Search Results (22)

Search Parameters:
Keywords = disk clearance

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
21 pages, 6027 KiB
Article
Static Characteristic Analysis of Multi-Layer Foil Thrust Bearing: Considering Parameter Effects
by Yulong Jiang, Qianjing Zhu, Zhongwen Huang and Dongyan Gao
Lubricants 2025, 13(7), 285; https://doi.org/10.3390/lubricants13070285 - 25 Jun 2025
Viewed by 464
Abstract
A modified static characteristic model for the multi-layer foil thrust bearing (MLFTB) is established. In this model, the finite difference method and the thick plate element are implemented, the compressible Reynolds equation is linearized by the Newton–Raphson method, and the evolution law of [...] Read more.
A modified static characteristic model for the multi-layer foil thrust bearing (MLFTB) is established. In this model, the finite difference method and the thick plate element are implemented, the compressible Reynolds equation is linearized by the Newton–Raphson method, and the evolution law of the static characteristics with the geometric and operational parameters is derived by iterative solution. The results indicate that the bearing capacity could be generally decreased by around 3.15% when considering the slip boundary condition, which should not be neglected. Also, when under the rigorous wedge effect, the pressure peak near the mini clearance exhibits an obvious double peak shape. The bearing capacity can be slightly enhanced by an increase in the tilt angle of the thrust disk. In comparison to data in the literature, the current model shows satisfactory precision for the multi-layer foil thrust bearing. It aims to provide effective predictive means and theoretical reference for MLFTB. Full article
Show Figures

Figure 1

21 pages, 38213 KiB
Article
Aerodynamic Analysis and Application of the Channel Wing Configuration Based on the Actuator Disk Model
by Mingzhi Cao, Kun Liu and Jingbo Wei
Drones 2025, 9(6), 443; https://doi.org/10.3390/drones9060443 - 18 Jun 2025
Viewed by 482
Abstract
The channel wing offers unique advantages in the short take-off and landing (STOL) application of Unmanned Aerial Vehicles (UAVs). To investigate its aerodynamic performance, an individual propeller was simulated using the actuator disk model. The computed values were in close agreement with the [...] Read more.
The channel wing offers unique advantages in the short take-off and landing (STOL) application of Unmanned Aerial Vehicles (UAVs). To investigate its aerodynamic performance, an individual propeller was simulated using the actuator disk model. The computed values were in close agreement with the experimental data. To conduct an initial assessment of the aerodynamic advantages offered by the channel wing, this study compared three configurations: a clean wing, a wing with a forward propeller, and a channel wing. The analysis revealed that the channel wing exhibits a better lift-to-drag ratio than the wing with a forward propeller. Further analysis investigated how propeller-to-wing clearance, axial placement relative to the wing’s leading edge, and changes in propeller diameter influence the channel wing aerodynamic characteristics. To validate the simulation results, a test platform was designed, and the calculated results were qualitatively verified. The findings indicated that reducing the propeller-to-wing clearance enhances the channel wing’s lift force and contributes to a higher lift-to-drag ratio. Altering the propeller’s installation position along the chordwise direction of the channel wing significantly influences its aerodynamic performance. Finally, the channel wing configuration was applied to a lifting-fuselage tandem-wing drone. A comparison with the conventional forward propeller configuration demonstrated that the drone with the channel wing achieves a higher lift-to-drag ratio, with a maximum value of 18.6. Compared with “forward propeller” configuration, the lift-to-drag ratio exhibits an improvement of 97.8% under the optimal configuration. Full article
(This article belongs to the Section Drone Design and Development)
Show Figures

