Electrically charged particles present in this layer of the Earth’s atmosphere can alter radio waves, such as those from GPS, Galileo, or BeiDou, resulting in non-estimated errors with respect to the available navigation models for the end user. For most positioning algorithms based in sequential filters, this effect is translated into a slow convergence towards a solution around the decimeter error level. If we consider that the ionosphere’s effect varies based on the user’s location and solar activity due to the atmosphere particle composition, it becomes clear that a global accurate model, valid across wide areas accounting for different seasons and timespans, is, at the very least, quite challenging. The focus of this paper is the demonstration of a global ionosphere model designed to improve the positioning accuracy of the end user through the estimation of ionospheric corrections to the broadcasted navigation message. Mathematically, this method is based on a spherical harmonic expansion model. This approach has the advantage of reducing the dependency from a highly densified station network where the ionosphere delay must be constantly estimated in dozens of locations, in favor of a simplified model that barely needs to be adjusted with a limited set of real-time data (around 40 stations). In this case, GMV’s global station network was used, which comprises geodetic-grade receivers tracking the signal in open-sky locations around the globe. The global ionospheric model is configured to process signals from GPS and Galileo constellations. To evaluate the performances of this model on the final user position estimation, several precise point positioning (PPP) solutions were computed at different locations. The results were compared with PPP solutions calculated without ionospheric corrections at the same stations. The goal of this paper is to show the significant performance improvement observed with the implementation of the global model. Full article

With the growing demand for high-efficiency and secure information transmission, ultra-long-range optical communication has demonstrated significant potential. This paper proposes a method for establishing ground-based fixed-point ultra-long-range atmospheric optical communication links, aiming to overcome challenges such as atmospheric turbulence, transmission loss, and environmental interference. Through theoretical analysis and experimental validation, we developed a high-precision optical communication terminal installation model, determined the terminal’s optical axis direction via stellar calibration, and established a coordinate transformation model from geodetic coordinates to initial pointing angles. By analyzing initial pointing errors, we designed a laser link scanning strategy to compensate for uncertainties in the initial pointing region. The feasibility of this approach was verified through near-field validation and a long-distance link acquisition experiment exceeding 100 km. Experimental results demonstrated successful 100 km/100 Gbps ultra-high-speed optical communication. This breakthrough study is expected to play a critical role in future space-localized optical communication networks. Full article

Atmospheric refraction is a significant challenge to accurate distance and angle measurements in open-air environments, often limiting the precision of measurements obtained using electro-optic geodetic instruments despite their nominal accuracies. This study introduces a novel model, 3D-RM, designed to mitigate atmospheric effects on both distance and vertical angle measurements. The 3D-RM integrates in situ meteorological data from a network of automatic data-loggers, terrain information from a digital terrain model (DTM), and sensible heat flux from the fifth generation of European Centre for Medium-Range Weather Forecast reanalysis (ERA5), which is used in the application of the Turbulence Transfer Model (TTM) for estimating vertical refractivity gradients at various height levels. The model was tested with total station observations to 10 target points during two field campaigns. The results show that applying the model for distance correction leads to improvements in terms of closeness to reference values when compared to the standard method, which relies only on meteorological data collected at the station. Furthermore, the model has been additionally tested by removing the station meteorological data (3D-RM2). The results demonstrate that accurate corrections can be obtained even without the need of meteorological sensors specifically installed at the station point, which makes it more flexible. The 3D-RM is a cost-effective and relatively easy-to-implement solution, offering a promising alternative to existing methodologies, such as measuring meteorological values at both station and target points or the development of new instruments that can compensate the refractivity (such as a multiple-color electronic distance meter). Full article

This study addresses the potential of machine learning (ML) algorithms in geophysical and geodetic research, particularly for enhancing GNSS time series analysis. We employed XGBoost and Long Short-Term Memory (LSTM) networks to analyze GNSS time series data from the tectonically active Anatolian region. The primary objective was to detect discontinuities associated with seismic events. Using over 13 years of daily data from 15 GNSS stations, our analysis was conducted in two main steps. First, we characterized the signals by identifying linear trends and seasonal variations, achieving $R^2$ values of 0.84 for the XGBoost v.2.1.0 model and 0.81 for the LSTM model. Next, we focused on the residual signals, which are primarily related to tectonic movements. We applied various threshold values and tested different hyperparameters to identify the best-fitting models. We designed a confusion matrix to evaluate and classify the performance of our models. Both XGBoost and LSTM demonstrated robust performance, with XGBoost showing higher true positive rates, indicating its superior ability to detect precise discontinuities. Conversely, LSTM exhibited a lower false positive rate, highlighting its precision in minimizing false alarms. Our findings indicate that the best fitting models for both methods are capable of detecting seismic events (Mw ≥ 4.0) with approximately 85% precision. Full article

