SWOT-enhanced altimetry in resolving its structure and dynamics. Initial eddy identification is performed using satellite ocean color imagery, followed by a qualitative and quantitative comparison of multiple altimetric datasets, ranging from conventional nadir altimetry to wide-swath products derived from SWOT. We analyze multiple altimetric variables—Sea Level Anomaly, Absolute Dynamic Topography, Velocity Magnitude, Eddy Kinetic Energy, and Relative Vorticity—highlighting substantial differences in spatial detail and intensity. Our results show that SWOT-enhanced observations significantly improve the spatial characterization and dynamical depiction of the eddy. Furthermore, Lagrangian transport simulations reveal how altimetric resolution influences modeled transport pathways and retention patterns. These findings underline the critical role of SWOT in advancing the monitoring of coastal mesoscale processes and improving our ability to model oceanic transport mechanisms. Full article

In recent years, synthetic aperture radars (SARs) have been widely applied in various fields due to their all-weather, day-and-night global imaging capabilities. As one of the most common types of antennas, the reflector antenna offers some advantages for spaceborne radars, including low cost, lightweight, high gain, high radiation efficiency, and low sidelobes. Consequently, spaceborne SAR systems based on reflector antennas exhibit significant potential. This paper reviews the main types and characteristics of reflector antennas, with particular attention to the structural configurations and feed arrangements of deployable reflector antennas in spaceborne SAR applications. Additionally, some emerging techniques, such as digital beamforming, staggered SAR, and SweepSAR based on reflector antennas, are examined. Finally, future development directions in this field are discussed, including high-resolution wide-swath imaging and advanced antenna deployment schemes. Full article

To satisfy the requirement of the modern spaceborne synthetic aperture radar (SAR) system, SAR imaging mode design makes a trade-off between resolution and swath coverage by controlling radar antenna sweeping. Existing spaceborne SAR systems can perform earth observation missions well in various modes, but they still face challenges in data acquisition, storage, and transmission, especially for high-resolution wide-swath imaging. In the past few years, sparse signal processing technology has been introduced into SAR to try to solve these problems. In addition, sparse SAR imaging shows huge potential to improve system performance, such as offering wider swath coverage and higher recovered image quality. In this paper, the design scheme of spaceborne sparse SAR imaging modes is systematically introduced. In the mode design, we first design the beam positions of the sparse mode based on the corresponding traditional mode. Then, the essential parameters are calculated for system performance analysis based on radar equations. Finally, a sparse SAR imaging method based on mixed-norm regularization is introduced to obtain a high-quality image of the considered scene from the data collected by the designed sparse modes. Compared with the traditional mode, the designed sparse mode only requires us to obtain a wider swath coverage by reducing the pulse repetition rate (PRF), without changing the existing on-board system hardware. At the same time, the reduction in PRF can significantly reduce the system data rate. The problem of the azimuth ambiguity signal ratio (AASR) increasing from antenna beam scanning can be effectively solved by using the mixed-norm regularization-based sparse SAR imaging method. Full article

Synthetic aperture radar (SAR) is an all-weather and all-day imaging technique for Earth observation. Achieving efficient observation, high resolution, and wide swath coverage have remained critical development goals in SAR technology, which inherently require extended synthetic aperture time. However, various non-ideal factors, including atmospheric disturbances, orbital perturbations, and antenna vibrations. degrade imaging performance, causing defocusing and ghost targets. Furthermore, the long synthetic time and large imaging swath further enlarge the temporal and spatial variability of these factors and seriously degrade the imaging effect. These inherent challenges make autofocusing indispensable for SAR imaging with a long synthetic time and large swath. In this paper, a novel autofocus method specifically designed to address these non-ideal factors is proposed for SAR imaging with a long synthetic time and large swath. The innovation of the method mainly consists of two parts. The first is the autofocus for multiple non-ideal factors, which is accomplished by an improved phase gradient autofocus (PGA) equipped with amplitude error estimation and discrete windowing. PGA with amplitude error estimation can solve the problem of defocus, and discrete windowing can focus the energy of paired echoes. The second is an error fusion and interpolation method for a long synthetic time and large swath. This method fuses errors among sub-apertures in the long synthetic time and can fulfill autofocus for blocks where strong scatterers are not sufficient in the large swath. The proposed method can effectively achieve SAR focusing with a long synthetic time and large swath, considering spatial and temporal variant non-ideal factors. Point target simulations and distributed target simulations based on real scenarios are conducted to validate the proposed method. Full article

