Search Results (208)

Deep excavation groups in soft soil can endanger adjacent historic buildings. This paper presents a 3D finite element analysis of a project in Ningbo, employing the HSS constitutive model. Three excavation schemes were compared. The small-zone staged excavation from near to far proved optimal: relative to the conventional large-block scheme, it reduced maximum wall displacement on the heritage-building side by 37.0% and building tilt by 54.0%; servo struts were then introduced in the critical sub-excavation and optimized via response surface methodology. A layered control hierarchy was revealed—wall bulging is governed by the third and fourth struts (F₃ ≈ F₄ > F₂), and mean settlement by the third strut (F₃ > F₂ ≈ F₄). Building tilt control relies on synergistic action of all three struts (F₃ > F₂ > F₄), with significant antagonistic interactions among struts at high force levels. The optimal combination (F₂ = 1200 kN, F₃ = 1800 kN, F₄ = 1550 kN) limits maximum tilt to 0.380‰, well below the 1.0‰ code limit, and remains robust under various weighting scenarios. Full article

Slope stability in open-pit mining is not a static condition but evolves continuously as excavation progresses and geomechanical conditions change. In this study, an integrated approach combining ground-based radar monitoring, satellite-based InSAR time-series analysis, and numerical stability modeling was applied to evaluate slope behavior in a large-scale open-pit copper mine with complex geological and structural characteristics. Radar data revealed progressive and episodic deformation concentrated in specific slope sectors, while InSAR observations showed that deformation continued at lower rates after the main movement phase, providing a longer-term perspective of slope response. Stability analyses using limit equilibrium and finite element methods indicate that the slope operates close to a limit equilibrium condition, particularly under saturated scenarios where factors of safety approach critical levels and strain localization becomes more pronounced. The results show a clear link between observed deformation patterns and calculated stability conditions, with structural discontinuities and groundwater playing a dominant role in controlling slope behavior. Based on these findings, an integrated workflow is proposed that links monitoring data with stability assessment, enabling the identification of critical zones and supporting the evaluation of slope conditions during ongoing mining operations. This approach contributes to more reliable decision-making and supports safer and more sustainable open-pit mining practices. Full article

Strong seismic waves induced by drill-and-blast tunnel excavation threaten the structural integrity of adjacent existing tunnels; however, prevailing safety evaluation methods mostly simplify tunnel linings as homogeneous continua, failing to accurately characterize the meso-scale uncoordinated dynamic response between rebar and concrete under blast impact. To fill this research gap, a 1:1 full-scale separated three-dimensional finite element model of reinforced concrete composite linings was established using the LS-DYNA explicit dynamic numerical algorithm, which was verified by previous 1:25 scaled physical model tests. This study systematically quantifies the spatiotemporal evolution of lining dynamic responses under two core parameters—tunnel clear distance (10 m to 60 m) and single-delay detonating charge quantity (10.8 kg to 28.8 kg)—to validate the response differences between materials. It is abstracted that the structural failure is dominated by axial tensile stress, with the embedded rebar being significantly more sensitive to internal stress surges (reaching 3.5 times the peak stress of concrete), while the concrete is more sensitive to particle vibration velocity amplification, a mismatch that is particularly acute within a 30 m clear distance. This study highlights the severe interfacial stress gradient between rebar and concrete, providing an indirect but critical indicator for the potential risk of interface debonding under adjacent blasting, and offers a quantitative theoretical basis for extending safety assessments from macro-surface vibration control to refined meso-scale internal stress monitoring. Full article

