Maritime power systems must reduce fuel use and emissions while improving resilience. We study a shipboard PV–battery subsystem interfaced with a DC–DC converter running maximum power point tracking (MPPT) and curve-scanning GMPPT to manage partial shading. Dynamic average-value models capture irradiance steps and show GMPPT sustains operation near the global MPP without local peak trapping. We compare converter options—conventional single-port stages, high-gain bidirectional dual-PWM converters, and three-level three-port topologies—provide sizing rules for passives, and note soft-switching in order to limit loss. A Fourier framework links the switching ripple to power quality metrics: as irradiance falls, the current THD rises while the PCC voltage distortion remains constant on a stiff bus. We make the loss relation explicit via $I_{rms}^{2}R$ scaling with THDi and propose a simple reactive power policy, assigning VAR ranges to active power bins. For AC-coupled cases, a hybrid EMT plus transient stability workflow estimates ride-through margins and critical clearing times, providing a practical path from modeling to monitoring. Full article

Recently, artificial intelligence (AI) has become a promising solution to the optimization of the energy harvesting and performance of photovoltaic (PV) systems. Traditional maximum power point tracking (MPPT) algorithms have several drawbacks on tracking the global maximum power point (GMPP) under partial shading conditions (PSCs). To track the GMPP, AI enabled methods stand out over other traditional solutions in terms of faster tracking dynamics, lesser oscillation, higher efficiency. However, such AI-based MPPT methods differ significantly in various applications, and thus, a full picture of AI-based MPPT methods is of interest to further optimize the PV energy harvesting. In this paper, various AI-based global maximum power point tracking (GMPPT) techniques are then implemented and critically compared by highlighting the advantages and disadvantages of each technique under dynamic weather conditions. The comparison demonstrates that the hybrid AI techniques are more reliable, which offer higher efficiency and better dynamics to handle PSCs. According to the benchmarking, a modified particle swarm optimization (PSO) GMPPT algorithm is proposed, and the experimental results validate its ability to achieve GMPPT with faster dynamics and higher efficiency. This paper is intended to motivate engineers and researchers by offering valuable insights for the selection and implementation of GMPPT techniques and to explore the AI techniques to enhance the efficiency and reliability of PV systems by providing fresh perspectives on optimal AI-based GMPPT techniques. Full article

Under uniform operating conditions, the power–voltage (P-V) and current–voltage (I-V) curves of a photovoltaic (PV) system have only one maximum point, which facilitates the operation of maximum power point tracking (MPPT) algorithms. In practice, the PV systems often operate under heterogeneous environments due to partial shading conditions (PSCs). The P-V and I-V curves exhibit multiple extremes, and distinguishing between the global maximum power point (GMPP) and local maximum power point (LMPP) is a major challenge for algorithms aiming to improve performance and convergence speed. This paper presents a global maximum power point tracking (GMPPT) method based on simulating the behavior of the I-V curve of a PV system under the influence of PSCs. With only one initial parameter selected, the proposed solution quickly determines the LMPPs based on the characteristics of the PV type and the shading condition during operation. This work helps to limit the potential GMPP region to reduce the search time and improve efficiency by using a simple algorithm and a small tuning step size. The experimental results demonstrate that the proposed method provides superior MPPT performance and significantly reduces search time due to improved GMPP detection accuracy combined with small step sizes. Full article

In this paper, an improved firefly algorithm (FA) was proposed for application on photovoltaic module arrays (PVMAs) with partial modules under shading so that the maximum power point tracking (MPPT) could be implemented. Firstly, a new model of high voltage step-up converter was developed for executing the MPPT of the PVMA. For the energy storage inductor of the developed converter, the architecture of the coupled inductor was adopted so that the converter switch did not need to operate under an excessive duty cycle, which could increase the voltage gain and reduce the ripple of the output voltage at the same time. To prevent shading on the partial modules within the PVMA and generate more than one peak on the power-voltage (P-V) output characteristic curve, where the conventional MPPT could only track the local maximum power point (LMPP) and reduce the output power of the PVMA, the maximum power tracker, based on the improved FA, was proposed in this paper. Such a tracker could perform an automatic online adjustment on the FA iteration parameters, according to the slope of the P-V output characteristic curve, for the PVMA and, at the same time, perform at 0.8 times of the maximum power point (MPP) voltage for the module array under standard test condition (STC), serving as the initial tracking voltage for implementing the global maximum power point tracking (GMPPT). Lastly, the actual test results were applied to verify that the proposed converter indeed contained a high voltage step-up and low-ripple output voltage. The improved FA could also track GMPP faster and further improve the power-generating efficiency of the PVMA. Full article