Figure 1

21 pages, 5815 KiB
Article
Model-Based Optimization of a Sliding Vane Rotary Pump for Micro-Organic Rankine Cycle
by Fabio Fatigati, Giammarco Di Giovine and Roberto Cipollone
Energies 2025, 18(1), 97; https://doi.org/10.3390/en18010097 - 30 Dec 2024
Cited by 1 | Viewed by 697
Abstract
The residential sector is one of the main sectors responsible for the atmospheric emission of CO2. Hence, a significant effort is required to develop technological solutions to enable decarbonization. The integration of Organic Rankine Cycle (ORC)-based units with renewable sources at [...] Read more.
The residential sector is one of the main sectors responsible for the atmospheric emission of CO2. Hence, a significant effort is required to develop technological solutions to enable decarbonization. The integration of Organic Rankine Cycle (ORC)-based units with renewable sources at a micro-scale of cogeneration units is commonly believed to be one of the most important technological alternatives. Indeed, an ORC-based unit allows the exploitation of low-temperature heat sources in the production of electricity. The low power scale of this application (1–5 kW) and the severe operating conditions call for the reliable and proper design of components. Particularly critical is the pump, as the experimental analyses available in the literature show its efficiency rarely exceeds values of 0.3. The most suitable technology is volumetric, and among those available, the sliding vane types are interesting candidates. However, low efficiency leads to a significant erosion of the power produced by the expander, limiting the achievement of high-efficiency values. What is more, in the literature, there is a lack of development of optimization strategies to improve the performance of this machine. To fill this knowledge gap, in this present paper an optimized sliding vane rotary pump was designed. Thanks to a comprehensive experimentally validated model, the pump performance was assessed for a wide range of operating conditions. Results confirmed that a disk-shaped configuration also ensures the best efficiency is achieved for small-scale pumps. Moreover, the model allowed for a detailed analysis of efficiency, evaluating the volumetric, fluid dynamic and mechanical behaviors. Results demonstrated that the weakest point was the mechanical efficiency, which was between 0.45 and 0.55. The best configuration was that involving four blades, the adoption of graphite and a clearance gap between the rotor face and casing of 10 μm. These design solutions improved efficiency by up to 25%, with a maximum value equal to 0.50, which is close to double with respect to the usual values. A final remark concerns the operating robustness of the machine, as the efficiency demonstrated weak variations even when wide operating conditions were considered. Full article
(This article belongs to the Section B2: Clean Energy)
Show Figures

Figure 1

16 pages, 7704 KiB
Article
Numerical Research on Flow Characteristics at High Radii of Rim Seals with Different Geometric Structures
by Qichao Xue, Xueying Li and Jing Ren
Energies 2024, 17(8), 1877; https://doi.org/10.3390/en17081877 - 15 Apr 2024
Viewed by 1091
Abstract
In the high-temperature mainstream of gas turbines, there is a rim clearance between the rotor and the stator. A rim seal is to prevent the intrusion of high-temperature gas by spraying cool fluid from the inside of the rim clearance to the outside. [...] Read more.
In the high-temperature mainstream of gas turbines, there is a rim clearance between the rotor and the stator. A rim seal is to prevent the intrusion of high-temperature gas by spraying cool fluid from the inside of the rim clearance to the outside. In the past research on rim seals, the focus was on the overall performance of the sealing structure, and the flow in the disc cavity was studied more, but the high-radius flow was simplified. In recent years, additional research in the field has focused on more complex sealing structures and high-radius flows, such as the interface between the disk cavity and the mainstream. There is more work to be conducted in this area of research. In this paper, the unsteady numerical simulation of the flow in four different rim sealing geometries is carried out by the URANS method. The flow phenomena and the influence of geometry on the flow are studied. The numerical simulation results are validated with the experimental results. It is found that the fluid in the rim sealing obviously presents two distinct forms and confrontations according to the tangential velocity. The flow in the sealing structure presents obvious circumferential non-uniformity. Compared with the single-axial structure, in the single-radial structure, the mixing area is induced by the radial geometry, and more vortex structures are generated, the mixing process is more intense, and the sealing effect is better. In the double-sealing structure, the inner structure plays the role of a barrier, and the cavity geometry between the two layers has a major influence on the sealing performance. Full article
(This article belongs to the Section J1: Heat and Mass Transfer)
Show Figures

