In high-voltage transmission lines, insulators subjected to prolonged electromechanical stress are prone to zero-value defects, leading to insulation failure and posing significant risks to power grid reliability. The conventional detection method of spark gap is vulnerable to environmental interference, while the emerging electric field distribution-based techniques require complex instrumentation, limiting its applications in scenes of complex structures and atop tower climbing. To address these challenges, this study proposes an electroluminescent sensing strategy for zero-value insulator identification based on the electroluminescence of ZnS:Cu. Based on the stimulation of electrical stress, real-time monitoring of the health status of insulators was achieved by applying the composite of epoxy and ZnS:Cu onto the connection area between the insulator steel cap and the shed. Experimental results demonstrate that healthy insulators exhibit characteristic luminescence, whereas zero-value insulators show no luminescence due to a reduced drop in electrical potential. Compared with conventional detection methods requiring access of electric signals, such non-contact optical detection method offers high fault-recognition accuracy and real-time response capability within milliseconds. This work establishes a novel intelligent sensing paradigm for visualized condition monitoring of electrical equipment, demonstrating significant potential for fault diagnosis in advanced power systems. Full article

The accurate detection of electrical equipment states and faults is crucial for the reliable operation of such equipment and for maintaining the health of the overall power system. The state of power equipment can be effectively monitored through deep learning-based visual inspection methods, which provide essential information for diagnosing and predicting equipment failures. However, there are significant challenges: on the one hand, electrical equipment typically operates in complex environments, thus resulting in captured images that contain environmental noise, which significantly reduces the accuracy of state recognition based on visual perception. This, in turn, affects the comprehensiveness of the power system’s situational awareness. On the other hand, visual perception is limited to obtaining the appearance characteristics of the equipment. The lack of logical reasoning makes it difficult for purely visual analysis to conduct a deeper analysis and diagnosis of the complex equipment state. Therefore, to address these two issues, we first designed an image super-resolution reconstruction method based on the Generative Adversarial Network (GAN) to filter environmental noise. Then, the pixel information is analyzed using a deep learning-based method to obtain the spatial feature of the equipment. Finally, by constructing the logic diagram for electrical equipment clusters, we propose an interpretable fault diagnosis method that integrates the spatial features and temporal states of the electrical equipment. To verify the effectiveness of the proposed algorithm, extensive experiments are conducted on six datasets. The results demonstrate that the proposed method can achieve high accuracy in diagnosing electrical equipment faults. Full article

Motors constitute one critical part of industrial production and everyday life. The effective, timely and convenient diagnosis of motor faults is constantly required to ensure continuous and reliable operations. Infrared imaging technology, a non-invasive industrial fault diagnosis method, is usually applied to detect the equipment status in extreme environments. However, conventional Infrared thermal images inevitably show a large amount of noise interference, which affects the analysis results. In addition, each motor may only possess a small amount of fault data in practice, as collecting an infinite amount of motor data to train the diagnostic system is impossible. To overcome these problems, a novel automatic fault diagnosis system is proposed in this study. Data features are enhanced by a normalization module based on color bars first, as the same color in various infrared thermal images represent different temperatures. Then, the few-shot learning method is used to diagnose the faults of unseen electric motors. In the few-shot learning method, the minimum dataset size required to expand system universality is fifteen pieces, effectively solving the universality problem of artificial-to-natural data migration. The method saves a large amount of training data resources and the experimental training data collection. The accuracy of the fault diagnosis system achieved 98.9% on similar motor datasets and 91.8% on the dataset of motors that varied a lot from the training motor, which proves the high reliability and universality of the system. Full article

Power transformers are complex and extremely important piece of electrical equipment in a power system, playing an important role in changing voltage and transmitting electricity. Its operational status directly affects the stability and safety of power grids, and once a fault occurs, it may lead to significant economic losses and social impacts. The traditional detection methods rely on the technical level of power system operation and maintenance personnel, and are based on Dissolved Gas Analysis (DGA) technology, which analyzes the components of dissolved gases in transformer oil for preliminary fault diagnosis. However, with the increasing accuracy and intelligence requirements for transformer fault diagnosis in power grids, the DGA analysis method is no longer able to meet the requirements. Therefore, this article proposes an improved transformer fault diagnosis method based on a residual BP neural network. This method deepens the BP neural network by stacking multiple residual network modules, and fuses and expands gas feature information through an improved BP neural network. In the improved residual BP neural network, SVM is introduced to judge the extracted feature vectors at each layer, screen out feature vectors with high accuracy, and increase their weights. The feature vector with the highest cumulative weight is selected as an input for transformer fault diagnosis. This method utilizes multi-layer neural network mapping to extract gas feature information with more significant feature differences after fusion expansion, thereby effectively improving diagnostic accuracy. The experimental results show that, compared with traditional BP neural network methods, the proposed algorithm has higher accuracy in transformer fault diagnosis, with an accuracy rate of 92%, which can ensure the sustainable, normal, and safe operation of power grids. Full article

