Search Results (30)

The aim of this current work is to identify three different gears of cross-country skiing utilizing embedded inertial measurement units and a suitable deep learning model. The cross-country style studied was the skating style during the uphill, which involved three different gears: symmetric gear pushing with poles on both sides (G3) and two asymmetric gears pushing with poles on the right side (G2R) or to the left side (G2L). To monitor the technique, inertial measurement units (IMUs) were affixed to the skis, recording acceleration and Euler angle data during the uphill tests performed by two experienced skiers using the gears under study. The initiation and termination points of the tests were controlled via Bluetooth by a smartphone using a custom application developed with Android Studio. Data were collected on the smartphone and stored on the SD memory cards included in each IMU. Convolutional neural networks combined with long short-term memory were utilized to classify and extract spatio-temporal features. The performance of the model in cross-user evaluations demonstrated an overall accuracy of 90%, and it achieved an accuracy of 98% in the cross-scene evaluations for individual users. These results indicate a promising performance of the developed system in distinguishing between different ski gears within skating styles, providing a valuable tool to enhance ski training and analysis. Full article

In this study, a novel magnetic gear design is introduced. Unlike conventional magnetic gears that can only achieve a single gear ratio using permanent magnetic poles, the proposed design incorporates electromagnetic coils that can adapt to various control strategies, resulting in a multiple gear ratio for the same machine design. We selected a gear system with five gear ratios to validate the new design. The performance of the proposed design was compared with that of the conventional magnetic gear. While permanent magnet poles offer high torque transmission with a small volume, they cannot provide different gear ratios for the same configuration. Therefore, this work suggests using a single-gear machine based on a fixed number of electromagnetic coils to achieve different gear ratios. This research outlines the design steps, simulation process, and detailed analysis. The results demonstrate the effectiveness of the proposed design strategy, which can be potentially applied to wind turbines, transportation, and other scenarios with comparable success. Full article

This study presents an approach for calculating the stress and deformation increase in the modulation of magnetically geared machines using a mathematical method. An analytical method is employed to obtain the magnetic force density acting on the modulation components. Afterward, the proposed mathematical method predicts the mechanical characteristics. The 9 slots/32 poles/19 modulations model was evaluated via a comparison with the finite element method simulation. Full article

Based on the magnetic gear effect, the field-modulated permanent-magnet machine (FMPMM) can realize the unequal pole design of the rotor PM field and the stator armature magnetic field. With the advantages of high torque density and high efficiency, the FMPMM has been widely studied in low-speed direct-drive applications. As a kind of machine excited by PMs, the performance of the FMPMM was affected by the demagnetization state. However, the method for establishing the FMPMM demagnetization model based on a finite element analysis (FEA) presented some problems, including tedious repeated modeling work and long calculation time-consuming under fine subdivision. Therefore, in this paper, a six-phase surface-mounted FMPMM was taken as an example, and an equivalent magnetic network (EMN) model was proposed for evaluating the machine performance under demagnetization. In order to realize the rapid establishing EMN models under diverse demagnetization types, the variable coercivity of PM was introduced. Furthermore, for the purpose of improving the calculation accuracy and shortening the calculation time, the least square method was used in fitting and analyzing the discrete results. Then, in order to verify the validity of the proposed EMN model, a prototype was fabricated and a testing platform was built. The air-gap flux density and the no-load back EMF obtained by the FEA, the proposed EMN model, and the experimental testing were compared. The results showed that the proposed EMN model can realize the rapid modeling and accurate analysis of the six-phase surface-mounted FMPMM under diverse demagnetization types. Full article

This paper presents the profiling of the hob mill designed to generate the active surface of the cam of a cycloidal reducer. The algorithm allows determining the active surface of the generating rack gear, which is reciprocally enveloping with the active surface of the cycloidal disk. The novelty of the algorithm, based on the determination of the intermediate surface, consists in the fact that an innovative method of determining this surface is used, called the “virtual pole” method. The method allows determining the enwrapping curve of an ordered curl of surfaces, generated in the rolling movement of two conjugated centrodes. Using the “virtual pole” method, the calculation time for tool profiling is significantly reduced and the disadvantage of the resulting error, small enough to be neglected from a technical point of view, is fully compensated by this reduction in calculation time. Full article

There is a trend to go towards low gear-ratio or even direct-drive actuators in novel robotic applications in which high-torque density electric motors are required. The Yokeless and Segmented Armature Axial Flux Permanent Magnet Synchronous Machine is therefore considered in this work. In these applications, the motors should be capable to deliver high torque at standstill for long periods of time. This can cause overheating of the motors due to a concentration of the losses in a single phase; hence, it becomes necessary to derate the motor torque. In this work the influence of the slot/pole combination, the addition of a thermal end-winding interconnection and the equivalent thermal conductivity of the winding body on the torque performance at standstill will be studied both experimentally via temperature measurements on a prototype stator, and via a calibrated 3D thermal Finite Element model. It was found that both a good choice of the slot/pole combination and the addition of a thermal end-winding interconnection have a significant influence on the torque performance at standstill, and allow up to 8% increase in torque at standstill in comparison to a reference design. Full article

