Search Results (29)

Stretchable transparent electrodes play a pivotal role in flexible electronics, requiring excellent stretchability, transparency, and conductivity. However, these properties often impose conflicting demands, making it challenging to achieve a balanced design. This paper proposes a topology optimization-based method for designing stretchable transparent electrode structures, which achieves a well-balanced trade-off among these attributes while maintaining excellent numerical robustness under extreme deformations. The proposed method incorporates an improved eigenvalue stabilization technique to address the critical issue of severe mesh distortion during geometrically nonlinear finite element analysis. Specifically, elements at high risk of distortion are identified via eigenvalue decomposition of their tangent stiffness matrices, and both small and negative eigenvalues are corrected to prevent the global stiffness matrix from becoming ill-conditioned. This stabilization scheme enables the optimization to robustly handle large deformations without altering the underlying physical problem or sensitivity analysis. Conductivity is evaluated using a homogenization approach, stretchability is characterized by the maximum element strain energy under geometric nonlinearity, and transparency is controlled through a volume constraint. A topology optimization model that balances these performance metrics is then formulated, and analytical sensitivities are derived. Several numerical examples demonstrate the effectiveness of the proposed method. Full article

Nonlinear structural analysis serves as a fundamental tool for accurately predicting structural bearing capacity and ultimate strength. The incremental-iterative solution scheme represents the prevailing methodology for tracing nonlinear load–displacement responses and is implemented in most commercial finite element software. To enhance the robustness and computational efficiency of existing schemes, this paper first revisits the incremental-iterative framework, providing a detailed analysis that clarifies the distinct roles of the load increment factor in the predictor and corrector phases. Subsequently, a novel framework of updated orthogonal iterative schemes (UOIS) is established. Within this framework, the current generalized stiffness parameter (CGSP) and a cumulative indicator $S_i$ are introduced in the predictor phase to adaptively control the magnitude and sign of the load increment, respectively. In the corrector phase, four enhanced orthogonal iteration strategies are formulated. Furthermore, to improve computational efficiency, a novel acceleration strategy is proposed, which embeds a secant prediction operator in the predictor phase, thereby circumventing the costly assembly and inversion of the tangent stiffness matrix. The results demonstrate that: (1) compared to the conventional generalized stiffness parameter (GSP), the proposed CGSP exhibits superior stability in tracking stiffness variations, offering a more reliable indicator for adaptive step-size control; (2) the cumulative indicator $S_i$ reliably identifies load limit points and accurately distinguishes between loading and unloading regimes; (3) the UOIS framework demonstrates strong convergence in tracing complex equilibrium paths with multiple critical points and exhibits significantly superior robustness under large increment sizes compared to the generalized displacement control method (GDCM); and (4) the secant-prediction acceleration strategy achieves substantial improvements in computational efficiency without compromising solution accuracy. Full article

Discrete Body Dynamics (DBD) is a recently developed approach for solving multibody dynamics problems that aims to improve the numerical treatment of systems with joint compliance. Conventional multibody formulations typically rely on kinematic constraints, which can increase numerical complexity and sensitivity, particularly in closed-chain systems. In this work, DBD is presented as a unified framework that combines a new modeling approach with a new numerical solution strategy. Mechanical joints are modeled explicitly using sets of springs and dampers, replacing ideal constraints and transforming the governing equations from a differential-algebraic system into a purely differential one. Based on this modeling framework, the numerical solution avoids global matrix operations and relies on element-wise computations, resulting in linear computational complexity with respect to the number of bodies. The numerical performance of the DBD method is investigated using a set of closed-chain benchmark systems, which are known to be challenging for conventional constraint-based solvers. The analysis examines the influence of joint stiffness, system dynamics, time-step selection, and mechanism topology on numerical stability, energy dissipation, and computational efficiency. The results show that DBD maintains robust and accurate solutions across the examined scenarios and exhibits a well-defined operating region with low numerical dissipation. Across the examined compliant-joint benchmarks, DBD shows the potential for up to three orders of magnitude lower energy drift at comparable simulation-time-to-real-world time (SRT), or up to about one order of magnitude higher SRT at comparable energy drift, relative to ADAMS/View. These findings indicate that DBD is well suited for the simulation of realistic multibody systems with compliant joints, including closed-chain configurations. Full article

