To enhance the fidelity of the DEM representation of sugar beet roots, the root geometry was reconstructed from three-dimensional scanning data and represented in EDEM2024 as a multi-sphere clump. The Hertz–Mindlin (no slip) model was used to describe particle contact behavior. The root–Q235 steel contact parameters were determined by drop-rebound, inclined-plane sliding, and inclined-plane rolling experiments. For root–root interactions, the parameters were further refined through cylinder-lifting repose-angle simulations combined with the steepest-ascent method and a three-factor quadratic orthogonal rotatable regression scheme. The optimized inter-root restitution coefficient, static friction coefficient, and rolling friction coefficient were 0.534, 0.728, and 0.080, respectively. With this parameter set, the deviation between the simulated and measured angles of repose was 0.86%, and the error obtained in the independent validation test was 1.5%. These results demonstrate that the proposed DEM model and calibrated parameter set can accurately represent the motion and contact behavior of sugar beet roots. Full article

To address the significant differences in the structure and mechanical properties of various components of the Shanghai bok choy plug seedling, and the lack of an accurate and reliable discrete element model of the whole plant and key bonding parameters in the simulation of the automatic transplanting process, a 128-cell Shanghai bok choy plug seedling was selected as the research object. Morphological, physical, mechanical, and contact property tests were systematically conducted to obtain the basic parameters of the seedling pot, leaf, petiole, and stem. A whole-plant discrete element model of Shanghai bok choy plug seedling, consisting of the seedling pot, leaf, petiole, and stem, was established using a combined method of component-wise modeling and overall reconstruction. The Hertz–Mindlin (no slip) and Bonding V2 contact models were jointly adopted to characterize interparticle contact, continuous structural behavior, and failure characteristics. Taking the ultimate compressive failure load of the seedling pot, leaf compression density, ultimate bending failure load of the petiole, and ultimate bending failure load of the stem as response indices, significant parameters were screened using the Plackett–Burman test, the optimization ranges were determined through the steepest ascent test, and the key bonding parameters were optimized and calibrated using the Box–Behnken response surface test. The results showed that the relative errors between the simulated and experimental values of the ultimate compressive failure load of the seedling pot, leaf compression density, ultimate bending failure load of the petiole, and ultimate bending failure load of the stem after optimization were 1.19%, 1.13%, 0.99%, and 0.72%, respectively, indicating that the established model can accurately characterize the mechanical response of the constituent parts of Shanghai bok choy plug seedling. The results provide a basis for discrete element simulation of the interaction between Shanghai bok choy plug seedling and key components of automatic transplanting equipment, as well as for the design optimization of automatic transplanting equipment. Full article

Residual film recovery is a crucial approach to mitigating agricultural “white pollution” and ensuring sustainable land use. Currently, the development of residual film recovery machines relies primarily on theoretical analysis and field performance tests. The lack of support from computational simulation models often leads to suboptimal mechanical performance, severely restricting the design and optimization of recovery equipment. To address this, this study proposes a method for constructing and experimentally validating a discrete element model of plow-layer residual film using EDEM software. First, field tests were conducted to measure soil compaction and residual film distribution at various depths. The ultimate tensile force of the residual film was also evaluated to provide fundamental data for model development. Using the Hertz–Mindlin with bonding contact model in EDEM, the intrinsic parameters of the residual film were selected and optimized. Combined with a Box–Behnken experimental design, a quadratic regression model relating normal stiffness per unit area, critical normal stress, and bond radius to the ultimate tensile force of the film was constructed. The optimal parameter combination was determined as follows: normal stiffness = 1.11 × 10⁶ N·m⁻³, critical normal stress = 2.45 × 10⁶ Pa, and bond radius = 0.03 mm. Under these parameters, the theoretically predicted ultimate tensile force was 1.18 N, and the simulated value yielded a relative error of only 1.69%, validating the effectiveness of the single-film model. Furthermore, using the field-measured data, a coupled film–soil model was established via the “rainfall” method to conduct simulated penetration tests. Parameter calibration was executed using the multivariate Newton–Raphson iteration method. The optimal bonding parameters for soil particles were identified as follows: normal stiffness per unit area = 9.6 × 10⁵ N/m², shear stiffness per unit area = 9.6 × 10⁵ N/m², critical normal stress = 5.38 × 10⁵ Pa, critical shear stress = 5.38 × 10⁵ Pa, and bond radius = 4.3 mm. The average simulated penetration resistance was 59.61 N, showing a relative error of 5.91% compared to the field-measured value of 56.28 N. These results demonstrate that the developed coupled film–soil DEM can be effectively applied to simulate the lifting and throwing processes of plow-layer residual film recovery machines, thereby providing vital modeling support for the design and optimization of residual film recovery mechanisms. Full article

