Search Results (16)

This paper examines how the fractional Fourier transform (FrFT) can be used to form and analyze acoustic holograms produced by a moving, linear, frequency-modulated (LFM) source in a shallow water waveguide. In these environments, the source sound field creates an interference pattern, referred to as a two-dimensional interferogram, which represents the distribution of acoustic intensity in the frequency–time domain. This interferogram consists of parallel interference fringes. Consequently, focal points are formed and aligned along a straight line in the source hologram, which is represented by the two-dimensional Fourier transform of the interferogram. We have developed a holographic method for constructing the interferogram of an LFM source signal and transforming it into a Fourier hologram based on FrFT in the presence of strong noise. A key finding of this study is that the FrFT-based holographic method enables localized focal regions to emerge from modal interference even under high-intensity noise conditions. The positions of these focal spots are directly related to the source parameters, enabling the estimation of key characteristics such as the distance and velocity of the LFM source. We analyzed the effectiveness of the FrFT-based holographic method through numerical experiments in the 100–150 Hz frequency band. The results demonstrate the method’s high noise immunity for source localization in realistic shallow water environments under strong noise. Full article

In this paper, to counteract the sensitivity of the traditional Hough transform to noise and the fluctuations in parameter estimation, we propose a hyperbolic warping transform that integrates all interference fringes in the time–frequency domain to accurately estimate the motion parameters of a single hydrophone. This method can accurately estimate the target motion parameters, including the time of closest point of approach ($t_{CPA}$), the ratio of the nearest distance to the speed ($b=r_{CPA}/v$), and the waveguide invariant ($\beta$). The two algorithms are compared by simulation and sea trial experiments. Hyperbola-warping improves the noise immunity performance by 10 dB in simulation experiments, increases the detection range by 20% in sea trial experiments, and demonstrates that the method proposed in this paper has better noise resistance and practicality. Full article

Fringe projection profilometry (FPP) is widely used for high-accuracy 3D imaging. However, employing multiple sets of fringe patterns ensures 3D reconstruction accuracy while inevitably constraining the measurement speed. Conventional dual-frequency FPP reduces the number of fringe patterns for one reconstruction to six or fewer, but the highest period-number of fringe patterns generally is limited because of phase errors. Deep learning makes depth estimation from fringe images possible. Inspired by unsupervised monocular depth estimation, this paper proposes a novel, weakly supervised method of depth estimation for single-camera FPP. The trained network can estimate the depth from three frames of 64-period fringe images. The proposed method is more efficient in terms of fringe pattern efficiency by at least 50% compared to conventional FPP. The experimental results show that the method achieves competitive accuracy compared to the supervised method and is significantly superior to the conventional dual-frequency methods. Full article

In this study, repeat-pass synthetic aperture radar interferometry (repeat-pass THz InSAR) is first extended to the terahertz band, and it has tremendous potential in the application of high-resolution three-dimensional (3D) imaging due to its shorter wavelength, larger bandwidth, and greater sensitivity to elevation variation. The super-resolution and high sensitivity of THz InSAR pose greater demands on the baseline calibration for high-precision digital elevation model (DEM) generation. To meet the elevation accuracy requirement of THz InSAR, we propose a baseline calibration method relying on the estimation of the azimuth fringe frequency (EAFF) of the interferometric phase. Initially, a model for non-parallel sampling path errors within the squint SAR repeat-pass interferometry was established, and then, we conducted the theoretical analysis of the phase errors induced by the non-parallel errors. Following this, using a reference DEM, the relationship between the fringe frequency of the error phase and the bias in the repeat-path positioning was established. This allowed the estimation of the position errors to be transformed into the frequency spectrum estimation based on the FFT, which would mitigate the impact of unknown SAR sampling positions. Ultimately, we investigated the accuracy of the proposed EAFF calibration method, and the simulation showed that it can achieve the theoretical accuracy when the correlation coefficient exceeds 0.3. Furthermore, we configured the repeat-pass THz InSAR system with the 0.3 THz stepped-frequency radar. Compared to the conventional calibration based on ground control points (GCPs), the 3D reconstruction of both a knife and a terrain model, calibrated using the proposed EAFF algorithm, demonstrated that the elevation accuracy can achieve millimeter-level precision across the entire image swath. The above results also proved the great potential of THz InSAR in high-precision 3D imaging and remote sensing. Full article

