Tesla valves have emerged as promising passive flow-regulation devices for sustainable water systems because they provide directional flow control without moving parts, external energy input, or complex maintenance requirements. This review systematically examines the fundamental mechanisms, structural evolution, and engineering applications of Tesla valves in water-related systems. The underlying rectification behavior is analyzed from the perspectives of flow separation, recirculation, jet interaction, vortex evolution, and mechanism switching under varying hydraulic conditions. Recent advances in geometric optimization, multistage configurations, three-dimensional architectures, topology optimization, and data-driven design approaches are summarized to illustrate the transition from classical Tesla geometries to next-generation passive flow-control structures. Current applications in microfluidic systems, water-quality monitoring, thermo-hydraulic devices, pressure-regulation networks, and hydraulic safety enhancement are critically reviewed. The analysis indicates that Tesla-valve performance is governed by coupled interactions among geometry, flow regime, fluid properties, and operating conditions, while multifunctional designs increasingly integrate flow regulation, mixing enhancement, heat transfer, and pressure management. Finally, key challenges related to performance standardization, realistic operating conditions, manufacturability, and system-level integration are discussed. Tesla valves are expected to play an increasingly important role in intelligent and energy-efficient water infrastructure, supporting the development of next-generation sustainable water and fluid-management systems. Full article

The Tesla valve is a fluidic diode that enables unidirectional flow while impeding the reverse flow without the assistance of any moving parts. Conventional Tesla valves share a distinctive feature of a bifurcated section that connects the inlet and outlet. This study uses computational fluid dynamic (CFD) simulations to analyze the importance of the bifurcated design to the efficiency of the Tesla valve, quantified by diodicity. Simulations over the range of the Reynolds number, Re = 50–2000, are performed for three designs: the T45-R, D-valve, and GMF valve, each with two versions with and without the bifurcated section. For the T45-R valve, removing the bifurcated section leads to a consistent increase in diodicity, particularly at high Re. In contrast, the diodicity of the GMF valve drops significantly when the bifurcated section is removed. The D-valve exhibits a mixed behavior. Without the bifurcated section, its diodicity is suppressed at low Re but begins to increase for Re > 1100, eventually matching the diodicity of the bifurcated version at Re = 2000. The results highlight the intricate relationship between valve geometry and efficiency of Tesla-type valves and the dependence of this relationship on the Reynolds number. Full article

The performed research presents modeling results for designing microfluidic vortex diodes. These devices rectify fluid flow and can be used in many applications on micro and macro scales. The modeling, utilizing computational fluid dynamics (CFD) with the turbulence model RANS k-ε in COMSOL Multiphysics, has led to optimizing diodicity—the reversed-to-forward flow pressure drop ratio. The goal was to find the best flow-rectifying geometry within the 2D vortex-type design by changing the wall geometry, diode shape, and inflow velocities, identifying significant parameters and dependencies. Improving diodicity can be achieved by increasing the radius r₁ of the central channel, increasing the entire diode radius r₂, decreasing the width w of the rectangular channel, and reducing its length L. Additionally, changing the circular shape of the diode to an elliptical one can improve diodicity. The significance of this research is evident in the potential applications of these devices in microfluidic setups where fixed-geometry unidirectional flow is required, e.g., mixing, filtration, cell separation, and drug delivery, or on industrial scales, e.g., energy harvesting, wastewater treatment, and water sterilization. Full article

In order to investigate an efficient water control method suitable for the bottom water occurring during the production process of horizontal wells in bottom water reservoirs, the characteristic curves of a Fluidic Diode AICD (Automatic Inflow Control Device) were tested, and a mathematical modeling method is proposed. First, the working principle of a Fluidic Diode AICD was analyzed; subsequently, a Fluidic Diode AICD test platform was designed and built independently, and pressure test experiments of the Fluidic Diode AICD under different flow conditions were carried out to obtain characteristic curves of the Fluidic Diode AICD. Finally, a mathematical model of the flow–pressure drop characteristic curves of the Fluidic Diode AICD was developed and applied to the simulation of water control production in horizontal wells in bottom water reservoirs. The results of the study showed that the Fluidic Diode AICD produces a more significant pressure drop under high water content conditions, and has a better oil and water stabilization function in production. In this study, the reservoir flow, annulus flow, AICD flow, and horizontal wellbore flow are considered, and an integrated coupling model for horizontal wells in bottom water reservoirs is established. This study provides a basis for using Fluidic Diode AICDs in horizontal wells in bottom water reservoirs. Full article

