With the increasing penetration of distributed generation and the diversification of electrical equipment, distribution networks face issues like three-phase unbalance and harmonic currents, while the voltage stability and inertia of the grid-connected system also decrease. A certain amount of energy storage is needed in a Distribution Static Synchronous Compensator (DSTATCOM) to manage power quality and actively support voltage and inertia in the network. This paper first addresses the limitations of traditional $dq0$ compensation algorithms in effectively filtering out negative-sequence twice-frequency components. An improved $dq0$ compensation algorithm is proposed to reduce errors in detecting positive-sequence fundamental current under unbalanced three-phase conditions. Second, considering the impedance ratio characteristics of the distribution network, while reactive power voltage regulation is common, active power regulation is more effective in high-resistance distribution networks. A grid-forming model-based active and reactive power coordinated voltage regulation method is proposed. This method uses synchronous control to establish a virtual three-phase voltage internal electromotive force, forming a comprehensive compensation strategy that combines power quality improvement and active voltage support, exploring the potential of energy storage DSTATCOM applications in distribution networks. Finally, simulation and experimental results demonstrate the effectiveness of the proposed control method. Full article

In this paper, we address the problem of intelligent operation of Distribution Static Synchronous Compensators (D-STATCOMs) in power distribution systems to reduce energy losses and CO₂ emissions while improving system operating conditions. In addition, we consider the entire set of constraints inherent in the operation of such networks in an environment with D-STATCOMs. To solve such a problem, we used three master–slave methodologies based on sequential programming methods. In the proposed methodologies, the master stage solves the problem of intelligent D-STATCOM operation using the continuous versions of the Monte Carlo (MC) method, the population-based genetic algorithm (PGA), and the Particle Swarm Optimizer (PSO). The slave stage, for its part, evaluates the solutions proposed by the algorithms to determine their impact on the objective functions and constraints representing the problem. This is accomplished by running an Hourly Power Flow (HPF) based on the method of successive approximations. As test scenarios, we employed the 33- and 69-node radial test systems, considering data on power demand and CO₂ emissions reported for the city of Medellín in Colombia (as documented in the literature). Furthermore, a test system was adapted in this work to the demand characteristics of a feeder located in the city of Talca in Chile. This adaptation involved adjusting the conductors and voltage limits to include a test system with variations in power demand due to seasonal changes throughout the year (spring, winter, autumn, and summer). Demand curves were obtained by analyzing data reported by the local network operator, i.e., Compañía General de Electricidad. To assess the robustness and performance of the proposed optimization approach, each scenario was simulated 100 times. The evaluation metrics included average solution quality, standard deviation, and repeatability. Across all scenarios, the PGA consistently outperformed the other methods tested. Specifically, in the 33-node system, the PGA achieved a 24.646% reduction in energy losses and a 0.9109% reduction in CO₂ emissions compared to the base case. In the 69-node system, reductions reached 26.0823% in energy losses and 0.9784% in CO₂ emissions compared to the base case. Notably, in the case of the Talca feeder—particularly during summer, the most demanding season—the PGA yielded the most significant improvements, reducing energy losses by 33.4902% and CO₂ emissions by 1.2805%. Additionally, an uncertainty analysis was conducted to validate the effectiveness and robustness of the proposed optimization methodology under realistic operating variability. A total of 100 randomized demand profiles for both active and reactive power were evaluated. The results demonstrated the scalability and consistent performance of the proposed strategy, confirming its effectiveness under diverse and practical operating conditions. Full article

