Semiconductor optical amplifiers (SOAs) are central to the development of ultrafast, low-power all-optical signal processing systems. Their strong nonlinear response, compact size, and compatibility with photonic integration platforms make them key enablers for implementing all-optical logic functions beyond the limitations of electronic switching. This review offers a comprehensive analysis of the principal SOA technologies used in all-optical logic gate implementations, including conventional bulk and quantum well SOAs, quantum dot SOAs (QD-SOAs), photonic crystal SOAs (PhC-SOAs), reflective SOAs (RSOAs), and carrier reservoir SOAs (CR-SOAs). For each architecture, we examine the carrier dynamics, gain recovery mechanisms, saturation behavior, and fabrication considerations, together with their associated nonlinear effects such as cross-gain modulation, cross-phase modulation, and four-wave mixing. We further evaluate reported implementations of key logic operations—AND, NAND, OR, NOR, XOR, and XNOR—highlighting performance trade-offs in terms of speed, extinction ratio, operational power, integration complexity, and scalability. The review concludes with current challenges and emerging research directions aimed at realizing fully integrated, high-speed, and energy-efficient all-optical logic systems based on next-generation SOA technologies. Full article

The continuous emission of persistent and bioaccumulative pollutants into aquatic environments has become a critical global issue. Among these, per- and polyfluoroalkyl substances (PFASs) are of particular concern due to their exceptional stability, extensive industrial use, and adverse impacts on ecosystems and human health. Their resistance to conventional physical, chemical, and biological treatments stems from the strength of the carbon–fluorine bond, which prevents efficient degradation under standard conditions. This review provides a concise and updated assessment of emerging advanced oxidation processes (AOPs) for PFAS remediation, with emphasis on heterogeneous photocatalysis and electrochemical oxidation. Photocatalytic systems based on In₂O₃, Bi-based oxyhalides, and Ga₂O₃ exhibit high PFAS degradation under UV light, while heterojunctions and MOF-derived catalysts improve defluorination under solar irradiation. Electrochemical oxidation—particularly using Ti₄O₇ reactive electrochemical membranes and BDD anodes—achieves near-complete mineralization with comparatively low specific energy demand. Energy consumption (E_EO) was calculated from literature data for UV- and simulated-solar-driven photocatalytic systems, enabling a direct comparison of their energy performance. Although solar-driven processes offer clear environmental advantages, they generally exhibit higher E_EO values, mainly due to lower apparent quantum yields and less efficient utilization of the incident solar photons compared to UV-driven systems. Hybrid systems coupling photocatalysis and electro-oxidation emerge as promising strategies to enhance degradation efficiency and reduce energy requirements. Overall, the review highlights key advances and future research directions toward scalable, energy-efficient, and environmentally sustainable AOP-based technologies for PFAS removal. Full article

This paper proposes a novel photonic crystal fiber-based 1 × 3 optical drop multiplexer design. According to numerical simulations, optical signals can be injected on the left core and divided into another core at various distances to separate the optical signals in a photonic crystal fiber structure. Throughout the length of the fiber, the innovative design controls the direction of light transmission between layers by alternating between multiple air-hole positions using pure silica layers. The optical systemic communications industry cannot function without wavelength multiplexers/demultiplexers. They function as a data combiner/separator. By employing an optical add-drop multiplexer, it becomes possible to add or remove signals from a stream of multiplexed signals without the need to be concerned about any potential interference with the existing signals, even when they are traveling at varying on-axis distances. This study provides findings about small optical drop multiplexers for fiber-to-the-home applications employing photonic crystal fiber at wavelengths of 0.85, 1.45, and 1.2 µm. Full article

We employ the Dynamical Projective Operatorial Approach (DPOA) to investigate the ultrafast optical excitations of germanium under intense, ultrashort pump pulses. The method has very low resource demand relative to many other available approaches and enables detailed calculation of the residual electron and hole populations induced by the pump pulse. It provides direct access to the energy distribution of excited carriers and to the total energy transferred to the system. By decomposing the response into contributions from different multi-photon resonant processes, we systematically study the dependence of excited-carrier density and absorbed energy on key pump-pulse parameters: duration, amplitude, and photon energy. Our results reveal a complex interplay between these parameters, governed by resonant Rabi-like dynamics and competition between different multi-photon absorption channels. For the studied germanium setup, we find that two-photon processes are generally dominant, while one- and three-photon channels become significant under specific conditions of pump-pulse frequency, duration, and intensity. This comprehensive analysis offers practical insights for optimizing ultrafast optical control in semiconductors by targeting specific multi-photon pathways. Full article