We propose to study the nonlinear stroke and lower-order modal interactions of a clamped–clamped shallow-arch flexible micro-electrode. The flexible electrode is electrically actuated through an in-plane parallel-plates field superimposed over out-of-plane electrostatic fringing fields. The in-plane electrostatic fields result from a difference of potential between the initially curved flexible electrode and a lower stationary parallel-grounded electrode. Moreover, the out-of-plane fringing fields are mainly due to the out-of-plane asymmetry of the flexible shallow arch and two respective surrounding stationary side electrodes (left and right). A nonlinear beam model is first introduced, consisting of a nonlinear partial differential equation governing the flexible shallow-arch in-plane deflection. Then, a resultant reduced-order model (ROM) is derived assuming a Galerkin modal decomposition with mode-shapes of a clamped–clamped beam as basis functions. The ROM coupled modal equations are numerically solved to obtain the static deflection. The results indicate the possibility of mono-stable and bi-stable structural behaviors for this particular device, depending on the flexible electrode’s initial rise and the size of its stationary side electrodes. The eigenvalue problem is also derived and examined to estimate the variation of the first three lower natural frequencies of the device when the microbeam is electrostatically actuated. The proposed micro-device is tunable with the possibility of pull-in-free states in addition to modal interactions through linear coupled mode veering and crossover processes. Remarkably, the veering zone between the first and third modes can be electrostatically adjusted and reach $22.6$kHz for a particular set of design parameters. Full article

A microwave absolute distance measurement method with ten-micron-level accuracy and meter-level range based on frequency domain interferometry is proposed and experimentally demonstrated for the first time. Theoretical analysis indicates that an interference phenomenon occurs instantaneously in the frequency domain when combining two homologous broad-spectrum microwave beams with different paths, and the absolute value of the distance difference between the two paths is only inversely proportional to the period of frequency domain interference fringes. The proof-of-principle experiments were performed to prove that the proposed method can achieve absolute distance measurement in the X-band with standard deviations of 15 μm, 17 μm, and 26 μm and within ranges of 1.69 m, 2.69 m, and 3.75 m. Additionally, a displacement resolution of 100 microns was realized. The multi-target recognition performance was also verified in principle. Furthermore, at the expense of a slight decrease in ranging accuracy, a fast distance measurement with the single measurement time of 20 μs was achieved by using a digitizer combined with a Fourier transform analyzer. Compared with the current microwave precision ranging technologies, the proposed method not only has the advantages of high precision, large range, and rapid measurement capability, but the required components are also easily obtainable commercial devices. The proposed method also has better complex engineering applicability, because the ten-micron-level ranging accuracy is achievable only by using a simple Fourier transform without any phase estimation algorithm, which greatly reduces the requirement for signal-to-noise ratio. Full article

Laser interferometers that operate over a dynamic range exceeding one wavelength are used as compact displacement sensors for gravitational wave detectors and inertial sensors and in a variety of other high-precision applications. A number of approaches are available to extract the phase from such interferometers by implementing so-called phasemeters, algorithms to provide a linearised phase estimate. While many noise sources have to be considered for any given scheme, they are fundamentally limited by additive noise in the readout, such as electronic readout, digitisation, and shot-noise, which manifest as an effective, white phase noise in the phasemeter output. We calculated and compared the Cramer–Rao lower bound for phasemeters of some state-of-the-art two-beam interferometer schemes and derived their noise limitations for sub-fringe operation and for multi-fringe readout schemes. From this, we derived achievable noise performance levels for one of these interferometer techniques, deep-frequency modulation interferometry. We then applied our analysis to optical resonators and show that frequency scanning techniques can in theory benefit from such resonant enhancement, indicating that the sensitivities can be improved in future sensors. Full article