Permanent Scatterer Interferometric Synthetic Aperture Radar (PSInSAR), with millimeter-level accuracy and full-resolution capabilities, is essential for monitoring urban deformation. With the advancement of SAR sensors in spatial and temporal resolution and the expansion of wide-swath observation capabilities, the number of permanent scatterers (PSs) in high-density urban areas has surged exponentially. To address these computational and memory challenges in high-density urban PSInSAR processing, this paper proposes an efficient method for integrating regular grid partitioning and connected component constraints. First, adaptive dynamic regular grid partitioning was employed to divide monitoring areas into sub-blocks, balancing memory usage and computational efficiency. Second, a weighted least squares adjustment model using common PS points in overlapping regions eliminated systematic inter-sub-block biases, ensuring global consistency. A graph-based connected component constraint mechanism was introduced to resolve multi-component segmentation issues within sub-blocks to preserve discontinuous PS information. Experiments on TerraSAR-X data covering Fuzhou, China (590 km²), demonstrated that the method processed 1.4 × 10⁷ PS points under 32 GB memory constraints, where it achieved a 25-fold efficiency improvement over traditional global PSInSAR. The deformation rates and elevation residuals exhibited high consistency with conventional methods (correlation coefficient ≥ 0.98). This method effectively addresses the issues of memory overflow, connectivity loss between sub-blocks, and cumulative merging errors in large-scale PS networks. It provides an efficient solution for wide-area millimeter-scale deformation monitoring in high-density urban areas, supporting applications such as geohazard early warning and urban infrastructure safety assessment. Full article

Traditional methods for the construction of intertidal digital elevation models (DEMs) require the integration of long-term multi-sensor datasets and struggle to capture the spatiotemporal variation caused by ocean dynamics. The SWOT (surface water and ocean topography) mission, with its wide-swath interferometric altimetry technology, provides instantaneous full-swath elevation data in a single pass, offering a revolutionary data source for high-precision intertidal topographic monitoring. This study presents a framework for SWOT-based intertidal DEM extraction that integrates data preprocessing, topographic slope map construction, and tidal channel masking. The radial sand ridge region along the Jiangsu coast is analyzed using SWOT L2 LR (Low Resolution) unsmoothed data from July 2023 to December 2024. Multisource validation data are used to comprehensively assess the accuracy of sea surface height (SSH) and land elevation derived from LR products. Results show that the root mean square error (RMSE) of SSH at Dafeng, Yanghe, and Gensha tide stations is 0.25 m, 0.19 m, and 0.32 m, respectively. Validation with LiDAR data indicates a land elevation accuracy of ~0.3 m. Additionally, the topographic features captured by LR products are consistent with the patterns observed in the remote sensing imagery. A 16-month time-series analysis reveals significant spatiotemporal variations in the Tiaozini area, particularly concentrated in the tidal channel areas. Furthermore, the Pearson correlation coefficient for the DEMs generated from SWOT data decreased from 0.94 over a one-month interval to 0.84 over sixteen months, reflecting the persistent impact of oceanic dynamic processes on intertidal topography. Full article

Based on Digital Beamforming (DBF) technology, spaceborne SAR systems can achieve high-resolution and wide-swath (HRWS) imaging. When combined with reflector antennas, the DBF-SCORE (Digital Beamforming-SCan On REceive) system also features light weight and low cost, making it an important choice for spaceborne HRWS SAR. This paper firstly proposes an advanced Full-chain Real-time Internal Calibration (FRIC) scheme, where the calibration path covers the entire receive chain from the antenna feed port to the input port of the Analog-to-Digital Converter (ADC) and achieves high-precision internal calibration concurrently with data acquisition. Secondly, based on the L-band reflector antenna DBF-SCORE system architecture, the design of radio frequency (RF) front end, namely the Transmit-Receive-Calibration Module (TRCM), is carried out. We propose the implementation of azimuth encoding modulation of the calibration signal through periodic switch control within the TRCM. Subsequently, the calibration signal is extracted using waveform diversity technology and its Signal-to-Noise Ratio (SNR) is improved through azimuth coherent integration technology. In addition, a ground verification system is established using the TRCM to evaluate the comprehensive performance of transmitting, receiving, and real-time internal calibration. Experimental results verify the effectiveness of the FRIC scheme and provide valuable insights for future spaceborne DBF SAR systems. Full article