In this work, we present a compact micro-opto-fluidic sensing platform for the measurement of volumetric refractive index (RI) variations of ultra-low volumes of fluids with respect to a reference liquid. In the instrumental configuration, we employed a disposable plastic micro-channel, which was customized with integrated back and front aluminum reflectors, deposited by sputtering. The presence of the double metallization is exploited to create a zigzag guiding path for the radiation provided by a semiconductor laser diode, so that light crosses the fluid under test multiple times before reaching a 1-D Position Sensitive Detector (PSD). According to Snell law, when fluids with different RI indices fill the channel, the radiation is deflected at different angles and the output beam shifts along the channel surface. RI variations are monitored by measuring the position of the output light spot on the surface of the PSD. To validate the results, a theoretical model based on ray optics was developed to study the propagation of the radiation travelling through the fluidic channel. Experimental results showed a beam displacement per RI unit up to 3234 μm/RIU, in agreement with the prediction of the analytical model. The proposed sensing method is label-free, contactless, non-invasive, and biologically safe. Moreover, the micro-opto-fluidic sensing platform could be exploited in a wide range of applications, ranging from biology to medicine to the agri-food industry. Full article

Formaldehyde (HCHO), a chemical compound used in the fabrication process of a broad range of household products, is present indoors as an airborne pollutant due to its high volatility caused by its low boiling point ( $T=-19$ °C). Miniaturization of analytical systems towards palm-held devices has the potential to provide more efficient and more sensitive tools for real-time monitoring of this hazardous air pollutant. This work presents the initial steps and results of the prototyping process towards on-chip integration of HCHO sensing, based on the Hantzsch reaction coupled to the fluorescence optical sensing methodology. This challenge was divided into two individually addressed problems: (1) efficient airborne HCHO trapping into a microfluidic context and (2) 3,5–diacetyl-1,4-dihydrolutidine (DDL) molecular sensing in low interrogation volumes. Part (2) was addressed in this paper by proposing, fabricating, and testing a fluorescence detection system based on an ultra-low light Complementary metal-oxide-semiconductor (CMOS) image sensor. Two three-layer fluidic cell configurations (quartz–SU-8–quartz and silicon–SU-8–quartz) were tested, with both possessing a 3.5 µL interrogation volume. Finally, the CMOS-based fluorescence system proved the capability to detect an initial 10 µg/L formaldehyde concentration fully derivatized into DDL for both the quartz and silicon fluidic cells, but with a higher signal-to-noise ratio (SNR) for the silicon fluidic cell ( $SN{R}_{silicon}=6.1$ ) when compared to the quartz fluidic cell ( $SN{R}_{quartz}=4.9$ ). The signal intensity enhancement in the silicon fluidic cell was mainly due to the silicon absorption coefficient at the excitation wavelength, $a\left({\lambda }_{abs}=420 \mathrm{nm}\right)=5\times {10}^4{\mathrm{cm}}^{-1}$ , which is approximately five times higher than the absorption coefficient at the fluorescence emission wavelength, $a\left({\lambda }_{em}=515 \mathrm{nm}\right)=9.25\times {10}^3{\mathrm{cm}}^{-1}$ . Full article

A simple deep-ultraviolet (UV) absorption spectrophotometer based on ultraviolet light-emitting diode (UV LED) was developed for the detection of air-borne toluene with a good sensitivity. A fiber-coupled deep UV-LED was employed as a light source, and a spectrometer was used as a detector with a gas cell in between. 3D printed opto-fluidics connectors were designed to integrate the gas flow with UV light. Two types of hollow core waveguides (HCW) were tested as gas cells: a glass capillary tube with aluminum-coated inner walls and an aluminum capillary tube. The setup was tested for different toluene concentrations (10–100 ppm), and a linear relationship was observed with sensitivities of 0.20 mA·U/ppm and 0.32 mA·U/ppm for the glass and aluminum HCWs, respectively. The corresponding limits of detection were found to be 8.1 ppm and 12.4 ppm, respectively. Full article

A novel optofluidic sensor that measures the local pressure of the fluid inside a microfluidic channel is presented. It can be integrated directly on-channel and requires no additional layers in fabrication. The detection can be accomplished at a single wavelength; and thereby, only a single laser diode and a single photodetector are required. This renders the sensor to be compact, cheap and easy to fabricate. Basically, the sensor consisted of a Fabry–Pérot microresonator enclosing the fluidic channel. A novel structure of the Fabry–Pérot was employed to achieve high-quality factor, that was essential to facilitate the single wavelength detection. The enhanced performance was attributed to the curved mirrors and cylindrical lenses used to avoid light diffraction loss. The presented sensor was fabricated and tested with deionized water liquid and shown to exhibit a sensitivity up to 12.46 dBm/bar, and a detection limit of 8.2 mbar. Numerical simulations are also presented to evaluate the mechanical–fluidic performance of the device. Full article