The development of photonic-integrated circuits (PICs) for data communication, sensing, and quantum computing is hindered by the high complexity and cost of traditional fabrication methods, which rely on expensive equipment, limiting accessibility for research and prototyping. This study introduces a Direct Laser Writing (DLW) system designed as a low-cost alternative, utilizing an XY platform for precise substrate movement and an optical system comprising a collimator and lens to focus the laser beam. Operating on a single layer, the system employs SU-8 photoresist to fabricate polymer-based structures on substrates such as ITO-covered glass. Preparation involves thorough cleaning, spin coating with photoresist, and pre- and post-baking to ensure material stability. This approach reduces dependence on costly infrastructure, making it suitable for academic settings and enabling rapid prototyping. A user interface and custom slicer process standard .dxf files into executable commands, enhancing operational flexibility. Experimental results demonstrate a resolution of 10 µm, with successful patterning of structures, including diffraction grids, waveguides, and multimode interference devices. This system aims to transform PIC prototype fabrication into a cost-effective, accessible process. Full article

Multilayer liquid crystal devices can offer enhanced optical functionalities for augmented reality and photonic applications, but fabrication remains severely limited by solvent incompatibility between photoalignment materials and underlying polymerized layers. Conventional photoalignment agents use aggressive solvents like N,N-dimethylformamide that damage polymerized substrates, necessitating protective interlayers. This study demonstrates a water-soluble photoalignment approach using AbA-2522 that eliminates these fabrication barriers. The water-soluble alignment material enables direct multilayer processing without layer damage while maintaining alignment quality equivalent to conventional materials. We successfully fabricate compact transmissive devices integrating liquid crystal polarization gratings with quarter-wave plates, achieving a first-order diffraction efficiency of 65.4% for 9 μm period gratings for linearly polarized incident light (λ = 457 nm). The multilayer structure exhibits highly selective polarization-dependent diffraction with efficiency ratios exceeding 10:1 between preferred and suppressed orders, eliminating external polarization control elements. Polarized optical microscopy confirms excellent alignment uniformity, while the fabrication process offers environmental benefits and reduced complexity. This approach establishes a practical pathway for advanced multilayer photonic devices critical for next-generation augmented reality systems and photonic integration, addressing fundamental challenges that have limited multilayer liquid crystal device development. Full article

Diffractive optical elements (DOEs) offer significant advantages over conventional refractive optics, particularly in non-visible spectral regions such as ultraviolet, gamma rays, and X-rays, where material limitations restrict traditional optical components. Owing to their design flexibility, DOEs enable the generation of complex beam profiles—including circular, vortex, and Airy beams—across a wide range of wavelengths. Despite their structural simplicity and compatibility with micro- and nanoscale fabrication, conventional DOEs often suffer from limited focusing efficiency, frequently requiring additional refractive lenses that introduce optical aberrations, increased system complexity, and higher cost. In this work, we present an integrated design and fabrication approach for micro-scale diffractive optical elements capable of achieving high focusing performance without reliance on supplementary optical components. A machine learning-based decision tree method is employed to generate optimized writing paths, which are subsequently fabricated using direct laser lithography. The proposed integrated DOE structures enable efficient focusing of multiple customized beam profiles within a compact and standalone optical element. This approach improves optical efficiency while maintaining low fabrication cost and system simplicity. The demonstrated integrated micro-DOEs provide a scalable and versatile platform for advanced beam shaping and focusing applications in photonics, particularly where compactness and performance are critical. Full article

Quantum imaging leverages entanglement and photon correlations to surpass classical limits in resolution and noise performance. However, its practical deployment is constrained by bulky optical setups and limited system adaptability. Metasurfaces—ultrathin, subwavelength-structured devices—offer a compact and reconfigurable solution for wavefront control in quantum light fields. This review presents recent advances in geometric-, propagation-, and hybrid-phase metasurface designs, showcasing their contributions to enhanced spatial resolution, improved visibility, and system miniaturization across applications such as ghost imaging, quantum holography, and single-photon microscopy. It also examines key challenges—including photon loss, fabrication-induced phase noise, and the lack of dynamic tunability—while outlining future directions for developing integrated, noise-resilient, and task-specific quantum imaging platforms. Full article

