This paper presents the research, development, and functional validation of an original rear suspension system designed for hybrid reverse trike vehicles (two guided wheels on the front axle and a twin-tire-driven assembly at the rear). Conventional configurations featuring a single rear wheel exhibit severe limitations regarding lateral stability under critical dynamic regimes and induce roll-induced torsional loading in flexible chain drives. The proposed solution utilizes a twin-tire rear assembly integrated into an articulated suspension mechanism with two degrees of freedom (2 DoF), which reconfigures the geometric stability polygon from a triangle into an isosceles trapezoid. A mathematical model based on tire dynamics and tire slip phenomena demonstrates that introducing a controlled roll stiffness on the rear axle stabilizes the slip angles, ensuring a neutral and predictable steering behavior. Structural validation via finite element analysis (FEA) performed in SOLIDWORKS Simulation on the entire assembly under a conservative combined load scenario (2400 N vertical force shared by the two wheel bearings, 2400 N lateral force, and 1200 N tractive force) indicated a minimum factor of safety of 1.26 on S275N structural steel, confirmed by an eleven-run mesh independence study. Finally, the system’s functionality was experimentally confirmed through the manufacturing and road testing of a full-scale (1:1) demonstrator vehicle powered by an 1129 cc Boxer engine, highlighting a measurable increase in rollover resistance and trouble-free operation of the two-stage chain drive throughout the test program. A numerical evaluation shows that for rear-biased vehicles of the category the proposed axle raises the rollover-related lateral acceleration threshold by up to 54% and replaces the strongly oversteering balance of the single-wheel layout with a near-neutral, tunable one. Full article

This paper presents an iterative graph-analytical procedure for determining the roll center height, one of the most critical design parameters influencing vehicle dynamic behavior during cornering. The conventional approaches generally determine roll center locations from suspension kinematics and then evaluate vehicle behavior using multibody or numerical vehicle dynamics models. By contrast, the proposed method is intended for the preliminary design stage and provides a direct correlation between front and rear target roll center heights using tire test data, load transfer and axle-level equilibrium conditions. The main advantage of the method is that it helps define a feasible design space before detailed geometry optimization or MBD validation is performed. The objective is to achieve stable and neutral handling (avoiding intrinsic understeer or oversteer tendencies) during steady-state cornering at a predefined target lateral acceleration. The methodology integrates (i) lateral force equilibrium at the axle level, (ii) a dynamic load transfer model based on axle roll stiffness and roll center heights, and (iii) experimental tire grip characteristics (lateral force–slip angle curves under varying vertical loads), processed through numerical interpolation. The procedure is demonstrated using a vehicle model with specific geometric and mass parameters. The results indicate that the methodology does not yield a single unique solution, but rather a set of correlated roll center heights, allowing the designer to select the most feasible geometric configuration while maintaining neutral handling. As an example, the paper presents a convergent solution for the front and rear roll center heights that satisfy neutrality conditions at a slip angle of approximately 4°. This study provides a fundamental framework for the geometric design of suspension systems and serves as a basis for subsequent numerical and experimental validation. Full article

Accurate estimation of axle torque is essential for performance evaluation and energy management of electric tractors. However, direct torque measurement and access to motor controller data are often limited in commercial platforms. This study proposes a machine learning-based framework for predicting axle torque in a commercial electric tractor using field-measured sensor signals. The framework incorporates a horizon-aware architecture to capture the temporal dependencies of dynamic load fluctuations. Field experiments were conducted during plow tillage operation under multiple gear–speed combinations. Several machine learning models (multiple linear regression, multilayer perceptron, and CatBoost) were evaluated for axle torque prediction. The results showed that rear axle torque exhibited a stronger relationship with traction demand under two-wheel-drive operation, resulting in higher prediction accuracy than front axle torque. Among the evaluated models, CatBoost achieved the best overall performance, with an $R^2$ of 0.83 and an RMSE of 189.35 Nm for the rear axle prediction. The proposed framework enables real-time axle torque estimation using commonly available sensor signals and provides a practical alternative to direct torque measurement for onboard load monitoring and energy management in electric tractor systems. Full article

This study investigates the structural performance of a lightweight frame for electrically power-assisted cycles (EPACs) subjected to a variable loading at the front axle, in accordance with the reference standard. A finite element model was developed to evaluate the stress distribution in the frame and was validated through experimental testing using uniaxial strain gauges. Finite element and experimental stress values showed good agreement, confirming the reliability of the model in predicting the global structural response. Experimental results and fatigue considerations based on finite element results indicate that the frame strength is largely verified under the prescribed loading condition. The validated model therefore provides a robust tool for supporting the design and optimization of EPAC frames. Full article