Transformers and circuit breakers are essential equipment in traction power supply systems. Once a fault occurs, it will affect the train’s regular operation and even threaten passengers’ personal safety. Therefore, it is essential to diagnose the faults of the transformers and circuit breakers of the traction power supply system. At present, power companies have made many achievements in fault diagnosis of power equipment, but there are still problems with real-time and accuracy. The Internet of Things (IoT) is a technology that connects different types of terminal devices for information exchange and communication to achieve intelligence. It includes data acquisition and transmission, information interaction, processing, and decision-making from bottom to top. It uses sensor terminals to obtain real-time status information on electrical equipment. Moreover, it conducts real-time monitoring and intelligent processing of the equipment status of the traction power supply system. In this paper, the multi-data fusion technology of the IoT combines the real-time information of electrical equipment with fault diagnosis to realize the fault diagnosis of transformers and circuit breakers. First, we built an equipment fault diagnosis system based on the multi-terminal data fusion technology of the IoT. Secondly, the transformer fault diagnosis model is established. We adopt the BP neural network algorithm based on particle swarm optimization (PSO) to realize transformer fault diagnosis and use PSO to optimize the feature subset to improve the diagnosis performance. Finally, the fault diagnosis model of the vacuum circuit breaker is established. We select the current change and time node as typical fault feature quantities and use the PSO–BP neural network algorithm to realize the fault diagnosis of the circuit breaker. Full article

As an important production equipment of the offshore platform, the operation reliability of submersible motors is critical to oil and gas production, natural gas energy supplies, and social and economic benefits, etc. In order to realize the health management and fault diagnosis of submersible motors, a motor fault-monitoring method based on multi-signal fusion is proposed. The current signals and vibration signals were selected as characteristic signals. Through fusion correlation analysis, the correlation between different signals was established to enhance the amplitude at the same frequency, so as to highlight the motor fault characteristic frequency components, reduce the difficulty of fault identification, and provide sample data for motor fault pattern identification. Furthermore, the wavelet packet node energy analysis and back propagation neural network were combined to identify the motor faults and realize the real-time monitoring of the operating status of the submersible motor. The genetic algorithm was used to optimize the parameters of the neural network model to improve the accuracy of motor fault pattern recognition. The results show that the combination of multi-signal fusion monitoring and an artificial intelligence algorithm can diagnose motor fault types with high confidence. This research originally proposed the fusion correlation spectrum technology, which solved the shortcomings of the small amplitude and complex composition of the single signal spectrum components in the fault diagnosis and improved the reliability of the fault diagnosis. It further combined the neural network to realize the automatic monitoring and intelligent diagnosis of submersible motors, which has certain application value and inspiration in the field of electrical equipment intelligent monitoring. Full article

Power transformer bushings withstand great electrical and mechanical stress during high voltage and high current working conditions. Sealing failure poses a great threat to the long-term and reliable operation of the bushing and power transformer; however, the criterion to evaluate the sealing status of a bushing caused by mechanical problems is still lacking. In this paper, a transformer bushing model is established to gain theoretical insight into the relationship between temperature and pressure of a compact multilayer bushing. To evaluate the bushing mechanical status, different sealing conditions are tested based on the temperature and pressure monitoring within the physical 110 kV bushing. The results show that mechanical sealing failure can be diagnosed when the fluctuation of the oil pressure value exceeds the theoretical curve in steady state by 3 kPa. With different reliability coefficients, gas leakage and oil leakage are available to be further determined. The primary and auxiliary criteria based on oil pressure and its gradient are proposed to evaluate comprehensively the actual sealing condition of the bushing, and a wireless oil pressure module is developed at the bottom valve, which is quite beneficial to field online application. It is promising to extend the online mechanical monitoring and diagnosis to oil-immersed power equipment. Full article

