Gas-insulated switchgears (GISs) and gas-insulated transmission lines (GILs) are essential for large-capacity power transmission in demanding environments, such as high drops, large spans, and heavy pollution. As the core components providing both electrical insulation and mechanical support, ultra-high voltage (UHV) epoxy-based insulators often suffer from high internal residual stress. This issue, compounded by a lack of reliable detection methods, frequently results in equipment being commissioned with hidden defects. To address this, this review first examines the formation mechanisms of curing deformation and residual stress in oversized insulators based on cure kinetics and thermo-chemical coupling models. Subsequently, it provides a comprehensive summary of current residual stress measurement techniques, comparing the applicability and limitations of embedded sensors, direct mechanical measurements, and indirect non-destructive testing (NDT) methods. Finally, by coupling residual stress with filler sedimentation, the stress distribution patterns and mechanical reliability of epoxy-based insulators across different life-cycle stages are analyzed. These insights offer valuable theoretical references for the structural design, process optimization, and performance evaluation of oversized epoxy-based insulators, ultimately contributing to the intrinsic safety of UHV power equipment. Full article

The operational reliability of gas-insulated switchgear/gas-insulated transmission lines (GIS/GIL) is critically threatened by internal metallic particles, which serve as primary triggers for insulation degradation. Conventional partial discharge (PD) detection methods often lack sensitivity during the early stages of particle movement. To overcome these limitations, this study aims to develop a novel non-intrusive defect diagnosis methodology based on the analysis of mechanical vibration signals. The coupled particle motion model integrating the electrostatic field, particle tracking, and multibody dynamics has been established. This model reveals the dynamic law that metallic particles migrate toward the conductor and undergo charge polarity reversal after collision, with a maximum speed of 2.7 m/s. Meanwhile, the peak vibration acceleration excited by the collision is calculated as 0.02 m/s². Accordingly, the high-voltage experimental platform with the full-scale prototype is built to simulate the actual operating conditions of the power grid. With the particle defects set inside the prototype, vibration signals are collected by using an accelerometer, and the measured peak vibration acceleration is 0.017 m/s². Finally, a defect diagnosis method based on the Hilbert–Huang Transform (HHT) and correlation coefficient analysis is proposed. This method uses Empirical Mode Decomposition (EMD) to extract the IMF4 component of the signal in the vicinity of the 1000 Hz frequency band. When particle defects occur, the correlation coefficient between the IMF4 component and the original signal exceeds 0.7668. This vibration-based monitoring technique provides an alternative for the condition-based maintenance of GIS/GIL, offering significant engineering value for enhancing the safety and reliability of power transmission infrastructure. Full article

The residual sub-millimeter metal particles in gas-insulated metal enclosed switchgear (GIS) and gas-insulated transmission lines (GILs) are significant factors that trigger insulation failures. During actual operation, these particles not only endure the action of alternating electric fields but also are continuously stimulated by mechanical vibrations. Current research mostly focuses on the behavior of millimeter-sized particles under a single physical field, lacking in-depth understanding of the jumping characteristics of sub-millimeter-scale particles under the combined action of alternating electric fields and mechanical vibrations. This paper has built a collaborative action test platform and constructed a spherical-bowl-shaped electrode defect model. It systematically studied the jumping behavior, motion evolution, and local discharge characteristics of 20-mesh and 40-mesh irregular aluminum particles under the combined action of different voltages (0–7 kV) and mechanical vibrations (amplitude 0.01–0.1 mm, frequency 10–100 Hz). The results show that mechanical vibrations provide initial kinetic energy for the particles, significantly reducing the threshold for jumping, and are the key initiating factor in the collaborative action; in the low-voltage stage, vibration dominates the jumping behavior, while in the high-voltage stage, the electric field dominates the motion evolution; and under dual stimulation, the jumping area of the particles is wider and the motion forms are more diverse (such as flying-flying motion, vertical state, pile-up excitation, etc.), and the starting voltage of discharge is significantly reduced, the discharge repetition rate increases with the increase in vibration intensity and voltage, and is closely related to the particle size. This paper reveals the uniqueness of particle motion and discharge under the collaborative action, providing a theoretical basis for the assessment of multi-physical field states and fault prediction of GIS/GIL. Full article