With the increasing development in urban underground spaces towards greater depth, scale, and complexity, the prediction and control of deformations in deep excavation engineering have become critical challenges in geotechnical engineering. This study investigates the ultra-deep excavation of the Tianjin Metro Line 8 Liulitai Station, analyzing the deformation characteristics of the retaining structure during top-down construction in soft soil based on field monitoring data. The results reveal a typical “bulging” pattern in the horizontal displacement of the diaphragm wall, which accumulates progressively with excavation depth. To enhance deformation prediction accuracy, a self-developed beam-plate finite element method (BPFEM) platform, implemented in Python (version 3.11.9), is introduced. The platform integrates code-specified analytical methods and the incremental approach to simulate the internal forces and deformations of the support system with high precision. By incorporating a dual-parameter back-analysis technique—adjusting both the horizontal subgrade reaction modulus and active earth pressure—the numerical model achieves significantly improved agreement with monitoring data. The proposed method demonstrates strong predictive capability, with a maximum error of only 4.4% in subsequent construction stages, confirming its feasibility and reliability for deformation forecasting in top-down deep excavations. The BPFEM framework and parameter inversion strategy presented herein provide an effective technical basis for intelligent prediction and dynamic control in deep excavation projects under complex geological conditions. Full article

Ground engaging tool (GET) wear monitoring is important for mining excavator maintenance, but progressive multi-tooth wear estimation remains insufficiently explored. This study presents a vibration-based framework for GET wear estimation during operations using modal analysis, finite element (FE) modelling, and machine learning as a supporting evaluation tool. A laboratory-scale mining bucket surrogate with detachable attached masses was used to represent progressive tooth wear through controlled mass-loss conditions. Experimental impact hammer tests under approximately free-free boundary conditions were conducted to validate the FE modal model through natural-frequency comparison and qualitative mode correspondence. The validated FE model was then used to generate a broader dataset of multi-tooth wear scenarios, from which the first ten natural frequencies were extracted as modal features. Linear Regression (LR) was adopted as a simple and interpretable baseline to evaluate both overall wear estimation and individual tooth wear estimation. High accuracy was obtained for overall wear estimation for both the non-symmetric and symmetry-augmented datasets, with R² values of 0.9983 and 0.9976, respectively. In contrast, individual tooth prediction was more challenging, and the symmetry-augmented results showed that mirrored tooth locations can produce non-unique frequency-based signatures. An additional asymmetric FE sensitivity study further confirmed that structural symmetry can limit local wear identifiability when only global natural frequencies are used. These findings demonstrate the potential of FE-derived modal frequency features for laboratory-scale GET wear assessment, while also highlighting the limitations of frequency-only features for unique local wear localisation in symmetric structures. This is a promising approach for wear estimation during mining operations. Full article

Given the challenges posed by high groundwater levels, thick sand layers, and strong permeability in water-rich sandy strata, cut-off walls often fail to fully isolate the hydraulic connection between the inside and outside of a foundation pit. As a result, dewatering inside the pit—especially from confined aquifers—can cause significant external groundwater drawdown and subsequent ground settlement. Using a deep excavation conducted in Xiamen as a case study, this study developed a two-dimensional hydro-mechanical coupled finite element model to systematically investigate the effects of various dewatering scenarios and soil permeability coefficients on surface settlement around the pit, and to reveal settlement patterns induced by dewatering and excavation in such strata. Field monitoring data were incorporated to validate the numerical model, ensuring accuracy and reliability. Key findings include the following: (1) Dewatering contributes to over 76% of the total settlement at each stage, with confined drawdown being the dominant factor, implying that dewatering optimization should take priority over controlling excavation rate. (2) Under confined dewatering, the settlement influence zone extends beyond 80 m, far exceeding the extension caused by excavation alone; thus, monitoring and protection ranges must be adjusted dynamically. (3) The horizontal permeability of sand shows a nonlinear positive correlation with settlement, and this sensitivity grows with depth, highlighting the need for accurate permeability determination and stricter controls in deep excavations within water-rich sand layers. From an engineering perspective, these findings underscore the importance of prioritizing confined aquifer dewatering management, dynamically expanding settlement monitoring zones, and rigorously characterizing permeability profiles to mitigate excessive ground settlement and protect adjacent infrastructure. Full article

