Search Results (44)

A prescribed performance neuro-adaptive control scheme is proposed for a single-link flexible-joint robotic manipulator with unknown deadzone and actuator faults. A new smooth deadzone inverse model is constructed to offset the adverse effect caused by the input deadzone in the actuator of flexible-joint manipulators. The control law is developed by coordinating prescribed performance control with a backstepping technique to ensure transient/steady-state performance, while adaptive neural networks are employed for uncertainty approximation. The tracking error is always restricted within the prescribed bound during the control process, and it ultimately converges to the small neighborhood of origin. All signals in the closed-loop flexible-joint robotic manipulator system are proved to be uniformly bounded. Simulation results are provided to demonstrate the efficiency of the prescribed performance adaptive neural network backstepping control scheme. Full article

This study presents a two-segment continuum robot with piecewise stiffness, designed to enhance the precision, adaptability, and safety of tracheal intubation procedures. The robot employs a continuum manipulator (CM) as its end-effector, featuring a proximal segment (PS) with an aluminum alloy interlocking joint, which provides high axial stiffness for stable insertion, and a distal segment (DS) with a micro-nano resin-based notched structure, offering increased flexibility and compliance to navigate complex anatomical structures such as the epiglottis and vocal cords, thereby reducing airway trauma. To describe the motion behavior of the robot, a piecewise variable curvature kinematic model is developed, capturing the deformation characteristics of each segment under actuation. Furthermore, a piecewise stiffness analysis is conducted to determine the axial and bending stiffness of each segment, ensuring an appropriate balance between stability and flexibility. To enhance control precision, an active tendon-driven decoupling control strategy is introduced, effectively minimizing the interaction forces between flexible segments and improving end-effector maneuverability. The results demonstrate that the proposed design significantly improves the adaptability of the tracheal intubation robot, ensuring controlled insertion while reducing the risk of excessive force on the airway walls. This study provides theoretical and technical insights into the mechanical design and control strategies of continuum robots, contributing to the safety and efficiency of tracheal intubation. Full article

With the continuous development of modern robotics technology, in order to overcome the obstacles to the ability to complete tasks due to the fixed structure of the robot itself, to realize the reconfigurable purpose of the manipulator, it can be assembled into different degrees of freedom or configurations according to the needs of different tasks, which has the characteristics of a compact structure, high integrability, and low cost. The overall design scheme of a cable-free modular reconfigurable manipulator is proposed, and based on the target design parameters, the structural design of each module is completed, and the module library is constructed. Each module realizes rapid assembly or disassembly through a new type of docking mechanism module, which improves the flexibility and reliability of the manipulator. Meanwhile, a finite element analysis is carried out on the whole manipulator to optimize the structure that does not meet the strength and stiffness requirements. The wireless energy transmission module is integrated into the joint module to realize the cable-free design of the manipulator in the structure. The kinematic models of each module are established separately, providing a method to quickly construct the kinematics of different configurations of the manipulator, and the dexterity of the workspace is analyzed. Then, two methods, joint space planning and Cartesian space planning, are adopted to generate the corresponding motion paths and kinematic curves, which successfully verifies the reasonableness of the kinematics of the designed manipulator. Finally, combined with the results of the dynamics simulation, the corresponding dynamics curves of the end of each joint are generated to further verify the reliability of its design. It provides a new way of thinking for the research and development of highly intelligent and highly integrated manipulators. Full article

Inspired by the characteristics of living organisms with soft bodies and flexibility, continuum robots, which bend their robotic bodies and adapt to different shapes, have been widely introduced. Such robots can be used as manipulators to handle objects by wrapping themselves around them, and they are expected to have high grasping performance. However, their infinite degrees of freedom and soft structure make modeling and controlling difficult. In this study, we develop a tendon-driven continuum robot system with color-based posture sensing. The robot is driven by dividing the continuum body into two parts, enabling it to grasp objects by flexible motions. For posture sensing, each joint is painted in a different color, and the 3D coordinates of each joint are detected by a stereo camera for estimating the 3D shape of the robotic body. By taking a video of the robot in actuation and using image processing to detect joint positions, we succeeded in obtaining the posture of the entire robot in experiments. We also robustly demonstrate the grasping manipulation of an object using the redundant structure of the continuum body. Full article