Vertical displacements are traditionally measured with precise levelling, which is inherently time consuming. Rapid or even real-time height determination can be achieved by the Global Navigation Satellite System (GNSS). Nevertheless, the accuracy of real-time GNSS positioning is limited, and the deployment of a network of continuously operating GNSS receivers is not cost effective unless low-cost GNSS receivers are considered. In this study, we examined the use of geodetic-grade and low-cost GNSS receivers for static and real-time GNSS levelling, respectively. The results of static GNSS levelling were processed in four different software programs or services. The largest differences for ellipsoidal/normal heights reached 0.054 m/0.055 m, 0.046 m/0.047 m, and 0.058 m/0.058 m for points WRO1, BM_ROOF, and BM_CP, respectively. In addition, the values depended on the software used and the location of the point. However, the multistage experiment was designed to analyze various strategies for GNSS data processing and to define a method for detecting vertical displacement in a time series of receiver coordinates. The developed method combined time differentiation of coordinates estimated for a single GNSS receiver using the Precise Point Positioning (PPP) technique and Butterworth filtering. It demonstrated the capability of real-time detection of six out of eight displacements in the range between 20 and 55 mm at the three-sigma level. The study showed the potential of low-cost GNSS receivers for real-time displacement detection, thereby suggesting their applicability to structural health monitoring, positioning, or early warning systems. Full article

The optimization of measurements in a geodetic network (second-order design) has been investigated in the past; however, the practical usability of the outcomes of most of such studies is doubtful. Hence, we have proposed a new automated optimization algorithm, taking into account the practical aspects of total station measurements. The algorithm consists of four parallel partial algorithms, of which one is subsequently automatically selected—the one meeting the geodetic network accuracy requirements with the lowest number of necessary measurements. We tested the algorithm (and individual partial algorithms) on four geodetic networks designed to resemble real-world networks with 50–500 modifications to each of those networks in individual tests. The results indicate that (i) the results achieved by the combined algorithm are close to the optimal results and (ii) none of the four partial algorithms universally performs the best, implying that the combination of the four partial algorithms is necessary for achieving the best possible results of geodetic network optimization. Full article

The development of precision agriculture requires unmanned aerial vehicles (UAVs) to collect diverse data, such as RGB images, 3D point clouds, and hyperspectral images. Recently, convolutional networks have made remarkable progress in downstream visual tasks, while often disregarding the trade-off between accuracy and speed in UAV-based segmentation tasks. The study aims to provide further valuable insights using an efficient model named Taoism-Net. The findings include the following: (1) Prescription maps in agricultural UAVs requires pixel-level precise segmentation, with many focusing solely on accuracy at the expense of real-time processing capabilities, being incapable of satisfying the expectations of practical tasks. (2) Taoism-Net is a refreshingly segmented model, overcoming the challenges of complexity in deep learning, based on minimalist design, which is used to generate prescription maps through pixel level classification mapping of geodetic coordinates (the lychee tree aerial dataset in Guangdong is used for experiments). (3) Compared with mainstream lightweight models or mature segmentation algorithms, Taoism-Net achieves significant improvements, including an improvement of at least 4.8% in mIoU, and manifested a superior performance in the accuracy–latency curve. (4) “The greatest truths are concise” is a saying widely spread by ancient Taoism, indicating that the most fundamental approach is reflected through the utmost minimalism; moreover, Taoism-Net expects to a build bridge between academic research and industrial deployment, for example, UAVs in precision agriculture. Full article

This study analyzes repercussions for the morphology, talweg, riverbanks and surrounding structures of several aquatic systems transformed by multipurpose reservoirs located within the Ecuadorian territory of South America. For this purpose, several geomatics techniques were used simultaneously, minimizing the temporal error in the reservoir water level in order to measure the impact of partial or total emptying operations on these reservoirs. High precision geodetic networks were designed to synchronously use geospatial data-capturing equipment, namely UASs/drones with INS/GNSS systems, LiDAR sensors, RGB optical sensors, USVs/aquatic drones equipped with GNSS systems, and single-beam sensors. Photogrammetric, LiDAR and underwater results were contrasted with topographic techniques used in the monitoring and control of structures. Environmental changes in the surroundings, soil movements due to sedimentary and erosive effects, and possible displacements in existing structures were analyzed. Full article