In biomass pellet combustion, the formation of ash layers on particle surfaces severely hinders combustion reactions and heat transfer, while the key parameters governing particle motion behavior and ash pre-separation in rotating cone burners remain insufficiently understood. To address these challenges and to optimize particle mixing and ash separation performance, this study adopts a combined numerical approach. The discrete element method (DEM) coupled with the Hertz–Mindlin (no-slip) contact model is employed to simulate particle motion and mixing dynamics, while a separate cold-state computational fluid dynamics (CFD) model based on the Realizable k-ε turbulence model and the discrete phase model (DPM) with Rosin–Rammler particle size distribution is established to investigate ash separation mechanisms. The Lacey mixing index is used to quantify mixing uniformity, and grid independence verification is performed to ensure numerical reliability. Key findings reveal that the rolling regime (rotational speed: 1.7–11 r/min), a uniform particle size of 25 mm, and a cone inclination angle of 45° collectively optimize particle mixing. Rotational speed is identified as the dominant factor affecting mixing effectiveness. Furthermore, an optimal secondary-to-primary air ratio of approximately 7:3 (within the tested range) balances enhanced centrifugal separation with flow field stability by mitigating backflow and excessive turbulence. This work not only fills the knowledge gap regarding the coupled effects of operational and structural parameters on particle behavior in rotating cone burners but also provides novel, quantitative guidance for the rational design and parameter tuning of such burners to improve combustion efficiency and operational stability. Full article

To determine the optimal operating parameters of the single-longitudinal-axial-flow threshing device for wheat harvesters under high feed rate conditions and lay a theoretical and methodological foundation for the subsequent development of a specialist system for threshing device parameter optimization, this study constructed a discrete element model (DEM) of wheat plants at harvest stage in EDEM software based on the Hertz–Mindlin with bonding contact model, combined with the discrete element parameters of wheat plants calibrated by a texturometer. Simulation experiments were designed and conducted to optimize the operating parameters of the threshing device, and a methodology that employs simulation experiments to obtain optimal parameter combinations under different operating environments was proposed, which was applied to the development of a specialist system for threshing device parameter optimization. Taking cylinder speed, cylinder inclination and threshing gap as experimental factors, and unthreshed rate, separation loss rate and breakage rate as evaluation indexes, single-factor and Box–Behnken simulation experiments were carried out. Mathematical models were established to reveal the correlation between evaluation indexes and influencing parameters, and then the optimal parameter combination was solved. The results showed that the threshing device achieved the optimal comprehensive operating performance at a cylinder speed of 850 r/min, a cylinder inclination of 6° and a threshing gap of 20 mm, with an unthreshed rate of 1.575%, a separation loss rate of 0.158% and a breakage rate of 0.509%. Bench validation tests indicated that the relative errors between simulated and measured indexes were all less than 5%, verifying the reliability of the established DEM. Compared with bench tests, the simulation experiment method in this study ensured high accuracy while significantly reducing the time and labor costs of tests. The obtained optimal operating parameters and the proposed simulation optimization methodology provide core data support and technical reference for the development of a specialist system for parameter optimization of the threshing device of wheat harvesters. Full article