Pneumatic artificial muscles (PAMs) are flexible actuators that can be contracted or expanded by applying air pressure. They are used in robotics, prosthetics, and other applications requiring flexible and compliant actuation. PAMs are basically designed to mimic the function of biological muscles, providing a high force-to-weight ratio and smooth, lifelike movement. Inflation and deflation of these muscles can be controlled rapidly, allowing for fast actuation. In this work, a continuum mechanics-based model is developed to predict the output parameters of PAMs, like actuation force. Comparison of the model results with experimental data shows that the model efficiently predicts the mechanical behaviour of PAMs. Using the actuation force–air pressure–contraction relation provided by the proposed mechanical model, a dynamic model is derived for a multi-link PAM-actuated robot manipulator. An adaptive fixed-time fast terminal sliding mode control is proposed to track the desired joint position trajectories despite the model uncertainties and external disturbances with unknown magnitude bounds. Furthermore, the performance of the proposed controller is compared with an adaptive backstepping fast terminal sliding mode controller through numerical simulations. The simulations show faster convergence and more precise tracking for the proposed controller. Full article

Flexible surgical robots are emerging as advanced tools for minimally invasive surgeries, offering greater versatility compared to traditional rigid robots. Unlike commercial endoscopes, the overtube should remain fixed to maintain stability, ensure a clear field of view, and allow surgical tools to perform tasks efficiently. While constant curvature bending of the overtube is sufficient for some lesions, certain lesions require the overtube to bend into specific shapes to achieve appropriate positioning. Various methods for creating different bending shapes have been proposed in previous research, typically involving connecting multiple segments. However, this approach complicates control and reduces both space and cost efficiency. This study proposed a conceptual method for adding a shaping tendon to control the bending shape and mathematically analyzed the effect of this shaping tendon, inserted along an arbitrary path in addition to the main driving tendons for constant curvature bending, on the bending shape of the hyper-redundant manipulator with rolling joints. The overall system was modeled and analyzed from an energy perspective, and the validity of the proposed mathematical modeling was verified through comparison with results obtained from physical experiments. In addition, it was identified that the design parameter determining the tendon path is a significant element in defining the bending shape of the overtube. Full article

Robot acceptance is rapidly increasing in many different industrial applications. The advancement of production systems and machines requires addressing the productivity complexity and flexibility of current manufacturing processes in quasi-real time. Nowadays, robot placement is still achieved via industrial practices based on the expertise of the workers and technicians, with the adoption of offline expensive software that demands time-consuming simulations, detailed time-and-motion mapping activities, and high competencies. Current challenges have been addressed mainly via path planning or robot-to-workpiece location optimization. Numerous solutions, from analytical to physical-based and data-driven formulation, have been discussed in the literature to solve these challenges. In this context, the machine learning approach has proven its superior performance. Nevertheless, the industrial environment is complex to model, generating extra training effort and making the learning procedure, in some cases, inefficient. The industrial problems concern workstation productivity; path-constrained minimal-time motions, considering the actuator’s torque limits; followed by robot vibration and the reduction in its accuracy and lifetime. This paper presents a procedure to find the robot base location for a prescribed task within the robot’s workspace, complying with multiple criteria. The proposed hybrid procedure includes analytical, physical-based, and data-driven modeling to solve the optimization problem. The contribution of the algorithm, for a given user-defined task, is the search for the best robot base location that enables the target points, maximizing the manipulability, avoiding singularities, and minimizing energy consumption. Firstly, the established method was verified using an anthropomorphic robot that considers different levels of a priori kinematics and system dynamics knowledge. The feasibility of the proposed method was evaluated through various simulations for small- and medium-sized robots. Then, a commercial offline program was compared, considering three scenarios and fourteen robots demonstrating an energy reduction in the 7.6–13.2% range. Moreover, the unknown joint dependency in real robot applications was investigated. From 11 robot positions for each active joint, a direct kinematic was appraised with an automatic DH scheme that generates the 3D workspace with an RMSE lower than 65.0 µm. Then, the inverse kinematic was computed using an ANN technique tuned with a genetic algorithm showing an RMSE in an S-shape task close to 702.0 µm. Finally, three experimental campaigns were performed with a set of tasks, repetitions, end-effector velocity, and payloads. The energy consumption reduction was observed in the 12.7–22.9% range. Consequently, the proposed procedure supports the reduction in workstation setup time and energy saving during industrial operations. Full article