Power supply for traction substations (TSs) of AC railways has traditionally been provided by 110–220 kV overhead transmission lines (OHL). These OHLs can be damaged during strong winds and ice formation. Furthermore, these lines generate significant electromagnetic fields (EMFs), which adversely affect maintenance personnel, the public, and the environment. Mitigating the resulting damages requires the establishment of protection zones, necessitating significant land allocation. Enhancing the reliability of power supply to traction substations and reducing EMF levels can be achieved through the use of gas-insulated lines (GIL), whose application in the power industry of many countries is continuously increasing. The aim of the research presented in this article was to develop computer models for determining the EMF of a GIL supplying a group of traction substations, taking into account actual traction loads characterized by non-sinusoidal waveforms and asymmetry. To solve this problem, an approach implemented in the Fazonord AC-DC software package, based on the use of phase coordinates, was applied. This allowed for the correct accounting of the skin effect and proximity effect in the massive current-carrying parts of the GIL, as well as the influence of asymmetry and harmonic distortions. The simulation results showed that the use of GIL brings the voltage unbalance factors at the 110 kV busbars of the traction substations within the permissible range, with the maximum values of these coefficients not exceeding 2%. The results of the harmonic distortion assessment demonstrated a significant reduction in harmonic distortion factors in the 110 kV network for the GIL compared to the OHL. The performed electromagnetic field calculations confirmed that the GIL generates magnetic field strengths one order of magnitude lower than those of the OHL. The obtained results lead to the conclusion that the use of gas-insulated lines for powering traction substations is highly effective, ensuring increased reliability, improved power quality, and a reduced negative impact of EMF on personnel, the public, the environment, and electronic equipment. Full article

Gas-insulated transmission lines (GILs) are increasingly deployed in dense urban power networks, where complex construction activities may introduce external mechanical impacts and pose risks to pipeline structural integrity. However, existing GIL monitoring approaches mainly emphasize electrical and gas-state parameters, while lightweight solutions capable of rapidly detecting and localizing impact-induced structural anomalies remain limited. To address this gap, this paper proposes an intelligent end-edge-cloud monitoring system for impact anomaly detection in GIL pipelines. Numerical simulations are first conducted to analyze the dynamic response characteristics of the pipeline under impacts of varying magnitudes, orientations, and locations, revealing the relationship between impact scenarios and vibration mode evolution. An end-tier multi-parameter intelligent sensor is then developed, integrating triaxial acceleration and angular velocity measurement with embedded lightweight computing. Laboratory impact experiments are performed to acquire sensor data, which are used to train and validate a multi-class extreme gradient boosting (XGBoost) model deployed at the edge tier for accurate impact-location identification. Results show that, even with a single sensor positioned at the pipeline midpoint, fusing acceleration and angular velocity features enables reliable discrimination of impact regions. Finally, a lightweight cloud platform is implemented for visualizing structural responses and environmental parameters with downsampled edge-side data. The proposed system achieves rapid sensor-level anomaly detection, precise edge-level localization, and unified cloud-level monitoring, offering a low-cost and easily deployable solution for GIL structural health assessment. Full article

Basin insulator is a critical component of gas-insulated transmission line (GIL) systems. Air gap defects and surface crack defects may form in basin insulators due to casting, installation, or transport processes. This phenomenon poses a significant threat to long-term safety and stability and may even lead to partial discharges. This study establishes a simulation model of a GIL system-incorporating insulator to systematically analyze the influence patterns of various defects on the insulation characteristics of the basin insulator. Meanwhile, an equation predicting the relationship between defect size and maximum electric field strength is derived. The research revealed the following: For short air gap defects near the conductor, increasing length reduces their impact on the surrounding electric field, with the radius having minimal effect; for long air gap defects near the conductor, increasing length amplifies their influence. Smooth air gap defects distant from the conductor show negligible variation in maximum electric field strength with increasing length, while unsmooth air gap defects exhibit more pronounced effects at shorter lengths. Under identical conditions, unsmooth air gap defects demonstrate greater influence on the electric field than smooth ones. For elliptical surface defects, variations in radius show the strongest distortion. The degree of influence from surface crack defects correlates directly with their proximity to the conductor. These findings provide critical diagnostic criteria for assessing the insulation performance of basin insulator under damaged conditions. Full article

In direct-current gas-insulated transmission lines (DC GIL), complex heat transfer processes accelerate surface charge accumulation on insulators, causing local electric field distortion and elevating the risk of surface flashover. This study develops a three-dimensional multi-physics coupled mathematical model for ±200 kV DC GIL basin-type insulators. The bulk and surface conductivity of insulator materials were experimentally measured under varying temperature and electric field conditions, with fitting equations derived to describe their behavior. The model investigates surface charge accumulation and electric field distribution under DC voltage and polarity-reversal conditions, incorporating multi-field coupling effects. Results show that, at a 3150 A current in a horizontally arranged DC GIL, insulator temperatures reach approximately 62.8 °C near the conductor and 32 °C near the enclosure, with the convex surface exhibiting higher temperatures than the concave surface and distinct radial variations. Under DC voltage, surface charge accumulates faster in high-temperature regions, with both charge and electric field distributions stabilizing after approximately 300 h, following significant changes within the first 40 h. Following stabilization, the distribution of surface charge and electric field varies across different radial directions. During polarity reversal, residual surface charges cause electric field distortion, increasing maximum field strength by 13.6% and 47.2% on the convex and concave surfaces, respectively, with greater distortion on the concave surface, as calculated from finite element simulations with a numerical accuracy of ±0.5% based on mesh convergence and solver tolerance. These findings offer valuable insights for enhancing DC GIL insulation performance. Full article