With the growing demand for large-scale urban observation, multi-channel technology has become a cornerstone of high-resolution wide-swath SAR systems. The challenge of storing and transmitting the large data volumes generated by multi-channel systems has driven the development of advanced data compression techniques. However, in onboard implementations with non-power-of-two channel numbers and serial data formats, the existing multi-channel compression algorithms reveal significant conflicts involving channel counts, FFT cores, and the Krieger method. To address these issues, this paper introduces the Channel-Adaptive Range-Doppler domain filtering Serial Block Adaptive Quantization algorithm (CARDS-BAQ). By incorporating a point-frequency RD domain filtering approach and leveraging serial data matrix splicing and rollback combined with point-frequency ABAQ, CARDS-BAQ enables efficient data compression for arbitrary channel counts. The performance of CARDS-BAQ is validated using GF-3 measured data through comparative analysis with BAQ, ABAQ, MCBAQ, and 3MBAQ algorithms under power-of-two channel conditions. Additionally, its applicability and reliability for non-power-of-two channel numbers are demonstrated through payload flight experiments conducted in 2024 in Yingkou, Liaoning Province, China. CARDS-BAQ effectively supports data storage and transmission for large-scale urban observation, marking a significant advancement in remote sensing technology. Full article

With the development and application of spaceborne Synthetic Aperture Radar (SAR), higher resolution and a wider swath have become significant demands. However, as the resolution increases and the swath widens, the two-dimensional (2D) spatial variation between different targets in the scene and the radar becomes very pronounced, severely affecting the high-precision focusing and high-quality imaging of spaceborne SAR. In previous studies on the correction of two-dimensional spatial variation in spaceborne SAR, either the models were not accurate enough or the computational efficiency was low, limiting the application of corresponding algorithms. In this paper, we first establish a slant range model and a signal model based on the zero-Doppler moment according to the spaceborne SAR geometry, thereby significantly reducing the impact of azimuth spatial variation in two-dimensional spatial variation. Subsequently, we propose a Curve-Sphere Model (CUSM) to describe the ground observation geometry of spaceborne SAR, and based on this, we establish a more accurate theoretical model and quantitative description of two-dimensional spatial variation. Next, through modeling and simulation, we conduct an in-depth analysis of the impact of two-dimensional spatial variation on spaceborne SAR imaging, obtaining corresponding constraints and thresholds and concluding that in most cases, only one type of azimuth spatial variation needs to be considered, thereby greatly reducing the demand and difficulty of two-dimensional spatial variation correction. Relying on these, we propose a two-dimensional spatial variation correction method that combines range blocking and azimuth nonlinear chirp scaling processing and analyze its scalability to be applicable to more general cases. Finally, the effectiveness and applicability of the proposed method are validated through both simulation experiments and real data experiments. Full article

Phase denoising constitutes a critical component of the synthetic aperture radar interferometry (InSAR) processing chain, where noise suppression and detail preservation are two mutually constraining objectives. Recently, deep learning has attracted considerable interest due to its promising performance in the field of image denoising. In this paper, a Neighbor2Neighbor denoising network (NBDNet) is proposed, which is capable of simultaneously estimating phase and coherence in both single-look and multi-look cases. Specifically, repeat-pass PALSAR real interferograms encompassing a diverse range of coherence, fringe density, and terrain features are used as the training dataset, and the novel Neighbor2Neighbor self-supervised training framework is leveraged. The Neighbor2Neighbor framework eliminates the necessity of noise-free labels, simplifying the training process. Furthermore, rich features can be learned directly from real interferograms. In order to validate the denoising capability and generalization ability of the proposed NBDNet, simulated data, repeat-pass data from Sentinel-1 Interferometric Wide (IW) swath mode, and single-pass data from Hongtu-1 stripmap mode are used for phase denoising experiments. The results demonstrate that NBDNet performs well in terms of noise suppression, detail preservation and computation efficiency, validating its potential for high-precision and high-resolution topography reconstruction. Full article

Sparse Synthetic Aperture Radar (SAR) imaging has garnered significant attention due to its ability to suppress azimuth ambiguity in under-sampled conditions, making it particularly useful for high-resolution wide-swath (HRWS) SAR systems. Traditional compressed sensing-based sparse SAR imaging algorithms are hindered by range–azimuth coupling induced by range cell migration (RCM), which results in high computational cost and limits their applicability to large-scale imaging scenarios. To address this challenge, the approximated observation-based sparse SAR imaging algorithm was developed, which decouples the range and azimuth directions, significantly reducing computational and temporal complexities to match the performance of conventional matched filtering algorithms. However, this method requires iterative processing and manual adjustment of parameters. In this paper, we propose a novel deep neural network-based sparse SAR imaging method, namely the Self-supervised Azimuth Ambiguity Suppression Network (SAAS-Net). Unlike traditional iterative algorithms, SAAS-Net directly learns the parameters from data, eliminating the need for manual tuning. This approach not only improves imaging quality but also accelerates the imaging process. Additionally, SAAS-Net retains the core advantage of sparse SAR imaging—azimuth ambiguity suppression in under-sampling conditions. The method introduces self-supervision to achieve orientation ambiguity suppression without altering the hardware architecture. Simulations and real data experiments using Gaofen-3 validate the effectiveness and superiority of the proposed approach. Full article