Harvesting energy from the fringing electric field of power lines is a topic of recent interest. So far, most of the reported energy harvesting processes used a fixed ground connection that makes the harvesting process immobile. This paper presents a new idea to avoid the fixed ground connection and make the extraction process mobile, which can lead to charging of wearable and mobile devices, reducing the frequency of battery charging and enhancing the longevity of the batteries. A comprehensive circuit model for the energy extraction system is still absent, and this research proposes a circuit model that forms a basis for the circuit design and prediction of the energy extraction efficacy. The circuit model provides the analytical basis to estimate charging time, optimum operating voltage and optimum power for such circuits. Experimental results are also presented to justify the circuit model. Although the actual amount of power extracted was very small, further research is needed to enhance the energy extraction efficacy. Full article

In this paper, a method based on the inherent event-based sampling capability of laser optical feedback interferometry (OFI) is proposed to assess the optical feedback factor C when the laser operates in the moderate and strong feedback regimes. Most of the phase unwrapping open-loop OFI algorithms rely on the estimation of C to retrieve the displacement with nanometric precision. Here, the proposed method operates in open-loop configuration and relies only on OFI’s fringe detection, thereby improving its robustness and ease of use. The proposed method is able to estimate C with a precision of <5%. The obtained performances are compared to three different approaches previously published and the impacts of phase noise and sampling frequency are reported. We also show that this method can assess C on the fly even when C is varying due to speckle. To the best of the authors’ knowledge, these are the first reported results of time-varying C estimation. In addition, through C estimation over time, it could pave the way not only to higher performance phase unwrapping algorithms but also to a better control of the optical feedback level via the use of an adaptive lens and thus to better displacement retrieval performances. Full article

This paper introduces a method for the range localization of a moving ship based on the vertical hydrophone line array. The main implementation steps of the proposed algorithm are as follows. First, the stable low-frequency line spectrum component of the broadband radiated noise from the moving ship was extracted through the Detection of Envelope Modulation on Noise (DEMON) spectrum analysis method. Second, the pressure difference between the two different ranges was derived, and the corresponding interference fringes were observed in the plane of time and time interval. Then, the radial velocity of the moving ship could be obtained based on the period of the pattern oscillations of the interference fringes. Further, we estimated the time and range information of the Closest Point of Approach (CPA) and computed the ship range versus time. Finally, each element of the vertical hydrophone line array was processed by the method proposed above, and data fusion technology was adopted to reduce the impact of ineffective elements and improve the range estimation accuracy. The results of the simulation and experiment of a 16-element vertical array performed in the South China Sea verified the effectiveness of the algorithm. Full article

In this paper, the synthesis and characterization of CuIn_1−xGa_xSe₂ (0 ≤ x ≤ 1) nanocrystals are reported with the influences of x value on the structural, morphological, and optical properties of the nanocrystals. The X-ray diffraction (XRD) results showed that the nanocrystals were of chalcopyrite structure with particle size in the range of 11.5–17.4 nm. Their lattice constants decreased with increasing Ga content. Thus, the x value of the CuIn_1−xGa_xSe₂ nanocrystals was estimated by Vegard’s law. Transmission electron microscopy (TEM) analysis revealed that the average particle size of the nanocrystals agreed with the results of XRD. Well-defined lattice fringes were shown in the TEM images. An analysis of the absorption spectra indicated that the band gap energy of these CuIn_1−xGa_xSe₂ nanocrystals was tuned from 1.11 to 1.72 eV by varying the x value from 0 to 1. The Raman spectra indicated that the A₁ optical vibrational mode of the nanocrystals gradually shifted to higher wavenumber with increasing x value. A simple theoretical equation for the A₁ mode frequency was proposed. The plot of this equation showed the same trend as the experimental data. Full article