Mining articulated vehicles (MAVs) are widely used as primary transportation equipment in both underground and open-pit mines. These include various machines such as Load–Haul–Dump machines and mining trucks. Path tracking control for MAVs has been an important research topic. Most current research focuses on path tracking control during forward driving. However, there are relatively limited studies on reverse path tracking control. Reversing plays a crucial role in the operation of MAVs. Nevertheless, existing methods typically use the center of the front axle as the control point; therefore, the positioning system is usually installed at the front axle. In practice, however, this means the positioning system is actually located at the rear axle during reverse operations. While it is theoretically possible to infer the position and orientation of the front axle from the rear axle, a strong nonlinear relationship exists between the motion states of the front and rear axles, which introduces significant errors in the system. As a result, these existing methods are not suitable for reverse driving conditions. To address this issue, this paper proposes a nonlinear model predictive control (NMPC) method for path tracking during mining-articulated vehicle (MAV) reverse operations. This method innovatively reconstructs the reverse-motion model by selecting the center of the rear axle as the control point, effectively addressing the instability issues encountered in traditional control methods during reverse maneuvers without requiring additional positioning devices. A comparative analysis with other control strategies, such as NMPC for forward driving, reverse NMPC using the front axle model, and reverse linear model predictive control (LMPC), reveals that the proposed NMPC method achieves excellent control accuracy. Displacement and heading error amplitudes do not exceed 0.101 m and 0.0372 rad, respectively. The maximum solution time per control period is 0.007 s. In addition, as the complexity of the reverse path increases, it continues to perform excellently. Simulation results show that as the curvature of the U-shaped curve increases, the proposed NMPC method consistently maintains high accuracy under various operational conditions. Full article

In the V-cycle of distributed electric wheel loaders (DEWLs), transport accounts for about 70% of the cycle, making energy saving urgent, while shovel-stage slip limits traction stability. This paper proposes a two-module control framework: (i) a preferred-motor transport strategy that reduces parasitic losses and concentrates operation in high-efficiency regions; and (ii) a load-ratio-based front–rear torque distribution for shoveling that allocates tractive effort according to instantaneous axle vertical loads so that each axle’s torque respects its available adhesion. For observability, we deploy a pre-calibrated lookup-table (LUT) mapping from bucket cylinder pressure to the front-axle load ratio, derived offline from a back-propagation neural network (BP-NN) fit. Tests on a newly developed DEWL show that, compared with dual-motor fixed-ratio control, transport-stage mechanical and electrical power drop by 18–37%, and drive-system efficiency rises by 6–13%. During shoveling, the strategy reduces the peak inter-axle slip from 22–35% to 13–15% and lowers the mean slip to 2.6–5.9%, suppressing sawtooth-like wheel-speed oscillations without sacrificing peak capacity. The method reduces parasitic energy flow, improves traction utilization, and is readily deployable. Full article

The dynamic load caused by vehicle vibration due to an uneven pavement surface is a primary factor affecting the structural performance and service life of asphalt pavement. As the principles of vibration mechanics, in conjunction with the coherence function of the vehicle’s left and right wheels, along with the lag between front and rear wheels, the entire vehicle vibration model for three-axle and four-axle heavy-load vehicles was developed using Simulink software. Through simulation, the root-mean-square value of the dynamic load and the dynamic load coefficient of the vehicle with different pavement roughness grades, speeds, loads, and cornering radii were analyzed. The outcomes demonstrate that a nonlinear rise in the wheel dynamic load occurs when pavement roughness increases. The greater the speed, the greater the impact of pavement roughness on the dynamic load. An increase in vehicle load tends to reduce vehicle vibrations. The interaction between vehicle vibration frequency and road excitation frequency is essential in figuring out the loads, and a negative influence on the pavement structure should be given more attention when the vehicle is driving at low speed. The dynamic load coefficient of the left and right wheels is greatly affected when the vehicle is in a lateral tilt. The findings offer valuable insights for selecting appropriate loads in pavement structure design. By constructing 11 degrees of freedom for a three-axle vehicle and 16 degrees of freedom for a four-axle heavy-duty vehicle model, the dynamic load variation law under different roughness excitation conditions is systematically analyzed. The results can be applied to the selection of vehicle load in asphalt pavement design to make it closer to the actual driving state, which will be helpful for improving accuracy in the design of pavement structure and avoiding early damage to the pavement. Full article