This paper describes a flexible and seamless processor for Unmanned Aerial Vehicle (UAV)-borne Synthetic Aperture Radar (SAR) imagery. When designing a focusing algorithm for large-scale and high-resolution SAR images, efficiency and accuracy are two mandatory aspects to consider. The proposed processing scheme is based on a modified version of Fast Factorized Back-Projection (FFBP), in which the factorization procedure is interrupted on the basis of a computational cost analysis to reduce the number of complex operations at its minimum. The algorithm gains efficiency in the case of low-altitude platforms, where there are significant variations in azimuth resolution, but not in the case of conventional airborne missions, where the azimuth resolution can be considered constant in the swath. The algorithm’s performance is derived by assessing the number of complex operations required to focus an SAR image. Two scenarios are tackled in a numerical simulation: a UAV-borne SAR with a short synthetic aperture and a wide field of view, referred to as the ground-based-like (GBL) scenario, and a classical stripmap scenario. In both cases, we consider mono-static and bi-static radar configurations. The results of the numerical simulations show that the proposed algorithm outperforms FFBP in the stripmap scenario while achieving the same performance as FFBP in the GBL scenario. In addition, the algorithm is validated thanks to an experimental UAV-borne SAR campaign in the X-band. Full article

Hyperspectral payloads with high spatial and spectral resolution, combined with a wide field of view, are crucial for tackling the complexity of coastal and estuarine water ecosystems, enabling effective monitoring of water quality and ecological conditions. This study introduces a modular spectrometer design utilizing multiple sub-modules in an extended slit configuration. The system delivers a spectral resolution of 5 nm (400–1000 nm) and 10 nm (1000–2500 nm), a spatial resolution of 20 m, and a swath width of 80 km. Smile and keystone distortions are maintained below 1/5 of a pixel. Using Modran to simulate solar irradiance, the SNR of different targets under typical background conditions is calculated. Compared to conventional designs, the proposed modular approach provides compactness and high fidelity, effectively addressing size and optical aberration challenges. The simulation results confirm the system’s robustness, setting a benchmark for next-generation coast observation missions, particularly in coastal monitoring, underwater exploration, and dynamic environmental change tracking. Full article

Traditional single-channel Synthetic Aperture Radar (SAR) cannot achieve high-resolution and wide-swath (HRWS) imaging due to the constraint of the minimum antenna area. Distributed HRWS SAR can realize HRWS imaging and also possesses the resolution ability in the height dimension by arranging multiple satellites in the elevation direction. Nevertheless, due to the excessively high pulse repetition frequency (PRF) of the distributed SAR system, range ambiguity will occur in large detection scenarios. When directly performing 3D-imaging processing on SAR images with range ambiguity, both focused point clouds and blurred point clouds will exist simultaneously in the generated 3D point clouds, which affects the quality of the generated 3D-imaging point clouds. To address this problem, this paper proposes a 3D blur suppression method for HRWS blurred images, which estimates and eliminates defocused point clouds based on focused targets. The echoes with range ambiguity are focused in the near area and the far area, respectively. Then, through image registration, amplitude and phase correction, and height-direction focusing, the point clouds in the near area and the far area are obtained. The strongest points in the two sets of point clouds are iteratively selected to estimate and eliminate the defocused point clouds in the other set of point clouds until all the ambiguity is eliminated. Simulation experiments based on airborne measured data verified the capability to achieve HRWS 3D blur suppression of this method. Full article

Azimuth multi-channel techniques show great promise in high-resolution, wide-swath synthetic aperture radar systems. However, in practical engineering applications, errors between channels can significantly affect the reconstruction of multi-channel echo data, leading to a degraded synthetic aperture radar image. To address this issue, this article derives the formula expression in the two-dimensional time domain after single-channel processing under the assumption of an insufficient azimuth sampling rate and proposes a novel algorithm based on the statistical treatment of characteristic clusters. In this algorithm, channel imaging is first performed separately; then, the image is divided into a predefined number of sub-images. The characteristic clusters and points within each sub-image are identified, and their positions, amplitude, and phase information are used to obtain the range synchronization errors, amplitude errors, and phase errors between channels. Compared with traditional methods, the proposed method does not require iteration or the complex eigenvalue decomposition of the covariance matrix. Furthermore, it can utilize existing imaging tools and software in single-channel synthetic aperture radar systems. The effectiveness of the proposed method is validated through simulation experiments and real-world data processing. Full article