The optimal integration of photovoltaic (PV) systems and distribution static synchronous compensators (D-STATCOMs) in electrical distribution networks is important to reduce their operating costs, improve their voltage profiles, and enhance their power quality. To this effect, this paper proposes a mixed-integer convex (MI-Convex) optimization model for the optimal siting and sizing of PV systems and D-STATCOMs, with the aim of minimizing investment and operating costs in electrical distribution networks. The proposed model transforms the traditional mixed-integer nonlinear programming (MINLP) formulation into a convex model through second-order conic relaxation of the nodal voltage product. This model ensures global optimality and computational efficiency, which is not achieved using traditional heuristic-based approaches. The proposed model is validated on IEEE 33- and 69-bus test systems, showing a significant reduction in operating costs in both feeders compared to traditional heuristic-based approaches such as the vortex search algorithm (VSA), the sine-cosine algorithm (SCA), and the sech-tanh optimization algorithm (STOA). According to the results, the MI-convex model achieves cost savings of up to 38.95% in both grids, outperforming the VSA, SCA, and STOA. Full article

The proactive involvement of photovoltaic (PV) smart inverters (PVSIs) in grid management facilitates voltage regulation and enhances the integration of distributed energy resources (DERs) within distribution networks. However, to fully exploit the capabilities of PVSIs, it is essential to achieve optimal control of their operations and effective coordination with voltage-regulating devices in the distribution network. This study developed a dual strategy approach to forecast the optimal setpoints of onload tap changers (OLTCs), PVSIs, and distribution static synchronous compensators (DSTATCOMs) to improve the voltage profiles in power distribution systems. The study began by running a centralized AC optimal power flow (CACOPF) and using the hourly PV output power and the load demand to determine the optimal active and reactive power of the PVSIs, the setpoint of the DSTATCOM, and the optimal tap setting of the OLTC. Furthermore, Machine Learning (ML) models were trained as controllers to determine the reactive-power setpoints for the PVSIs and DSTATCOMs as well as the optimal OLTC tap position required for voltage stability in the network. To assess the effectiveness of the method, comprehensive evaluations were carried out on a modified IEEE 33 bus with a high penetration of PV energy. The results showed that deep neural networks (DNNs) outperformed other ML models used to mimic the coordination method based on CACOPF. Furthermore, when the DNN-based controller was tested and compared with the optimizer approach under different loading and PV conditions, the DNN-based controller was found to outperform the optimizer in terms of computational time. This approach allows predictive control in power systems, helping system operators determine the action to be initiated under uncertain PV energy and loading conditions. The approach also addresses the computational inefficiency arising from contingencies in the power system that may occur when optimal power flow (OPF) is run multiple times. Full article

This study proposes an optimized energy management strategy for alternating current microgrids, integrating wind generation, battery energy storage systems (BESSs), and distribution static synchronous compensators (D-STATCOMs). The objective is to minimize operational costs, including grid electricity purchases (grid-connected mode), diesel generation costs (islanded mode), and maintenance expenses of distributed energy resources while ensuring voltage limits, maximum line currents, and power balance. A master–slave optimization approach is employed, where the Gray Wolf Optimizer (GWO) determines the optimal dispatch of energy resources, and successive approximations (SAs) perform power flow analysis. The methodology was validated on a 33-node microgrid, considering variable wind generation and demand profiles from a Colombian region under grid-connected and islanded conditions. To assess performance, 100 independent runs per method were conducted, comparing GWO against particle swarm optimization (PSO) and genetic algorithms (GAs). Statistical analysis confirmed that GWO achieved the lowest operational costs (USD 3299.39 in grid-connected mode and USD 11,367.76 in islanded mode), the highest solution stability (0.19% standard deviation), and superior voltage regulation. The results demonstrate that GWO with SA provides the best trade-off between cost efficiency, system stability, and computational performance, making it an optimal approach for microgrid energy management. Full article