Maintaining the integrity of impermeable strata between mine workings and overlying aquifers is critical, because seepage pathways may cause mine flooding and surface subsidence. In the Upper Kama potash deposit, the impermeable sequence is a 50–140 m thick layered sequence of evaporites and clays overlying mined-out chambers. Under long-term loading, salt rocks tend to creep, soften, and localize damage, which can cause failure in the impermeable strata. In this paper, the Concrete damage-plasticity model, supplemented by the N2PC-MCT viscoplastic creep model, is applied to simulate the initiation and evolution of seepage pathways in the Upper Kama impermeable strata. Model parameters are obtained from published laboratory tests (uniaxial and triaxial compression and tension) and validated using observed ground-surface subsidence. A plane-strain finite-element model incorporates the stratified lithology, interface elements between layers, and sequential excavation. Long-term simulations up to 50 years investigate two operational scenarios: with and without backfilling. The calibrated model reproduces the main stages of surface subsidence and chamber closure. Without backfilling, simulations indicate that tensile damage localizes mainly in a stiff central salt layer of the impermeable strata, with most cracks appearing approximately between 33 and 37 years after the start of mining. With backfill, tensile crack propagation stops and damage remains stable. A hypothetical homogeneous impermeable strata case confirms that the observed central-layer cracking is associated with stiffness contrasts and composite bending in the stratified system. An approximate analytical multilayer beam solution, based on energy minimization, predicts bending stress concentration in stiff intermediate layers and is consistent with the numerical stress distribution. The combined numerical and analytical results provide insight into the mechanisms of long-term conductive fracture initiation in stratified impermeable strata and may serve as a basis for preliminary hazard indication and for planning mitigation measures, including backfilling and focused monitoring of stiff central layers. Because the study is based on a 2D plane-strain model, the quantitative estimates should be regarded as preliminary and require verification by 3D modelling and further field observations. Full article

In mining TBM excavation, the mineralogical heterogeneity of rock significantly impacts tunneling efficiency and rock-breaking performance. The cutting process of tunnel boring machine (TBM) double-disc cutters is significantly influenced by the combined effects of mineral composition differences and cutter spacing parameters. In this study, a heterogeneous granite model was constructed using the finite–discrete element method (FDEM), with quartz content fixed at 30%. Different mineral compositions were generated by adjusting the proportions of feldspar and mica, and a double-disc cutter–rock contact model was employed with various cutter spacings to perform numerical cutting simulations. Cutter work was calculated by integrating the force–displacement curves, rock-breaking efficiency was evaluated by the specific energy (SE) defined as the energy consumed per unit rock chip area, and fracture types, as well as fragmentation volumes, were identified. The results show that the total input energy ranged from 2.2 to 3.4 mJ, reaching a peak at medium cutter spacings of 50–70 mm; as feldspar content increased, the overall energy level rose significantly. Rock-breaking efficiency was relatively high at medium cutter spacings, and the favorable spacing range shifted from approximately 50 mm to 60 mm when feldspar content increased from 40–50% to 60%. Excessively small spacing led to a higher proportion of crushing and repeated damage, while overly large spacing weakened crack interactions, both of which reduced efficiency. Overall, cutter spacing mainly controlled the crack interaction patterns, whereas the feldspar–mica ratio dominated energy utilization. These findings suggest that, in practical TBM excavation, cutter spacing should be reasonably optimized according to the mineral composition of the surrounding rock to avoid energy waste caused by extreme spacing and to achieve a balance between efficiency and energy consumption. Full article

The primary objective of this research is to quantitatively isolate the complex driving factors of slope deformation and explicitly reveal the long-term creep mechanism induced by early excavation unloading, thereby providing a theoretical basis for long-term stability evaluation. To achieve this, this study adopts a combined approach of multivariate statistical regression and numerical simulation inversion based on long-sequence monitoring data. First, a multivariate statistical regression model incorporating time-dependent, rainfall, temperature, valley width, and excavation components was constructed to quantitatively separate the contribution weights of each factor. Second, by introducing a rock–soil creep constitutive model, a refined finite element model was established to perform back-analysis of creep parameters and numerical simulation. The results indicate that two large-scale slope-cutting excavations were the direct triggers for the deformation, resulting in shear dislocation of the deep ancient sliding zone and superficial slippage. The dominant factors exhibit distinct phasic and spatial differences: before impoundment, the time-dependent component was absolutely dominant (>80%); after impoundment, low-elevation areas were significantly affected by valley width shrinkage (>60%), while high-elevation areas remained dominated by time-dependent deformation (>74%). Numerical simulation confirmed that the nature of the deformation is “excavation unloading-induced creep along the ancient sliding zone,” and the simulation results considering creep effects accurately reproduced the actual deformation characteristics observed in situ. It is concluded that the rheological effects induced by early excavation unloading are central to the control of long-term stability. Full article