Motor failure is one of the biggest problems in the safe and reliable operation of large mechanical equipment such as wind power equipment, electric vehicles, and computer numerical control machines. Fault diagnosis is a method to ensure the safe operation of motor equipment. This research proposes an automatic fault diagnosis system combined with variational mode decomposition (VMD) and residual neural network 101 (ResNet101). This method unifies the pre-analysis, feature extraction, and health status recognition of motor fault signals under one framework to realize end-to-end intelligent fault diagnosis. Research data are used to compare the performance of the three models through a data set released by the Federal University of Rio de Janeiro (UFRJ). VMD is a non-recursive adaptive signal decomposition method that is suitable for processing the vibration signals of motor equipment under variable working conditions. Applied to bearing fault diagnosis, high-dimensional fault features are extracted. Deep learning shows an absolute advantage in the field of fault diagnosis with its powerful feature extraction capabilities. ResNet101 is used to build a model of motor fault diagnosis. The method of using ResNet101 for image feature learning can extract features for each image block of the image and give full play to the advantages of deep learning to obtain accurate results. Through the three links of signal acquisition, feature extraction, and fault identification and prediction, a mechanical intelligent fault diagnosis system is established to identify the healthy or faulty state of a motor. The experimental results show that this method can accurately identify six common motor faults, and the prediction accuracy rate is 94%. Thus, this work provides a more effective method for motor fault diagnosis that has a wide range of application prospects in fault diagnosis engineering. Full article

Distribution automation (DA) and Internet of Things (IoT) all need the topology information of power distribution network to support some applications, such as fault diagnosis, network reconfiguration and optimization. IEC 61850 is a general communication model and standard for information exchange between intelligent electronic devices (IEDs). However, it has no mechanism for feeder topology information exchange. This paper solves this problem by developing the corresponding information model. Firstly, a feeder model is established as a container of the equipment along a distribution line. Secondly, logical models, such as terminal and connection nodes, are added to describe the physical connection relationship between the electrical equipment. Taking a circuit breaker as an example, this paper introduces how to add the terminal attribute to an existing logical node (XCBR). The physical connection between the circuit breaker and other electrical equipment is described by adding the logic node LCNN. Then, a new logical node LTPN is added to describe the logical connection between the devices. A new logical node, FTPA, is added to describe the status of the topology analysis and the topology results. Based on these new logical nodes, this paper proposes the mechanism of topology information exchange between IEDs. Three IEDs and the IEEE 13-node model are used to build an experimental environment. The result verifies the effectiveness of this method. More distributed applications can be used to test the validity and interoperability of the proposed model. Full article

The recognition of the creepage discharge development process of oil–paper insulation under AC–DC combined voltage is the basis for fault monitoring and diagnosis of converter transformers; however, only a few related studies are available. In this study, the AC–DC combined voltage with a ratio of 1:1 was used to develop a recognition method for the creepage discharge development process of an oil–paper insulation under a cylinder–plate electrode structure. First, the pulse current method was used to collect the discharge signals in the creepage discharge development process. Then, 24 characteristic parameters were extracted from four types of creepage discharge characteristic spectra after dimensionality reduction. Finally, based on the online sequential extreme learning machine (OS-ELM) algorithm, these characteristic parameters were used to recognize the development stage of the creepage discharge of the oil–paper insulation. The results showed that when the size of the sample training set used in the OS-ELM algorithm is close to the number of hidden layer neurons, a high recognition accuracy can be obtained, and the type of activation function has little influence on the recognition accuracy. Four stages of the creepage discharge development process were recognized using the OS-ELM algorithm; the trend was the same as that of the characteristic parameters of the entire creepage discharge development process. The recognition accuracy was 91.4%. The algorithm has a high computing speed and high accuracy and can train data in batches. Therefore, it can be widely used in the field of online monitoring and evaluation of electrical equipment status. Full article

Faults in electrical facilities may cause severe damages, such as the electrocution of maintenance personnel, which could be fatal, or a power outage. To detect electrical faults safely, electricians disconnect the power or use heavy equipment during the procedure, thereby interrupting the power supply and wasting time and money. Therefore, detecting faults with remote approaches has become important in the sustainable maintenance of electrical facilities. With technological advances, methodologies for machine diagnostics have evolved from manual procedures to vibration-based signal analysis. Although vibration-based prognostics have shown fine results, various limitations remain, such as the necessity of direct contact, inability to detect heat deterioration, contamination with noise signals, and high computation costs. For sustainable and reliable operation, an infrared thermal (IRT) image detection method is proposed in this work. The IRT image technique is used in various engineering fields for diagnosis because of its non-contact, safe, and highly reliable heat detection technology. To explore the possibility of using the IRT image-based fault detection approach, object detection algorithms (Faster R-CNN; Faster Region-based Convolutional Neural Network, YOLOv3; You Only Look Once version 3) are trained using 16,843 IRT images from power distribution facilities. A thermal camera expert from Korea Hydro & Nuclear Power Corporation (KHNP) takes pictures of the facilities regarding various conditions, such as the background of the image, surface status of the objects, and weather conditions. The detected objects are diagnosed through a thermal intensity area analysis (TIAA). The faster R-CNN approach shows better accuracy, with a 63.9% mean average precision (mAP) compared with a 49.4% mAP for YOLOv3. Hence, in this study, the Faster R-CNN model is selected for remote fault detection in electrical facilities. Full article