In this work, a comprehensive planning framework for an electric vehicle charging ecosystem (EVCE) is developed, incorporating solar distributed generation (DG) and a distribution static compensator (DSTATCOM), to assess their long-term techno–economic and environmental impacts. The optimal locations and capacities of the EVCE, solar DG, and DSTATCOM are determined using an improved particle swarm optimization algorithm based on the success rate technique. The study aims to maximize the technical, financial, and social benefits while ensuring that all security constraints are met. To assess the financial viability of the proposed model over a 10-year horizon, a detailed economic analysis comprising installation cost, operation, and maintenance cost is conducted. To make the model more realistic, various practical parameters, such as the inflation rate and interest rate, are incorporated during the financial analysis. Additionally, to highlight the societal benefits of the approach, the study quantifies the long-term carbon emissions and the corresponding cost of emissions. The proposed framework is tested on both a 33-bus distribution network and a 108-bus Indian distribution network. Various planning scenarios are explored, with different configurations of the EVCE, solar-based DG, and DSTATCOM, to assist power system planners in selecting the most suitable strategy. Full article

At present, the integration of microgrids into power systems presents significant power quality challenges in terms of the rising adoption of nonlinear loads and electric vehicles. Ensuring the stability and efficiency of the electrical network in this evolving landscape is crucial. This paper explores the implementation of cascading Proportional–Integral (PI-PI) and cascading Fractional-Order PI (FOPI-FOPI) controllers for a Distribution Static Compensator (DSTATCOM) in hybrid microgrids that include photovoltaic (PV) systems and fuel cells. A novel hybrid optimization algorithm, WSO-WOA, is introduced to enhance power quality. This algorithm leverages the strengths of the White Shark Optimization (WSO) algorithm and the Whale Optimization Algorithm (WOA), with WSO generating new candidate solutions and WOA exploring alternative search areas when WSO does not converge on optimal results. The proposed approach was rigorously tested through multiple case studies and compared with established metaheuristic algorithms. The findings demonstrate that the WSO-WOA hybrid algorithm significantly outperforms others in optimizing the PI-PI and FOPI-FOPI controllers. The WSO-WOA algorithm showed an improvement in accuracy, surpassing the other algorithms by approximately 7.29% to 14.1% in the tuning of the PI-PI controller and about 8.5% to 21.2% in the tuning of the FOPI-FOPI controller. Additionally, the results confirm the superior performance of the FOPI-FOPI controller over the PI-PI controller in enhancing the effectiveness of the DSTATCOM across various scenarios. The FOPI-FOPI provided controller a reduced settling time by at least 30.5–56.1%, resulting in marked improvements in voltage regulation and overall power quality within the microgrid. Full article

The growing adoption of electric vehicles (EVs) offers notable benefits, including reduced maintenance costs, improved performance, and environmental sustainability. However, integrating EVs into radial distribution systems (RDSs) poses challenges related to power losses and voltage stability. The model accounts for hourly variations in demand, making it crucial to determine the optimal placement of electric vehicle charging stations (EVCSs) throughout the day. This study proposes a new approach that combines EVCSs, distribution static compensators (DSTATCOMs), and renewable distributed generation (RDG) from solar and wind sources, with a focus on dynamic analysis over 24 h. The spotted hyena optimization algorithm (SHOA) is employed to determine near-global optimum locations and sizes for RDG, DSTATCOMs, and EVCSs, aiming to minimize real power loss while meeting system constraints. The SHOA outperforms traditional methods due to its unique search mechanism, which effectively balances exploration and exploitation, allowing it to find superior solutions in complex environments. Simulations on an IEEE 34-bus RDS under dynamic load conditions validate the approach, demonstrating a reduction in average power loss from 180.43 kW to 72.04 kW, a 72.6% decrease. Compared to traditional methods under constant load conditions, the SHOA achieves a 77.0% reduction in power loss, while the BESA and PSO achieve reductions of 61.1% and 44.7%, respectively. These results underscore the effectiveness of the SHOA in enhancing system performance and significantly reducing real power loss. Full article