The notion of surface plasmon resonance (SPR) sensor research emerged more than eight decades ago from the first observed phenomena in 1902 until the first introduced principles for gas sensing and biosensing in 1983. The sensing platform has been hand-in-hand with the plethora of sensing technology advancement including nanostructuring, optical technology, fluidic technology, and light source technology, which contribute to substantial progress in SPR sensor evolution. Nevertheless, the commercial products of SPR sensors in the market still require high-cost investment, component, and operation, leading to unaffordability for their implementation in a low-cost point of care (PoC) or laboratories. In this article, we present a comprehensive review of SPR sensor development including the state of the art from a perspective of light source technology trends. Based on our review, the trend of SPR sensor configurations, as well as its methodology and optical designs are strongly influenced by the development of light source technology as a critical component. These simultaneously offer new underlying principles of SPR sensor towards miniaturization, portability, and disposability features. The low-cost solid-state light source technology, such as laser diode, light-emitting diode (LED), organic light emitting diode (OLED) and smartphone display have been reported as proof of concept for the future of low-cost SPR sensor platforms. Finally, this review provides a comprehensive overview, particularly for SPR sensor designers, including emerging engineers or experts in this field. Full article

We introduce herein the induced-charge electrokinetic phenomenon to nanometer fluidic systems; the design of the nanofluidic ion diode for field-effect ionic current control of the nanometer dimension is developed by enhancing internal ion concentration polarization through electrochemical transport of inhomogeneous inducing-counterions resulting from double gate terminals mounted on top of a thin dielectric layer, which covers the nanochannel connected to microfluidic reservoirs on both sides. A mathematical model based on the fully-coupled Poisson-Nernst-Plank-Navier-Stokes equations is developed to study the feasibility of this structural configuration causing effective ionic current rectification. The effect of various physiochemical and geometrical parameters, such as the native surface charge density on the nanochannel sidewalls, the number of gate electrodes (GE), the gate voltage magnitude, and the solution conductivity, permittivity, and thickness of the dielectric coating, as well as the size and position of the GE pair of opposite gate polarity, on the resulted rectification performance of the presented nanoscale ionic device is numerically analyzed by using a commercial software package, COMSOL Multiphysics (version 5.2). Three types of electrohydrodynamic flow, including electroosmosis of 1st kind, induced-charge electroosmosis, and electroosmosis of 2nd kind that were originated by the Coulomb force within three distinct charge layers coexist in the micro/nanofluidic hybrid network and are shown to simultaneously influence the output current flux in a complex manner. The rectification factor of a contrast between the ‘on’ and ‘off’ working states can even exceed one thousand-fold in the case of choosing a suitable combination of several key parameters. Our demonstration of field-effect-tunable nanofluidic ion diodes of double external gate electrodes proves invaluable for the construction of a flexible electrokinetic platform for ionic current control and may help transform the field of smart, on-chip, integrated circuits. Full article

Cost-effective pharmaceutical drug discovery depends on increasing assay throughput while reducing reagent needs. To this end, we are developing an ultrasensitive, fluorescence-based platform that incorporates a nano/micro-fluidic chip with an array of closely spaced channels for parallelized optical readout of single-molecule assays. Here we describe the use of direct femtosecond laser machining to fabricate several hundred closely spaced channels on the surfaces of fused silica substrates. The channels are sealed by bonding to a microscope cover slip spin-coated with a thin film of poly(dimethylsiloxane). Single-molecule detection experiments are conducted using a custom-built, wide-field microscope. The array of channels is epi-illuminated by a line-generating red diode laser, resulting in a line focus just a few microns thick across a 500 micron field of view. A dilute aqueous solution of fluorescently labeled biomolecules is loaded into the device and fluorescence is detected with an electron-multiplying CCD camera, allowing acquisition rates up to 7 kHz for each microchannel. Matched digital filtering based on experimental parameters is used to perform an initial, rapid assessment of detected fluorescence. More detailed analysis is obtained through fluorescence correlation spectroscopy. Simulated fluorescence data is shown to agree well with experimental values. Full article

This work presents patterning of thick (10–50 µm) hybrid polymer structures of ORMOCER^® by laser direct writing. ORMOCER^® combine polymer-like fabrication processes with glass-like surface chemistry that is beneficial for many bio-microfluidic applications. ORMOCER^® is liquid before exposure, so patterning is done by contact-free lithography, such as proximity exposure. With laser direct writing, we obtained higher resolution patterns, with smaller radius of curvature (~2–4 µm), compared to proximity exposure (~10–20 µm). Process parameters were studied to find the optimal dose for different exposure conditions and ORMOCER^® layer thicknesses. Two fluidic devices were successfully fabricated: a directional wetting device (fluidic diode) and an electrophoresis chip. The fluidic diode chip operation depends on the sharp corner geometry and water contact angle, and both have been successfully tailored to obtain diodicity. Electrophoresis chips were used to separate of two fluorescent dyes, rhodamine 123 and fluorescein. The electrophoresis chip also made use of ORMOCER^® to ORMOCER^® bonding. Full article