Figure 1

21 pages, 19765 KiB
Article
Misalignment and Rub-Impact Coupling Dynamics of Power Turbine Rotor with Offset Disk
by Guofang Nan, Sirui Yang and Dengliang Yu
Appl. Sci. 2024, 14(3), 1298; https://doi.org/10.3390/app14031298 - 4 Feb 2024
Cited by 3 | Viewed by 1585
Abstract
When the dual rotor system of the aircraft engine is operating, the mass eccentricity of the power turbine rotor and the misalignment of the shaft coupling or the bearing will cause too large vibration of the rotor; this vibration leads to the rub-impact [...] Read more.
When the dual rotor system of the aircraft engine is operating, the mass eccentricity of the power turbine rotor and the misalignment of the shaft coupling or the bearing will cause too large vibration of the rotor; this vibration leads to the rub-impact between the rotor and the casing. The power turbine rotor from the dual rotor system is taken as the research object in this paper. Considering the misalignment, the resulting rub-impact faults, the imbalance of rotor and the disk offset, the equation of motion for the system is developed according to the Lagrangian Equation, and then the Range-Kutta Method is adopted to solve the equation. The influence of the key parameters such as the rotating speed, the misalignment angle and the rub-impact clearance on the dynamics of the system is studied; the finite element analysis was carried out to validate the correctness of the theoretical modeling method. The results show that the rub-impact increases the stiffness of the system; the Hopf bifurcation occurs in the misalignment and rub-impact coupling system; the vibrational stability near the half of the switching speed slumps with the increase of the misalignment angle; with increasing of the stiffness, the number of the chaotic zone increases, and the range of the chaos is widening; enlarging the rub-impact clearance is beneficial to reduce the degree of the rub-impact system and enhance the stability of the system. Full article
(This article belongs to the Section Acoustics and Vibrations)
Show Figures

Figure 1

13 pages, 4685 KiB
Article
The Effect of Slider Configuration on Lubricant Depletion at the Slider/Disk Contact Interface
by Yuxin Chen, Dongdong Zhou and Zhengqiang Tang
Lubricants 2024, 12(1), 17; https://doi.org/10.3390/lubricants12010017 - 8 Jan 2024
Cited by 1 | Viewed by 2224
Abstract
With decreasing clearance between the protrusion of a slider and a disk interface, there is a higher likelihood of contact occurring during shock or vibration experienced by hard disk drives (HDDs), which may induce lubricant depletion. Based on the molecular dynamics (MD) model [...] Read more.
With decreasing clearance between the protrusion of a slider and a disk interface, there is a higher likelihood of contact occurring during shock or vibration experienced by hard disk drives (HDDs), which may induce lubricant depletion. Based on the molecular dynamics (MD) model of perfluoropolyether lubricant with a coarse-grained beads spring approach, we compared the slider configurations’ influence on the lubricant transfer volume quantitatively. By further investigating the parameters of the cylindrical asperities, including the width and depth, as well as considering the asperity amounts of the slider, we successfully observed the lubricant depletion process during slider and disk contact. The results demonstrate that the penetration depth was reduced as the asperity amount increased, mainly owing to the increased contact area between the surfaces. The decreasing depth of the asperity and the increasing width of the asperity helped to reduce the depletion volume. In addition, the utilization of a cylindrical slider configuration can contribute to a reduction in lubricant depletion resulting from contact between the head and disk. Full article
(This article belongs to the Special Issue Dynamics of Lubricated Interfaces)
Show Figures