This paper presents a new optimization technique for the locations and sizes of Distributed Generators (DGs) and distribution static compensators (DSTATCOMs) in a radial system of a distribution network based on a multi-objective approach. It uses black widow optimization to improve voltage profile and power loss reduction. The black widow optimization simulates the mating behaviour of black widow spiders. The optimum size and placement of DGs and DSTATCOMs are deemed to be decision variables that are defined by using black widow optimization. The proposed technique is implemented in selected IEEE bus systems to evaluate its performance. The simulation results indicate reduced power losses and voltage profile enhancement as sizes and locations of integrated DGs and DSTATCOMs are adjusted based on optimization. The number of DGs and DSTATCOMs required to achieve the objectives is reduced. Furthermore, the results of the black widow algorithm are compared to existing techniques in the literature. Full article

This research emphasizes a meta-heuristic modified ant lion optimizer (MALO) optimization approach for the simultaneous utilization of DSTATCOM devices and distributed photovoltaic (PV) sources with network reconfiguration in a radial power distribution scheme. In a radial power distribution network with network reconfiguration, the majority of the research is based on constant power model analysis. However, it is noticed that load models have a substantial impact on the distributed PV sources and the DSTATCOM device’s optimal size and position. The effect of the constant power (CP) and polynomial (ZIP) with load growth load models for the simultaneous insertion of distributed PV sources and DSTATCOM devices with network reconfiguration is examined in this research work for power system planning. The penetration levels of distributed PV sources considered for the investigation are 25%, 50%, 75%, and 100%. The principal objective of this research is to reduce network total power losses, enhance the voltage magnitude profile at all buses, and reduce the overall operating cost while adhering to equality and inequality constraints. The proposed algorithm is verified on 118-node test systems. The investigation is carried out for planning network upgrading to a high-voltage distribution system (HVDS) on 317 nodes in the rural Bangalore Electricity Supply Company Limited (BESCOM) radial distribution scheme. The simulated results obtained with this method are validated with the BAT algorithm and techniques available in the literature. It is observed that in the IEEE 118-bus system, via the simultaneous placement and sizing of PV sources considering a 25% penetration level and DSTATCOM devices during network reconfiguration, the total power loss reduction is 41.47% and 42.98% for the constant power model and ZIP with the load growth model. For the 317-bus system, the total power loss reduction observed for 11 kV is 49.77% and 59.34% for the constant power model and ZIP model with load growth. Similarly, for the 22 kV system, the power loss reduction observed is 51.69% and 55.75% for the constant power model and ZIP with the load growth model. Full article

Over the last decade, flexible alternating current transmission systems (FACTS) have been crucial in ensuring optimal power distribution within modern power systems. A vital component of FACTS devices is the distribution static compensator (DSTATCOM), which is essential for maintaining a reliable power supply. It is commonly used for reactive power compensation, voltage regulation, and harmonic reduction. Determining the appropriate size and placement of DSTATCOMs is vital to ensuring their efficiency. This study introduces the improved gray wolf optimizer (I-GWO), a refined version of the classical gray wolf optimization (GWO) method. The I-GWO incorporates a dimension learning-based hunting (DLH) strategy to preserve population diversity, balance exploration and exploitation, and prevent the premature convergence of classical GWO. In this research, the I-GWO was applied to determine the optimum allocation and sizing of the DSTATCOMs, considering system constraints, including those presented by the intermittent and stochastic nature of the load and renewable energy resources, specifically wind and solar energy. The suggested approach was successfully tested on 33-, 69-, and 85-bus distribution systems and then compared with existing studies. The results demonstrated the I-GWO-based approach’s superiority in terms of reducing power losses, improving voltage profiles, and enhancing voltage stability. Full article

This study focuses on the application of the JAYA algorithm to optimize the implementation and sizing of a distribution static synchronous compensator (DSTATCOM) in distribution systems to reduce power losses and enhance voltage profiles, ensuring a total harmonic distortion of voltage (THDv) below 3% at all system nodes. The algorithm, developed and modelled in MATLAB, addresses power flow solutions and analyzes harmonic influence from implementing a DSTATCOM as reactive compensation via a non-iterative harmonic penetration analysis. Successful algorithm implementation results in a significant reduction in both active and reactive power losses in 33- and 34-node systems while maintaining a THDv below 3% at all nodes. Although imposing the THDv limit constraint reduces power loss, this compensation ensures low THDv levels in the voltage. In contrast to existing literature that focuses on power loss reduction via reactive compensation, this work addresses and controls the inclusion of harmonics in the electrical network as a consequence of such reactive compensation, marking a novel contribution to the field. Full article