Deformation monitoring of Gas-Insulated Transmission Lines (GILs) is critical for the early detection of structural issues and for ensuring safe power transmission. In this study, we introduce a rapid monocular measurement method that leverages deep learning for real-time monitoring. A YOLOv10 model is developed for automatically identifying regions of interest (ROIs) that may exhibit deformations. Within these ROIs, grayscale data is used to dynamically set thresholds for FAST corner detection, while the Shi–Tomasi algorithm filters redundant corners to extract unique feature points for precise tracking. Subsequent subpixel refinement further enhances measurement accuracy. To correct image tilt, ArUco markers are employed for geometric correction and to compute a scaling factor based on their known edge lengths, thereby reducing errors caused by non-perpendicular camera angles. Simulated experiments validate our approach, demonstrating that combining refined ArUco marker coordinates with manually annotated features significantly improves detection accuracy. Our method achieves a mean absolute error of no more than 1.337 mm and a processing speed of approximately 0.024 s per frame, meeting the precision and efficiency requirements for GIL deformation monitoring. This integrated approach offers a robust solution for long-term, real-time monitoring of GIL deformations, with promising potential for practical applications in power transmission systems. Full article

The advanced Gas Insulated Switchgear/Gas Insulated Lines (GIS/GIL) transmission equipment serves as an essential physical infrastructure for establishing a new energy power system. An analysis spanning nearly a decade on faults arising from extra/ultra-high voltage discharges reveals that over 60% of such faults are attributed to the discharge of metal particles and dust. While existing technical means, such as ultra-high frequency and ultrasonic sensing, exhibit effectiveness in online monitoring of particles larger than sub-millimeter dimensions, the inherent randomness and elusive nature of micron-nano dust pose challenges for effective characterization through current technology. This elusive micron-nano dust, likely concealed as a latent threat, necessitates special attention due to its potential as a “safety killer”. To address the challenges associated with detecting micron-nano dust and comprehending its intricate mechanisms, this paper introduces a micron-nano dust adsorption experimental platform tailored for observation and practical application in GIS/GIL operations. The findings highlight that micron-nano dust’s adsorption state in the electric field predominantly involves agglomerative adsorption along the insulator surface and diffusive adsorption along the direction of the ground electrode. The pivotal factors influencing dust movement include the micron-nano dust’s initial position, mass, material composition, and applied voltage. Further elucidation emphasizes the potential of micron-nano dust as a concealed safety hazard. The study reveals specific physical phenomena during the adsorption process. Agglomerative adsorption results in micron-nano dust speckles forming on the epoxy resin insulator’s surface. With increasing voltage, these speckles undergo an “explosion”, forming an annular dust halo with deepening contours. This phenomenon, distinct from the initial adsorption, is considered a contributing factor to flashovers along the insulator’s surface. The physical mechanism behind flashovers triggered by micron-nano dust is uncovered, highlighting the formation of a localized short circuit area and intense electric field distortion constituted by dust speckles. These findings establish a theoretical foundation and technical support for enhancing the safe operational performance of AC and DC transmission pipelines’ insulation. Full article

The overhead gas-insulated transmission line (GIL) in ultra-high-voltage converter stations, distinct from traditional buried pipelines, demands a thorough investigation into its seismic behavior due to limitations in existing codes. A refined finite element model is established, considering internal structure, slip between various parts, and the relative displacement at the internal conductor joint. Seismic analysis reveals the vulnerability of the GIL at the corner of the pipeline height change, with two failure modes: housing strength failure and internal conductor displacement exceeding the limit. Furthermore, the acceleration amplification coefficient of the support generally exceeds 2.0. Two retrofit methods, namely increasing the fundamental frequency of all supports and fixing the connections between all supports and the housing, have been proposed. The results indicate the effectiveness of both methods in reducing the relative displacement. Fixing all the supports effectively reduces the stress, whereas the other one yields the opposite effect. The seismic performance of a GIL is determined not by the dynamic amplification of supports, but by the control of relative displacement between critical sections, specifically influenced by the angular deformation of the pipeline’s first-order translational vibration mode along the line direction. Seismic vulnerability analysis reveals a reduction of over 50% in the failure probability of the GIL after the retrofit compared to before the retrofit, with the PGA exceeding 0.4 g. Full article