Seafloor geodetic network (SGN) is the foundation for building an underwater positioning, navigation and timing (PNT) system. Traditional network deployment mainly focuses on the deployment of underwater sensor network nodes. However, for SGN, there is no surface buoy node and submarine buoy node, and the number of anchors is limited because it is quite expensive to fully cover large scale areas. To achieve wide coverage and good positioning service of each set of underwater base stations, we focus on the network design of a single set of reference stations in this paper. We propose several deployment plans for a local SGN and then analyze their service quality indicators by considering the stratification effect caused by non-uniformly distributed sound speed. To evaluate the performance of each topology of SGN, we compare their coverage range, horizontal dilution precision (HDOP) and accuracy performance of positioning tests. Based on the overall performance in our simulation, we believe that the star five-node topology is a good topology design under sufficient economic conditions. Full article

Geodetic-grade Global Navigation Satellite System (GNSS) receivers designed to implement permanent stations represent the most complex and costly technology in the field of GNSS instrumentation. On the other hand, a large number of innovative applications, highly demanding in terms of positioning precision and accuracy, is pushing the implementation of networks of permanent stations with a higher and higher spatial density. In this scenario, the development of brand new GNSS reference stations, which combine the most advanced technologies in the field of data availability and integrity together with reduced costs (of instrumentation, installation and management) is becoming of paramount importance. For this reason, in 2019 the EU Agency for the Space Programme (EUSPA) has financed a research project, called “next Generation gnss REference stATion—GREAT”, aimed at developing and demonstrating the potentiality of a brand new GNSS receiver suitable to implement permanent stations. This paper describes the solution developed by the project consortium, composed of four Small or Medium Enterprises (SMEs) based in Italy, France and Belgium, and the preliminary results achieved in the field tests. Full article

This paper presents the CRBeDaSet—a new benchmark dataset designed for evaluating close range, image-based 3D modeling and reconstruction techniques, and the first empirical experiences of its use. The test object is a medium-sized building. Diverse textures characterize the surface of elevations. The dataset contains: the geodetic spatial control network (12 stabilized ground points determined using iterative multi-observation parametric adjustment) and the photogrammetric network (32 artificial signalized and 18 defined natural control points), measured using Leica TS30 total station and 36 terrestrial, mainly convergent photos, acquired from elevated camera standpoints with non-metric digital single-lens reflex Nikon D5100 camera (ground sample distance approx. 3 mm), the complex results of the bundle block adjustment with simultaneous camera calibration performed in the Pictran software package, and the colored point clouds (ca. 250 million points) from terrestrial laser scanning acquired using the Leica ScanStation C10 and post-processed in the Leica Cyclone™ SCAN software (ver. 2022.1.1) which were denoized, filtered, and classified using LoD3 standard (ca. 62 million points). The existing datasets and benchmarks were also described and evaluated in the paper. The proposed photogrammetric dataset was experimentally tested in the open-source application GRAPHOS and the commercial suites ContextCapture, Metashape, PhotoScan, Pix4Dmapper, and RealityCapture. As the first experience in its evaluation, the difficulties and errors that occurred in the software used during dataset digital processing were shown and discussed. The proposed CRBeDaSet benchmark dataset allows obtaining high accuracy (“mm” range) of the photogrammetric 3D object reconstruction in close range, based on a multi-image view uncalibrated imagery, dense image matching techniques, and generated dense point clouds. Full article

The idea of constructing the “GNSS-like” seafloor geodetic network for underwater positioning, navigation, and timing (PNT) has been proposed by many countries. Based on this idea, this paper introduces the principle of the seafloor PNT network and provides a combined measurement method, including the absolute positioning and the relative positioning. Experimental results show that the positioning difference between the proposed method and circle-sailing positioning is approximately 10 cm, and the observation efficiency is higher than the existing measurement in the seafloor PNT network. In addition, a model is derived to determine the optimal configuration of the unit network (the basic component of the seafloor PNT network), considering the ranging capability of acoustic beacons, which is helpful to balance the side length of the unit network and the number of observation sessions in the relative positioning. Finally, a chain coordinate transfer strategy in the whole seafloor PNT network is proposed, and the positions where the absolute positioning should be carried out in the whole network are derived based on the conditional adjustment model. Based on this strategy, the design schemes of a seafloor PNT network with centimeter, decimeter, and meter positioning accuracy when the acoustic velocity measuring accuracy is 0.02 m/s and the time measuring accuracy is 10⁻⁵ s, are given in the experimental section. Full article

