Search Results (28)

Electric motors play a decisive role in electric vehicles by converting electrical energy into mechanical motion across various drivetrain components. However, failures in these motors can interrupt the motor function, with approximately 40% of these failures stemming from bearing issues. Key contributors to bearing degradation include shaft voltage, bearing current, and electric discharge material spalling current, especially in motors powered by inverters or variable frequency drives. This review explores the tribological and vibrational aspects of bearing currents, analyzing their mechanisms and influence on electric motor performance. It addresses the challenges faced by electric vehicles, such as high-speed operation, elevated temperatures, electrical conductivity, and energy efficiency. This study investigates the origins of bearing currents, damage linked to shaft voltage and electric discharge material spalling current, and the effects of lubricant properties on bearing functionality. Moreover, it covers various methods for measuring shaft voltage and bearing current, as well as strategies to alleviate the adverse impacts of bearing currents. This comprehensive analysis aims to shed light on the detrimental effects of bearing currents on the performance and lifespan of electric motors in electric vehicles, emphasizing the importance of tribological considerations for reliable operation and durability. The aim of this study is to address the engineering problem of bearing failure in inverter-fed EV motors by integrating electrical, tribological, and lubrication perspectives. The novelty lies in proposing a conceptual link between lubricant breakdown and damage morphology to guide mitigation strategies. The study tasks include literature review, analysis of bearing current mechanisms and diagnostics, and identification of technological trends. The findings provide insights into lubricant properties and diagnostic approaches that can support industrial solutions. Full article

Compared to traditional dense asphalt concrete mixtures, stone mastic asphalt (SMA) generally offers superior performance in terms of its mechanical resistance and extended pavement lifespan. Focusing on the Norwegian scenario, this laboratory-based study investigated the durability of SMA considering the influence of the aggregate shape and petrography. The rock aggregates were classified according to three different-shaped refinement stages involving vertical shaft impact crushing. Further, the aggregates were sourced from three distinct locations (Jelsa, Tau and Dirdal) characterized by different petrographic origins: granodiorite, quartz diorite and granite, respectively. Two mixtures with maximum aggregate sizes of 16 mm (SMA 16) and 11 mm (SMA 11) were designed according to Norwegian standards and investigated in terms of their durability performance. In this regard, two main functional tests were performed for the asphalt mixture, namely resistance against permanent deformation and abrasion by studded tyres, and one for the asphalt mortar, namely water sensitivity. Overall, the best test results were related to the aggregates sourced from Jelsa and Tau, thus highlighting that the geological origin exerts a major impact on SMA’s durability performance. On the other hand, the different aggregate shapes related to the crushing refinement treatments seem to play an effective but secondary role. Full article

Double-suction centrifugal pumps are extensively employed in industrial applications owing to their high efficiency, low vibration, superior cavitation resistance, and operational durability. This study analyzes how impeller oblique cutting angles (0°, 6°, 9°, 12°) affect a double-suction pump at a fixed 4% trimming ratio and constant average post-trim diameter. Numerical simulations and tests reveal that under low-flow (0.7Q_d) and design-flow conditions, the flat-cut (0°) minimizes reflux ratio and maximizes efficiency by aligning blade outlet flow with the mainstream. Increasing oblique cutting angles disrupts this alignment, elevating reflux and reducing efficiency. Conversely, at high flow (1.3Q_d), the 12° bevel optimizes outlet flow, achieving peak efficiency. Pressure pulsation at the volute tongue (P11) peaks at the blade-passing frequency, with amplitudes significantly higher for 9°/12° bevels than for 0°/6°. The flat-cut suppresses wake vortices and static–rotor interaction, but oblique cutting angle choice critically influences shaft-frequency pulsation. Entropy analysis identifies the volute as the primary loss source. Larger oblique cutting angles intensify wall effects, increasing total entropy; pump chamber losses rise most sharply due to worsened outlet velocity non-uniformity and turbulent dissipation. The flat-cut yields minimal entropy at Q_d. These findings provide a basis for tailoring impeller trimming to specific operational requirements. Furthermore, the systematic analysis provides critical guidance for impeller trimming strategies in other double-suction pumps and pumps as turbines in micro hydropower plants. Full article