Removing the gearbox from the single-motor configuration of an electric vehicle (EV) would improve motor-to-wheel efficiency by preventing mechanical losses, thus extending the autonomy of the EV. To this end, a permanent-magnet Vernier machine (PMVM) is designed to ensure such operation. This machine avoids the high volume and large pole-pair number of the armature winding since its operating principle resembles that of a synchronous machine with an integrated magnetic gear. Therefore, such a structure achieves low-speed and high-torque operation at standard supply frequencies. From the specification of an urban vehicle, the required specification for direct-drive operation is first determined. On this basis, an initial prototype of a Vernier Machine with permanent magnets in the rotor that can replace the traction part (motor + gearbox) is designed and sized. This first prototype uses radial contiguous surface-mounted magnets and its performance is then analyzed using finite element analysis (FEA), showing a relatively high torque ripple ratio. The rotor magnets are then arranged in a quasi-Halbach configuration and simulations are performed with different stator slot openings and different ratios of the tangential part of the magnet in order to quantify the effect of each of these two quantities in terms of average torque, torque ripples and harmonics of the back-electromotive force at no load. Since the design and optimization of this motor is finite element-assisted, a coupling process between FEA Flux software and Altair HyperStudy is implemented for optimization. This method has the advantages of high accuracy of the magnetic flux densities and electromagnetic torque estimates, and especially the torque ripples. The optimization process leads to a prototype with an average torque value that meets the specification, along with a torque ripple ratio below 5% and a high power factor, while keeping the same amount of magnet and copper. Full article

In this paper, a staggered vernier generator suitable for a counter-rotating self-adaptable WEC is proposed to meet the energy demand of the small-scale engineering equipment in the deep sea. According to the vernier effect of the magnetic gear, the generator modulates the low-order rotating magnetic field generated by the rotation of the low-speed permanent magnet rotor into a high-order magnetic field rotating at a high speed, thereby realizing the acceleration of the generator magnetic field. A staggered structure permanent magnet vernier generator with 18 teeth/28 poles is designed. The main magnetic flux path on the staggered structure in the staggered vernier generator is analyzed, and the air-gap magnetic field distribution of the generator is analyzed with the help of numerical simulation software. The influence of different design parameters on the vernier generator is discussed. The staggered vernier structure can improve the main magnetic flux of the generator, reduce the magnetic flux leakage, and improve the performance of the generator without adding additional structures and materials. Full article

This paper investigates the prospect of permanent magnet vernier machine (PMVM) technology for wind power applications. Two types of PMVMs are defined based on the winding arrangements and resultant gear ratio ranges. A comprehensive design study of the selected PMVM topologies is conducted at 1 and 3 MW power levels. The optimized candidate designs of the PMVMs are then evaluated and also compared against the equivalent permanent magnet synchronous machine (PMSM) in terms of performance, costs, size and mass. While the existing research publications mainly focused on the PMVM designs of ($G_r=5$), this study reveals that the pole/slot combinations of PMVMs with ($G_r\le 5$) are more appealing as there is a good trade-off between a reasonable power factor and high power density in these designs. It shows, in this paper, that the PMVM is a promising alternative to common PMSM technology for utility-scale wind-turbine drive-train applications. Full article

The present work investigates the size of gear damage required for significant recognisable change in the vibration signal and presents a method to determine digital filter limits in order to emphasise the vibration behaviour in the time domain. For this purpose, two gears are artificially damaged to four different degrees. The damage levels are determined by a tactile gear measurement and the gears are inserted into two intact gearboxes. Measurements at different speeds are used to generate a representative dataset. On the one hand, the recorded signals are examined via cross-correlation in the time domain. On the other hand, the occurring frequency components are examined using a windowed fast Fourier transformation. Based on the two observations, a statement is made about the recognisability of the damage levels of the two gears in the vibration signal. Furthermore, smoothed spectra are calculated via linear prediction coefficients (LPC) and an appropriate number of required coefficients is estimated via the Akaike information criterion. Subsequently, the calculated prediction coefficients are used as coefficients of an all-pole filter to calculate difference spectra. Based on the difference spectra, filter limits for a digital filter are derived to emphasise the damaged tooth meshing in the time domain. Full article