The measurement and analysis of partial discharges (PD) are like medical examinations, such as Electrocardiogram (ECG), in which there are preestablished criteria. However, each patient will present his particularities that will not necessarily imply his condemnation. The consolidated method for PD processing has high qualifications in the statistical analysis of insulation status of electric generators. However, although the IEEE 1434 standard has well-established standards, it will not always be simple to classify signals obtained in the measurement of the hydro generator coupler due to variations in the same type of PD incidence that may occur as a result of the uniqueness of each machine subject to staff evaluation. In order to streamline the machine diagnostic process, a tool is suggested in this article that will provide this signal classification feature. These measurements will be established in groups that represent each known form of partial discharge established by the literature. It was combined with supervised and unsupervised techniques to create a hybrid method that identified the patterns and classified the measurement signals, with a high degree of precision. This paper proposes the use of data-mining techniques based on clustering to group the characteristic patterns of PD in hydro generators, defined in standards. Then, random forest decision trees were trained to classify cases from new measurements. A comparative analysis was performed among eight clustering algorithms and random forest for choosing which is the superior combination to make a better classification of the equipment diagnosis. R² was used for assessing the data trend. Full article

With the increasing application of unmanned aerial vehicles (UAVs) to the inspection of high-voltage overhead transmission lines, the study of the safety distance between drones and wires has received extensive attention. The determination of the safety distance between the UAV and the transmission line is of great significance to improve the reliability of the inspection operation and ensure the safe and stable operation of the power grid and inspection equipment. Since there is no quantitative data support for the safety distance of overhead transmission lines in UAV patrol, it is impossible to provide accurate navigation information for UAV safe obstacle avoidance. This paper proposes a mathematical model based on a multi-sensor data fusion algorithm. The safety distance of the line drone is diagnosed. In these tasks, firstly, the physical model of the UAV in the complex electromagnetic field is established to determine the influence law of the UAV on the electric field distortion and analyze the maximum electric and magnetic field strength that the UAV can withstand. Then, based on the main factors affecting the UAV such as the maximum wind speed, inspection speed, positioning error, and the size of the drone, the adaptive weighted fusion algorithm is used to perform first-level data fusion on the homogeneous sensor data. Then, based on the improved evidence, the theory performs secondary fusion on the combined heterogeneous sensor data. According to the final processing result and the type of proposition set, we diagnose the current safety status of the drone to achieve an adaptive adjustment of the safety distance threshold. Lastly, actual measurement data is used to verify the mathematical model. The experimental results show that the mathematical model can accurately identify the safety status of the drone and adaptively adjust the safety distance according to the diagnosis result and surrounding environment information. Full article

Partial discharges (PD) measurement provides valuable information for the condition assessment of the insulation status of high-voltage (HV) electrical installations. During the last three decades, several PD sensors and measuring techniques have been developed to perform accurate diagnostics when PD measurements are carried out on-site and on-line. For utilities, the most attractive characteristics of on-line measurements are that once the sensors are installed in the grid, the electrical service is uninterrupted and that electrical systems are tested in real operating conditions. In medium-voltage (MV) and HV installations, one of the critical points where an insulation defect can occur is inside metal-clad switchgears (including the cable terminals connected to them). Thus, this kind of equipment is increasingly being monitored to carry out proper maintenance based on their condition. This paper presents a study concerning the application of different electromagnetic measuring techniques (compliant with IEC 62478 and IEC 60270 standards), together with the use of suitable sensors, which enable the evaluation of the insulation condition mainly in MV switchgears. The main scope is to give a general overview about appropriate types of electromagnetic measuring methods and sensors to be applied, while considering the level of detail and accuracy in the diagnosis and the particular fail-save requirements of the electrical installations where the switchgears are located. Full article