Rabbit manure with high-moisture content exhibits complex adhesive and flow behaviors, which make accurate parameterization in discrete element method (DEM) simulations difficult. To improve the reliability of DEM modeling for rabbit manure composting processes, this study calibrated the contact parameters of rabbit manure at 65% moisture content using the angle of repose as the target response. A physical angle of repose test was first conducted using the cylindrical lifting method, yielding a measured value of 38.77°. The Hertz–Mindlin with Johnson–Kendall–Roberts (JKR) contact model was then adopted to represent the adhesive behavior of the material, and a three-stage optimization strategy consisting of a Plackett–Burman screening test, a steepest ascent test, and a Box–Behnken design was applied to identify and optimize the key parameters. The results showed that the particle restitution coefficient, rabbit manure–PLA rolling friction coefficient, and surface energy were the dominant factors affecting the angle of repose. The optimal parameter combination was a particle restitution coefficient of 0.56, a rabbit manure–PLA rolling friction coefficient of 0.375, and a surface energy of 0.243 J/m². Under these conditions, the simulated angle of repose was 39.21°, with a relative error of 1.13%. These calibrated parameters provide a reliable basis for DEM simulation and engineering optimization of rabbit manure composting equipment. Full article

This study presents an integrated experimental and modeling framework to investigate human–robot collision dynamics involving a collaborative manipulator (KUKA LBR iiwa 14 R820). A dedicated impact test prototype was developed to reproduce controlled contact scenarios between the robot and human body analogues under various dynamic conditions. The experimental setup enables the acquisition of synchronized force, velocities, and displacement signals during contact events. These data are used to calibrate and validate a set of contact models, ranging from classical formulations such as Hertz and Hunt–Crossley to more recent supervised machine learning models. The proposed methodology allows a quantitative assessment of model accuracy and physical consistency in replicating real collision phenomena. Furthermore, the effective mass of the robot along its kinematic chain is estimated to compute impact energy and predict the interaction severity according to ISO 10218-1/2:2025 safety limits. The results highlight the trade-off between model complexity and predictive capability, offering alternative guidelines for collision severity evaluation in collaborative robotics applications. Full article

This study addresses key challenges in high-precision industrial motion control, including dynamic load disturbances, nonlinear parameter coupling, and degradation in synchronization accuracy. A dual-motor cross-coupled synchronous control strategy is proposed, integrating Hertzian contact theory with an adaptive fuzzy PI control algorithm. First, a precise pressure measurement model for the printing contact zone is established based on Hertzian contact theory. The model quantitatively characterizes the relationship between structural parameters and pressure distribution. Key parameters include cylinder radius and plate thickness. This provides a theoretical foundation for precise regulation. Subsequently, a fuzzy PI controller with parameter self-tuning capability is incorporated into the motor speed loop, enabling real-time adjustment of control parameters to effectively compensate for system nonlinearities and time-varying disturbances. Furthermore, a cross-coupled synchronization architecture is designed to enable bidirectional compensation between the two motors, significantly improving synchronization accuracy under complex operating conditions. Simulations were performed in MATLAB/Simulink. The tests covered typical operational scenarios, including load start-up, single-motor disturbance, and multi-disturbance conditions. The results demonstrate that the proposed system achieves high performance: dual-motor speed synchronization accuracy reaches 99.5%; the response time for disturbance compensation is within 0.3 s; and printing-pressure fluctuation is confined to ±0.8%. This performance represents a 62.5% improvement in stability over conventional single-motor control systems. This research not only resolves the long-standing issue of pressure non-uniformity in flexographic printing but also provides a generalizable framework for multi-motor synchronous control in precision manufacturing. The findings offer substantial academic insight and practical value for advancing intelligent industrial measurement and control technologies. Full article

Under extreme heterogeneous loading conditions in the deep sea, obtaining well-preserved and stratigraphically coherent cores is a critical challenge that requires urgent resolution. Current methods cannot directly determine the preservation of core stratigraphic information or the sampling behaviour of drill bits through experimentation. Consequently, a new evaluation method for angular velocity-based stratigraphic preservation, which is grounded in Discrete Element Method (DEM) theory, is proposed. Simulation modelling uses the Hertz–Mindlin contact model to construct a multi-scale geotechnical–drill string numerical coupling model. The drill string structure is simplified while incorporating actual geometric dimensions and material properties. By simulating and extracting particle angular velocity data under various operating conditions, a correlation is established between particle motion characteristics and the stratigraphic preservation status. Experiments were conducted on a customised drilling rig platform using specimens with deep-sea geomechanical properties consistent with the simulations. Drilling tools with multiple inner diameter specifications were configured, and multiple variable combinations of the rotational speed and feed rate were set. The degree of bedding preservation in the sampled cores was recorded synchronously. The study clarified the relationship between particle angular velocity and bedding preservation, identifying the influence patterns of parameters such as the tool inner diameter, rotational speed, and feed rate on bedding preservation. Results indicate that when the rotational speed exceeds 200 rpm and the feed rate falls below 0.018 m/s, stratigraphic distortion significantly increases; the drill bit inner diameter exhibits a non-linear negative correlation with core disturbance. This study provides theoretical underpinnings and experimental evidence for multi-parameter process optimisation in maintaining stratigraphic integrity during deep-sea submersible coring operations. Full article