Persistently and reliably harvesting wind energy to power intelligent online monitoring devices for transmission lines promotes the intelligent and sustainable development of the Internet of Things. Current small-scale wind-energy-harvesting devices, relying on a single energy conversion principle, face challenges such as low efficiency and poor performance at low wind speeds. This paper presents a coaxial rotating non-contact coupling transducer structure, and its optimization methods have been studied, which are based on electret electrostatic induction and magnetically actuated piezoelectric conversion. By analyzing the principles of alternating positive–negative unipolar electret components and constructing a finite element model, improved output capacity is demonstrated. The electric signals from electret components are more suitable for inferring the shaft and wind speeds compared to piezoelectric components. The piezoelectric components utilize frequency up-conversion theory to enhance output while addressing the low power density of the electrostatic components. Experimental results indicate that the proposed structure operates reliably at rotational speeds of 100–700 rpm, achieving a maximum output power of 6.742 mW. The output power of the electret electrostatic component’s electrodes nearly doubled, with the signal positively correlated to rotation speed. The optimized structure of the magnetically actuated piezoelectric component achieved a power increase of 11.51% at four excitations and 250 rpm. This study provides a new design approach for more durable and efficient small-scale wind-energy-harvesting devices, as well as for achieving integrated measurement and supply. Full article

The present paper deals with a review on bearing currents in electrical machines, with major emphasis on mechanisms, impacts, and mitigation strategies. High-frequency common-mode voltages from the inverter-driven system have been found to be the main reason for bearing current leading to motor bearing degradation and eventual failure. This paper deals with bearing currents—electrical discharge machining (EDM) currents, circulating bearing currents, and rotor-to-ground bearing currents—and the various methods of their generation and effects that are harmful to the bearings and lubricants of a motor. Mitigation techniques, among which the following have been taken into account, are studied in this context: the optimization of PWM modulation, and the use of shaft grounding brushes, insulated bearings, and passive or active filters. Finally, advantages, limitations, and implementation challenges are discussed. A review comparing three-phase and dual three-phase inverters showed that, due to the increased degree of freedom in modulation strategies, it is possible to eliminate common-mode voltages through active modulation techniques. Such added flexibility will reduce the risk of bearing currents effectively. It also highlights future research directions in bearing current suppression, including the development of multi-phase motor systems, real-time monitoring technologies with artificial intelligence, and the use of new insulation materials for the enhancement of bearing reliability. The results obtained should guide future research and engineering practices in suppressing bearing currents to improve motor durability with high performance. Full article

This study presents a method for determining the optimal gear ratio in electric trains by examining the effects of motor efficiency, wheel wear, and relative damage to the input and output shafts of the reduction gear. In electric trains, reduction gears and wheels are critical for converting the driving motor’s torque and determining the motor’s operational point, which in turn affects efficiency and durability. Over time, wheel wear from regular use and periodic profiling reduces the wheel radius, causing an effective increase in the gear ratio, which impacts the motor efficiency and load distribution across drivetrain components. This study models the dynamic behavior of the vehicle’s drivetrain system using MATLAB/Simulink and incorporates real-world data on wheel wear to address the problem. Through simulations with varying gear ratios, it analyzes changes in motor efficiency and uses Miner’s rule to assess the relative damage on the reduction gear’s input and output shafts. The results enable the identification of a gear ratio that balances motor efficiency and reduces cumulative fatigue damage, which is especially important for maintaining long-term drivetrain durability. This approach provides a systematic way to enhance the overall performance and lifespan of electric train systems by selecting a gear ratio that optimally aligns efficiency and durability. Full article

In addressing the challenges of high labor intensity, cost, and potential mechanical damage to banana fruit in orchards, this study presents the design of a banana bunch transport device featuring a lifting mechanism and an automatic fruit shaft bottom-fixing system. The device is tailored to the planting and morphological characteristics of banana bunches, aiming for efficient, low-loss, and labor-saving mechanized transport. Key design considerations included the anti-overturning mechanism and the lifting system based on transportation conditions and the physical dimensions of banana bunches. A dynamic simulation was conducted to analyze the angular velocity and acceleration during the initial conveying stages, forming the basis for the fruit shaft bottom-fixation mechanism. A novel horizontal multi-point scanning method was developed to accurately identify and secure the fruit shaft bottom, complemented by an automated control system. Experimental results showed a 95.83% success rate in identification and fixation, validated by field trials that confirmed the necessity and stability of the fixation mechanism. To enhance the durability of the fruit shaft bottom-fixation mechanism, a multi-factor test was conducted, optimizing the device’s maximum travel speed and minimizing the banana bunch’s oscillation angle. Field tests showed an oscillation angle of 8.961°, closely matching the simulated result of 9.526°, demonstrating the reliability of the response surface analysis model. This study offers a practical and efficient solution for banana bunch transport in orchards, showcasing significant practical value and potential for wider adoption. Full article

