Wireless power transfer (WPT) is increasingly used in smart manufacturing, unmanned platforms, and contactless power-supply applications. However, weak coupling, load-dependent impedance drift, and spatial misalignment can shift the resonant condition, leading to unstable output voltage and reduced transfer efficiency. This paper proposes a constant-voltage WPT method that combines a non-uniform winding coupler, parasitic coils, and dynamic capacitor compensation. A composite magnetic coupler with dense outer windings, loose inner windings, and parasitic coils is first developed, and a region-based electromagnetic model is established to characterise self-inductance, mutual inductance, and coupling coefficients. An improved LCC-S compensation network with a dynamic capacitor compensation matrix is then derived to keep the system close to resonant operation at the nominal 85 kHz operating point under load variation and coil-displacement-induced coupling changes. A zero-voltage-switching-angle tracking method with mutual-inductance correction is further introduced to compensate for phase deviation and maintain soft-switching operation through limited switching-frequency adjustment. Experimental validation demonstrates that the system maintains a stable constant-voltage output across a load range of 20–50 Ω and under 5 cm lateral and longitudinal offsets. The measured efficiency remains above 89% and reaches 93.7% under the optimal coupling and load-matching condition. Full article

Direct grid-connected wireless charging based on direct AC–AC conversion is attractive for electric vehicles (EVs) because it can reduce power conversion stages and improve charger compactness. In matrix-converter-based wireless power transfer (WPT) systems, the grid-frequency AC voltage can be directly converted into high-frequency AC voltage without using bulky DC-link electrolytic capacitors. However, the removal of the intermediate energy-storage stage also makes the EV wireless charger more sensitive to grid-voltage fluctuation. For an LCC-S compensated WPT system, the voltage-source output characteristic makes the charging-side voltage sensitive to grid-voltage disturbance, resulting in severe MC output-current and battery charging-current overshoot. This transient overcurrent may threaten both the power converter and the EV battery charging process. In this paper, a dual-frequency state-space model is developed for the matrix-converter-based electrolytic-capacitor-less LCC-S WPT system to analyze the disturbance propagation from the grid side to the high-frequency resonant stage and the EV battery side. Based on the model, the current-overshoot suppression capability and bandwidth limitation of the conventional dual closed-loop control strategy are investigated. To further enhance transient current protection, a grid-voltage feedforward strategy is proposed to compensate for the disturbance before severe current overshoot is formed. Finally, experimental results verify that the proposed method effectively suppresses the MC output-current and battery charging-current overshoot under grid-voltage fluctuation, thereby improving the grid-disturbance resilience and dynamic safety of direct grid-connected EV wireless charging systems. Full article

Decarbonizing heavy-duty road transport requires comparing zero-emission options to guide infrastructure investments along strategic corridors. This study develops a scenario-based techno-economic model to evaluate hydrogen fuel cell trucks (HFCTs) and battery electric trucks supported by dynamic wireless power transfer (DWPT) on a 100 km segment of Italy’s A4 motorway in 2030 and 2050 scenarios. The framework integrates traffic flows, vehicle archetypes, infrastructure sizing, and end-to-end energy chains (power-to-hydrogen-to-wheel for hydrogen and grid-to-wheel for WPT) to estimate capital and operating costs, efficiencies, and energy demand. Results show that hydrogen refueling infrastructure requires lower initial investment (approximately €60 million CAPEX and €20 million annual OPEX) than wireless charging systems (€80 million CAPEX and €15 million OPEX). However, WPT achieves significantly higher grid-to-wheel efficiency (96% vs. 62%) and lower per-vehicle energy demand (18 MWh/year vs. 25 MWh/year). These findings highlight a fundamental trade-off: hydrogen solutions offer operational flexibility and are better suited to long-haul or low-density contexts, while WPT systems are more efficient and become increasingly competitive in high-traffic corridors with high infrastructure utilization. Overall, the results suggest that no single technology universally dominates and that optimal deployment depends on traffic density, infrastructure usage, and system integration. A combined implementation of hydrogen and wireless charging technologies may provide the most effective pathway to balance efficiency, flexibility, and cost in future heavy-duty transport systems. Full article