Severe coronary artery calcification (CAC) remains a major challenge in percutaneous coronary intervention (PCI), driving stent under-expansion and higher rates of restenosis and adverse events. Balloon-based calcium modification remains central to lesion preparation, with the available tools ranging from high-pressure non-compliant balloons and ultra-high-pressure balloons to cutting, scoring, and intravascular lithotripsy (IVL) balloons. While traditional IVL has advanced the field by permitting circumferential fracture of deep calcium through acoustic shockwaves, important drawbacks persist, including problems in deliverability, energy distribution, and questionable efficacy in nodular or eccentric calcium. This review examines all contemporary balloon-based modification strategies and introduces the novel Hertz-contact IVL (HC-IVL), a new technology designed to transmit mechanical energy through direct contact rather than shockwave propagation. Based on Hertzian mechanics, this device may facilitate more focused energy delivery, improved lesion crossing, and enhanced calcium fracture in complex morphologies. A detailed comparison between HC-IVL and standard IVL is provided, along with a proposed algorithm for device selection. Taking into consideration the limitations of current tools, HC-IVL represents a promising mechanistic innovation in balloon-based calcium modification, warranting further validation in randomized, imaging-guided clinical studies. Full article

This paper investigates deflection deformation and premature bearing failure in deep-hole machining spindles with high length-to-diameter ratios under eccentric loading. A contact stiffness model for angular contact ball bearings was developed based on Hertz contact theory. Combined with the finite element method (FEM), a comprehensive mechanical analysis model of the spindle was established. The results show that spindles with high length-to-diameter ratios exhibit significant cantilever behavior, leading to considerable front-end deflection under eccentric loading. This deflection causes the inner and outer rings to incline, resulting in localized stress concentrations, which are the primary contributors to spindle fatigue failure. To improve the spindle’s stress distribution and dynamic performance, an optimized design replacing the metal housing with carbon fiber composite material is proposed. Static and modal analyses were performed using Abaqus and Romax. The analysis results demonstrate that the carbon fiber shell reduces self-weight deformation by 35.8%, decreases coupled deformation under self-weight and grinding loads by 28.6%, and increases modal fundamental frequencies by 20.88% to 47.41%. These improvements significantly enhance structural stiffness and dynamic stability. Experimental vibration monitoring during machine testing validated the accuracy of the modeling and simulation. Full article

Contact mechanics models are often inaccurate, due to (i) unknown contact radius, (ii) mechanical models not parameterizing it, (iii) in some models it is neither assumed meaningfully nor determined, and (iv) uncertain probe radius arising from manufacturer-specified nominal values and manufacturing tolerances. In this paper, an FEA model was used to quantify the evolution of the contact radius during indentation for two probe geometries: a pyramidal indenter (TRIANG2 nominal apex radius 2 nm) and a flat-ended punch (FLAT4000; nominal punch radius 4000 nm) on poly (vinyl chloride) (PVC), for which Young’s modulus (E_ref) was obtained by a standard mechanical tensile method. The effective contact radius, $R_{eff}$, determined from FEA, was subsequently used in a Hertz-based force–indentation parametrization. Uncertainty in the probe apex radius due to manufacturer tolerances was addressed by SEM measurement of the conical tip, enabling assessment of its impact on the modulus estimated from AFM indentation. Based on these results, we propose a practical, geometry-aware analysis methodology that is transferable across probe geometries. The effective contact radius, $R_{eff}$, is first established using a well-characterized reference material and subsequently applied to a mechanical model to extract Young’s modulus. In this approach, the Hertz-based parametrization is used as a consistent mathematical framework, while the effective contact radius accounts for probe-dependent contact evolution. Full article