The operational stability of agricultural tractors is directly influenced by the mass distribution between axles, particularly when using mounted implements with variable loads. This study aimed to evaluate how different masses of a mounted sprayer (550 kg, 850 kg, and 1150 kg) and tire inflation pressures (151.7–193.1 kPa) affect the load distribution between axles, tire contact area, center of gravity (CG) displacement, and tractor lead ratio. A 3 × 4 factorial design was adopted with a statistical analysis of key parameters across 12 experimental combinations. The results demonstrated that increasing implement mass significantly shifted the load toward the rear axle, reducing the front axle load by up to 46% and displacing the CG rearward by more than 11 cm, thereby compromising stability. Tire pressure, as well as the interaction between mass and pressure, also exhibited statistically significant influence on load distribution and CG positioning while modulating the tire contact area. The lead ratio increased linearly with mass, exceeding the recommended 5% threshold when the sprayer was at full capacity. These findings indicate that while the implement mass exerts a dominant effect, tire pressure management represents a statistically relevant factor for stability, requiring integrated management that considers the interaction between ballasting and tire inflation to mitigate operational risks. Full article

Research on electric wheel loaders (EWLs) has predominantly focused on battery management, hybrid technologies, and energy recovery. However, the influence of motor types and drivetrains on the drive performance of EWLs has received little attention in previous studies. This case study addresses this gap by examining different EWL configurations and analyzing the drive theory and force requirements by integrating classic vehicle theory with EWL-specific characteristics. The study compares an original EWL, equipped with Permanent Magnet Synchronous Motors (PMSMs) on both the front and rear axles with identical transmission ratios of 22.85, to a modified EWL, which features a Switched Reluctance Motor (SRM) on the front axle and a transmission ratio of 44.05. Walking and shoveling tests were conducted to evaluate performance. The walking test results reveal that, at motor speeds of 200 rpm, 400 rpm, and 600 rpm, energy consumption in R-drive mode is 68.56%, 71.88%, and 74.87% of that in F-drive mode when two PMSMs are used. When an SRM is applied with a transmission ratio of 44.05, these values shift to 73.90%, 70.35%, and 67.72%, respectively. This demonstrates that using the rear motor alone for driving under walking conditions can yield greater energy savings. The shoveling test results indicate that distributing torque according to wheel load reduces rear wheel slippage, and the SRM with a transmission ratio of 44.05 delivers sufficient drive force while operating within a high-efficiency speed range for the EWL. Full article

Increasing urbanisation and growing environmental awareness in society require new and innovative vehicle concepts. In the present work, the design freedoms of additive manufacturing (AM) are used to develop a front-axle wheel suspension for a novel modular vehicle concept. The development of the suspension components is based on a new method using industry-standard load cases for the strength design of the components. To design the chassis components, the available installation space is determined, and a suitable configuration of the chassis components is defined. Furthermore, numerical methods are used to identify the component geometries that are suitable for the force flow. The optimisation setup is selected in such a way that it is possible to integrate information, energy, and material-carrying conductions into the suspension arms. High-strength light metals are used to minimise the component masses. Apertures are provided through the components for the routing of electrical conductors. The transport of fluids is realised by conductions integrated into the wishbones. The final geometries of the suspension components are then validated by a finite element analysis (FEA) of the overall suspension model. The results of the applied method are lightweight suspension components with a high degree of functional integration. This improves the vehicle package and achieves higher front-wheel clearance, increasing the possible steering angles and thus improving manoeuvrability. The saving of unsprung mass can improve handling and has a positive effect on the vehicle’s energy consumption. Furthermore, the sectional conduction integration is followed by a simplified assembly of the front-axle suspension. Full article

As a transitional vehicle between fuel and electric vehicles, hybrid vehicles achieve energy savings and emission reductions without range anxiety. Regenerative braking has a direct impact on the fuel consumption of the whole vehicle; however, the current regenerative braking strategy for commercial vehicles is not yet perfect and has a poor adaptability in terms of working conditions and whole-vehicle load changes. Therefore, this paper proposes a regenerative braking strategy based on the identification of working conditions, by considering the influence of the vehicle load state and driving conditions on braking. Firstly, historical driving data of commercial vehicles were obtained from GPS data, driving conditions were classified using principal component analysis (PCA) and K-means, and a working condition recogniser was constructed using a back propagation neural network (BPNN) optimised with the Coati optimisation algorithm (COA). The recognition accuracy of the COA-BPNN was 7.6% better than that of the BPNN. Secondly, front and rear axle braking force distribution strategies are proposed, according to the braking intensity magnitude and load state under empty-, half-, and full-load conditions. Finally, a genetic algorithm (GA) was used to find the optimal control parameters for each category of working conditions, and the COA-BPNN condition recogniser identified the current category of working conditions needed to retrieve the corresponding optimal control parameters in the offline parameter library. The simulation results under C-WTVC and synthetic conditions show that the energy recovery rate of the proposed strategy in this paper reached up to 69.65%, which is at most 206.3% higher than that of the fixed-ratio strategy and at most 37.4% higher than that of the fuzzy control strategy. Full article