Constant current/voltage (CC/CV) output of wireless power transfer (WPT) systems deviates due to increased load resistance during charging and mutual inductance variations caused by misalignment. Dynamically regulating the DC input voltage can maintain a stable output at the preset value, and predicting the mutual inductance and load resistance can help monitor charging status. However, joint prediction of characteristics and regulation degree can be nonlinear and complicated. This work proposes a data-driven method for characteristic prediction and output optimization for WPT systems based on the current waveform from only the transmitter side. A Multi-Scale Parallel Convolutional (MSPC) neural network is applied to simultaneously predict the load resistance, mutual inductance, output deviation factor and regulation coefficient. By leveraging its multi-scale feature extraction capabilities, it can accurately estimate the aforementioned parameters based on only the AC current waveform at the transmitter side. To improve the model’s generalizability under practical conditions, transfer learning (TL) is utilized to minimize the discrepancy between simulated and physical data. Finally, a 140 W prototype of the series-series (SS)-compensated WPT system is built to validate the effectiveness of the proposed method. Full article

Microwave wireless power transfer (MWPT) is a promising technology for powering dedicated industrial Internet of Things (IoT) devices, enabling battery-free operation. However, in realistic MWPT deployments, the received RF signals fluctuate drastically due to varying transmission distances and multipath fading. Additionally, the equivalent impedance of sensor nodes varies significantly during duty cycles, shifting between a low-resistance active state and a high-resistance sleep state. Consequently, maintaining high rectification efficiency under these dynamic conditions remains a critical challenge. This paper proposes a high-efficiency rectifier with a wide input power and load range based on the suppression of second and third harmonics. The rectifier adopts a dual-diode parallel configuration. By leveraging the impedance compensation characteristics of two short-circuited stubs with distinct electrical lengths, it simultaneously achieves fundamental-frequency impedance matching and harmonic suppression without the need for an additional matching network. Validated through theoretical derivation, simulation analysis, and physical prototype testing, the proposed 2.45 GHz rectifier realizes high-efficiency rectification over a wide dynamic range. Experimental results demonstrate that the power dynamic range reaches 10 dB when the rectification efficiency exceeds 70%, and extends to 17 dB when the efficiency is above 60%. Furthermore, the rectification efficiency is insensitive to load variations (100–1200 Ω), making it highly suitable for powering wireless sensor nodes with varying operating modes in complex electromagnetic environments. Full article

Little existing work addresses the joint design of time slot allocation and power splitting ratio optimization in simultaneous wireless information and power transfer (SWIPT)-enabled wireless sensor networks (WSNs). To fill this gap, this paper proposes a novel energy-sustainable framework termed ETAPS that co-optimizes time slot allocation and power splitting ratio for SWIPT-enabled WSNs. A dedicated frame structure is designed that partitions each cluster member (CM) into four operational modes for slot scheduling, toward conflict-free and coordinated resource allocation among CMs. A dynamic power splitting strategy is further developed to adaptively refine slot allocation for CMs and derive the optimal power splitting ratio for the cluster head (CH). Comprehensive numerical simulations are performed to validate the proposed scheme. The results demonstrate that ETAPS maintains effective energy sustainability even under limited energy input from the energy access point (EAP). When the EAP provides a sufficient energy supply, the optimal power splitting ratio converges to 0.9. Moreover, under sufficient transmit power at CMs, ETAPS adaptively allocates transmission time from CMs to the CH by setting the optimal power splitting ratio to 0.6. Full article

As Intelligent Transportation Systems (ITS) transition towards automated ecosystems, the deployment of advanced wireless charging technologies becomes a critical infrastructure requirement. Central to the management of these networks is the Open Charge Point Protocol (OCPP), which ensures interoperability across diverse hardware vendors. However, the reliance on digital communication for power transfer introduces significant cybersecurity vulnerabilities. This paper presents a methodology for evaluating the impact of cyber-threats on urban transport services, with a specific focus on the communication layers that support these Advanced Wireless Power Transfer (WPT) environments. Utilising Stochastic Petri net (SPN) ontology, we model the operational states of an Electric Vehicle (EV) service—including the activation and the arrival phases—to quantify how protocol-level vulnerabilities affect service reliability. We introduce an Extended Vulnerability List (EVL) and analyse two distinct scenarios: a public transport service and a weather forecasting integration. Our results demonstrate that as wireless charging moves towards standardization, the security of the OCPP-based backbone is a fundamental necessity for preventing service disruption. The proposed assessment framework provides a roadmap for securing the next generation of dynamic wireless charging infrastructures against evolving cyber-physical threats. Full article