Incorporating Distribution Static Synchronous Compensator (DSTATCOM) units into the radial distribution network (RDN) represents a practical approach to providing reactive compensation, minimizing power loss, and enhancing voltage profile and stability. This research introduces a unique optimization technique called the Black Widow Optimization (BWO) algorithm for strategically placing DSTATCOM units within the RDN. The primary objective is to minimize power loss while simultaneously evaluating various techno-economic parameters such as the voltage profile index (VPI), voltage stability index (VSI), and annual cost savings. The analysis of optimal DSTATCOM allocation, employing the proposed BWO algorithm, encompasses different load models, including constant impedance (CZ), constant current (CI), constant power (CP), and composite (ZIP) models. These analyses consider three distinct scenarios: single and multiple DSTATCOM integration. To gauge the effectiveness of the proposed BWO technique, it is applied to the IEEE 33-bus and 69-bus RDNs as test cases. Simulation results confirm the efficiency of the proposed approach across all four load models. Notably, in the case of the constant power model, the percentage reduction in power loss is substantial, with a reduction of 34.79% for the IEEE 33-bus RDN and 36.09% for the IEEE 69-bus RDN compared to their respective base cases. Full article

The existing distribution networks were designed at a time when there was virtually no embedded generation. The design methods ensured the voltage at various parts of the network remained within the limits required by standards, and for the most part, this was very successfully achieved. As Distributed Energy Resources (DERs) started to grow, the rise in voltage due to injected currents and the local impedances started to push network voltages toward, and even above, the desired upper limits. Voltage limits are based on typical appliance requirements, and long-term over-voltages will ultimately result in unacceptably short appliance life spans. Distribution Static Compensators (dSTATCOMs) are shunt-connected devices that can improve low-voltage networks’ performance by injecting currents that do not transfer real power. The currents can be reactive, negative or zero sequence, or harmonic. System performance can be improved by reducing conduction loss, improving voltage profile and voltage balance, or reducing Total Harmonic Distortion (THD). To obtain these benefits, optimal sizes of dSTATCOMs need to be placed at optimal locations within the distribution network. This paper has considered seventy research articles published over the past years related to the optimal placement and sizing of dSTATCOMs. In this study, minimization of power losses, voltage profile improvement, loadablity factor, voltage sag mitigation, and reduction in annual operating costs are considered fitness functions that are subjected to multiple constraint sets. The optimization algorithms found in the literature are categorized into six methods: analytical methods, artificial neural network-based methods, sensitivity approaches, metaheuristic methods, a combination of metaheuristic and sensitivity analysis, and miscellaneous. This study also presents a comparison among distribution network types, load flow methods optimization tools, etc. Therefore, a comprehensive review of optimal allocation and sizing of dSTATCOMs in distribution networks is presented in this paper, and guidance for future research is also provided. Full article

As a technique to control the voltage drop at network peak periods and voltage rise at middays when a high number of rooftop photovoltaic systems exist in a low-voltage feeder (LVF), two or more neighboring LVFs can be coupled. To add voltage controllability to the coupling point, a distribution static compensator (DSTATCOM) can be installed. An important issue for such a system is its operation under short-circuit conditions in one of the LVFs and relevant protection aspects. This paper investigates the performance of such a system under fault conditions and presents a protection scheme that can achieve the desired operation of the system, under short-circuit faults in either of the LVFs. The performance of the system of coupled LVFs is investigated by numerical analysis in MATLAB while the dynamic feasibility of the proposed technique is validated by simulation studies in PSCAD/EMTDC. Full article