Figure 1

19 pages, 5618 KiB
Article
Synchronous Vibration Parameter Recognition of Constant-Speed Blades Based on Blade Tip Clearance Measurement
by Liang Zhang, Yiming Xia, Cong Chen, Qingxi Song and Junjun Cao
Appl. Sci. 2024, 14(1), 254; https://doi.org/10.3390/app14010254 - 27 Dec 2023
Cited by 1 | Viewed by 1488
Abstract
A new method for the synchronous vibration parameter identification of constant-speed rotating blades based on blade tip clearance (BTC) measurement and blade tip timing (BTT) is introduced. A BTC sensor is used to measure the BTC when the blade tip passes through each [...] Read more.
A new method for the synchronous vibration parameter identification of constant-speed rotating blades based on blade tip clearance (BTC) measurement and blade tip timing (BTT) is introduced. A BTC sensor is used to measure the BTC when the blade tip passes through each sensor. The BTT method is used to determine whether the blade tip arrives in advance or lags. The geometric model between the BTC and the blade tip vibration displacement (BTVD) is established, and the BTVD of the blade tip passing through each sensor is obtained. Then, the nonlinear least squares method is used to determine the synchronous vibration parameters of the constant-speed rotating blade. The results show that with an increase in amplitude, the higher the accuracy of the vibration parameter identification proposed in this paper; with a decrease in the random error of the BTC measurement, the higher the accuracy of the vibration parameter identification proposed in this paper; with a decrease in the random error in the measurement of the blade disk dimensions, the higher the accuracy of the vibration parameter identification proposed in this paper. In addition, the smaller the ratio of the blade length to the blade disk radius, the higher the accuracy of the vibration parameter identification method introduced in this paper. Because the structure of the gas turbine compressor and turbine blade disk has a small blade disk ratio, the method proposed in this paper is suitable for the simultaneous vibration parameter identification of gas turbine compressor blades and turbine blades. Full article
(This article belongs to the Section Acoustics and Vibrations)
Show Figures

Figure 1

25 pages, 4783 KiB
Article
Analytical, Numerical and Experimental Analysis of a Positive Displacement Cam Mechanism—A Case Study
by Eugen Merticaru, Vasile Merticaru, Gheorghe Nagîț, Andrei Marius Mihalache, Liviu Lucian Tăbăcaru and Marius Ionuț Rîpanu
Machines 2023, 11(7), 770; https://doi.org/10.3390/machines11070770 - 24 Jul 2023
Cited by 4 | Viewed by 2915
Abstract
Cam mechanisms, covering a large structural variety, are widely used in machinery, mainly as components of automated systems. Their functioning behavior is affected by negative dynamic phenomena determined by specific high velocities and acceleration rates. Within the various types of research on the [...] Read more.
Cam mechanisms, covering a large structural variety, are widely used in machinery, mainly as components of automated systems. Their functioning behavior is affected by negative dynamic phenomena determined by specific high velocities and acceleration rates. Within the various types of research on the dynamic behavior of cam mechanisms, this study addresses the need to clarify the influence of geometrical parameters and technological conditions on some indicators of the jump phenomenon in contact loss for a cam-follower mechanism. This particularly developed case study referred to a mechanism with a profiled grooved disk cam and oscillating follower. To highlight the influence of the cam-follower contact elasticity on the jump phenomenon, two dynamic models were developed: one considering rigid elements in contact and the second considering elastic cam-follower contact. The models were tested within a virtually simulated experiment, and the numerical simulation results evidenced the influence of input factors like the applied load on the mechanism, the clearance in the cam-follower kinematic pair, and the rotational speed of the cam, and the inertia moment was reduced to the follower on some indicators of the jump phenomenon. Validation FEA and experiments were performed, proving the reliable appropriateness of the dynamic model based on elastic cam-follower contact. Full article
(This article belongs to the Section Machine Design and Theory)
Show Figures