This article presents the results of a study of oil lip seals with a modified outer lip layer texture. In the first step, the interaction of flat rubber samples with different surface layer textures with the steel surface was recognised. Measurements of the friction coefficient of flat samples with different surface layer textures were carried out. The next step was an experimental study of rotating shaft lip seals in standard and prototype versions. The contact width of the sealing lip before and after durability tests was examined, and the clamping force of the lip on the shaft before and after durability tests was measured. The final step was to create a FEM model of the interaction of the sealing ring lip with the shaft to determine the lip seal pressure and width. These calculations, in cooperation with the previously determined friction coefficient and porosity of the lip seal, allowed the calculation of the friction torque. The solution proposed in this article was intended to be simple and viable for industrial applications. Satisfactory results were achieved with prototype rings in terms of reduced resistance to movement, tightness, and durability. Full article

The possibility of increasing the durability of steel pins working against bronze bushings through plasma–electrolytic nitrocarburizing of the surface of medium carbon steel is shown. The phase composition, microhardness, morphology, and surface roughness were studied. Tribological tests were carried out under dry friction conditions according to the shaft-pad scheme. It has been established that plasma–electrolytic nitrocarburizing of the surface of medium carbon steel at a temperature of 700 °C for 5 min leads to a decrease in the friction coefficient by 2.3 times, the weight wear of steel by 24.9 times, and the wear of the bronze counterbody by 5.9 times. At the same time, the contact stiffness increases by 2.6 times. Type of wear: wear with dry friction and plastic contact. The changes in tribological characteristics are associated with the high hardness of the hardened steel surface combined with the effect of dispersed nitrides and iron carbonitrides. Full article

Industrial materials are materials used in the manufacture of products such as durable machines and equipment. For this reason, industrial materials have importance in many aspects of human life, including social, environmental, and technological elements, and require further attention during the production process. Optimization and modeling play an important role in achieving better results in machining operations, according to common knowledge. As a widely preferred material in the automotive sector, hardened AISI 4140 is a significant base material for shaft, gear, and bearing parts, thanks to its remarkable features such as hardness and toughness. However, such properties adversely affect the machining performance of this material system, due to vibrations inducing quick tool wear and poor surface quality during cutting operations. The main focus of this study is to determine the effect of parameter levels (three levels of cutting speed, feed, and cutting depth) on vibrations, surface roughness, and acoustic emissions during dry turning operation. A fuzzy inference system-based machine learning approach was utilized to predict the responses. According to the obtained findings, fuzzy logic predicts surface roughness (88%), vibration (86%), and acoustic emission (87%) values with high accuracy. The outcome of this study is expected to make a contribution to the literature showing the impact of turning conditions on the machining characteristics of industrially important materials. Full article

The technology of producing threads, especially in materials that are difficult to cut, is a rare subject of research and scientific publications. The requirements for the production of these elements apply not only to the geometry, but also to the quality of the surface obtained. This is particularly important in the aviation industry, where the durability of the threaded connection affects passenger safety. Due to the design of the thread, the quality of its surface is assessed visually in industrial practice. The authors of this study decided to examine the surface topography of external threads made by turning on Inconel 718 shafts in order to confirm the visual evaluation, as well as to investigate the influence of such factors as cutting speed, turning direction and type of profile. Three types of contours were cut for the research: triangular, trapezoidal symmetrical and trapezoidal asymmetrical. Turning of each was carried out twice at cutting speeds v_c = 17 m/min and v_c = 30 m/min. On each of the threads, the side surface of the profile made in the direction of the insert feed and the opposite surface were examined. The surface texture parameters Sa, Sq, Sp, Sv, Sz, Ssk and Sku were determined and compared. It was noticed that the thread surfaces show a tendency to irregular roughness, which was confirmed by the analysis of the Sku and Ssk coefficients. The sides of the contours made in the direction of the insert feed are characterized by a higher roughness in relation to the opposite sides, which may result from high cutting forces and difficulties with chip evacuation. With the cutting speed being considered, lower values of Sa and Sq were obtained for v_c = 17 m/min, which differed from the visual assessment, proving its high subjectivity. Full article