Ceramic Matrix Composites (CMCs) have emerged as a structural material alternative to nickel superalloys for high-pressure turbines (HPT) components operating at high temperature, like shrouds. Despite the outstanding thermal stability of the CMCs, limited cooling is still necessary due to the extreme thermal operating conditions necessary to maximize engine performance and minimize fuel consumption. The design of CMC components, indeed, must consider a maximum service temperature that should not be exceeded to avoid damage and accelerated oxidation. The cooling, on the other hand, may induce the formation of thermal gradients and thermal stresses. In this work, different design options for the cooling system are investigated to minimize the thermal stresses of an HPT shroud-like geometry subjected to maximum temperature constraints on the material. Cooling is obtained via colder air jet streams (air taken from the compressor), whose impact position (the surface where the cold air impacts the component) has a different effect on the temperature field and on the induced stress field. Besides stress evaluation with different cooling systems, an ONERA damage model is investigated at a key location to potentially take into account stress components acting simultaneously and potential stiffness degradation of the CMC. Finally, the design evaluation of potential discrete crack propagation is discussed. A standard cohesive elements approach has been compared with a brittle element death approach. The results showed that the cohesive element approach resulted in shorter crack propagation, underestimating the actual crack behavior due to the embedded stiffness degradation method, while the element death returned encouraging results as a quicker, less complex, but still accurate design evaluation. Full article

Background/Objectives: Bone defects remain widespread. Type I collagen–hydroxyapatite composites suit bone engineering by mimicking matrix structure, making them pertinent materials for bone tissue engineering across a range of defect types. Their application is well aligned with non-load-bearing conditions, while use in load-bearing sites requires mechanical properties that meet the demands of those environments. Marine collagen offers a low-cost source from processing by-products. This work aimed to develop perch collagen–hydroxyapatite scaffolds for bone tissue engineering. Methods: Composites with COLL:HAp ratios of 100:0, 50:50, 40:60, and 30:70 were prepared. After crosslinking and freeze-drying, porosity and water absorption were examined. SEM and X-EDS assessed morphology and elemental distribution. FT-IR confirmed the chemical composition. Compression tests evaluated mechanical behavior. Cell viability and colonization assessed the biological performance. Biodegradability, thermal stability, and antimicrobial activity were also determined. Results: FT-IR confirmed the characteristic absorption bands of both components. SEM and swelling behavior showed porous, interconnected structures with uniform hydroxyapatite dispersion. X-EDS indicated Ca/P ratios consistent with hydroxyapatite. Thermal analysis demonstrated scaffold stability. Compression tests showed mechanical resistance for all the scaffolds, with stiffness increasing with the inorganic content. Perch collagen enhanced biological functionality, supporting osteoblast viability and colonization. Biodegradation gradually proceeded. Antibacterial activity against the tested pathogens was detectable, though moderate. Conclusions: The developed scaffolds combined structural stability, controlled degradation, and favorable cell response, constituting a viable and promising candidate for applications in bone tissue engineering. Full article

The material point method (MPM) has shown significant potential for simulating problems involving large deformations. However, many implicit MPM formulations based on the traditional Updated Lagrangian (UL) scheme still face challenges in terms of computational stability. In this study, we propose a novel Lagrangian equilibrium formulation for an implicit MPM that is tailored to large-deformation problems. (1) The previously converged state is utilized to simplify stiffness matrix computations, thereby improving the stability of the algorithm. (2) The framework supports a variety of high-order interpolation functions, which effectively mitigate numerical artifacts such as cell-crossing errors. (3) The B-bar technique is further incorporated to suppress spurious stress oscillations in the incompressible limit. The proposed method is validated through two classical benchmark tests, the simple shear of a single element and the cantilever beam problem, by comparing the simulation results with analytical solutions and alternative numerical approaches. Finally, its capability is demonstrated in slope stability and strip footing analyses, confirming the superior accuracy, stability, and robustness of the method for large-deformation elastoplastic problems. Full article

An integrated evaluation framework merging the analytic hierarchy process (AHP) and an improved matter–element extension model based on asymmetric proximity is developed to classify large deformation risk levels in soft-rock tunnel construction. From geological surveys and real-time monitoring, ten core indicators spanning three dimensions—geology (surrounding rock grade, groundwater condition, strength–stress ratio, adverse geological condition), design (excavation cross-sectional shape, excavation span, excavation cross-sectional area), and support (support stiffness, support installation timing, construction step length)—are selected. AHP constructs and validates a judgment matrix to derive subjective weights for each indicator. Within a three-tier hierarchy (indicator, criterion, and target layers), the asymmetric proximity quantifies each tunnel’s proximity to the matter–element representing predefined risk levels. Risk levels are then automatically assigned by selecting the maximum composite proximity. Application to representative soft-rock tunnel cases confirms the method’s high accuracy, stability, and operational feasibility, closely matching field observations. This framework enables precise risk stratification and intuitive visualization, offering critical technical support for optimizing tunnel design and operations, and ultimately enhancing the safety, resilience, and sustainability of large-scale infrastructure. Full article