A PV system’s operation highly depends on weather conditions. In case of varying irradiances or load changes, there is a power mismatch between various modules of the PV array. This power mismatch causes instability in the output of the PV system and deteriorates the overall system efficiency. To overcome instability and lower efficiency problems, and to extract maximum power from the PV system, various maximum power point tracking (MPPT) techniques are employed. The success of these techniques depends on the identification of the actual operating conditions of the system. This article proposes a hybrid maximum power point tracking (MPPT) technique that is capable of efficiently differentiating between uniform irradiance, non-uniform irradiance, and load variations on the PV system. Based on the identified operating conditions, the proposed method uses modified perturb and observe (Modified P&O) to cope with uniform irradiance variations and chimp optimization algorithms (ChOA) for non-uniform conditions to track the oscillation free maximum power-point. The proposed method is implemented and verified using a 4 × 3 PV array model in MATLAB Simulink software. Different cases of uniformly changing irradiance and non-uniformly changing irradiance are applied to test the performance of the proposed hybrid technique. The load varying conditions are performed by applying a variable load resistor. The authenticity of the proposed hybrid technique is critically evaluated against the well-known and most widely used optimization techniques of modified perturb and observe (Modified P&O), particle swarm optimization (PSO), flower pollination algorithm (FPA), and grey wolf optimization (GWO). The results demonstrate the superiority of the proposed technique in oscillation-free tracking of global maximum power point (GMPP) in a minimum tracking time of 0.4 s and 0.15 s, and steady-state MPPT efficiency of 96.92% and 99.54% under uniform and non-uniform irradiance conditions, respectively. Full article

The output power against voltage curve of the photovoltaic system changes its characteristics under partial shading conditions because of using bypass diodes. These bypass diodes are connected across the PV modules inside the string to avoid hotspot formation in the shaded PV modules. Therefore, the output curve has multiple power peaks with only one Global Max Power Point. The classical Maximum Power Point Tracking algorithms may fail to track that Global Max Power. Several soft computing algorithms have been proposed to improve tracking efficiency with different optimization principles. In this paper, an Improved Cuckoo Search Algorithm has been proposed to increase the tracking speed with minimum output power oscillation. The proposed algorithm avoids spreading the initial particles among the whole curve to predict shading pattern, but it reduces the exploration area after each iteration to compensate for the algorithm’s randomness. The proposed algorithm was compared with other methods by simulation using MATLAB/Simulink program and with practical experiments under the same operating conditions. The comparison showed that the proposed algorithm overcomes the other methods’ drawbacks and concurrently minimizes the convergence time, power oscillation, and system power losses. Full article

The efficiency of photovoltaic (PV) systems depends directly on solar irradiation, so drastic variations in solar exposure will undoubtedly move its maximum power point (MPP). Furthermore, the presence of partial shading conditions (PSCs) generates local maximum power points (LMPPs) and one global maximum power point (GMPP) in the P-V characteristic curve. Therefore, a proper maximum power point tracking (MPPT) technique is crucial to increase PV system efficiency. There are classical, intelligent, optimal, and hybrid MPPT techniques; this paper presents a novel hybrid MPPT technique that combines Surface-Based Polynomial Fitting (SPF) and Perturbation and Observation (P&O) for solar PV generation under PSCs. The development of the experimental PV system has two stages: (i) Modeling the PV array with the DC-DC boost converter using a real-time and high-speed simulator (PLECS RT Box), (ii) and implementing the proposed GMPPT algorithm with the double-loop controller of the DC-DC boost converter in a commercial low-priced digital signal controller (DSC). According to the simulation and the experimental results, the suggested hybrid algorithm is effective at tracking the GMPP under both uniform and nonuniform irradiance conditions in six scenarios: (i) system start-up, (ii) uniform irradiance variations, (iii) sharp change of the (PSCs), (iv) multiple peaks in the P-V characteristic, (v) dark cloud passing, and (vi) light cloud passing. Finally, the experimental results—through the standard errors and the mean power tracked and tracking factor scores—proved that the proposed hybrid SPF-P&O MPPT technique reaches the convergence to GMPP faster than benchmark approaches when dealing with PSCs. Full article