Magnetic gear mechanisms have advanced to have a promising future in transmission technology. Previous research indicates that magnetic gear mechanisms might replace mechanical gear mechanisms in some applications. Small-scale wind turbines (SWT) with counter-rotating rotors that were initially fitted by bevel gears are proposed to be replaced by a coaxial magnetic gear train (CMGT). The CMGT is intended for use as a speed multiplier in order to obtain maximum power at low wind speeds, due to its beneficial transmission of power without physical contact. The primary objective of this study is to build a dual-input CMGT that will be employed in the transmission system of small-scale counter-rotating wind turbines. A dual-input CMGT is built through the analytical modeling of an equivalent magnetic circuit (EMC), which aims to predict the magnetic flux density in the air-gaps of CMGT. Several models within design constraints were compared to obtain the optimum design parameters of the preliminary CMGT design resulting from an EMC analysis. The optimized critical design parameters were then selected and analyzed using finite-element analysis (FEA) to depict the performance of the proposed SWT design. According to the findings, the developed design can generate an inner air-gap flux density of 0.8314 T and an outer air-gap flux density of 1.0200 T. The model likewise produces promising simulation results with an output transmitted torque in the inner rotor (output link) of 8.7 Nm, 56.9 Nm in the outer rotor, and 48.0 Nm in the carrier with pole-pieces. Thus, this design can generate higher torque than a bevel-geared wind turbine. The speed characteristics are also compromised in order to raise the generator’s rotating speed to generate more power. Finally, this study demonstrates the performance and embodiment design of the proposed SWT using CMGT. Full article

This paper reports the design of a magnetic-geared permanent magnet synchronous motor (MG-PMSM) for a 45 kW tram traction system based on high torque density. In the case of the existing tram driving system, due to mechanical reduction gear and induction motor, it causes power transmission loss, low efficiency, and difficulty in lightweight. To solve this problem, research on the MG-PMSM, which combines a contactless magnetic gear with a high-power-density PMSM, is being actively conducted. This motor has a double rotor structure, and the inner rotor, including permanent magnet, and the outer rotor composed of pole-pieces rotate at different mechanical speeds. However, it is hard to design a tram driving system with a high torque density within limited conditions, because only one rotor in MG-PMSM is used as an output. In addition, there is no study conducted from basic design to final design, including gear ratio and topology selection in MG-PMSM for tram. Therefore, this paper presents the design process of MG-PMSM with high torque density to be applied to the 45 kW–class tram driving system. After designing the magnetic gear part that increases torque and efficiency by selecting an appropriate topologies-and-gear ratio that meets the constraints, the final finite elements method (FEM) model and electromagnetic field analysis results were derived by considering the number of poles and the number of slots. Through this, we confirmed that it is superior in output characteristics compared to the existing induction motor + mechanical gear. Full article

With the development of robot technology, integrated joints with small volume and convenient installation have been widely used. Based on the double inertia system, an integrated joint motor servo system model considering gear angle error and friction interference is established, and a joint control strategy based on BP neural network and pole assignment method is designed to suppress the vibration of the system. Firstly, the dynamic equation of a planetary gear system is derived based on the Lagrange method, and the gear vibration of angular displacement is calculated. Secondly, the vibration displacement of the sun gear is introduced into the motor servo system in the form of the gear angle error, and the double inertia system model including angle error and friction torque is established. Then, the PI controller parameters are determined by pole assignment method, and the PI parameters are adjusted in real time based on the BP neural network, which effectively suppresses the vibration of the system. Finally, the effects of friction torque, pole damping coefficient and control strategy on the system response and the effectiveness of vibration suppression are analyzed. Full article

The magnetic geared permanent magnet synchronous motor (MG-PMSM) is a PMSM that has two rotors with different rotation speeds and includes the function of magnetic gear. The design studies of the 45kW-class MG-PMSM are conducted for the application of the driving system for a tram. In this research, first, to derive the detailed model of the 45kW-class MG-PMSM for the tram, the analysis of the characteristics according to the stator winding method was performed. After selecting the winding method that can reduce the size of the MG-PMSM, two design topologies were applied to determine the number of stator poles, the number of outer rotor pole pieces, and the number of inner rotor poles of the MG-PMSM. A 45kW-class MG-PMSM detailed model was derived by applying a design topology that can minimize the size of the MG-PMSM, and it was confirmed that the required performance is satisfied through electromagnetic characteristics analysis. In addition, the 4.5kW-class small-scaled MG-PMSM prototype with concentrated winding was manufactured to verify the validity of the analytical model, and performance verification was performed. Full article

This paper describes and explains the synthesis of an astronomical clock mechanism which displays the mean position of the Sun, the Moon, the lunar node and zodiac circle as well as the Moon phases and their motion during the year as seen from the Earth. The clock face represents the stereographic projection of the celestial equator, celestial tropics, zodiac circle (ecliptic) and horizon for the latitude of Belgrade from the north celestial pole to the equator plane. The observed motions of celestial objects are realized by a set of clock gear trains with properly calculated gear ratios. The method of continued fraction is applied in the computation of proper and practically applicable gear ratios of the clock gear trains. The fully operational 3D model of the astronomical clock is created and the motion study of its operation is accomplished by using the SolidWorks 2016 application. The simulation results are compared with the ephemeris data and the detected differences are used to evaluate the long-term accuracy of the astronomical clock operation. The presented methods of the clock mechanism synthesis can be useful for the design, maintenance and conservation of large-scale city astronomical clocks since these clocks represent a precious historical and cultural heritage of European civilization. Full article