The transition toward Industry 4.0 requires advanced sensing platforms capable of delivering real-time, high-fidelity data under extreme industrial conditions. Thin-film sensors, leveraging both photonic and functional approaches, are emerging as key enablers of this transformation. By exploiting optical phenomena such as Fabry–Pérot interference, guided-mode resonance, plasmonics, and photonic crystal effects, thin-film photonic devices provide highly sensitive, electromagnetic interference-immune, and remotely interrogated solutions for monitoring temperature, strain, and chemical environments. Complementarily, functional thin films including oxide-based chemiresistors, nanoparticle coatings, and flexible electronic skins extend sensing capabilities to diverse industrial contexts, from hazardous gas detection to structural health monitoring. This review surveys the fundamental optical principles, material platforms, and deposition strategies that underpin thin-film sensors, emphasizing advances in nanostructured oxides, 2D materials, hybrid perovskites, and additive manufacturing methods. Application-focused sections highlight their deployment in temperature and stress monitoring, chemical leakage detection, and industrial safety. Integration into Internet of Things (IoT) networks, cyber-physical systems, and photonic integrated circuits is examined, alongside challenges related to durability, reproducibility, and packaging. Future directions point to AI-driven signal processing, flexible and printable architectures, and autonomous self-calibration. Together, these developments position thin-film sensors as foundational technologies for intelligent, resilient, and adaptive manufacturing in Industry 4.0. Full article

Studying nanoscale self-assembly in real time using external stimuli unlocks new opportunities for dynamic and adaptive materials. While electrostatic self-assembly is well-established, real-time monitoring of its structural evolution under light irradiation remains largely unexploited. In this study, we employ light-responsive azobenzene dyes (Acid Yellow 38, AY38) and pH-sensitive polyamidoamine (PAMAM) dendrimers to investigate the kinetics of electrostatic self-assembly under UV irradiation. Using a custom in situ small-angle neutron scattering (SANS) setup, we track the real-time morphological transformations of self-assembled structures with sub-minute resolution. We introduce two distinct pathways: method A (pre-irradiated cis-AY38 for controlled, slow kinetics) and method B (direct UV-induced self-assembly, fast kinetics). The results reveal that trans-cis isomerization kinetics dictate the rate of self-assembly, influencing aggregate stability, ζ-potential evolution, and final morphology. Structural analysis using dynamic and static light scattering (DLS and SLS) and SANS elucidates a transition from spherical to ellipsoidal morphologies governed by electrostatic and dipole-dipole interactions. These findings establish photoisomerization-driven self-assembly as a robust mechanism for tunable nanoscale architectures, paving the way for adaptive photonic materials, targeted drug delivery, and reconfigurable nanostructures. Full article

Over the past two decades, Light Detection and Ranging (LiDAR) technology has evolved from early National Aeronautics and Space Administration (NASA)-led airborne laser altimetry into commercially mature systems that now underpin vegetation remote sensing across scales. Continuous advancements in laser engineering, signal processing, and complementary technologies—such as Inertial Measurement Units (IMU) and Global Navigation Satellite Systems (GNSS)—have yielded compact, cost-effective, and highly sophisticated LiDAR sensors. Concurrently, innovations in carrier platforms, including uncrewed aerial systems (UAS), mobile laser scanning (MLS), Simultaneous Localization and Mapping (SLAM) frameworks, have expanded LiDAR’s observational capacity from plot- to global-scale applications in forestry, precision agriculture, ecological monitoring, Above Ground Biomass (AGB) modeling, and wildfire science. This review synthesizes LiDAR’s cross-domain capabilities for the following: (a) quantifying vegetation structure, function, and compositional dynamics; (b) recent sensor developments encompassing ALS discrete-return ${(ALS}_D)$, and ALS full-waveform $\left({ALS}_{FW}\right)$, photon-counting LiDAR (PCL), emerging multispectral LiDAR (MSL), and hyperspectral LiDAR (HSL) systems; and (c) state-of-the-art data processing and fusion workflows integrating optical and radar datasets. The synthesis demonstrates that many LiDAR-derived vegetation metrics are inherently transferable across domains when interpreted within a unified structural framework. The review further highlights the growing role of artificial-intelligence (AI)-driven approaches for segmentation, classification, and multitemporal analysis, enabling scalable assessments of vegetation dynamics at unprecedented spatial and temporal extents. By consolidating historical developments, current methodological advances, and emerging research directions, this review establishes a comprehensive state-of-the-art perspective on LiDAR’s transformative role and future potential in monitoring and modeling Earth’s vegetated ecosystems. Full article