A critical advancement in solar photovoltaic (PV) establishment has led to robust acceleration towards the evolution of new MPPT techniques. The sun-oriented PV framework has a non-linear characteristic in varying climatic conditions, which considerably impact the PV framework yield. Furthermore, the partial shading condition (PSC) causes major problems, such as a drop in the output power yield and multiple peaks in the P–V attribute. Hence, following the global maximum power point (GMPP) under PSC is a demanding problem. Subsequently, different maximum power point tracking (MPPT) strategies have been utilized to improve the yield of a PV framework. However, the disarray lies in choosing the best MPPT technique from the wide algorithms for a particular purpose. Each algorithm has its benefits and drawbacks. Hence, there is a fundamental need for an appropriate audit of the MPPT strategies from time to time. This article presents new works done in the global power point tracking (GMPPT) algorithm field under the PSCs. It sums up different MPPT strategies alongside their working principle, mathematical representation, and flow charts. Moreover, tables depicted in this study briefly organize the significant attributes of algorithms. This work will serve as a reference for sorting an MPPT technique while designing PV systems. Full article

If we look at the history of renewable energy sources (RESs), how it all began, and how rapidly they continue to develop, it can be argued that one of the main reasons is due to the rapid improvements in power electronics technology in interfacing the renewable source to the grid [...] Full article

This work introduces a light harvesting system with battery management. In contrast to relevant solutions that operate in limited ranges, the proposed system covers a wide operating input power range from 10 uW up to 300 mW. Specifically, experimental results highlight that, combined with a 73 × 94 mm flexible light harvester, it can harness light in a range from 50 LUX (indoor lighting) up to 120,000 LUX (outdoor lighting). The introduced system consists of a boost converter and an ultra-low power microcontroller (MCU). The MCU performs Global Maximum Power Point Tracking (GMPPT), using a resistor-free time-based input power sensing method, to calculate the input power of the converter, which does not interfere with the operation of the boost converter. The efficiency of the GMPPT system was evaluated with detailed experimentation, where we achieved 99.75% average GMPPT tracking efficiency while consuming only 73.5 uW at 4.2 V. Full article

Photovoltaic (PV) module working conditions lack consistency and PV array power outputs fluctuate due to the non-uniform impact that aging has on various PV modules in a PV array. No assessment has been conducted on the energy potential of a non-uniform PV array, despite the fact that the maximum power point (MPP) can be tracked by global maximum power point tracking (GMPPT). Therefore, the present work undertakes such an assessment by devising an algorithm to optimise the PV array electrical structure as the PV modules undergo aging in a non-uniform way. To enable PV arrays with non-uniform aging to produce as much power as possible and to make maintenance more cost-effective, the work puts forward a novel approach for reconfiguring PV arrays, where the PV modules are repositioned by retaining the aged PV modules. By this approach, the selection of the best reconfiguration topology necessitates the information on the electrical parameters associated with the PV modules in an array. Furthermore, the non-uniform aging of the PV modules can engender an incompatibility effect, which can be diminished in the proposed algorithm through iterative sorting of the modules in a hierarchical pattern. To determine how effective the method is for PV arrays with non-uniform aging and of different sizes, such as 3 × 4, 5 × 8 and 7 × 8 arrays, computer simulation and analysis have been conducted, with findings indicating that, irrespective of dimensions, PV arrays with non-uniform aging can have improved power yield. Full article