In urban subway construction, shield tunneling inevitably passes in close proximity to existing pile foundations, inducing adverse effects on their internal forces and deformations. Taking the twin shield tunnels with small clearance adjacent to the bridge piles as the engineering background, this study establishes a three-dimensional finite element numerical model to investigate the deformation and internal force responses of the adjacent pile foundations under different pile lengths, twin-tunnel construction sequences, and tunnel face pressure conditions. The findings indicate that the primary influence zone affected by twin-tunnel excavation extends approximately twice the tunnel diameter (2D) before and after the pile foundation location. Compared with short piles, longer piles exhibit smaller vertical displacements. Meanwhile, the lateral displacements, additional axial forces and bending moments of medium and long piles increase, with their maximum values occurring near the tunnel centerline. For the near pile, when the right tunnel is excavated first, compared with the condition of the left-tunnel-first excavation, the lateral and vertical displacements slightly increase. In addition, the maximum additional axial force increases by 38.8%, while the maximum additional bending moment decreases by approximately 21%. Tunnel face pressure exerts a moderate influence on the vertical displacement of both the surrounding soil and pile foundation, while its effect on lateral displacement and internal forces is relatively insignificant. The tunnel face pressure within the range of 200 kPa to 300 kPa provides optimal control over pile foundation deformation. Full article

This study investigates road tunnel stability in heterogeneous flysch formations using the Zenica Tunnel as a case study. A hybrid research framework integrating empirical classification, analytical modeling, and numerical simulation was applied. The approach combines the Rock Mass Rating (RMR) system, the Convergence–Confinement Method (CCM), and nonlinear two-dimensional finite element (FEM) analyses. Statistical evaluation of the results reveals a strong exponential relationship between the stability factor N_s and measured tunnel convergence, with coefficients of determination (R²) between 0.89 and 0.96. Particular attention was given to sections classified as Category V rock mass. The analysis indicates that when RMR values fall below 25, the stability factor N_s exceeds the critical value of 5, marking the onset of pronounced squeezing behavior. The results show that analytical methods provide conservative estimates of tunnel stability, while numerical modeling enables improved calibration of support system stiffness. The proposed integrated methodology contributes to more reliable stability assessment and support design in road tunnels excavated in complex flysch formations. Full article

Excavation adjacent to operating urban rail transit faces formidable deformation control challenges. To address this, a parametric collaborative optimization framework integrating micro steel pipe pile isolation and temporary intermediate partition wall reinforcement is proposed. Taking a foundation pit project at Shangdi Station of Beijing Metro Line 13 as a case study, a three-dimensional finite element model was established using the Hardening Soil constitutive model and calibrated with field monitoring data. Optimization analysis reveals that micro-pile spacing is the dominant factor controlling local rail settlement, while intermediate partition wall thickness primarily dictates global surface settlement. By balancing stringent safety limits with construction economy through a multi-objective evaluation, the preferred support configuration was calculated to be 273 mm diameter micro-piles at 500 mm spacing, combined with a 300 mm-thick partition wall. This collaborative configuration successfully truncates lateral soil displacement, reducing maximum rail settlement by over 55% and surface settlement by 53.6% compared to the baseline. Field monitoring results show high consistency with the numerical predictions (RMSE = 0.1438 mm), confirming the reliability of the proposed parametric collaborative optimization framework. Ultimately, this framework provides a validated, quantitative design methodology and a practical reference for support design in constrained excavations adjacent to existing sensitive infrastructure. Full article