A new family of highly uniform, cubic-shaped Cu₃VS_xSe_4−x (CVSSe; 0 ≤ x ≤ 4) nanocrystals based on earth-abundant materials with intermediate bandgaps (IB) in the visible range is reported, synthesized via a hot-injection method. The IB transitions and optical band gap of the novel CVSSe nanocrystals are investigated using ultraviolet-visible spectroscopy, revealing tunable band gaps that span the visible and near-infrared regimes. The composition-dependent relationships among the crystal phase, optical band gap, and photoluminescence properties of the novel IB semiconductors with progressive substitution of Se by S are examined in detail. High-resolution transmission electron microscopy and scanning electron microscopy characterization confirm the high crystallinity and uniform size (~19.7 nm × 17.2 nm for Cu₃VS₄) of the cubic-shaped nanocrystals. Density functional theory (DFT) calculations based on virtual crystal approximation support the experimental findings, showing good agreement in lattice parameters and band gaps across the CVSSe series and lending confidence that the targeted phases and compositions have been successfully realized. A current conversion efficiency, i.e., incident photon-to-current efficiency, of 14.7% was achieved with the p-type IB semiconductor Cu₃VS₄. These novel p-type IB semiconductor nanocrystals hold promise for enabling thin film solar cells with efficiencies beyond the Shockley–Queisser limit by allowing sub-band-gap photon absorption through intermediate-band transitions, in addition to the conventional direct-band-gap transition. Full article

We present the design and characterisation of a 4.2-megapixel, wafer-scale CMOS image sensor, achieving over 5000 frames per second at full resolution. The sensor has a pixel pitch of 58 µm square pixels, thus being as large as a full 200 mm wafer. The sensor is read out on two sides and features column-parallel programmable gain amplifiers (PGAs) as well as analogue-to-digital converters (ADCs). The array has 2052 columns and 2064 rows; 12 rows are read in parallel, so that the total number of ADCs is 24,624. The data is transmitted through 216 sub-LVDS lanes running at 1 Gbps in double data rate (DDR). Besides the row and column control, the sensor generates the necessary voltages and currents on a chip. The programming is performed through a serial-to-parallel interface (SPI). The sensor was optimised for direct detection of electrons, but it can also detect photons. Thus, it could be a good candidate for applications where high speed is needed, such as wavefront sensing. Full article

Light detection and ranging (LiDAR) has been widely used in navigation and environmental perception owing to its excellent beam directivity and high spatial resolution. Among its modalities, single-photon (photon-counting) LiDAR offers higher detection sensitivity at long ranges and under weak-return conditions and has therefore attracted considerable attention. However, this high sensitivity also introduces substantial background counts into the raw measurements; without effective filtering, downstream tasks such as image reconstruction and target recognition are hindered. In this work, a 128-line single-photon LiDAR system for port-environment perception was designed, and a histogram-based statistical filtering engineering solution was proposed. The algorithm incorporates distance-based piecewise adaptive parameterization and adjacent-channel fusion while maintaining a small memory footprint and facilitating deployment. Field experiments using datasets collected in Qingdao and Shanghai demonstrated good denoising performance at ranges up to 2.4 km. In simulation experiments using synthetic data with ground truth, an F1 score of 0.9091 was achieved by RA-ACF HSF, outperforming the baseline methods DBSCAN (0.6979) and ROR (0.7500). The proposed system and method provide a practical engineering solution for maritime navigation and port-environment perception. Full article

Focused Ion Beam (FIB) systems are increasingly utilized in nanotechnology for nanostructuring, surface modification, doping, and rapid prototyping. Recently, their potential for quantum applications has been explored, leveraging FIB’s direct-write capabilities for in situ single ion implantation, which is crucial for fabricating single photon emitters. Color centers in diamond can function as qubits and are of particular interest due to their capacity to store and transmit quantum information. While Group-IV color centers exhibit high brightness, they require low temperatures to retain coherence. However, lead-vacancy in diamond (PbV) operates at the higher end (4 K) of this temperature spectrum due to larger ground-state splitting, making them particularly interesting. In this context, our study presents results for lead (Pb)-containing alloys with eutectic points below 600 °C and results on using tantalum (Ta) and titanium (Ti) as emitter materials for a Pb liquid metal alloy ion source. We show that a standard FIB system is able to resolve the different Pb isotopes and achieve nanoscale spot sizes, as required for quantum information science applications. Full article