A global maximum power point tracking (GMPPT) process must be applied for detecting the position of the GMPP operating point in the minimum possible search time in order to maximize the energy production of a photovoltaic (PV) system when its PV array operates under partial shading conditions. This paper presents a novel GMPPT method which is based on the application of a machine-learning algorithm. Compared to the existing GMPPT techniques, the proposed method has the advantage that it does not require knowledge of the operational characteristics of the PV modules comprising the PV system, or the PV array structure. Additionally, due to its inherent learning capability, it is capable of detecting the GMPP in significantly fewer search steps and, therefore, it is suitable for employment in PV applications, where the shading pattern may change quickly (e.g., wearable PV systems, building-integrated PV systems etc.). The numerical results presented in the paper demonstrate that the time required for detecting the global MPP, when unknown partial shading patterns are applied, is reduced by 80.5%–98.3% by executing the proposed Q-learning-based GMPPT algorithm, compared to the convergence time required by a GMPPT process based on the particle swarm optimization (PSO) algorithm. Full article

Photovoltaic (PV) modules experience some partial shading conditions (PSC) due to some various factors. In that kind of a condition, a few maximum power points (MPPs) possibly appear on the power-voltage (P-V) curve, which increases the tracking difficulties. It is known that maximum power point tracking (MPPT) may not be realized by hill climbing (HC) based conventional MPPT algorithms under PSCs. In this context, this paper presents a novel micro converter based algorithm that was developed by using P-V characteristics of PV modules. Unlike voltage or duty ratio scanning techniques, this paper introduces a new deciding method to determine the correct global MPP (GMPP) region. For this, the proposed method uses some duty ratios that were calculated corresponding to each MPP region. Thus, the initialization of duty ratio is done properly, which results in high tracking speed and accurate tracking of the GMPP. The other advantages of the proposed algorithm are structural simplicity, less computational burden, and ease of implementation with a basic microcontroller. The simulation results show that this algorithm has fast tracking capability and it manages to track GMPP for PSCs correctly, since it includes an artificial scanning procedure. Single ended primary inductance converter (SEPIC) is built in order to validate the proposed global maximum power point tracking (GMPPT) algorithm. The performance of the proposed GMPPT technique is verified by experimental studies. The results show that the proposed GMPPT technique is fast by up to five times than an adaptive full scanning strategy and improved IC algorithm. Furthermore, the proposed algorithm can be commercially used in micro converters, since it is compatible with small number of bypass diodes in a module. Full article

The output–voltage–power curves of photovoltaic (PV) arrays exhibit complex multi-peak shapes when local shading occurs. The existing maximum power point tracking (MPPT) algorithms to solve this multi-peak problem do not consider the possibility of tracking failures due to the time of the irradiance change. In this study, first, the reason for the failure of the global MPPT (GMPPT) algorithm is analyzed based on the PV array mathematical model and its output characteristics under partial shading conditions; then, in order to estimate the MPP voltage, an artificial neural network (ANN) is trained using environmental information such as irradiance. A hybrid MPPT method using an augmented state feedback precise linearization (AFL) controller combined with an ANN is proposed to solve problems such as the shift of the static operating point of the DC/DC boost converter. Finally, numerical simulations are conducted to validate the proposed method and eliminate the possibility of MPPT failure. The proposed hybrid MPPT method is compared with the conventional perturb and observe (P & O) method and the improved P & O method through simulations. Using the proposed neural network and nonlinear control strategy, the MPP can be tracked rapidly, accurately, and statically, proving that the method is feasible and effective. Full article

Partial shading (PS) is an unavoidable condition which significantly reduces the efficiency and stability of a photovoltaic (PV) system. With PS, the system usually exhibits multiple-peak output power characteristics, but single-peak is also possible under special PS conditions. In fact it is shown that the partial shading condition (PSC) is the necessary but not sufficient condition for multiple-peak. Based on circuit analysis, this paper shows that the number of peak points can be determined by short-circuit currents and maximum-power point currents of all the arrays in series. Then the principle is established based on which the number of the peak points is to be determined. Furthermore, based on the dynamic characteristic of solar array, this paper establishes the rule for determination of the relative position of the global maximum power point (GMPP). In order to track the GMPP within an appropriate period, a reliable technique and the corresponding computer algorithm are developed for GMPP tracking (GMPPT) control. It exploits a definable nonlinear relation has been found between variable environmental parameters and the output current of solar arrays at every maximum power point, obtained based on the dynamic performance corresponding to PSC. Finally, the proposed method is validated with MATLAB^®/Simulink^® simulations and actual experiments. It is shown that the GMPPT of a PV generation system is indeed realized efficiently in a realistic environment with partial shading conditions. Full article