Fringing reefs have significant impacts on beach dynamics, yet there is little research on how they should be considered in beach nourishment design, monitoring, and conservation works. Thus, the behavior and characteristics of nourishment projects at two reef protected beaches, Royal Hawaiian Beach (RHB) in Hawaii, USA, and Victoria Beach (VB) in Cadiz, Spain, are compared to provide transferable information for future nourishment projects and monitoring in fringing reef environments. The nourishment cost at RHB was nine times higher than VB. This is partly due to lower total volume and a more complex placement and spreading method at RHB, despite the much closer borrow site at RHB. There was a significant difference in post-nourishment monitoring frequency and assessment of accuracy. RHB elevation was monitored quarterly for 2.7 years at 30 m-spaced profiles, compared to 5 years of biannual surveys of 50 m-spacing at VB. An additional problem related to the presence of reefs at both RHB and VB was estimating the beach volume increase after nourishment, due to variable definitions of the ‘beach’ area and high alongshore variability in reef topography. At sites where non-native sediment is used, it is imperative to understand how wave and current energy changes due to reefs will influence nourishment longevity. Thus, differences in erosion and accretion mechanisms at both beaches have been detected, though are still little understood. Moreover, discrepancies in sediment porosity between the two sites (which should be surveyed in future nourishments) have been found, probably due to differences in the nourishment sand transportation and distribution methods. In summary, more dialogue is needed to explicitly consider the influence of fringing reefs on coastal processes and beach nourishment projects. Full article

Micro absolute distance measurement (MADM) is widely used in industrial and military fields. To achieve high accuracy and frequency response, a polarized low-coherence interferometry (PLCI)-based method for MADM is proposed. The nearly linear relationship between the envelope center and m-order PLCI fringe (PLCIF) peak center is found and verified. Dispersion compensation is achieved by fringe peak position estimation and polynomial fitting to get rid of the dependence on an a priori model and birefringence parameters, and make this method very robust. Meanwhile, the zero-order PLCIF center is estimated and located to demodulate the measured displacement. Then, the measurement accuracy is raised by polynomial fittings. In comparison to conventional methods, the proposed method can effectively avoid jump errors and has a higher accuracy. Experimental results indicate that the measurement accuracy is higher than 19.51 nm, the resolution is better than 2 nm, and its processing data rate can reach 35 kHz. Full article

Synthetic Aperture Radar Interferometry (SAR, InSAR) is increasingly being used for deformation monitoring. Uncertainty in satellite state vectors is considered to be one of the main sources of errors in applications such as this. In this paper, we present frequency and spatial domain based algorithms to model orbital errors in InSAR interferograms. The main advantage of this method, when applied to the spatial domain, is that the order of the polynomial coefficient is automatically determined according to the features of the orbital errors, using K-cross validation. In the frequency domain, a maximum likelihood fringe rate estimate is deployed to resolve linear orbital patterns in strong noise interferograms, where spatial-domain-based algorithms are unworkable. Both methods were tested and compared with synthetic data and applied to historical Environmental Satellite Advanced Synthetic Aperture Radar (ENVISAT ASAR) sensor and modern instruments such as Gaofen-3 (GF-3) and Sentinel-1. The validation from the simulation demonstrated that an accuracy of ~1mm can be obtained under optimal conditions. Using an independent GPS measurement that is discontinuous from the InSAR measurement over the Tohoku-Oki area, we found a 31.45% and 73.22% reduction in uncertainty after applying our method for ASAR tracks 347 and 74, respectively. Full article

The quality of an interferogram, which is limited by various phase noise, will greatly affect the further processes of InSAR, such as phase unwrapping. Interferometric SAR (InSAR) geophysical measurements’, such as height or displacement, phase filtering is therefore an essential step. In this work, an improved Goldstein interferogram filter is proposed to suppress the phase noise while preserving the fringe edges. First, the proposed adaptive filter step, performed before frequency estimation, is employed to improve the estimation accuracy. Subsequently, to preserve the fringe characteristics, the estimated fringe frequency in each fixed filtering patch is removed from the original noisy phase. Then, the residual phase is smoothed based on the modified Goldstein filter with its parameter alpha dependent on both the coherence map and the residual phase frequency. Finally, the filtered residual phase and the removed fringe frequency are combined to generate the filtered interferogram, with the loss of signal minimized while reducing the noise level. The effectiveness of the proposed method is verified by experimental results based on both simulated and real data. Full article