Underground metro tunnel failures in recent years have caused significant economic losses and posed serious risks to surface structures, highlighting the importance of accurately predicting tunnelling-induced ground deformations. Surface settlements occurring during TBM excavation may adversely affect existing infrastructure, particularly in sensitive urban areas. This study evaluates surface deformations induced by a TBM-driven metro tunnel as a case study, explicitly considering tunnel–structure interaction at locations where piled bridge piers are present. Due to site sensitivity, topographic monitoring was conducted during TBM passage, and measured settlement data were used for assessment. Settlement analyses were performed using the Peck (1969) empirical method and finite element modelling in Plaxis. Two constitutive soil models, Mohr–Coulomb (MC) and Hardening Soil (HS), were adopted to compare their predictive performance. The results show that the MC model predicts the highest surface settlements, whereas the Peck (1969) method provides results close to those obtained with the HS model, despite not explicitly incorporating structural loads. From the finite element tunnel models, it was determined—particularly from the two coordinate routes—that the HS model achieved prediction accuracy of up to approximately 95% compared to the measured values. Overall, the Peck approach and the HS model yielded more consistent predictions than the MC model for the investigated conditions, emphasizing the importance of appropriate soil model selection in finite element analyses of tunnelling-induced settlements. Full article

The Draa Sfar polymetallic mine, located near Marrakech in Morocco, represents the deepest currently operating underground mine in North Africa, with workings extending beyond depths of −1200 m. At such depths, mining activities are conducted within weak, highly anisotropic foliated black pelites, where recurrent instability mechanisms, most notably rib buckling and crown deterioration, are frequently observed, especially in drifts developed parallel to the foliation planes. In this context, the present study integrates detailed structural field observations with two-dimensional finite-element modelling using RS2 in order to analyse excavation-scale stability within these schistose pelitic rocks. Both numerical simulations and field evidence indicate that increasing depth-related confinement, together with a dominant in situ stress regime, favours stress channelling and localized damage development, while the pronounced transverse weakness of the pelites exerts a primary control on failure kinematics, including schistosity-parallel spalling, asymmetric rib buckling, and shear along inclined foliation intersecting the excavation back. Instability processes are further intensified by excavation geometry and mine layout: angular, square-shaped profiles and foliation-parallel drift orientations generate steeper stress gradients and greater convergence compared to arched sections, while proximity to stopes and adjacent openings enhances mining-induced stress redistribution and associated deformation. Intersection areas emerge as the most critical configurations, where the superposition of stress perturbations and structurally controlled damage mechanisms accelerates wall convergence and roof sagging. Overall, these findings demonstrate that drift stability cannot be adequately evaluated using generic design criteria when excavation geometry, interaction effects, and structural anisotropy exert a dominant influence on mechanical behaviour. Consequently, a fully integrated approach that combines drift geometry optimisation, detailed structural mapping, site-calibrated numerical modelling, and in situ monitoring is required to achieve reliable stability assessment and control. Full article

Three-dimensional spatial effects in deep excavations critically govern the mechanical response of retaining structures and adjacent soils, yet their quantitative characterization remains a challenge. This study systematically investigates the spatial behavior of row-pile-supported foundation pits through an integrated approach combining model tests, theoretical analysis, and numerical simulations. A novel formulation for the spatial effect influence coefficient K is derived from limit equilibrium principles and subsequently validated via ABAQUS-based finite element simulations. Model test results reveal pronounced spatial heterogeneity in earth pressure and bending moment distributions along the pit perimeter: lateral earth pressure at corner regions exceeds that at mid-side locations at equivalent depths, whereas bending moments in mid-side piles are substantially larger than those at corners. Displacement field measurements further demonstrate that corner zones, constrained bidirectionally, undergo minimal deformation, while maximum displacement occurs at the midpoints of the long sides. These observations collectively confirm the existence of a marked corner effect and a subdued side-midpoint effect under three-dimensional confinement. Complementary numerical analyses indicate that the coefficient K decreases monotonically with increasing half-angle corners and distance from the corner, thereby quantitatively capturing the decay of spatial constraint intensity. Together, these findings establish a theoretical framework for assessing excavation-induced spatial effects and provide actionable guidance for the rational design of deep foundation pit support systems. Full article