Studying the spatiotemporal distribution and motion of water vapour (WV), the most variable greenhouse gas in the troposphere, is pivotal, not only for meteorology and climatology, but for geodesy, too. In fact, WV variability degrades, in an unpredictable way, almost all geodetic observation based on the propagation of electromagnetic signal through the atmosphere. We use data collected on a dense GPS network, designed for the purposes of monitoring the active Neapolitan (Italy) volcanoes, to retrieve the tropospheric delay parameters and precipitable water vapour (PWV). This study has two main targets: (a) the analysis of long datasets (11 years) to extract trends of climatological meaning for the region; (b) studying the main features of the time evolution of the PWV during heavy raining events to gain knowledge on the preparatory stages of highly impacting thunderstorms. For the latter target, both differential and precise point positioning (PPP) techniques are used, and the results are compared and critically discussed. An increasing trend, amounting to about 2 mm/decades, has been recognized in the PWV time series, which is in agreement with the results achieved in previous studies for the Mediterranean area. A clear topographic effect is detected for the Vesuvius volcano sector of the network and a linear relationship between PWV and altitude is quantitatively assessed. This signature must be taken into account in any modelling for the atmospheric correction of geodetic and remote-sensing data (e.g., InSAR). Characteristic temporal evolutions were recognized in the PWV in the targeted thunderstorms (which occurred in 2019 and 2020), i.e., a sharp increase a few hours before the main rain event, followed by a rapid decrease when the thunderstorm vanished. Accounting for such a peculiar trend in the PWV could be useful for setting up possible early warning systems for those areas prone to flash flooding, thus potentially providing a tool for disaster risk reduction. Full article

The elevation of airport runways is specified in the operations manuals and in globally accepted design guidelines. Airport runways are constantly exposed to various physical and weather factors. However, these factors can deteriorate the condition of the runway to the point where it becomes unusable. Monitoring and the continuous inspection of runway evenness is an important element of a sustainable airport maintenance system. An important element of a sustainable airport maintenance system is a runway evenness detection and modelling system. The investigation of the use of various available methods for modelling runway evenness was conducted based on measurements of the actual condition of the existing runway at Edvard Rusjan Airport in Maribor, Slovenia. During the measurements of the runway condition, our own measurement equipment was used, which ensures the geodetic accuracy of the measurements. The novelty of the article is a comparison between five different approaches to modelling runway evenness: approximation with regression plane, inverse distance weighted interpolation (IWD) with a weighting factor of 1, 2, and 10, and interpolation based on a triangulated irregular network (TIN)–linear and cubic. In the methodology section, the advantages and disadvantages of the mentioned methods were described. The selected models were evaluated by required processor time, by the file size resulting from the modelling, and by the values of the descriptive statistics of the model deviation at the average uniform slope. It was found that the modelling method using linear triangular irregular network interpolation provided the most useful results. The results of the conducted analysis can be easily used in any runway management models at airport thet allow for professionally based actions aimed at ensuring the safety and efficiency of runway operations, especially at smaller, regional airports. Full article

The layout or stake-out is one of the most important assignments of the surveying engineer, and it is of vital importance in the building process, as the designed geometries of the structure ensure the verticality and the correct positioning inside the terrain. The mission of the surveying engineer involves both legal and technical aspects, and the correct planning of the layout process must take into consideration aspects regarding the site conditions, instrumentation used, the required and achievable accuracies, network design and survey methods used. Given the vast applications of geodesy and topography in different domains and industries, the study incorporates general notions and technical aspects regarding the workflow in cadastre and construction surveying, guidelines for an efficient design of site layout plan with on-site applicability, as well as a novel comparison between four methods of construction lines geometry layout on batter boards. The results of this study aim to further consolidate the importance of accurate and efficient construction layout projects, with comprehensive design plans, methods and instrumentation selection, as well as recommendations. The presented discussions and conclusions are of interest to the geodetic community as well as the construction industry, and due to the pragmatic and experimental nature of the research, incorporates technical notes and original results of professional and academic importance. Full article