During the operation of a wheel loader, the external load acting on the bucket undergoes many changes, resulting in significant changes in the load ratio on the front and rear axles. For this reason, controlling a standard wheel loader is not trivial. In addition, in the case of a distributed electric wheel loader (DEWL), the operating control algorithm is often complex and is, therefore, the subject of optimization studies. This study compared the electric power consumption across different vertical loads, speeds, and travel directions for single-front, single-rear, and dual-motor configurations, both during transporting and pre-shoveling operations. The analysis led to the development of control rules based on energy-saving objectives. Under the shoveling condition, it was observed that vertical loads can lead to an insufficient driving force and skidding, necessitating the proposal of a new optimized control scheme. The results revealed that the optimal solution for transporting is the single-motor drive control scheme without a mechanical connection between the front and rear motor. With the single-motor control scheme, comparing the preferred controlled motor with the unselected motor under different loads, the average electrical power savings for forward, backward, and circling were at least 3.51%, 3.12%, and 0.34%, respectively. Under the pre-shoveling condition, the optimal control scheme was identified as the single rear motor control scheme, effectively reducing electrical power consumption. In response to the issues encountered during the shoveling condition, an economical solution involving the modification of the front axle transmission ratio has been proposed, along with an optimized control scheme based on vertical load variations. Full article

The electric wheel loader is a new prototype in powertrains and drivetrains that saves energy consumption and diminishes emissions as earthmoving machinery. Dual-motor drive in the front and rear axles of electric wheel loaders helps the distribution of drive torque. However, challenges arise during shoveling conditions, particularly when one motor generates torque exceeding the ground’s adhesion force, leading to tire slippage. This study thoroughly examines the mechanical structure of the working unit and elucidates the correlation between wheel load and hydraulic pressure in the base chamber of the tilt cylinder. This analysis is accomplished through a combination of theoretical derivations and experimental tests. The experiments involve a 5 ton rated load electric wheel loader tested across five running cases as well as weighing tests on a 15 ton rated load electric wheel loader. Based on the experiment discoveries, a dual-motor drive electric wheel loader is designed with specific transmission ratios for the front and rear drivetrains, and a torque distribution strategy is proposed based on wheel load during shoveling. Running condition tests demonstrate sufficient drive force for the new electric wheel loader, and shoveling tests reveal a significant reduction in tire slippage when employing the proposed torque distribution strategy compared to evenly distributed torque in the front and rear axles. Moreover, the driving force during the shoveling process remains undiminished. This indicates that the newly designed loader, in conjunction with the proposed strategy, exhibits excellent shoveling efficiency. Full article

To elucidate the vibrational characteristics of power chassis in paddy fields, we examined the Yanmar VPG6G rice transplanter across diverse terrains, including paddy fields, dry land, and concrete roads. Vibrational acceleration measurements, taken in longitudinal, transverse, and vertical orientations at key chassis locations, revealed noteworthy findings. The Mizuta power chassis exhibited its lowest root-mean-square (RMS) vibrational acceleration on concrete, while the highest was observed on paddy fields. The acceleration power spectra predominantly peaked between 1~14 Hz, with peak values amplifying as speed increased. Additionally, pendant orientation frequencies exceeded those of longitudinal and lateral directions. Both front and rear wheels mirrored the vibrational accelerations of the rear axle, but dynamic load coefficients for the front wheels consistently surpassed the rear, particularly at elevated speeds. This research not only enhances our understanding of terrain-induced vibrations and the intricate dynamics between terrain and tires but also lays the groundwork for designing optimized vibration-damping solutions tailored to prevalent road conditions. Full article

Tractors transporting heavy hitches tend to tilt severely, resulting in significant dynamic loads on the front axle and affecting handling stability. Tractors and rear hitches can be considered vibration systems with two coupled masses. Thus, active damping control strategies between tractors and rear hitches are proposed in this study. The complexity and versatility of tractor hydraulic hitching during tractor transit transport are considered. A method of improving the tractor hydraulic hitch damping ratio with pressure feedback is proposed. The dynamic characteristics of the pressure feedback hydraulic hitch system are analyzed. A dynamic model of the tractor transfer transport unit is established, and a numerical simulation is carried out to verify the effectiveness of the proposed hydraulic hitch vibration reduction control strategy based on pressure feedback. A real test platform for tractor vibration reduction control is built. The test results show that the pressure feedback vibration reduction control method proposed in this paper affects tractor pitching motion suppression. In addition, the proposed control strategy does not require a force pin sensor. Tractor hydraulic hitch damping control costs are reduced. The vibration reduction control strategy proposed in this study has high reliability and can be used as a reference for non-road-vehicle vibration reduction control. Full article