Spiroid gears are used to transfer heavy loads with a significant reduction in input speed. Like most toothed gears, they are lubricated with oil whose physical properties change with temperature fluctuations, affecting the durability and reliability of the gear. Bearing this in mind, gear designers plan systems for measuring oil temperature during gear operation at the design stage. The authors of this paper are of the opinion that, in the case of spiroid gears, it may be insufficient to measure only oil temperature during gear operation. It seems that the working temperature of a pair of mating wheels has a decisive impact on the durability and reliability of the gear. The measurement of oil temperature in a tested gear should be treated as a supplementary measurement with the measurement of temperature on the toothed wheels as the basic measurement. Taking into consideration the above, an innovative test bench was designed and built, making it possible to observe how working parameters of the gear (torque and rotational speed) affect the temperature of the lubricating oil, but most of all, the working temperature of the pair of mating wheels. This paper presents, among others, the results of research on the impact of the rotational speed of the input shaft and load on the distribution of temperature on the toothed rim of the face gear. Full article

This article addresses the issue of the durability of mining shaft equipment elements. Shafts as a transport route are one of the most exploited parts of a mine. Consequently, their components are exposed to high mechanical stresses, which cause the deterioration of their mechanical properties. In the case of shafts with timber components, elements such as the shaft guides are evaluated on a purely macroscopic basis and are often unnecessarily replaced. This paper presents the possibilities for the application of non-destructive methods (ultrasound and laser scanning) and semi-destructive methods (sclerometric and drill resistance tests). The experimental results suggest that it was possible to derive correlations between penetration depth and drill resistance tests with bulk density. However, these tests were not directly correlated with flexural strength. The ultrasound studies did not indicate a significant relationship with the physical or mechanical properties. In contrast, the method of comparing the variation (wear) in the tested guides using 3D laser scanning demonstrated a high accuracy; moreover, this method is independent of factors that may affect the results of penetration depth or drill resistance measurements. The application of non-destructive and semi-destructive tests for the determination of the physical and mechanical properties of timber elements of mine shafts’ equipment may enable the detection of a defect earlier or extend the service life of elements, hence limiting the downtime of shaft operation related to the replacement of elements. Full article

The winnowing machine of chili pepper harvesters was developed to reduce the potential problem of low pepper stem and fruit separation. The developed winnowing machine was combined with two impellers and a center bearing to prevent a strain on the drive shaft and to ensure durability. The terminal velocity of chili pepper was measured, and an aerodynamic analysis was conducted based on this winnowing machine. A CFD (Computational Fluid Dynamics, Ansys Fluent 2020 R1) analysis was conducted for three levels of discharge port guide form (0, 3, and 5 guides) and three levels of rotating speed (1600, 1800, and 2000 RPM) of a winnowing machine designed utilizing aerodynamic analysis results. A validation test was conducted by fabricating a winnower test device. As for aerodynamic analysis conducted using measured values of terminal velocity, chili pepper fruits were collected at an outlet wind speed lower than 17.5 m/s and chili pepper branches were separated at a speed higher than 12.5 m/s. As a result of CFD analysis, the wind speed deviation at outlets of the 0-, 3-, and 5-guide depending on the rotating speed appeared to be 15.8, 1.4, and 1.0 m/s on average, respectively. The result of the CFD analysis showed values higher than wind speeds of the actual winnower test device by a minimum of 0 and a maximum of 2.4 m/s. Through the CFD analysis and the wind speed validation test of the winnower test device, optimal conditions to separate foreign materials were found to be a winnowing machine at a rotating speed of 1800 RPM with a discharge port having three guides or a winnowing machine at a rotating speed of 2000 RPM with a discharge port having five guides. Full article

Vibration monitoring provides a good-quality source of information about the health condition of machines, and it is often based on the use of accelerometers. This article focuses on the use of accelerometer sensors in fabricating a low-cost system for monitoring vibrations in agricultural machines, such as rotary tedders. The aim of the study is to provide useful data on equipment health for improving the durability of such machinery. The electronic prototype, based on the low-cost AVR microcontroller ATmega128 with 10-bit ADC performing a 12-bit measurement, is able to acquire data from an accelerometer weighing up to 10 g. Three sensors were exposed to low accelerations with the use of an exciter, and their static characteristics were presented. Standard experimental tests were used to evaluate the constructed machine monitoring system. The self-contained prototype system was calibrated in a laboratory test rig, and sinusoidal and multisinusoidal excitations were used. Measurements in time and frequency domains were carried out. The amplitude characteristic of the preformed system differed by no more than 15% within a frequency range of 10 Hz–10 kHz, compared to the AVM4000 commercial product. Finally, the system was experimentally tested to measure acceleration at three characteristic points in a rotational tedder, i.e., the solid grease gearbox, the drive shaft bearing and the main frame. The RMS amplitude values of the shaft vibrations on the bearing in relation to the change in the drive shaft speed of two tedders of the same type were evaluated and compared. Additionally, the parameters of kurtosis and crest factor were compared to ascertain the bearing condition. Full article