In flank milling of thin-walled workpieces, machining deformation is a key issue affecting workpiece accuracy and process stability. Although the traditional finite element method (FEM) offers high accuracy, its low computational efficiency makes it difficult to meet the requirements for rapid prediction in engineering practice. For this purpose, this paper proposes an efficient method for predicting workpiece deformation based on the voxel octree model. First, based on the analysis of the contact position between the cutting tool and the workpiece, the thin-walled workpiece is divided into six levels of voxel units, using a voxel octree model. Then, the stiffness matrix and update model of the voxel units are established. Finally, the deformation prediction is completed by calculating the micro-milling force and the voxel stiffness matrix. The experimental results show that the workpiece deformation predicted by the proposed method is highly consistent with the actual machining measurement. At the same time, compared with traditional FEM and voxel model methods, the calculation time is reduced by 90% and 13.2%, respectively. This method can provide rapid decision support for the optimization of thin-walled workpiece machining processes and effectively improve the efficiency of preliminary research in actual machining. Full article

The current study demonstrates the buckling properties of composite laminates reinforced with MWCNT fillers using a novel higher-order shear and normal deformation theory (HSNDT), which considers the effect of thickness in its mathematical formulation. The hybrid HSNDT combines polynomial and hyperbolic functions that ensure the parabolic shear stress profile and zero shear stress boundary condition at the upper and lower surface of the plate, hence removing the need for a shear correction factor. The plate is made up of carbon fiber bounded together with polymer resin matrix reinforced with MWCNT fibers. The mechanical properties are homogenized by a Halpin–Tsai scheme. The MATLAB R2019a code was developed in-house for a finite element model using C⁰ continuity nine-node Lagrangian isoparametric shape functions. The geometric nonlinear and linear stiffness matrices are derived using the principle of virtual work. The solution of the eigenvalue problem enables estimation of the critical buckling loads. A convergence study was carried out and model efficiency was corroborated with the existing literature. The model contains only seven degrees of freedom, which significantly reduces computation time, facilitating the comprehensive parametric studies for the buckling stability of the plate. Full article

A new computational framework for nonlinear dynamic analysis of smooth shell structures is presented in this paper. The new framework is based on Simo & Tarnow’s energy–momentum conservation algorithm. A novel co-rotational nine-node quadrilateral shell element is embedded in the new framework. The dynamic equilibrium differential equations are derived using the Hamilton principle and solved by the Newmark algorithm. At each step, midpoint interpolation is applied to both nodal variables and their time derivatives. The average value of strains at the beginning and the end of each step is used to evaluate strain energy to obtain a symmetric tangent stiffness matrix. When deriving the kinetic energy functional, the first-order derivatives of vectorial rotational variables are embedded into equivalent nodal forces. Therefore, a symmetric equivalent mass matrix is generated. The symmetric stiffness and mass matrices significantly reduce the workload in solving the nonlinear governing equations. Benchmark validations reveal close agreement with results in the existing literature. The proposed algorithm is applicable for solving smooth shell structures undergoing large displacements and rotations within spatial domains, while maintaining unconditional stability and geometric exactness. Full article

In the assembly of spacecraft cabins, the presence of uncertain and time-varying temperature environments can induce thermal deformation in bulkheads, potentially affecting dimensional stability. Online sensing of thermal deformation is critical for mitigating such risks. However, conventional finite element methods (FEMs) rely on cascading thermal and structural analyses, which suffer from inefficiency. To address this issue, we propose a methodology that integrates a physical model with a data-driven temperature field measurement technique, demonstrated through case studies involving a spacecraft porthole bulkhead. First, leveraging the geometric invariance of the bulkhead during assembly, a purely static FE model is established offline. Second, multi-point temperature measurements combined with Kriging estimation are employed to directly reconstruct the temperature field, circumventing the computationally intensive FEM-based thermal analysis process. Finally, by utilizing the precomputed inverse stiffness matrix and performing an online conversion from temperature to equivalent forces, thermal deformation is rapidly resolved. The numerical results demonstrate that the root-mean-square errors of the predicted full-field deformation are maintained at the micron level, with an average computation time of less than 0.14 s. Furthermore, a meticulously designed experiment was conducted, where the predicted thermal displacements of several key points showed good agreement with measurements by means of a laser tracker. This research provides a promising tool to achieve digital twinning of thermal deformation states for aerospace components. Full article