Gas-insulated power transmission lines (GILs) can replace cables and overhead transmission lines, playing an important role in DC transmission systems. However, the influence of surface charge accumulation on insulation reliability cannot be ignored as the operational voltage of the DC GIL increases. In this paper, the measurement methods for the insulator surface potential are summarized, including, dust maps, the Pockels effect method, and the electrostatic probe method. Then, a typical surface charge inversion algorithm is introduced. The main influencing factors of surface charge accumulation are analyzed, such as the applied voltage, insulation gas, insulator shape, and temperature. The charge accumulation pathway is revealed. Furthermore, methods for inhibiting the accumulation of surface charges and promoting the dissipation of accumulated charges are introduced to reduce the surface charges on insulators. Finally, the development direction of DC GIL insulators is predicted. We anticipate that the online monitoring of surface charge distribution, clarifying the percentage of charge accumulation pathways, and optimizing the insulator casting process will be the research directions for the insulator surface charge topic in the future. This article provides a comprehensive understanding of the surface charges of GIL insulators and a reference for the insulation design of DC GILs. Full article

Air gap defects inside a spacer reduce its insulation performance, resulting in stress concentration, partial discharge, and even flashover. If such gap defects are located at the interface between the insulation and conductor, a decrease in mechanical stress may occur. In this work, a finite element method-based simulation model is developed to analyze the influence of gap defects on the electrical and mechanical properties of a ±320 kV direct current gas insulated line (DC GIL) spacer. Present findings reveal that a radially distributed air gap produces a more significant effect on the electric field distribution, and an electric field strength 1.7 times greater than that of the maximum surface value is observed at the air gap. The axial distribution dominates the distortion of the surface stress by generating a stress concentration region in which the maximum stress of the air gap is twice the pressure in the surrounding area. Full article

Accidents always occur in gas-insulated switchgears (GIS) and gas-insulated lines (GIL) since filmed joint electrodes are produced when internal gases react with the electrode’s surface when there is a discharge or when internal electricals overheat. To solve the problem, this paper analyzed the evolution of elements on the contact electrode. The reaction of the SF6 and electrode’s surface under breakdown currents and overheating conditions was obtained, and the discharge time and discharge current effects upon the transfer of the element were proposed. It was found that the mobility of the F element on the electrode’s surface typically increases after electrical heating. The number of interruptions and short-circuit currents are important factors affecting the transfer of the F element to the electrode. The flashover current is the essential factor that accelerates the transfer of the F element to insulating materials. Frequent switching is a main factor that accelerates the transfer of the F element to the contact. It was also found that Al has little correlations with the breaking process, and metal fluorides become the main components on the electrode’s surface under discharge heating. The research provides a theoretical basis and data support for GIS/GIL surface optimization treatments and the improvement of fault detection methods. Full article

Metal particle contamination is an important reason for insulation failure of gas-insulated transmission lines (GILs). Particle trap is the common method for particle suppression. At present, research on the motion characteristics of metal particles near a particle trap and the optimization of trap parameters under AC voltage is insufficient. Based on that, firstly, a dynamic model of metal particles under AC voltage was established, and the motion characteristics of particles in front of the trap were studied, combined with experiments. Then, the influence of trap parameters on the capture effect was analyzed, and the optimization of the trap was realized by simulation. The results showed that, under AC voltage, the randomness of metal particle movement was strong, and the activity was low. The particles mainly moved away from the trap. Among the particles moving towards the trap, some stayed in front of the trap, and some fell into the trap from above. The thickness and height of the trap were the key parameters affecting the capture effect, and with the increase in height and thickness, the capture rate showed a trend of increasing first and then decreasing. The above conclusions can provide a reference for the optimization of a metal particle trap under AC voltage in engineering. Full article

Epoxy insulators are widely used in Gas-Insulated Transmission Lines (GILs), playing a significant role in electrical insulation and mechanical support. The metal particles generated during the production and operation of the equipment aggravate surface charge accumulation on the insulator, causing surface flashover. Therefore, it is necessary to study the suppression strategy of charge accumulation. In this paper, a downsized disc insulator was taken as the research object to investigate the effect of zoning coating on charge suppression with the presence of a linear aluminum metal particle under negative DC voltage. The zoning coating method was achieved by painting coatings with different conductivities in three areas on the insulator surface to regulate the charge. The inhibition mechanism of zoning coating on the charge accumulation in the presence of a linear metal particle was analyzed with the assistance of numerical simulation. The results showed that negative charges were accumulated in the nonplanar region as there was no metal particle, and the existence of metal particles led to the significant accumulation of positive charge speckles in the nonplanar region. The application of zoning coating could significantly inhibit the charge accumulation in the nonplanar area of the insulator and the charge injection from the grounded electrode to reduce the charge density. Under −25 kV, the maximum charge density on the insulator with the zoning coating was 48.1% lower than that without the coating, and the inhibition effect increased by 57.9% when the metal particle was introduced. This paper provides a new way to suppress the charge accumulation on the insulator surface. Full article