Figure 1

25 pages, 14033 KiB
Article
Large Eddy Simulation of Rotationally Induced Ingress and Egress around an Axial Seal between Rotor and Stator Disks
by Sabina Nketia, Tom I-P. Shih, Kenneth Bryden, Richard Dalton and Richard A. Dennis
Energies 2023, 16(11), 4354; https://doi.org/10.3390/en16114354 - 26 May 2023
Cited by 2 | Viewed by 1486
Abstract
In gas turbines, the hot gas exiting the combustor can have temperatures as high as 2000 °C, and some of this hot gas enter into the space between the stator and rotor disks (wheelspace). Since the entering hot gas could damage the disks, [...] Read more.
In gas turbines, the hot gas exiting the combustor can have temperatures as high as 2000 °C, and some of this hot gas enter into the space between the stator and rotor disks (wheelspace). Since the entering hot gas could damage the disks, its ingestion must be minimized. This is carried out by rim seals and by introducing a cooler flow from the compressor (sealing flow) into the wheelspace. Ingress and egress into rim seals are driven by the stator vanes, the rotor and its rotation, and the rotor blades. This study focuses on the ingress and egress driven by the rotor and its rotation. This is carried out by performing wall-resolved large eddy simulation (LES) around an axial seal in a rotor–stator configuration without vanes and blades. Results obtained show the mechanisms by which the rotor and its rotation induce ingress, egress, and flow trajectories. Kelvin–Helmholtz instability was found to create a wavy shear layer and displacement thickness that produces alternating regions of high and low pressures around the rotor side of the seal. Vortex shedding on the backward-facing side of the seal and its impingement on the rotor side of the seal also produces alternating regions of high and low pressures. The locations of the alternating regions of high and low pressures were found to be statistically stationary and to cause ingress to start on the rotor side of the seal. Vortex shedding and recirculating flow in the seal clearance also cause ingress by entrainment. With the effects of the rotor and its rotation on ingress and egress isolated, this study enables the effects of stator vanes and rotor blades to be assessed. Full article
(This article belongs to the Special Issue New Insights of Gas Turbine Cooling Systems)
Show Figures

Figure 1

15 pages, 3214 KiB
Article
Design and Test of Peanut Root-Disk Full-Feeding Longitudinal Axial Flow Pod-Picking Device
by Xiaodong Liu, Qingqing Lü, Liquan Yang and Guangxi Li
Agronomy 2023, 13(4), 1103; https://doi.org/10.3390/agronomy13041103 - 12 Apr 2023
Cited by 4 | Viewed by 1906
Abstract
To improve the pod-picking efficiency of the combine harvester for both peanut seedlings and peanuts, a longitudinal axial flow pod-picking device is designed in this study. The fixation and adjustment modes of the pod-picking rod were determined. The pod-picking roller’s rotational speed, the [...] Read more.
To improve the pod-picking efficiency of the combine harvester for both peanut seedlings and peanuts, a longitudinal axial flow pod-picking device is designed in this study. The fixation and adjustment modes of the pod-picking rod were determined. The pod-picking roller’s rotational speed, the pod-picking roller’s diameter, the pod-picking roller, the pod-picking roller’s effective rod-picking length, and the screw-feeding stirrer’s critical parameters were determined by theoretical calculation. A combined design of quadratic regression orthogonal rotation was achieved by using Box-Behnken design (BBD) response surface optimization analysis in Design-Expert, with the linear speed of the pod-picking roller, the clearance between the concave screen and the pod-picking roller, and the spacing between the pod-picking rods as the testing factors, and the picking rate and the crushing rate as the indicators. The optimized parameters are as follows: a linear speed of the pod-picking roller of 6.8 m/s, a clearance between the concave screen and the pod-picking roller of 28.5 mm, and a spacing between the pod-picking rods of 18.60 mm. The performances of conventional peanut full-feeding pod-picking devices and the proposed peanut root-disk full-feeding longitudinal axial flow pod-picking device were investigated and compared to clarify the pod-picking performance of the proposed peanut root-disk full-feeding longitudinal axial flow pod-picking device under optimized parameters. The results showed that the picking and crushing rates of the proposed peanut root-disk full-feeding longitudinal axial flow pod-picking device under optimized parameters were 98.93 and 1.62%, respectively, both of which were superior to those of conventional peanut full-feeding pod-picking devices. A pod-picking device matching the combine harvester for peanut seedlings and peanuts was processed under optimized parameters. Field tests revealed that the picking and crushing rates of the proposed harvester were 99.07 and 1.58%, respectively, meeting the industry standards. These findings are instrumental in the further improvement of peanut pod-picking devices. Full article
Show Figures