This study aims to design a novel combined spherical tensegrity structure and evaluate its cushioning performance to offer a new option for a planetary exploration landing mechanism. Initially, based on the circumferential assembling method, a “class II” spherical tensegrity structure was constructed using the square frustum tensegrity unit as the basic element. Then, the equilibrium equations for the structure were formulated in accordance with the principle of virtual work to confirm the self-equilibrium of the tensegrity configuration, and the stability of the designed structure was assessed by determining the type of the tensegrity structure according to the Maxwell criterion and the character of the stiffness matrix. Subsequently, the simulation and analysis of the compressive stiffness of the structure under different parameters were carried out based on the finite element analysis method. The landing collision was simulated by using dynamic software to analyze the influence of the structure parameters on the cushioning performance. Finally, an experimental model was built to verify the above analysis, which demonstrates that the designed spherical tensegrity structure offered a large loading space and great cushioning performance. Full article

A generalized buckling solution for anisotropic laminated composite fixed–free columns under axial compression is developed using the critical stability matrix. The axial, coupling, and flexural equivalent stiffness coefficients of the anisotropic layup are determined from the generalized constitutive relationship through the static condensation of the composite stiffness matrix. The derived formula reduces down to the Euler buckling equation for isotropic and some special laminated composites. The analytical results are verified against finite element solutions for a wide range of anisotropic laminated layups yielding high accuracy. A parametric study is conducted to examine the effects of ply orientations, element thickness, finite element type, column size, and material properties. Comparisons with numerical results reveal a very high accuracy across the entire parametric profile and a linear correlation between the percentage error and a non-dimensional condensed parameter is extracted and plotted. Full article

This study investigates the novel role of yarn-level fibre hybridisation in tailoring thermomechanical properties and thermal residual stress (TRS) fields in the resin at both micro- and meso-scales of 3D orthogonal-woven flax/E-glass hybrid composites. Unlike previous studies, which primarily focus on macro-scale composite behaviour, this work integrates a two-scale homogenisation scheme. It combines microscale representative volume element (RVE) models and mesoscale repeating unit cell (RUC) models to capture the effects of hybridisation from the fibre to lamina scale. The analysis specifically examines the cooling phase from a curing temperature of 100 °C down to 20 °C, where TRS develops due to thermal expansion mismatches. Microstructures are generated employing a random sequential expansion algorithm for RVE models, while weave architecture is generated using the open-source software TexGen 3.13.1 for RUC models. Results demonstrate that yarn-level hybridisation provides a powerful strategy to balance mechanical performance, thermal stability, and residual stress control, revealing its potential for optimising composite design. Stress analysis indicates that under in-plane tensile loading, stress levels in matrix-rich regions remain below 1 MPa, while binder yarns exhibit significant stress concentration, reaching up to 8.71 MPa under shear loading. The study quantifies how varying fibre hybridisation ratios influence stiffness, thermal expansion, and stress concentrations—bridging the gap between microstructural design and macroscopic composite performance. These findings highlight the potential of yarn-level fibre hybridisation in tailoring thermomechanical properties of yarns and laminae. The study also demonstrates its effectiveness in reducing TRS in composite laminae post-manufacturing. Additionally, hybridisation allows for adjusting density requirements, making it suitable for applications where weight and thermal properties are critical. Full article

This work focuses on small bearingless permanent magnet synchronous motors (BPMSMs). In order to enhance its torque control stiffness and improve the stability of its torque and magnetic levitation force dynamic waveforms, a novel six-phase distributed single-winding BPMSM with 12 slots and 2 poles (six-phase DSW-12/2-BPMSM) is proposed and researched in this work. First, the structure and working principle of the six-phase DSW-12/2-BPMSM are analyzed. Subsequently, considering the relative permeability of permanent magnets, mathematical models of the inductance matrix, electromagnetic torque and radial magnetic levitation force are established. Then, using the finite element method (FEM), the control characteristics of the electromagnetic torque and magnetic levitation force of the six-phase DSW-12/2-BPMSM are analyzed, and the mathematical model is verified. Finally, FEM simulation analysis and comparisons are conducted with a commonly used six-phase centralized single-winding BPMSM with 6 slots and 2 poles (six-phase CSW-6/2-BPMSM). The research results show that the established mathematical model is effective and accurate compared with the six-phase CSW-6/2-BPMSM. The six-phase DSW-12/2-BPMSM has greater torque control stiffness, its dynamic waveforms of torque and radial magnetic levitation force have higher quality and stability, and the coupling degree between its torque and radial magnetic levitation force is lower. Full article