Dynamic wireless charging (DWC) of electric vehicles (EVs) offers a promising solution to mitigate range anxiety and enhance the feasibility of electrified transportation; however, achieving optimal power transfer requires precise alignment between the primary coil embedded in the roadway and the secondary coil mounted on the vehicle. In practice, lateral misalignment (LTM) frequently occurs, leading to reduced efficiency. Although conventional controllers can partially compensate for these losses, their performance degrades under significant misalignment, resulting in overshoot and steady-state error (SSE). To overcome these limitations, this paper proposes a model predictive control (MPC)-based approach to mitigate the effects of LTM and restore efficient power transfer. A comparative study between the proposed MPC and a conventional proportional–integral (PI) controller is conducted to assess performance and suitability. The MPC utilizes an optimization framework to determine optimal control actions over a prediction horizon, thereby minimizing SSE and reducing overshoot under varying misalignment conditions. The effectiveness of the proposed method is validated through MATLAB/Simulink simulations and experimental testing. The results demonstrate that the MPC maintains stable operation over a wide LTM range, achieving a maximum power transfer efficiency of 93% at zero misalignment, which decreases to 83% at severe misalignment (LTM = 0.5). Compared to the PI controller, the MPC improves average efficiency by approximately 8–12%, leading to improved robustness and smoother dynamic response. These results confirm the effectiveness of the proposed MPC approach in maintaining high efficiency and stable operation in misaligned DWC systems. Full article

This paper addresses the problem of throughput utility maximization in a non-orthogonal multiple access (NOMA)-enabled wireless power transfer mobile edge computing (WPT-MEC) network with dynamic task arrivals and user cooperation. To promote fairness and effectively handle random task arrivals and time-varying channels, we model the system utility as a nonlinear function of time-averaged throughput. We then formulate a stochastic optimization problem aimed at maximizing utility while strictly maintaining sensor queue stability. By leveraging the Lyapunov optimization framework, the long-term network-wide utility maximization is decomposed into efficient, slot-wise convex subproblems that operate online without requiring prior knowledge of future task arrivals or channel states. We develop a Dynamic User Cooperation Throughput Maximization (DUCTM) algorithm that enables adaptive resource allocation and cooperative computation offloading in an online manner. Theoretical analysis establishes a provable $\left[O\right(1/V),O(V\left)\right]$ trade-off between utility optimality and queue backlog. Extensive simulations demonstrate that our approach consistently outperforms baseline methods, providing robust and stable performance even under bursty traffic and highly dynamic environmental conditions. Full article

This study proposes a metasurface integrated reconfigurable unit-cell coupler designed for wireless power transfer (WPT) applications in unmanned aerial vehicles (UAVs). In near-field capacitive WPT systems, flexible UAV charging is restricted by rotational misalignment, which causes null power points (NPP) where energy transfer is suppressed. To address this, the proposed model emulates 1-bit digital coding states through Symmetric Excitation (SE) and Cross-Excitation (CE) states. Since precise unit-cell characterization is a prerequisite for array expansion, this research focuses on meta-atom-level analysis at 6.78 MHz with a deep sub-wavelength profile (0.002λ). Characterized through 3D full-wave analysis, the unit-cell achieves peak transmission coefficients of 0.945 for SE State and 0.903 for CE State. Crucially, these states exhibit complementary extinction angles at 90° and 45°, respectively, ensuring that the NPP of one state is effectively bypassed by the high transmissivity of the other. This dynamic switching between coding states maintains stable power transfer across a full 360° rotation, providing a technical foundation for scalable, intelligent metasurface-based wireless charging platforms. Full article