Figure 1

9 pages, 261 KiB
Article
Vancomycin and Linezolid-Resistant Enterococcus Isolates from a Tertiary Care Center in India
by Mallika Sengupta, Riya Sarkar, Soma Sarkar, Manideepa Sengupta, Sougata Ghosh and Parthajit Banerjee
Diagnostics 2023, 13(5), 945; https://doi.org/10.3390/diagnostics13050945 - 2 Mar 2023
Cited by 8 | Viewed by 2666
Abstract
Introduction: There is increasing development of antibiotic resistance among the Enterococcus species. Objectives: This study was performed to determine prevalence and characterize the vancomycin-resistant and linezolid-resistant enterococcus isolates from a tertiary care center. Moreover, the antimicrobial susceptibility pattern of these isolates was also [...] Read more.
Introduction: There is increasing development of antibiotic resistance among the Enterococcus species. Objectives: This study was performed to determine prevalence and characterize the vancomycin-resistant and linezolid-resistant enterococcus isolates from a tertiary care center. Moreover, the antimicrobial susceptibility pattern of these isolates was also determined. Materials and Methods: A prospective study was performed in Medical College, Kolkata, India, over a period of two years (from January 2018 to December 2019). After obtaining clearance from the Institutional Ethics Committee, Enterococcus isolates from various samples were included in the present investigation. In addition to the various conventional biochemical tests, the VITEK 2 Compact system was used to identify the Enterococcus species. The isolates were tested for antimicrobial susceptibility to different antibiotics using the Kirby–Bauer disk diffusion method and VITEK 2 Compact to determine the minimum inhibitory concentration (MIC). The Clinical and Laboratory Standards Institute (CLSI) 2017 guidelines were used to interpret susceptibility. Multiplex PCR was performed for genetic characterization of the vancomycin-resistant Enterococcus isolates and sequencing was performed for characterization of the linezolid-resistant Enterococcus isolates. Results: During the period of two years, 371 isolates of Enterococcus spp. were obtained from 4934 clinical isolates showing a prevalence of 7.52%. Among these isolates, 239 (64.42%) were Enterococcus faecalis, 114 (30.72%) Enterococcus faecium, and others were Enterococcus durans, Enterococcus casseliflavus, Enterococcus gallinarum, and Enterococcus avium. Among these, 24 (6.47%) were VRE (Vancomycin-Resistant Enterococcus) of which 18 isolates were Van A type and six isolates of Enterococcus casseliflavus and Enterococcus gallinarum were resistant VanC type. There were two linezolid-resistant Enterococcus, and they were found to have the G2576T mutation. Among the 371 isolates, 252 (67.92%) were multi-drug resistant. Conclusion: This study found an increasing prevalence of vancomycin-resistant Enterococcus isolates. There is also an alarming prevalence of multidrug resistance among these isolates. Full article
(This article belongs to the Section Diagnostic Microbiology and Infectious Disease)
34 pages, 18673 KiB
Article
Swirl Flow and Heat Transfer in a Rotor-Stator Cavity with Consideration of the Inlet Seal Thermal Deformation Effect
by Yu Shi, Shuiting Ding, Peng Liu, Tian Qiu, Chuankai Liu, Changbo Qiu and Dahai Ye
Aerospace 2023, 10(2), 134; https://doi.org/10.3390/aerospace10020134 - 31 Jan 2023
Cited by 10 | Viewed by 3544
Abstract
In the typical structure of a turboshaft aero-engine, the mass flow of the cooling air in the rotor-stator cavity is controlled by the inlet seal labyrinth. This study focused on the swirl flow and heat transfer characteristics in a rotor-stator cavity with considerations [...] Read more.
In the typical structure of a turboshaft aero-engine, the mass flow of the cooling air in the rotor-stator cavity is controlled by the inlet seal labyrinth. This study focused on the swirl flow and heat transfer characteristics in a rotor-stator cavity with considerations of the inlet seal thermal deformation effect. A numerical framework was established by integrating conjugate heat transfer (CHT) analysis and structural finite element method (FEM) analysis to clarify the two-way aero-thermo-elasto coupling interaction among elastic deformation, leakage flow, and heat transfer. Simulation results showed that the actual hot-running clearance was non-uniform along the axial direction due to the temperature gradient and inconsistent structural stiffness. Compared with the cold-built clearance (CC), the minimum tip clearance of the actual non-uniform hot-running clearance (ANHC) was reduced by 37–40%, which caused an increase of swirl ratio at the labyrinth outlet by 5.3–6.9%, a reduction of the Nusselt number by up to 69%. The nominal uniform hot-running clearance (NUHC) was defined as the average labyrinth tip clearance. The Nusselt number of the rotating disk under the ANHC was up to 81% smaller than that under the NUHC. Finally, a clearance compensation method was proposed to increase the coolant flow and decrease the metal temperature. Full article
(This article belongs to the Special Issue Fluid-Dynamics and Heat Transfer in Aerospace Propulsion Systems)
Show Figures