The peanut, a globally important oil and economic crop, has thin, brittle pods that are prone to breakage under external forces during mechanical harvesting, transportation, and processing. To minimize this loss and reduce production costs, we conducted an in-depth study of the pod-breaking process by integrating manual and automatic filling approaches within the discrete element method (DEM) with the Hertz–Mindlin with bonding model. A breakable layered bonding model for peanut pods was developed, which is capable of precisely characterizing the disparities in the mechanical properties of peanut pod shells and kernels. Physical tests were performed to obtain the relevant contact parameters of peanut pods. Compression tests combined with calibration approaches were employed to identify the bonding parameters of peanut pods, which are not easily accessible via direct experimental measurements. The optimal combination of simulation parameters for the model was determined via a Plackett–Burman test, steepest ascent test, and Box–Behnken test. The results indicated that the critical normal stress between pod shells is the most significant influencing factor. The optimal parameter combination for the proposed model is as follows: the normal stiffness per unit area between pod shells is 7.81 × 10¹⁰ N/m³, the shear stiffness per unit area between pod shells is 9.00 × 10⁸ N/m³, the critical normal stress between pod shells is 2.17 × 10⁵ N/m³, and the critical shear stress between pod shells is 2.25 × 10⁵ N/m³. The established layered bonding model for breakable peanut pods was validated using both cylinder-lifting simulation tests and physical shelling experiments. The relative error in the angle of repose between the cylinder-lifting simulation and physical tests was 1.6%, while the deviation in the shelling experiment was only 0.7%. This model provides a theoretical foundation for the design and optimization of machinery used in peanut pod harvesting, transportation, and processing. Full article

In most AFM nanoindentation experiments on soft biological samples, classical contact mechanics models, such as Hertz or Sneddon’s equations, are commonly employed to determine the Young’s modulus. However, biological materials are inherently heterogeneous, and their mechanical properties often depend on the indentation depth. In this work, we present a novel and simple approach to quantify how the apparent modulus varies with increasing indentation depth. The method is based on the general indentation equation for axisymmetric indenters combined with a straightforward polynomial fitting of the force–indentation data. The proposed approach offers significant advantages, as it greatly simplifies the fitting process without requiring any advanced algorithms, while maintaining high accuracy. In addition, it is shown that the depth-dependent mechanical properties of cells can be described by a simple law, $E\left(h\right)=C_d/h+E_l$ , where $E_l$ is the limiting value of the apparent modulus at large indentations, and $C_d/h$ represents the depth-dependent contribution dominant at the initial stages of the indentation process. Here, $C_d$ is a positive stiffness coefficient, and $h$ is the indentation depth. This is a very important result, indicating that by using the pair of coefficients $C_d$ and $E_l$, we can fully describe the mechanical properties of cells, capturing their depth-dependent mechanical behavior. Experiments on fibroblasts and H4 human glioma cells confirm the accuracy of this equation. The proposed methods provide an accessible and reliable framework for nanoscale mechanical characterization, offering insights into the depth-dependent elasticity of heterogeneous soft materials and revealing mechanical patterns in biological samples. Full article

Existing research on the linear rolling guide has predominantly focused on performance under ideal conditions or isolated error types, while systematic studies concerning multi-error coupling mechanisms and their impact on internal contact parameters remain limited. To address this, a comprehensive static model based on Hertz contact theory is proposed that simultaneously incorporates ball diameter, raceway radius, and raceway curvature center distance errors. This model is validated using finite element analysis (FEA) in ABAQUS, and the numerical results verify the feasibility and effectiveness of the proposed analytical model. Analysis of single, combined, and random errors indicates that geometric errors significantly influence vertical stiffness, load distribution, and critical load-carrying capacity. For example, as the ball diameter error varies from −2.5 to 2.5 μm, the vertical stiffness increases by a factor of 3.8, while a representative negative error combination reduces the critical load by nearly 40%. Additionally, random error analysis reveals that larger manufacturing tolerance ranges lead to increased fluctuation in ball contact forces, raising performance uncertainty. These findings establish the proposed model as a theoretical foundation for the precision design and load-bearing assessment of linear rolling guides under static conditions. Full article