This paper presents the design, construction, and implementation of a soft robotic system comprising a continuum manipulator arm equipped with a compliant gripper. Three main objectives were pursued: (1) developing a soft silicone gripper as an alternative to expensive and rigid steel grippers, enabling safe and precise handling of delicate or irregular objects such as fruits, glassware, and irregular shapes; (2) fabricating a continuum manipulator arm with robotic joints inspired by vertebrae, allowing for smooth, non-linear motion and more excellent maneuverability compared to traditional rigid arms, enabling access to hard-to-reach areas; and (3) integrating the compliant gripper with the continuum manipulator and implementing a control system for the soft gripper and remote bending arm using a microcontroller. The soft gripper, manipulator arm vertebrae, and other components were fabricated using 3D printing with PLA material for the molds. The gripper construct used hyperelastic silicone (Ecoflex 00.30). The continuum manipulator achieved a higher degree of freedom and mobility, while simulations and experiments validated the design’s effectiveness. The comparison shows that the close agreements differ by only 2.5%. In practical experiments involving lifting objects, the gripper was able to carry items with a greater mass. The proposed soft, integrated robotic system outperformed traditional rigid approaches, offering safe and flexible handling capabilities in unstructured environments. The nature-inspired design enabled a compliant grip and enhanced maneuverability, making it suitable for various applications requiring dexterous manipulation of delicate or irregularly shaped objects. Full article

Robotic manipulators are critical for industrial automation, boosting productivity, quality, and safety in various production applications. Key factors like the payload, speed, accuracy, and reach define robot performance. Optimizing these factors is crucial for future robot applications across diverse fields. While 6-Degrees-of-Freedom (DoF)-articulated robots are popular due to their diverse applications, this research proposes a novel 5-DoF robot design for industrial automation, featuring a combination of three prismatic and two revolute (2R) joints, and analyzes its workspace. The proposed techno-economically efficient design offers control over the robot manipulator to achieve any reachable position and orientation within its workspace, replacing traditional 6-DoF robots. The kinematic model integrates both parallel and serial manipulator principles, combining a Cartesian mechanism with rotational mechanisms. Simulations demonstrate the end effector’s flexibility for tasks like welding, additive manufacturing, and material inspections, achieving the desired position and orientation. The research encompasses the design of linear and rotational actuators, kinematic modeling, Human–Machine Interface (HMI) development, and welding application integration. The developed robot demonstrates a superior performance and user-friendliness in welding. The experimental work validates the design’s optimized joint trajectories, efficient power usage, singularity avoidance, easy access in application areas, and reduced costs due to fewer actuators. Full article

DC motors are widely used in industries to provide mechanical power in speed and torque. The position and speed control of DC motors is receiving interest from the scientific community in robotics, especially in robotic arms, a flexible joint manipulator. The current research work is based on the position control of DC motors using experimental investigations in LabVIEW. The linear control strategy is applied to track the position and speed of the DC motor with comparative analysis in the LabVIEW platform and simulation analysis in MATLAB. The tracking error in the hardware setup based on LabVIEW programming is slightly greater than the simulation analysis in MATLAB due to the inertial load of the motor during steady-state conditions. The controller output shows the input voltage applied to the DC motor varies between 0 and 8 V to ensure minimal steady error while tracking the position and speed of the DC motor. Full article