Figure 1

22 pages, 10354 KiB
Article
Research on the Power Loss of High-Speed and High-Load Ball Bearing for Cryogenic Turbopump
by Wenhu Zhang, Chaojie Zhang, Xusheng Miao, Liang Li and Sier Deng
Machines 2022, 10(11), 1080; https://doi.org/10.3390/machines10111080 - 16 Nov 2022
Cited by 3 | Viewed by 2901
Abstract
This paper studies the lubrication characteristics of ball bearings for cryogenic turbopumps. First, the frictional coefficients between 440C and a Ag coating, 440C and solid PTFE (polytetrafluoroethylene), and 440C and a PTFE coating in LN2 (liquid nitrogen) are obtained using a ball-on-disk testing [...] Read more.
This paper studies the lubrication characteristics of ball bearings for cryogenic turbopumps. First, the frictional coefficients between 440C and a Ag coating, 440C and solid PTFE (polytetrafluoroethylene), and 440C and a PTFE coating in LN2 (liquid nitrogen) are obtained using a ball-on-disk testing machine under a high sliding speed in the range of 0 to 8 m/s and a high contact stress in the range of 2.5 to 3.5 GPa. Dynamic and power loss models of high-speed and high-load ball bearings are established to study the key factors affecting the heat generation characteristics. In order to verify the correctness of these two theoretical models, a coupled fluid-thermal finite element model is built to evaluate the temperatures of the outer ring under different bearing speeds, which are then proved by experiments with ball bearings for cryogenic turbopumps. The results show that the power loss due to the spinning-sliding of the ball and the churning and drag of LN2 account for more than 80% of the total power loss; the spin-roll ratio of the ball on the inner raceway is a key indicator for this type of ball bearing, and the relatively small radial clearance and contact angle are suggested. Both of the proposed theoretical models have sufficient accuracy and can be used in the performance evaluation and optimization design of bearings. Full article
(This article belongs to the Special Issue Advanced Dynamic Analysis and Vibro-Acoustic Control Methods)
Show Figures

Figure 1

16 pages, 44317 KiB
Article
Cantilevered Tandem Stator in Annular High Speed Test Rig
by Roland Rückert and Dieter Peitsch
Int. J. Turbomach. Propuls. Power 2022, 7(3), 24; https://doi.org/10.3390/ijtpp7030024 - 20 Jul 2022
Cited by 3 | Viewed by 2894
Abstract
The present paper investigates the aerodynamic performance of a cantilevered tandem stator based on experiments conducted within a high speed annular test rig at the Technische Universitaet Berlin. A tandem blade in this context describes a double rowed stator configuration where the turning [...] Read more.
The present paper investigates the aerodynamic performance of a cantilevered tandem stator based on experiments conducted within a high speed annular test rig at the Technische Universitaet Berlin. A tandem blade in this context describes a double rowed stator configuration where the turning of the incoming flow is split up between two blades arranged in succession. For evaluation purposes, a conventional single bladed stator is used as reference. To provide machine relevant boundary conditions of cantilevered stator assemblies, the moving hub wall is recreated by a rotating disk. Overall, the tandem stator is able to achieve higher flow turning while keeping the total pressure losses below those of a single stator. It is found that the tandem stator in general behaves similar to the conventional stator. When installed in cantilevered fashion, both stator types benefit considerably in terms of loss reduction. Without the hub clearance and therefore absence of the clearance flow, each of the configurations suffered from severe corner separation. The tandem stator responds more sensitively to change in clearance height. Full article
Show Figures