Wireless Power Transfer (WPT) systems often face performance limitations due to the right-half-plane zero (RHPz) in conventional constant-current-fed Buck converters, which can lead to negative undershoot and a slow dynamic response. In this paper, we propose a Buck converter topology with an additional active switch in series with the input capacitor. This mechanism-level modification effectively mitigates the RHPz. The operating modes, steady-state behavior, and small-signal characteristics of the converter are systematically analyzed. A tailored control strategy enables independent regulation of input and output capacitor charging times, supporting improved voltage regulation. Experimental results indicate that the proposed converter reduces settling time by approximately 83%, substantially suppresses negative undershoot, and maintains stable voltage regulation under reference step changes and load transients. The converter maintains high efficiency while demonstrating improved dynamic performance and stability relative to conventional topologies, providing a practical approach for advanced WPT applications. Full article

This paper presents an efficient control strategy for a wireless power transfer (WPT) system based on a series–parallel (SP) compensation topology, specifically optimized to enhance efficiency under a wide load range, including light-load conditions. The system employs a half-bridge inverter on the transmitter side and a semi-active rectifier (SAR) on the receiver side to achieve zero phase angle (ZPA) operation. Zero voltage switching (ZVS) is achieved by synchronizing and phase-adjusting the SAR switching signals with the rectified input voltage, thereby effectively reducing switching losses. Furthermore, a perturbation and observation (P&O)-based variable duty cycle (VDC) control is applied to the half-bridge inverter to dynamically optimize the light-load efficiency, thereby enhancing efficiency when conventional fixed duty methods underperform. The proposed control strategy is implemented using a TI TMS320F28335 digital signal processor. Experimental results demonstrate that the method significantly improves system efficiency at light loads while maintaining high performance at heavy loads, verifying its practical feasibility for diverse WPT applications. Full article

Dynamic wireless power transfer can reduce electric vehicles’ charging downtime and range anxiety, but its benefits depend on route characteristics and system design. This work develops an integrated numerical framework combining (i) route-specific drive-cycle analysis, (ii) identification of candidate charging segments based on speed, stops and slope constraints, (iii) a physics-informed inductive wireless power transfer model and (iv) a Matlab/Simulink vehicle energy model to quantify energy demand, transferred energy and state-of-charge evolution. Two vehicle types (a passenger light-duty vehicle and a light commercial van) and multiple Lisbon Metropolitan Area routes are analyzed, including commuting, ride-hailing and urban logistics operations. Results show that low-speed, stop-rich urban corridors achieve the highest transfer rates (typically 0.4 kWh/km and over 2 kWh for more than 15 stops in the analyzed cases), whereas expressway deployments are much less effective (down to 0.1 kWh/km and 0.5 kWh below 5 stops) unless congestion lowers average speeds. The proposed workflow provides a replicable basis to identify candidate segments and to size wireless power transfer and corridor length for city-scale deployment scenarios. Full article

Dynamic Wireless Power Transfer (DWPT) represents a promising solution to advance sustainable electric mobility by reducing vehicle downtime, extending driving range, and mitigating the need for battery oversizing. However, the lack of integrated and flexible experimental testbeds still limits the validation of emerging technologies. This paper presents DEXTER (Development of an Enhanced eXperimental proTotype of wirEless chargeR), a 1:2-scale open platform specifically designed for research on DWPT systems. The setup integrates a three-axis motion control for coil misalignments and trajectory emulation, digitally regulated TX/RX converters, a programmable battery emulator, and electromagnetic shielding coils equipped with field probes. A MATLAB-based interface enables automated testing and Hardware-in-the-Loop (HiL) integration. By combining modularity, scalability, and reproducibility, DEXTER provides a comprehensive framework for experimental optimization of power electronics and electromagnetic design while ensuring compliance with international safety standards. The case studies analyzed here demonstrate the capability of such a platform to validate and optimize the DWPT design choices, checking their impact on the overall performance of these systems. The platform constitutes a reference environment for both academia and industry, supporting the development of next-generation wireless charging systems and contributing to the sustainability and reliability of future electric mobility infrastructures. Full article