High-precision industrial manipulators are essential components in advanced manufacturing. Model-based feedforward is the key to realizing the high-precision control of industrial robot manipulators. However, traditional feedforward control approaches are based on rigid models or flexible joint models which neglect the elasticities out of the rotational directions and degrade the setpoint precision significantly. To eliminate the effects of elasticities in all directions, a high-precision setpoint feedforward control method is proposed based on the output redefinition of the extended flexible joint model (EFJM). First, the flexible industrial robots are modeled by the EFJM to describe the elasticities in joint rotational directions and out of the rotational directions. Second, the nonminimum-phase EFJM is transformed into a minimum-phase system by using output redefinition. Third, the setpoint control task is transformed from Cartesian space into joint space by trajectory planning based on the EFJM. Third, a universal recursive algorithm is designed to compute the feedforward torque based on the EFJM. Moreover, the computational performance is improved. By compensating the pose errors caused by elasticities in all directions, the proposed method can effectively improve the setpoint control precision. The effectiveness of the proposed method is illustrated by simulation and experimental studies. The experimental results show that the proposed method reduces position errors by more than 65% and the orientation errors by more than 62%. Full article

The unmanned aerial manipulator (UAM) is a kind of aerial robot that combines a quadrotor aircraft and an onboard manipulator. This paper focuses on the problems of structure design, system modeling, and motion control of an UAM applied for water sampling. A novel, light, cable-driven UAM has been designed. The drive motors installed in the base transmit the force and motion remotely through cables, which can reduce the inertia ratio of the manipulator. The Newton–Euler method and Lagrangian method are adopted to establish the quadrotor model and manipulator model, respectively. External disturbances, model uncertainty, and joint flexibility are also accounted for in the two submodels. The quadrotor and manipulator are controlled separately to ensure the overall accurate aerial operation of the UAM. Specifically, a backstepping control method is designed with the disturbance observer (BC-DOB) technique for the position loop and attitude loop control of the quadrotor. A backstepping integral fast terminal sliding mode control based on the linear extended state observer (BIFTSMC-LESO) has been developed for the manipulator to provide precise manipulation. The DOB and LESO serve as compensators to estimate the external disturbances and model uncertainty. The Lyapunov theory is used to ensure the stability of the two controllers. Three simulation cases are conducted to test the superior performance of the proposed quadrotor controller and manipulator controller. All the results show that the proposed controllers provide better performances than other traditional controllers, which can complete the task of water quality sampling well. Full article

Delta robot is a lightweight parallel manipulator capable of accurately moving heavy loads at high speed and acceleration along a spatial trajectory. This intensive dynamic process may have a significant impact on the end-effector trajectory precision and motor behavior. The paper highlights the influence on the dynamic behavior of a Delta robot by considering individual and combined effects of clearances and friction in the spherical joints, as well as the flexibility of the rod elements. The CAD modeling of the Delta robot and its motion simulation on a representative spatial trajectory where the maximum allowed values of speed and acceleration are reached were performed using the Catia and Adams software packages. The obtained results show that the methods used were successfully applied and the effects are mutually interconnected, but not cumulative. Full article

The aerial flexible-joint robot (AFJR) manipulation system has been widely used in recent years. To handle uncertainty, the input saturation and the output constraint existing in the system, a fixed-time observer-based adaptive control scheme (FTOAC) is proposed. First, to estimate the input saturation and disturbances from the internal force between the robot and the flight platform, a fixed-time observer is designed. Second, a tangent-barrier Lyapunov function is introduced to implement the output constraint. Third, adaptive neural networks are introduced for the online identification of nonlinear unknown dynamics in the system. In addition, a fixed-time compensator is designed in this paper to eliminate the adverse effects caused by filtering errors. The stability analysis shows that all the signals of the closed-loop system are bounded, and the system satisfies the condition of fixed-time convergence. Finally, the simulation results prove the superiority of the proposed control strategy by comparing it with the previous schemes. Full article

With the vigorous development of mechanical intelligence in industrial manufacturing, tracking control dynamic systems have been widely applied in many aspects of industry. In this paper, we present one theorem to discuss the validity condition of a ZD model with order-n for solving the tracking control problem of a nonlinear problem by utilizing a Lie derivative. Moreover, we also give the unified formula of the ZD model with order-n and rigorously prove it mathematically. In addition, we present three other theorems to give the global exponential convergence property of the ZD controller u(t), and the steady-state tracking error bound of the ZGD controller u(t), and the radius bound where the steady-state tracking error converges exponentially. Finally, simulations are conducted to demonstrate the validity and parameter influences of the ZD model and ZGD model for solving the tracking control problem with a single linear or nonlinear output of the single-link manipulator with flexible joints. Full article