Figure 1

10 pages, 2996 KiB
Article
Research on the Possibility of Lowering the Manufacturing Accuracy of Cycloid Transmission Wheels with Intermediate Rolling Elements and a Free Cage
by Egor A. Efremenkov, Nikita V. Martyushev, Vadim Yu Skeeba, Maria V. Grechneva, Andrey V. Olisov and Anatoly D. Ens
Appl. Sci. 2022, 12(1), 5; https://doi.org/10.3390/app12010005 - 21 Dec 2021
Cited by 42 | Viewed by 2840
Abstract
Purpose: In the present work, different combinations of fits and accuracies, in relation to the profiles of mating parts, have been analysed in order to assess the degree of the engagement of transmissions that contain intermediate rolling elements. The aim of this work [...] Read more.
Purpose: In the present work, different combinations of fits and accuracies, in relation to the profiles of mating parts, have been analysed in order to assess the degree of the engagement of transmissions that contain intermediate rolling elements. The aim of this work is to determine which fits have decreased accuracy, but nevertheless provide a minimum manufacturing clearance for the transmission engagement in order to reduce the cost of parts production. Methods and materials: Considering the normal probabilistic distribution law in relation to the obtained dimensions of the manufacturing equipment, a combination of fits were selected using the incomplete interchangeability method, taking into account the peculiarities of the cycloid engagement in transmissions with intermediate rolling elements (IRE). Results: Having studied various combinations of fits of parts that are engaged in transmissions with intermediate rolling elements and a free cage (IREFC), a combination of fits for a “ring, rolling-element cam” were determined, in which a technological clearance of 3 µm is formed in the engagement. At the same time, cycloid disk profiles are manufactured according to the 9th tolerance grade, which reduces the laboriousness and cost of the production. Discussion. When reducing the manufacturing accuracy of cycloid disks, it is possible to obtain both very ample clearances and significant negative allowances. For example, having manufactured a ring with the H9 fit, rolling elements with h6 and a cam with js9, the maximum manufacturing clearance can reach 0.086 mm, while the clearance limits vary from 0.025 mm to 0.061 mm. Additionally, if mating parts are manufactured using a combination of K9-h6-js9 fits, a negative allowance varying from 0.014 mm to 0.026 mm will emerge in the engagement. Both described cases are unacceptable because both ample clearances and large negative allowances will negatively influence the working capacity of the mechanism. However, it is possible to select a combination of fits using the 9th tolerance grade of the basic parts, by which the parts will contact in the range from a small negative allowance of 1 µm to a clearance of 3–4 µm. Furthermore, if this is considered, taking into account the machine settings, it is possible to obtain parts according to the 9th accuracy tolerance grade and, at the same time, provide a clearance in the engagement that is almost equal to zero. Moreover, such a combination of fits is relevant for any transmission with IRE. This is a positive result because it reduces the laboriousness when manufacturing parts and, at the same time, provides high accuracy of the mechanism. Conclusions: It has been established that when lowering the accuracy of manufacturing transmission parts with IRE, both clearances and negative allowances may occur in the engagement, depending on the combination of fits. At the same time, it is possible to select such a combination of fits, by which the parts manufactured according to the 9th tolerance grade, will provide almost zero clearance of the engagement of the transmission. In this way, it is possible to reduce the cost of manufacturing the parts for gears with intermediate rolling elements and, at the same time, maintain a high accuracy of the transmission mechanism. Full article
Show Figures

Figure 1
